Summary of Contents for Mazda 2008 RX-8

Page 3: A Word To Mazda Owners
Mazda product. Important Notes About This Manual Keep this manual in the glove box as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 4: How To Use This Manual
Illustrations complement the words of the manual to best explain how to enjoy your Mazda. By reading your manual, you can find out about the features, important safety information, and driving under various road conditions.
Page 5: Table Of Contents
Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts.
Page 7: Your Vehicle At A Glance
Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Dashboard and Interior Overview ... 1-2 Exterior Overview ... 1-4...
Page 8: Dashboard And Interior Overview
Your Vehicle at a Glance Dashboard and Interior Overview Refer to Navigation System at the separate manual (if equipped). The equipment and installation position varies by vehicle...
Page 9 Your Vehicle at a Glance Dashboard and Interior Overview Power door lock switch ... page 3-28 Outside mirror switch ... page 3-48 Dashboard illumination ... page 5-37 DSC OFF switch ... page 5-24 Lighting control/Turn signals ... page 5-55 Audio control switch ... page 6-40 Instrument cluster ...
Page 10: Exterior Overview
Your Vehicle at a Glance Exterior Overview The equipment and installation position varies by vehicle...
Page 11 Your Vehicle at a Glance Exterior Overview Trunk lid ... page 3-31 Rear window defroster ... page 5-60 Antenna ... page 6-10 Power windows ... page 3-34 Outside mirror ... page 3-48 Tires ... page 8-22 Light bulbs ... page 8-27 Hood ...
Page 13: Essential Safety Equipment
Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats ... 2-2 Front Seats (Manually Operated Seats) ... 2-2 Front Seats (Electrically Operated Seats) ... 2-5 Rear Seat ... 2-8 Seat Belt Systems ... 2-9 Seat Belt Precautions ...
Page 14: Seats
Such modifications could damage the supplemental restraint system and result in serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Do not drive with damaged front seats: Driving with damaged front seats is dangerous.
Page 15 qSeat Recline WARNING Do not drive with the seats reclined: Sitting in a reclined position while the vehicle is moving is dangerous because you don't get the full protection from seat belts. During sudden braking or a collision, you can slide under the lap belt and suffer serious internal injuries.
Page 16 Essential Safety Equipment Seats CAUTION When returning a rear-reclined seatback to its upright position, make sure you hold onto the seatback with your other hand while operating the lever. If the seatback is not supported, it will flip forward suddenly and could cause injury. qHeight Adjustment (Driver's Seat) By moving the seat lever up or down, the seat bottom height can be adjusted.
Page 17: Front Seats (Electrically Operated Seats)
Such modifications could damage the supplemental restraint system and result in serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Do not drive with damaged front seats: Driving with damaged front seats is dangerous.
Page 18 Essential Safety Equipment Seats qSeat Recline WARNING Do not drive with the seats reclined: Sitting in a reclined position while the vehicle is moving is dangerous because you don't get the full protection from seat belts. During sudden braking or a collision, you can slide under the lap belt and suffer serious internal injuries.
Page 19 Rear of seat bottom Raise or lower the back of the switch to adjust the rear height of the seat bottom. qLumbar Support Adjustment The amount of lumbar support can be adjusted by pressing the switch. To increase the seat firmness, press and hold the front part of the switch to the desired position, then release it.
Page 20: Rear Seat
Essential Safety Equipment Seats qSeat Warmer The front seats are electrically heated. The ignition switch must be in the ON position. Press the switch to turn the seat warmer on or off. When the switch is in the ON position, the indicator light will come on. NOTE The seat temperature is regulated automatically by a thermostat.
Page 21: Seat Belt Systems
Seat belts help to decrease the possibility of severe injury during accidents and sudden stops. Mazda recommends that the driver and all passengers always wear seat belts. All of the seat belt retractors are designed to keep the lap/shoulder belts out of the way when not in use.
Page 22 Always have an Authorized Mazda Dealer inspect the seat belt pretensioners and air bags after any collision. Expended seat belt pretensioners and air bags must be replaced after any collision which caused them to deploy.
Page 23 Essential Safety Equipment Seat Belt Systems qPregnant Women and Persons with Serious Medical Conditions Pregnant women should always wear seat belts. Ask your doctor for specific recommendations. The lap belt should be worn SNUGLY AND AS LOW AS POSSIBLE OVER THE HIPS. The shoulder belt should be worn across your shoulder properly, but never across the stomach area.
Page 24: Location Of Seat Belt
Essential Safety Equipment Seat Belt Systems Location of Seat Belt For rear seat For front seat 2-12...
Page 25: Seat Belt
Seat Belt qFastening the Seat Belt 1. Grasp the tongue. 2. Slowly pull out the lap/shoulder belt. 3. Insert the tongue into the buckle until you hear a click. Buckle WARNING Positioning the Shoulder Portion of the Seat Belt: Improper positioning of the shoulder portion of the seat belt is dangerous.
Page 26: Front Seat Belt Pretensioner And Load Limiting Systems
Even if the pretensioners have not fired, the load limiting function must be checked by an Authorized Mazda Dealer.
Page 27 If the seat belt pretensioners are not replaced, the risk of injury in a collision will increase. Always have an Authorized Mazda Dealer inspect the seat belt pretensioners and air bags after any collision. Expended seat belt pretensioners and air bags must be replaced after any collision which caused them to deploy.
Page 28 ON position. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident.
Page 29: Seat Belt Extender
When ordering an extender, only order one that provides the necessary additional length to fasten the seat belt properly. Please contact your Authorized Mazda Dealer for more information. Essential Safety Equipment Seat Belt Systems...
Page 30: Seat Belt Warning Light/Beep
ON beep sound will not be position. heard. qBelt Minder NOTE The belt minder can be deactivated. Consult an Authorized Mazda Dealer to deactivate and restore the seat belt minder. Result...
Page 31 The belt minder is a supplemental warning to the seat belt warning function. If the driver's seat belt is not fastened when the ignition switch is turned to the ON position, the warning light/beep operates to give you further reminders according to the chart below.
Page 32: Child Restraint
Even if the front passenger air bag is shut off, Mazda strongly recommends that children be properly restrained and child-restraint systems of all kinds are properly secured on the rear seats which are the best place for children.
Page 33 WARNING Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size. If not, the child could be seriously injured or even killed in an accident. Follow the manufacturer's instructions and always keep the child-restraint system buckled down: An unsecured child-restraint system is dangerous.
Page 34 Essential Safety Equipment Child Restraint Do not install a front-facing child-restraint system on the front passenger seat unless it is unavoidable: In a collision, the force of a deploying air bag could cause serious injury or death to the child. If installing a front-facing child-restraint system on the front passenger seat is unavoidable, move the front passenger seat as back as possible.
Page 35 NOTE Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. When using these anchors to secure a child-restraint system, refer to “LATCH Child-Restraint Systems” (page 2-30).
Page 36: Installing Child-Restraint Systems
Some child-restraint systems now come with tethers and therefore must be installed on the seats that take tethers to be effective. In your Mazda, tethered child-restraint systems can only be accommodated in the two positions on the rear seat.
Page 37 3. Push the child-restraint system firmly into the vehicle seat. Be sure the belt retracts as snugly as possible. Clicking from the retractor will be heard during retraction if the system is in the automatic locking mode. If the belt does not lock the seat down tight, repeat this step.
Page 38: For Children
NOTE To check if your front seats have side air bags: Mazda vehicles equipped with side air bag will have a “SRS AIRBAG” tag on the outboard shoulder of the front seats. To check if your vehicle has curtain air...
Page 39 WARNING Always move the front passenger seat as far back as possible if installing a front-facing child-restraint system on it is unavoidable: As your vehicle has front air bags and doubly so if your vehicle has side air bags, a front-facing child- restraint system should be put on the front passenger seat only when it is unavoidable.
Page 40 Essential Safety Equipment Child Restraint 2. Secure the child-restraint system with the lap portion of the lap/shoulder belt. See the manufacturer's instructions on the child-restraint system for belt routing instructions. 3. To get the retractor into the automatic locking mode, pull the shoulder belt portion of the seat belt until the entire length of the belt is out of the retractor.
Page 41 Authorized Mazda Dealer as soon as possible. Essential Safety Equipment Child Restraint 2-29...
Page 42: Latch Child-Restraint Systems
Child Restraint LATCH Child-Restraint Systems Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. Both anchors must be used, otherwise the seat will bounce around and put the child in danger. Most LATCH child-restraint systems must also be used in conjunction with a tether to be effective.
Page 43 qLATCH Child-Restraint System Installation Procedure (Rear Seats) 1. Expand the open seams on the rear of the seat bottom slightly to verify the locations of the LATCH lower anchors. NOTE The markings above the LATCH lower anchors indicate the locations of LATCH lower anchors for the attachment of a child-restraint system.
Page 44 Essential Safety Equipment Child Restraint WARNING Use the tether and tether anchor only for a child-restraint system: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous. This could weaken or damage the tether or tether anchor and result in injury.
Page 45: Srs Air Bags
Supplemental Restraint Systems (SRS) Precautions The front and side supplemental restraint systems (SRS) include up to 6 air bags. Please verify which kinds of air bags are equipped on your vehicle by locating the SRS AIRBAG location indicators. These indicators are visible in the area where the air bags are installed.
Page 46 Essential Safety Equipment SRS Air Bags WARNING Seat belts must be worn in air bag equipped vehicles: Depending only on the air bags for protection during an accident is dangerous. Alone, air bags may not prevent serious injuries. The appropriate air bags can be expected to inflate only in the first collision with frontal, near frontal or side forces that are at least moderate.
Page 47 Sit in the center of the seat and wear seat belts properly: Sitting too close to the side air bag modules or placing hands on them is extremely dangerous. The side air bags inflate with great force and speed directly out of the outboard side of the front seat and expand along the front door on the side the car is hit.
Page 48 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.
Page 49: Supplemental Restraint System Components
Supplemental Restraint System Components The supplemental restraint systems (SRS) have two basic subsystems: The air bag system with inflators and air bags. The electrical system with crash sensors and diagnostic module. The air bags are mounted in the following locations: The steering wheel hub The front passenger dashboard The outboard sides of the front seatbacks...
Page 50 Essential Safety Equipment SRS Air Bags qFront Air Bag System Components (11) (10) (1) Driver seat slide position sensor (page 2-40) (2) Front seats (3) Air bag/front seat belt pretensioner system warning light (page 2-49) (4) Front dual stage inflators and air bags (5) Front air bag sensor (6) Front passenger air bag deactivation indicator light (page 2-40) (7) Front seat belt pretensioner and load limiting systems (page 2-14)
Page 51 Essential Safety Equipment SRS Air Bags qSide and Curtain Air Bag System Components (1) Air bag/front seat belt pretensioner system warning light (page 2-49) (2) Side and curtain inflators and air bags (3) Front seats (4) Side crash sensor (5) Crash sensors and diagnostic module (SAS unit) 2-39...
Page 52: How The Air Bags Work
The front air bags will function only once. After that, the front air bags will not work again and must be replaced. Only an Authorized Mazda Dealer can replace the system components. The front, dual stage air bags control air bag inflation in two energy stages. During an impact of moderate severity the front air bags deploy with lesser energy, whereas during more severe impacts, they deploy with more energy.
