Installation Guide

For Model:

RVF52ABZ5

E206035

net weight of fan: 21.61 lb. (9.8 kg)

READ THESE INSTRUCTIONS AND

SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the RVF52ABZ5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ellington RVF52ABZ5

Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Model: RVF52ABZ5 Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly. pgs. 4 - 5 Wiring.
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches 7 feet that the hanging location allows the blades a (2.13 m) (76 cm) clearance of 7 feet (2.13 m) from the floor and 30 in (76 cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12 ft.
Page 5: Fan Assembly. Pgs
5. Fan Assembly. set screw hole set screw If you wish to extend the hanging length of your fan, stop pin you must remove the hanging ball from the 5-inch downrod provided to use with an extended downrod (sold separately). [If you wish to use the 5-inch downrod, please proceed to instructions hanging ball following the first dotted line below.]...
Page 6 5. Fan Assembly. (cont.) safety cable loop With the hanging bracket secured to the outlet wood box and able to support the fan, you are now ceiling ready to hang your fan. Grab the fan firmly with joist two hands. Slide downrod through opening in wood screw and washer hanging bracket and let hanging ball rest on the...
Page 7: Wiring
6. Wiring. CAUTION: Be sure outlet box is properly grounded and that a ground wire (GREEN or Bare) is present. white supply wire ground (green or bare) Make sure all electrical connections comply with black supply wire Local Codes or Ordinances and the National Electrical Code.
Page 8: Canopy Assembly
hanging bracket 7. Canopy Assembly. Raise canopy to hanging bracket and align slotted holes in canopy with loosened screws in hanging bracket. Twist canopy to lock. Re-insert screws that were previously removed (page 3, Section 4) and secure all screws with Phillips screwdriver.
Page 9: Switch Housing Assembly
9. Switch Housing Assembly. motor housing Remove 1 screw from switch housing plate (on underside of motor) and loosen the other 2 screws. Align slotted holes at top of switch housing with loosened screws in switch switch housing housing plate, allowing the male plug from plate the motor housing to come through hole in male plug...
Page 10: Testing Your Fan
10. Light Kit Assembly (Optional). (cont.) Replace lock washer and hex nut on threaded rod. Tighten hex nut over lock washer so that the switch housing cap fits securely on the light kit fitter. Make wire connections as described below. Connect WHITE wire from light kit fitter to WHITE wire from switch housing.
Page 11: Troubleshooting
Return fan, shipping prepaid, to either direction. Craftmade/Ellington. We will repair or ship you a 3. Check to be sure fan is wired properly. replacement fan, and we will pay the return shipping cost.

This manual is also suitable for:

Pom52abz5
