Mercedes-Benz 2000 CLK 430 Operator's Manual

Mercedes-benz 2000 clk-class coupe automobile operator's manual
Hide thumbs

Advertisement

Table of Contents
CLK Coupé
CLK 430
Operator's Manual

Advertisement

Table of Contents
loading

  Also See for Mercedes-Benz 2000 CLK 430

  Related Manuals for Mercedes-Benz 2000 CLK 430

  Summary of Contents for Mercedes-Benz 2000 CLK 430

  • Page 1 CLK Coupé CLK 430 Operator’s Manual...
  • Page 2 Your Mercedes-Benz represents the efforts of many skilled engineers and craftsmen. To ensure your pleasure of ownership, and for your safety and that of your passengers, we ask you to make a small investment of your time: •...
  • Page 3 Introduction Product information Operator’s manual Where to find it 13 Trunk Reporting Safety Defects 15 Trunk lid release switch Instruments and controls Instruments and controls 18 Power seats, front Center console 20 Front head restraints Overhead control panel 21 Head restraints, rear Operation Vehicle keys 24 Heated seats...
  • Page 4: 123 Driving

    Operation Audio and telephone 123 Driving Power windows Sliding/pop-up roof 143 Control and operation of radio Interior lighting 145 transmitters Rear window sunshade 146 COMAND, radio, telephone and Sun visors 146 two-way radio Illuminated vanity mirrors 147 Maintenance Interior 147 Catalytic converter Storage compartments, armrest and cup holder Glove box...
  • Page 5 Instrument cluster display Malfunction and indicator lamps in the instrument cluster On-board diagnostic system Check engine malfunction indicator lamp Brake warning lamp Supplemental restraint system (SRS) indicator lamp Fuel reserve and fuel cap placement warning Electronic stability program(ESP) warning lamp BAS/ESP malfunction indicator lamp ABS malfunction indicator lamp Telescoping steering column –...
  • Page 6: Table Of Contents

