Memorex MX4122 User Manual

Home audio system with mp3/wma cd player and am/fm stereo radio
Hide thumbs Also See for MX4122:

Advertisement

Quick Links

MX4122
User's Guide
Home Audio System with
MP3/WMA CD Player and
AM/FM Stereo Radio
Before operating this product,
please read these instructions completely.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX4122 and is the answer not in the manual?

Questions and answers

Summary of Contents for Memorex MX4122

  • Page 1 MX4122 User’s Guide Home Audio System with MP3/WMA CD Player and AM/FM Stereo Radio Before operating this product, please read these instructions completely.
  • Page 2 PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. For future reference, record the serial number of the unit printed on the rear of the cabinet.
  • Page 3 Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
  • Page 4 Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna. READ INSTRUCTIONS All the safety and operating instructions should be read before the product is operated.
  • Page 5: Preparation For Use

    AC OPERATION Unwind the AC power cord and extend it to its full length. Insert the AC power cord into any convenient 120V 60Hz household outlet. Please note that this unit is equipped with a polarized AC plug which has one blade wider than the other. This is a safety feature to reduce the likelihood of electric shock.
  • Page 6: Headphone Jack

    HEADPHONE JACK For private listening, connect 3.5mm (32 ohm) stereo headphones (not included) to this jack. The speakers are automatically disconnected when the headphone plug is inserted in the jack. BATTERY PRECAUTIONS From MX4122 EXTERNAL UNIT Aux Out – –...
  • Page 7: Location Of Controls

    LOCATION OF CONTROLS 1. CD Compartment 2. Tune/Skip/Search n and o Buttons 3. Speaker Terminals (Rear of Unit) 4. STOP/BAND ( ) Button 5. Display 6. FUNCTION Button 7. PRESET EQ Button 8. PROGRAM/CLOCK SET Button 9. P-MODE (Play Mode) Button 10.
  • Page 8 LOCATION OF CONTROLS (CONTINUED) REMOTE 1. FUNCTION Button 2. PRESET EQ Button 3. PLAY/PAUSE (®p) Button 4. Tune/Skip/Search o Button 5. STOP ( )/BAND Button 6. VOLUME Down Button 7. PROGRAM/CLOCK SET Button 8. SKIP -10 TRACKS Button 9. P-MODE (Play Mode)/MEMORY UP Button 10.
  • Page 9: Setting The Clock

    OPERATING INSTRUCTIONS SETTING THE CLOCK With the power off, press the PROGRAM/CLOCK SET button; the hours will blink. Press the Tune/Skip/Search n 1 or o 2 button to set the current minute. PRESET EQ With the power on, press the PRESET EQ button to cycle through the preset EQ settings or to turn the EQ off.
  • Page 10: Listening To The Radio

    OPERATING INSTRUCTIONS (CONTINUED) LISTENING TO THE RADIO Press the POWER button to turn the unit on; the Standby indicator will go out. MANUAL TUNING: Repeatedly press the Tune/Skip/Search n 1 or o 2 button to manually advance the frequency in the display up or down until the desired frequency appears.
  • Page 11: Setting Radio Presets

    OPERATING INSTRUCTIONS (CONTINUED) SETTING RADIO PRESETS This unit can preset 10 AM and 10 FM radio stations for convenient recall. Press the POWER button to turn the unit on; the Standby indicator will go out. Press the PROGRAM/CLOCK SET button 1. Press the FOLDER/ MEMORY UP button 2 (on the main unit) or press the P- MODE/MEMORY UP or MEMORY...
  • Page 12: Playing Compact Discs

    OPERATING INSTRUCTIONS (CONTINUED) PLAYING COMPACT DISCS This CD player is designed to play all kinds of Audio Discs and MP3/WMA CD Roms, such as CD recordables and rewriteables. Do not try to play CDI, CDV, DVD or computer CDs in this unit. Press the POWER button to turn the unit on;...
  • Page 13: To Begin Playback From A Specific Track

    OPERATING INSTRUCTIONS (CONTINUED) TO BEGIN PLAYBACK FROM A SPECIFIC TRACK While in the CD mode, insert a disc into the CD player. Then the unit will read the table of the contents on the disc. After the total number of tracks appear, press either the Tune/Skip/Search n 1 or o 2 button to select a specific track for playback.
  • Page 14: Repeat Playback

    OPERATING INSTRUCTIONS (CONTINUED) FORWARD/REVERSE SKIP 10 TRACK BUTTONS STANDARD AUDIO CD: If, for example, the CD has 17 tracks, press the SKIP +10 TRACKS button 1 during playback of the first track to skip to the eleventh track. If you press the SKIP +10 TRACKS button 1 again, it would go back to the first track as there are only 17 tracks on the CD.
  • Page 15: Programmed Playback

    OPERATING INSTRUCTIONS (CONTINUED) repeat files album/folder (MP3/WMA disc only), press the P-MODE button 1 twice; “REP FOLDER” will appear in the display. Press the FOLDER/MEMORY UP button 2 (on the main unit) or FOLDER UP/DOWN buttons (on the remote) to select the specific folder that you wish to repeat.
  • Page 16 OPERATING INSTRUCTIONS (CONTINUED) Press the Tune/Skip/Search n 1 or o 2 button to select the first track that you wish to program. When the desired track number appears in the display, press the PROGRAM/CLOCK SET button again. Repeat steps 4 through 7 until you have programmed up to 20 track numbers into the CD Program Memory.
  • Page 17: Programmed Repeat

    OPERATING INSTRUCTIONS (CONTINUED) PROGRAMMED REPEAT It is also possible to use the Program and Repeat functions together to repeat a specific program indefinitely. First, make a program as described above, then press the P-MODE button twice to enter the Repeat-All mode.
  • Page 18: Setting The Timer

    OPERATING INSTRUCTIONS (CONTINUED) SETTING THE TIMER Set the timer to turn the unit on to the Tuner or CD mode at a preset time as follows: With the unit off (in the Standby mode), press the TIMER/SLEEP button once, "Timer" will appear and the hours will blink in the display.
  • Page 19: Activating The Sleep Function

    OPERATING INSTRUCTIONS (CONTINUED) ACTIVATING THE SLEEP FUNCTION Set the sleep timer as follows: During playback of a CD or while listening to the radio, press the TIMER/SLEEP button once, “90” will blink and “SLEEP” will appear in the display. TO CANCEL SLEEP TIME: To cancel the Sleep function, press the TIMER/SLEEP button once and the "SLEEP"...
  • Page 20: Single Session

    OPERATING INSTRUCTIONS (CONTINUED) MP3/WMA FAQs–Frequently Asked Questions Please read before playing an MP3/WMA disc. Does the unit support packet write CD-RW? Yes, it can. You can add or delete MP3/WMA files without reformatting. It appears like a PC hard drive. Can the unit read regular music CDs? Yes, it can.
  • Page 21: Troubleshooting Guide

    OR CONTACT CUSTOMER SERVICE AT (954) 660-7100. PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1-800-321-6993.
  • Page 22: Radio Section

    GENERAL Power Source...AV 120V, 60 Hz Battery for the Remote...2 x AAA size Alkaline batteries Left & Right Speakers...2 x 8 ohms. Output Power ... 2 x 12.5W RADIO SECTION Frequency (FM)..87.5 - 108 MHz Frequency (AM) ...520 - 1710 KHz CD SECTION Disc Diameter ...4.72"...
  • Page 23 Memcorp, Inc. Weston, FL Printed in Hong Kong Visit our website at www.memorexelectronics.com...
