Page 3 Mazda product. Important Notes About This Manual Keep this manual in the glove box as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 4: How To Use This Manual
Illustrations complement the words of the manual to best explain how to enjoy your Mazda. By reading your manual, you can find out about the features, important safety information, and driving under various road conditions.
Page 5: Table Of Contents
Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts.
Page 7: Your Vehicle At A Glance
Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Interior Overview ... 1-2 Interior Equipment (View A) ... 1-2 Interior Equipment (View B) ... 1-3 Interior Equipment (View C) ... 1-4 Exterior Overview ... 1-5 Front (4 Door) ...
Page 8: Interior Overview
Your Vehicle at a Glance Interior Overview Interior Equipment (View A) Door-lock knob ... page 3-31 Power door lock switch ... page 3-32 DSC OFF switch ... page 5-26 Turn and lane-change signals ... page 5-60 Lighting control ... page 5-56 Dashboard illumination knob ...
Page 9: Interior Equipment (View B)
Your Vehicle at a Glance Interior Overview Interior Equipment (View B) Audio control switches ... page 6-56 SRS air bags ... page 2-44 Multi information display ... page 6-98 Navigation system (if equipped) ... Refer to the separate manual Audio system ... page 6-18 Information display ...
Page 10: Interior Equipment (View C)
Your Vehicle at a Glance Interior Overview Interior Equipment (View C) Seat belts ... page 2-16 SRS air bag ... page 2-44 Remote fuel-filler lid release ... page 3-44 Trunk release lever ... page 3-38 Bottle holder ... page 6-109 Vanity mirror ...
Page 11: Exterior Overview
Your Vehicle at a Glance Exterior Overview Front (4 Door) Hood ... page 3-46 Windshield wiper blades ... page 8-26 Moonroof ... page 3-47 Child safety locks ... page 3-34 Tires ... page 8-33 Door lock ... page 3-31 Light bulbs ... page 8-37 The equipment and installation position varies by vehicle...
Page 12: Rear (4 Door)
Your Vehicle at a Glance Exterior Overview Trunk lid ... page 3-37 Rear window antenna ... page 6-17 Outside mirror ... page 3-58 Tires ... page 8-33 Fuel-filler lid ... page 3-44 Light bulbs ... page 8-37 The equipment and installation position varies by vehicle Rear (4 Door)
Page 13: Front (5 Door)
Your Vehicle at a Glance Exterior Overview Front (5 Door) Hood ... page 3-46 Windshield wiper blades ... page 8-26 Moonroof ... page 3-47 Door lock ... page 3-31 Tires ... page 8-33 Light bulbs ... page 8-37 The equipment and installation position varies by vehicle...
Page 14: Rear (5 Door)
Your Vehicle at a Glance Exterior Overview Rear wiper blade ... page 8-28 Liftgate ... page 3-34 Antenna ... page 6-17 Fuel-filler lid ... page 3-44 Child safety lock ... page 3-34 Outside mirror ... page 3-58 Tires ... page 8-33 Light bulbs ...
Page 15: Essential Safety Equipment
Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats ... 2-2 Front Seats (Manually Operated Seats) ... 2-2 Front Seats (Electrically Operated Seats) ... 2-4 Rear Seat ... 2-9 Head Restraints ... 2-12 í...
Page 16: Seats
Such modifications could damage the supplemental restraint system and result in serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Do not drive with damaged front seats: Driving with damaged front seats is dangerous.
Page 17 qSeat Recline WARNING Do not drive with either front seat reclined: Sitting in a reclined position while the vehicle is moving is dangerous because you do not get the full protection from seat belts. During sudden braking or a collision, you can slide under the lap belt and suffer serious internal injuries.
Page 18: Front Seats (Electrically Operated Seats)
Such modifications could damage the supplemental restraint system and result in serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Do not drive with damaged front seats: Driving with damaged front seats is dangerous.
Page 19 CAUTION Ø The seat-bottom power adjustment is operated by motors. Avoid extended operation because excessive use can damage the motors. Ø To prevent the battery from running down, avoid using the power adjustment when the engine is stopped. The adjuster uses a large amount of electrical power.
Page 20 Essential Safety Equipment Seats qHeight Adjustment (Driver's Seat) The seat height can be adjusted by moving the switch up or down. qSeat Position Memory One-touch seat position programming and activation is available on the driver's seat. CAUTION When activating the seat position, do not place your hands or fingers around the seat bottom.
Page 21 Operation using the seat-side buttons Programming Park the vehicle in a safe location before performing the seat position programming. (Vehicle must be stopped) 1. Adjust the seat to the desired position. For each seat position adjustment method refer to the following pages: Seat Slide (page 2-5) Seat Recline (page 2-5) Height Adjustment (page 2-6)
Page 22 Essential Safety Equipment Seats With retractable type key Unlock button Lock button Operation indicator light Programming One seat position can be programmed into each advanced key/retractable type key. After the following conditions have been met, operate the seat and the advanced key/retractable type key to program the seat positions.
Page 23: Rear Seat
NOTE Memory will also be erased if any of the following operations are performed: The advanced key/retractable type key code has been changed. Refer to Immobilizer System (with Advanced Key) on page 3-49. Refer to Immobilizer System (without Advanced Key) on page 3-52. The vehicle battery is disconnected for vehicle maintenance or other reasons.
Page 24 Essential Safety Equipment Seats Never allow a passenger to sit or stand on the folded seatback while the vehicle is moving: Driving with a passenger on the folded seatback is dangerous. Allowing a child to sit up on the folded seatback while the vehicle is moving is particularly dangerous.
Page 25 qSplit-Folding Rear Seatback To fold the seatbacks CAUTION When operating the rear seatback knob, make sure you support the seatback with your hand. If the seatback is not supported with your hand, it will flip forward suddenly and could cause injury to the finger that pushes the rear seatback knob down.
Page 26: Head Restraints
Essential Safety Equipment Seats qArmrest The rear armrest in the center of the rear seatback can be used (no occupant in the center seat) or placed upright. 2-12 Head Restraints Head restraints are intended to help protect you and the passengers from neck injury.
Page 27 Rear seat Removal/Installation To remove the head restraint, pull it up while pressing the stop-catch. To install the head restraint, press the uprights into the holes while pressing the stop-catch. WARNING Always drive with the head restraints set up when seats are being used and make sure they are properly set up: Driving with the head restraints not set up is dangerous.
Page 28: Seat Warmer Í
Essential Safety Equipment Seats NOTE The active head restraints operate in a rear-end collision. The head restraints return to their original position after the collision. The method for adjusting the active head restraints is the same as a normal head restraint.
Page 29 WARNING Ø Be careful when using the seat warmer. The heat from the seat warmer may be too hot for some people, as indicated below, and could cause a low-temperature burn. Ø Infants, small babies, elderly people, and physically challenged people Ø...
Page 30: Seat Belt Systems
Seat belts help to decrease the possibility of severe injury during accidents and sudden stops. Mazda recommends that the driver and all passengers always wear seat belts. All of the seat belt retractors are designed to keep the lap/shoulder belts out of the way when not in use.
Page 31 Using a damaged seat belt is dangerous. An accident could damage the belt webbing of the seat belt in use. A damaged seat belt cannot provide adequate protection in a collision. Have an Authorized Mazda Dealer inspect all seat belt systems in use during an accident before they are used again.
Page 32 Essential Safety Equipment Seat Belt Systems CAUTION Belt retraction may become difficult if the belts and rings are soiled, so try to keep them clean. For more details about cleaning the seat belts, refer to “Cleaning the Lap/Shoulder Belt Webbing” (page 8-60). qPregnant Women and Persons with Serious Medical Conditions Pregnant women should always wear seat belts.
Page 33 Essential Safety Equipment Seat Belt Systems qAutomatic Locking Mode Always use the automatic locking mode to keep the child-restraint system from shifting to an unsafe position in the event of an accident. To enable seat belt automatic locking mode, pull it all the way out and connect it as instructed on the child-restraint system. It will retract down to the child-restraint system and stay locked on it.
Page 34: Seat Belt
Essential Safety Equipment Seat Belt Systems Seat Belt qFastening the Seat Belt 1. Grasp the seat belt tongue. 2. Slowly pull out the lap/shoulder belt. 3. Insert the seat belt tongue into the seat belt buckle until you hear a click sound.
Page 35 NOTE If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an Authorized Mazda Dealer. Essential Safety Equipment Seat Belt Systems qFront Shoulder Belt Adjuster Adjust the height of the shoulder belt if the seat belt touches your neck, or if it crosses your arm instead of your shoulder.
Page 36: Front Seat Belt Pretensioner And Load Limiting Systems
Even if the pretensioners have not fired, the load limiting function must be checked by an Authorized Mazda Dealer after any collision. 2-22 WARNING Wear seat belts only as recommended...
Page 37 ON. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident. WARNING...
Page 38: Seat Belt Extender
The air bag and seat belt pretensioner system warning beep sound will continue to be heard for approximately 35 minutes. Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible. WARNING Do not drive the vehicle with the air...
Page 39 NEVER use the extender in a different vehicle or seat. If you sell your Mazda, do not leave your seat belt extender in the vehicle. It could be used accidentally by the new owner of the vehicle.
Page 40: Seat Belt Warning Light/Beep
ON. heard. qBelt Minder NOTE The belt minder can be deactivated. Consult an Authorized Mazda Dealer to deactivate or restore the seat belt minder. 2-26 Driver seated/Front passenger not seated The belt minder is a supplemental warning to the seat belt warning function.
Page 41 Driver seated/Front passenger seated The seat belt warning function reminds the front passenger to fasten the seat belt according to the chart below. Vehicle speed Between 0 Condition km/h 12 mph) Seat belt (Driver) Seat belt (Passenger) Indicator Beep : Fastened : Unfastened : Illuminated : Flashing...
Page 42: Child Restraint
Even if the front passenger air bag is shut off, Mazda strongly recommends that children be properly restrained and child-restraint systems of all kinds are properly secured on the rear seats which are the best place for children.
Page 43 WARNING Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size. If not, the child could be seriously injured or even killed in an accident. Follow the manufacturer's instructions and always keep the child-restraint system buckled down: An unsecured child-restraint system is dangerous.
Page 44 Essential Safety Equipment Child Restraint Do not install a front-facing child-restraint system on the front passenger seat unless it is unavoidable: In a collision, the force of a deploying air bag could cause serious injury or death to the child. If installing a front-facing child-restraint system on the front passenger seat is unavoidable, move the front passenger seat as far back as possible.
Page 45 NOTE Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. When using these anchors to secure a child-restraint system, refer to LATCH Child-Restraint Systems (page 2-39).
Page 46: Installing Child-Restraint Systems
Some child-restraint systems now come with tethers and therefore must be installed on the seats that take tethers to be effective. In your Mazda, tethered child-restraint systems can only be accommodated in the three positions on the rear seat.
Page 47 4. To get the retractor into the automatic locking mode, pull the shoulder belt portion of the seat belt until the entire length of the belt is out of the retractor. 5. Push the child-restraint system firmly into the vehicle seat. Be sure the belt retracts as snugly as possible.
Page 48 Essential Safety Equipment Child Restraint Anchor bracket location (5 Door outboard position) Tether strap position (5 Door outboard position) Tether strap Forward Anchor bracket location (5 Door center position) 2-34 Tether strap position (5 Door center position) Tether strap 7. Install the head restraint. Refer to Head Restraints on page 2-12.
Page 49 NOTE To check if your front seats have side air bags: Mazda vehicles equipped with side air bag will have a SRS AIRBAG tag on the outboard shoulder of the front seats. To check if your vehicle has curtain air...
Page 50 Essential Safety Equipment Child Restraint WARNING Always move the front passenger seat as far back as possible if installing a front-facing child-restraint system on it is unavoidable: As your vehicle has front air bags and doubly so because your vehicle has side air bags, a front-facing child-restraint system should be put on the front passenger seat only...
Page 51 2. Secure the child-restraint system with the lap portion of the lap/shoulder belt. See the manufacturer's instructions on the child-restraint system for belt routing instructions. 3. To get the retractor into the automatic locking mode, pull the shoulder belt portion of the seat belt until the entire length of the belt is out of the retractor.
Page 52 If the indicator light does not illuminate after seating a child in a child-restraint system on the front passenger seat, seat a child in a child-restraint system on the rear seat and consult an Authorized Mazda Dealer as soon as possible. 2-38...
Page 53: Latch Child-Restraint Systems
LATCH Child-Restraint Systems Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. Both anchors must be used, otherwise the seat will bounce around and put the child in danger. Most LATCH child-restraint systems must also be used in conjunction with a tether to be effective.
Page 54 Essential Safety Equipment Child Restraint qLATCH Child-Restraint System Installation Procedure (Rear Outboard Seats) 1. Make sure the seatback is securely latched by pushing it back until it is fully locked. 2. Expand the area between the seat bottom and the seatback slightly to verify the locations of the LATCH lower anchors.
Page 55 Anchor bracket location (5 Door) Tether strap position (5 Door) Tether strap Forward 6. Install the head restraint. Refer to Head Restraints on page 2-12. Essential Safety Equipment Child Restraint WARNING Use the tether and tether anchor only for a child-restraint system: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous.
Page 56 Essential Safety Equipment Child Restraint qLATCH Child-Restraint System Installation Procedure (Rear Center Seat) The LATCH lower anchors at the center of the rear seat are much further apart than the sets of LATCH lower anchors for child-restraint system installation at other seating positions.
Page 57 3. Secure the child-restraint system using BOTH LATCH lower anchors, following the child-restraint system manufacturer's instructions. Pull on the child-restraint to be sure both anchors are engaged. 4. If your child-restraint system came equipped with a tether, that means it is very important to properly secure the tether for child safety.
Page 58: Srs Air Bags
Essential Safety Equipment SRS Air Bags Supplemental Restraint System (SRS) Precautions The front and side supplemental restraint systems (SRS) include 6 air bags. Please verify the air bags equipped on your vehicle by locating the SRS AIRBAG location indicators. These indicators are visible in the area where the air bags are installed. The air bags are installed in the following locations: The steering wheel hub (driver air bag) The front passenger dashboard (front passenger air bag)
Page 59 WARNING Seat belts must be worn in air bag equipped vehicles: Depending only on the air bags for protection during an accident is dangerous. Alone, air bags may not prevent serious injuries. The appropriate air bags can be expected to inflate only in the first accident, such as frontal, near frontal, side collisions that are at least moderate.
Page 60 Essential Safety Equipment SRS Air Bags Sit in the center of the seat and wear seat belts properly: Sitting too close to the side air bag modules or placing hands on them, or sleeping up against the door or hanging out the windows is extremely dangerous. The side and curtain air bags inflate with great force and speed directly expanding along the door on the side the car is hit.
Page 61 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.
