Sentrol ZX400 Installation Manual

Hide thumbs Also See for ZX400:
Table of Contents

Advertisement

Quick Links

See also: Programming Manual , Operating Manual
SENTROL ZX400/ZX410
Security System Control
Installation
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZX400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sentrol ZX400

Summary of Contents for Sentrol ZX400

  • Page 1 SENTROL ZX400/ZX410 Security System Control Installation...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Table of Contents New Features ......................5 ZX400/ZX410 Wiring Diagrams................6 ZX400/ZX410 Terminal Descriptions ................ 8 “2 in 1” Zoning™ ...................... 9 Conventional Methods of Wiring ................11 Class ‘B’ End-Of-Line Resistor Supervised Zones ............. 11 Non-Supervised Closed Circuit Loop (No EOL Resistor Supervision) ...... 11 Control Station Addressing and Supervision ............
  • Page 4 TABLE OF CONTENTS Specifications And Features ..................25 Control Board ......................25 Power Supply ......................25 Recommended Battery ................... 25 Recommended Transformer ................... 25 Enclosure ........................ 25 Digital Communicator .................... 25 Control Stations ..................... 26 ZXLCD Control Station ................... 26 ZXVFD Control Station ...................

  • Page 5: New Features

    The Sentrol ZX400/ZX410 Security Control features ity. Using the Series 4000 Wireless System, you can ease of installation and programming. The ZX400/ expand the ZX400/ZX410 to include up to 16 wire- ZX410 is easily programmed with any one of four less zones.

  • Page 6: Zx400/Zx410 Wiring Diagrams

    FLOAT BATTERY VOLTAGE: SMOKE DETECTOR BROWN BROWN 13.6 - 13.8V SENTROL 2-WIRE MODELS Max. current: 500mA. (See ZX400/ZX410 Interconnect Label POWER SUPERVISION UNIT P/N 64600310-NOTE 2) QUIESCENT CHARGE ESL MODEL 204-12/24V OR EQUIV. CURRENT: 20mA. Replacement: Every 3 - 5 years.
  • Page 7 ZX400/ZX410 WIRING DIAGRAMS MPI-206 SUPV TELEPHONE INSTALL SUPERVISION JUMPER CONNECTION TO TERMINAL 7 JUMPER TO TERMINAL 4 MPI-206 PROGRAMMABLE OUTPUT 1 CONNECTION SENTROL RJ38 CORD PG01 (shown) TO TERMINAL 10 TO TERMINAL 20 OPTIONAL - When relay is required OPTIONAL - When Telco Supervision is required...

  • Page 8: Zx400/Zx410 Terminal Descriptions

    ZX400/ZX410 TERMINAL DESCRIPTIONS ZX400/ZX410 Terminal Descriptions TERMINAL FUNCTION DESCRIPTION 1, 2 AC Input Connect the appropriate UL Class II transformer using 18 gauge minimum 2 conductor wire. Do not exceed 50 feet. Use a 16.5 VAC 35 VA transformer or an optional 16.5 VAC 20 VA transformer.

  • Page 9: In 1" Zoning

    The Sentrol ZX400/ZX410 Security Control intro- duces an all new method of wiring zones that saves both time and wire costs. “2 in 1” Zoning™ allows 1500Ω...
  • Page 10 “2 in 1” Zoning™ CONDITION NOMINAL LOOP RESISTANCE VOLTAGE READING Primary Zone and Secondary Zone Infinite Ohms 5.24 - 8.25 V Open Contacts; Loop Cut or Open Secondary Zone Open Contact, 1500 Ohms 4.24 - 5.23 V Primary Zone Normal Primary Zone Open Contact, 825 Ohms 3.24 - 4.23 V...

  • Page 11: Conventional Methods Of Wiring

    Form A and Form B devices are either a short or an open condition. See the ZX400/ connected and provides a high degree of protec- ZX410 Programming Manual for programming an un- tion against compromise or tampering.

  • Page 12: Control Station Addressing And Supervision

    CONTROL STATION ADDRESSING AND SUPERVISION Control Station Addressing and Supervision All Control Stations are shipped from the factory as NOTE Control Station #1 and supervised. They may be set When unsupervised Control Stations to other addresses and to unsupervised as described are used, ALL unsupervised LED Con- below.