Page 53 Front passenger seat weight sensors Your vehicle is equipped with the front passenger seat weight sensors (page 2-27). These sensors are located under both of the front passenger seat rails. These sensors determine the total seated weight on the front passenger seat. The SAS unit is designed to prevent the front passenger front and side air bags and seat belt pretensioner system from deploying if the total seated weight is less than approximately 30 kg (66 lb).
Page 54 ON position and does not illuminate as indicated in the above chart, do not allow a child to sit in the front passenger seat and consult an Authorized Mazda Dealer as soon as possible. The system may not work properly in an accident.
Page 55 WARNING Do not decrease the total seated weight on the front passenger seat: When an adult or large child sits on the front passenger seat, decreasing the total seated weight on the front passenger seat from the total seated weight of approximately 42 kg (93 lb) required for air bag deployment is dangerous.
Page 56 Essential Safety Equipment SRS Air Bags Do not increase the total seated weight on the front passenger seat: When an infant or small child sits on the front passenger seat, increasing the total seated weight on the front passenger seat from the total seated weight of approximately 30 kg (66 lb) is dangerous.
Page 57 The side and curtain air bags will function only once. After that, the side and curtain air bags will not work again and must be replaced. Only an Authorized Mazda Dealer can replace the systems. The side and curtain air bags will deploy only on the side the vehicle receives the force of the impact.
Page 58 Essential Safety Equipment SRS Air Bags qAir Bag Activation/Deactivation NOTE If the front passenger seat weight sensors detect a total seated weight on the front passenger seat is less than approximately 42 kg (93 lb), the front passenger front and side air bags and seat belt pretensioner may not deploy (page 2-40), but the curtain air bags may deploy.
Page 59 Frontal offset impact to the vehicle may not provide the stopping force necessary for air bag deployment. Rear-ending or running under a truck's tail gate may not provide the stopping force necessary for air bag deployment. Non-activation of front air bags Front air bags will not normally inflate in the following cases: Collision from the rear.
Page 60 Essential Safety Equipment SRS Air Bags Side impacts involving trees or poles can cause severe cosmetic damage but may not have enough impact force to activate the side and curtain air bags. Vehicle roll-over may not provide enough side force to deploy the side and curtain air bags.
Page 61 ON position. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident.
Page 62 Unless all safety procedures are followed, injury can result. Ask an Authorized Mazda Dealer how to safely dispose of an air bag or how to scrap an air bag equipped vehicle.
Page 63: Knowing Your Mazda
Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts. Advanced Keyless Entry and Start System ... 3-2 í Advanced Keys Operation Using Advanced Keyless Functions ... 3-7 Operation Using Advanced Key Functions ... 3-13 Advanced Key Suspend Function ...
Page 64: Advanced Keyless Entry And Start System
Knowing Your Mazda Advanced Keyless Entry and Start System The advanced keyless functions (advanced keyless entry and start system) enables the following operations while the advanced key is being carried (page 3-7). Locking/unlocking the doors, and opening the trunk lid, without operating the key.
Page 65 Also write down the code number and keep it in another safe and handy place, but not in the vehicle. If your key is lost, consult your Authorized Mazda Dealer with the code number ready. CAUTION Ø Because the advanced key uses low-intensity radio waves, it may not function correctly under the following conditions: Ø...
Page 66 Battery life is about one year. Replace the battery when the KEY indicator light (green) flashes in the instrument cluster. Refer to Advanced Key Battery Dead Warning on page 3-17. Additional advanced keys can be obtained at an Authorized Mazda Dealer. Up to 6 advanced keys can be used with the advanced keyless functions per vehicle.
Page 67 The system's operational range is reduced. Advanced Keyless Entry and Start System Replacing the battery at an Authorized Mazda Dealer is recommended to prevent damage to the advanced key. If replacing the battery by yourself, follow the instruction below. Replacing the advanced key battery 1.
Page 68 Authorized Mazda Dealer. If your advanced key is lost or stolen, bring all remaining advanced keys to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen advanced key inoperative.
Page 69: Operation Using Advanced Keyless Functions
80 cm (2.6 ft) from the center of the trunk lid. Starting the engine The operational range for starting the engine includes nearly the entire cabin area. Knowing Your Mazda Exterior transmitter Operational range Interior transmitter Operational range...
Page 70 Knowing Your Mazda Advanced Keyless Entry and Start System NOTE The trunk is out of the operational range, however, starting the engine may be possible. The engine may not start if the advanced key is placed in the following areas:...
Page 71 Engine Ignition switch positions Without a traditional key, some of the ignition switch functions are different. Knowing Your Mazda Start knob...
Page 72 Knowing Your Mazda Advanced Keyless Entry and Start System LOCK (Released) The steering wheel locks to help protect against theft. LOCK (Depressed) The ignition switch can be turned to the ACC position when the KEY indicator light (green) illuminates in the instrument cluster.
Page 73 The starter will not operate if the clutch pedal is not depressed all the way. (Automatic transmission) The starter will not operate if the shift lever is not in P or N. 6. Push the start knob slowly all the way Knowing Your Mazda 3-11...
Page 74 Knowing Your Mazda Advanced Keyless Entry and Start System 7. Verify that the KEY indicator light (green) illuminates in the instrument cluster. The KEY warning light (red) means you cannot continue to start the engine using the Advanced Keyless System. You may have to use the auxiliary key instead (page 3-20).
Page 75: Operation Using Advanced Key Functions
If the transmitter does not operate when pressing a button or the operational range becomes too small, the battery may be dead. To install a new battery, refer to Maintenance (page 3-5). Knowing Your Mazda 3-13...
Page 76 Knowing Your Mazda Advanced Keyless Entry and Start System Transmitter Lock button Unlock button NOTE (U.S.A.) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
Page 77 The engine can be started with the auxiliary key, refer to Ignition Switch (page 5-2). Locking, unlocking the glove box The glove box can be locked/unlocked using the auxiliary key, refer to Glove Box (page 6-50). Knowing Your Mazda 3-15...
Page 78: Advanced Key Suspend Function
Park the vehicle in a safe place and use the auxiliary key to continue driving the vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. Refer to Ignition Switch (page 5-2). qStart Knob Not in LOCK Warning Beep...
Page 79 The advanced key is placed in areas where it is difficult for the system to detect the signal (page 3-7). A key from another manufacturer similar to the advanced key is in the operational range. Knowing Your Mazda 3-17...
Page 80 Knowing Your Mazda Advanced Keyless Entry and Start System qAdvanced Key Left-in-trunk Warning Beep If the advanced key is left in the trunk compartment with all doors locked and the trunk lid closed, a beep sound is heard for about 10 seconds to remind the driver the advanced key has been left in the trunk compartment.
Page 81: Setting Change (Function Customization)
Setting Change (Function Customization) The following function settings are possible. These settings can only be changed by an Authorized Mazda Dealer. Setting Advanced key battery KEY indicator light (green) flashes to indicate dead indicator that the advanced key battery power is low.
Page 82: When Warning Indicator/Beep Is Activated
Refer to Advanced Key Maintenance on page 3-5. The advanced key is malfunctioning. Park the vehicle in a safe place, and use the auxiliary key to continue driving the vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible.
Page 83: Doors And Locks
Write down the code number and keep it in a separate safe and convenient place, but not in the vehicle. If your key is lost, consult your Authorized Mazda Dealer and have your code number ready. Key extend/retract method (Retractable type key) To extend the key, press the release button.
Page 84: Keyless Entry System (With Retractable Type Key)
To install a new battery, refer to Maintenance (page 3-24). Additional transmitters can be obtained at an Authorized Mazda Dealer. Up to 3 transmitters can be used with the keyless entry system per vehicle. Bring all transmitters to an Authorized Mazda Dealer when additional transmitters are required.
Page 85 After unlocking with the transmitter, all doors will automatically lock if one of the doors is not opened within about 30 seconds. Trunk button To open the trunk, press the trunk button for more than 1 second. Knowing Your Mazda Doors and Locks 3-23...
Page 86 Knowing Your Mazda Doors and Locks Panic button If you witness from a distance someone attempting to break into or damage your vehicle, pressing the panic button will activate the vehicle's alarm. NOTE The panic button will work whether any door is open or closed.
Page 87 Authorized Mazda Dealer. If your transmitter is lost or stolen, bring all remaining transmitters to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen transmitter inoperative. Knowing Your Mazda...
Page 88: Door Locks
Knowing Your Mazda Doors and Locks CAUTION Radio equipment like this is governed by laws in the United States. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Page 89 To unlock, pull it out. Door-lock knob Lock Unlock To lock either front door with the door- lock knob from the outside, push the door-lock knob to the lock position and close the door. Door-lock knob Knowing Your Mazda 3-27...
Page 90 Knowing Your Mazda Doors and Locks NOTE (With advanced key) The driver's door cannot be locked using the door-lock knob from the outside. (Without advanced key) The driver's door cannot be locked using the door-lock knob from the outside if the key is in the ignition switch.
Page 91 Opening the freestyle doors 1. Open the front door first. Unlock Lock 2. Pull the rear door handle and open the rear door. Rear door handle Knowing Your Mazda Doors and Locks Front door 3-29...
Page 92 Knowing Your Mazda Doors and Locks CAUTION Before closing a front door make sure other passengers are not operating a rear door and a rear passenger's head or hands are away from the rear door. If the front door is closed...
Page 93: Trunk Lid
Exhaust gas entering the cabin of a vehicle through an open trunk is dangerous. This gas contains CO (carbon monoxide), which is colorless, odorless, and highly poisonous. If inhaled, it can cause loss of consciousness and death. Knowing Your Mazda 3-31...
Page 94 Knowing Your Mazda Doors and Locks qOpening and Closing the Trunk WARNING Close the trunk lid and do not allow children to play inside the vehicle: Leaving the trunk lid open or leaving children in the vehicle with the keys is dangerous.
Page 95: Inside Trunk Release Lever
Always keep the car from being a tempting place to play by locking doors and the trunk, and keeping the keys where children can not play with them: Knowing Your Mazda Doors and Locks WARNING Leaving the trunk lid open or leaving children in the vehicle with the keys is dangerous.
Page 96: Power Windows
Knowing Your Mazda Doors and Locks qOpening the Trunk Lid from the Inside Slide the inside trunk release lever in the direction of the arrow. The lever is made of material that will glow for hours in the darkness of the trunk following a brief exposure to ambient light.
Page 97 Power window lock switch Passenger's window To open the window to the desired position, hold down the switch. To close the window to the desired position, pull up the switch. Open Knowing Your Mazda Close 3-35...
Page 98: Rear Quarter Windows
Knowing Your Mazda Doors and Locks qPower Window Lock Switch With the lock switch in the unlocked position, all power windows on each door can be operated. With the lock switch in the locked position, only the driver's side power window can be operated.
Page 99: Fuel-Filler Lid And Cap
CAUTION Always use only a genuine Mazda fuel cap or an approved equivalent, available at an Authorized Mazda Dealer. The wrong cap can result in a serious malfunction of the fuel and emission control systems.
Page 100: Hood
(even after you have tightened the cap securely, driven, and restarted the engine several times), it may indicate a different problem. Contact an Authorized Mazda Dealer as soon as possible. 3-38 Hood WARNING Always check that the hood is closed...
Page 101: Moonroof Í
NOTE After washing your Mazda or after it rains, wipe the water off the moonroof before operating it to avoid water penetration which could cause rust and water damage to your headliner.
Page 102 Knowing Your Mazda Doors and Locks qTilt Operation The rear of the moonroof can be tilted open to provide more ventilation. To fully tilt automatically, momentarily push the rear of the tilt switch. To stop tilting partway, push any part of the tilt or slide switch.