Page 62: Supplemental Restraint System Components
Essential Safety Equipment SRS Air Bags Supplemental Restraint System Components Driver/Front passenger dual stage inflators and air bags Crash sensor, and diagnostic module (SAS unit) Front seat belt pretensioner and load limiting systems (page 2-22) Front air bag sensor Side crash sensors Air bag/front seat belt pretensioner system warning light (page 2-51) Side and curtain inflators and air bags Front passenger air bag deactivation indicator light (page 2-56)
Page 63: How The Srs Air Bags Work
SRS Air Bags How the SRS Air Bags Work Your Mazda is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
Page 64 Essential Safety Equipment SRS Air Bags qFront Passenger Air Bag The front passenger air bag is mounted in the front passenger dashboard. The inflation mechanism for the front passenger air bag is the same as the driver's air bag, as mentioned above. In addition, the front passenger air bag is designed to only deploy in accordance with the total seated weight on the front passenger seat.
Page 65 A system malfunction is indicated if the warning light constantly flashes, constantly illuminates or does not illuminate at all when the ignition is switched ON. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident.
Page 66 The air bag and seat belt pretensioner system warning beep sound will continue to be heard for approximately 35 minutes. Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible. WARNING Do not drive the vehicle with the air bag/front seat belt pretensioner system warning...
Page 67: Srs Air Bag Deployment Criteria
SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) A severe frontal/near frontal collision equipment Front seat belt (both sides) pretensioner Driver air Front...
Page 68: Limitations To Srs Air Bag
Essential Safety Equipment SRS Air Bags Limitations to SRS Air Bag In severe collisions such as those described previously in SRS Air Bag Deployment Criteria , the applicable SRS air bag equipment will deploy. However, in some accidents, the equipment may not deploy depending on the type of collision and its severity. Limitations to front/near front collision detection: The following illustrations are examples of front/near front collisions that may not be detected as severe enough to deploy the SRS air bag equipment.
Page 69 Essential Safety Equipment SRS Air Bags Roll-over 2-55...
Page 70: Driver And Front Passenger Occupant Classification System
Essential Safety Equipment SRS Air Bags Driver and Front Passenger Occupant Classification System First, please read Supplemental Restraint System (SRS) Precautions (page 2-44) carefully. qDriver Seat Slide Position Sensor Your vehicle is equipped with a driver seat slide position sensor as a part of the supplemental restraint system.
Page 71 ON position and does not illuminate as indicated in the above chart, do not allow a child to sit in the front passenger seat and consult an Authorized Mazda Dealer as soon as possible. The system may not work properly in an accident.
Page 72 Essential Safety Equipment SRS Air Bags WARNING Do not decrease the total seated weight on the front passenger seat: When an adult or large child sits on the front passenger seat, decreasing the total seated weight on the front passenger seat from the total seated weight of approximately 42 kg (93 lbs) required for air bag deployment is dangerous.
Page 73 Do not increase the total seated weight on the front passenger seat: When an infant or small child sits on the front passenger seat, increasing the total seated weight on the front passenger seat from the total seated weight of approximately 30 kg (66 lbs) is dangerous.
Page 74 If the front passenger air bag deactivation indicator light does not illuminate after installing a child-restraint system on the front passenger seat, install the child-restraint system on the rear seat and consult an Authorized Mazda Dealer as soon as possible. qDriver and Front Passenger Buckle Switches The buckle switches on the front seat belts detect whether or not the front seat belts are securely fastened and further control the deployment of the air bags.
Page 75: Monitoring And Maintenance
The air bag systems do not require regular maintenance. But if any of the following occurs, take your vehicle to an Authorized Mazda Dealer as soon as possible: The air bag system warning light flashes. The air bag system warning light remains illuminated.
Page 76 Improper disposal of an air bag or a vehicle with live air bags in it can be extremely dangerous. Unless all safety procedures are followed, injury can result. Ask an Authorized Mazda Dealer how to safely dispose of an air bag or how to scrap an air bag equipped vehicle.
Page 77: Knowing Your Mazda
Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts. Advanced Keyless Entry and Start System ... 3-2 í Advanced Keys Operation Using Advanced Keyless Functions ... 3-7 Operation Using Advanced Key Functions ... 3-16 Advanced Key Suspend Function ...
Page 78: Advanced Keyless Entry And Start System
Knowing Your Mazda Advanced Keyless Entry and Start System The advanced keyless functions (advanced keyless entry and start system) enables the following operations while the advanced key is being carried (page 3-7). Locking/unlocking the doors and the liftgate, and opening the liftgate, and opening the trunk lid, without operating the key.
Page 79 (not in the vehicle) for use if you need to make a replacement key. Also write down the code number and keep it in another safe and handy place, but not in the vehicle. If your key is lost, consult your Authorized Mazda Dealer with the code number ready.
Page 80 Refer to Advanced Key Battery Dead Warning on page 3-21. Additional advanced keys can be obtained at an Authorized Mazda Dealer. Up to 6 advanced keys can be used with the advanced keyless functions per vehicle.
Page 81 The system's operational range is reduced. Advanced Keyless Entry and Start System Replacing the battery at an Authorized Mazda Dealer is recommended to prevent damage to the advanced key. If replacing the battery by yourself, follow the instruction below. Replacing the advanced key battery 1.
Page 82 Knowing Your Mazda Advanced Keyless Entry and Start System 3. Insert the flathead screwdriver into the gap between the cover and the transmitter, and then rotate the screwdriver to detach the cover. 4. Remove the battery cap, then remove the battery.
Page 83: Operation Using Advanced Keyless Functions
Authorized Mazda Dealer. If your advanced key is lost or stolen, bring all remaining advanced keys to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen advanced key inoperative.
Page 84 Knowing Your Mazda Advanced Keyless Entry and Start System 5 door (Locking) Exterior transmitter Operational range 5 door (Unlocking) Exterior transmitter Operational range NOTE The system may not operate if you are too close to the windows, door handles, or liftgate.
Page 85 When the doors are locked by pressing the request switch on the front doors while the theft-deterrent system is armed, the hazard warning lights will flash once to indicate that the system is armed. Refer to the theft-deterrent system on page 3-54. Knowing Your Mazda Request switch...
Page 86 Knowing Your Mazda Advanced Keyless Entry and Start System To unlock Driver's door request switch To unlock the driver's door, press the request switch. A beep sound will be heard twice and the hazard warning lights will flash twice. To unlock all doors and the liftgate, press the request switch again within 5 seconds and two more beep sounds will be heard.
Page 87 To unlock the steering wheel, jiggle the steering wheel from side to side while pressing the push button start. Knowing Your Mazda 3-11...
Page 88 Knowing Your Mazda Advanced Keyless Entry and Start System Ignition positions Each time the push button start is pressed, the ignition switches in the order of off, ACC, and ON. Pressing the push button start again from ON switches the ignition off.
Page 89 If the KEY indicator light (green) does not illuminate while the advanced key is being carried, you may have to use the auxiliary key to start the engine instead (page 3-23). Knowing Your Mazda 3-13...
Page 90 ACC or ON. Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible. 3-14 NOTE Under the following conditions, the KEY...
Page 91 Starting a Flooded Engine under Emergency Starting. If the engine still does not start, have your vehicle inspected by an Authorized Mazda Dealer (page 7-17). Starting the engine using the auxiliary If the engine cannot be started for reasons...
Page 92: Operation Using Advanced Key Functions
Knowing Your Mazda Advanced Keyless Entry and Start System 2. (Manual transaxle) Shift into neutral. (Automatic transaxle) Shift the shift lever to the P position. 3. Press the push button start to turn off the engine. CAUTION When leaving the vehicle, make sure the push button start is pressed to off.
Page 93 Refer to the theft-deterrent system on page 3-54. The system can be set to unlock all doors by performing a single operation. Refer to Personalization Features on page 10-9. Knowing Your Mazda 3-17...
Page 94 Knowing Your Mazda Advanced Keyless Entry and Start System NOTE All doors and the liftgate cannot be locked when any door or the liftgate is open. Confirm that all doors and the liftgate are locked visually or audibly by use of the double click.
Page 95: Advanced Key Suspend Function
(Manual transaxle) When carrying another advanced key, depress the clutch pedal until the KEY indicator light (green) illuminates. (Automatic transaxle) When carrying another advanced key, depress the brake pedal until the KEY indicator light (green) illuminates. Knowing Your Mazda 3-19...
Page 96: Warning Lights And Beep Sounds
Park the vehicle in a safe place and use the auxiliary key to continue driving the vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. Refer to Starting the engine (page 3-11). qIgnition Not Switched Off...
Page 97 To restore the advanced key function, perform the applicable procedure (page 3-19). The system can be set not to open the trunk. Refer to Personalization Features on page 10-9. Knowing Your Mazda 3-21...
Page 98 Knowing Your Mazda Advanced Keyless Entry and Start System qAdvanced Key Left-in-vehicle Warning Beep If an advanced key is left in the vehicle cabin and all the doors are locked using a separate advanced key, a beep sound is heard for about 10 seconds to remind the driver that the advanced key has been left in the vehicle cabin.
Page 99: When Warning Indicator/Beep Is Activated
The advanced key is malfunctioning. Park the vehicle in a safe place, and use the auxiliary key to continue driving the vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. Knowing Your Mazda How to check...
Page 100: Doors And Locks
If your key is lost, consult your Authorized Mazda Dealer and have your code number ready. Some types of key chains cannot be attached to the retractable type key. In this...
Page 101: Keyless Entry System Í
Ø Disassemble the transmitter. Ø Expose the transmitter to any kind of magnetic field. Ø Expose the transmitter to high temperatures on places such as the dashboard or hood, under direct sunlight. í Some models. Knowing Your Mazda í 3-25...
Page 102 To install a new battery, refer to Maintenance (page 3-28). Additional transmitters can be obtained at an Authorized Mazda Dealer. Up to 3 transmitters can be used with the keyless entry system per vehicle. Bring all transmitters to an Authorized Mazda Dealer when additional transmitters are required.
Page 103 The time required for the doors to lock automatically can be changed. Refer to Personalization Features on page 10-9. Trunk button To open the trunk, press and hold the trunk button until the trunk lid opens. Knowing Your Mazda 3-27...
Page 104 Knowing Your Mazda Doors and Locks NOTE To open the trunk when the ignition is switched to a position other than off, use the remote release lever inside the vehicle (page 3-38). Panic button If you witness from a distance someone...
Page 105 CAUTION Insert the key into the transmitter securely until a click sound is heard. If it is not inserted securely, it could detach from the transmitter. Knowing Your Mazda 3-29...
Page 106: Door Locks
Authorized Mazda Dealer. If your transmitter is lost or stolen, bring all remaining transmitters to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen transmitter inoperative. CAUTION Radio equipment like this is governed by laws in the United States.
Page 107 Keyless Entry System (page 3-25). qLocking, Unlocking with Door- Lock Knob To lock any door from the inside, push the door-lock knob. To unlock, pull it out. This does not operate the other door locks. Lock Unlock Knowing Your Mazda 3-31...
Page 108 Knowing Your Mazda Doors and Locks To lock the front passenger door with the door-lock knob from the outside, push the door-lock knob to the lock position and close the door. This does not operate the other door locks. Door-lock knob...
Page 109 NOTE Additional auto lock/unlock function (Automatic transaxle) A function setting is also available which enable automatic locking and unlocking of doors and the liftgate when shifting gears. Refer to Personalization Features on page 10-9. Knowing Your Mazda 3-33...
Page 110: Liftgate (5 Door)
Knowing Your Mazda Doors and Locks qRear Door Child Safety Locks These locks are intended to help prevent children from accidentally opening the rear doors. Use them both whenever a child rides in the vehicle. If you slide the child safety lock to the lock position before closing that door, the door cannot be opened from the inside.
Page 111 Press the electric liftgate opener button again to fully open the liftgate. To close the liftgate from its slightly raised position, open it first by pressing the electric liftgate opener button and waiting for 1 second or longer, then close it. Knowing Your Mazda 3-35...
Page 112 3. Turn the lever to the right to unlock the liftgate. Lever After performing this emergency measure, have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. 3-36 Closing the liftgate Use both hands to push the liftgate down until the lock snaps shut.
Page 113: Trunk Lid (4 Door)
Exhaust gas entering the cabin of a vehicle through an open trunk is dangerous. This gas contains CO Strap (carbon monoxide), which is colorless, odorless, and highly poisonous. If inhaled, it can cause loss of consciousness and death. Knowing Your Mazda Doors and Locks 3-37...
Page 114 Knowing Your Mazda Doors and Locks qOpening and Closing the Trunk Lid WARNING Close the trunk lid, be sure the seat backs are latched and do not allow children to play inside the vehicle: Leaving the trunk lid open or leaving children in the vehicle with the keys is dangerous.
Page 115: Inside Trunk Release Lever
Knowing Your Mazda 3-39...
Page 116 Knowing Your Mazda Doors and Locks WARNING Close the trunk lid, be sure the seat backs are latched and do not allow children to play inside the vehicle: Leaving the trunk lid open or leaving children in the vehicle with the keys is dangerous.
Page 117: Power Windows
To fully close the window automatically, pull the switch completely up, then release. The window will fully close automatically. To stop the window partway, pull or press the switch in the opposite direction and then release it. Knowing Your Mazda 3-41...
Page 118 Knowing Your Mazda Doors and Locks NOTE If the battery was disconnected during vehicle maintenance, or for other reasons such as a switch continues to be operated after the window is fully open/close, the window will not fully open and close automatically. Carry out the following procedure to resume operation: 1.
Page 119 Unless a passenger needs to operate a power window, keep the power window lock switch in the locked position: Unintentional power window operation is dangerous. A person's hands, head, or neck could be caught by the window and result in serious injury. Knowing Your Mazda 3-43...
Page 120: Fuel-Filler Lid And Cap
CAUTION Always use only a genuine Mazda fuel-filler cap or an approved equivalent, available at an Authorized Mazda Dealer. The wrong cap can result in a serious malfunction of the fuel and emission control systems.
Page 121 Doors and Locks NOTE The removed cap can be attached to the inner side of the lid during refueling to prevent fuel on the cap from dripping onto the vehicle. Knowing Your Mazda 3-45...
Page 122: Hood
Knowing Your Mazda Doors and Locks Hood WARNING Always check that the hood is closed and securely locked: A hood that is not closed and securely locked is dangerous as it could fly open while the vehicle is moving and block the driver's vision which could result in a serious accident.
Page 123: Moonroof
Before washing your Mazda, make sure the moonroof is completely closed so that water does not get inside the cabin area. After washing your Mazda or after it rains, wipe the water off the moonroof before operating it to avoid water penetration which could cause rust and water damage to your headliner.
