One For All URC-3550 User Manual & Code Book

“super easy”.
Hide thumbs

Advertisement

URC-3550
"SUPER EASY"
Universal Remote
U S E R G U I D E & C O D E B O O K
R e t a i n F o r F u t u r e R e f e r e n c e

Advertisement

   Related Manuals for One for All URC-3550

   Summary of Contents for One for All URC-3550

  • Page 1

    URC-3550 “SUPER EASY” Universal Remote U S E R G U I D E & C O D E B O O K R e t a i n F o r F u t u r e R e f e r e n c e...

  • Page 2: Table Of Contents

    Table of Contents ABOUT YOUR SUPER EASY THE KEYPAD INSTALLING THE BATTERIES SETTING UP THE SUPER EASY Setting Up Your Device ADVANCED FEATURES Reassigning the Device Keys Teletext and Fastext Menu Control Controlling Colour and Brightness Punch-Through Preventing accidental code changes TROUBLE-SHOOTING Searching for Your Code Code Blink Out...

  • Page 3: About Your Super Easy

    About Your SUPER EASY Your SUPER EASY Package contains: Your SUPER EASY Remote Your SUPER EASY Manual Your manual is divided into two parts: set-up instructions and device codes. You will need your manual to set up your new SUPER EASY so please be sure to keep it. Your SUPER EASY needs four new AAA/LR03 alkaline batteries.

  • Page 4

    About Your SUPER EASY Setup Power Device Keys Mute Channel+ Volume+ Volume- Menu Channel- Number Keys -/-- Key Play Rewind Fast Forward Teletext Keys Record Pause Stop...

  • Page 5: The Keypad

    The Keypad Function The LED (Light Emitting Diode) flashes red to show the remote is working. Power The Power key controls the same function as on your original remote. POWER Device Keys The TV, VCR and SAT keys select the home entertainment device to be controlled.

  • Page 6

    The Keypad Function Video Recorder Keys After pressing the VCR key, the Video Recorder keys operate the functions of your Video Recorder. To prevent accidental recording, the Record key must be pressed twice to start recording. Teletext Keys After pressing the TV key, the Rewind and Fast Forward keys are used to operate the main teletext functions.

  • Page 7: Installing The Batteries

    Installing the Batteries Your SUPER EASY needs four new AAA/LR03 alkaline batteries. Remove the battery cover from the back of your SUPER EASY Match the batteries to the + and - marks inside the battery case, then insert the batteries. Press the battery cover back into place.

  • Page 8: Setting Up Your Device

    Setting Up The SUPER EASY Setting Up Your Device To set up the SUPER EASY for your Device: Find your Television code in the Set-Up Code section (starting on page 20). Codes are listed by brand name. The most popular code is listed first. Make sure your Television is switched on.

  • Page 9: Advanced Features, Changing The Device Keys

    Advanced Features Changing the Device Keys If you want, you can change any of the device keys (TV, VCR or SAT) to operate another type of device. The chart below lists how to change the keys and to set up that device: To Change: Press: SETUP* 9 9 2 VCR TV,...

  • Page 10: Teletext And Fastext

    Teletext and Fastext The SUPER EASY is designed to operate the basic functions of teletext (text on and text off). Symbol Title Description TEXT Puts the Television in the teletext mode. Switches the Television back to regular viewing mode. On some Televisions, this may be done by pressing the TEXT key several times.

  • Page 11: Menu Control

    Advanced Features Menu Control If your original remote had Menu control, your SUPER EASY will be able to control this feature. To use Menu, find the description below which describes how your original remote navigated through menu. Original remote used Up, Down, Left, Right: After pressing the Menu key on the SUPER EASY, the Volume and Channel keys can be used as directional keys.

  • Page 12

    Advanced Features Colour & Brightness Depending on the functions of your original remote control, the SUPER EASY may operate the colour and brightness settings of your Television. To adjust the colour and brightness settings: Press the Menu key first. Once this key is pressed: To adjust the colour: Press Volume+ (for colour up) or Volume- (for colour down).

  • Page 13: Punch-through, Preventing Accidental Code Changes

    Advanced Features Punch Through You may be able to use some features of your Television, Video Recorder and Satellite Receiver at the same time. If you're watching a programme on your Video, you can adjust the volume (a TV function) without first pressing the TV key. The chart below lists some of the possibilities: Last Key Pressed: You Can Control:...

  • Page 14: Searching For Your Code

    Trouble-Shooting The Search Method If your Television, Video Recorder or Satellite Receiver does not respond to the SUPER EASY after you have tried all the codes listed for your brand, try the Search Method. The Search Method may also work if your brand is not listed at all. Let's say you cannot get your SUPER EASY to control your Television: Switch your Television on.