Page 103: Security System
This device complies with RSS-210 of Industry CANADA. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Knowing Your Mazda 3-41...
Page 104 If the security indicator light flashes continuously while you are driving, don't shut off the engine. Go to an Authorized Mazda Dealer and have it checked. If the engine is shut off while the indicator light is flashing, you won't be able to restart it.
Page 105: Immobilizer System (Without Advanced Key)
Authorized Mazda Dealer. Always keep a spare advanced key in case one is lost. If an advanced key is lost, consult an Authorized Mazda Dealer as soon as possible. If you lose an advanced key (including auxiliary key), an Authorized Mazda Dealer...
Page 106 Knowing Your Mazda Security System CAUTION When starting the engine do not allow the following, as the engine may not start due to the electronic signal from the ignition key not being transmitted correctly. Ø A key ring rests on the key grip.
Page 107 If the security indicator light flashes continuously while you are driving, don't shut off the engine. Go to an Authorized Mazda Dealer and have it checked. If you shut off the engine while the light is flashing you won't be able to restart it.
Page 108: Theft-Deterrent System Í
Knowing Your Mazda Security System Theft-Deterrent System If the theft deterrent system detects an inappropriate entry into the vehicle, which could result in the vehicle or its contents being stolen, the alarm alerts the surrounding area of an abnormality by sounding the horn and flashing the hazard warning lights.
Page 109 Security System qTheft-Deterrent Labels A label indicating that your vehicle is equipped with a Theft-Deterrent System is in the glove box. Mazda recommends that you affix it to the lower rear corner of a front door window. Knowing Your Mazda 3-47...
Page 110: Steering Wheel And Mirrors
Knowing Your Mazda Steering Wheel and Mirrors Steering Wheel WARNING Never adjust the steering wheel while the vehicle is moving: Adjusting the steering wheel while the vehicle is moving is dangerous. Moving it can very easily cause the driver to abruptly turn to the left or right.
Page 111 Rearview mirror adjustment Before driving, adjust the rearview mirror to center on the scene through the rear window. Manual day/night mirror Knowing Your Mazda í WARNING Cargo stacked higher than the seatbacks is dangerous. It can block your view in the rearview mirror, which might cause you to hit another car when changing lanes.
Page 112 Knowing Your Mazda Steering Wheel and Mirrors Auto-dimming mirror NOTE For the manual day/night mirror, perform the adjustment with the day/night lever in the day position. Reducing glare from headlights Manual day/night mirror Push the day/night lever forward for day driving.
Page 113 Light sensor Light sensor For information regarding the 3 buttons ) on the auto-dimming mirror, refer to HomeLink Wireless Control System (page 5-61). Knowing Your Mazda Steering Wheel and Mirrors 3-51...
Page 114 3-52...
Page 115 Before Driving Your Mazda Important information about driving your Mazda. Fuel and Engine Exhaust Precautions ... 4-2 Fuel Requirements ... 4-2 Emission Control System ... 4-3 Engine Exhaust (Carbon Monoxide) ... 4-4 Before Starting the Engine ... 4-5 Before Getting In ... 4-5 After Getting In ...
Page 116: Fuel And Engine Exhaust Precautions
Ø Never add fuel system additives. Never add cleaning agents other than those specified by Mazda. Other cleaning agents and additives may damage the system. Consult an Authorized Mazda Dealer. Gasoline blended with oxygenates such as alcohol or ether compounds are generally referred to as oxygenated fuels.
Page 117: Before Driving Your Mazda
Ø USE ONLY UNLEADED FUEL. Ø Don't drive your Mazda with any sign of engine malfunction. Ø Don't coast with the ignition switch turned off. Ø Don't descend steep grades in gear with the ignition switch turned off.
Page 118: Engine Exhaust (Carbon Monoxide)
When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside your vehicle, keep all windows fully open and contact an Authorized Mazda Dealer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.
Page 119: Before Starting The Engine
NOTE Engine oil, engine coolant, brake/clutch fluid, washer fluid, and other fluid levels should be inspected. See Maintenance, Section 8. Before Driving Your Mazda Before Starting the Engine After Getting In Are all doors closed and locked? Is the seat adjusted properly?
Page 120: Driving Tips
No special break-in is necessary, but a few precautions in the first 1,000 km (600 miles) may add to the performance, economy, and life of your Mazda. Don't race the engine. Don't maintain one constant speed, either slow or fast, for a long period of time.
Page 121: Hazardous Driving
NOTE Use snow chains only on the rear wheels. Before Driving Your Mazda Driving Tips Rocking the Vehicle WARNING Do not spin the wheels at more than 56...
Page 122: Winter Driving
Carry emergency gear, including tire chains, window scraper, flares, a small shovel, jumper cables, and a small bag of sand or salt. Ask an Authorized Mazda Dealer to perform the following precautions: Have the proper ratio of antifreeze in the radiator.
Page 123: Driving In Flooded Area
1. Secure the chains on the rear tires as tightly as possible. Always follow the chain manufacturer's instructions. 2. Retighten the chains after driving 1/2 1 km (1/4 1/2 mile). Before Driving Your Mazda Driving Tips Driving In Flooded Area WARNING Dry wet brakes by driving very slowly...
Page 124: Overloading
Before Driving Your Mazda Driving Tips Overloading WARNING Be careful not to overload your vehicle: The gross axle weight rating (GAWR) and the gross vehicle weight rating (GVWR) of your vehicle are on the Motor Vehicle Safety Standard Label on the driver's door frame. Exceeding these ratings can cause an accident or vehicle damage.
Page 125: Towing
Before Driving Your Mazda Towing Trailer Towing The Mazda RX-8 is not designed for towing. Never tow a trailer with your Mazda RX-8. 4-11...
Page 126 4-12...
Page 127: Driving Your Mazda
Driving Your Mazda Explanation of instruments and controls. Starting and Driving ... 5-2 Ignition Switch ... 5-2 Starting the Engine ... 5-4 Brake System ... 5-5 Manual Transmission Operation ... 5-10 Automatic Transmission Controls ... 5-12 Power Steering ... 5-19 Cruise Control ...
Page 128: Starting And Driving
Driving Your Mazda Starting and Driving Ignition Switch Auxiliary key (with advanced key) NOTE When starting the engine using the advanced key, refer to Starting the Engine (page 3-9). When starting the engine with the auxiliary key, perform the following procedure.
Page 129 If turning the key is difficult, jiggle the steering wheel from side to side. Leaving the key or start knob in any position but LOCK position also disables some of the security features and may run the battery down. Driving Your Mazda Starting and Driving WARNING...
Page 130: Starting The Engine
Driving Your Mazda Starting and Driving ACC (Accessory) The steering wheel unlocks and some electrical accessories will operate. This is the normal running position after the engine is started. The warning lights (except brakes) should be inspected before the engine is started (page 5-39).
Page 131: Brake System
Starting and Driving Brake System qFoot Brake Your Mazda has power-assisted brakes that adjust automatically through normal use. Should power-assist fail, you can stop by applying greater force than normal to the brake pedal.
Page 132 Driving Your Mazda Starting and Driving WARNING Do not coast with the engine stalled or turned off, find a safe place to stop: Coasting with the engine stalled or turned off is dangerous. Braking will require more effort, and the brake's power-assist could be depleted if you pump the brake.
Page 133 Have it towed to an Authorized Mazda Dealer. Even if the light goes out have your brake system inspected as soon as possible by an Authorized Mazda Dealer. Driving Your Mazda...
Page 134 Starting and Driving NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. WARNING Do not drive with the brake system warning light illuminated.
Page 135 ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS warning light comes on.
Page 136: Manual Transmission Operation
Do not drive with worn disc pads: Driving with worn disc pads is dangerous. The brakes could fail and cause a serious accident. As soon as you hear a screeching noise consult an Authorized Mazda Dealer. 5-10 Manual Transmission Operation qManual Transmission Shift Pattern...
Page 137 This reduces the chance of stalling and gives better acceleration when you need more speed. On a steep downgrade, downshifting helps maintain safe speed and prolongs brake life. Driving Your Mazda 5-11...
Page 138: Automatic Transmission Controls
Driving Your Mazda Starting and Driving Automatic Transmission Controls Various Lockouts: Indicates that you must depress the brake pedal to shift (The ignition switch must be in the ACC or ON position). Indicates the shift lever can be shifted freely into any position.
Page 139 6-gear sequence. M (Manual) M is the manual shift mode position. Gears can be shifted up or down by operating the shift lever or steering shift switches. Refer to Manual Shift Mode (page 5-14). Driving Your Mazda 5-13...
Page 140 Driving Your Mazda Starting and Driving qActive Adaptive Shift (AAS) Active Adaptive Shift (AAS) automatically controls the transmission shift points to best suit the road conditions and driver input. This optimizes engine performance and improves driving comfort. When cornering the vehicle,...
Page 141 To shift up to a higher gear with the steering shift switches, tap either of the UP switches toward you once with your fingers. Driving Your Mazda Starting and Driving The steering shift switch and the shift lever are operated simultaneously.
Page 142 Driving Your Mazda Starting and Driving WARNING Keep your hands on the steering wheel rim when using fingers or thumbs on the steering shift switches: Putting your hands inside the rim of the steering wheel when using the steering shift switches is dangerous.
Page 143 If the vehicle is kicked down at the following speeds or lower, the gears shift down automatically: Gear M6→M5 M6→M4 M5→M4 Driving Your Mazda Vehicle speed Vehicle speed 60 km/h (37 mph) 40 km/h (24 mph) 26 km/h (16 mph) 18 km/h (11 mph)
Page 144 Driving Your Mazda Starting and Driving Recommendations for shifting Upshifting For normal acceleration, we recommend these shift points. Gear Vehicle speed M1 to M2 19 km/h (12 mph) M2 to M3 35 km/h (22 mph) M3 to M4 47 km/h (29 mph)
Page 145: Indicator Light
If the steering feels stiffer than usual during normal driving, consult an Authorized Mazda Dealer. NOTE The steering may feel rigid if you continuously attempt to steer when the vehicle is stopped or moving extremely slowly.
Page 146: Cruise Control
Driving Your Mazda Starting and Driving Cruise Control With cruise control, you can set and automatically maintain any speed of more than about 30 km/h (19 mph). WARNING Do not use the cruise control under the following conditions: Using the cruise control under the...
Page 147 1.6 km/h (1 mph) by a momentary tap of the RES/ACCEL button. Multiple taps will increase your vehicle speed 1.6 km/h (1 mph) for each tap. Driving Your Mazda 5-21...
Page 148 Driving Your Mazda Starting and Driving To increase speed using accelerator pedal Depress the accelerator pedal to accelerate to the desired speed. Press the SET/COAST button and release it immediately. NOTE Accelerate if you want to speed up temporarily when the cruise control is on. Greater speed will not interfere with or change the set speed.
Page 149: Traction Control System (Tcs)
The traction control system (TCS) alone cannot provide adequate traction and you could still have an accident. NOTE To turn off the TCS, press the DSC OFF switch (page 5-26). í Some models. Driving Your Mazda 5-23...
Page 150: Dynamic Stability Control (Dsc)
Driving Your Mazda Starting and Driving qTCS/DSC Indicator Light This indicator light stays on for a few seconds when the ignition switch is turned to the ON position. If the TCS or DSC is operating, the indicator light flashes. If the light stays on, the TCS or DSC may have a malfunction and they may not operate correctly.