Page 124 Knowing Your Mazda Doors and Locks To close to the desired position, press the front of the slide switch or pull the tilt switch. Open Close qPower Moonroof Re-set Procedure If the battery is disconnected, the moonroof may not operate correctly. The moonroof will not operate correctly until it is re-set.Carry out the following...
Page 125: Security System
If you have a problem with the immobilizer system or the advanced key (including auxiliary key), consult an Authorized Mazda Dealer. CAUTION Ø Radio equipment like this is governed by laws in the United States.
Page 126 Authorized Mazda Dealer. Always keep a spare advanced key in case one is lost. If an advanced key is lost, consult an Authorized Mazda Dealer as soon as possible. If you lose an advanced key (including auxiliary key), an Authorized Mazda Dealer...
Page 127 Go to an Authorized Mazda Dealer and have it checked. If the engine is shut off while the indicator light is flashing, you will not be able to restart it.
Page 128: Immobilizer System (Without Advanced Key)
Knowing Your Mazda Security System Immobilizer System (without Advanced Key) The immobilizer system allows the engine to start only with a key the system recognizes. If someone attempts to start the engine with an unrecognized key, the engine will not start, thereby helping to prevent the theft of your vehicle.
Page 129 Always keep a spare key, in case one is lost. If a key is lost, contact an Authorized Mazda Dealer as soon as possible. If you lose a key, an Authorized Mazda Dealer will reset the electronic codes of your remaining keys and immobilizer system.
Page 130: Theft-Deterrent System
Go to an Authorized Mazda Dealer and have it checked. If you shut off the engine while the light is flashing you will not be able to restart it.
Page 131 The security indicator light in the instrument panel flashes twice per second for 20 seconds. The theft deterrent system can also be armed by activating the auto re-lock function with all the doors, the liftgate/ trunk lid and the hood closed. Knowing Your Mazda 3-55...
Page 132 Knowing Your Mazda Security System NOTE Locking the doors with the inside door-lock knob will not arm the system. 3. After 20 seconds, the system is fully armed. NOTE Auto re-lock function After unlocking with the transmitter or the request switch, all doors and the liftgate...
Page 133 Labels A label indicating that your vehicle is equipped with a Theft-Deterrent System is in the glove compartment. Mazda recommends that you affix it to the lower rear corner of a front door window. Knowing Your Mazda Security System...
Page 134: Steering Wheel And Mirrors
Knowing Your Mazda Steering Wheel and Mirrors Steering Wheel WARNING Never adjust the steering wheel while the vehicle is moving: Adjusting the steering wheel while the vehicle is moving is dangerous. Moving it can very easily cause the driver to abruptly turn to the left or right.
Page 135 Before driving, adjust the rearview mirror to center on the scene through the rear window. Manual day/night mirror Auto-dimming mirror Knowing Your Mazda WARNING Cargo stacked higher than the seatbacks is dangerous. It can block your view in the rearview mirror, which might cause you to hit another car when changing lanes.
Page 136 Knowing Your Mazda Steering Wheel and Mirrors NOTE For the manual day/night mirror, perform the adjustment with the day/night lever in the day position. Reducing glare from headlights Manual day/night mirror Push the day/night lever forward for day driving. Pull it back to reduce glare of headlights from cars at the rear.
Page 137 Light sensor Light sensor The auto-dimmer function is canceled when the ignition is switched ON and the shift lever/selector lever is in reverse (R). Knowing Your Mazda Steering Wheel and Mirrors 3-61...
Page 138 3-62...
Page 139 Before Driving Your Mazda Important information about driving your Mazda. Fuel and Engine Exhaust Precautions ... 4-2 Fuel Requirements ... 4-2 Emission Control System ... 4-3 Engine Exhaust (Carbon Monoxide) ... 4-4 Before Starting the Engine ... 4-5 Before Getting In ... 4-5 After Getting In ...
Page 140: Fuel And Engine Exhaust Precautions
Ø Never add fuel system additives. Never add cleaning agents other than those specified by Mazda. Other cleaning agents and additives may damage the system. Consult an Authorized Mazda Dealer. Gasoline blended with oxygenates such as alcohol or ether compounds are generally referred to as oxygenated fuels.
Page 141: Before Driving Your Mazda
Ø USE ONLY UNLEADED FUEL. Ø Do not drive your Mazda with any sign of engine malfunction. Ø Do not coast with the ignition switched off. Ø Do not descend steep grades in gear with the ignition switched off.
Page 142: Engine Exhaust (Carbon Monoxide)
When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside your vehicle, keep all windows fully open and contact an Authorized Mazda Dealer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.
Page 143: Before Starting The Engine
NOTE Engine oil, engine coolant, brake/clutch fluid, washer fluid, and other fluid levels should be inspected. See Maintenance, Section 8. Before Driving Your Mazda Before Starting the Engine After Getting In Are all doors closed and locked? Is the seat adjusted properly?
Page 144: Driving Tips
No special break-in is necessary, but a few precautions in the first 1,000 km (600 miles) may add to the performance, economy, and life of your Mazda. Do not race the engine. Do not maintain one constant speed, either slow or fast, for a long period of time.
Page 145: Hazardous Driving
NOTE Use snow chains only on the front wheels. Before Driving Your Mazda Driving Tips Floor Mat WARNING Make sure the floor mats are hooked...
Page 146: Rocking The Vehicle
Carry emergency gear, including tire chains, window scraper, flares, a small shovel, jumper cables, and a small bag of sand or salt. Ask an Authorized Mazda Dealer to perform the following precautions: Have the proper ratio of antifreeze in the radiator.
Page 147 Install the chains on the front tires. Do not use chains on the rear tires. Use only genuine Mazda tire chains. Please consult an Authorized Mazda Dealer. Installing the chains 1.
Page 148: Driving In Flooded Area
Before Driving Your Mazda Driving Tips Driving In Flooded Area WARNING Dry wet brakes by driving very slowly and applying the brakes lightly until brake performance returns to normal: Driving with wet brakes is dangerous. Increased stopping distance or the vehicle pulling to one side when braking could result in a serious accident.
Page 149: Driving On Uneven Road
As a result, the sidewall of the tires are very thin and the tires and wheels can be damaged if driven through potholes or on rough/uneven roads at excessive speeds. Use care and reduce speed when traveling on rough/uneven roads or through potholes. Driving on Uneven Road Before Driving Your Mazda Driving Tips 4-11...
Page 150: Towing
Before Driving Your Mazda Towing Trailer Towing The Mazda3 is not designed for towing. Never tow a trailer with your Mazda3. 4-12...
Page 151: Driving Your Mazda
Driving Your Mazda Explanation of instruments and controls. Starting and Driving ... 5-2 Ignition Switch ... 5-2 Starting the Engine ... 5-4 Brake System ... 5-5 Manual Transaxle Operation ... 5-9 Automatic Transaxle Controls ... 5-12 Power Steering ... 5-18 í...
Page 152: Starting And Driving
Driving Your Mazda Starting and Driving Ignition Switch With advanced key Refer to Starting the engine (page 3-11) for information on how to use the ignition switch. qIgnition Switch Positions (Without Advanced Key) LOCK The steering wheel locks to protect against theft.
Page 153 ACC with the key inserted, a continuous beep sound will be heard when the driver's door is opened. NOTE A personalized function is available to change the sound volume for the ignition key reminder. Refer to Personalization Features on page 10-9. Driving Your Mazda...
Page 154: Starting The Engine
If the engine does not start the first time, refer to Starting a Flooded Engine under Emergency Starting. If the engine still does not start, have your vehicle inspected by an Authorized Mazda Dealer (page 7-17).
Page 155: Brake System
Brake System qFoot Brake Your Mazda has power-assisted brakes that adjust automatically through normal use. Should power-assist fail, you can stop by applying greater force than normal to the brake pedal. But the distance required to stop will be greater than usual.
Page 156 Driving Your Mazda Starting and Driving qParking Brake WARNING Before leaving the driver's seat, always switch the ignition off, set the parking brake, and make sure the shift lever is in P (automatic transaxle) or in 1st gear or R (manual transaxle):...
Page 157 Starting and Driving NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. WARNING Do not drive with the brake system warning light illuminated.
Page 158 ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS warning light may illuminate.
Page 159: Manual Transaxle Operation
WARNING Do not drive with both the ABS warning light and brake warning light illuminated. Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as soon as possible: Driving when the brake system warning light and ABS warning light are illuminated simultaneously is dangerous.
Page 160 Driving Your Mazda Starting and Driving (6-speed transaxle) Vehicles with 6-speed transaxle are equipped with a device to prevent shifting to R (reverse) by mistake. Push the shift lever downward and shift to R. WARNING Do not use sudden engine braking on...
Page 161 Driving Your Mazda Starting and Driving Downshifting When you must slow down in heavy traffic or on a steep upgrade, downshift before the engine starts to overwork. This reduces the chance of stalling and gives better acceleration when you need more speed.
Page 162: Automatic Transaxle Controls
Driving Your Mazda Starting and Driving Automatic Transaxle Controls Various Lockouts: Indicates that you must depress the brake pedal to shift (The ignition must be switched to ACC or ON). Indicates the shift lever can be shifted freely into any position.
Page 163 5-gear sequence. M (Manual) M is the manual shift mode position. Gears can be shifted up or down by operating the shift lever. Refer to Manual Shift Mode (page 5-15). Driving Your Mazda 5-13...
Page 164 1. Remove the shift-lock override cover using a cloth-wrapped flat head screwdriver. 2. Insert a screwdriver and push it down. Cover 3. Move the shift lever. 4. Take the vehicle to an Authorized Mazda Dealer to have the system checked.
Page 165 This is a normal function to protect the AT. After the ATF temperature has decreased, the gear position indicator illumination turns back on and driving in manual shift mode is restored. Driving Your Mazda 5-15...
Page 166 Driving Your Mazda Starting and Driving Shifting Manually Shifting up (M1→M2→M3→M4→M5) To shift up to a higher gear, tap the shift lever back ( ) once. NOTE When driving slowly, the gears may not shift up depending on vehicle speed.
Page 167 For normal acceleration and cruising, we recommend these shift points. Gear M1 to M2 M2 to M3 M3 to M4 M4 to M5 Driving Your Mazda Vehicle speed 196 km/h (121 mph) 135 km/h (83 mph) 90 km/h (55 mph) 37 km/h (22 mph) Vehicle speed...
Page 168: Power Steering
Driving Your Mazda Starting and Driving Downshifting When you must slow down in heavy traffic or on a steep upgrade, downshift before the engine starts to overwork. This gives better acceleration when you need more speed. On a steep downgrade, downshifting helps maintain safe speed and prolongs brake life.
Page 169: Cruise Control
If the light remains illuminated, the power steering is still inoperable. Consult an Authorized Mazda Dealer. NOTE The power steering system is inoperable when the power steering malfunction indicator light illuminates. Steering is possible, but requires more physical effort.
Page 170 Driving Your Mazda Starting and Driving qActivation/Deactivation To activate the system, press the ON switch. To deactivate the system, press the OFF switch. (Type A) (Type B) 5-20 WARNING Always turn off the cruise control system when it is not in use:...
Page 171 Follow either of these procedures. To increase speed using cruise control switch Type A Press up the cruise control SET and hold it. Your vehicle will accelerate. Release the switch at the speed you want. Cruise control switch Driving Your Mazda switch 5-21...
Page 172 Driving Your Mazda Starting and Driving Your vehicle has a tap-up feature that allows you to increase your current speed in increments of 1.6 km/h (1 mph) by a momentary tap of the cruise control SET switch. Multiple taps will increase your vehicle speed 1.6 km/h (1 mph) for...
Page 173 RES switch is pressed. If vehicle speed is below 32 km/h (20 mph), increase the vehicle speed up to 32 km/h (20 mph) or more and press the RES switch. Driving Your Mazda Starting and Driving 5-23...
Page 174 Driving Your Mazda Starting and Driving (Type A) (Type B) qTo Cancel To cancel the system, use one of these methods: Press the OFF switch. Slightly depress the brake pedal. Depress the clutch pedal (Manual transaxle only). Press the CANCEL switch.
Page 175: Traction Control System (Tcs)
If the light stays on, the TCS or DSC may have a malfunction and they may not operate correctly. Take your vehicle to an Authorized Mazda Dealer. NOTE In addition to the indicator light flashing, a slight lugging sound will come from the engine.
Page 176: Dynamic Stability Control (Dsc)
CAUTION Ø The DSC may not operate correctly unless the following are observed: Ø Use tires of the correct size specified for your Mazda on all four wheels. Ø Use tires of the same manufacturer, brand and tread pattern on all four wheels.
Page 177 (page 5-27). If the light stays on when the TCS/DSC is not switched off, take your vehicle to an Authorized Mazda Dealer. The dynamic stability control may have a malfunction. qDSC OFF Switch Press the DSC OFF switch to turn off the TCS/DSC.
Page 178: Tire Pressure Monitoring System
Driving Your Mazda Starting and Driving í Tire Pressure Monitoring System The tire pressure monitoring system (TPMS) monitors the pressure for each tire. If tire pressure is too low in one or more tires, the system will inform the driver via the warning light in the instrument panel and by the warning beep sound.
Page 179 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Driving Your Mazda Starting and Driving 5-29...
Page 180 Authorized Mazda Dealer or a tire repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Page 181 Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
Page 182 The signal code must be registered with the TPMS before it can work. The easiest way to do it is to have an Authorized Mazda Dealer change your tire and complete ID signal code registration. When having tires changed at an...
Page 183 Replacing tires and wheels CAUTION Ø When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. Ø The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Page 184: Instrument Cluster And Indicators
Driving Your Mazda Instrument Cluster and Indicators (Black-out meter) When the ignition is switched ON, the dashboard gauges illuminate. Speedometer ... page 5-35 Odometer, Trip Meter and Trip Meter Selector ... page 5-35 Tachometer ... page 5-36 Fuel Gauge ... page 5-37 Dashboard Illumination ...
Page 185 The trip meter can record the total distance of two trips. One is recorded in trip meter A, and the other is recorded in trip meter B. Driving Your Mazda Trip meter A Press the selector Trip meter B Press the selector...
Page 186 Driving Your Mazda Instrument Cluster and Indicators For instance, trip meter A can record the distance from the point of origin, and trip meter B can record the distance from where the fuel tank is filled. When trip meter A is selected, pressing the selector again within one second will change to trip meter B mode.
Page 187 When driving on snowy or foggy roads, or in other situations when the instrument cluster or information display's visibility is reduced due to glare from surrounding brightness, cancel the illumination dimmer and increase the illumination intensity. Driving Your Mazda position. Bright 5-37...
Page 188 Driving Your Mazda Instrument Cluster and Indicators To cancel the illumination dimmer, press the dashboard illumination knob. NOTE This symbol ( ) indicates the knob to adjust the brightness of the dashboard illumination. If the illumination dimmer is cancelled, the...