  • Page 13: Control Station Troubleshooting

    CONTROL STATION TROUBLESHOOTING Control Station Troubleshooting If a Control Station is incorrectly wired, it will not accept keystroke entries. The following symptoms may appear: SYMPTOM CONDITION No Control Station LED’s or display Black or Red Wire removed or cut No response from key presses Green Wire removed or cut or two supervised Control Stations at the same address LED’s flash and may display “No Communication...

  • Page 14: 12 Vdc Outputs

    MADE IN (USA) Output conditions can be programmed as one of ASSEMBLED IN USA many conditions. Refer to the ZX400/ZX410 Pro- gramming Manual for programming information and restrictions. OUTPUTS 1 2 3 4 5 6 7 8 9 10 NEG 12V...
  • Page 15 12 VDC AND ADDITIONAL OUTPUTS Outputs may be wired to indicator devices or re- TAN WIRE lay module triggers (like the MPI-206) provided Output 1 470Ω the 40 mA current draw condition is not exceeded. BLACK WIRE Figure 10 shows a wiring example for a relay to Connects to J3 (part of 12-wire cable) ODM 1 Output 2.

  • Page 16: Expansion Zones

    (ZXEXP, ZEM, RF Gate- way 1 or RF Gateway 2). Assignment of these zones to expansion devices is done through programming (see ZX400/ZX410 Programming Manual). The options available for all zones are described in the table below.

  • Page 17: Zxexp Zone Expander Module

    ZXEXP Zone Expander Module Installation This module provides an additional 8 zones for the ZX400/ZX410 Control. If “2 in 1” Zoning™ is de- 1. Remove the plastic lid from the ZXEXP Zone sired, this module provides 16 zones. All zones are Expander Module.

  • Page 18: Wireless Devices

    WIRELESS DEVICES Wireless Devices The ZX400/ZX410 provides an option for including key. Next press the RF Zone Device Number (13 to 28). The Control Station will display and sound the Wireless (or RF) Devices.The RF Devices may consist of RF Zone Devices (Universals, Door Contacts,...

  • Page 19: Fire Zone Modules

    Always use a ZEM/ODM Mounting Hardware Pack Class B Fire zones. These zones may be connected (P/N 13000515). Connect the ZEM to the ZX400/ to ZEM Fire Zone Expansion Modules. There are two ZX410 local data bus using one of the ZEM’s two models of ZEMs available: data bus connectors.
  • Page 20 FIRE ZONE MODULES Connect initiating devices to the ZEM (see figures below). Databus Connector Databus Connector (2502) 429C ZONE 1 ZONE 2 2.7K 429C 2.7K Zone 1 is shown with 2-wire detectors, wired in Class B (Style B) FIGURE 15 Class B Connection Databus Connector...

  • Page 21: Zrm Zone Relay Module

    FIRE ZONE MODULES ZRM Zone Relay Module ZXCFK Fire Module Kit The ZXCFK Fire Module Kit is designed to provide The ZRM Zone Relay Module is a zone follower with the hardware necessary to upgrade a ZX410 to meet a relay following its corresponding zone on a ZEM. the requirements for a UL Listed commercial fire sys- A ZRM plugs directly into a ZEM and only requires tem per UL 864/NFPA 72 Local Protective Signaling...

  • Page 22: Power Issues

    12 VDC, 7 Ah sealed lead acid batteries must To Bat. - On The Control be installed utilizing the Dual Battery Harness pro- vided as shown in Figure 18. FIGURE 18 Connection of the Dual Battery Harness ZX400/ZX410 Power Worksheet TOTAL TOTAL TOTAL STANDBY STANDBY...

  • Page 23: Auxiliary Power Supply Installation

    POWER ISSUES Auxiliary Power Supply Installation To increase the available current supplied by the When using this power supply on a listed system, a duplex utility cover for the primary power outlet must control, a HCP-12SULC Power Supply may be added. Each HCP-12SULC supplies an additional 450 mA of be installed.