    Vehicle care Cleaning and care of the vehicle Engine cleaning Vehicle washing Plastic and rubber parts Tar stains Window cleaning Headlamps, taillamps, turn signal lenses Wiper blade Seat belts Headliner and shelf below rear window 275 Instrument cluster Steering wheel and gear selector lever Hard plastic trim items Upholstery Paintwork, painted body components...
  • Page 7 Use of such parts and accessories could adversely affect the safety, performance or reliability of your vehicle. Please do not use them. Mercedes-Benz original parts as well as conversion parts and accessories approved by us are available at your authorized Mercedes-Benz Center where you will receive comprehensive information, also on permissible technical modifications, and where proper installation will be performed.
  • Page 8 Ignoring them could result in damage to the vehicle or personal injury to you or others. Vehicle damage caused by failure to follow instructions is not covered by the Mercedes-Benz Limited Warranty. Your vehicle may have some or all of the equipment described in this manual. Therefore, you may find explanations for optional equipment not installed in your vehicle.
  • Page 9 The Service Booklet describes all the necessary maintenance work which should be performed at regular intervals. Always have the Service Booklet with you when you take the vehicle to your authorized Mercedes-Benz Center for service. The service advisor will record each service in the booklet for you.
  • Page 10 Introduction Roadside assistance The Mercedes-Benz Roadside Assistance Program provides factory trained technical help in the event of a breakdown. Calls to the toll-free Roadside Assistance number: 1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada) will be answered by Mercedes-Benz Client Assistance Representatives 24 hours a day, 365 days a year.
  • Page 11 • gasoline may have a considerably lower octane rating, and improper fuel can cause engine damage. Certain Mercedes-Benz models are available for delivery in Europe under our European Delivery Program. For details, consult your authorized Mercedes-Benz Center or write to:...
  • Page 12 If there are any equipment details that are not shown or described in this Operator’s Manual, your authorized Mercedes-Benz Center will be glad to inform you of correct care and operating procedures. The Operator’s Manual and Service Booklet are important documents and should be kept with the vehicle.
  • Page 13 Where to find it The Operator’s Manual is divided into eight sections: • Instruments and controls: An overview of all the controls that can be operated from the driver’s seat. • Operation: Information on the vehicle’s equipment and its operation. •...
  • Page 14 If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact your authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is not handled to your...
  • Page 15 If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your retailer, or Mercedes-Benz USA, LLC.
  • Page 17 Instruments and controls Instruments and controls ... 18 Center console ...20 Overhead control panel ... 21 Contents – Instruments and controls Instruments Operation Driving and controls Instrument Practical hints Car care cluster display Technical Index data...
  • Page 18 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instruments and controls Instruments and controls...
  • Page 19 For more detailed descriptions see Index on page For adjustment of air outlets, refer to automatic climate control, see page 116 . Side air outlet, adjustable Air volume control for side air outlet Exterior lamp switch, see page 11 0 Parking brake release, see page 184 Parking brake pedal, see page 184 Hood lock release, see page 233...
  • Page 20 Instruments Operation Driving and controls Instruments and controls Center console Instrument Practical hints cluster display ESP control switch, see page 201 Program mode selector switch, see page 182 Switch for rear window sunshade, see page 146 Airbag Off indicator lamp, see page 212 Left power window switch, see page 141 Trunk lid release switch, see page 40 Mirror adjustment switch, see page 75...
  • Page 21 Overhead control panel Instruments and controls Instruments Operation Driving and controls Interior lighting, see page 145 Sliding/pop-up roof, see page 143 Tele Aid (emergency call system), see page 166 Hands-free microphone for Tele Aid, telephone and voice recognition system. Rear view mirror, see page 74 Garage door opener, see page 157 P82.00-2049-27 Instrument...
  • Page 22 Operation Vehicle keys 24 Front head restraints Start lock-out 26 Head restraints, rear General notes on the central locking system 26 Central locking system 27 Multicontour seat Radio frequency and infrared remote control 27 Locking and unlocking 29 Seat belts and integrated restraint system Choosing global or selective mode on remote control 29 Opening the trunk...
  • Page 23 Engine oil consumption 109 Glove box Exterior lamp switch 110 Ashtrays Night security illumination 111 Lighter Headlamp cleaning system 112 Enlarged cargo area – split folding rear Combination switch 113 Loading instructions Hazard warning flasher switch 115 Cargo tie down rings Automatic climate control 116 Parcel net in front passenger footwell Operation Audio and telephone...
  • Page 24 Instruments Operation Driving and controls Central locking system Vehicle keys Included with your vehicle are: • 2 electronic main keys with integrated radio frequency and infrared remote controls plus removable mechanical key. The locking tabs for the mechanical key portion of the two electronic main keys are a different color to help distinguish it.
  • Page 25 The mechanical key (2) can be removed b y sliding it out of the remote control. To do so, move lock (3) in direction of arrow and slide the mechanical key (2) in direction of arrow ( 5 ). When using the mechanical key (2) for lock operations, it can be removed by sliding it out of the remote control.
  • Page 26 Your vehicle is equipped with a theft deterrent locking system requiring a special key manufacturing process. For security reasons, replacement keys can only be obtained from your authorized Mercedes-Benz Center. Start lock-out Important! Removing the electronic key from the steering lock activates the start lock-out.
  • Page 27 Instruments Operation Driving and controls Central locking system Central locking system Radio frequency and infrared remote control The electronic main key has an integrated radio frequency and infrared remote control. Due to the extended operational range of the remote control, it could be possible to unintentionally lock or unlock the vehicle by pressing the transmit button.
  • Page 28 Infrared receiver in driver’s door handle Infrared receiver in passenger door handle Central locking system Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
  • Page 29 Instruments Operation Driving and controls Central locking system Locking and unlocking with remote control Unlocking: Press transmit button Œ. All turn signal lamps blink once to indicate that the vehicle is unlocked. The remote control can be programmed for two kinds of unlocking modes (see below): Selective unlocking mode –...
  • Page 30 Opening the trunk The trunk lid will swing open automatically. You should always make sure there is sufficient clearance. A minimum height clearance of 5.9 ft. (1.8 m) is required to open the trunk lid. Press transmit button Š until trunk lid is open. Important! Do not place remote control in trunk since trunk is locked when the lid is closed if the vehicle is centrally...
  • Page 31 Instruments Operation Driving and controls Central locking system To close: Continue to press transmit button ‹ after locking the vehicle. The windows and sliding/pop-up roof begin to close after approx. 1 second. To interrupt closing procedure, release transmit button. Warning! Never operate the windows or sliding/pop-up roof if there is the possibility of anyone being harmed by the opening or closing procedure.
  • Page 32 Panic button To activate press and hold button (1) for at least one second. An audible alarm and blinking exterior lamps will operate for approximately 3 minutes. To deactivate press button (1) again, or insert electronic key in steering lock. Central locking system Instruments Operation...
  • Page 33 Instruments Operation Driving and controls Central locking system Doors Opening – pull handle Unlocking driver’s door Locking driver’s door Individual door from inside: • Push lock button down to lock. • Pull inside door handle to unlock. Instrument Practical hints Car care cluster display Important!
  • Page 34 If the vehicle has previously been locked from the outside, opening a door from the inside will trigger the alarm. When opening a door while the central locking system is in the: • selective unlocking mode, only that individual door is unlocked.
  • Page 35 Instruments Operation Driving and controls Central locking system Central locking switch Locking Unlocking The central locking switch is located in the center console. Instrument Practical hints Car care cluster display The doors and trunk can only be locked with the central locking switch, if both doors are closed.
  • Page 36 Automatic central locking The central locking switch also operates the automatic central locking. With the automatic central locking system activated, the doors and trunk are locked at vehicle speeds of approx. 9 mph (15 km/h) or more. The fuel filler flap remains unlocked.
  • Page 37 Instruments Operation Driving and controls Central locking system Important! When towing the vehicle, or with the vehicle on a dynamometer test stand, please, note the following: With the automatic central locking activated and the electronic key in steering lock position 2, the vehicle doors will lock if the left front wheel as well as the right rear wheel spin at vehicle speeds of approx.
  • Page 38 Trunk When the trunk is separately locked, it remains locked when centrally unlocking the vehicle. To deny any unauthorized person access to the trunk, lock it separately with the mechanical key. Leave only the electronic main key less its mechanical key with the vehicle.
  • Page 39 Notes: In case of a malfunction in the central locking system the trunk can be unlocked individually. To unlock and open the trunk lid, turn mechanical key to position 1, hold and push to open. If the fuel filler flap cannot be opened, see page 268. Important! Do not place mechanical key inside trunk, since trunk is locked when the lid is closed if the vehicle has been...
  • Page 40 Instruments Operation Driving and controls Central locking system Trunk lid release switch The switch is located on the center console. Instrument Practical hints Car care cluster display A minimum height clearance of 5.9 ft. (1.8 m) is required to open the trunk lid. To open the trunk, the vehicle must be at standstill.
  • Page 41 Instruments Operation Driving and controls Antitheft alarm system Antitheft alarm system Indicator lamp in switch located in center console Instrument Practical hints Car care cluster display The antitheft alarm is automatically armed or disarmed with the remote control by locking or unlocking the vehicle.
  • Page 42 The alarm will last approximately 3 minutes in form of flashing exterior lamps. At the same time an alarm will sound for 30 seconds. The alarm will stay on even if the activating element (a door, for example) is immediately closed.
  • Page 43 Instruments Operation Driving and controls Tow-away alarm Tow-away alarm The switch is located in the center console. Press to switch off Indicator lamp Once the alarm system has been armed, the exterior vehicle lamps will flash and an alarm will sound when someone attempts to raise the vehicle.
  • Page 44 Power seats, front Warning! Do not adjust the driver’s seat while driving. Adjusting the seat while driving could cause the driver to lose control of the vehicle. Never ride in a moving vehicle with the backrest reclined. Sitting in an excessively reclined position can be dangerous.
  • Page 45 Instruments Operation Driving and controls Seats The slide switches are located in each door. We recommend to adjust the power seat in the following order: Seat, up/down Press the switch (up/down direction) until comfortable seating position with still sufficient headroom is reached. Seat, fore/aft Press the switch (fore/aft direction) until a comfortable seating position is reached that still...
  • Page 46 Memory storing and recalling Memory button Position buttons Seats Instruments Operation Driving and controls Synchronizing power seats and head restraints If the power supply was interrupted (battery disconnected or empty), the power seats and head restraints are no longer adjusted automatically. To resynchronize the adjustment feature, turn electronic key in steering lock to position 2, move the seat completely forward and the head restraint fully...
  • Page 47 Instruments Operation Driving and controls Seats Storing Three sets of seat/head restraint and exterior rear view mirror positions may be programmed into memory. After the seat/head restraint and exterior rear view mirrors are positioned, push memory button (6), release, and within 3 seconds push position button “1”. A second and third set of positions for the same seat/ head restraint and exterior rear view mirrors can be programmed into memory by pushing first memory...
  • Page 48 Driving and controls Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart which operates with the BabySmart installed in the vehicle to deactivate the passenger side front airbag when it is properly installed.
  • Page 49 Instruments Operation Driving and controls Seats Front head restraints Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint to support the back of the head approximately at ear level. Do not drive the vehicle without the seat head restraints.
  • Page 50 Instruments Operation Driving and controls Seats Head restraints, rear Folding head restraints backward (with electronic key in steering lock position 2): Press symbol-side of rocker switch to release the head restraints. The head restraints will then fold backward for increased visibility. Placing head restraints upright: Pull head restraint forward until it locks in position.
  • Page 51 Backrest Release lever Folding forward: Lift release lever (1) and fold backrest forward. The seat will automatically slide forward and the head restraint will move down. Folding back: Lift release lever (1) and fold backrest back. The seat and head restraint return to their previous positions. To interrupt the procedure, activate the power seat switch.
  • Page 52 Instruments Operation Driving and controls Seats Multicontour seat (optional) We recommend to adjust the multicontour seat in the following order: Seat cushion depth Backrest bottom Backrest center Side bolster adjustment Instrument Practical hints cluster display The seat cushion movement and amount of backrest cushion height and curvature can be continuously varied with regulators (1, 2 and 3) after turning the electronic key in steering lock to position 2.
  • Page 53 Heated seats (front) The front seat heater switches are located in the center console. The front seat heaters can be switched on with the electronic key in steering lock positions 1 or 2. Seats Instruments Operation Driving and controls Press switch to turn on seat heater: Normal seat heating mode.
  • Page 54 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Notes: When in operation, the seat heater consumes a large amount of electrical power. It is not advisable to use the seat heater longer than necessary. The seat heaters may automatically switch off if too many power consumers are switched on at the same time, or if the battery charge is low.
  • Page 55 Driving and controls Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart which operates with the BabySmart installed in the vehicle to deactivate the passenger front airbag when it is properly installed.
  • Page 56 Instruments Operation Driving and controls Restraint systems Warning! Never ride in a moving vehicle with the backrest reclined. Sitting in an excessively reclined position can be dangerous. You could slide under the seat belt in a collision. If you slide under it, the belt would apply force at the abdomen or neck.