Page 151 CAUTION Ø The DSC may not operate correctly unless the following are observed: Ø Use tires of the correct size specified for your Mazda on all four wheels. Ø Use tires of the same manufacturer, brand and tread pattern on all four wheels.
Page 152 Driving Your Mazda Starting and Driving qDSC OFF Switch Press the DSC OFF switch to turn off the TCS/DSC. The DSC OFF indicator light will illuminate. Press the switch again to turn the TCS/ DSC back on. The DSC OFF indicator light will go out.
Page 153: Tire Pressure Monitoring System
Driving Your Mazda Starting and Driving í Tire Pressure Monitoring System The tire pressure monitoring system (TPMS) monitors the pressure for each tire. If tire pressure is too low in one or more tires, the system will inform the driver via the warning light in the instrument panel and by the warning beep sound.
Page 154 Driving Your Mazda Starting and Driving CAUTION Ø Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a...
Page 155 Authorized Mazda Dealer or a tire repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Page 156 Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
Page 157 The signal code must be registered with the TPMS before it can work. The easiest way to do it is to have an Authorized Mazda Dealer change your tire and complete ID signal code registration. When having tires changed at an...
Page 158 Replacing tires and wheels CAUTION Ø When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. Ø The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Page 159: Instrument Cluster And Indicators
Driving Your Mazda Instrument Cluster and Indicators Meters and Gauges When the ignition switch is in the ON position, the dashboard gauges illuminate. Speedometer ... page 5-34 Speed Unit Selector ... page 5-34 Odometer, Trip Meter and Trip Meter Selector ... page 5-34 Tachometer ...
Page 160 Driving Your Mazda Instrument Cluster and Indicators qSpeedometer The speedometer indicates the speed of the vehicle. qSpeed Unit Selector In some countries, you may have to change the speed units between km/h and mph. Press the speed unit selector for 2 second or more.
Page 161 The vehicle is driven over 999.9 km (mile). qTachometer The tachometer shows engine speed in thousands of revolutions per minute (rpm). Automatic transmission Manual transmission Driving Your Mazda Striped zone Red zone Striped zone Red zone 5-35...
Page 162 Driving Your Mazda Instrument Cluster and Indicators CAUTION Don't run the engine with the tachometer needle in the RED ZONE. This may cause severe engine damage. NOTE The beep sounds to indicate engine overrev when the tachometer needle enters the striped zone.
Page 163 Don't run the engine if the oil pressure is low. It could result in extensive engine damage. NOTE The Mazda RX-8 requires regular checking of the engine oil level. The compact, high performance RENESIS rotary engine in your vehicle consumes a small amount of engine oil due to its structural design.
Page 164 Driving Your Mazda Instrument Cluster and Indicators To cancel the illumination dimmer, rotate the thumb wheel upward fully. You may hear a click sound and the illumination dimmer will be canceled (instrument cluster illumination color turns to white). NOTE If the dashboard illumination switch is kept at...
Page 165: Warning/Indicator Lights And Beep Sounds
ABS Warning Light Air Bag/Front Seat Belt Pretensioner System Warning Light Low Fuel Warning Light Seat Belt Warning Light/Beep Warning/Indicator lights will appear in any of the highlighted areas Warning/Indicator Lights Driving Your Mazda Page 5-41 5-42 5-42 5-43 5-43...
Page 166 Driving Your Mazda Warning/Indicator Lights and Beep Sounds Signal Door-Ajar Warning Light Low Washer Fluid Level Warning Light Automatic Transmission Warning Light Tire Pressure Monitoring System Warning Light KEY Warning Light (Red)/KEY Indicator Light (Green) Security Indicator Light Headlight High-Beam Indicator Light...
Page 167 NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. Do not drive with the brake system warning light illuminated. Contact an...
Page 168 WARNING Do not drive with both the ABS warning light and brake warning light illuminated. Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as soon as possible: Driving when the brake system warning light and ABS warning light are illuminated at the same time is dangerous.
Page 169 Don't run the engine if the oil level is low. It could result in extensive engine damage. NOTE The Mazda RX-8 requires regular checking of the engine oil level. The compact, high performance RENESIS rotary engine in your vehicle consumes a small amount of engine oil due to its structural design.
Page 170 The fuel-filler cap is missing or not tightened securely. If the check engine light remains on or flashes continuously, do not drive at high speeds and consult an Authorized Mazda Dealer as soon as possible. qAir Bag/Front Seat Belt Pretensioner System Warning Light...
Page 171 Belt minder NOTE The belt minder can be deactivated. Consult an Authorized Mazda Dealer to deactivate and restore the seat belt minder. Warning/Indicator Lights and Beep Sounds The belt minder is a supplemental warning to the seat belt warning function.
Page 172 CAUTION If the automatic transmission warning light illuminates, the transmission has an electrical problem. Continuing to drive your Mazda in this condition could cause damage to your transmission. Consult an Authorized Mazda Dealer as soon as possible. í 5-46 Some models.
Page 173 Authorized Mazda Dealer or a tire repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Page 174 Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
Page 175 Park the vehicle in a safe place and use the auxiliary key to continue driving the vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. Warning/Indicator Lights and Beep Sounds When flashing...
Page 176 If the engine doesn't start with the correct ignition key, and the security indicator light keeps illuminating or flashing, the system may have a malfunction. Consult an Authorized Mazda Dealer. qHeadlight High-Beam Indicator Light This light indicates one of two things: The high-beam headlights are on.
Page 177 TCS/DSC is switched off (page 5-26). If the light stays on when the TCS/DSC is not switched off, take your vehicle to an Authorized Mazda Dealer. The dynamic stability control may have a malfunction. Driving Your Mazda í...
Page 178 If the TCS/DSC indicator light and the DSC OFF indicator light remain illuminated even after turning the ignition switch to the ON position, consult an Authorized Mazda Dealer. qCruise Main Indicator Light (Amber)/Cruise Set Indicator Light (Green) The indicator light has two colors.
Page 179: Beep Sounds
Thereafter, the indicator light will illuminate when the headlight auto- leveling system has a malfunction. If the indicator light illuminates, contact an Authorized Mazda Dealer. qTurn-Signal/Hazard Warning Indicator Lights When operating the turn signal lights, the left or right turn signal indicator light flashes to indicate which turn signal light is operating (page 5-57).
Page 180 Driving Your Mazda Warning/Indicator Lights and Beep Sounds qTire Inflation Pressure Warning í Beep The warning beep sound will be heard for about 3 seconds when there is any abnormality in tire inflation pressures (page 5-27). qAdvanced Keyless Warning (with...
Page 181: Switches And Controls
Consult an Authorized Mazda Dealer when the replacement is necessary. NOTE If the headlights flicker, or the brightness weakens, the bulb-life may be depleted and a replacement is necessary.
Page 182 Thereafter, the indicator light will illuminate when the headlight auto- leveling system has a malfunction. If the indicator light illuminates, contact an Authorized Mazda Dealer. qDaytime Running Lights (Canada) In Canada, vehicles must be driven with the headlights on during daytime operation.
Page 183: Turn And Lane-Change Signals
OFF position or turn the headlight switch to the position. NOTE The fog lights will turn off when the headlights are set at high beam. until the Driving Your Mazda Switches and Controls í Fog Lights position. Fog light switch or OFF í...
Page 184: Windshield Wipers And Washer
After 5 minutes, turn on the switch and the blades should operate normally. If they don't resume functioning, consult an Authorized Mazda Dealer as soon as possible. Drive to the side of the road and park off the right-of- way. Wait until the weather clears before trying to drive with the wipers inoperative.
Page 185: Headlight Washer Í
If the washer doesn't work, inspect the fluid level (page 8-16). If it's OK, consult an Authorized Mazda Dealer. NOTE (With headlight washers) When the headlights are on, the headlight washers operate automatically once every fifth time the windshield washer operates.
Page 186: Rear Window Defroster
Driving Your Mazda Switches and Controls Rear Window Defroster The rear window defroster clears frost, fog, and thin ice from the rear window. The ignition switch must be in the ON position. Press the switch to turn on the rear window defroster.
Page 187: Hazard Warning Flasher
Pressing the HomeLink button on the auto-dimming mirror activates garage doors, gates and other devices surrounding your home. Indicator light HomeLink button í Some models. Driving Your Mazda 5-61...
Page 188 Driving Your Mazda Switches and Controls WARNING Do not use the HomeLink system with any garage door opener that lacks the safety stop and reverse feature: Using the HomeLink system with any garage door opener that lacks the safety stop and reverse feature as required by federal safety standards is dangerous.
Page 189 HomeLink button. Repeat the press/hold/release sequence a second time, and, depending on the brand of the garage door opener (or other rolling code equipped device), repeat this sequence a third time to complete the programming process. Driving Your Mazda 5-63...
Page 190 Driving Your Mazda Switches and Controls HomeLink should now activate your rolling code equipped device. NOTE To program the remaining two HomeLink buttons, begin with “Programming” ― step 2. Do not repeat step 1. For questions or comments, please contact HomeLink at www.homelink.com or 1-...
Page 191: Interior Comfort
Interior Comfort Use of various features for drive comfort, including air-conditioning and audio system. Climate Control System ... 6-2 Operating Tips ... 6-2 Vent Operation ... 6-3 Control Panel ... 6-5 Audio System ... 6-10 Antenna ... 6-10 Operating Tips for Audio System ... 6-10 Audio Set ...
Page 192: Climate Control System
Have the air conditioner checked before the weather gets hot. Lack of refrigerant may make the air conditioner less efficient. Consult an Authorized Mazda Dealer for refrigerant inspection. The air conditioner is filled with HFC134a (R134a), a refrigerant that will not damage the ozone layer.
Page 193: Vent Operation
qAdjusting the Vents Directing airflow Side Vents To adjust the direction of airflow, open the vents and rotate them left and right. Climate Control System Vent Operation Center vents Center Vents To adjust the direction of airflow, move the adjustment knob. NOTE When using the air conditioner, mist may come out from the vents.
Page 194 Interior Comfort Climate Control System qSelecting the Airflow Mode Dashboard Vents Dashboard and Floor Vents Floor Vents Defroster and Floor Vents Defroster Vents...
Page 195: Control Panel
Climate control information is displayed on the information display. Windshield defroster switch Fan control dial qControl Switches Temperature control dial Cold This dial controls temperature. Turn it clockwise for hot and counterclockwise for cold. Control Panel A/C switch Air intake selector Mode selector switch Fan control dial This dial allows variable fan speeds.
Page 196 Interior Comfort Climate Control System Mode selector switch Press the mode selector switch to select airflow mode (page 6-4). NOTE To set the air vent to , press the windshield defroster switch. A/C switch Push the A/C switch to turn the air conditioner on.
Page 197 This position can be used when driving on a dusty road or in similar conditions. It also helps to provide quicker cooling of the interior. WARNING Do not use the position in cold or rainy weather: Using the position in cold or rainy weather is dangerous as it will cause the windows to fog up.
Page 198 Interior Comfort Climate Control System CAUTION When using the air conditioner while driving up long hills or in heavy traffic, closely monitor the temperature gauge (page 5-36). The air conditioner may cause engine overheating. If the gauge indicates overheating, turn the air conditioner off (page 7-16).
Page 199 qDehumidifying (With Air Conditioner) Operate the air conditioner in cool or cold weather to help defog the windshield and side windows. 1. Press the mode selector switch to the desired position. 2. Set the air intake selector to the position. 3.
