USER MANUAL
MANUEL D'UTILISATION
MANUAL DEL USUARIO
ELECTRIC BLOWER / VACUUM Model 2204, 2205
ASPIRATEUR / SOUFFLEUR ELECTRIQUE Modèle 2204, 2205
SOPLADORA / ASPIRADORA ELECTRICA Modelo 2204, 2205
ALWAYS WEAR EYE PROTECTION
TOUJOURS PORTER UNE PROTECTION
OCULAIRE
USE SIEMPRE LA PROTECCION OCULAR
2204 FEATURES:
Double Insulated
125 mph Velocity
320 cfm Air Volume
9 amp, 120 volt Motor
2205 FEATURES:
Double Insulated
200 mph Velocity
405 cfm Air Volume
12 amp, 120 volt Motor
CAUTION
Read all safety instructions care-
fully before attempting to operate.
Retain for future reference.
PN 6096-220402
CARACTÉRISTIQUES DE 2204
Double Isolation
Vélocité 200 km/h (125 m/h)
Volume d'air 8,64 m
3
(320 pi.
Moteur 9 a, 120 volts
CARACTÉRISTIQUES DE 2205
Double Isolation
Vélocité 320 km/h (200 m/h)
Volume d'air 10,94 m
3
(405 pi.
Moteur 12 a, 120 volts
ATTENTION
Lire complétement les instructions
avant d'utiliser. Conserver pour
future référence.
FOR HOUSEHOLD USE ONLY
POUR UTILISATION DOMESTIQUE SEULEMENT
PARA USO FAMILIAR SOLAMENTE
CARACTERISTICAS DE 2204:
Aislamiento Doble
Velocidad de 125 MPH (200 KMH)
Volumen de Aire de 320 CFM (8,64m
3
)
Motor de 9 amp, 120 voltios
CARACTERISTICAS DE 2205:
Aislamiento Doble
Velocidad de 200 MPH (320 KMH)
Volumen de Aire de 405 CFM (10,94m
3
)
Motor de 12 amp, 120 voltios
Lea todas las instrucciones de seguridad
antes de intentar su functionamiento.
Conserve esto para consultarlo en el futuro.
© 2002 McCulloch Motors • Printed in China
3
/min)
3
/min)
PRECAUTION
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2205 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for McCulloch 2205

Summary of Contents for McCulloch 2205

  • Page 1 USER MANUAL MANUEL D’UTILISATION MANUAL DEL USUARIO ELECTRIC BLOWER / VACUUM Model 2204, 2205 ASPIRATEUR / SOUFFLEUR ELECTRIQUE Modèle 2204, 2205 SOPLADORA / ASPIRADORA ELECTRICA Modelo 2204, 2205 ALWAYS WEAR EYE PROTECTION TOUJOURS PORTER UNE PROTECTION OCULAIRE USE SIEMPRE LA PROTECCION OCULAR...

  • Page 2: Please Read

    Todo el servicio que no sea el mantenimiento del usuario se llevará a cabo en un Centro de Servicio Autorizado McCulloch. Los d años o las condiciones que hagan inoperable este producto debido a las prácticas inadecuadas de mantenimiento anularán la garantía del fab r icante.

  • Page 3: Specifications

    ......3.9 Kg (8,6 Lbs) ....4.2 Kg (9,2 Lbs) 2204 2204 2204 /RPM....17,000 min /RPM....14,000 min 2205 2205 2205 /RPM. /RPM.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS DE SECURITE IMPOR- TANTES - IMPORTANTES INSTRUC- CIONES DE SEGURIDAD PLEASE READ - SAVE THESE INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed to assure maximum safety and optimum per- formance. Read the User manual before assembling and operating this appliance. Failure to comply with instructions may result in fire, electrical shock or personal injury.
  • Page 5 7. Do not allow unit to be used as a toy or to run unattended at any time. Keep children away. 8. Do not use accessories or attachments except as recommended and provided by McCulloch Corporation. Use this appli- ance only for its intended use as described in this manual.
  • Page 6 18. Never blow debris in the direction of bystanders or solid objects. The force of the air can cause objects to be blown or ric - ochet which can harm people. Never place objects inside blower tubes. 19. Never operate with any air openings blocked. Keep air openings free of dust, lint, hair and anything that may reduce air flow.
  • Page 7 23.Do not use in the presence of flammable liquids or gases, smoking or burning materials to avoid creating a fire or explo- sion. 24.Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where they may be present. 25.Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
  • Page 8 2. Always wear long pants, shoes and gloves. Do not wear loose clothing, jewelry, short pants, sandals, or go barefoot. 3. Always wear a respirator or face mask when working with the blower in a dusty environment. 4. Always inspect the area before starting the appliance to remove debris and hard or sharp objects that can be blown or cause damage during operation.
  • Page 9 INSTRUCCIONES DE ENSAMBLE FIG.1A FIG.1C Remove blower from carton and examine it thoroughly to make sure it is not damaged. This electric blower requires no tools for assembly. Read your User manual carefully before assembly and operation. • VACUUM ATTACHMENT ASSEMBLY Turn off unit and unplug from electric outlet.
  • Page 10 3. Pull the blower tube (B) from (C), till it’s engaged. (Fig. 2D) 4. Attach the blower tubes to the unit by sliding the large end of the blower tube into the blower outlet until firmly in place. (Fig. 2E) •...

  • Page 11: Extension Cord

    EXTENSION CORD EXTENSION CORD LENGTH VOLTS * American Wire Gauge TABLE 1 1. When using the appliance, an extension cord of adequate size must be used for safety, and to prevent loss of power and overheating. See Table 1. 2. The extension cord must be specifically designed for outdoor use and marked “SW-A”, “SOW-A”, “STW-A”, “STOW-A”, “SJW-A”, “SJOW-A”, “SJTOW-A”, “SJTW-A”, or “SJTW”.

  • Page 12: Conseils D'utilisation

    3. Be careful when working near valuable plants. The force of air could damage tender plants. 4. Uses for your blower: •Sweeping debris or grass clippings from driveways, sidewalks, patios, parks, parking lots, barns, etc. •Gathering grass clippings, staw or leaves into piles. •Removing debris from corners, around joints and between bricks.
  • Page 13 électrique. Si l’appareil ne fonctionne toujours pas, appeler le service de réparation des pro- duits de McCulloch au numéro gratuit indiqué à la couverture arrière. Ne pas essayer de réparer le souffleur soi-même. L’appareil ne comporte aucune pièce interne réparable par l’utilisateur.
  • Page 14 WARNING DO NOT EXPOSE TO RAIN. AVOID ALL TYPES OF DETERGENTS, CLEANERS OR SOLVENTS. NEVER SUBMERGE IN WA TER OR OTHER LIQUIDS. 3. Do not leave extension cord lying on the ground once you have finished using the appliance. It can become a tripping haz- ard.
  • Page 16 ® STOP ARRÊT ALTO...
