McCulloch Cabrio 115249726 Instruction Manual

Mcculloch corporation trimmer instructions manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTION MANUAL
IMPORTANT INFORMATION
: Please read these instructions carefully and make
GB
sure you understand them before using this unit. Retain these instructions for future
reference.
MANUEL D'INSTRUCTIONS
RENSEIGNEMENTS IMPORTANTS:
Avant d'utiliser cet appareil, veuillez lire
FR
atentivement les instructions et assurez- -vous de les avoir comprises. Conservez
les instructions pour référence ultérieure.
BETRIEBSANWEISUNG
WICHTIGE INFORMATION:
Lesen Sie diese Hinweise zur Handhabung des
DE
Geräts aufmerksam durch. Verwenden Sie es erst, wenn Sie sicher sind, daß Sie
alle Anweisungen verstanden haben und gut aufbewahren.
MANUAL DE INSTRUCCIONES
INFORMACIÓN IMPORTANTE:
ES
Lea atentamente las instrucciones y
asegúrese de entenderlas antes de utilizar esta aparato. Conserve las instruc-
ciones para la referencia en el futuro.
115249726 Rev. 1
9/15/09 BRW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cabrio 115249726 and is the answer not in the manual?

Questions and answers

Related Manuals for McCulloch Cabrio 115249726

Summary of Contents for McCulloch Cabrio 115249726

  • Page 1 INSTRUCTION MANUAL IMPORTANT INFORMATION : Please read these instructions carefully and make sure you understand them before using this unit. Retain these instructions for future reference. MANUEL D’INSTRUCTIONS RENSEIGNEMENTS IMPORTANTS: Avant d’utiliser cet appareil, veuillez lire atentivement les instructions et assurez- -vous de les avoir comprises. Conservez les instructions pour référence ultérieure.

  • Page 2: Table Of Contents

    14. Throttle lock- -out 3. ON/STOP switch 15. Starter handle 4. Shoulder strap clamp 16. Fuel cap 5. Shoulder strap 17. Primer bulb 6. Trimmer head 18. Start lever 7. Line limiter blade 19. Muffler 8. Shield 20. Wrench 9. Shaft 21.

  • Page 3: Identification Of Symbols

    Keep people and animals 15 meters away. WARNING! Blade/trimmer line can throw objects violently. You and others can be blinded or injured. Always wear eye protection and leg protection. The operator of the machine must insure that no one comes within a 15 meter radius while working.

  • Page 4: Operator Safety

    S Maintain unit according to recommended procedures. Keep blade sharp. Keep cut- ting line at the proper length. S Use only 2,4 mm diameter McCulloch brand replacement line. Never use wire, rope, string, etc. S Install required shield properly before using the unit.

  • Page 5: Fuel Tank

    S Hold the unit firmly with both hands. S Keep firm footing and balance. Do not overreach. S Keep blade or trimmer head below waist level. Do not raise engine above your waist. S Keep all parts of your body away from blade, trimmer head, and muffler when engine is running.

  • Page 6: Shoulder Strap

    INSTALLING TRIMMER ATTACHMENT WARNING: When installing attach- ment, place the unit on a flat surface for stabil- ity. 1. Loosen the coupler by turning the knob counterclockwise. Coupler Shipping protector LOOSEN Knob TIGHTEN 2. Remove shipping protector from coupler. 3. Remove the shaft cap from the attachment (if present).

  • Page 7: Trimmer Head

    TRIMMER HEAD NOTE: Remove the blade and metal shield be- fore attaching the plastic shield and trimmer head. To remove blade, align hole in the dust cup with the hole in the side of the gearbox by rotating the blade. Insert a small screwdriver into aligned holes.

  • Page 8: Blade

    Do not use any blades, or fastening hardware other than the washers and nuts shown in the following illustrations. These parts must be provided by McCulloch and installed as shown below. Failure to use proper parts can cause the blade to fly off and seriously hurt you or others.