Page 200: Audio System
Interior Comfort Audio System Antenna qRear Window Antenna The rear window antenna receives both AM and FM signals. CAUTION When washing the inside rear window, use a soft cloth dampened in lukewarm water, gently wiping the antenna lines. Use of glass cleaning products could damage the antenna.
Page 201 qRadio Reception AM characteristics AM signals bend around such things as buildings or mountains and bounce off the ionosphere. Therefore, they can reach longer distances than FM signals. Because of this, two stations may sometimes be picked up on the same frequency at the same time.
Page 202 Interior Comfort Audio System Flutter/Skip noise Signals from an FM transmitter move in straight lines and become weak in valleys between tall buildings, mountains, and other obstacles. When a vehicle passes through such an area, the reception conditions may change suddenly, resulting in annoying noise.
Page 203 Use a good quality head- cleaning tape or a liquid cleaner cassette tape to remove it. Should the unit not operate normally, consult an Authorized Mazda Dealer. Never attempt to repair it or insert a screwdriver or anything else. Handling the cassette tape player The following precautions should be observed.
Page 204 Interior Comfort Audio System qOperating Tips for CD Player/In- Dash CD Changer Condensation phenomenon Immediately after turning on the heater when the vehicle is cold, the CD or optical components (prism and lens) in the CD player/In-dash CD changer may become clouded with condensation.
Page 205 A new CD may have rough edges on its inner and outer perimeters. If a disc with rough edges is used, proper setting will not be possible and the CD player/In-dash CD changer will not play the CD. In addition, the disc may not eject resulting in a malfunction.
Page 206 Interior Comfort Audio System Do not stick paper or tape on the CD. Avoid scratching the reverse side (the side without a label). The disc may not eject resulting in a malfunction. Dust, finger smudges, and dirt can decrease the amount of light reflected from the signal surface, thus affecting sound quality.
Page 207 qOperating tips for MP3 NOTE Supply of this product only conveys a license for private, non-commercial use and does not convey a license nor imply any right to use this product in any commercial (i.e. revenue- generating) real time broadcasting (terrestrial, satellite, cable and/or any other media), broadcasting/streaming via the Internet, intranets and/or other networks or in other...
Page 208 Interior Comfort Audio System About folders and files The order of hierarchy for MP3 files and folders during playback or other functions is from shallow to deep. The arrangement and playing order of a recorded disc containing MP3 files is as follows: File number A numerical file number is assigned...
Page 209 About ID3 Tag display This unit can only display ID3 Tag album, track and artist names that have been input using Ver.1.0/1.1/2.2/2.3 formats. Any other data that may have been input cannot be displayed. This unit can only display English (including numerals) one-byte characters.
Page 210 MEMO 6-20...
Page 211: Audio Set
Audio information is displayed on the information display. There are two types of CD players. Check which CD player your vehicle is equipped with. CD Player (non-MP3 compatible) CD Player (MP3 compatible) Power/Volume/Sound Controls ... page 6-22 Operating the Radio ... page 6-26 Operating the Cassette Tape Player ...
Page 212 Interior Comfort Audio System qPower/Volume/Sound Controls Power ON/OFF Turn the ignition switch to the ACC or ON position. Press the power/volume dial to turn the audio system on. Press the power/volume dial again to turn the audio system off. NOTE To prevent the battery from being discharged, do not leave the audio system on for a long period of time when the engine is not running.
Page 213 Bose Sound System- equipped model * Depending on the mode selected, the indication changes. 2. Turn the audio control dial to adjust the selected functions as follows: Standard audio-equipped model Indication Turn Left Turn Right Decrease bass Decrease mid-range Decrease treble Shift the sound to the...
Page 214 Interior Comfort Audio System The following four modes are available. Select the desired mode. Mode Volume change No change Minimum Medium Maximum Turn the audio control dial to select ALC OFF or ALC LEVEL1 3 modes. The selected mode will be indicated. ®...
Page 215 MEMO 6-25...
Page 216 Interior Comfort Audio System qOperating the Radio Band selector button Seek tuning button Manual tuning dial/Auto memory button/Electric serial number button Radio ON Press a band selector button ( turn the radio on. Band selection Successively pressing the band selector button ( ) switches the bands as follows: FM1→FM2→AM.
Page 217 NOTE If you continue to press and hold the button, the frequency will continue changing without stopping. Scan tuning Press the scan button ( automatically sample strong stations. Scanning stops at each station for about 5 seconds. To hold a station, press the scan button ( ) again during this interval.
Page 218 Interior Comfort Audio System 1221 Avenue Of The Americas New York, NY 10020 Attention: Customer Care Include your Sirius Radio ESN (Electronic Serial Number) when subscribing or requesting technical assistance. See the Satellite Radio Kit manual accompanying the SIRIUS unit for complete satellite radio activation procedures and information on how to display the ESN#.
Page 219 MEMO 6-29...
Page 220 Interior Comfort Audio System qOperating the Cassette Tape Player APC button: (next program) (one being played) Dolby NR button Cassette tape insert Insert the cassette tape into the slot, open edge to the right and cassette tape will begin play, and TAPE PLAY will be displayed.
Page 221 Fast-forward/Rewind Press the fast-forward button ( fast-forward. Press the rewind button ( To stop this operation and play the cassette tape, press the button again. NOTE When the cassette tape ends during fast- forward or rewind, it automatically stops and starts playing.
Page 222 Interior Comfort Audio System qOperating the Compact Disc (CD) Player Music CD player (non-MP3 compatible) Music CD/MP3 CD player (MP3 compatible) Load button Track up button Track down button Folder down button Folder up button There are two types of CD players. Check which CD player your vehicle is equipped with.
Page 223 Fast-forward/Reverse Press and hold the fast-forward button ) to advance through a track at high speed. Press and hold the reverse button ( to reverse through a track at high speed. Track search Press the track up button ( skip forward to the beginning of the next track.
Page 224 If CHECK CD is displayed, it means that there is some CD malfunction. Check the CD for damage, dirt, or smudges, and then properly reinsert. If the message appears again, take the unit to an Authorized Mazda Dealer for service.
Page 225 MEMO 6-35...
Page 226 Interior Comfort Audio System qOperating the In-Dash CD Changer Load button CD slot Track up button Track down button Disc down button Disc up button Inserting the CD The CD must be label-side up when inserting. The auto-loading mechanism will set the CD and begin play. There will be a short lapse before play begins while the player reads the digital signals on the The disc number and the track number...
Page 227 2. Wait 3 seconds or press the load button ) again within 3 seconds after the beep sound is heard. 3. When IN is displayed, insert the CD. 4. When IN is displayed again, insert the next CD. NOTE The first-inserted CD will be played automatically when: No other CD is inserted within 15 seconds after “IN”...
Page 228 Interior Comfort Audio System Disc search Press the disc up button ( forward to the beginning of the next CD. Press the disc down button ( skip back to the beginning of the previous Music scan This feature helps to find a program by playing about the first 10 seconds of each track.
Page 229 Indications If you see an error indication on the display, find the cause in the chart. If you cannot clear the error indication, take the vehicle to an Authorized Mazda Dealer. Indication CD is inserted upside down CHECK CD...
Page 230: Audio Control Switch Operation
When a cassette tape/CD being played is ejected. (For the In-dash CD changer, when all CDs are ejected.) NOTE Mazda has installed this system to prevent distraction while driving the vehicle and using audio controls on the dashboard. Always make safe driving your first priority.
Page 231 NOTE Cassette tape, CD, CD changer, and SIRIUS digital satellite radio modes cannot be selected in the following cases: A cassette deck, CD, CD changer, or SIRIUS digital satellite radio unit is not equipped on the audio system. A cassette tape, or CD has not been inserted.
Page 232: Safety Certification
Ø This CD player should not be adjusted or repaired by anyone except qualified service personnel. If servicing is required, contact an Authorized Mazda Dealer. Ø Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser exposure. Never operate the CD player with the top case of the unit removed.
Page 233: Interior Equipment
Sunvisors When you need a sunvisor, lower it for use in front or swing it to the side. Sunvisor qVanity Mirrors To use the vanity mirror, lower the sunvisor. The vanity mirror light will illuminate when you open the cover. Interior Equipment Interior Lights qIlluminated Entry System...
Page 234 Interior Comfort Interior Equipment qOverhead Lights Front Switch Front Overhead Lights Position Light off Light is on when any door is open Light is on or off when the illuminated entry system is on Rear Switch Rear Overhead Lights Position Light off Light is on when any door is open Light is on or off when the...
Page 235: Information Display
qInformation Display Functions The information display has the following functions: Clock Ambient Temperature Display (Outside Temperature Display) Climate Control Display Audio Display Information Display Interior Comfort Interior Equipment 6-45...
Page 236 Interior Comfort Interior Equipment qClock When the ignition switch is in the ACC or ON position, the time is displayed. Time setting 1. Press the CLK switch until a beep sounds, and 12Hr and 24Hr will be displayed. 2. Press the SET switch to switch between 12Hr and 24Hr displays.
Page 237: Lighter
qAudio Display The audio system status is displayed. To operate the audio system, refer to Audio System (page 6-10). Interior Equipment Lighter The ignition switch must be in the ACC or ON position. 1. Open the cover. 2. Press the lighter in and release it. When ready for use, it automatically pops out.
Page 238: Ashtray
Ø Don't use the lighter socket for plug-in accessories such as shavers and coffee pots. They may damage it or cause electrical failure. Use only a genuine Mazda lighter or the equivalent. Ø If the lighter doesn't pop out within 30 seconds, remove it to prevent overheating.
Page 239: Cup Holder
Cup Holder WARNING Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous. If the contents spill, you could be scalded. Do not put anything other than cups or drink cans in cup holders: Putting objects other than cups or...
Page 240: Storage Compartments
Interior Comfort Interior Equipment Storage Compartments WARNING Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving. CAUTION Do not leave lighters or eyeglasses in the storage boxes while parked under...
Page 241 qCenter Console Front 1. Slide the lid while pushing the button until you hear a click sound. 2. Open the lid. Interior Equipment Rear To open, pull the release catch. CAUTION Do not place bottles filled with fluid (e.g. cosmetic fragrance) in the console box.
Page 242 Interior Comfort Interior Equipment To open, squeeze the latch and pull the lid down. When closing the storage box, put the storage box back in its original position until you hear a click sound. NOTE When using the storage box to store heavy accessories, remove the storage box before placing or removing the accessories.
Page 243: Accessory Socket
Accessory Socket The ignition switch must be in the ACC or ON position. Only use genuine Mazda accessories or the equivalent requiring no greater than 120 W (DC 12 V, 10 A). The accessory socket is in the center console.
Page 244 6-54...
Page 245 In Case of an Emergency Helpful information on what to do in an emergency. Parking in an Emergency ... 7-2 Parking in an Emergency ... 7-2 Flat Tire ... 7-3 Spare Tire and Tool Storage ... 7-3 Instant Mobility System (IMS) Emergency Flat Tire Repair Kit ...
Page 246: In Case Of An Emergency
In Case of an Emergency Parking in an Emergency Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.
Page 247: Flat Tire
In Case of an Emergency Flat Tire Spare Tire and Tool Storage Tools are stored in the locations illustrated in the diagram. Instant Mobility System (IMS) Emergency Flat Tire Repair Kit Tool box Lug wrench Jack handle Jack Tiedown eyelet...