  • Page 24: Zxptr Printer Interface Module

    ZXPTR PRINTER INTERFACE MODULE ZXPTR Printer Interface Module The optional ZXPTR Printer Interface Module con- nects to the local data bus and can be used for print- ing events in real-time or on command. This mod- ule interfaces with any Centronics-style parallel printer.

  • Page 25: Specifications And Features

    SPECIFICATIONS AND FEATURES Specifications And Features Recommended Battery Control Board Rechargeable 12 VDC 7 Ah sealed lead acid. Use • Six (6) two-wire zones, each supervised with a • two (2) batteries to meet CSFM and Household 1500 Ohm end-of-line resistor. “2 in 1” Zon- Fire requirement of 24-hour standby at 450 mA.

  • Page 26: Control Stations

    • Dual and split reporting capability. 154.4 mm x 26.0 mm). Pager capability with 16-digit programmable • message and 2-digit coded messages. Sentrol communication defaults for quick pro- • ZXLED12 Control Station gramming. • Disable call waiting. Thirteen (13) LEDs annunciate general purpose •...

  • Page 27: Output Provisions

    Nominal current drain: 45 - 55 mA without • 4655 Sharpshooter PIR with Transmitter and printer connected. battery. • ZX410 - ZX400 Control board mounted in • 4004 Four Button Wireless Key Transmitter and EX1414 enclosure. (The ZX410 assembly is re- Battery. quired for Burglary applications).

  • Page 28: List Of Compatible Accessories

    System Sensors Four-Wire Smoke Receivers Detectors 1112, 1112 Ionization 2412B Photoelectric UL permits communication with the following UL Listed Central Station receivers (see the ZX400/ZX410 Pro- 1412B Ionization 2412THB Photoelectric 1451 Ionization 2412AT Photoelectric gramming Guide, P/N 64812702, for format):...

  • Page 29: Agency Requirements

    AGENCY REQUIREMENTS Agency Requirements UL has established certain requirements which per- detailed in this manual. It is the responsibility of the tain to the installation, use, and programming of this installing dealer to check with the AHJ and/or UL be- equipment.

  • Page 30: Ul And Ulc Listings

    AGENCY REQUIREMENTS UL and ULC Listings APPLICATION LISTING Household Burglary UL 1023 Household Fire UL 985 Household Burglary/Household Fire Combination UL 1023/UL 985 Local Burglar Alarm Grades A, B and C Central Station UL 609 Police Station Connect Burglar Alarm Unit UL 365 Digital Alarm Communicator System UL 1635...

  • Page 31: National Fire Protection Association (Nfpa) Rules

    NFPA RULES National Fire Protection Association (NFPA) Rules The National Fire and Burglar Alarm Association Testing (NFPA) has established rules to follow pertaining to fire prevention and the installation of fire detection This system should be tested weekly. All switches, equipment.

  • Page 32: System Troubleshooting

    SYSTEM TROUBLESHOOTING System Troubleshooting When the system detects a trouble condition, it is passcode) or until the trouble condition restores. The periodically displayed on the Control Station(s) and display of a trouble condition will continue to ap- a trouble tone is sounded. The trouble tone will pear until the condition either restores or is cleared.
  • Page 33 NOTES Notes ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...

  • Page 34: Fcc Compliance

    FCC COMPLIANCE FCC Compliance Part 68 Notification You should notify the telephone company if this equipment is removed from the premises and the telephone jack is no longer needed. This equipment complies with Part 68 of the Fed- eral Communications Commissions (FCC) rules. All connections to the telephone network must be made Part 15 Notification through standard telephone company plugs and...
  • Page 35 In some cases, the company’s inside wiring associated with a single The ZX400/ZX410 is part of a system designed to line individual service may be extended by means warn against unauthorized entry or of other situa- of a certified connector assembly (telephone exten- tions.
  • Page 36 SENTROL CONTROLS GROUP Sentrol reserves the right to change specifications PO Box 2904, 1510 Tate Blvd. SE without notice. Hickory, NC 28603 ©1997 Sentrol Tel.: 503.692.4052 Fax: 503.691.7566 U.S. & Canada: 800.547.2556 Technical Service: 800.800.2027 SENTROL FaxBack: 800.483.2495 64812692F...
