- Page 1 MVDP1075 User’s Guide 7'' TFT DISPLAY PORTABLE DVD PLAYER WITH REMOTE CONTROL Before operating this product, please read these instructions completely.
-
Page 2: Table Of Contents
Contents ......1 Important Safety Instructions ..2 Precautions . -
Page 3: Important Safety Instructions
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 4 SURGE PROTECTORS: It is recommended to use a surge protector for AC connection. Lightning and power surges ARE NOT covered under warranty for this product. LASER WARNING: This unit employs a Laser only qualified service personal should attempt to service this device due to possible eye injury.
- Page 5 Dear Customer: Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
-
Page 6: Notes On Handling
NOTES ON HANDLING: • When shipping the DVD player, always use the original shipping carton and packing materials. For maximum protection, repack the unit as it was originally packed at the factory. • Do not use volatile liquids, such as insect spray, near the DVD player. Do not leave rubber or plastic products in contact with the DVD player for a long time. -
Page 7: To Obtain A Clear Picture
TO OBTAIN A CLEAR PICTURE: The DVD player is a high technology, precision device. If the optical pick-up lens and disc drive parts are dirty or worn down, the picture quality becomes poor. To obtain a clear picture, we recommend regular inspection and maintenance (cleaning or parts replacement) every 1,000 hours of use depending on the operating environment. -
Page 8: Power Sources
AC CONNECTION Insert the small end of the AC adapter into the jack on the side of the unit. Insert the other end (with the 2 blades) into a conveniently located AC outlet having 120V AC, 60Hz. DO NOT insert into the DC IN CHARGE jack. -
Page 9: Charging The Battery Pack
CHARGING THE BATTERY PACK “LOW BATTERY” will appear on the screen when the battery is low and needs recharging. The battery can be charged while attached or not attached to the unit as follows: WITH THE BATTERY ATTACHED TO THE UNIT: With the battery pack attached, insert the small end of the AC adapter into the DC IN CHARGE jack on the side of the battery pack or the DC IN jack on the side of the unit. -
Page 10: Location Of Controls
MAIN UNIT Unit OPEN Switch Display Left Speaker MENU Button CHARGE Indicator (Side of the Rechargeable Battery) DC IN CHARGE Jack 9V z (Side of the Rechargeable Battery) DC IN Jack 9V z (Side of the Main Unit) Disc Compartment Disc Door OPEN Button 10. -
Page 11: Side
SIDE 1. VOLUME Control 2. Headphone Jack 3. AUDIO OUT Jack 4. VIDEO/COAXIAL OUT Jack REMOTE 5. S-VIDEO OUT Jack 6. Battery Release Switch (Bottom of the Battery Pack) 7. Battery Pack 1. DISPLAY Button 2. MENU Button 3. STANDBY Button 4. -
Page 13: Connection
CONNECTING THE DVD TO A TV USING THE A/V CABLE (INCLUDED) NOTES FOR CONNECTING TO A TV: • If your TV has an S-Video input, connect the DVD player with the S-Video cable for best results. • Set the TV’s TV/VIDEO button or switch to the VIDEO setting. •... -
Page 14: Connecting The Dvd To A Tv Using The S-Video Cable
CONNECTING THE DVD TO A TV USING THE S-VIDEO CABLE (INCLUDED) NOTES FOR CONNECTING TO A TV: • If your TV has an S-Video input, connect the DVD player with the S-Video cable for best results. • Set the TV’s TV/VIDEO button or switch to the VIDEO setting. •... -
Page 15: Connecting The Dvd To A Home Theater System (Audio Jack)
CONNECTING THE DVD TO A HOME THEATRE SYSTEM (AUDIO JACK) Place the subwoofer, front, rear and center speakers in locations as shown/described here. After correctly positioning the speakers, perform the Tone Test on the AV Amplifier and adjust the Volume control(s) until the desired sound is achieved. -
Page 16: Connecting The Dvd To A Home Theater System (Coaxial Jack)
CONNECTING THE DVD TO A HOME THEATRE SYSTEM (COAXIAL JACK) Place the subwoofer, front, rear and center speakers in locations as shown/described here. After correctly positioning the speakers, perform the Tone Test on the AV Amplifier and adjust the Volume control(s) until the desired sound is achieved. -
Page 17: Playable Discs
ABOUT DISCS The region number for this DVD Player is: See the following page for information regarding region numbers. PLAYABLE DISCS: The following discs can be played back on this DVD player: DISC TYPES: Data on most DVDs is divided into sections called “titles”... - Page 18 ABOUT DISCS (CONTINUED) Notes on Copyright: It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public and rent copyrighted material without permission. DVD video discs are copy protected, and any recordings made from these discs will be distorted. This product incorporates copyright protection technology that is protected by method claims of certain U.S.