  • Page 57 Fastening of seat belts Latch plate Buckle Release button Restraint systems Instruments Operation Driving and controls Push latch plate (1) into buckle (2) until it clicks. Do not twist the belt. A twisted seat belt may cause injury. To help avoid severe or fatal injuries, the lap belt must be positioned as low as possible on your hips and not across the abdomen.
  • Page 58 Instruments Operation Driving and controls Restraint systems Tighten the lap portion to a snug fit by pulling shoulder portion up. The shoulder portion of the seat belt must be pulled snug and checked for snugness immediately after engaging it. Adjust seat belt so that shoulder portion is located as close as possible to the middle of your shoulder (it should not touch the neck).
  • Page 59 Unfastening of seat belts Push the release button (3) in the belt buckle (2). Allow the retractor to completely rewind the seat belt by guiding the latch plate (1). Operation The inertia reel stops the belt from unwinding during sudden vehicle stops or when quickly pulling on the belt.
  • Page 60 Instruments Operation Driving and controls Restraint systems • Never wear the shoulder belt under your arm, against your neck or off your shoulder. In a crash, your body would move too far forward. That would increase the chance of head and neck injuries.
  • Page 61 Warning! USE CHILD RESTRAINTS PROPERLY. Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart installed in the vehicle to deactivate the passenger front airbag when it is properly installed.
  • Page 62 BabySmart airbag deactivation system Special BabySmart compatible child seats, designed for use with the Mercedes-Benz system and available at any authorized Mercedes-Benz Center are required for use with the BabySmart airbag deactivation system. With the special child seat properly installed, the passenger front airbag will not deploy.
  • Page 63 Supplemental restraint system (SRS) Airbags are intended as a supplement to seat belts. Airbags alone cannot protect as well as airbags plus seat belts in impacts for which the airbags were designed to operate, and do not afford any protection whatsoever in crashes for which the airbags are not designed to deploy.
  • Page 64 Instruments Operation Driving and controls Restraint systems Airbags Driver airbag The driver airbag is located in the steering wheel hub. Instrument Practical hints cluster display Front passenger airbag The passenger front airbag is located in the dash board ahead of the front passenger. Technical Car care data...
  • Page 65 0 to positions 1 or 2, malfunctions in the crash-sensor are detected and indicated (the “SRS” indicator lamp stays on longer than 4 seconds or does not come on). Have the system checked at your authorized Mercedes-Benz Center immediately. Instrument Practical hints Car care cluster display...
  • Page 66 Instruments Operation Driving and controls Restraint systems In the operational mode, after the indicator lamp has gone out following the initial check, interruptions or short circuits in the airbag ignition circuit and in the driver and front passenger seat belt buckle harnesses, and low voltage in the entire system are detected and indicated.
  • Page 67 Important! Airbags are designed to activate only in certain frontal (front airbags) impacts, or side (side impact airbags) impacts which exceed preset thresholds. Only during these types of impacts, if of sufficient severity to meet the deployment thresholds, will they provide their supplemental protection. The driver and passenger should always wear their seat belts, otherwise it is not possible for the airbags to provide their intended supplemental protection.
  • Page 68 If you have any problems, please see your authorized Mercedes-Benz Center. • Do not lean with your head or chest close to the steering wheel or dashboard.
  • Page 69 • Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the vehicle to deactivate the passenger front airbag when it is properly installed.
  • Page 70 “SRS” inoperative or causing unintended airbag deployment. Work on the “SRS” must therefore only be performed by an authorized Mercedes-Benz Center. • For your protection and the protection of others, when scrapping the airbag unit or emergency tensioning retractor, our safety instructions must be followed.
  • Page 71 Car care cluster display Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart which operates with the BabySmart installed in the vehicle to deactivate the passenger front airbag when it is properly installed.
  • Page 72 Instruments Operation Driving and controls Restraint systems Children too big for child restraint systems must ride in back seats using regular seat belts. Position shoulder belt across chest and shoulder, not face or neck. A booster seat may be necessary to achieve proper belt positioning for children from 41 lbs.
  • Page 73 Adjusting telescoping steering column Warning! Do not adjust the steering wheel while driving. The telescoping adjustment must be locked while driving. Adjusting the steering wheel while driving, or driving without the telescoping adjustment locked could cause the driver to lose control of the vehicle.
  • Page 74 Inside rear view mirror Manually adjust the mirror. Use your inside mirror to determine the size and distance of objects seen in the passenger side convex mirror. Antiglare night position With the electronic key in steering lock position 2, the mirror reflection brightness responds to changes in light sensitivity.
  • Page 75 Exterior rear view mirrors The switch is located on the center console. Turn electronic key in steering lock to position 2. First select the mirror to be adjusted – press button: % Left mirror & Right mirror To adjust, toggle the switch forward, backward or to either side.
  • Page 76 Instruments Operation Driving and controls Rear view mirrors Warning! In the case of an accident liquid electrolyte may escape the mirror housing when the mirror glass breaks. Electrolyte has an irritating effect. Do not allow the liquid come into contact with eyes, skin, clothing, or respiratory system.
  • Page 77 Parking position The passenger-side exterior mirror can be adjusted and programmed to assist the driver during parking maneuvers (e.g. to observe the curb or other objects close to the vehicle). With electronic key in steering lock position 2, and the exterior rear view mirror switch in the passenger side position, the passenger-side mirror will be turned downward when placing the gear selector lever in “R”...
  • Page 78 Instrument cluster...
  • Page 79 Push buttons V and W for intensity of instrument lamps, see page 81 Push button J for resetting trip odometer, see page 85, or multifunction indicator see page Coolant temperature gauge, see page 82 Fuel gauge with reserve and fuel cap placement warning lamp, see page 210 Outside temperature indicator, see page 82 Left turn signal indicator lamp, see combination...
  • Page 80 Instruments Operation Driving and controls Instrument cluster Indicator lamps in the instrument cluster High beam ABS malfunction, see page 211 Brake fluid low (except Canada), BRAKE Parking brake engaged, see page 217 Brake fluid low (Canada only), Parking brake engaged, see page 217 BAS malfunction, see page 196 ESP malfunction, see page 200 ESP.
  • Page 81 Activating instrument cluster display The instrument cluster is activated by: • Opening the door. • Pressing button J, V or W on the instrument cluster. • Turning the electronic key in steering lock to position 1 or 2. • Switching on the exterior lamps. Display illumination The display for temperature, odometer, multifunction indicator, FSS indicator and clock is illuminated briefly...
  • Page 82 The engine should not be operated with the coolant temperature in the red zone. Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty. Warning! • Driving when your engine is badly overheated can cause some fluids which may have leaked into the engine compartment to catch fire.
  • Page 83 Avoid this engine speed, as it may result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. To help protect the engine, the fuel supply is interrupted if the engine is operated within the red marking.
  • Page 84 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Multifunction steering wheel, multifunction display...
  • Page 85 Depending on your vehicle’s equipment, you may use the buttons on the multifunction steering wheel to call up, control and set the following systems in the multifunction display: Trip odometer and main odometer, see page 88 Flexible service system (FSS), see page 105 Engine oil level indicator, see page 108 Audio systems, see page 89 Radio, see page 89...
  • Page 86 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display 120 140 20km/h Multifunction steering wheel Multifunction display Instrument Practical hints cluster display Turn the electronic key in steering look to position 1 or 2. Press button: è for next system ÿ...
  • Page 87 Press the è or ÿ button repeatedly until the required system is displayed. Pressing the è button advances the display to the next system. Pressing the ÿ button returns the display to the previous system. You may call up additional displays in some systems by pressing the j or k button.
  • Page 88 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Trip and main odometer, vehicle speed, FSS and engine oil level indicator Instrument Practical hints Car care cluster display Trip odometer and main odometer See page 8 3 for instructions on resetting the trip odometer.
  • Page 89 Audio systems Radio Multifunction steering wheel, multifunction display Instruments Operation Driving and controls Audio system is switched off. The radio is switched on. Wave band setting and memory location number, where appropriate. Station frequency. This only appears when “MEMORY” rather than “FREQUENCY”...
  • Page 90 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display CD player (optional) Instrument Practical hints Car care cluster display Audio system is switched off. The CD player is switched on. The number of the CD currently playing is displayed if you are using a CD changer.
  • Page 91 Cassette player Multifunction steering wheel, multifunction display Instruments Operation Driving and controls Audio system is switched off. The cassette player is switched on. Side being played. The radio must be switched on. The cassette player must be switched on. Press the è or ÿ button repeatedly until display (2) appears.
  • Page 92 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Telephone Telephone book Instrument Practical hints Car care cluster display The telephone is switched off. The vehicle is currently outside the transmitter or receiver range. The telephone is ready for use. Name selected from the telephone book.
  • Page 93 The telephone must be switched on. Press the è or ÿ button repeatedly until the display (3) appears. Refer to the separate telephone instruction manual. Pressing j or k “browses” alphabetically forwards or backwards through the telephone book, providing it was previously downloaded. See telephone operator’s manual for details concerning downloading.
  • Page 94 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Redialing Instrument Practical hints Car care cluster display The telephone is ready for use. Number or name stored in the redial memory. Number in the redial memory – redialing has commenced.
  • Page 95 The telephone must be switched on. Press the è or ÿ button repeatedly until the display (1) appears. Pressing the í button activates the redial memory and the most recently dialed number is displayed. Pressing the j or k button “browses” forwards or backwards through the redial memory.
  • Page 96 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Incoming call The telephone must be switched on. Instrument Practical hints Car care cluster display “CALL” — you are being called Press the í button to answer the call. Press the ì button to hang up or if you do not wish to answer the incoming call.
  • Page 97 Navigation system (optional) Multifunction steering wheel, multifunction display Instruments Operation Driving and controls The navigation system is switched off. The navigation system is switched on but no destination has been specified. The navigation system is switched on and destination guidance is active. Press the è...
  • Page 98 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Trip computer Instrument Practical hints Car care cluster display “AFTER START” – trip odometer records distance from first engine start after more than five hours of electronic key not being in steering lock position 2 “AFTER RESET”...
  • Page 99 Press the button è or ÿ repeatedly until the display (1) appears. Press the j or k button until the display for trip odometer memory “AFTER START” (1) and “AFTER RESET” (2), or the display (3) for estimated driving range remaining and fuel tank contents appears.
  • Page 100 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Malfunction message memory Instrument Practical hints Car care cluster display There are no messages stored in the system Number of messages stored in the system Press the è or ÿ button repeatedly until the malfunction message memory (1 or 2) is displayed.
  • Page 101 Mercedes-Benz Center to address the malfunction and warning messages. See page 213. Instrument Practical hints...
  • Page 102 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Individual settings...
  • Page 103 Preliminary display of the individual settings “SET TIME HOURS” (Only vehicles without COMAND) “SET TIME MINUTES” (Only vehicles without COMAND) “12/24 HOURS” – the unit set is displayed in the instrument cluster (Only vehicles without COMAND) “TEMP. INDICATOR” – the unit set is displayed in the outside temperature display in the instrument cluster and in the automatic air conditioner display “TEXT”...
  • Page 104 Instruments Operation Driving and controls Multifunction steering wheel, multifunction display Press the è or ÿ button repeatedly until the individual setting preliminary display (1) appear. Press the j or k button until the required setting menu (2 to 8) is displayed. Pressing the æ...
  • Page 105 Flexible service system (FSS) (service indicator) 120 140 20km/h The FSS permits a flexible service schedule that is directly related to the operating conditions of the vehicle. The symbol 9 or ½ appears together with a message in the multifunction indicator prior to the next suggested service.
  • Page 106 Any such days not counted by the FSS can be added by your Mercedes-Benz Center. The interval between services is determined by the type of driving for which the vehicle is used. For example,...
  • Page 107 Following a completed A or B service the Mercedes-Benz Center sets the counter mileage to 10 000 miles (Canada: 15 000 km) and 365 days. The counter can also be set by any individual. To do so: Turn the electronic key in steering lock to position 2.
  • Page 108 Instruments Operation Driving and controls Engine oil level indicator Engine oil level indicator To check the engine oil level, park vehicle on level ground, with engine at normal operational temperature. Check oil level approximately 5 minutes after stopping the engine, allowing for the oil to return to the oil pan. Instrument Practical hints Car care...
  • Page 109 Excessive oil must be siphoned or drained off. It could cause damage to the engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. The message “PERF. SERV. ON TIME” (perform service [engine oil level check] on time) will be displayed if a proper oil level check cannot be performed.
  • Page 110 Instruments Operation Driving and controls Exterior lamp switch Exterior lamp switch D Off C Parking lamps (also side marker lamps, taillamps, license plate lamps, instrument panel lamps) Canada only: When the engine is running, the low beam is additionally switched on. Instrument Practical hints Car care...
  • Page 111 When exiting the vehicle after driving with the exterior lamps on, they switch on again for added illumination for approximately 30 seconds after closing the last door. The lamp-on time period can be changed at your Mercedes-Benz Center. Instrument Practical hints Car care...
  • Page 112 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Headlamp cleaning system Headlamp cleaning system (optional) The switch is located in the center console. The headlamp washer can be activated with the electronic key in steering lock position 2. Briefly press symbol side of switch.
