- Page 1 Precision Turntable MT10 Owner’s Manual McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: 607-723-3512 FAX: 607-724-0549...
-
Page 2: Important Safety Instructions
The lightning flash with arrowhead, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “danger- ous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. WARNING - TO REDUCE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO... -
Page 3: Table Of Contents
Phone: 607-723-1545 Fax: 607-724-0549 Customer Service If it is determined that your McIntosh product is in need of repair, you can return it to your Dealer. You can also return it to the McIntosh Laboratory Service Department. For assistance on factory repair return procedure, contact the McIntosh Service Department at: McIntosh Laboratory, Inc. -
Page 4: General Information
1. For additional connection information, refer to the owner’s manual(s) for any component(s) connected to the MT10 Precision Turntable. 2. The MT10 Precision Turntable comes with the McIn- tosh MCC10 High Performance Moving Coil Cartridge preinstalled. 3. It is recommended the Professionals at your McIntosh... -
Page 5: Introduction
Emitting Diodes (LEDs). • Glass Front Panel and Super Mirror Chassis Finish The famous McIntosh Illuminated Glass Front Panel and the Stainless Steel Chassis with Super Mirror Finish ensure the pristine beauty of the MT10 will be retained for many years. -
Page 6: Dimensions
Dimensions The following dimensions can assist in determining the best location for your MT10. Front View of the MT10 Rear View of the MT10 1" 2.54cm Side View of the MT10 " 44.45cm 3/16 20.80cm Note: The above height measurments are with the McIntosh Cartridge installed. -
Page 7: Unpacking The Turntable
Unpacking the Turntable To protect the fine finish of the MT10 Precision Turntable during the assembly and adjustment process, it is advisable to prepare a suitable clean working area with a soft, clean fabric, such as a bed linen or blanket. -
Page 8: Assembling The Turntable
Assembling the Turntable Locate the McIntosh MCC10 Moving Coil Cartridge, Tools and Mounting Hardware from the Accessory Box. In the following steps the Cartridge will be installed in the Tone Arm Headshell of the Turntable. CAUTION: To prevent possible damage to the Cartridge Sty- lus, DO NOT remove the clear protective cover at this time. - Page 9 Coun- ter Weight. 9. Locate the Tone Arm Height Gauge (used for the McIntosh MCC10 Cartridge) from inside the accessory box. 10. The gauge should just fit between the Tone Arm Hous- ing and the Mounting Plate of the Tone Arm.
- Page 10 Bubble is not in the center circle of the Bubble Level adjust the height the Turntable Feet (by rotating them clockwise or counter clockwise) until it is level. Refer to figure 21. 20. Carefully slide off the clear protective cover from the car- tridge by pulling the cover straight toward you.
-
Page 11: Rear Panel Connections And Adjustments
AUDIO OUTPUTS connect to MC (Moving Coil) Inputs of the Pream- plifier or A/V Control Center when the McIntosh MCC10 Cartridge is installed. Contact your McIntosh Dealer for additional assistance. POWER CONTROL REMOTE IN receives turn-on signals from a McIntosh component and switches the Front Panel Illumination On/Off. -
Page 12: How To Connect The Turntable
MT10 POWER CONTROL REMOTE OUT to the POWER CONTROL IN jack of a McIntosh source component. 3. Connect a wire from the MT10 GND (Ground) Post to the GND (Ground) post on the McIntosh Preamplifier or A/V Control Center. 4. Connect Audio Cables from the MT10 OUT L and R... -
Page 13: Front Panel Display, Switches, Lever And Record Clamp
Front Panel Display, Switches, Lever and Record Clamp Meter indicates actual rotation speed of the turntable platter POWER Switch turns AC Power On/Off, or Standby for Illumination only... -
Page 14: How To Operate The Turntable
Platter during playback of the recording. Refer to figure 52. Tone Arm Lift The McIntosh MT10 Precision Turntable has a built-in manual Tone Arm Lift Mechanism for safe placement and removal of the cartridge stylus on the photograph record. Perform the following steps: 1. - Page 15 Notes...
- Page 17 Notes...
-
Page 18: General Specifications
Ebony wood tone MT10 Turntable Specifications Playback Speeds 33-1/3 rpm, 45 rpm and 78rpm Motor Type DC Brushless MT10 External Power Supply Specifications Output Voltage 24 Volts, 625ma Power Requirement 100 Volts, 50/60Hz at 400ma 110 Volts, 50/60Hz at 400ma... -
Page 19: Packing Instruction
If a shipping carton or any of the interior part(s) are needed, please call or write Customer Service Department of McIntosh Laboratory. Refer to page 3. Please see the Part List for the correct part numbers. - Page 20 McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, NY 13903 The continuous improvement of its products is the policy of McIntosh Laboratory Incorporated who reserve the right to improve design without notice. Printed in the U.S.A. McIntosh Part No. 04106300...