Page 189: Warning/Indicator Lights And Beep Sounds
Check Engine Light High Engine Coolant Temperature Warning Light ABS Warning Light Air Bag/Front Seat Belt Pretensioner System Warning Light Warning/Indicator lights will appear in any of the highlighted areas Warning/Indicator Lights Driving Your Mazda Page 5-41 5-43 5-43 5-43...
Page 190 Driving Your Mazda Warning/Indicator Lights and Beep Sounds Signal Low Fuel Warning Light Check Fuel Cap Warning Light Seat Belt Warning Light/Beep Door-Ajar Warning Light Low Washer Fluid Level Warning Light Automatic Transaxle Warning Light Tire Pressure Monitoring System Warning Light...
Page 191 NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. Do not drive with the brake system warning light illuminated. Contact an...
Page 192 ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS warning light may illuminate.
Page 193 If the light remains illuminated even after you add oil, stop the engine immediately and have your vehicle towed to an Authorized Mazda Dealer. qCheck Engine Light This indicator light illuminates when the ignition is switched ON and turns off when the engine is started.
Page 194 The fuel-filler cap is missing or not tightened securely. If the check engine light remains on or flashes continuously, do not drive at high speeds and consult an Authorized Mazda Dealer as soon as possible. qHigh Engine Coolant Temperature Warning Light...
Page 195 ON. Belt minder NOTE The belt minder can be deactivated. Consult an Authorized Mazda Dealer to deactivate or restore the seat belt minder. Driver seated/Front passenger not seated The belt minder is a supplemental warning to the seat belt warning function.
Page 196: Warning Light
Driving Your Mazda Warning/Indicator Lights and Beep Sounds Once the beep sound is heard, it continues sounding even if the vehicle speed lowers to 20 km/h (12 mph) or less until the seatbelt is fastened or the beep sound period has passed.
Page 197 CAUTION If the automatic transaxle warning light illuminates, the transaxle has an electrical problem. Continuing to drive your Mazda in this condition could cause damage to your transaxle. Consult an Authorized Mazda Dealer as soon as possible. qTire Pressure Monitoring System...
Page 198 Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your...
Page 199 Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. The advanced key battery is dead. The advanced key is not within operational range.
Page 200 Driving Your Mazda Warning/Indicator Lights and Beep Sounds Under the following conditions, the KEY warning light (red) will flash continuously when the push button start has not been pressed off to notify the driver that the advanced key has been removed. The KEY warning light...
Page 201 Indicator Light This indicator light stays on for a few seconds when the ignition is switched ON. If the TCS or DSC is operating, the indicator light flashes. Driving Your Mazda Gear position indicator í í Some models. 5-51...
Page 202 (page 5-27). If the light stays on when the TCS/DSC is not switched off, take your vehicle to an Authorized Mazda Dealer. The dynamic stability control may have a malfunction. qAFS OFF Indicator Light The AFS OFF indicator light illuminates briefly when the ignition is switched ON, and then turns off.
Page 203 If the light remains illuminated, the power steering is still inoperable. Consult an Authorized Mazda Dealer. NOTE The power steering system is inoperable when the power steering malfunction indicator light illuminates. Steering is possible, but requires more physical effort.
Page 204 The air bag and seat belt pretensioner system warning beep sound will continue to be heard for approximately 35 minutes. Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible. WARNING Do not drive the vehicle with the air...
Page 205 Refer to Warning and Beep Sounds on page 3-20. qElectronic Steering Lock Warning Beep The warning beep operates if the steering wheel is not unlocked after the push button start is pressed. (page 3-11) Driving Your Mazda í í í Some models. í 5-55...
Page 206: Switches And Controls
Driving Your Mazda Switches and Controls Lighting Control qHeadlights Type A (Without AUTO position) Turn the headlight switch to turn the headlights, other exterior lights and dashboard illumination on or off. Switch Position Headlights Taillights Parking lights License lights Side-marker lights...
Page 207 The timing for turning on the headlights, other exterior lights and dashboard illumination can be delayed by adjusting the sensitivity of the light sensor. Consult an Authorized Mazda Dealer regarding sensor adjustment. The sensitivity of the AUTO lights may be changed.Refer to Personalization Features on page 10-9.
Page 208 Driving Your Mazda Switches and Controls NOTE If the headlights flicker, or the brightness weakens, the bulb-life may be depleted and a replacement is necessary. Consult an Authorized Mazda Dealer. qLights-On Reminder If lights are on and the key is removed...
Page 209 AFS function and illuminates the indicator light. The following conditions could indicate that the system is malfunctioning. If one of the following conditions occurs, consult an Authorized Mazda Dealer. Switch Load The AFS OFF indicator light does not Position illuminate even though the ignition is switched ON.
Page 210 Driving Your Mazda Switches and Controls Pressing the AFS OFF switch again turns off the AFS OFF indicator light and turns on the AFS. qDaytime Running Lights (Canada) In Canada, vehicles must be driven with the headlights on during daytime operation.
Page 211 If the fog light switch is in the ON position and the headlight switch is in the AUTO position, the fog lights will be turned on when the exterior lights and dashboard illumination are automatically turned on. í Some models. Driving Your Mazda í 5-61...
Page 212 After 5 minutes, turn on the switch and the blades should operate normally. If they do not resume functioning, consult an Authorized Mazda Dealer as soon as possible. Drive to the side of the road and park off the right-of- way. Wait until the weather clears before trying to drive with the wipers inoperative.
Page 213 From the center position (normal), turn the switch towards (+) for higher sensitivity (faster response) or turn the switch towards ( _ ) for less sensitivity (slower response). Switch Driving Your Mazda Higher sensitivity Center position Less sensitivity í 5-63...
Page 214 Driving Your Mazda Switches and Controls CAUTION Ø Do not shade the rain sensor by adhering a sticker or a label on the windshield. Otherwise the rain sensor will not operate correctly. Rain sensor 5-64 Ø When the wiper lever is in the...
Page 215 With the wiper lever in the OFF or INT (Type A)/AUTO (Type B) position, the wipers will operate continuously until the lever is released. If the washer does not work, inspect the fluid level (page 8-25). If it's normal, consult an Authorized Mazda Dealer. Driving Your Mazda Washer 5-65...
Page 216 Driving Your Mazda Switches and Controls Rear Window Wiper and Washer (5 Door) The ignition switch must be in the ON position. qRear Window Wiper Turn the wiper on by turning the rear wiper/washer switch. Normal Intermittent qRear Window Washer...
Page 217 To turn on the mirror defrosters, switch the ignition ON and press the rear window defroster switch (page 5-66). Switches and Controls Horn To sound the horn, press the the steering wheel. í Some models. Driving Your Mazda mark on 5-67...
Page 218 Driving Your Mazda Switches and Controls Hazard Warning Flasher The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.
Page 219: Interior Comfort
System ... 6-80 Hands-Free Setting ... 6-86 When Bluetooth Hands-Free Cannot be Used ... 6-92 Safety Certification ... 6-92 Mazda Bluetooth Hands-Free Customer Service ... 6-93 Interior Equipment ... 6-94 Sunvisors ... 6-94 Interior Lights ... 6-94 Information Display ... 6-96 Multi Information Display Cup Holder ...
Page 220: Climate Control System
Have the air conditioner checked before the weather gets hot. Lack of refrigerant may make the air conditioner less efficient. Consult an Authorized Mazda Dealer for refrigerant inspection. The air conditioner is filled with HFC134a (R134a), a refrigerant that will not damage the ozone layer.
Page 221 qAdjusting the Vents Directing airflow Side Vents To adjust the direction of airflow, open the vents and rotate them left and right. Push Climate Control System Vent Operation Center Vents To adjust the direction of airflow, move the adjustment knob. NOTE When using the air conditioner under humid ambient temperature conditions, the system...
Page 222 Interior Comfort Climate Control System qSelecting the Airflow Mode Dashboard Vents Dashboard and Floor Vents Floor Vents Defroster and Floor Vents Defroster Vents...
Page 223 Interior Comfort Climate Control System Types of the Climate Control System Manual type and fully automatic type climate control systems are explained separately. Check your vehicle's climate control type and read the appropriate pages. Manual Type ... page 6-6 Fully Automatic Type ... page 6-11...
Page 224 Interior Comfort Climate Control System Mode selector dial qControl Switches Temperature control dial Cold This dial controls temperature. Turn it clockwise for hot and counterclockwise for cold. í Some models. í Manual Type Fan control dial Temperature control dial A/C switch Air intake selector Fan control dial This dial allows variable fan speeds.
Page 225 Mode selector dial Turn the mode selector dial to select airflow mode (page 6-4). NOTE The mode selector dial can be set at the intermediate positions ( mode. Set the dial to a intermediate position if you want to slightly adjust the airflow amount.
Page 226 Interior Comfort Climate Control System Recirculated air mode (indicator light illuminated) Outside air is shut off. Air within the vehicle is recirculated. This mode can be used when driving on a dusty road or in similar conditions. It also helps to provide quicker cooling of the interior.
Page 227 CAUTION If the air conditioner is used while driving up long hills or in heavy traffic, monitor the engine coolant temperature warning light to see if it is illuminated or flashing (page 5-44). The air conditioner may cause engine overheating. If the warning light is illuminated or flashing, turn the air conditioning off (page 7-15).
Page 228 Interior Comfort Climate Control System qDehumidifying (With Air í Conditioner) Operate the air conditioner in cool or cold weather to help defog the windshield and side windows. 1. Set the mode selector dial to the desired position. 2. Set the air intake selector to the outside air mode.
Page 229 Interior Comfort Climate Control System í Fully Automatic Type Climate control information is displayed on the information display. Information display Airflow display Air intake display DUAL AUTO Temperature setting display (passenger) Temperature setting display (driver) Mode selector display Driver temperature control dial Fan control dial Passenger temperature control dial AUTO switch...
Page 230 Interior Comfort Climate Control System qControl Switches AUTO switch By pressing the AUTO switch the following functions will be automatically controlled in accordance with the selected set temperature: Airflow temperature Amount of airflow Selection of airflow mode Outside/Recirculated air selection Air conditioner operation NOTE AUTO switch indicator light...
Page 231 Mode selector switch The desired airflow mode can be selected (page 6-4). NOTE With the airflow mode set to the position and the temperature control dial set at a medium temperature, heated air is directed to the feet and a comparably lower air temperature will flow through the central, left and right vents.
Page 232 Interior Comfort Climate Control System WARNING Do not use the position in cold or rainy weather: Using the position in cold or rainy weather is dangerous as it will cause the windows to fog up. Your vision will be hampered, which could lead to a serious accident.
Page 233 2. Use the temperature control dial to select a desired temperature. Press the DUAL switch or turn the front passenger temperature control dial to control the set temperature individually for the driver and front passenger. To turn off the system, press the OFF switch.
Page 234 Interior Comfort Climate Control System qSunlight/Temperature Sensor The fully automatic air conditioner function measures inside and outside temperatures, and sunlight. It then sets temperatures inside the passenger compartment accordingly. CAUTION Do not obstruct either sensor, otherwise the automatic air conditioner will not operate properly. Sunlight sensor Interior temperature sensor 6-16...
Page 235: Audio System
Antenna qAntenna (4 Door) AM/FM Radio Antenna The AM/FM radio antenna receives both AM and FM signals. The AM/FM radio antenna is in the rear window. CAUTION When washing the inside rear window, use a soft cloth dampened in lukewarm water, gently wiping the antenna lines.
Page 236 Interior Comfort Audio System NOTE When leaving your vehicle unattended, we recommend that you remove the antenna and store it inside the vehicle. 6-18 Operating Tips for Audio System WARNING Do not adjust the audio control switches while driving the vehicle: Adjusting the audio while driving the vehicle is dangerous as it could distract your attention from the...
Page 237 qRadio Reception AM characteristics AM signals bend around such things as buildings or mountains and bounce off the ionosphere. Therefore, they can reach longer distances than FM signals. Because of this, two stations may sometimes be picked up on the same frequency at the same time.
Page 238 Interior Comfort Audio System Flutter/Skip noise Signals from an FM transmitter move in straight lines and become weak in valleys between tall buildings, mountains, and other obstacles. When a vehicle passes through such an area, the reception conditions may change suddenly, resulting in annoying noise.
Page 239 qOperating Tips for CD Player/In- Dash CD Changer Condensation phenomenon Immediately after turning on the heater when the vehicle is cold, the CD or optical components (prism and lens) in the CD player/In-dash CD changer may become clouded with condensation. At this time, the CD will eject immediately when placed in the unit.
Page 240 Interior Comfort Audio System A new CD may have rough edges on its inner and outer perimeters. If a disc with rough edges is used, proper setting will not be possible and the CD player/In-dash CD changer will not play the CD. In addition, the disc may not eject resulting in a malfunction.
Page 241 Insert discs one by one. If two discs are inserted at the same time, the system may not operate properly. The CD player/In-dash CD changer ejects the CD if the CD is inserted upside down. Also dirty and/or defective CDs may be ejected. An 8 cm (3 in) CD can be played in the CD player.
Page 242 Interior Comfort Audio System This unit handles MP3 files conforming to the MP3 format containing both header frames and data frames. This unit can play multi-session recorded discs that have up to 40 sessions. This unit can play MP3s with sampling frequencies of 16/22.05/24/32/44.1/48 kHz.
Page 243 A single disc with up to 512 files can be played and a single folder with up to 255 files can be played. When naming an MP3 file, be sure to add an MP3 file extension (.mp3) after the file name. The maximum number of characters that can be used for file names is as follows.
Page 244 Interior Comfort Audio System Bit rate Refers to the volume of data per second, expressed in bps (bits per second). Generally, the larger the number of the transfer bit rate when compressing an MP3 file, the more information regarding musical reproduction it carries, and therefore the better the sound quality.
Page 245 Interior Comfort Audio System Audio Set Audio information is displayed on the information display. CD Player In-Dash CD Changer Power/Volume/Sound Controls ... page 6-28 Operating the Radio ... page 6-32 Operating the Satellite Radio ... page 6-34 Operating the Compact Disc (CD) Player ... page 6-46 Operating the In-Dash CD Changer ...
Page 246: Power/Volume/Sound Controls
Interior Comfort Audio System qPower/Volume/Sound Controls Power/Volume dial Power ON/OFF Switch the ignition to ACC or ON. Press the power/volume dial to turn the audio system on. Press the power/volume dial again to turn the audio system off. NOTE To prevent the battery from being discharged, do not leave the audio system on for a long period of time when the engine is not running.
Page 247 Standard audio-equipped model Bose Sound System-equipped model *1 Depending on the mode selected, the indication changes. *2 Depending on the model, this function, may not be available. 2. Turn the audio control dial to adjust the selected functions as follows: Standard audio-equipped model Indication Interior Comfort...