-
Page 19: Setup Menu
The Setup Menu lets you customize the DVD player by allowing you to select various language preferences, set up a parental level, turn screen saver on and off, adjust what type of television screen you have and more. Use the following instructions to navigate and change the options as described on the upcoming pages. -
Page 20: General Setup Menu
GENERAL SETUP MENU: Press the SETUP button to enter the menu, select GENERAL SETUP using the Navigation (√,®) buttons, then press the PLAY/ENTER button to select it. Select/change the Setup option as described on page 18. TV DISPLAY General Audio Dolby - - General Setup Page - - Normal/PS... -
Page 21: Audio Setup Menu
CAPTIONS General General Audio Dolby - - General Setup Page - - TV Display Angle Mark OSD Lang Spdif Output Captions Screen Saver Closed Caption When this option is set to ON, Closed Captions will appear on the screen for the hearing impaired (if originally recorded on the DVD). -
Page 22: Dolby Setup Menu
DOLBY SETUP MENU: Press the SETUP button to enter the menu, select DOLBY SETUP using the Navigation (√,®) buttons, then press the PLAY/ENTER button to select it. Select/change the Setup option as described on this page using the Navigation (√,®,π,†) buttons and the PLAY/ENTER button. DUAL MONO General General... -
Page 23: Video Setup Menu
General General Audio Dolby Video VIDEO SETUP MENU: - - Video Setup Page - - Press the SETUP button to enter the menu, select VIDEO SETUP using the Navigation (√,®) buttons, Component Sharpness then press the PLAY/ENTER button to select it. Select/change the setup option as described on this and Brightness the following page using the Navigation (√,®,π,†) buttons and the PLAY/ENTER button. -
Page 24: Preference Setup Menu
General General Audio Dolby PREFERENCE SETUP MENU: - - Preference Page - - Audio English Press the SETUP button to enter the menu, select PREFERENCE SETUP using the Navigation (√,®) Subtitle German buttons, then press the PLAY/ENTER button to select it. Select/change the setup option as described on Disc Menu French Spanish... -
Page 25: Parental
PARENTAL The Parental option enables parents to prevent their children from watching inappropriate material on a DVD. It reads the ratings for programming, then denies access to programming if the program’s rating meets the limitations you select. In this case, the user will have to enter a password. -
Page 26: Password
General Audio General - - Preference Page - - Audio Subtitle Disc Menu Parental PASSWORD Password Default Select this option to change the password. You must know the old password in order to Set Parental Control change it. If you have forgotten the password, call customer service at the number listed on page 41. -
Page 27: Basic Operation
When “ ” appears while pressing a button, this means that the corresponding function cannot be performed either on the disc inserted, or MUTE Press the MUTE button once to mute the sound; “MUTE” will appear on the screen. Press the MUTE button again to restore the sound;... -
Page 28: Display Button
DISPLAY BUTTON While playing a DVD, press the DISPLAY button to cycle as follows: 1st press: Title elapsed time 2nd press: Title remaining time 3rd press: Chapter elapsed time 4th press: Chapter remaining time 5th press: Display off While playing a CD, press the DISPLAY button to cycle between single elapsed time and single remaining time. -
Page 29: Important Notes
IMPORTANT NOTES: • After plugging in, the unit will be in the Power Off mode. Press and hold the Power ON/Play/Pause (®p) button on the main unit for two seconds to turn on the unit; the Power indicator will light. •... - Page 30 Close the disc tray. After loading, the menu screen of the DVD should appear. Use the Navigation (√,®,π,†) buttons 1 to select the desired option and press the PLAY/ENTER button 2 to select it. Adjust the VOLUME control 3 as desired. NOTE: If the menu screen does not appear, press the MENU button to access it.