  • Page 9: Operation

    Before operation, petrol must be mixed with a good quality 2-cycle air-cooled engine oil. We recommend McCulloch brand oil mixed at a ratio of 40:1 (2.5%). A 40:1 ratio is obtained by 7. Align hole in dust cup with hole in side of gearbox by rotating the blade.

  • Page 10: On/Stop Switch

    WARNING: Always stop unit and dis- connect spark plug before removing or instal- ling attachments. REMOVING TRIMMER ATTACH- MENT (OR OTHER OPTIONAL AT- TACHMENTS) CAUTION: When removing or installing at- tachments, place the unit on a flat surface for stability.

  • Page 11: Line Limiter Blade

    S Maintain full weight of tool on your left shoulder. S Without bending over, keep the blade or trimmer head near and parallel to the ground and not crowded into material being cut. OPERATING INSTRUCTIONS FOR USE WITH TRIMMER HEAD...
  • Page 12 S For mowing or sweeping, use full throttle for a good clean job. TRIMMING - - Hold the bottom of the trimmer head about 8 cm above the ground and at an angle. Allow only the tip of the line to make contact.

  • Page 13: Throttle Trigger

    S Cut only from your left to your right. Cutting on right side of the shield will throw debris away from the operator. S Use the shoulder strap and keep a firm grip on the unit with both hands. A properly adjusted shoulder strap will support the weight of the unit, freeing your arms and hands to control and guide the cutting motion.
  • Page 14 S Always wear gloves when servicing or cleaning the tines. The tines become very sharp from use. S Do not run unit at high speed unless cultivating. HEDGE TRIMMER SAFETY DANGER: RISK OF CUT; KEEP HANDS AWAY FROM BLADE moves momentarily after the trigger is re- leased.
  • Page 15 WARNING: Falling objects can cause severe head injury. Wear head protec- tion when operating this unit with a pole prun- er attachment. WARNING: To prevent serious injury, do not use more than one boom extension with a pole pruner attachment. WARNING: Keep the pruner away from power lines or electrical wires.

  • Page 16: Maintenance

    S Wipe off unit with a clean dry cloth. SERVICE AND ADJUSTMENTS REPLACING THE LINE 1. Press the tabs on the side of the trimmer head and remove cover and spool. CLEAN AIR FILTER A dirty air filter decreases engine perform- ance and increases fuel consumption and harmful emissions.
  • Page 17 4. Replace with a pre-wound spool, or re- place line using a 4,5 meters length of 2,4 mm diameter McCulloch brand line. WARNING: Never use wire, rope, string, etc., which can break off and become a dangerous missile.

  • Page 18: Muffler

    Adjustments may be necessary if you notice any of the following conditions: S Engine will not idle when the throttle is re- leased. S The trimmer head moves/spins at idle speed. WARNING: Perform the following steps after each use: S Allow engine to cool before storing or trans- porting.

  • Page 19: Troubleshooting Table

    SEASONAL STORAGE Prepare unit for storage at end of season or if it will not be used for 30 days or more. If your unit is to be stored for a period of time: S Clean the entire unit before lengthy storage. S Store in a clean dry area.

  • Page 20: Declaration Of Conformity

    We, Husqvarna AB, SE- -561 82 Huskvarna, Sweden, Tel: +46- -36- -146000, as authorised representative in the Community, declare that the brushcutter model McCulloch Cabrio 433L from serial numbers 2009- -031N00001 and onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S...

  • Page 21: Technical Data

    SOUND POWER LEVELS in accordance with ISO 22868 Idling, dB(A) Racing, dB(A) VIBRATION LEVELS measured in accordance with ISO 22867 LEFT HANDLE Idling, m/s Racing, m/s RIGHT HANDLE Idling, m/s Racing, m/s Trimmer Blade 7000 7000 10000 10000 7400 7400 2900 2900 Opt.

This manual is also suitable for:

Cabrio 433l
