Summary of Contents for Memorex MT3010OM
- Page 1 MT3010 User’s Guide 30" Wide-screen LCD Stereo HDTV* Monitor with Integrated TV Tuner * High Definition (HDTV) monitors require an optional set-top box to receive true digital high definition broadcasts. Before operating this product, please read these instructions completely.
-
Page 2: Table Of Contents
CONTENTS Contents ...1 Important Safety Instructions...2 Power Source...4 Location of Controls ...4 • Front...4 • Rear Panel ...5 Remote Control...6 • Battery Installation ...7 • Effective Distance of the Remote Control Transmitter ...7 Cable (CATV)/Satellite Connections ...8 Outdoor Antenna Connections ...9 VCR Connections ...10 DVD Connections ...12 Stereo Connection...13... -
Page 3: Important Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. TO PREVENT ELECTRIC SHOCK, MATCH THE WIDE BLADE OF THE PLUG TO THE WIDE SLOT AND FULLY INSERT. - Page 4 IMPORTANT SAFETY INSTRUCTIONS (CONTINUED) 13. LIGHTNING To protect your product from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.
-
Page 5: Power Source
To operate the unit using AC power, connect the AC Adapter to the AC jack on the rear of the unit, then connect the AC adapter to a wall outlet having 120V AC, 60Hz only. NOTE: If the AC adapter’s plug does not fit into a nonpolarized outlet, do not file or cut the wide blade. -
Page 6: Rear Panel
LOCATION OF CONTROLS (CONTINUED) REAR PANEL 1. HDTV IN Jacks (R/L/P 2. S IN Jacks (R/L/S) 3. AV IN Jacks (R/L/V) 4. VGA IN Jack 5. UHF/VHF Antenna Jack 6. AUDIO OUT Jacks (R/L) 7. VGA AUDIO IN Jacks (R/L) 8. -
Page 7: Remote Control
1. RECALL Button 2. CH LOCK Button 3. TV/AV/PC Button 4. CHANNEL Up Button 5. VOLUME Down Button 6. CHANNEL Down Button 7. MTS Button 8. VIDEO MODE Button 9. WIDE Button 10. AUDIO MODE Button 11. SRS (Surround Sound) Button 12. -
Page 8: Battery Installation
BATTERY INSTALLATION – – Follow these precautions when using batteries in this device: 1. Use only the size and type of batteries specified. 2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment. Reversed batteries may cause damage to the device. -
Page 9: Cable (Catv)/Satellite Connections
CABLE (CATV)/SATELLITE CONNECTIONS This TV has an extended tuning range and can tune most cable channels without using a Cable TV converter box. Some Cable TV companies offer “premium pay channels” in which the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the cable company. -
Page 10: Outdoor Antenna Connections
OUTDOOR ANTENNA CONNECTIONS OUTDOOR VHF/UHF ANTENNA CONNECTION (ANTENNA NOT SUPPLIED) Follow the instructions for the type of antenna system you intend to use. Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire) VHF/UHF 75 Ohm Connect the 75 ohm cable from the combination VHF/UHF antenna to the antenna jack. -
Page 11: Vcr Connections
CONNECTION USING COAXIAL CABLE: Follow the instructions below to connect a VCR to your television using a 75 ohm coaxial cable. (CABLES NOT INCLUDED.) REAR OF TV 1. Connect the cable, satellite or incoming antenna to the VHF/UHF IN jack on the rear of the VCR. 2. - Page 12 CONNECTION USING S-VIDEO CABLE: Follow the instructions below to connect an S-VIDEO VCR to your television using an S-video cable. (CABLES NOT INCLUDED.) INCOMING CATV CABLE From VCR AUDIO OUT jacks 1. Connect the cable, satellite or incoming antenna to the ANT jack on the rear of the VCR. 2.