  • Page 113 Combination switch Low beam (exterior lamp switch position B) High beam (exterior lamp switch position B) Combination switch Instruments Operation Driving and controls High beam flasher (high beam available independent of exterior lamp switch position) Turn signals, right Turn signals, left To signal minor directional changes, such as changing lanes on a highway, move combination switch to the point of resistance only and hold it there.
  • Page 114 Instruments Operation Driving and controls Combination switch Control for windshield wiper/washer system: Push briefly for single wipe without adding washer fluid (use only when windshield is wet). Push past detent and hold to activate wiper and washer. Windshield wiper Instrument Practical hints cluster display 0 Wiper off...
  • Page 115 Windshield wiper smears If the windshield wiper smears the windshield, even during rain, activate the washer system as often as necessary. The fluid in the washer reservoir should be mixed in the correct ratio . Blocked windshield wiper If the windshield wiper becomes blocked (for example, due to snow), switch off the wiper.
  • Page 116 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Automatic climate control P83.40-2156-29...
  • Page 117 Air volume control for center air outlets, turn wheel up to open. Air volume control for side air outlet. To open air outlets: Turn wheel to position i. Center air outlet, adjustable Side air outlet, adjustable Display and controls The system is always at operational readiness, except when manually switched off.
  • Page 118 Instruments Operation Driving and controls Automatic climate control Display and controls Press the desired button to activate, indicator lamp is on while activated. U Automatic mode f Raise temperature g Lower temperature Instrument Practical hints cluster display P Defrost O Air recirculation F Rear window defroster b Air distribution, manual S Economy mode...
  • Page 119 Economy The function of this setting corresponds to the automatic mode. However, because the air conditioning compressor will not engage (fuel savings), it is not possible to air condition in this setting. Press S button to activate. Press S button once again to return to previous setting.
  • Page 120 Instruments Operation Driving and controls Automatic climate control Rear window defroster Turn electronic key in steering lock to position 2. To select, press F button. To cancel, press F button again. Notes: Heavy accumulation of snow and ice should be removed before activating the defroster.
  • Page 121 Air recirculation This mode can be selected to temporarily reduce the entry of annoying odors or dust into the vehicle’s interior. Outside air is not supplied to the vehicle’s interior. To select, press O button. To cancel, press O button again. The system will automatically switch from recirculated air to fresh air •...
  • Page 122 Instruments Operation Driving and controls Automatic climate control Dust filter Nearly all dust particles and pollen are filtered out before outside air enters the passenger compartment through the air distribution system. Note: Keep the air intake grille in front of windshield free of snow and debris.
  • Page 123 Audio and telephone, operation These instructions are intended to help you become acquainted with your Mercedes-Benz vehicle radio. They contain useful tips and a detailed description of the user functions. Warning! In order to avoid distraction which could lead to an...
  • Page 124 Instruments Operation Driving and controls Audio system Operating and display elements On/off, volume, see page 127 Telephone mode selector, see page 138 Seek, see page 129, 132 and 136 Radio mode selector, see page 129 Tune, see page 129 and 130 Fast forward/reverse, see page 133 and 136 Instrument Practical hints...
  • Page 125 Soft keys for radio band selection, see page 129 tone controls, see page 127 scan, see page 130 Tape eject, see page 132 Tape track select, see page 132 Dolby, see page 133 CD Random/repeat, see page 137 Tape mode selector, see page 131 Anti-theft system If the power supply to the radio has been interrupted,...
  • Page 126 Instruments Operation Driving and controls Audio system Entering the code number Switch on the radio. “CODE” will appear on the display. Using the buttons on the alpha-numeric keypad, enter the five digit code. Confirm by pressing the “OK” key. If an incorrect code has been entered and confirmed, “CODE”...
  • Page 127 Operation Switching on and off Press the control knob The radio is switched off when the ignition key is turned to position 0 or removed from the ignition. The radio is switched on again when the ignition key is turned to position 1 or 2.
  • Page 128 Instruments Operation Driving and controls Audio system Fader Press the AUD key repeatedly until “FADER” appears on the display. Press the “R” key to move the sound to the rear speakers or the “F” key to move the sound to the front speakers. Balance Press the AUD key repeatedly until “BALANCE”...
  • Page 129 Radio mode Selecting radio mode Press button. Selecting the band Press the key located below the desired band. The band selected is shown in the top line of the display. Frequency ranges: Audio system Instruments Operation Driving and controls Manual tuning The first three tuning steps will take place without muting.
  • Page 130 Instruments Operation Driving and controls Audio system Scan tuning Press the SC key. Each strong receivable station on the band selected will be tuned in for 8 seconds. The first scan will tune only the stations with a high signal strength. The second scan will tune every receivable station.
  • Page 131 Cassette mode Note: Vehicles equipped with the COMAND system do not come with a factory installed cassette mechanism. A standard 1/8” stereo phono plug for auxiliary audio input (located in glove box) is provided for connection of a portable battery operated cassette player or any other portable device which uses a headphone output.
  • Page 132 Instruments Operation Driving and controls Audio system Cassette eject Press the eject (EJ) key. The display will fold down and the cassette will be ejected. Remove the cassette, then fold the display back up manually. The radio will switch back to radio mode automatically. Note: The cassette will not be ejected when the radio is switched off.
  • Page 133 Fast forward/reverse Press the “FORWARD” will appear on the display and fast forward will start. Press the “REWIND” will appear on the display and fast reverse will start. Fast forward/reverse is stopped by pressing the same button again, or it will stop automatically at the beginning or the end of the tape.
  • Page 134 CD mode General notes on CD mode Should excessive temperatures occur while in CD mode, “TEMP HIGH” will appear in the display and muting will take place. The unit will then switch back to radio mode until the temperature has decreased to a safe operating level.
  • Page 135 Instruments Operation Driving and controls Audio system CD changer installed CD changer CD magazine CD tray If a CD changer is installed, it can be operated from the front control panel of the radio. A loaded magazine must be installed for CD playing. 1 Optional equipment Instrument Practical hints...
  • Page 136 If there is no CD in the selected magazine slot, “NO CD” and the corresponding slot number will be displayed (e.g.“NO CD3”). After the last track on a CD has been played, the next CD will automatically be selected and played.
  • Page 137 Instruments Operation Driving and controls Audio system Random play/repeat function The tracks of the current CD are played in random order when the random feature (RDM) is selected. Press the RDM key to switch on, and press RDM again to switch off.
  • Page 138 Telephone operation Various functions of the Mercedes-Benz integrated cellular telephone can be performed and displayed via the car radio. Further instructions for operating the car telephone can be found in the operation guide for the cellular telephone Switching the telephone on and off Switching on: Press the button, “TEL”...
  • Page 139 Instruments Operation Driving and controls Audio system Switching between name search and number search Press ABC key - Name search Press NUM key - Number search Searching and selecting phone book entries by name Press the ABC key. The current name is shown on the display.
  • Page 140 Failure of one of the components can lead to malfunctions of the other components. Please contact your authorized Mercedes-Benz Center or call 1-800-FOR-MERCedes for more information in the event of a malfunction. 1 Optional equipment...
  • Page 141 Instruments Operation Driving and controls Interior equipment Power windows Power window switches located on center console Instrument Practical hints Car care cluster display Turn electronic key in steering lock to position 1 or 2. Press switch in to resistance point: k to open j to close Release switch when window is in desired position.
  • Page 142 Express opening and closing of front door windows Press switch k or j past resistance point and release — window opens or closes completely. To interrupt procedure, briefly press k or j. If the upward movement of the window is blocked during the closing procedure, the window will stop during the last few inches before closure and open slightly.
  • Page 143 Instruments Operation Driving and controls Interior equipment Sliding /pop-up roof (optional) to slide roof open to slide roof closed to raise roof at rear to lower roof at rear Instrument Practical hints Car care cluster display Turn electronic key in steering lock to position 1 or 2. The switch is illuminated when the exterior lamps are switched on (except standing lamps).
  • Page 144 With the roof closed or tilted open, a screen can be slid into the roof opening to guard against sun rays. When sliding the roof open, the screen will also retract. Interior equipment Instruments Operation Driving and controls Synchronizing sliding/pop-up roof If the power supply was interrupted (battery disconnected or low), or if the sliding/pop-up roof is blocked during closing/opening procedure, the system...
  • Page 145 Instruments Operation Driving and controls Interior equipment Interior lighting Automatic interior lighting Press once and the automatic interior lighting is activated. Interior lamps are switched on, and off (soft fade) delayed, when unlocking or locking the vehicle, or when opening or closing a door. However, there will be no (soft fade) delay when the electronic key is in steering lock position 2.
  • Page 146 Rear window sunshade (optional) The switch is located on the center console. Turn electronic key in steering lock to position 1 or 2. Hold to raise Hold to lower Always raise the sunshade fully for its support against the window frame. Interior equipment Instruments Operation...
  • Page 147 Instruments Operation Driving and controls Interior equipment Illuminated vanity mirrors With the visor engaged in its inner mounting, the lamp is switched on by opening the cover. Warning! Do not use the vanity mirror while driving. The lamp goes out automatically after approximately 5 minutes.
  • Page 148 Glove box Unlocking: Turn mechanical key to vertical position and remove. Locking: Turn mechanical key to the right and remove. Opening: Pull on handle. Interior equipment Instruments Operation Driving and controls Storage compartments in center console P68.00-2067-26 To open compartment in armrest: Press button (4) and lift lid.
  • Page 149 Instruments Operation Driving and controls Interior equipment Cup holder in center console To open cup holder: Briefly press button (7). The cup holder opens automatically. To store cup holder: Push button (7) down until cup holder engages. Close cover . Instrument Practical hints Car care...
  • Page 150 Instruments Operation Driving and controls Interior equipment Ashtray Center console, front By touching the bottom of the cover lightly, the ashtray opens automatically. Instrument Practical hints Car care cluster display Prior to removing the ashtray insert, move the gear selector lever to position “N”. Warning! Remove front ashtray only with vehicle standing still.
  • Page 151 Rear Seats To remove ashtray: Push cover (2) down and pull out insert (3). To install ashtray: Push ashtray down to engage. Interior equipment Instruments Operation Driving and controls Lighter Turn electronic key in steering lock to position 1 or 2. Push in lighter (1);...
  • Page 152 Enlarged cargo area – split folding rear seat backrest Locking handle, left backrest Locking handle, right backrest Pass-through The two sections can be folded down separately to enlarge the cargo area. Interior equipment Instruments Operation Driving and controls Indicator, right backrest lock, visible in unlocked position Indicator, left backrest lock, visible in unlocked position...
  • Page 153 Instruments Operation Driving and controls Interior equipment Fold down: Pull locking handle and fold backrest forward. Set up: Pull backrest up until it locks in its upright position. Check for secure locking by pushing and pulling on the backrest. Warning! Always lock backrest in its upright position when rear seat bench is occupied by passengers, cargo is being carried in the trunk, or the extended cargo...
  • Page 154 The handling characteristics of a fully loaded vehicle depend greatly on the load distribution. It is therefore recommended to load the vehicle according to the illustrations shown, with the heaviest items being placed towards the front of the vehicle. Always place items being carried against front or rear seat backrests, and fasten them as securely as possible.
  • Page 155 Instruments Operation Driving and controls Interior equipment Cargo tie down rings Ring Carefully secure cargo by applying even load on all four rings with rope of sufficient strength to hold down the cargo. Instrument Practical hints Car care cluster display Parcel net in front passenger footwell A small convenience parcel net is located in the front passenger footwell.
  • Page 156 Cellular telephone The vehicle is prepared for the installation of a cellular telephone. For further information and installation contact your authorized Mercedes-Benz Center. Warning! Some jurisdictions prohibit the driver from using a cellular telephone while driving a vehicle. Whether...
  • Page 157 Certain types of garage door openers are incompatible with the integrated opener. If you should experience difficulties with programming the transmitter, contact your authorized Mercedes-Benz Center, or call Mercedes-Benz Client Assistance Center (in the USA only) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100. Technical...
  • Page 158 For operation in the USA only: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 159 Instruments Operation Driving and controls Garage door opener Rolling code programming: To train a garage door opener (or other rolling code devices) with the rolling code feature, follow these instructions after completing the “Programming” portion of this text. (A second person may make the following training procedures quicker and easier.) 1.
  • Page 160 Operation of remote control: 1. Turn electronic key in steering lock to position 1 or 2. 2. Select and press the appropriate button to activate the remote controlled device. The integrated remote control transmitter continues to send the signal as long as the button is pressed –...
  • Page 161 Driving Control and operation of radio transmitters COMAND, radio, telephone and two-way radio Maintenance Catalytic converter Emission control Tele Aid Steering lock Starting and turning off the engine Automatic transmission Parking brake Driving instructions Drive sensibly – save fuel Drinking and driving Pedals Power assistance Brakes...
  • Page 162 Instruments Operation Driving and controls Control and operation of radio transmitters Control and operation of radio transmitters COMAND, radio and telephone Warning! Please do not forget that your primary responsibility is to drive the vehicle. Only operate the COMAND (Cockpit Management and Data System), radio or telephone conditions permit.
  • Page 163 See Flexible service system (FSS) in Index. We strongly recommend that you have your vehicle serviced by your authorized Mercedes-Benz Center, in accordance with the Service Booklet at the times called for by the FSS.
  • Page 164: Catalytic Converter