  • Page 15: Code Blink Out

    Trouble-Shooting Code Blink Out Even if you have used the Search Method, it is handy to know your Television, Video or Satellite Receiver code for future reference. It's easy to get your code after you have set up your Television, Video or Satellite. To blink out your Television code: Press TV.

  • Page 16: Helpful Hints

    Trouble-Shooting Helpful Hints Problem: Solution: Red light does not blink Replace batteries with 4 fresh, when you press a key? new AAA alkaline batteries. The does not respond Make sure you are using new after pressing a key? batteries and are aiming the at your device.

  • Page 17: Consumer Help-line

    1-800 553 118 fax: +31 53 4329816 e-mail: ofahelp@ueic.com In Australia: phone: 1800 064 472 e-mail: ofahelp@ueic.com Your remote model: URC-3550 Date of purchase: day/month/year ----- ------- ------- day/month/year Your devices: (The first row is an example of how to complete this table)

  • Page 18: Quick Code Reference

    Trouble-Shooting Quick Code Reference The following pages list the codes for your equipment. The most popular codes for each brand are listed first. If your device does not respond to the SUPER EASY after you have tried all the codes for your brand, try the search method (page 15).

  • Page 19: Televisions

    Set-Up Codes - TV Bondstec Televisions Boots Acura Brandt Admiral 087 093 418 213 264 Adyson Brinkmann Agazi Brionvega Britannia Aiko 216 009 037 371 035 Bruns 072 361 191 037 274 Akai 208 361 371 037 191 Bush 035 009 072 218 163 Akiba 218 282 455 037 Capsonic...

  • Page 20

    Set-Up Codes - TV Elite 218 037 Hifivox HiLine Elman Hinari Elta Emerson 177 213 087 247 Hisawa Emperor Hitachi Erres 037 012 Etron 037 009 Euro-Feel Hoshai Euromann 216 264 037 217 421 Hygashi Hornyphon Europhon 037 516 102 213 217 Hyper Hypersonic Expert...

  • Page 21

    235 177 009 355 011 Phoenix 072 036 037 487 217 Phonola 294 371 443 Pioneer McMichael Plantron Mediator 037 556 012 Policom Memorex Poppy Memphis 337 072 009 Prandoni- Mercury Prince Metz 087 195 535 447 239 Precision 213 554 275 367...

  • Page 22

    Set-Up Codes - VCR 087 102 010 516 213 Tokyo 294 296 206 037 Tomashi Seleco 206 226 362 259 411 Toshiba Sencora Towada Sentra 276 035 218 Trans Sharp 093 157 036 294 Continens Shorai Trident Siarem 087 102 213 Triumph Siemens 191 535 554 157 195...

  • Page 23

    278 020 045 Manesth Dansai Marantz Daytron Matsui Decca 000 041 081 008 067 DeGraaf 042 166 081 104 048 Mediator Dual 041 081 Memorex Dumont 000 081 104 105 278 240 Memphis Elcatech Metz Elin Elta Migros Emerson Minerva Etzuko...

  • Page 24: Satellite Receivers

    Set-Up Codes - SAT Saba 041 187 206 320 384 White Wes- tinghouse Yamashi Saisho 004 209 208 192 Salora 046 043 106 104 Yokan Samsung 240 432 Yoko Samurai Sansui 041 067 106 Sanwa Satellite Receivers Sanyo 104 046 047 Saville 352 278 240 Akai...

  • Page 25

    Set-Up Codes - SAT Cosat Intervision Crown 243 518 ITT/Nokia Daewoo Dansat 067 183 Johansson 366 373 Kathrein Diamond Discovery Diskxpress Kolon Distrisat Kosmos Ditristrad Kreiselmeyer 173 200 458 396 Kyostar Dual Lasat Dune Lenco Echostar 396 668 Lennox Einhell 333 243 421 288 252 Lenson 513 518 713 501...

  • Page 26: Cable Converters

    Set-Up Codes - CAB Palladium 243 571 Tagra Palsat Tantec Panasonic 455 328 Techniland Panda 455 067 108 Technisat Paristad Teco Patriot 515 668 Telasat Philips 200 220 183 292 455 Teleciel 328 667 750 710 613 Telefunken Phoenix 366 183 Teleka Phonotrend 288 592 502 656...

  • Page 27

    Universal Electronics Inc. URC-3550 700475 Printed on Recycled Paper In Australia KENMARK INDUSTRIAL (A) CO.PTY.LTD.
