Memorex MX4302 Operating Instructions Manual

Home audio system with cd player and am/fm stereo radio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MX4302.O/M.QXD
3/4/03
7:47 AM
Page 21
HOME AUDIO SYSTEM WITH CD
PLAYER AND AM/FM STEREO RADIO
MODEL: MX4302
BEFORE OPERATING THIS PRODUCT, PLEASE READ THESE
INSTRUCTIONS COMPLETELY.

OPERATING INSTRUCTIONS

Advertisement

Table of Contents
loading

Related Manuals for Memorex MX4302

Summary of Contents for Memorex MX4302

  • Page 1: Operating Instructions

    MX4302.O/M.QXD 3/4/03 7:47 AM Page 21 HOME AUDIO SYSTEM WITH CD PLAYER AND AM/FM STEREO RADIO MODEL: MX4302 BEFORE OPERATING THIS PRODUCT, PLEASE READ THESE INSTRUCTIONS COMPLETELY. OPERATING INSTRUCTIONS...

  • Page 2: Fcc Warning

    PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. Model Number: MX4302 Serial Number: _______________________________________...
  • Page 3 MX4302.O/M.QXD 3/4/03 7:47 AM IMPORTANT SERVICE SAFETY INSTRUCTIONS Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna.

  • Page 4: Preparation For Use

    MX4302.O/M.QXD 3/4/03 7:47 AM AC OPERATION Unwind the AC cord and extend it to its full length. Insert the small end of the AC cord into the AC power jack on the rear of the unit. Insert the other end of the AC cord into any convenient 120V 60Hz household outlet.

  • Page 5: Battery Operation

    MX4302.O/M.QXD 3/4/03 7:47 AM PREPARATION FOR USE (CONTINUED) BATTERY OPERATION The battery compartment is located on the rear of the remote control. • Remove the battery compartment door by pressing down and sliding the door in the direction of the arrow.

  • Page 6: Location Of Controls And Indicators

    MX4302.O/M.QXD 3/4/03 7:47 AM LOCATION OF CONTROLS AND INDICATORS 1. Display 2. Speaker Terminals (Rear of Unit) 3. POWER Button and Remote Sensor 4. STOP( )/BAND Button 5. TUNING/CD Skip/Search 6. PLAY/PAUSE ( ) Button 7. TUNING/CD Skip/Search 8. REPEAT/MEMORY UP Button 9.

  • Page 7: Function Button

    MX4302.O/M.QXD 3/4/03 7:47 AM LOCATION OF CONTROLS AND INDICATORS REMOTE 1. FUNCTION Button 2. Direct Track Selection Buttons 3. OVER Button 4. PLAY/PAUSE Button 5. STOP/BAND Button 6. TUNING DN/UP Buttons 7. RANDOM Button 8. DISPLAY Button 9. INTRO Button 10.

  • Page 8: Setting The Clock

    MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS SETTING THE CLOCK With the power off, press and hold the MEMORY/CLOCK SET button; “24H” will blink. Press the TUNING/CD Skip/ Search button to set the current hour, then press MEMORY/CLOCK button again; the minute digits will blink.
  • Page 9 MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS (CONTINUED) DISPLAY BUTTON (REMOTE CONTROL ONLY) PRESET EQ MUTE COLOR BUTTONS When the unit is on, the display will cycle through the colors of the selected Color options - experiment for your favorite color sequence! Change the color selection, or hold a particular color as follows:...

  • Page 10: Listening To The Radio

    MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS (CONTINUED) LISTENING TO THE RADIO Press the POWER button to turn the unit on. Press the TUNING/CD Skip/ Search button to select a station (see Tuning note below). NOTE: If the FM band is selected...

  • Page 11: Setting Radio Presets

    MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS (CONTINUED) SETTING RADIO PRESETS This unit can preset 10 AM and 10 FM radio stations for convenient recall. Press the POWER button to turn the unit on. Press the MEMORY/CLOCK SET button . Within four seconds,...

  • Page 12: Playing Compact Discs

    MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS (CONTINUED) PLAYING COMPACT DISCS NORMAL PLAYBACK Press the POWER button to turn the unit on. The CD player will read the table of contents on the disc and the total number of tracks and total playing time on the disc will appear in the display.

  • Page 13: Cd Pause Control

    MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS (CONTINUED) CD PAUSE CONTROL During CD playback, if you wish to pause the disc momentarily, press the PLAY/PAUSE ( button again. Playback stops but the disc continues to spin and the time display will blink.

  • Page 14: Repeat Playback

    MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS (CONTINUED) REPEAT PLAYBACK To repeat a single track, while in Stop mode, press REPEAT/MEMORY UP button once; “REPEAT” will blink in the display. Press the CD Skip/Search button to select the specific track that you wish to repeat.

  • Page 15: Programmed Repeat

    MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS (CONTINUED) Press the CD Skip/Search button to select the first track that you wish to program. When the desired track number appears in the display, press the MEMORY/CLOCK SET button again. NOTE: If no button is pressed within five seconds, the unit will revert back to the total time/tracks on the CD.

  • Page 16: Random Playback

    MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS (CONTINUED) RANDOM PLAYBACK To play the tracks on the CD in a random order, while in the Stop mode, press the RANDOM button. Playback will start automatically and all the tracks will play in a random order.

  • Page 17: Setting The Timer

    MX4302.O/M.QXD 3/4/03 7:47 AM OPERATING INSTRUCTIONS (CONTINUED) SETTING THE TIMER Set the timer to turn the unit on to the Tuner or CD mode at a preset time as follows : NOTE: Please make sure the volume is set to the desired level to wake you up.

  • Page 18: Care And Maintenance

    MX4302.O/M.QXD 3/4/03 7:47 AM Caring for Compact Discs • Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the compact disc. • Do not attach adhesive tape, stickers, etc. to the compact disc label.

  • Page 19: Troubleshooting Guide

    MX4302.O/M.QXD 3/4/03 7:47 AM TROUBLESHOOTING GUIDE Should this unit exhibit a problem, check the following before seeking service: Symptom Possible Cause Radio Noise or sound distorted Station not tuned properly for on radio broadcasts. AM or FM. FM: Wire Antenna is not extended.
  • Page 20 OR CONTACT CUSTOMER SERVICE AT 1-800-919-3647. PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1-800-321-6993.
  • Page 21 MX4302.O/M.QXD 3/4/03 7:47 AM Page 20 Memcorp, Inc. Weston, FL Printed in Hong Kong Visit our website at www.memorexelectronics.com...