    Driving and controls Catalytic converter Catalytic converter Your Mercedes-Benz is equipped with monolithic type catalytic converters, an important element in conjunction with the oxygen sensors to achieve substantial control of the pollutants in the exhaust emissions. Keep your vehicle in proper operating condition by following our recommended maintenance instructions as outlined in your Service Booklet.
  • Page 165: Emission Control

    Mercedes- Benz authorized center technicians. Engine adjustments should not be altered in any way. Moreover, the specified service jobs must be carried out regularly according to Mercedes-Benz servicing requirements. For details refer to the Service Booklet. Emission control Instruments...
  • Page 166: Tele Aid

    Instruments Operation Driving and controls Tele Aid Tele Aid The electronic key in the steering lock must be in position 1 or 2 for the Tele Aid to be operational. Important! The initial activation of the Tele Aid system may only be performed by completing the subscriber agreement and placing an acquaintance call using the “SOS”...
  • Page 167 Instruments Operation Driving and controls Tele Aid The Tele Aid system is available if: • it has been activated and is operational. Activation requires a subscription for monitoring services and cellular air time, • the relevant cellular phone network and GPS signals are available and pass the information on to the response center.
  • Page 168 Located below the center armrest cover is the Roadside Assistance button •. Pressing and holding the button (for longer than 2 seconds) will initiate a call to a Mercedes-Benz Roadside Assistance dispatcher. The button will flash while the call is in progress. The message “ROADSIDE ASSISTANCE – CONNECTING CALL”...
  • Page 169: Information Button

    Center representative and the occupants of the vehicle will be established. Information regarding the operation of your vehicle, the nearest Mercedes-Benz Center or Mercedes-Benz USA products and services is available to you. If you have chosen the Route Guidance Service (only USA) your communication will be transferred to our Emergency Response Center, who will provide the appririate information.
  • Page 170 If the indicator lamp continues to flash or the system does not reset, contact the Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada), or Mercedes-Benz Client Assistance at 1-800-FOR-MERCedes (1-800-367-6372) in the USA or Customer Service at 1-800-387-0100 in Canada.
  • Page 171 Vehicle location service Should you wish to locate your vehicle, contact the Emergency Response Center at 1-800-756-9018. You will be asked to provide your personal identifier witch you selected as part of your customer subscriber agreement. The Center will then attempt to covertly contact the vehicle’s Tele Aid system. The electronic key in the steering lock must be in position 1 or 2 and the cellular and GPS signals must be available.
  • Page 172: Steering Lock

    Instruments Operation Driving and controls Steering lock Steering lock The electronic key can be withdrawn in this position only. The steering is locked when the electronic key is removed from the steering lock. If necessary, move steering wheel slightly to allow the locking mechanism to engage.
  • Page 173 Important! If the electronic key is left in the steering lock position 0 for an extended period of time, it can no longer be turned in the lock. In this case, remove electronic key from steering lock and reinsert. Caution! To prevent accelerated battery discharge and a possible dead battery, always remove the electronic key from the steering lock.
  • Page 174: Starting And Turning Off The Engine

    If engine will not run, and the starting procedure stops, turn electronic key completely to the left and repeat starting the engine. After several unsuccessful attempts, have the system checked at the nearest authorized Mercedes-Benz Center. Instrument Practical hints Car care...
  • Page 175: Automatic Transmission

    Automatic transmission Automatic transmission Instruments Operation Driving and controls The automatic transmission selects individual gears automatically, dependent upon • Selector lever position • Program mode selector • Accelerator position • Vehicle speed The gear shifting process is continuously adapted, dependent on the driving style, the driving situation and the road characteristics.
  • Page 176 Instruments Operation Driving and controls Automatic transmission Driving The selector lever is automatically locked while in position “P”. To move the selector lever out of position “P”, the service brake pedal must be firmly depressed before the shift lock will release. Shift selector lever to the desired position only when the engine is idling normally and the service brake is applied.
  • Page 177 Stopping For brief stops, e.g. at traffic lights, leave the transmission in gear and hold vehicle with the service brake. For longer stops with the engine idling, shift into “N” or “P” and hold the vehicle with the service brake. When stopping the vehicle on an uphill gradient, do not hold it with the accelerator, use the brake.
  • Page 178 Instruments Operation Driving and controls Automatic transmission Selector lever position The current selector lever position is indicated in the gear range indicator display. The automatic gear shifting process can be adapted to specific operating conditions using the selector lever. Instrument Practical hints Car care cluster display...
  • Page 179 Coasting the vehicle, or driving for any other reason with selector lever in “N” can result in transmission damage that is not covered by the Mercedes-Benz Limited Warranty. The transmission automatically upshifts through 5th gear. Position “D” provides optimum driving characteristics under all normal operating conditions.
  • Page 180 Instruments Operation Driving and controls Automatic transmission Press and hold selector lever in the æ direction: The transmission will shift from the current gear directly to gear range “D”. Warning! On slippery road surfaces, never downshift in order to obtain braking action. This could result in drive wheel slip and reduced vehicle control.
  • Page 181 Gear ranges: Upshift through 4th gear only. Suitable for performance driving. Upshift through 3rd gear only. Suitable for moderately steep hills. Since the transmission does not shift higher than 3rd gear, this gear selection will allow use of the engine’s braking power downhill.
  • Page 182 Instruments Operation Driving and controls Automatic transmission Program mode selector switch The transmission is provided with a selector switch (1) for Standard “S” and Winter/Wet (snow and ice) “W” program modes. Standard mode Press switch on symbol “S”. Use this mode for all regular driving.
  • Page 183 “R” (for reverse gear). Have the transmission checked at your authorized Mercedes-Benz Center as soon as possible. With a malfunction in the vehicle’s electrical system the selector lever may be locked in position “P”. To unlock the selector lever manually, see page 255.
  • Page 184: Parking Brake

    • allow engine to warm up under low load use, • avoid frequent acceleration and deceleration, • have all maintenance work performed at regular intervals by an authorized Mercedes-Benz Center. Fuel consumption is also increased by driving in cold weather, in stop-and-go traffic, on short trips and in hilly country.
  • Page 185: Drinking And Driving

    Drinking and driving Warning! Drinking or taking drugs and driving can be a very dangerous combination. Even a small amount of alcohol or drugs can affect your reflexes, perceptions and judgement. The possibility of a serious or even fatal accident is sharply increased when you drink or take drugs and drive.
  • Page 186: Driving Off

    When starting off on a slippery surface, do not allow one drive wheel to spin for an extended period with the ESP switched off. Doing so may cause serious damage to the drive train which is not covered by the Mercedes-Benz Limited Warranty. Technical...
  • Page 187: Parking

    Inspect the tires and under the vehicle for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for repairs. Tread wear indicators (TWI) are required by law. These...
  • Page 188 Instruments Operation Driving and controls Driving instructions Warning! Do not allow your tires to wear down too far. As tread depth approaches in (1.5 mm), the adhesion properties on a wet road are sharply reduced. Depending upon the weather and/or road surface (conditions), the tire traction varies widely.
  • Page 189 Tire traction The safe speed on a wet, snow covered or icy road is always lower than on a dry road. You should pay particular attention to the condition of the road whenever the outside temperatures are close to the freezing point. Warning! If ice has formed on the road, tire traction will be substantially reduced.
  • Page 190: Snow Chains

    Driving instructions Snow chains Use only snow chains that are tested and recommended by Mercedes-Benz. Your authorized Mercedes-Benz Center will be glad to advise you on this subject. Chains should only be used on the rear wheels. Follow the manufacturer’s mounting instructions.
  • Page 191: Deep Water

    Driving instructions Winter driving Have your vehicle winterized at your authorized Mercedes-Benz Center before the onset of winter. • Change the engine oil if the engine contains an oil which is not approved for winter operation. For viscosity (SAE/CCMC class) and filling quantity, see page 284.
  • Page 192: Passenger Compartment

    Traveling abroad Abroad, there is a widely-spread Mercedes-Benz service network at your disposal. If you plan to travel into areas which are not listed in the index of your Mercedes-Benz Center directory, you should request pertinent information from your authorized Mercedes-Benz Center.
  • Page 193: Cruise Control

    Instruments Operation Driving and controls Driving systems Cruise control The cruise control allows you to drive in a more relaxed manner, for example over long distances, as it automatically maintains the set speed by actively regulating the throttle setting. Any given speed above approximately 25 mph (40 km/h) can be maintained with the cruise control by operating the lever.
  • Page 194 If the cruise control cancels by itself and remains inoperative until the engine is restarted, have the system checked at your authorized Mercedes-Benz Center as soon as possible. Resume If the lever is briefly pushed to position 4 when driving at a speed exceeding approx.
  • Page 195 Instruments Operation Driving and controls Driving systems Notes: If the engine does not brake the vehicle sufficiently while driving on a downgrade, the speed you set on the cruise control may be exceeded. In this case the automatic transmission shifts down (max. to 3rd gear) to maintain the set cruise control speed by using the engine’s braking power.
  • Page 196: Brake Assist System (Bas)