Page 248 Perform the removal procedure in reverse. qSpare Tire A temporary spare tire is not equipped with your Mazda. If an emergency tire repair is needed, repair the flat tire with the emergency flat tire repair kit (page 7-5). If you require a temporary spare tire, consult an Authorized Mazda Dealer.
Page 249: Instant Mobility System (Ims) Emergency Flat Tire Repair Kit
When doing the repair, refer to the instructions included in the emergency flat tire repair kit. After temporarily repairing a tire with the emergency flat tire repair kit, take your vehicle to an Authorized Mazda Dealer to have the tire replaced. Flat Tire...
Page 250: Tire Repair Kit
NOTE The tire sealant cannot be reused. Purchase new tire sealant at an Authorized Mazda Dealer. The emergency flat tire repair kit cannot be used in the following cases. Consult an Authorized Mazda Dealer.
Page 251 4. Unload passengers and luggage, and remove the emergency flat tire repair kit. 5. Shake the tire sealant well. CAUTION If the bottle is shaken after the injection hose is screwed on, tire sealant could spray out from the injection hose. Tire sealant contacting clothing or other objects may be impossible to remove.
Page 252 NOTE The tire sealant cannot be reused. Purchase a new tire sealant kit at an Authorized Mazda Dealer. 11. Pull out the injection hose from the valve. Reinsert the valve core into the valve and turn it clockwise to install 12.
Page 253 Do not throw away the empty tire sealant bottle after use. Return the empty tire sealant bottle to an Authorized Mazda Dealer when replacing the tire. The empty tire sealant bottle will need to be used to extract and dispose of the used sealant from the tire.
Page 254 19. Put the emergency flat tire repair kit in the trunk and continue driving. CAUTION Ø Drive carefully to an Authorized Mazda Dealer and keep the vehicle speed below 80 km/h (50 mph). Ø If the vehicle is driven 80 km/h (50 mph) or higher, the vehicle might begin to vibrate.
Page 255: Changing The Tire
Check the period of effective use indicated on the bottle label and do not use it if it has expired. Have the tire sealant replaced at an Authorized Mazda Dealer before the period of effective use has expired. In Case of an Emergency...
Page 256 In Case of an Emergency Flat Tire 3. Turn on the hazard warning flasher. 4. Have everyone get out of the vehicle and away from the vehicle and traffic. 5. Remove the jack, and tool (page 7-3). 6. Block the wheel diagonally opposite the tire to be changed.
Page 257 Before removing the lug nuts, make sure your Mazda is firmly in position and that it cannot slip or move. 5. Remove the lug nuts by turning them counterclockwise, then remove the wheel.
Page 258 If you lose this key, consult an Authorized Mazda Dealer or use the lock manufacturer's order form, which is with the registration card.
Page 259 Because the wheel studs and lug nuts on your Mazda have metric threads, using a non-metric nut is dangerous. On a metric stud, it would not secure the wheel and would damage the stud, which could cause the wheel to slip off and cause an accident.
Page 260: Overheating
If the cooling fan does not operate while the engine is running, the engine temperature will increase. Stop the engine and call an Authorized Mazda Dealer. 6. Make sure the cooling fan is operating, then turn off the engine after the temperature has decreased.
Page 261 Carefully add coolant as required (page 8-13). CAUTION If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an Authorized Mazda Dealer. In Case of an Emergency Overheating 7-17...
Page 262: Emergency Starting
Do not hold the ignition switch in the START position for over 10 seconds. It may damage the starter and drain the battery. If the engine still does not start using the above procedure, have your vehicle inspected by an Authorized Mazda Dealer. 7-18...
Page 263: Jump-Starting
Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. WARNING Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 264 In Case of an Emergency Emergency Starting Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
Page 265 3. Remove the battery cover from its rear side. 4. Make sure the booster battery is 12 V and that its negative terminal is grounded. 5. If the booster battery is in another vehicle, don't allow the vehicles to touch. Turn off the engine of the vehicle with the booster battery and all unnecessary electrical loads in both vehicles.
Page 266: Push-Starting
In Case of an Emergency Emergency Starting Push-Starting Do not push-start your Mazda. WARNING Never tow a vehicle to start it: Towing a vehicle to start it is dangerous. The vehicle being towed could surge forward when its engine starts, causing the two vehicles to collide.
Page 267: Emergency Towing
Towing Description We recommend that towing be done only by an Authorized Mazda Dealer or a commercial tow-truck service. Proper lifting and towing are necessary to prevent damage to the vehicle. Government and local laws must be followed. A towed vehicle usually should have its drive wheels (rear wheels) off the ground.
Page 268: Tiedown Hooks
In Case of an Emergency Emergency Towing Tiedown Hooks CAUTION Don't use the tiedown hooks under the front and rear for towing. They are designed ONLY for tying down the vehicle when it's being transported. Using them for towing will damage the bumper. qTiedown Hooks 1.
Page 269: Recreational Towing
4. Hook the tying rope to the tiedown eyelet. Front Rear CAUTION If the tiedown eyelet is not securely tightened, it may loosen or disengage from the bumper when tying down the vehicle. Make sure that the tiedown eyelet is securely tightened to the bumper.
Page 270 7-26...
Page 271: Maintenance And Care
Maintenance and Care How to keep your Mazda in top condition. Introduction ... 8-2 Introduction ... 8-2 Scheduled Maintenance ... 8-3 Scheduled Maintenance ... 8-3 Owner Maintenance ... 8-8 Owner Maintenance Schedule ... 8-8 Owner Maintenance Precautions ... 8-9 Engine Compartment Overview ... 8-10 Engine Oil ...
Page 272: Introduction
Claims against the warranty resulting from lack of maintenance, as opposed to defective materials or authorized Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance. But we recommend that it always be done by an Authorized...
Page 273: Scheduled Maintenance
Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are being used Driving on rough or muddy roads Extended periods of idling or low-speed operation Driving for long periods in cold temperatures or extremely humid climates...
Page 274 Maintenance and Care Scheduled Maintenance qSchedule 1 Maintenance Interval ENGINE Engine oil Engine oil filter Drive belt AIR FILTER Air filter IGNITION SYSTEM Spark plugs FUEL SYSTEM Fuel filter Fuel lines, hoses and connections COOLING SYSTEM Cooling system Engine coolant CHASSIS AND BODY Brake lines, hoses and connections Disc brakes...
Page 275 *1 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 276 Maintenance and Care Scheduled Maintenance qSchedule 2 Maintenance Interval ENGINE Engine oil Engine oil filter Drive belt AIR FILTER Air filter IGNITION SYSTEM Spark plugs FUEL SYSTEM Fuel filter Fuel lines, hoses and connections COOLING SYSTEM Cooling system Engine coolant Engine coolant level ELECTRICAL SYSTEM Function of all lights...
Page 277 *1 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 278: Owner Maintenance
The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.
Page 279: Owner Maintenance Precautions
Improper owner maintenance during the warranty period may affect warranty coverage. For details, read the separate Mazda Warranty statement provided with the vehicle. If you're unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.
Page 280: Engine Compartment Overview
Maintenance and Care Owner Maintenance Engine Compartment Overview Windshield washer fluid reservoir Cooling system cap Engine coolant reservoir Battery 8-10 Engine oil-filler cap Engine oil dipstick Fuse block (near battery) Air filter Brake/Clutch fluid reservoir Fuse block (next to air filter)
Page 281: Engine Oil
NOTE Changing the engine oil should be done by an Authorized Mazda Dealer. The Mazda RX-8 requires regular checking of the engine oil level. The compact, high performance RENESIS rotary engine in your vehicle consumes a small amount of engine oil due to its structural design.
Page 282 Maintenance and Care Owner Maintenance Except U.S.A. and CANADA The quality designation SL,SM, or ILSAC must be on the label. –30 –10 –20 –20 5W-20 qInspecting Engine Oil Level 1. Be sure the vehicle is on a level surface. 2. Warm up the engine to normal operating temperature.
Page 283: Engine Coolant
NOTE Each mark from the F mark equates to about 0.5 L (US 0.5 qt, Imp 0.4 qt). There are 3 marks between L and F. Verify that the engine cover is securely installed. Maintenance and Care Owner Maintenance Engine Coolant qInspecting Coolant Level WARNING Do not use a match or live flame in the...
Page 284 NOTE Changing the coolant should be done by an Authorized Mazda Dealer. Inspect the antifreeze protection and coolant level in the coolant reservoir at least once a year at the beginning of the...
Page 285: Brake/Clutch Fluid
(page 8-3). If the coolant reservoir is empty or new coolant is required frequently, consult an Authorized Mazda Dealer. Maintenance and Care Owner Maintenance Brake/Clutch Fluid qInspecting Brake/Clutch Fluid Level The brakes and clutch draw fluid from the same reservoir.
Page 286: Washer Fluid
(page 10-4) will damage the systems. Mixing different fluids will also damage them. If the brake/clutch system frequently requires new fluid, consult an Authorized Mazda Dealer. 8-16 Washer Fluid qInspecting Washer Fluid Level WARNING Use only windshield washer fluid or...
Page 287: Body Lubrication
Inspect fluid level in the washer fluid reservoir; add fluid if necessary. Use plain water if washer fluid is unavailable. But use only washer fluid in cold weather to prevent it from freezing. Body Lubrication All moving points of the body, such as door and hood hinges and locks, should be lubricated each time the engine oil is changed.
Page 288: Wiper Blades
Maintenance and Care Owner Maintenance Wiper Blades CAUTION Ø Hot waxes applied by automatic car washers have been known to affect the wiper's ability to clean windows. Ø To prevent damage to the wiper blades, don't use gasoline, kerosene, paint thinner, or other solvents on or near them.
Page 289 3. Remove the metal stiffeners from each blade rubber and install them in the new blade. CAUTION Ø Don't bend or discard the stiffeners. You need to use them again. Ø If the metal stiffeners are switched, the blade's wiping efficiency could be reduced.
Page 290: Battery
Maintenance and Care Owner Maintenance WARNING Wash hands after handling the battery and related accessories: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery: Working without eye protection is dangerous.
Page 291 Maintenance and Care Owner Maintenance Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
Page 292: Tires
Use all radial, all bias-belted, or all bias-type tires. Using Wrong-Sized Tires: Using any other tire size than what is specified for your Mazda (page 10-6) is dangerous. It could seriously affect ride, handling, ground clearance, tire clearance, and speedometer calibration.
Page 293 NOTE Because your vehicle is not equipped with a spare tire, you cannot do a tire rotation safely with the jack that comes with your vehicle. Have an Authorized Mazda Dealer perform tire rotation. Maintenance and Care í 8-23...
Page 294 Reduced braking, steering, and traction could result in an accident. CAUTION (With Tire Pressure Monitoring System) When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged.
Page 295 Refer to The tire labeling on page 9-18. Maintenance and Care Owner Maintenance qTemporary Spare Tire Your Mazda is not equipped with a spare tire. If you require a spare tire, consult an Authorized Mazda Dealer. Inspect the temporary spare tire at least monthly to make sure it's properly inflated and stored.
Page 296 Ø (With Tire Pressure Monitoring System) Ø When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. Ø The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Page 297: Light Bulbs
Brake lights/Taillights Trunk light High-mount brake light License plate light Overhead light/Map lights (Front) Vanity mirror lights Parking lights Fog lights Headlights (High-beam) Owner Maintenance Light Bulbs Maintenance and Care Overhead light (Rear) Rear side-marker lights Rear turn signal lights Reverse lights Courtesy lights Front side-marker lights...
