FORMULA
FKB113 / FKB116 / FKB157
FTB169 / FSB213 / FSB216
Thank you for choosing MB Quart Formula speakers for your car audio
sound system. With proper installation, you are on the path to
experiencing your music in a way you only imagined possible. Here at
MB Quart, we call this "Sound In Every Detail."
The Formula series speakers have been designed for the enthusiast
looking for great sound at an affordable price. The Formula series
speakers feature the following:
- Progressive Grill
- High Energy Magnet
- Polypropylene Cone
- Woven Tinsel Leads
- Spade Style Speaker Terminals
- 19mm Titanium Dome Tweeter
- Small Chassis Crossover For Components
- Stamped Steel Basket