-
Page 31: Skip
SKIP Press the Skip (n) button 1 to advance the DVD to the beginning of the next chapter. Press the Skip (o) button 2 to move the DVD to the beginning of the current or previous chapters. SLOW MOTION Use this feature to move the DVD in slow motion. During playback, press the SLOW button 1 to move the DVD forward in slow motion speeds of 1/2, 1/4, 1/8, 1/16 and resume... -
Page 32: Title/Chapter Search
TITLE/CHAPTER SEARCH Use this feature to directly go to a specific title and/or chapter. Press the GOTO button 1 once. Press the Navigation (√,®) buttons 2 to select TITLE, then use the Number buttons 3 to select the desired title number. Playback will start immediately. -
Page 33: Repeat Playback
REPEAT PLAYBACK While playing back a DVD, this unit can repeatedly playback a chapter or title. While in the Playback mode, press the REPEAT button once; “ appear on the screen and the currently playing Chapter will repeat continuously. Press the REPEAT button a second time; “... -
Page 34: Audio Menu
AUDIO MENU Press the AUDIO button repeatedly to change the audio language. This feature is not available on all discs. DVD MENU Press the MENU button 1, and the Main Menu of the disc will appear. Use the Navigation (√,®,π,†) buttons 2 to select the desired option, and then press the PLAY/ENTER button 3. -
Page 35: Zoom In
ZOOM IN The image on the screen can be magnified as follows: Press the ZOOM button 1 once during Normal, Slow or Still playback modes, and the unit will zoom x2. Press once or twice more and the unit will zoom x3/x4. Use the Navigation (√,®,π,†) buttons 2 to move the image on the TV screen. -
Page 36: Programmed Playback
PROGRAMMED PLAYBACK The DVD player in this unit has a 20 chapter programmable memory that allows you to program up to 20 chapters on any disc for playback in any desired order. You may program 20 different chapters or you may also program certain chapters to play more than once. To perform Programmed Playback, proceed as follows: During playback of a DVD disc, press the PROGRAM button;... -
Page 37: Cd Operation
PLAYBACK OF A CD Press the STANDBY button on the remote to turn on the unit; the POWER indicator will light. Close the disc tray. After loading, playback will start automatically. To stop playback, press the Stop (X) button. Press the Disc Door OPEN button to open the disc tray, “OPEN”... -
Page 38: Random Playback
RANDOM PLAYBACK SKIP Press the Skip (n) button 1 to advance to the beginning of the next file. Press the Skip (o) button 2 to move to the beginning of the previous file. While in the Stop mode, press the SHUFFLE button 1 once, “SHUFFLE”... -
Page 39: Pause
PAUSE Press the PAUSE button to pause playback; the Pause indicator will appear on the screen. Press again to resume playback; the Pause indicator will turn into the Play indicator again. REPEAT PLAYBACK While playing back a disc, this unit can repeatedly playback 1 or all track(s) on a disc. -
Page 40: Picture Cd Operation
Press the STANDBY button to turn on the unit; the POWER indicator will light. After loading a picture CD, the pictures will automatically show as a slideshow on the screen. Press the Skip (n) 1 or (o) 2 to select the previous or next picture. After the slideshow is done, it will stop. -
Page 41: Troubleshooting Guide
Check the following before requesting service: SYMPTOM GENERAL No power. Power on, but unit not functioning properly. No picture. No sound. Playback picture rolls. The playback picture is poor. The Search feature is not working. The picture is not fitting properly. The remote control is not working. - Page 42 CONTACT CUSTOMER SERVICE AT PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1- 800-321-6993. POSSIBLE CAUSE Rating level set to block the DVD.
-
Page 43: Care And Maintenance
Caring for Discs • Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the disc. • Do not attach adhesive tape, stickers, etc. to the disc label. •... -
Page 44: Compact Disc
Power Requirements ...DC IN 9V (Center Positive z) Battery Packs...Li-Polymer Rechargeable Battery DC 7.4V 2600mAh Power Consumption...8.5W Weight ...2 Lbs Dimensions...(Main unit without battery pack) 8.2 x 6.4 x 1.6 inches Operating Temperature...+5° to +35°C Operating Humidity Range ...5% to 90% (no condensation) Accessories...AC Adapter, Rechargeable Battery, Remote Control ...Remote Battery, Car Adapter, Audio cable, Audio(Coaxial)Video Cable, S-Video Cable Discs Played:... - Page 45 Memcorp, Inc. Weston, FL Printed in Hong Kong Visit our website at www.memorexelectronics.com...