    Instruments Operation Driving and controls Driving systems Brake assist system (BAS) Warning! BAS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded.
  • Page 197 With the ABS malfunctioning, the BAS is also switched off. Both malfunction indicator lamps come on with the engine running. If the BAS warning message is displayed, have the BAS or ESP checked at your authorized Mercedes-Benz Center as soon as possible. Instrument Practical hints...
  • Page 198: Antilock Brake System (Abs)

    Instruments Operation Driving and controls Driving systems Antilock brake system (ABS) Warning! Do not pump the brake pedal, rather use firm, steady brake pedal pressure. Pumping the brake pedal defeats the purpose for ABS and significantly reduces braking effectiveness. Important! The ABS improves steering control of the vehicle during hard braking maneuvers.
  • Page 199 If the ABS malfunction indicator lamp stays illuminated, have the system checked at your authorized Mercedes-Benz Center as soon as possible. Warning! ABS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase...
  • Page 200: Electronic Stability Program (Esp)

    If the BAS malfunctions, the brake system functions in the usual manner, but without BAS. If the ESP warning message is displayed, have the BAS or ESP checked at your authorized Mercedes-Benz Center as soon as possible. With the ABS malfunctioning, the ESP is also switched off.
  • Page 201 ESP will immediately be engaged and will apply the rear wheel brakes. In winter operation, the maximum effectiveness of the ESP is only achieved with Mercedes-Benz recommended M+S rated radial-ply tires and/or snow chains. Synchronizing ESP If the power supply was interrupted (battery...
  • Page 202 24 mph (40 km/h), and switches off at 50 mph (80 km/h). Note: Avoid spinning of one drive wheel. This may cause serious damage to the drive train which is not covered by the Mercedes-Benz Limited Warranty. Instrument Practical hints Car care cluster display...
  • Page 203: What You Should Know At The 184 Gas Station

    Instruments Operation Driving and controls What you should know at the gas station What you should know at the gas station Fuel supply Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious injury. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extinguish all smoking materials.
  • Page 204 • Engine oil Engine oil level check, see page 108 and page 234 Fill quantity between upper and lower dipstick marking level: 2.1 US qt (2.0 l). Recommended engine oils, see Approved Service Products sheet. • Coolant For normal replenishing, use water (potable water quality).
  • Page 205: Check Regularly And Before A Long Trip

    Instruments Operation Driving and controls Check regularly and before a long trip Check regularly and before a long trip Instrument Practical hints Car care cluster display Engine oil level See “Engine oil level, checking” on page 108 and page 234. Coolant level See “Coolant level”...
  • Page 207 Instrument cluster display Malfunction and indicator lamps in the instrument cluster On-board diagnostic system Check engine malfunction indicator lamp Brake warning lamp Supplemental restraint system (SRS) indicator lamp Fuel reserve and fuel cap placement warning Electronic stability program(ESP) warning lamp BAS/ESP malfunction indicator lamp ABS malfunction indicator lamp Telescoping steering column –...
  • Page 208: Instrument Cluster Display

    Mercedes-Benz Center as soon as possible. If the “CHECK ENGINE” lamp comes on continuously and/ or the vehicle is not driving normally (e.g.
  • Page 209: Brake Warning Lamp

    Brake warning lamp BRAKE Except Canada Canada only When the brake warning lamp and message appear while the engine is running, this means: • there is insufficient brake fluid in the reservoir (engine running and parking brake released), or • the parking brake is set (engine running). Malfunction and indicator lamps Instruments Operation...
  • Page 210: Supplemental Restraint System (Srs) Indicator Lamp

    OBD selfcheck. If the warning lamp continues to blink after closing the fuel cap correctly, have the fuel system checked at your authorized Mercedes-Benz Center as soon as possible. Leaving the engine running and the fuel cap open can for belt also cause the “CHECK ENGINE”...
  • Page 211: Bas/Esp Malfunction Indicator Lamp

    When the voltage is above this value again, the malfunction indicator lamp should go out and the ABS is operational. Have the system checked at your authorized Mercedes-Benz Center as soon as possible. See page 198 for notes on the antilock brake system (ABS). Instrument...
  • Page 212: Telescoping Steering Column Indicator Lamp

    Instruments Operation Driving and controls Malfunction and indicator lamps Telescoping steering column – indicator lamp The indicator lamp in the instrument cluster comes on with the electronic key in steering lock position 2 and should go out with the engine running. If the indicator lamp does not go out after starting the engine, the adjustable steering column is not properly locked.
  • Page 213: Malfunction And Warning Messages In

    Mercedes-Benz Center. Failure to repair condition noted may cause damage not covered by the Mercedes-Benz Limited Warranty, or result in property damage or personal injury. Technical...
  • Page 214: Display Defective

    DISPLAY DEFECTIVE Line 1 Line 2 DISPLAY DEFECTIVE VISIT WORKSHOP! * C = Category, see page 213 This message is displayed to indicate that the information being relayed by the engine control unit is no longer complete. The coolant temperature gauge, tachometer, or the cruise control may have failed.
  • Page 215: Battery/Alternator

    Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Technical Index data...
  • Page 216: Abs-System

    * C = Category, see page 213 A malfunction has been detected in the system. The brake system functions in the usual manner, but without BAS. Have the system checked at your authorized Mercedes-Benz Center as soon as possible. Instrument Practical hints cluster display Line 2...
  • Page 217: Brake Fluid

    * C = Category, see page 213 When this message appears during braking, it indicates that the brake pads are worn down. Have the brake system checked at your authorized Mercedes-Benz Center as soon as possible. Instrument Practical hints Car care...
  • Page 218: Parking Brake

    PARKING BRAKE Line 1 Line 2 PARKING BRAKE RELEASE BRAKE! * C = Category, see page 213 Parking brake, see page 184. Malfunction and warning messages Instruments Operation Driving and controls ENGINE FAN Line 1 ENGINE FAN * C = Category, see page 213 1 The cooling fan for the coolant is faulty.
  • Page 219: Coolant (Coolant Level)

    The low engine coolant level warning should not be ignored. Extended driving with the symbol displayed may cause serious engine damage not covered by the Mercedes-Benz Limited Warranty. Notes: Do not drive without coolant in the cooling system. The engine will overheat causing major engine damage.
  • Page 220: Coolant (Coolant Temp.)

    Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Malfunction and warning messages Instruments...
  • Page 221: Steer. Wheel Adjust

    LIGHT SENSOR With the electronic key removed and the driver’s door open, a warning sounds and the message “SWITCH OFF LIGHTS!” appears in the multifunction indicator if the vehicle’s exterior lamps (except standing lamps) are not switched off. Malfunction and warning messages Instruments Operation Driving...
  • Page 222: Lighting System

    LIGHTING SYSTEM Line 1 Line 2 LAMP DEFECTIVE CHECK LAMPS! DISPLAY DEFECTIVE VISIT WORKSHOP! * C = Category, see page 213 Malfunction and warning messages Instruments Operation Driving and controls When the message appears after starting the engine, or if it comes on while driving, this indicates a failure in the parking lamp, taillamp, stop lamp, or low beam headlamp.
  • Page 223: Washer Fluid

    Instruments Operation Driving and controls Malfunction and warning messages WASHER FLUID Line 1 Line 2 WASHER FLUID CHECK LEVEL! * C = Category, see page 213 Instrument Practical hints Car care cluster display When this message appears while the engine is running, the level of the reservoir has dropped to approx.
  • Page 224: Oil Temp. (Engine Oil Temperature)

    Instruments Operation Driving and controls Malfunction and warning messages OIL TEMP. (engine oil temper atur e) Line 1 Line 2 OIL TEMP. TOO HIGH REDUCE REVS.! * C = Category, see page 213 There is a danger of engine damage - change to a higher gear or reduce road speed.
  • Page 225 “full” mark on the dipstick with an approved oil. The engine oil level warnings should not be ignored. Extended driving with the symbol displayed could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Technical Index data...
  • Page 226: Elec. Stabil. Prog

    ELEC. STABIL. PROG. (Electronic stability program) Line 1 Line 2 DISPLAY DEFECTIVE VISIT WORKSHOP! ELEC. STABIL. PROG. VISIT WORKSHOP! * C = Category, see page 213 Malfunction and warning messages Instruments Operation Driving and controls 1 A malfunction has been detected in the system. Pressing the accelerator pedal will require greater effort.
  • Page 227 Practical hints First aid kit Shelf below rear window Stowing things in the vehicle Spare wheel, vehicle tools, storage compartment Vehicle jack Fuses Hood Checking engine oil level Automatic transmission fluid level Coolant level Adding coolant Windshield washer / headlamp clean.system Windshield and headlamp washer fluid mixing ratio...
  • Page 228: Practical Hints

    Instruments Operation Driving and controls First aid kit First aid kit The first aid kit is stored in the shelf below the rear window. Pull handle (1) to open the lid. Instrument Practical hints cluster display Shelf below rear window Warning! The shelf below the rear window should not be used to carry objects.
  • Page 229: Spare Wheel, Vehicle Tools, Storage Compartment

    Instruments Operation Driving and controls Spare wheel, vehicle jack Spare wheel, vehicle tools, storage compartment Trunk floor Handle Luggage bowl Vehicle tools Instrument Practical hints Car care cluster display Lift trunk floor and engage handle in grip molding of luggage cover. To remove spare tire: Turn luggage bowl counterclockwise and remove.
  • Page 230: Vehicle Jack

    Vehicle jack Jack arm Jack base See illustration for proper storage of jack. Before storing the jack on the felt in the spare wheel well, the jack arm must be lowered almost to the base of the jack. Spare wheel, vehicle jack Instruments Operation Driving...
  • Page 231: Fuses

    Fuses Before replacing a blown fuse, determine the cause of the short circuit. Spare fuses are supplied inside the main fuse box (1). Observe amperage and color of fuse. A special fuse puller is supplied with the vehicle tools. Always use a new fuse for replacement. Never attempt to repair or bridge a blown fuse.
  • Page 232 Auxiliary fuse box below the trunk floor Auxiliary fuse box below the trunk floor. To gain access, lift trunk floor. Fuses Instruments Operation Driving and controls Auxiliary fuse box in the dashboard Auxiliary fuse box to left of exterior lamp switch. To gain access, open door, pry off cover (3) and remove.
  • Page 233: Hood