Page 248 Interior Comfort Audio System ® Bose Sound System-equipped model Indication Turn Left Turn Right Decrease bass Decrease treble Shift the sound to the front Shift the sound to the left NOTE About 5 seconds after selecting any mode, the volume function will be automatically selected. To reset bass, treble, fade, and balance, press the audio control dial for 2 seconds.
Page 249 ® ® AudioPilot 2 (Bose Sound System- equipped model) ® AudioPilot 2 automatically adjusts audio volume and sound quality in accordance with the level of noise entering the vehicle interior while driving. When AudioPilot 2 is turned on, the system automatically calculates the conditions for optimum hearing of sound which may be difficult to hear depending on exterior noise.
Page 250: Operating The Radio
Interior Comfort Audio System qOperating the Radio Channel preset buttons Band selector buttons Seek tuning buttons Radio ON Press a band selector button ( turn the radio on. Band selection Choose AM by pressing the AM button ) and FM by pressing the FM button The selected mode will be indicated.
Page 251 NOTE If you continue to press and hold the button, the frequency will continue changing without stopping. Scan tuning Press the scan button ( automatically sample strong stations. Scanning stops at each station for about 5 seconds. To hold a station, press the scan button ( ) again during this interval.
Page 252: Operating The Satellite Radio
Interior Comfort Audio System qOperating the Satellite Radio Band selector buttons Seek tuning buttons Display button Channel preset buttons Information display All operations of the satellite radio are displayed on the Information display. Channel number, Channel name, Category name, Artist name, Song title, ID code, Preset channel number, Bank number, Error signs 6-34 Satellite button...
Page 253 NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, If not installed and used in accordance with the instructions,...
Page 254 Interior Comfort Audio System How to subscribe to satellite radio Once the system is installed you must first subscribe to the SIRIUS Radio service to activate the system. The SIRIUS Radio service uses an ID code to identify your radio. This code is needed to subscribe to SIRIUS Radio, and if needed, is also used to report any problems should there be any in the...
Page 255 Every time the satellite button is pressed, the bank changes in the order shown below. NOTE SR1, SR2 and SR3: six stations can be stored in each bank for convenient access to your favorite stations. Operation in the initial state It may take some time to start up the equipment when it is in the initial state, when there is a change in the user's...
Page 256 Interior Comfort Audio System Preset channel programming (Programming with channel number display) 1. Select the desired channel to be programmed. At this point, the following is displayed: (bank number) number)] 2. Keep pressing the channel preset button for 1.5 seconds or more. The programming process is complete after the channel number flashes.
Page 257 Channel selection within a category If category is not in ALL and the channel number is displayed, turning the manual tuning dial moves the channel number up/down in the present category. Turn the manual tuning dial clockwise: Channel Up Turn the manual tuning dial counterclockwise: Channel Down NOTE The channel number needs to be indicated in...
Page 258 Interior Comfort Audio System The long name is displayed first, and three seconds later the short name is displayed. If there is no short name, the long name is displayed. To display the rest of the characters of the category name, press the text button (TEXT).
Page 259 If ESN FAIL is displayed after pressing the ESN button for 1.5 seconds or longer, contact an Authorized Mazda Dealer. Initialization of ID code If the registered ID code is forgotten, return the ID code to the default [0000] by...
Page 260 Interior Comfort Audio System (Master code input determination) 5. Determine the master code which has been input by pressing the auto memory button (scan button). 6. PIN CLEARED appears which indicates that the master code input has been completed. 7. The ID code is set to the default [0000] and the initialization process is completed.
Page 261 (Verification with the registered ID code) 5. Determine the input code by pressing the auto memory button (scan button). 6. If it does not match with the previously registered code, SR1 Err is displayed and then it returns to SR1 - - - - . 7.
Page 262 Interior Comfort Audio System 8. If it matches the registered code, SR1 LOCK appears for three seconds which indicates that the code input has been completed. 9. SR1 LOCK 100 appears which indicates that the parental lock is activated. At this time, mute is on and no sound is heard.
Page 263 Error signs (1) Depending on the surrounding conditions (such as large trees, buildings, or tunnels) and special weather conditions, the reception of SIRIUS radio waves may be decreased or temporarily interrupted. ACQUIRING may appear. (2) In case of an antenna malfunction, ANTENNA FAIL is displayed.
Page 264: Operating The Compact Disc (Cd) Player
Interior Comfort Audio System qOperating the Compact Disc (CD) Player Load button Track up/Fast- forward button Repeat button Random button Track down/Reverse button Type Playable data Music/MP3/WMA CD · Music data (CD-DA) player · MP3/WMA file NOTE If a disc has both music data (CD-DA) and MP3/WMA files, playback of the two or three file types differs depending on how the disc was recorded.
Page 265 Fast-forward/Reverse Press and hold the fast-forward button ) to advance through a track at high speed. Press and hold the reverse button ( reverse through a track at high speed. Track search Press the track up button ( file dial clockwise once to skip forward to the beginning of the next track.
Page 266 Interior Comfort Audio System (CD random) 1. Press the random button ( playback, and then press the button again within 3 seconds to play the tracks on the CD randomly. DISC RDM is displayed. 2. Press the button again to cancel the random playback.
Page 267 If CHECK CD is displayed, it means that there is some CD malfunction. Check the CD for damage, dirt, or smudges, and then properly reinsert. If the message appears again, take the unit to an Authorized Mazda Dealer for service. 6-49...
Page 268: Operating The In-Dash Cd Changer
Interior Comfort Audio System qOperating the In-Dash CD Changer Load button Disc down button Random button Repeat button Channel preset buttons Track down/Reverse button Type Playable data Music/MP3/WMA CD ·Music data (CD-DA) player ·MP3/WMA file NOTE If a disc has both music data (CD-DA) and MP3/WMA files, playback of the two or three file types differs depending on how the disc was recorded.
Page 269 Multiple insertion 1. Press and hold the load button ( for about 2 seconds until a beep sound is heard. 2. When IN is displayed, insert the CD. 3. When IN is displayed again, insert the next CD. NOTE The first-inserted CD will be played automatically when: No other CD is inserted within 15 seconds after IN is displayed.
Page 270 Interior Comfort Audio System Press and hold the reverse button ( reverse through a track at high speed. Track search Press the track up button ( file dial clockwise once to skip forward to the beginning of the next track. Press the track down button ( the file dial counterclockwise once to skip back to the beginning of the current track.
Page 271 (CD random) 1. Press the random button ( playback, and then press the button again within 3 seconds to play the tracks on the CD randomly. DISC RDM is displayed. 2. Press the button again to cancel the random playback. Switching the display For files with a file name or other name that have been input, the display changes...
Page 272: Operating The Auxiliary Jack
CD for damage, dirt, or smudges, and then properly reinsert. If the message appears again, take the unit to an Authorized Mazda Dealer for service. qOperating the Auxiliary jack You can connect portable audio units or similar products on the market to the...
Page 273: Error Indications
Indications If you see an error indication on the display, find the cause in the chart. If you cannot clear the error indication, take the vehicle to an Authorized Mazda Dealer. Indication CD is inserted upside down CHECK CD...
Page 274 The talk button, pick-up button, and hang- up button are operable with the audio unit turned off. Mazda has installed this system to prevent distraction while driving the vehicle and using audio controls on the dashboard. Always make safe driving your first priority.
Page 275 Without Bluetooth Hands-Free and navigation system With Bluetooth Hands-Free only/ Bluetooth Hands-Free and navigation system Audio System qChanging the Source Press the mode switch ( the audio source (FM1 radio> FM2 radio> AM radio> CD player or CD changer> SIRIUS1> SIRIUS2> SIRIUS3> AUX> BT audio>...
Page 276 Interior Comfort Audio System NOTE CD, CD changer, SIRIUS digital satellite radio, and BT audio modes cannot be selected in the following cases: · SIRIUS digital satellite radio unit, or BT audio unit is not equipped on the audio system. ·...
Page 277 í qMute Switch Press the mute switch ( ) once to mute audio, press it again to resume audio output. NOTE If the ignition is turned off (LOCK) with the audio muted, the mute will be canceled. Therefore, when the engine is restarted, the audio is not muted.
Page 278 Interior Comfort Audio System NOTE Before using the auxiliary jack, read the manufacturer's instructions for the product being connected. Use a commercially-available, non- impedance (3.5 ) stereo mini plug for connecting the portable audio unit to the auxiliary jack. Before using the auxiliary jack, read the manufacture's instructions for connecting a portable audio unit to the auxiliary jack.
Page 279 3. Press the AUX button ( audio unit or the mode switch ( of the audio control switches on the steering wheel to change to the AUX mode. Audio Unit Audio Control Switches NOTE Set the volume of the portable audio unit to the maximum within the range that the sound does not become distorted, then adjust the volume using the power/volume...
Page 280 Ø This CD player should not be adjusted or repaired by anyone except qualified service personnel. If servicing is required, contact an Authorized Mazda Dealer. Ø Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser exposure. Never operate the CD player with the top case of the unit removed.
Page 281: Bluetooth Audio
Bluetooth audio system while the vehicle is stopped. Ø Because only specified Bluetooth audio devices can be used, consult an Authorized Mazda Dealer when purchasing or changing devices. Bluetooth audio devices which correspond to specified Bluetooth versions and profiles can be...
Page 282 Interior Comfort Bluetooth Audio NOTE It may not be possible to play a Bluetooth audio device if it is placed anywhere transmission is compromised, such as inside a metal container or the trunk. Move the Bluetooth audio device to a location where transmission is possible.
Page 283 Bose Sound System-equipped model *1 Depending on the mode selected, the indication changes. *2 Depending on the model, this function, may not be available. 2. Turn the audio control dial and select a desired mode. Display PAIR DEVICE LINK CHANGE PAIR DELETE DEVICE INFO 3.
Page 284 Interior Comfort Bluetooth Audio NOTE Always perform Bluetooth audio device programming while the vehicle is stopped. If a Bluetooth device has already been programmed to the vehicle as a hands-free mobile phone, it does not need to be programmed again when using the device as a Bluetooth audio device.
Page 285 NOTE Some Bluetooth audio devices need a certain amount of time before the symbol is displayed. If the programming failed, Err flashes for three seconds then it returns to PAIR DEVICE . Programming cannot be performed while the vehicle is moving. If you attempt to perform programming while the vehicle is moving, PAIR DISABLE is displayed and it returns to PAIR DEVICE .
Page 286 Interior Comfort Bluetooth Audio Changing the link to a Bluetooth audio device If several devices have been programmed, the Bluetooth unit links the device last programmed. If you would like to link a different programmed device, it is necessary to change the link. The order of device priority after the link has been changed is maintained even when the ignition is switched off (LOCK).
Page 287 NOTE Some Bluetooth audio devices need a certain amount of time before the symbol is displayed. If a hands-free type mobile phone has been the most recently programmed device, the Bluetooth unit links this device. If you would like to use a Bluetooth audio type device which has been previously programmed to the Bluetooth unit, the link must be changed to this device.
Page 288 Interior Comfort Bluetooth Audio 7. Press the audio control dial to delete the selected device. NOTE Select GO BACK and press the audio control dial to return to the PAIR DELETE display. 8. PAIR DELETED is displayed for 3 seconds after the deletion is completed, and then it returns to the normal display.
Page 289 2. Turn on the Bluetooth audio device's power. Make sure that the displayed in the information display. The symbol is not displayed if an unprogrammed Bluetooth audio device is being used or the vehicle's Bluetooth unit has a malfunction. NOTE Some Bluetooth audio devices need a certain amount of time before the displayed.
Page 290 Bluetooth devices (Mobile phone) are some which will not connect with your Mazda or will have limited function. Therefore, consult Mazda Bluetooth Hands-Free Customer Service for information regarding device (Mobile phone) compatibility: Phone: 800-430-0153 Web: www.MazdaUSA.com/...
Page 291 OPP (Object Push Profile) Ver. 1.1 Bluetooth is the registered trademark of Bluetooth SIG. Inc. NOTE If the ignition is turned off (LOCK) during a hands-free call, the line is transferred to the device (Mobile phone) automatically. If the device (Mobile phone) is in a location where radio reception is difficult such as a metal container or in the trunk, the call may not be connected using Bluetooth.
Page 292 Interior Comfort Bluetooth Hands-Free Information display When available, the information display shows telephone numbers, Bluetooth Hands-Free messages, and operation status. Microphone The microphone is used for speaking voice commands or exchanging conversation. Audio unit The audio unit is used for adjusting the volume.
Page 293 Please be aware that the voice recognition may error despite following the above points. qFunction Restrictions While Using Bluetooth Hands-Free Some functions are limited while Bluetooth Hands-Free is being used. They include: Beep sound and voice guidance related to the audio unit are not heard. Beep sound related to the A/C operation is not heard.
Page 294 Interior Comfort Bluetooth Hands-Free Basic Bluetooth Hands- Free Operation qBluetooth Hands-Free Preparation Language setting The available languages are English, Spanish, and Canadian French. If the language setting is changed, all of the voice guidance and voice input commands are done in the selected language.
Page 295 NOTE For the operation of the device, refer to its instruction manual. 15. Select Mazda from the device list searched by the device. 16. Input the 4-digit pairing code set in Step 9 to the device. 17. Prompt: Please say the name of the device after the beep.
Page 296 Interior Comfort Bluetooth Hands-Free 18. Say: [Beep] XXXX - - - (Speak a device tag , an arbitrary name for the device.) Example: Stan's device. NOTE Speak a programmed device tag within 10 seconds. If more than two devices are to be programmed, they cannot be programmed with the same or similar device tag .
Page 297 qReceiving an Incoming Call 1. Prompt: Incoming call, press the pickup button to answer . 2. To accept the call, press the pick-up button. To reject the call, press the hang-up button. qHanging Up a Call Press the hang-up button during the call. A beep sound will confirm that call is ended.
Page 298 Interior Comfort Bluetooth Hands-Free Convenient Use of the Hands-Free System qPhonebook Usage Phonebook registration Phone numbers can be registered to the Bluetooth Hands-Free phonebook. NOTE Do this function only when parked. It is too distracting to attempt while driving and you may make too many errors to be effective.
Page 299 7. Prompt: X (Number of locations which include data) numbers have been imported. What name would you like to use for these numbers? 8. Say: [Beep] XXXXX... (Ex. Mary's phone ) (Say a voice tag for the name registered.) 9. Prompt: Adding XXXXX... (Ex. Mary's phone ) (Voice tag).
Page 300 Interior Comfort Bluetooth Hands-Free qRefusing an Incoming Call For incoming call refusal, refer to Receiving an incoming call (page 6-79). qMute The microphone can be muted during a call. 1. Press the talk button with a short press. 2. Say: [Beep] Mute 3.
Page 301 Three-way call function 1. Press the talk button with a short press. 2. Say: [Beep] Join call 3. Prompt: Joining calls Making a call using a telephone number 1. Press the talk button with a short press. 2. Say: [Beep] Dial 3.
