Summary of Contents for Mega A-5507-H

  • Page 1 MELCHOR GABILONDO, S.A. Polígono Industrial Eitua, 6 / 48240 Bérriz (Vizcaya) ESPAÑA / Tel. 94 622 50 90 Intl.: 34-94 622 50 90 / Telefax: 94 622 52 78 / Intl.: 34-94 622 52 78 Teléfono Ventas: 94 622 50 30 / Telefax Ventas: 94 682 73 50 E-MAIL: interior@mega-sa.com / export@mega-sa.com Web: www.mega.es...
  • Page 3 The high reputation of MEGA abroad has enabled us to consolidate a firm position on the markets of all five continents. Plate laser cutting and welding Head office and factory of hydraulic components. BERRIZ facilities. CEGAMA We have come a long way, but after more than fifty years our course is still market by the desire to achieve quality and innovation so that we can live up to our permanent...
  • Page 4 Always use a cylinder of a capacity and hydraulic stroke 25% higher than the weight of the load to be lifted. Position the cylinder on a solid, even Clean couplers before connecting and make and horizontal surface. sure the connections are securely tightened. Never use the cylinder on a slope.
  • Page 5 / in Hose Transmits the oil flow. Page 28 A-5507-M Male quick coupler Oil volume Page 28 of cylinder A-5507-H Female quick coupler Page 28 Gauge To control pressure. Page 29 Gauge adapter for each meter To mount the gauge.
  • Page 6 These cylinders are fitted with a removable grooved saddle, pressure mounted or screwed in the piston head. They are also equipped with a high flow female quick coupler with dust cap, ref. A-5507-H. Maximum Ref. Stroke capacity CSRA-5A...
  • Page 7 Each ram is equipped with a female quick coupler with air dust cap, ref. A-5507-H. With mounting holes and protected threaded areas against possible blows for easy coupling or special tooling applications.

  • Page 8: General Application

    With built-in bronze guide for easier sliding of piston. These cylinders are fitted with a removable grooved saddle, pressure mounted or screwed in the piston head. They are also equipped with a female quick coupler with dust cap, ref. A-5507-H. Ref. Stroke CSB-11A CSB-23B CSB-31B...
  • Page 9 They are also equipped with a high flow female quick coupler with dust cap, ref. A-5507-H. Carry handles on models weighing from 20 kg/44 lbs to 40 kg/88 lbs Heavier models are fitted with eye hooks for transport.
  • Page 10 All pistons have a hard chrome plating treatment to resist corrosion. Equipped with high flow female quick coupler with dust cap, ref. A-5507-H and carrying handle. Designed for pulling and tensioning applications, they can be used in those operations where two heavy pieces have to be put one near the other.

  • Page 11: Double-Acting Cylinders

    Are also equipped with a high flow female quick coupler with dust cap, ref. A-5507-H. Carry handles on models weighing from 20 kg/44 lbs to 40 kg/88 lbs. Heavier models are fitted with eye hooks for transport.
  • Page 12 These cylinders are fitted with a removable saddle, and are also equipped with a high flow female quick coupler with dust cap, ref. A-5507-H. Carry handles on models weighing from 20 kg/44 lbs to 40 kg/88 lbs. Heavier models are fitted with eye hooks for transport.
  • Page 13 H Y D R A U L I C T O O L S Spread cylinder SH-1 Spring return Capacity: 1 t Weight: 3,5kg / 7,7lbs Fitted with female quick coupler, ref. A-5506-H. Widely used for spreading operations in tight spaces where a high force is required.

  • Page 14: Hydraulic Pumps

    H Y D R A U L I C P U M P S Single-acting hand pumps BM-04, BM-1, BM-2 and BMPA-1 All are single acting, one-speed hand pumps, and can be used as a portable hydraulic tool or in a fixed position. They can operate both in a horizontal or vertical position.
  • Page 15 H Y D R A U L I C P U M P S Air hydraulic pumps NS-1, NS-21, NS-22 and NAP-3 Single-acting, one-speed air pumps. Air driven pumps for operation where electric power is not available or dangerous. With safety relief valve, factory rated at the maximum working pressure. Once the NS-1, NS-21 and NS-22 air pumps are connected to the air line, press down on the back section of pedal for operation.
  • Page 16 A Series Adapters These adapters allow an easy way of fitting the gauge into cylinder or pump. Characteristics Complete A-5507 coupler Male quick A-5507-M coupler Female quick A-5507-H coupler Complete A-5506 coupler Male quick A-5506-M coupler Female quick A-5506-H coupler Complete...