    Instruments Operation Driving and controls Engine compartment Hood Warning! To help prevent personal injury, stay clear of moving parts when the hood is open and the engine is running. Be sure the hood is properly closed before driving. When closing hood, use extreme caution not to catch hands or fingers.
  • Page 234: Checking Engine Oil Level

    Instruments Operation Driving and controls Engine compartment Pull handle (2) to its stop out of radiator grill and open hood (do not pull up on handle). To close: Lower hood and let it drop into lock from a height of approx.
  • Page 235 Do not overfill the engine. Excessive oil must be drained or siphoned. It could cause damage to engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. See malfunction and warning messages on page 2 3 1 if an engine oil level display appears on the multifunction display when the engine is running.
  • Page 236: Automatic Transmission Fluid Level

    Regular automatic transmission fluid level checks and changes are not required. For this reason the dipstick is omitted. If you notice fluid leaks or gear shifting malfunctions, have your authorized Mercedes-Benz Center check the transmission fluid level. Instrument Practical hints...
  • Page 237: Adding Coolant

    Adding coolant If coolant has to be added, a 50/50 mixture of water and MB anticorrosion/antifreeze should be added. The drain plugs for the cooling system are located on the right side of the engine block and at the bottom of the radiator.
  • Page 238: Windshield Washer / Headlamp Clean.system

    Windshield washer/headlamp cleaning system Windshield washer/headlamp cleaning system fluid reservoir The reservoir should be refilled with MB Windshield washer concentrate and water (or commercially available premixed windshield washer solvent/ antifreeze, depending on ambient temperatures). Engine compartment Instruments Operation Driving and controls Warning! Washer solvent/antifreeze is highly flammable.
  • Page 239: Wheels

    Wheels Replace rims or tires with the same designation, manufacturer and type as shown on the original part. See your authorized Mercedes-Benz Center for further information. See your authorized Mercedes-Benz Center for information on tested and recommended rims and tires for summer and winter operation.
  • Page 240: Rotating Wheels

    Rotating wheels The wheels can be rotated according to the degree of tire wear while retaining the same direction of travel. Rotating, however, should be carried out as recommended by the tire manufacturer, before the characteristic tire wear pattern (shoulder wear on front wheels and tread center wear on rear wheels) becomes visible, as otherwise the driving properties deteriorate.
  • Page 241: Spare Wheel

    Spare wheel Important! The spare wheel rim size is 7 The spare wheel rim is mounted with a full size tire of the same type as on the vehicle’s front axle, and is fully functional. However, that spare wheel rim is weight optimized and has a limited service life of 12 000 miles (20 000 km) use before a standard wheel rim must replace it.
  • Page 242: Changing Wheels

    Instruments Operation Driving and controls Tires, Wheels Changing wheels Warning! The jack is designed exclusively for jacking up the vehicle at the jack tubes built into either side of the vehicle. To help avoid personal injury, use the jack only to lift the vehicle during a wheel change. Never get beneath the vehicle while it is supported by the jack.
  • Page 243 4. Using the wrench, loosen but do not yet remove the wheel bolts. Tires, Wheels Instruments Operation Driving and controls 5. Remove the protective cover from the jack support tube opening by inserting the screwdriver (supplied in the tool kit) in the opening and prying it out. The tube openings are located directly behind the front wheel housings and in front of the rear wheel housings.
  • Page 244 Instruments Operation Driving and controls Tires, Wheels 6. Insert jack arm fully into the tube hole up to the stop. Place jack on firm ground. Position the jack so that it is always vertical (plumb-line) as seen from the side (see arrow), even if the vehicle is parked on an incline.
  • Page 245 10. Clean contact surfaces of wheel and wheel hub. Install spare wheel on wheel hub. Insert wheel bolts and tighten them slightly. To avoid paint damage, place wheel flat against hub and hold it there while installing first wheel bolt. Unscrew the alignment bolt (1) to install the last wheel bolt.
  • Page 246 Instruments Operation Driving and controls Tires, Wheels Warning! Always replace wheel bolts that are damaged or rusted. Never apply oil or grease to wheel bolts. Damaged wheel hub threads should be repaired immediately. Incorrect mounting bolts or improperly tightened mounting bolts can cause the wheel to come off. This could cause an accident.
  • Page 247: Tire Inflation Pressure

    Tire inflation pressure A table (see fuel filler flap) lists the tire inflation pressures specified for Mercedes-Benz recommended tires as well as for the varying operating conditions. Important! Tire pressure changes by approx. 1.5 psi (0.1 bar) per 18°F (10°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage –...
  • Page 248 Instruments Operation Driving and controls Battery If a tire constantly loses air, it should be inspected for damage. The spare tire should be checked periodically for condition and inflation. Spare tire will age and become worn over time even if never used, and thus should be inspected and replaced when necessary.
  • Page 249: Battery

    Instruments Operation Driving and controls Battery Battery Warning! Failure to follow these instructions can result in severe injury or death. Never lean over batteries while connecting, you might get injured. Battery fluid contains sulfuric acid. Do not allow this fluid to come in contact with eyes, skin or clothing.
  • Page 250 Notes: After reconnecting the battery also resynchronize the front seats , front seat head restraints (see page 49), the express feature of the power windows (see page 142), and the electronic stability program (ESP) (see page 201). Battery Instruments Operation Driving and controls Battery recycling...
  • Page 251: Jump Starting

    Only use 12 V battery to jump start your vehicle. Jump starting with more powerful battery could damage the vehicle’s electrical systems, which will not be covered by the Mercedes-Benz Limited Warranty. The battery is located in the trunk under the trunk floor. Proceed as follows: 1.
  • Page 252 2 AWG • Maximum length of 11.5 ft. (3.5 m). Notes: If engine does not run after several unsuccessful starting attempts, have it checked at the nearest authorized Mercedes-Benz Center. Excessive unburned fuel may damage the catalytic converter. Instrument Practical hints...
  • Page 253: Towing The Vehicle

    Instruments Operation Driving and controls Towing Towing the vehicle Prior to towing the vehicle with all wheels on the ground, make certain that the electronic key is in steering lock position 2. If the electronic key is left in the steering lock position 0 for an extended period of time, it can no longer be turned in the lock.
  • Page 254 We recommend that the vehicle be transported using flat bed equipment. This method is preferable to other types of towing. The vehicle may be towed with all wheels on the ground and the selector lever in position “N” for distances up to 30 miles (50 km) and at a speed not to exceed 30 mph (50 km/h).
  • Page 255: Transmission Selector Lever, Manually Unlocking

    Transmission selector lever, manually unlocking In the case of power failure the transmission selector lever can be manually unlocked, e.g. to tow the vehicle. Towing Instruments Operation Driving and controls To do so, insert a pin (1), e.g. ball point pen, into the covered opening below the position “D”...
  • Page 256: Bulbs

    Instruments Operation Driving and controls Exterior lamps Bulbs Headlamp adjustment Correct headlamp adjustment is extremely important. Check and readjust headlamps at regular intervals and when a bulb has been replaced. For adjusting headlamp aim see page 261. Replacing bulbs Warning! Bulbs and bulb holders can be very hot.
  • Page 257 Headlamp assembly (Halogen) Headlamp vertical adjustment screw Cover for low beam headlamp Cover for high beam headlamp, parking and standing lamp Exterior lamps Instruments Operation Driving and controls Headlamp assembly (Xenon) P82.10-2394-26 Bulb socket for turn signal lamp Electrical connector for low beam headlamp bulb Electrical connector for high beam headlamp bulb Bulb socket for parking and standing lamp Instrument...
  • Page 258 Instruments Operation Driving and controls Exterior lamps Bulbs for low or high beam H7 (55 W) Open hood. Rotate cover (2 or 3) counterclockwise and remove. Pull off electrical connector (5 or 6). Unhook clamping ring and remove bulb. Insert new bulb (seating properly in cutouts of bulb socket), mount clamping ring.
  • Page 259 Taillamp assemblies Open trunk lid. Swing cover aside (bulbs 1, 2 and 3). Turn signal lamp (21 W/24 cp bulb) Stop, tail, parking, and side marker lamp (21/4 W bulb) Tail and parking lamp (5 W/4 cp bulb) Exterior lamps Instruments Operation Driving...
  • Page 260 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamps Side marker lamp, front (5 W/4 cp bulb) Carefully slide lamp towards front (arrow), and remove back and first. Twist bulb socket counterclockwise and pull out. Push bulb socket, turn counterclockwise and remove.
  • Page 261: Adjusting Headlamp Aim

    The high mounted stop lamp (3rd brake lamp), and the additional turn signals on the exterior mirrors are equipped with LEDs. Have the system checked at an authorized Mercedes-Benz Center if a fault or defect occurs. Exterior lamps Instruments Operation...
  • Page 262 As a check, the distance between centerlines should be inches (1250 mm). If the distance does not check, have the system verified at an authorized Mercedes-Benz Center. Instrument Practical hints Car care cluster display 3.
  • Page 263 (8 and 9). The left and right headlamps must be adjusted individually. Note: If it is not possible to obtain a proper headlamp adjustment, have the system checked at your authorized Mercedes-Benz Center. Instrument Practical hints Car care cluster display Technical...
  • Page 264: Changing Batteries In The Electronic Main Key

    Instruments Operation Driving and controls Electronic main key Changing batteries in the electronic main key Transmit buttons Lamp for battery check and function control Checking batteries If one of the transmit buttons (1) is pressed, the battery check lamp (2) lights up briefly – indicating that the batteries are in order.
  • Page 265 Insert mechanical key (4) in side opening (5) to open latch. Press briefly (do not use mechanical key as lever) to release battery compartment. Remove mechanical key from side opening. Lift battery compartment in direction of arrow (7) and remove in direction of arrow (8). Electronic main key Instruments Operation...
  • Page 266: Synchronizing Remote Control

    Instruments Operation Driving and controls Electronic main key Important! Batteries contain materials that can harm the environment if disposed of improperly. Recycling of batteries is the preferred method of disposal. For disposal, please follow manufacturer’s recommendation on battery package. Replacement Battery: Lithium, type CR 2025 or equivalent.
  • Page 267: Emergency Operation Of Sliding/Pop-Up Roof