Page 302 Interior Comfort Bluetooth Hands-Free 8. Say: [Beep] Home (Say the registered location to be edited: Home , Work , Mobile , or Other ). 9. Prompt: XXXXX... (Ex. Mary's phone ) (Registered voice tag) XXXX (Ex. home ) (Registered location). Is this correct? 10.
Page 303 5. Prompt: Are you sure you want to erase everything from your Hands Free system phonebook? 6. Say: [Beep] Yes 7. Prompt: You are about to delete everything from your Hands Free system phonebook. Do you want to continue? 8. Say: [Beep] Yes 9.
Page 304 Interior Comfort Bluetooth Hands-Free Hands-Free Setting qDevice Device registration For the registration of a Bluetooth equipped device to Bluetooth Hands-Free, refer to Bluetooth Hands-Free preparation (page 6-76). Registered device read-out Bluetooth Hands-Free can read-out the devices registered to its system. NOTE Do this function only when parked.
Page 305 3. Prompt: Select one of the following: Pairing options, confirmation prompts, language, passcode, select phone or select music player. 4. Say: [Beep] Select phone 5. Prompt: Please say 1 for XXXXX... (Ex. device A), 2 for XXXXX... (Ex. device B...) 6.
Page 306 Interior Comfort Bluetooth Hands-Free NOTE Say All to delete all devices (Mobile phone). 9. Prompt: Deleting XXXXX... (Ex. device B...) (Registered device tag). Is this correct? 10. Say: [Beep] Yes 11. Prompt: Deleted Registered device editing 1. Press the pick-up button or talk button with a short press.
Page 307 2. Prompt: Hands-Free system is locked. State the passcode to continue. 3. Say: [Beep] XXXX (Say the set passcode PCode .) 4. If the correct passcode is input, voice guidance XXXXXX... (Ex. Mary's device) (Device tag) is connected is announced. If the passcode is incorrect, voice guidance XXXX (4-digit passcode, Pcode) incorrect passcode, please try...
Page 308 Interior Comfort Bluetooth Hands-Free qVoice Recognition Learning Function (Speaker Enrollment) The voice recognition learning function enables voice recognition appropriate to the characteristics of the user's voice. If the recognition of the voice input commands to the system is not adequate, this function can largely improve the system's voice recognition of the user.
Page 309 7. The voice guidance reads out the voice input command number (refer to the voice input command list for voice recognition learning). (Ex. Please read phrase 1 ) 8. Say: [Beep] 0123456789 (Say the voice input command for voice recognition learning (1 to 8) according to the voice guidance.) 9.
Page 310 Interior Comfort Bluetooth Hands-Free When Bluetooth Hands- Free Cannot be Used Bluetooth Hands-Free cannot be used under the following conditions: The device is outside of the communication area. The device has a malfunction. The device is not connected to the hands-free unit equipped on the vehicle.
Page 311 Mazda Bluetooth Hands- Free Customer Service For toll-free Bluetooth Hands-Free customer service call 800-430-0153 or go to www.MazdaUSA.com/bluetooth for assistance. Interior Comfort Bluetooth Hands-Free 6-93...
Page 312 Interior Comfort Interior Equipment Sunvisors When you need a sunvisor, lower it for use in front or swing it to the side. Sunvisor qVanity Mirrors To use the vanity mirror, lower the sunvisor. If your vehicle is equipped with a vanity mirror light, it will illuminate when you open the cover.
Page 313 qOverhead Lights Front Rear Switch Overhead Lights Position Light off Light is on when any door is open Light is on or off when the illuminated entry system is on Light on Interior Equipment qMap Lights The map lights are switched on or off by pressing the switches.
Page 314 Interior Comfort Interior Equipment Without multi information display Ambient temperature display With multi information display Clock adjustment buttons qInformation Display Functions The information display has the following functions: í Clock Ambient Temperature Display (Outside Temperature Display) Climate Control Display Audio Display Bluetooth Hands-Free Display í...
Page 315 í qClock The time is displayed when the ignition is switched to ACC or ON. Time setting 1. Turn the ignition switch to the ACC or ON position. 2. Adjust the time using the time setting buttons ( , The hours advance while the time setting button ( ) is pressed.
Page 316 Interior Comfort Interior Equipment Multi Information Display Without navigation system Steering switch Steering Switch Left switch Navi switch í 6-98 Some models. í With navigation system Clock adjustment buttons Enter (up/down) switch Right switch INFO switch BACK switch...
Page 317 Switch Enter (up/down) switch Used to select a menu and change numbers. Select up or down and press enter. Right switch/Left Used to select digits when setting numbers. switch Navi switch Press to switch the system to the navigation system screen. (With navigation sys- tem) BACK switch...
Page 318 Interior Comfort Interior Equipment qClock The time is displayed when the ignition is switched to ACC or ON. Time setting Refer to Clock on page 6-97. Time resetting Refer to Clock on page 6-97. With navigation system Time zone switching 1.
Page 319 1. Switch the ignition ON. 2. Press the INFO switch until the trip computer screen is displayed. If you have any problems with your trip computer, consult an Authorized Mazda Dealer. Average fuel economy This mode displays the average fuel...
Page 320 Interior Comfort Interior Equipment The current fuel economy will be calculated every 2 seconds. When you've slowed to about 5 km/h (3 mph), - - -L/100 km (- - -mpg) will be displayed. Distance-to-empty This mode displays the approximate distance you can travel on the remaining fuel based on the fuel economy.
Page 321 3. Select the item you want to turn on (TIRE ROTATION or SERVICE DUE) by pressing the Enter (up/down) switch up or down, and then press the Enter (up/down) switch. 4. Press the Enter (up/down) switch. 5. Select SET and press the Enter (up/ down) switch.
Page 322 Interior Comfort Interior Equipment Message display When the remaining days or the distance approaches 0, a message is displayed for 5 seconds each time the ignition is switched to ACC or ON. NOTE If the Enter (up/down) switch is pressed while a message is displayed, it will no longer be displayed the next time the engine is started.
Page 323 Display period Item TIRE ROTATION When remaining distance is less than 500 km (300 mile) SERVICE DUE When remaining distance is less than 500 km (300 mile), or remaining days are less than 15 (which ever comes first) Message display Item TIRE ROTATION Remaining distance:...
Page 324 Interior Comfort Interior Equipment 5. Select SET and press the Enter (up/ down) switch. NOTE If the SERVICE DUE item has been set, both the days and distance can be selected. Because the tire rotation item can only be set according to distance, the screen for setting distance is displayed when SET is selected.
Page 325 3. Select the item you want to turn off (TIRE ROTATION or SERVICE DUE) by pressing the Enter (up/down) switch up or down, and then press the Enter (up/down) switch. 4. Select OFF and press the Enter (up/ down) switch. qWarning Indicator The following warning indicators are displayed according to necessity.
Page 326 Authorized Mazda Dealer. If separate buzzer volume settings have been done at an Authorized Mazda Dealer, you will be unable to change the settings. Resetting the data for the trip computer average fuel economy and the average vehicle speed 1.
Page 327 qRear The rear cup holder is on the rear center armrest. Interior Equipment Bottle Holder Bottle holders are on the inside of the doors. Bottle holder CAUTION Do not use the bottle holders for containers without caps. The contents may spill when the door is opened or closed.
Page 328 Interior Comfort Interior Equipment Storage Compartments WARNING Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving. CAUTION Do not leave lighters or eyeglasses in the storage boxes while parked under...
Page 329 í Storage tray The storage tray can be installed to the left/right side of the center console. Storage tray í Using the armrest CAUTION When sliding the armrest, be careful not to hit a drink cup placed in a cup holder and spill its contents.
Page 330 Interior Comfort Interior Equipment qShopping Bag Hook The shopping bag hook can be used for hanging shopping bags. CAUTION Do not hang excessive weight on the shopping bag hook as it could be damaged. Shopping bag hook (tensile strength: 3 kg (6.6 lb)) qRear Coat Hooks WARNING...
Page 331 Accessory Sockets Only use genuine Mazda accessories or the equivalent requiring no greater than 120 W (DC 12 V, 10 A). Front The ignition switch must be in the ACC or ON position. To use, press the cover and open it.
Page 332 Ø Do not use accessories that require more than 120 W (DC 12 V, 10 A). Ø Do not use accessories that are not genuine Mazda accessories or the equivalent. Ø Close the cover when the accessory socket is not in use to prevent foreign objects and liquids from getting into the accessory socket.
Page 333: In Case Of An Emergency
In Case of an Emergency Helpful information on what to do in an emergency. Parking in an Emergency ... 7-2 Parking in an Emergency ... 7-2 Flat Tire ... 7-3 Spare Tire and Tool Storage ... 7-3 Changing a Flat Tire ... 7-9 Overheating ...
Page 334: Parking In An Emergency
In Case of an Emergency Parking in an Emergency Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.
Page 335: Flat Tire
In Case of an Emergency Flat Tire Spare Tire and Tool Storage Spare tire and tools are stored in the locations illustrated in the diagram. 4 Door Tiedown eyelet Spare tire Jack Lug wrench Jack handle Bolt for flat tire...
Page 336 In Case of an Emergency Flat Tire 5 Door Jack handle (Type A) (Type B) Jack handle Jack Jack Tiedown eyelet Spare tire Lug wrench Bolt for flat tire Tiedown eyelet Spare tire Lug wrench Bolt for flat tire...
Page 337 qJack To remove the jack (4 Door) 1. Remove the cover. 2. Turn the wing bolt and jack screw counterclockwise. (5 Door) 1. Turn the knob and remove the cover. 2. Turn the wing bolt and jack screw counterclockwise. Jack screw Wing bolt In Case of an Emergency Flat Tire...
Page 338 Make sure the jack screw is sufficiently tightened. qSpare Tire Your Mazda has a temporary spare tire. The temporary spare tire is lighter and smaller than a conventional tire, and is designed only for emergency use and should be used only for VERY short periods.
Page 339 NOTE (With Tire Pressure Monitoring System) A tire pressure sensor is not installed to the temporary spare tire. The warning light will flash continuously while the temporary spare tire is being used (page 5-30). To remove the spare tire (4 Door) 1.
Page 340 In Case of an Emergency Flat Tire For vehicles not equipped with a sub- (With sub-woofer) woofer, loosen the hold-down bolt and remove the spare tire. Tire hold-down bolt Sub-woofer To secure the spare tire Perform the removal procedure in reverse. Secure the spare tire using the hold-down bolt and tire clamp in the correct position as illustrated.
Page 341: Changing A Flat Tire
CAUTION (With Tire Pressure Monitoring System) The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors. Do not use non-genuine wheels, otherwise it may not be possible to install the tire pressure sensors.
Page 342 In Case of an Emergency Flat Tire qRemoving a Flat Tire 1. If your vehicle is equipped with a wheel cover, pry off the wheel cover with the beveled end of the lug wrench. NOTE Force the end of the lug wrench firmly between wheel and cover, or removal will be difficult.
Page 343 Before removing the lug nuts, make sure your Mazda is firmly in position and that it cannot slip or move. 6. Remove the lug nuts by turning them counterclockwise;...
Page 344 If you lose this key, consult an Authorized Mazda Dealer or use the lock manufacturer's order form, which is with the registration card.
Page 345 Because the wheel studs and lug nuts on your Mazda have metric threads, using a non-metric nut is dangerous. On a metric stud, it would not secure the wheel and would damage the stud, which could cause the wheel to slip off and cause an accident.
Page 346 In Case of an Emergency Flat Tire (With sub-woofer) Bolt for flat tire Sub-woofer 6. Remove the tire blocks and store the tools, jack, and damaged tire. 7. Check the inflation pressure. Refer to the specification charts on page 10-8. 8.
Page 347: Overheating
If the cooling fan does not operate while the engine is running, the engine temperature will increase. Stop the engine and call an Authorized Mazda Dealer. 6. Make sure the cooling fan is operating, then turn off the engine after the temperature has decreased.
Page 348 Carefully add coolant as required (page 8-20). CAUTION If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an Authorized Mazda Dealer. 7-16...
Page 349: Emergency Starting
4. If the engine fails to start, crank it without depressing the accelerator. In Case of an Emergency Emergency Starting If the engine still does not start using the above procedure, have your vehicle inspected by an Authorized Mazda Dealer. 7-17...
Page 350: Jump-Starting
In Case of an Emergency Emergency Starting Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. WARNING Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 351 Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries. Do not jump-start a frozen battery or one with a low fluid level: Jump-starting a frozen battery or one with a low fluid level is dangerous.
Page 352 In Case of an Emergency Emergency Starting 1. Remove the battery cover from its front side. Battery cover 2. Make sure the booster battery is 12 V and that its negative terminal is grounded. 3. If the booster battery is in another vehicle, don't allow both vehicles to touch.
Page 353: Push-Starting
Push-Starting Do not push-start your Mazda. WARNING Never tow a vehicle to start it: Towing a vehicle to start it is dangerous. The vehicle being towed could surge forward when its engine starts, causing the two vehicles to collide. The occupants could be injured.
Page 354: Emergency Towing
In Case of an Emergency Emergency Towing Towing Description We recommend that towing be done only by an Authorized Mazda Dealer or a commercial tow-truck service. Proper lifting and towing are necessary to prevent damage to the vehicle. Government and local laws must be followed.
Page 355: Tiedown Hook
CAUTION Do not use the hooks under the rear bumper for towing and tying down, as they cannot hold the load and it will damage the bumper. Hooks In Case of an Emergency Emergency Towing Tiedown Hook CAUTION Don't use the tiedown hook under the rear for towing.
Page 356 In Case of an Emergency Emergency Towing Type B CAUTION The cap cannot be completely removed. Do not use excessive force as it may damage the cap or scratch the painted bumper surface. 3. Securely install the tiedown eyelet using the lug wrench. Lug wrench 7-24 4.
Page 357: Recreational Towing
Recreational Towing An example of recreational towing is towing your vehicle behind a motorhome. The transaxle is not designed for towing this vehicle on all 4 wheels. When doing recreational towing refer to Towing Description (page 7-22) and Tiedown Hook (page 7-23) and carefully follow the instructions.
Page 358 7-26...
Page 359: Maintenance And Care
Maintenance and Care How to keep your Mazda in top condition. Introduction ... 8-2 Introduction ... 8-2 Scheduled Maintenance ... 8-3 Scheduled Maintenance (USA, Canada, and Puerto Rico) ... 8-3 Scheduled Maintenance (Mexico) ... 8-8 Owner Maintenance ... 8-15 Owner Maintenance Schedule ... 8-15 Owner Maintenance Precautions ...
Page 360: Introduction
Claims against the warranty resulting from lack of maintenance, as opposed to defective materials or authorized Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance.But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts.