-
Page 13: Dvd Connections
CONNECTION USING AUDIO/VIDEO CABLES: Follow the instructions below to connect a DVD player to your television using Audio/Video cables. (CABLES NOT INCLUDED.) DVD PLAYER From DVD OUT AUDIO/VIDEO jacks 1. Connect the left and right audio cable from the DVD’s Audio OUT jacks to the TV’s audio left and right AV IN jacks. Connect the DVD’s video OUT jack to the TV’s video AV IN jack. -
Page 14: Stereo Connection
CONNECTION USING COMPONENT CABLES: Follow the instructions below to connect a DVD player to your television using the Cr, Cb, Y jacks. (CABLES NOT NOTE: Connecting the DVD player to the TV using the component cables will provide the highest quality picture. Connecting using an S-video cable will provide the next highest quality picture, followed by standard Audio/Video cable connection. -
Page 15: Hdtv Connection
Follow the instructions below to connect an HDTV set top box to your television. (CABLES NOT INCLUDED.) AUDIO/VIDEO Cord HDTV SET TOP BOX From HDTV OUT jacks Video Cord 1. Connect the left and right audio cable from the HDTV’s Audio OUT jacks to the TV’s HDTV left and right Audio IN jacks. 2. -
Page 16: Wall Mounting The Unit
Please follow the instructions and figure below to install the unit using the supplied wall brackets and Hook Assemblies: 1. Before wall mounting the unit, you must remove the base stand as follows: a. Remove the two screws, then remove the base cover as shown in figure 1. b. - Page 17 WALL MOUNTING THE UNIT (CONTINUED) 2. Drill four 5mm holes through the wall for each bracket, or if there is a stud behind the wall where you are putting the bracket, drill four 5mm holes through the wall and into the studs for each bracket.
-
Page 18: Clock Setting
Press the POWER button ‚ to turn on the TV; the POWER indicator will light green. Press the MENU button ƒ; the MENU screen will appear. Set the hours using the VOLUME DOWN button ‚ and set the minutes using the VOLUME UP button ƒ. Press the CHANNEL UP ‚... -
Page 19: Setting The Air/Cable Option
Set the AIR/CABLE option as follows: Press the POWER button ‚ to turn on the TV; the POWER indicator will light green. Press the MENU button ƒ; the MENU screen will appear. Press the VOLUME UP ‚ or DOWN ƒ button to select between AIR and CABLE. -
Page 20: Setting The Channels Into Memory
SETTING THE CHANNELS INTO MEMORY This TV is equipped with a channel memory feature which allows channels to skip up or down to the next channels set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the TV’s memory. In addition to normal VHF/UHF channels, this TV can receive up to 113 Cable TV channels. -
Page 21: Setting Channels Into Memory
After setting channels into memory, you can add or delete channels as follows: Press the POWER button ‚ to turn on the TV; the POWER indicator will light green. Press the MENU button ƒ; the MENU screen will appear Select a channel to be skipped or added using the VOLUME UP ‚... -
Page 22: Setting Favorite Channels
Set up to ten channels into the Favorite Channel Preferences to easily access the channel. Set as follows: Press the POWER button ‚ to turn on the TV; the POWER indicator will light green. Press the MENU button ƒ; the MENU screen will appear Select a channel to be added to the Favorite Channel Preferences using the VOLUME UP ‚... -
Page 23: Setting The Sleep Timer
To set the TV to turn off after a preset amount of time, follow the steps below: Press the POWER button ‚ to turn on the TV; the POWER indicator will light green. Press the MENU button ƒ; the MENU screen will appear Select the desired sleep time from 10 minutes (“10M”) to 90 minutes (“90M”) using the VOLUME UP ‚... -
Page 24: Tv Operation
Press the POWER button to turn on the TV; the POWER indicator will light green. Adjust the volume level by pressing the VOLUME UP ‚ or DOWN ƒ button. The volume level will be indicated on the screen by a green numerical display between 0 and 100 where 0 is the lowest setting and 100 is the loudest. -
Page 25: Mute
MUTE Press the MUTE button ‚ to turn off the sound. The TV’s sound will be silenced and “AUDIO MUTE” will appear on the screen for a few seconds. The sound can be turned back on by pressing this button again or one of the VOLUME UP ƒ... -
Page 26: Display
DISPLAY Press the DISPLAY button once to show the time. Press again to show the mode (i.e. S-VIDEO). Press a third time to clear the screen or wait three seconds and the screen will clear automatically. AUDIO MODE Press to select a mode (PRESET, SOFT or USER) as set on page 29. -
Page 27: Wide