Page 298 Consult an Authorized Mazda Dealer when the replacement is necessary. Never touch the glass portion of a halogen bulb with your bare hands and...
Page 299 Low-beam bulb (Xenon fusion bulb) You cannot replace the low beam bulbs by yourself. The bulbs must be replaced at an Authorized Mazda Dealer. Maintenance and Care Owner Maintenance (Halogen bulbs) 1. Detach the electrical connector from the sealing cover by pulling it to the rear.
Page 300 Fog Light Bulb Due to the complexity and difficulty of the procedure, the bulbs should be replaced by an Authorized Mazda Dealer. qReplacing a Bulb (Front) 1. If you are changing the right bulb, start the engine, turn the steering wheel all the way to the right, and turn off engine.
Page 301 qReplacing a Bulb (Interior) Overhead light/Map lights (Front) 1. Remove the screws with a Phillips screwdriver. 2. Wrap a flathead screwdriver with a soft cloth to prevent damage to the trim and gently insert it in the overhead light as shown in the figure, and then remove the overhead light unit.
Page 302 Rear turn signal lights Brake lights/Taillights Reverse lights 4. Install the new bulb in the reverse order of removal. Rear side-marker lights Due to the complexity and difficulty of the procedure, the bulbs should be replaced by an Authorized Mazda Dealer.
Page 303 High-mount brake light 1. Turn the center section of the plastic retainer counterclockwise and remove the retainers and trunk rear trim. Removal Installation 2. Turn the socket and bulb assembly counterclockwise and remove it. 3. Disconnect the bulb from the socket. 4.
Page 304: Fuses
If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. qFuse Replacement Replacing the fuses on the driver's side If the electrical system does not work, first inspect the fuses on the driver's side.
Page 305 Normal WARNING Do not replace the main fuse by yourself. Have an Authorized Mazda Dealer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse. Incorrect...
Page 306 Maintenance and Care Owner Maintenance qFuse Panel Description Fuse block (Engine compartment) DESCRIPTION MAIN HEATER AIR PUMP DEFOG ABS/DSC HEAD HEAD LOW R HEAD LOW L SEAT WARM H/CLEAN R.FOG í 8-36 Some models. (Next to air filter) (Near battery) FUSE PROTECTED COMPONENT RATING...
Page 307 DESCRIPTION A/C MAG IG KEY STOP FUEL PUMP HORN HAZARD WIPER P.WIND ENGINE TAIL ILLUMI EGI COMP1 EGI COMP2 EGI INJ FUSE PROTECTED COMPONENT RATING í Fog lights Air conditioner For protection of various circuits For protection of various circuits Brake lights Fuel pump Horn...
Page 308 Maintenance and Care Owner Maintenance Fuse panel (Driver's side) DESCRIPTION CIGAR AUX PWR METER SPARE SPARE M.DEF AUDIO D.LOCK P.WIND ROOM SPARE SPARE í 8-38 Some models. FUSE PROTECTED COMPONENT RATING Lighter 7.5A Audio system, Power control mirror Accessory socket 7.5A Air conditioner Instrument cluster...
Page 309: Appearance Care
Prevention It is necessary to have your Mazda washed and waxed to preserve its finish according to the instructions in this section. This should be done as soon as possible.
Page 310 This increases the chance of paint chipping. Chipped paint can lead to rust forming on your Mazda. Before this happens, repair the damage by using Mazda touch-up paint according to the instructions in this section. Failure to repair the affected area could lead to serious rusting and expensive repairs.
Page 311: Exterior Care
Cleansers or wax containing abrasives are used. NOTE Mazda is not responsible for scratches caused by automatic car washes or improper washing. Scratches are more noticeable on vehicles with darker paint finishes.
Page 312 Exposed metal quickly rusts and can lead to major repairs. CAUTION If your Mazda is damaged and needs metal parts repaired or replaced, make sure the body shop applies anti-corrosion materials to all parts, both repaired and new. This will prevent them from rusting.
Page 313 qUnderbody Maintenance Road chemicals and salt used for ice and snow removal and solvents used for dust control may collect on the underbody. If not removed, they will speed up rusting and deterioration of such underbody parts as fuel lines, frame, floor pan, and exhaust system, even though these parts may be coated with anti-corrosive material.
Page 314: Interior Care
Maintenance and Care Appearance Care Interior Care qDashboard Precautions Prevent caustic solutions such as perfume and cosmetic oils from contacting the dashboard. They'll damage and discolor it. If these solutions get on the dashboard, wipe them off immediately. CAUTION Do not use glazing agents. Glazing agents contain ingredients which may cause discoloration, wrinkling, cracks and peeling.
Page 315 After cleaning the belts, thoroughly dry the belt webbing and make sure there is no remaining moisture before retracting them. WARNING Have an Authorized Mazda Dealer replace damaged seat belts immediately: Using damaged seat belts is dangerous. In a collision, damaged belts cannot provide adequate protection.
Page 316 8-46...
Page 317: Customer Information And Reporting Safety Defects
Mazda Importer/Distributors ... 9-8 Importer/Distributor ... 9-8 Distributor in Each Area ... 9-8 Warranty ... 9-9 Warranties for Your Mazda ... 9-9 Outside the United States ... 9-10 Outside Canada ... 9-11 Registering Your Vehicle in A Foreign Country (Except United States and Canada) ...
Page 318: Customer Assistance
1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 319: Customer Assistance (Canada)
3. Vehicle Identification Number (17 digits, noted on your registration or title or located on the upper driver's side corner of the dash) 4. Purchase date and current mileage 5. Your dealer's name and location 6. Your question(s) If you live outside the U.S.A., please contact your nearest Mazda Distributor.
Page 320: Customer Assistance (Puerto Rico)
Your complete and permanent satisfaction is of primary concern to Mazda. All Authorized Mazda Dealers have both the knowledge and tools to keep your Mazda in top condition. In our experience, any questions, problems, or complaints regarding the operation of your Mazda or any other general service transactions are most effectively resolved by your dealer.
Page 321 If a specific item of concern arises, where a solution cannot be reached between an owner, Mazda, and/or one of it's dealers (that all parties cannot agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 322 Provincial Administrators may be reached locally as listed below: Province/Territory British Columbia & Yukon Territories Alberta & Northwest Territories Saskatchewan Atlantic Canada qRegional Offices REGIONAL OFFICES MAZDA CANADA INC. WESTERN REGION 8171 ACKROYD ROAD SUITE 2000 RICHMOND B.C. V6X 3K1 (604) 303-5670 MAZDA CANADA INC.
Page 323: Customer Assistance (Puerto Rico)
1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 324: Mazda Importer/Distributors
55 Vogell Road, Richmond Hill, Ontario, L4B 3K5 Canada TEL: 1 (800) 263-4680 (in Canada) (905) 787-7000 (outside Canada) qPUERTO RICO/U.S. Virgin Island Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936-2722 TEL: (787) 641-9300...
Page 325: Warranties For Your Mazda
Emission Defect Warranty Emission Performance Warranty California Emission Control Warranty (U.S.A. only) Emission Control Warranty (Canada only) Replacement Parts and Accessories Limited Warranty Tire Warranty NOTE Detailed warranty information is provided with your Mazda. Customer Information and Reporting Safety Defects Warranty...
Page 326: Outside The United States
We strongly recommend that you NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety requirements (CMVSS).
Page 327: Outside Canada
We strongly recommend that you NOT take your Mazda outside Canada. However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with specific vehicle modifications to comply with the United States Federal Motor Vehicle Safety Standards (FMVSS).
Page 328: Registering Your Vehicle In A Foreign
Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 329: Add-On Non-Genuine Parts And Accessories
Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle's performance or safety systems;...
Page 330: Cell Phones
Customer Information and Reporting Safety Defects Cell Phones WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your country: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver's hands.
Page 331: Type Approval Of Equipment
Customer Information and Reporting Safety Defects Type Approval of Equipment Type Approval of Equipment Immobilizer system 9-15...
Page 332: Uniform Tire Quality Grading System
Customer Information and Reporting Safety Defects Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality Grading System (UTQGS) This information relates to the tire grading system developed by the U.S. National Highway Traffic Safety Administration for grading tires by tread wear, traction, and temperature performance.
Page 333 These grades will be added to the sidewalls of passenger vehicle tires over the next several years according to a schedule established by the NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicles may vary with respect to grade.
Page 334: Tire Information (U.s.a.)
Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Tire Labeling Federal law requires tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a tire identification number for safety standard certification and in case of a recall.
Page 335 11. Tread wear, traction and temperature grades 12. Max. permissible inflation pressure 13. SAFETY WARNING P215/65R15 95H is an example of a tire size and load index rating. Here is an explanation of the various components of that tire size and load index rating. Note that the tire size and load index rating may be different from the example.
Page 336 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) H is the speed rating. The speed rating denotes the maximum speed for which the use of the tire is rated. Letter Rating * For tires with a maximum speed capability over 149 mph, tire manufacturers sometimes use the letters ZR. For tires with a maximum speed capability over 186 mph, tire manufacturers always use the letters ZR.
Page 337 Tread Wear, Traction and Temperature Grades Tread wear: The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 338 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) qInformation on Temporary Tires Please refer to the diagram below. 1. Temporary tires 2. Nominal width of tire in millimeters 3. Ratio of height to width (aspect ratio) 4. Diagonal 5. Rim diameter code 6.
Page 339 70 is the aspect ratio. This two-digit number indicates the tire's ratio of height to width. D is the tire construction symbol. D indicates diagonal ply construction . 16 is the wheel rim diameter in inches. 90 is the Load Index. This two-or three-digit number indicates how much weight each tire can support.
Page 340: Location Of The Tire Label
Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Location of the Tire Label (Placard) You will find the tire label containing tire inflation pressure by tire size and other important information on the driver's side B-pillar or on the edge of the rear door on the driver's side. SAMPLE qRecommended Tire Inflation Pressure On the tire label you will find the recommended tire inflation pressure in both kPa and psi...
Page 341 WARNING Always check the tire inflation pressures on a regular basis according to the recommended tire inflation pressure on the tire label and in conjunction with the information in this owner's manual: Driving your vehicle with under-inflated tires is dangerous. Under-inflation is the most common cause of failures in any kind of tire and may result in severe cracking, tread separation or “blowout”, with unexpected loss of vehicle control and increased risk of injury.
Page 342 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) qGlossary of Terms Tire Placard: A label indicating the OE tire sizes, recommended inflation pressure, and the maximum weight the vehicle can carry. Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size, and date of manufacture.
Page 343: Tire Maintenance
Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Here are some important maintenance points: qTire Inflation Pressure Inspect all tire pressure monthly (including the spare) when the tires are cold. Maintain recommended pressures for the best ride, top handling, and minimum tire wear. Use the pressures specified on the vehicle tire information placard or tire label for optimum service.
Page 344 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) CAUTION Rotate unidirectional tires and radial tires that have an asymmetrical tread pattern or studs only from front to rear, not from side to side. Tire performance will be weakened if rotated from side to side. (With limited-slip differential) Don't use the following: Ø...
Page 345 qSafety Practices The way you drive has a great deal to do with your tire mileage and safety. So cultivate good driving habits for your own benefit. Observe posted speed limits Avoid fast starts, stops and turns Avoid potholes and objects on the road Do no run over curbs or hit the tire against the curb when parking CAUTION If you feel a sudden vibration or ride disturbance while driving or you suspect your...
