- Page 1 MP8700 User’s Guide Portable CD Player with AM/FM Stereo Radio Before operating this product, please read these instructions completely.
- Page 2 PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. For future reference, record the serial number of the unit printed on the rear of the cabinet.
- Page 3 Dear Customer: Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
-
Page 4: Safety Instructions
Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna. READ INSTRUCTIONS All the safety and operating instructions should be read before the product is operated. -
Page 5: Location Of Controls
FRONT VOLUME Control (Side of Unit) Display CD Door Open/Close Area Power Button MODE/CH+ Button PROG./CH SAVE Button HOLD Switch Headphones Jack Strap Holder 10. BAND (AM/FM) Button 11. BBS (Bass Boost) Button 12. Tune/Skip/Search o Button 13. PLAY/PAUSE (®p)/CD Button 14. -
Page 6: Power Sources
This unit is designed to operate on AC household current or DC (batteries). AC OPERATION To operate the unit using AC power, connect an AC adapter (included) to an AC outlet having 120V, 60Hz AC only. Plug the small end into the DC jack on the rear of the unit and connect the other end into the AC outlet. -
Page 7: Connecting The Strap
CONNECTING THE STRAP Insert the small arm straps into the slots on both sides of the unit and pull through. Connect the larger strap to the connected smaller straps. Insert the strap into the gap, pull through and then insert into the other gap. Pull tight to fasten. -
Page 8: Radio Operation
TO PLAY THE RADIO Press the POWER button to turn the unit on. AUTOMATIC TUNING: Press and hold the Tune/Skip/Search o 1 or n button until the frequency in the display starts to scan, and then release the button; the tuner will search and then stop on the next strong station it finds. - Page 9 RADIO OPERATION (CONTINUED) RADIO PRESETS - UP TO 5 AM AND 5 FM Press the POWER button to turn the unit on. Press the PROG./CH SAVE button 1; the preset number will blink in the display. Within three seconds, press the MODE/CH+ button 2 repeatedly until the desired memory number appears on the display.
- Page 10 COMPACT DISC (CD) OPERATION (CONTINUED) TO PLAY A CD (STANDARD CD, CD-R AND CD-RW CAN BE USED) Insert a CD as described on page 8. With the power on, press PLAY/PAUSE (®p)/CD button to select CD; playback will start automatically. To skip forward or backward through the tracks on the disc, press the Tune/Skip/Search o 1...
- Page 11 COMPACT DISC (CD) OPERATION (CONTINUED) TO REPEATEDLY PLAY BACK ONE TRACK Insert a CD as described on page 8. With the power on, press PLAY/PAUSE (®p)/CD button to select CD; playback will start automatically. TO REPEATEDLY PLAY BACK ALL TRACKS Insert a CD as described on page 8.
- Page 12 COMPACT DISC (CD) OPERATION (CONTINUED) TO PROGRAM THE MEMORY (UP TO 20 TRACKS) Insert a CD as described on page 8. With the power on, press PLAY/PAUSE (®p)/CD button to select CD; playback will start automatically. Select the first track to be played back using the Tune/Skip/Search o 1 or n 2 button.
-
Page 13: Random Playback
COMPACT DISC (CD) OPERATION (CONTINUED) RANDOM PLAYBACK While in the CD Stop mode, press the MODE/CH+ button once, the "RANDOM" indicator will appear in the display. INTRO PLAYBACK While in the CD Stop mode, press the MODE/CH+ button twice, the "INTRO"... -
Page 14: Care And Maintenance
CARE AND MAINTENANCE Caring for Compact Discs • Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the compact disc. • Do not attach adhesive tape, stickers, etc. to the disc label. •... -
Page 15: Troubleshooting Guide
AT WWW.MEMOREXELECTRONICS.COM OR CONTACT CUSTOMER SERVICE AT PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1-800-321-6993. -
Page 16: Specifications
SPECIFICATIONS GENERAL: Power Source...DC IN 9V, Center Positive Battery ...9V DC (6 x 1.5V "C" size batteries) Alkaline is recommended for longer life Speaker..2 x 3W 4 Ohms Output Power ... 2 x 1.2W RADIO SECTION: Frequency Range (FM)...87.5 - 108 MHz Frequency Range (AM) ...520 -1710 KHz CD SECTION: Disc Diameter ...4.72"... - Page 17 Memcorp, Inc. Weston, FL Printed in Hong Kong Visit our website at www.memorexelectronics.com...