Page 361: Scheduled Maintenance
Scheduled Maintenance (USA, Canada, and Puerto Rico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used Driving on rough or muddy roads Extended periods of idling or low-speed operation Driving for long periods in cold temperatures or extremely humid climates...
Page 362: Scheduled Maintenance (Mexico)
Maintenance and Care Scheduled Maintenance qSchedule 1 Maintenance Interval ENGINE Engine valve clearance Drive belts Engine oil Engine oil filter COOLING SYSTEM Engine coolant FUEL SYSTEM Air filter Fuel lines and hoses Hoses and tubes for emission IGNITION SYSTEM Spark plugs CHASSIS and BODY Brake lines, hoses and connections Disc brakes...
Page 363 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 364 Maintenance and Care Scheduled Maintenance qSchedule 2 Maintenance Interval ENGINE Engine valve clearance Drive belts Engine oil Engine oil filter COOLING SYSTEM Engine coolant Engine coolant level FUEL SYSTEM Air filter Fuel lines and hoses Hoses and tubes for emission IGNITION SYSTEM Spark plugs ELECTRICAL SYSTEM...
Page 365 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 366 Maintenance and Care Scheduled Maintenance Scheduled Maintenance (Mexico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used Driving on rough or muddy roads Extended periods of idling or low-speed operation Driving for long periods in cold temperatures or extremely humid climates...
Page 367 qSchedule 1 Maintenance Interval ENGINE Engine valve clearance Drive belts Engine oil Engine oil filter COOLING SYSTEM Cooling system Engine coolant FUEL SYSTEM Air filter Fuel lines and hoses Hoses and tubes for emission Fuel filter IGNITION SYSTEM Spark plugs CHASSIS and BODY Brake lines, hoses and connections Brake fluid level...
Page 368 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 369 qSchedule 2 Maintenance Interval ENGINE Engine valve clearance Drive belts Engine oil Engine oil filter COOLING SYSTEM Cooling system Engine coolant Engine coolant level FUEL SYSTEM Air filter Fuel lines and hoses Hoses and tubes for emission Fuel filter IGNITION SYSTEM Spark plugs ELECTRICAL SYSTEM Function of all lights...
Page 370 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 371 (Cont.) Maintenance Interval ENGINE Engine valve clearance Drive belts Engine oil Engine oil filter COOLING SYSTEM Cooling system Engine coolant Engine coolant level FUEL SYSTEM Air filter Fuel lines and hoses Hoses and tubes for emission Fuel filter IGNITION SYSTEM Spark plugs ELECTRICAL SYSTEM Function of all lights...
Page 372 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 373: Owner Maintenance
The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.
Page 374: Owner Maintenance Precautions
Improper owner maintenance during the warranty period may affect warranty coverage. For details, read the separate Mazda Warranty statement provided with the vehicle. If you're unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.
Page 375: Engine Compartment Overview
Maintenance and Care Owner Maintenance Engine Compartment Overview Engine coolant reservoir Brake/Clutch fluid reservoir Fuse block Engine oil-filler cap Battery Engine oil dipstick Power steering fluid reservoir Automatic transaxle fluid-level dipstick (Only for automatic transaxle) Windshield washer fluid reservoir 8-17...
Page 376: Engine Oil
Maintenance and Care Owner Maintenance Engine Oil NOTE Changing the engine oil should be done by an Authorized Mazda Dealer. qRecommended Oil Use SAE 5W-20 engine oil. Oil container labels provide important information. A chief contribution this type of oil makes...
Page 377 The quality designation SM, or ILSAC must be on the label. –30 –10 –20 –20 5W-20 qInspecting Engine Oil Level 1. Be sure the vehicle is on a level surface. 2. Warm up the engine to normal operating temperature. 3. Turn it off and wait at least 5 minutes for the oil to return to the oil pan.
Page 378: Engine Coolant
NOTE Changing the coolant should be done by an Authorized Mazda Dealer. 8-20 Inspect the antifreeze protection and coolant level in the coolant reservoir at least once a year at the beginning of the...
Page 379 (page 8-3). If the coolant reservoir is empty or new coolant is required frequently, consult an Authorized Mazda Dealer. 8-21...
Page 380: Brake/Clutch Fluid
Ø Using nonspecified brake and clutch fluids (page 10-4) will damage the systems. Mixing different fluids will also damage them. If the brake/clutch system frequently requires new fluid, consult an Authorized Mazda Dealer.
Page 381: Power Steering Fluid
The level must be kept between MIN and MAX. Visually examine the lines and hoses for leaks and damage. If new fluid is required frequently, consult an Authorized Mazda Dealer. Maintenance and Care Owner Maintenance Automatic Transaxle Fluid í (ATF)
Page 382 Maintenance and Care Owner Maintenance 4. While the engine is still idling, pull out the dipstick and wipe it clean, and then put it back. 5. Check the ATF level. If there is no ATF adhering 5 mm from the end of the dipstick, add ATF.
Page 383: Washer Fluid
Washer Fluid qInspecting Washer Fluid Level WARNING Use only windshield washer fluid or plain water in the reservoir: Using radiator antifreeze as washer fluid is dangerous. If sprayed on the windshield, it will dirty the windshield, affect your visibility, and could result in an accident.
Page 384: Body Lubrication
Be careful not to pinch hands or fingers as it may cause injury, or damage the wipers. When washing or servicing your Mazda, make sure the wiper lever is in the OFF position. Contamination of either the windshield or the blades with foreign matter can reduce wiper effectiveness.
Page 385 qReplacing Windshield Wiper Blades When the wipers no longer clean well, the blades are probably worn or cracked. Replace them. CAUTION To prevent damage to the wiper arms and other components, don't try to sweep the wiper arm by hand. 1.
Page 386 Maintenance and Care Owner Maintenance CAUTION Ø Don't bend or discard the stiffener. You need to use them again. Ø If the metal stiffeners are switched, the blade's wiping efficiency could be reduced. So don't use the driver's side metal stiffener on the passenger's side, or vice versa.
Page 387 3. Pull down the blade rubber and slide it out of the blade holder. 4. Remove the metal stiffeners from each blade rubber and install them in the new blade. CAUTION Don't bend or discard the stiffeners. You need to use them again. Maintenance and Care Owner Maintenance 5.
Page 388: Battery
Maintenance and Care Owner Maintenance WARNING Wash hands after handling the battery and related accessories: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery: Working without eye protection is dangerous.
Page 389 Maintenance and Care Owner Maintenance Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
Page 390 Maintenance and Care Owner Maintenance NOTE Remove the battery cover before performing battery maintenance. Battery cover qBattery Maintenance To get the best service from a battery: Keep it securely mounted. Keep the top clean and dry. Keep terminals and connections clean, tight, and coated with petroleum jelly or terminal grease.
Page 391: Tires
(radial, bias-belted, bias-type) on all four wheels. Using Wrong-Sized Tires: Using any other tire size than what is specified for your Mazda (page 10-8) is dangerous. It could seriously affect ride, handling, ground clearance, tire clearance, and speedometer calibration.
Page 392 Reduced braking, steering, and traction could result in an accident. CAUTION (With Tire Pressure Monitoring System) When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged.
Page 393 NOTE (With Tire Pressure Monitoring System) When tires with steel wire reinforcement in the sidewalls are used, the system may not function correctly even with a genuine wheel. Refer to System Error Activation on page 5-32. Be sure to install the tire pressure sensors whenever tires or wheels are replaced.
Page 394 Ø (With Tire Pressure Monitoring System) Ø When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. Ø The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Page 395: Light Bulbs
Xenon fusion bulb/Adaptable Front Lighting System Overhead light/Map lights (Front) Side turn signal light (LED type) Front turn signal lights/Front side- marker lights/ Adaptable Front Lighting System (AFS) Head lights (Low/High beam) Fog lights Parking lights/ Daytime running lights 4 Door Trunk light Rear side marker lights Brake lights/Taillights...
Page 396 Consult an Authorized Mazda Dealer when the replacement is necessary. Never touch the glass portion of a halogen bulb with your bare hands and...
Page 397 3. Turn the socket and bulb assembly to remove it. Carefully remove the bulb from its socket in the reflector by gently pulling it straight backward out of the socket. 4. Install the new bulb in the reverse order of the removal procedure. Front turn signal lights/Front side- marker lights 1.
Page 398 Maintenance and Care Owner Maintenance 2. Disconnect the electrical connector from the bulb by pressing the tab on the connector with your finger and pulling the connector downward. 3. Turn the socket and bulb assembly to remove it. Carefully remove the bulb from its socket in the reflector by gently pulling it straight backward out of the socket.
Page 399 3. Turn the center section of the plastic retainer counterclockwise and remove the retainers and partially peel back the mudguard. Removal Installation 4. Turn the socket and bulb assembly counterclockwise and remove it. 5. Disconnect the bulb from the socket. 6.
Page 400 Side-turn signal lights With LED bulb Due to the complexity and difficulty of the procedure, the LED bulbs should be replaced by an Authorized Mazda Dealer. NOTE LED bulb replacement is not possible. The rear combination component must be replaced.
Page 401 2. Remove the cover. Left side Right side 3. Turn the socket and bulb assembly counterclockwise and remove it. 4. Disconnect the bulb from the socket. 5. Install the new bulb in the reverse order of removal. Maintenance and Care Owner Maintenance Rear turn signal lights (4 Door)
Page 402 Maintenance and Care Owner Maintenance 2. Remove the cover. Left side Right side 3. Turn the socket and bulb assembly counterclockwise and remove it. 4. Disconnect the bulb from the socket. 5. Install the new bulb in the reverse order of removal.
Page 403 2. Remove the cover. 3. Turn the socket and bulb assembly counterclockwise and remove it. 4. Disconnect the bulb from the socket. 5. Install the new bulb in the reverse order of removal. High-mount brake light (4 Door) 1. Make sure the ignition is switched off, and the headlight switch is off.
Page 404 Maintenance and Care Owner Maintenance 5. Disconnect the bulb from the socket. 6. Install the new bulb in the reverse order of removal. License plate lights 1. Make sure the ignition is switched off, and the headlight switch is off. 2.
Page 405 Vanity mirror lights 3. Install the new bulb in the reverse order of removal. Trunk light (4 Door) 1. Press both sides of the lens cap to remove it. 2. Disconnect the bulb by pulling it out. 3. Install the new bulb in the reverse order of removal.
Page 406: Fuses
If a fuse has blown, the inside element will be melted. If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. qFuse Replacement Replacing the fuses on the vehicle's left side...
Page 407 Normal Do not replace the main fuse by yourself. Have an Authorized Mazda Dealer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse.
Page 408 Maintenance and Care Owner Maintenance qFuse Panel Description Fuse block (Engine compartment) 32 33 34 35 36 37 38 39 DESCRIPTION FAN 2 ENG MAIN BTN 1 A/C MAG H/L HI H/L WASH SUNROOF F.DEF RH F.DEF LH FAN 1 ROOM BTN 2 AT PUMP...
Page 409 DESCRIPTION R.DEF IGKEY 2 IGKEY 1 HORN STOP ENG+B FUEL PUMP SEAT WARM EHPAS ABS IG H/L LO RH H/L LO LH ILLUM TAIL ENG INJ ENG BAR ENG BAR 2 FUSE PROTECTED COMPONENT RATING 30 A Rear window defroster 40 A For protection of various circuits 40 A...
Page 410 Maintenance and Care Owner Maintenance Fuse block (Passenger's side) DESCRIPTION BOSE P SEAT P.WIND D LOCK ESCL HAZARD METER OUTLET R WIPER CIGAR HEATER MIRROR ST SIG í 8-52 Some models. FUSE PROTECTED COMPONENT RATING ® 30 A Bose Sound System-equipped model í...
Page 411 DESCRIPTION AUDIO M.DEF P.WIND F WIPER FUSE PROTECTED COMPONENT RATING 7.5 A Audio system í 7.5 A Mirror defroster 7.5 A Adaptive Front-Lighting System 20 A Engine control system 25 A Power window 25 A Windshield wiper and washer Maintenance and Care Owner Maintenance í...
Page 412: Appearance Care
Prevention It is necessary to have your Mazda washed and waxed to preserve its finish according to the instructions in this section. This should be done as soon as possible.
Page 413 This increases the chance of paint chipping. Chipped paint can lead to rust forming on your Mazda. Before this happens, repair the damage by using Mazda touch-up paint according to the instructions in this section. Failure to repair the affected area could lead to serious rusting and expensive repairs.
Page 414: Exterior Care
Be careful not to pinch hands or fingers as it may cause injury, or damage the wipers. When washing or servicing your Mazda, make sure the wiper lever is in the OFF position. To help protect the finish from rust and...
Page 415 Exposed metal quickly rusts and can lead to major repairs. CAUTION If your Mazda is damaged and needs metal parts repaired or replaced, make sure the body shop applies anti-corrosion materials to all parts, both repaired and new. This will prevent them from rusting.
Page 416 Maintenance and Care Appearance Care CAUTION Don't use steel wool, abrasive cleaners, or strong detergents containing highly alkaline or caustic agents on chrome-plated or anodized aluminum parts. This may result in damage to the protective coating and cause discoloration or paint deterioration.
Page 417: Interior Care
Interior Care qDashboard Precautions Prevent caustic solutions such as perfume and cosmetic oils from contacting the dashboard. They'll damage and discolor it. If these solutions get on the dashboard, wipe them off immediately. CAUTION Do not use glazing agents. Glazing agents contain ingredients which may cause discoloration, wrinkling, cracks and peeling.
Page 418 After cleaning the belts, thoroughly dry the belt webbing and make sure there is no remaining moisture before retracting them. WARNING Have an Authorized Mazda Dealer replace damaged seat belts immediately: Using damaged seat belts is dangerous. In a collision, damaged belts cannot provide adequate protection.
Page 419: Customer Information
Mazda Importer/Distributors ... 9-13 Importer/Distributor ... 9-13 Distributor in Each Area ... 9-13 Warranty ... 9-15 Warranties for Your Mazda ... 9-15 Outside the United States ... 9-16 Outside Canada ... 9-17 Registering Your Vehicle in A Foreign Country (Except United States and Canada) ...
Page 420: Customer Assistance
Answers to many questions, including how to locate or contact a local Mazda dealership in the U.S., can be found here. E-mail: click on Contact Us located on the Inside Mazda tab, or at the bottom of the page at www.mazdaUSA.com...
Page 421 Mazda North American Operations realizes that mutual agreement on some issues may not be possible. As a final step to ensure that your concerns are being fairly considered, Mazda North American Operations has agreed to participate in a dispute settlement program administered by the Better Business Bureau (BBB) system, at no cost to you the consumer.
Page 422 Mazda or one of our dealers, and a statement of the relief you are seeking. 5. BBB AUTO LINE staff may try to help resolve your dispute through mediation. If...
