Main Features

This adapter can be attached to a
GY-HM790CHU/GY-HM790U/GY-HM790CHE/
GY-HM790E unit for it to be used as a HD/SD
studio camera.
Analog 26-pin Camera Connector
By connecting to a Remote Control Unit
(RM-HP250AU/RM-HP250DE) (sold separately),
this adapter can be controlled from up to a
distance of 100 m away.
In this case, power is supplied to the camera by
the remote control unit, and thus a separate
power supply is not needed for the camera.
Also, you can choose to supply power from the
battery using the power selection switch.
Composite signals and Y/PB/PR component
signals are output from the 26-pin camera
connector.
Intercom Terminal
Using a headset enables communication with
the remote control unit operator.
Prompter Output Terminal
Outputs prompter video from the remote control
unit as composite signals.
How to use this manual
Symbols used
Note : Describes precautions concerning
the operation of this product.
Memo : Describes reference information,
such as functions and usage
restrictions of this product.
A
: Indicates the reference page
numbers and reference items.
Content of this manual
● All rights reserved by JVC. Unauthorized
duplication or reprinting of this manual, in
whole or in part, is strictly prohibited.
● All other product names used in this manual
are the trademarks or registered trademarks
of the respective companies. Marks such as
™, , and are omitted in this manual.
● Illustrated designs, specifications and other
contents of this manual are subject to
changes for improvement without prior
notice.