    Instruments Operation Driving and controls Emergency operation of sliding/pop-up roof Emergency operation of sliding/pop-up roof The sliding/pop-up roof can be opened or closed manually should an electrical malfunction occur. The sliding/pop-up roof drive is located behind the lens of the left interior lamp between the sun visors. 1.
  • Page 268: Manual Release For Fuel Filler Flap

    Manual release for fuel filler flap The manual release knob is located behind the right side trunk panel. In case the central locking system does not release the fuel filler flap, pull the manual release knob while simultaneously opening the fuel filler flap. Manual release for fuel filler flap Instruments Operation...
  • Page 269 Instruments Operation Driving and controls Replacing wiper blade insert Removal: Fold wiper arm forward. Press safety tab down (1), push wiper blade downward (2) and remove. Place wiper blade on firm support. Press down both tabs and slide (direction of arrow) the wiper blade insert out of the retainer claws.
  • Page 270: Trunk Lamp

    Instruments Operation Driving and controls Roof rack P82.20-2029-26 Use only those roof racks approved by Mercedes-Benz to avoid damage to the vehicle. Follow manufacturer’s installation instructions. Mount supports only between markings which are visible on the rubber molding. Instrument Practical hints...
  • Page 271 Vehicle care Cleaning and care of the vehicle Engine cleaning Vehicle washing Plastic and rubber parts Tar stains Window cleaning Headlamps, taillamps, turn signal lenses Wiper blade Seat belts Headliner and shelf below rear window Instrument cluster Steering wheel and gear selector lever Hard plastic trim items Upholstery Paintwork, painted body components...
  • Page 272 Your vehicle has been treated at the factory with a wax- base rustproofing in the body cavities which will last for the lifetime of the vehicle. Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others applied later.
  • Page 273: Engine Cleaning

    Mercedes-Benz Center. The following topics deal with the cleaning and care of your vehicle and give important “how-to” information as well as references to Mercedes-Benz approved car-care products. Additional information can be found in the booklet titled “Vehicle Care Guide”.
  • Page 274: Tar Stains

    Use a window cleaning solution on all glass surfaces. An automotive glass cleaner is recommended. Headlamps, taillamps, turn signal lenses Use a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo, with plenty of water. To prevent scratches, never apply strong force and use only a soft, non-scratchy cloth when cleaning the lenses.
  • Page 275: Headliner And Shelf Below Rear Window

    Steering wheel and gear selector lever Wipe with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care. Hard plastic trim items Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure. Instrument Practical hints...
  • Page 276: Paintwork, Painted Body Components

    Operation Driving and controls Light alloy wheels Mercedes-Benz approved Wheel Care should be used for regular cleaning of the light alloy wheels. If possible, clean wheels once a week with Mercedes- Benz approved Wheel Care, using a soft bristle brush and a strong spray of water.
  • Page 277 Technical data Spare parts service Warranty coverage Identification labels Layout of poly-V-belt drive Technical data Fuels, coolants, lubricants etc. – capacities Engine oils additives Engine oil Air conditioner refrigerant Brake fluid Premium unleaded gasoline Fuel requirements Gasoline additives Coolants Consumer information Uniform tire quality grading Index...
  • Page 278: Spare Parts Service

    Therefore, Mercedes-Benz original spare parts should be installed. Important! The use of non-genuine parts and accessories not authorized by Mercedes-Benz could damage the vehicle which damage is not covered by the Mercedes-Benz Limited Warranty or compromise its durability or safety. Instrument Practical hints Car care...
  • Page 279: Identification Labels

    Identification labels Certification label Technical data Instruments Operation Driving and controls Vehicle Identification Number (VIN) When ordering spare parts, please specify vehicle identification and engine numbers. Instrument Practical hints Car care cluster display Technical Index data...
  • Page 280: Layout Of Poly-V-Belt Drive

    Instruments Operation Driving and controls Technical data VIN, visible (lower edge of windshield) Engine number Body number and paintwork number Emission control label Information label, California version Vacuum line routing for emission control system Instrument Practical hints cluster display Layout of poly-V-belt drive Automatic belt tensioner Crankshaft Air conditioner compressor...
  • Page 281: Technical Data

    Maximum torque acc. to SAE J 1349 Maximum engine speed Firing order Poly-V-belt 1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Technical data Instruments...
  • Page 282 Instruments Operation Driving and controls Technical data Rims – Tires Rims front axle (AMG light alloy) Wheel offset 1.46 in (37 mm) Rims rear axle (AMG light alloy) Wheel offset 1.18 in (30 mm) Radial-ply tires Summer tires, front axle: 225/45 R 17 91 W Summer tires, rear axle: 245/40 R 17 91 W...
  • Page 283 Weights (see certification tag) Roof load max. 220 lb (100 kg) Trunk load max. 220 lb (100 kg) Technical data Instruments Operation Driving and controls Main dimensions Overall vehicle length Overall vehicle width Overall height Wheel base Track, front Track, rear Instrument Practical hints Car care...
  • Page 284: Fuels, Coolants, Lubricants Etc Capacities

    Fuels, coolants, lubricants etc. – capacities Vehicle components and their respective lubricants must match. Therefore use only brands tested and recommended by us. Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Center. Capacity Engine with oil filter 8.5 US qt (8.0 l)
  • Page 285: Engine Oils Additives

    Do not blend oil additives with engine oil. They may be harmful to the engine operation. Damage or malfunctions resulting from blending oil additives are not covered by the Mercedes-Benz Limited Warranty. Engine oils Engine oils are specifically tested for their suitability in our engines.
  • Page 286: Premium Unleaded Gasoline

    Instruments Operation Driving and controls Fuels, coolants, lubricants etc. Premium unleaded gasoline Caution! To maintain the engine’s durability and performance, premium unleaded gasoline must be used. If premium unleaded is not available and low octane fuel is used, follow these precautions: •...
  • Page 287: Gasoline Additives

    Gasoline additives A major concern among engine manufacturers is carbon build up caused by gasoline. Mercedes-Benz recommends the use of only quality gasoline containing additives that prevent the build up of carbon deposits. After an extended period of using fuels without such...
  • Page 288 Practical hints Car care cluster display Therefore the following product is strongly recommended for use in your vehicle: Mercedes-Benz Anticorrosion/antifreeze agent. Before the start of the winter season (or once a year in the hot southern regions), you should have the anticorrosion/antifreeze concentration checked.
  • Page 289: Consumer Information

    Consumer information This has been prepared as required of all manufactures of passenger cars under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”. Uniform tire quality grading Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width.
  • Page 290 Instruments Operation Driving and controls Consumer information Temperature The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 291: Index

    Index ABS (Antilock brake system)………………………….198 ABS-SYSTEM - malfunction and warning messages ...216 Adjusting headlamp aim ...261 Adjusting telescoping steering column ...73 Air conditioner refrigerant ...285 Airbag OFF indicator lamp ...212 Airbags ...64 Antilock brake system (ABS) ...198 Malfunction indicator lamp ...211 Antitheft alarm system...41 Aquaplaning ...188 Ashtray...
  • Page 292 Automatic transmission ...175 Emergency Operation ...183 Fluid level ...236 Program mode selector switch ...182 Selector lever position ...178 Transmission selector lever, manually unlocking ...255 BabySmart airbag deactivation system ...62 Self-test...62 Backrest ...51 BAS (Brake assist system)...196 Battery...249 Battery recycling ...250 BATTERY CHARGE - malfunction and warning messages ...215 BRAKE ASSIST - malfunction and...
  • Page 293 Checking engine oil level Via engine oil level indicator...108 Via oil dipstick ...234 Cleaning and care of the vehicle ...272 COMAND, radio, telephone and two-way radio ...162 Combination switch ...113 Consumer information ...289 Control and operation of radio transmitters ...162 COOLANT (coolant level) - malfunction and warning messages ...219 COOLANT (coolant temperature) -...
  • Page 294 Electronic stability program (ESP) Malfunction indicator lamp ...211 Warning lamp ...211 Emergency tensioning retractor (ETR) ...63 Emergency unlocking in case of accident ...37 Emission control ...165 Engine compartment ...233 ENGINE FAN - malfunction and warning messages ...218 Engine oil additives ...285 Engine oil consumption...109 Engine oil level Checking ...108, 234...
  • Page 295 Garage door opener...157 Gasoline Additives ...287 Fuel requirements ...286 Premium unleaded ...286 Glove box ...148 Hazard warning flasher switch...115 Head restraints Front ...49 Rear...50 Headlamp cleaning system...112 Heated seats...53 Hood ...233 Illuminated vanity mirrors ...147 Indicator lamps in the instrument cluster ...80 Infant and child restraint systems...70 Installation...
  • Page 296 Maintenance ...163 Malfunction and indicator lamps in the instrument cluster ...208 Malfunction and warning messages ...213 Malfunction message memory ...100 Manual operation of sliding/pop-up roof ...267 Multicontour seat ...52 Multifunction display ...84 Engine oil level indicator ...88 ESS (Flexible service system)...88 Setting the audio volume ...104 Trip and main odometer...88 Multifunction steering wheel...84...
  • Page 297 Rear seats Split folding backrest...152 Rear view mirrors Exterior ... 75 Inside ... 74 Rear window sunshade ...146 Replacing wiper blade insert ...268 Reserve key ...25 Roof rack..270 Safety guidelines for the seat belt, emergency tensioning retractor and airbag ... 69 Seat belts ...
  • Page 298 Tachometer ...83 Technical data ...281 Electrical system...282 Main dimensions ...283 Rims and tires...282 Weights ...283 Tele Aid...166 Initiating an emergency call ...167 Telephone ...92 General notes ...156 Incoming call...96 Redialing ...94 Telephone book...92 Telephones and two-way radios ...162 Telescoping steering column Adjusting...73 Indicator lamp...212 Telescoping steering column -...
  • Page 299 Warranty coverage ...278 WASHER FLUID (headlamp cleaning system) - malfunction and warning messages ...223 What you should know at the gas station ...203 Wheels ...239 Where to find it... 13 Windshield washer/headlamp cleaning system Refilling ...238 Wiper blade Replacing insert ... 268...

This manual is also suitable for:

2000 clk-class coupeClk 4302000 clk coupe 430