WIDE Press the WIDE button to select one of the screen modes: FULL: The image will stretch to cover the full screen; use this MODE when viewing wide-screen programming material. M1: The image will increase slightly over the standard size M2: The image will increase slightly over M1. -
Page 28: Closed Captions
WHAT IS CLOSED CAPTIONING? This television has the capability to decode and display Closed Captioned television programs. Closed Captioning will display text on the screen for hearing impaired viewers or it will translate and display text in another language. CLOSED CAPTIONING WITH A VCR Closed Captioned programs can be recorded and played back on a VCR with the Closed Captioned text intact. -
Page 29: On-Screen Control Adjustments (Picture)
ON-SCREEN CONTROL ADJUSTMENTS (PICTURE) Press the POWER button ‚ to turn on the TV; the POWER indicator will light green. Press the MENU button ƒ; the MENU screen will appear. Using the VOLUME UP ‚ or DOWN ƒ button, select SOFT or PRESET to access the preset settings. -
Page 30: On-Screen Control Adjustments (Sound)
ON-SCREEN CONTROL ADJUSTMENTS (SOUND) Press the POWER button ‚ to turn on the TV; the POWER indicator will light green. Press the MENU button ƒ; the MENU screen will appear. Using the VOLUME UP ‚ or DOWN ƒ button, select SOFT or PRESET to access the preset settings. -
Page 31: Screen Settings
Press the POWER button ‚ to turn on the TV; the POWER indicator will light green. Press the MENU button ƒ; the MENU screen will appear. Turn this option ON or OFF using the VOLUME UP ‚ or DOWN ƒ button. If set to ON, the TV will show the picture in picture. - Page 32 Press the CHANNEL UP ‚ or DOWN ƒ button until SWAP is selected. Turn this option ON or OFF using the VOLUME UP „ or DOWN … button. If set to ON, the PIP/POP screens will swap. Press the MENU button once when finished to return to the Main menu.
-
Page 33: Setting V-Chip
V-Chip enables parents to prevent their children from watching inappropriate material on TV. V-Chip reads the ratings for programming (except for news, sports, unedited movies on premium cable and Emergency System signals), then denies access to programming if the program’s rating meets the limitations you select. In this case, the program will be blocked. V-CHIP SET-UP Press the POWER button ‚... -
Page 34: Mpaa Rating Set-Up
SETTING PARENTAL CONTROL (CONTINUED) MPAA RATING SET-UP Enter the V-CHIP menu screen as described on page 32. Press the CHANNEL UP ‚ or DOWN ƒ button to select a rating, then press the the VOLUME UP „ or DOWN … button to block (see below). -
Page 35: Tv Rating Set-Up
SETTING PARENTAL CONTROL (CONTINUED) TV RATING SET-UP Enter the V-CHIP menu screen as described on page 32. Press the CHANNEL UP ‚ or DOWN ƒ button to select a rating, then press the the VOLUME UP „ or DOWN … button to block (see below). -
Page 36: Changing The Password
SETTING PARENTAL CONTROL (CONTINUED) CHANGING THE PASSWORD Enter the V-CHIP menu screen as described on page 32. Use the VOLUME UP ‚ or DOWN ƒ buttons to select the first digit (0-9), then use the CHANNEL UP „ or DOWN … button to select “1ST PASSWORD”... -
Page 37: Setting The On Timer
Press the POWER button ‚ to turn on the TV; the POWER indicator will light green. Press the MENU button ƒ; the MENU screen will appear. Turn this option ON or OFF using the VOLUME UP ‚ or DOWN ƒ button. Set the hours using the VOLUME DOWN button ‚... -
Page 38: Troubleshooting Guide
Check the following before requesting service: SYMPTOM POSSIBLE CAUSE POWER No power. The AC power cord is not connected. TV BROADCAST RECEPTION TV station experiencing problems. Poor or no picture. Picture control is not adjusted. Possible local interference. Antenna/CATV connector is not connected. TV station experiencing problems. -
Page 39: Reception Disturbances
RECEPTION DISTURBANCES Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF antenna. Outdoor antennas are recommended for best results if not using cable or a satellite. The most common types of television interference are shown below. -
Page 40: Specifications
Item Characteristics LCD Panel Type Active Display Area Pixel Pitch Max.Resolution Contrast Ratio Brightness Response Time Display Color Viewing Angle Back Light Lamp Life TV System Color System Sound System Stereo System Channel System TV Tuner System CATV Subtitles TV Performance Video System Video Signal Video Color System... -
Page 41: Care And Maintenance
OR CONTACT CUSTOMER SERVICE AT 1-800-919-3647. PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1-800-321-6993. - Page 42 Memcorp, Inc. Weston, FL Printed in Taiwan Visit our website at www.memorexelectronics.com...