Page 423 AND the nonconformity has been subject to repair two or more times by Mazda or its agents AND the buyer or lessee has directly notified Mazda of the need for the repair of the nonconformity; OR...
Page 424 11. If you accept the arbitrator's decision, Mazda will be bound by the decision, and will comply with the decision within a reasonable time not to exceed 30 days after we receive notice of your acceptance of the decision.
Page 425 Your complete and permanent satisfaction is of primary concern to Mazda. All Authorized Mazda Dealers have both the knowledge and tools to keep your Mazda in top condition. In our experience, any questions, problems, or complaints regarding the operation of your Mazda or any other general service transactions are most effectively resolved by your dealer.
Page 426 If a specific item of concern arises, where a solution cannot be reached between an owner, Mazda, and/or one of it's dealers (that all parties cannot agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 427 Provincial Administrators may be reached locally as listed below: Province/Territory British Columbia & Yukon Territories Alberta & Northwest Territories Saskatchewan Atlantic Canada qRegional Offices REGIONAL OFFICES MAZDA CANADA INC. WESTERN REGION 8171 ACKROYD ROAD SUITE 2000 RICHMOND B.C. V6X 3K1 (604) 303-5670 MAZDA CANADA INC.
Page 428 1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 429 1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 430 Customer Information Customer Assistance In order to serve you efficiently and effectively, please help us by providing the following information: 1. Your name, address, and telephone number 2. Year and model of vehicle 3. Vehicle Identification Number (17 digits, noted on your registration or title or located on the upper driver's side corner of the dash) 4.
Page 431 55 Vogell Road, Richmond Hill, Ontario, L4B 3K5 Canada TEL: 1 (800) 263-4680 (in Canada) (905) 787-7000 (outside Canada) qPUERTO RICO/U.S. Virgin Island Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936-2722 TEL: (787) 641-9300...
Page 432 Customer Information Mazda Importer/Distributors Triple J Saipan, Inc. (d.b.a. Triple J Motors) P.O. Box 500487 Saipan, MP 96950-0487 TEL: (670) 234-7133/3051 qAMERICAN SAMOA Polynesia Motors, Inc. P.O. Box 1120, Pago Pago, American Samoa 96799 TEL: (684) 699-9347 9-14...
Page 433 Federal Emission Control Warranty (U.S.A. only) Emission Defect Warranty Emission Performance Warranty California Emission Control Warranty (U.S.A. only) Emission Control Warranty (Canada only) Replacement Parts and Accessories Limited Warranty Tire Warranty NOTE Detailed warranty information is provided with your Mazda. Customer Information Warranty 9-15...
Page 434 We strongly recommend that you NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety requirements (CMVSS).
Page 435 We strongly recommend that you NOT take your Mazda outside Canada. However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with specific vehicle modifications to comply with the United States Federal Motor Vehicle Safety Standards (FMVSS).
Page 436 Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 437 Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle's performance or safety systems;...
Page 438: Cell Phones
Customer Information Cell Phones WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your State or Province: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver's hands.
Page 439 Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality Grading System (UTQGS) This information relates to the tire grading system developed by the U.S. National Highway Traffic Safety Administration for grading tires by tread wear, traction, and temperature performance. qTread Wear The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 440 These grades will be added to the sidewalls of passenger vehicle tires over the next several years according to a schedule established by the NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicles may vary with respect to grade.
Page 441 Customer Information Tire Information (U.S.A.) Tire Labeling Federal law requires tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a tire identification number for safety standard certification and in case of a recall.
Page 442 Customer Information Tire Information (U.S.A.) 11. Tread wear, traction and temperature grades 12. Max. permissible inflation pressure 13. SAFETY WARNING P215/65R15 95H is an example of a tire size and load index rating. Here is an explanation of the various components of that tire size and load index rating. Note that the tire size and load index rating may be different from the example.
Page 443 H is the speed rating. The speed rating denotes the maximum speed for which the use of the tire is rated. Letter Rating * For tires with a maximum speed capability over 149 mph, tire manufacturers sometimes use the letters ZR. For tires with a maximum speed capability over 186 mph, tire manufacturers always use the letters ZR.
Page 444 Customer Information Tire Information (U.S.A.) Tread Wear, Traction and Temperature Grades Tread wear: The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 445 Customer Information Tire Information (U.S.A.) qInformation on Temporary Tires Please refer to the diagram below. 1. Temporary tires 2. Nominal width of tire in millimeters 3. Ratio of height to width (aspect ratio) 4. Diagonal 5. Rim diameter code 6. Load index&speed symbol T115/70D 16 90M is an example of a tire size and load index rating.
Page 446 Customer Information Tire Information (U.S.A.) 70 is the aspect ratio. This two-digit number indicates the tire's ratio of height to width. D is the tire construction symbol. D indicates diagonal ply construction . 16 is the wheel rim diameter in inches. 90 is the Load Index.
Page 447 Customer Information Tire Information (U.S.A.) Location of the Tire Label (Placard) You will find the tire label containing tire inflation pressure by tire size and other important information on the driver's side B-pillar or on the edge of the driver's door frame. SAMPLE qRecommended Tire Inflation Pressure On the tire label you will find the recommended tire inflation pressure in both kPa and psi...
Page 448 Customer Information Tire Information (U.S.A.) WARNING Always check the tire inflation pressures on a regular basis according to the recommended tire inflation pressure on the tire label and in conjunction with the information in this owner's manual: Driving your vehicle with under-inflated tires is dangerous. Under-inflation is the most common cause of failures in any kind of tire and may result in severe cracking, tread separation or “blowout”, with unexpected loss of vehicle control and increased risk of injury.
Page 449 Customer Information Tire Information (U.S.A.) qGlossary of Terms Tire Placard: A label indicating the OE tire sizes, recommended inflation pressure, and the maximum weight the vehicle can carry. Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size, and date of manufacture.
Page 450: Specifications
Customer Information Tire Information (U.S.A.) Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Here are some important maintenance points: qTire Inflation Pressure Inspect all tire pressure monthly (including the spare) when the tires are cold. Maintain recommended pressures for the best ride, top handling, and minimum tire wear. Use the pressures specified on the vehicle tire information placard or tire label for optimum service.
Page 451 CAUTION Rotate unidirectional tires and radial tires that have an asymmetrical tread pattern or studs only from front to rear, not from side to side. Tire performance will be weakened if rotated from side to side. (With limited-slip differential) Don't use the following: Ø...
Page 452 Customer Information Tire Information (U.S.A.) qSafety Practices The way you drive has a great deal to do with your tire mileage and safety. So cultivate good driving habits for your own benefit. Observe posted speed limits Avoid fast starts, stops and turns Avoid potholes and objects on the road Do no run over curbs or hit the tire against the curb when parking CAUTION...
Page 453 WARNING Do not tow a trailer with this vehicle: Towing a trailer with this vehicle is dangerous because it has not been designed to tow a trailer and doing so will affect the drive system which could result in vehicle damage.
Page 454 Customer Information Tire Information (U.S.A.) Base Curb Weight is the weight of the vehicle including a full tank of fuel and all standard equipment. It does not include passengers, cargo, or optional equipment. Vehicle Curb Weight is the weight of your new vehicle when you picked it up from your dealer plus any aftermarket equipment.
Page 455 Customer Information Tire Information (U.S.A.) SAMPLE CARGO Cargo Weight includes all weight added to the Base Curb Weight, including cargo and optional equipment. The cargo weight limit decreases depending on the number of vehicle occupants. The cargo weight limit can be calculated by subtracting the total weight of the vehicle occupants from the combination weight of occupants and cargo should never exceed value on the tire label.
Page 456 Customer Information Tire Information (U.S.A.) Examples: Based on a single occupant weight of 68 kg (150 lbs), and a value of 385 kg (849 lbs) for the combination weight of occupants and cargo should never exceed : The cargo weight limit with one occupant is 385 kg (849 lbs) _ 68 kg (150 lbs) = 317 kg (699 lbs) The cargo weight limit with two occupants is 385 kg (849 lbs) _ (68 ×...
Page 457 SAMPLE WARNING Exceeding Axle Weight Rating Limits: Exceeding the Safety Certification Label axle weight rating limits is dangerous and could result in death or serious injury as a result of substandard vehicle handling, performance, engine, transmission and/or structural damage, serious damage to the vehicle, or loss of control.
Page 458 Customer Information Tire Information (U.S.A.) GCW (Gross Combination Weight) is the weight of the loaded vehicle (GVW). GCWR (Gross Combination Weight Rating) is the maximum allowable weight of the vehicle - including all cargo and passengers - that the vehicle can handle without risking damage.
Page 459 Steps for Determining the Correct Load Limit: Steps for Determining Correct Load Limit: (1) Locate the statement The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs on your vehicle's placard. (2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.
Page 460: Reporting Safety Defects
7755 Irvine Center Drive Irvine, California 92618-2922 P.O. Box 19734 Irvine, CA 92623-9734 Customer Assistance Center or toll free at 1 (800) 222-5500 If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown (page 9-13) in this booklet. 9-42...
Page 461 Customer Information Reporting Safety Defects Reporting Safety Defects (Canada) Canadian customers who wish to report a safety-related defect to Transport Canada, Defect Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330 Sparks Street, Ottawa ON K1A 0N5.
Page 462: Service Publications
Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair. When requesting any of our publications through an Authorized Mazda Dealer, refer to the chart below. If they don't have what you need in stock, they can order it for you.
Page 463 Customer Information Service Publications qNAVIGATION SYSTEM OWNER'S MANUAL: This booklet contains information regarding the proper operation and use of the navigation system. This is not a technician's manual. 9-45...
Page 464 9-46...
Page 465 Specifications Technical information about your Mazda. Identification Numbers ... 10-2 Vehicle Information Labels ... 10-2 Specifications ... 10-4 Specifications ... 10-4 Personalization Features ... 10-9 Personalization Features ... 10-9 10-1...
Page 466: Identification Numbers
Identification Numbers Vehicle Information Labels qVehicle Identification Number The vehicle identification number legally identifies your vehicle. The number is on a plate attached to the cowl panel located on the left corner of the dashboard. This plate can easily be seen through the windshield.
Page 467 Identification Numbers qEngine Number Forward 10-3...
Page 468: Specifications
Specifications qEngine Item Type Bore × Stroke Displacement Compression ratio qElectrical System Item 2.0-liter engine Battery 2.5-liter engine Spark-plug number Spark-plug gap *1 ex factory NOTE When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the iridium alloy and platinum tips could be damaged.
Page 469 qCapacities (Approximate Quantities) Item 2.0-liter engine Engine oil 2.5-liter engine Coolant 5-speed transaxle Manual transaxle 6-speed transaxle Automatic transaxle fluid 2.0-liter engine Fuel tank 2.5-liter engine Check oil and fluid levels with dipsticks or reservoir gauges. qDimensions 4 Door Item STANDARD TYPE Overall length SPORTY TYPE...
Page 470 Specifications 5 Door Item STANDARD TYPE (Canada) Overall length SPORTY TYPE Overall width Overall height 16 inch Front tread 17 inch 16 inch Rear tread 17 inch Wheelbase qWeights 4 Door 2.0-liter engine Item GVWR (Gross Vehicle Weight Rating) GAWR (Gross Axle Weight Rating) 2.5-liter engine Item GVWR (Gross Vehicle Weight Rating)
Page 471 qLight Bulbs Exterior light Light bulb Halogen Headlights Xenon fusion bulb High/Low beam Daytime running lights (Canada) Halogen/Xenon fusion bulb Front turn signal (With daytime running lights) lights/Front side-marker Xenon fusion bulb lights/Parking (Without daytime lights running lights) í Fog lights Bulb type Side turn signal lights...
Page 472 NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer. Check the tire pressure label for tire size and inflation pressure.
Page 473: Personalization Features
The following Personalization Features are available. These settings can only be changed by an Authorized Mazda Dealer. Setting The headlight illumination on/off timing based Auto headlight on/off on the surrounding lightness/darkness can be changed. The beep volume level can be changed.
Page 474 Personalization Features Setting The vehicle-speed-response auto lock function can be deactivated. Locking/unlocking of the doors can be set in Power door locks conjunction with the selector lever position. The function for unlocking the doors simultaneously when the ignition is switched off can be changed.
Page 475 Setting The function to automatically lock doors when leaving the vehicle while carrying the key can be activated. The advanced key's remaining battery level warning light in the instrument cluster can be deactivated. The volume of the answer-back beep during keyless entry system operation can be adjusted.
Page 476 10-12...
Page 477: Index
Index 11-1...
Page 478 Basic Bluetooth Hands-Free Operation ... 6-76 Convenient Use of the Hands-Free System ... 6-80 Hands-Free Setting ... 6-86 Mazda Bluetooth Hands-Free Customer Service ... 6-93 Safety Certification ... 6-92 When Bluetooth Hands-Free Cannot be Used ... 6-92 Body Lubrication ... 8-26 Bottle Holder ...
Page 479 Capacities ... 10-5 Carbon Monoxide ... 4-4 Cargo Securing Loops ... 6-111 Catalytic Converter ... 4-3 Cell Phones ... 9-20 Center Console ... 6-110 Child Restraint Child restraint precautions ... 2-28 Installing child-restraint systems ... 2-32 LATCH child-restraint systems ... 2-39 Child Safety Locks for Rear Doors ...
Page 480 Index Flasher Hazard warning ... 5-68 Headlights ... 5-56 Flat Tire ... 7-3 Changing ... 7-9 Spare tire and tool storage ... 7-3 Fluids Classification ... 10-4 Owner maintenance ... 8-15 Fog Lights ... 5-61 Foot Brake ... 5-5 Front Seats (Electrically Operated Seats) ...
Page 481 Interior Lights ... 6-94 Jump-Starting ... 7-18 Keyless Entry System ... 3-25 Keys ... 3-24 Label Information ... 10-2 Lane-Change Signals ... 5-60 Liftgate ... 3-34 Luggage compartment ... 3-36 Light Bulbs Replacement ... 8-37 Specifications ... 10-7 Lighting Control ... 5-56 Lubricant Quality ...
Page 482 Index Push-Starting ... 7-21 Rear Coat Hooks ... 6-112 Rear Door Child Safety Locks ... 3-34 Rear Seat ... 2-9 Rear Window Defroster ... 5-66 Rear Window Washer ... 5-66 Rear Window Wiper ... 5-66 Rearview Mirror ... 3-59 Recreational Towing ... 7-25 Registering Your Vehicle in A Foreign Country ...
Page 483 Tires Flat Tire ... 7-3 Inflation pressure ... 8-33 Replacement ... 8-34 Rotation ... 8-34 Snow tires ... 4-9 Spare tire and tool storage ... 7-3 Specifications ... 10-8 Tire chains ... 4-9 Uniform tire quality grading system (UTQGS) ... 9-21 Tool ...
Page 484 11-8...