Page 346: Vehicle Loading
Customer Information and Reporting Safety Defects Tire Information (U.S.A.) WARNING Do not taw a trailer with this vehicle: Towing a trailer with this vehicle is dangerous because it has not been designed to tow a trailer and doing so will affect the drive system which could result in vehicle damage.
Page 347 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Base Curb Weight is the weight of the vehicle including a full tank of fuel and all standard equipment. It does not include passengers, cargo, or optional equipment. Vehicle Curb Weight is the weight of your new vehicle when you picked it up from your dealer plus any aftermarket equipment.
Page 348 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) SAMPLE CARGO Cargo Weight includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight.
Page 349 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Examples: Based on a single occupant weight of 68 kg (150 lbs), and a value of 385 kg (849 lbs) for the combination weight of occupants and cargo should never exceed : The cargo weight limit with one occupant is 385 kg (849 lbs) _ 68 kg (150 lbs) = 317 kg (699 lbs) The cargo weight limit with two occupants is 385 kg (849 lbs) _ (68 ×...
Page 350 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) SAMPLE WARNING Exceeding Axle Weight Rating Limits: Exceeding the Safety Certification Label axle weight rating limits is dangerous and could result in death or serious injury as a result of substandard vehicle handling, performance, engine, transmission and/or structural damage, serious damage to the vehicle, or loss of control.
Page 351 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) GCW (Gross Combination Weight) is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combination Weight Rating) is the maximum allowable weight of the vehicle and the loaded trailer - including all cargo and passengers - that the vehicle can handle without risking damage.
Page 352 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) WARNING Exceeding GVWR or GAWR Specifications: Exceeding the GVWR or the GAWR specified on the certification label is dangerous. Exceeding any vehicle rating limitation could result in a serious accident, injury, or damage to the vehicle.
Page 353: Steps For Determining The Correct Load Limit
Steps for Determining the Correct Load Limit: Steps for Determining Correct Load Limit: (1) Locate the statement The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs on your vehicle's placard. (2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.
Page 354: Reporting Safety Defects
7755 Irvine Center Drive Irvine, California 92618-2922 P.O. Box 19734 Irvine, CA 92623-9734 Customer Assistance Center or toll free at 1 (800) 222-5500 If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown (page 9-8) in this booklet. 9-38...
Page 355: Reporting Safety Defects (Canada)
Customer Information and Reporting Safety Defects Reporting Safety Defects Reporting Safety Defects (Canada) Canadian customers who wish to report a safety-related defect to Transport Canada, Defect Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330 Sparks Street, Ottawa ON K1A 0N5.
Page 356: Service Publications
Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair. When requesting any of our publications through an Authorized Mazda Dealer, refer to the chart below. If they don't have what you need in stock, they can order it for you.
Page 357 Customer Information and Reporting Safety Defects Service Publications qNAVIGATION SYSTEM OWNER'S MANUAL: This booklet contains information regarding the proper operation and use of the navigation system. This is not a technician's manual. 9-41...
Page 358 9-42...
Page 359: Specifications
Specifications Technical information about your Mazda. Identification Numbers ... 10-2 Vehicle Information Labels ... 10-2 Specifications ... 10-4 Specifications ... 10-4 10-1...
Page 360: Identification Numbers
Identification Numbers Vehicle Information Labels qVehicle Identification Number The vehicle identification number legally identifies your vehicle. The number is on a plate attached to the left top side of the dashboard. This plate can easily be seen through the windshield. qMotor Vehicle Safety Standard Label 10-2 qChassis Number...
Page 361 Identification Numbers qEngine Number Forward 10-3...
Page 362 Quality Lubricant Engine oil Manual transmission oil Automatic transmission fluid Rear differential oil Brake/Clutch fluid * Not available from Mazda 10-4 Specifications Model Rotary engine 654 ml × 2 (654 cc × 2, 40.0 cu in × 2) 10.0...
Page 363 qCapacities (Approximate Quantities) Item With oil filter replacement Engine oil Without oil filter replacement Coolant Manual transmission oil Automatic transmission fluid Rear differential oil Fuel tank Check oil and fluid levels with dipsticks or reservoir gauges. qDimensions Item Overall length Overall width Overall height Front tread...
Page 364 NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer. í...
Page 365 Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation Pressure on page 8-22. Tire size 225/55R16 94V 225/45R18 91W Vehicle capacity weight: 308 kg (680 lbs) qFuses Refer to the fuse rating on page 8-34. Inflation pressure Front 220 kPa (32 psi)
Page 366 10-8...
Page 367: Index
Index 11-1...
Page 368 Index Accessory Socket ... 6-53 Add-On Non-Genuine Parts and Accessories ... 9-13 Advanced Key ... 3-2 Advanced key maintenance ... 3-5 Advanced key suspend function ... 3-16 Auxiliary key ... 3-15 Locking, unlocking with request switch ... 3-8 Opening the trunk lid with request switch ...
Page 369 Child Restraint Child restraint precautions ... 2-20 Installing child-restraint systems ... 2-24 LATCH child-restraint systems ... 2-30 Cigarette Lighter ... 6-47 Climate Control System ... 6-2 Gas specifications ... 10-5 Clock ... 6-46 Coin Box ... 6-50 Courtesy Lights ... 6-44 Cruise Control ...
Page 370 Index Front Seats (Manually Operated Seats) ... 2-2 Fuel Filler lid and cap ... 3-37 Gauge ... 5-36 Requirements ... 4-2 Tank capacity ... 10-5 Fuses ... 8-34 Panel description ... 8-36 Replacement ... 8-34 Gauges ... 5-33 Glove Box ... 6-50 Hazard Warning Flasher ...
Page 371 Lane-Change Signals ... 5-57 Light Bulbs Replacement ... 8-27 Specifications ... 10-6 Lighter ... 6-47 Lighting Control ... 5-55 Lubricant Quality ... 10-4 Maintenance Introduction ... 8-2 Owner maintenance precautions... 8-9 Owner maintenance schedule ... 8-8 Scheduled ... 8-3 Manual Transmission Operation ... 5-10 Recommendations for shifting...
Page 372 Index Seats Front seat (Electrically operated seats) ... 2-5 Front seat (Manually operated seats) ... 2-2 Rear seat ... 2-8 Seat warmer ... 2-8 Security System Immobilizer system (with advanced key) ... 3-41 Immobilizer system (without advanced key) ... 3-43 Service Publications ...
Page 373 Vehicle Information Labels ... 10-2 Warning Lights ... 5-39 ABS ... 5-41 Air bag system ... 5-44 Automatic transmission ... 5-46 Brake system ... 5-41 Charging system ... 5-42 Check engine ... 5-43 Door-ajar ... 5-45 Engine coolant level ... 5-43 Engine oil level ...
Page 374 11-8...
Page 375: Navigation System
Immediate use See page for specific information. Advanced use See page for specific information. If necessary See page for specific information. ©2007 Mazda Motor Corporation Printed in Japan May 2007(Print1) Before Use Getting started Routing Address Book Volume Adjustment...
Page 376: Accessories
Accessories Please contact an Authorized Mazda Dealer if you are missing the following accessory. lMap Disc CAUTION: THIS PRODUCT IS A CLASS I LASER PRODUCT. HOWEVER THIS PRODUCT USES A VISIBLE/ INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED.
Page 377 MEMO...
Page 378 Contents Preparation Before Use Accessories... 2 Laser products: ... 2 Contents ... 4 Safety Information ... 6 Introduction ... 8 (Use This Product Safety), (Navigation System), (Screens), (LCD (Liquid crystal display)) Names and Functions ... 10 Immediate use Getting started Activation...
Page 379 Advanced use Address Book Address Book ... 46 (Memory Point Storage), (Memory Point Confirmation and Modification), (Preset Destinations or Home storage), (Memory Point Deletion), (All Memory Point Deletion), (Displays Icons at Memory Points), (Avoid Area Storage), (Avoid Area Confirmation and Modification), (Avoid Area Deletion), (All Avoid Area Deletion), (Category Name Modification), (Previous Destination Deletion), (All Preset Destination Deletion)
Page 380: Safety Information
Expert dealer, we recommend an Authorized Mazda Dealer. Using the unit in an out-of-order condition may lead to accidents, fires, or electric shocks.
Page 381 This navigation system is designed exclusively for use in automobiles. This navigation system should only be installed in an automobile. Do not install it in a ship, aircraft, or any other vehicles except an automobile. Do not use it detached from the vehicle.
Page 382: Navigation System
If the system does not operate thereafter, consult an Authorized Dealer, we recommend an Authorized Mazda Dealer. This navigation system utilizes GPS* satellite signals, a speed sensor and gyrosensor to track and display your vehicle’s current position, and to guide you from your starting point to your...
Page 383 MEMO...
Page 384: Names And Functions
Names and Functions Mazda 3 Joystick lSelects items ENTER by tilting it up, down, right, and left. lScrolls map. RET key Returns to the previous screen. VOICE key lInitiates vocal guidance for route VOICE maneuvers. lAdjusts screen quality. page 28)
Page 385: Enter Key
POS (Position) key Displays your current position. ENTER key ENTER lExecutes a selected item. lDisplays pop up menu. MENU key Displays menu. MENU page 16) ZOOM key Changes the map scale. ZOOM page 29) DIM key Switches the display to day mode or night mode.
Page 386 Names and Functions Mazda RX-8 MENU key Displays menu. MENU page 16) VOICE key lInitiates vocal guidance for route VOICE maneuvers. lAdjusts screen quality. page 28)
Page 387 Joystick lSelects items ENTER by tilting it up, down, right, and left. lScrolls map. POS (Position) key Displays your current position. ZOOM key Changes the map scale. ZOOM page 29) ENTER key ENTER lExecutes a selected item. lDisplays pop up menu. RET key Returns to the previous screen.
Page 388: Activation
1 hour. Wipe the condensation off the map disc with a soft cloth. If the unit does not operate correctly after 1 hour, consult an Authorized Mazda Dealer. TILT When the TILT...
Page 389 Read CAUTION carefully, and select and press ENTER lThe Current Position screen appears. Note lYou can select the language by select selected language using Language Selection. ( lThe CAUTION screen remains on the display unless you select Removing the Map Disc When the ignition switch is in the ACC position and press EJECT Select the buttons by using Joystick and press...
Page 390: Menu
Menu Menu appears when pressing MENU Destination Entry and Route Search ( Address Book ( page 46) Cancel Guidance ( page 41) Route Options ( page 42) Volume ( page 50) Set Clock ( page 17) Navigation Set Up ( page 18) page 30)
Page 391: Set Clock
Set Clock The current time is set using this function. Since time notification is provided by a GPS satellite. Before Steps MENU Open the [SET CLOCK] screen Select 12-hour display. Select and similarly, select hour. How to exit Note Minutes and seconds are adjusted by the GPS, however, it is necessary to adjust hours under the following conditions: lDriving across different time zones lDaylight saving time start and end...
Page 392: Navigation Set Up
Navigation Set Up lYou can alter the map display conditions, the route guidance conditions and show the system information. Stop your vehicle before the following operations. Do not change the settings and destination locations while driving. Minimize the time spent viewing the monitor screen and listening to the voice guidance while driving. Warning Operating the system will distract the driver from looking ahead of the vehicle and may cause an accident.
Page 393: User Settings
Navigation Set Up MENU Before Steps ENTER Open the [USER SETTINGS] screen select ENTER select Map Color Select a screen color from Map Mode Auto : The display will automatically switch between Day and Night illumination mode when the headlights are turned off and on respectively.
Page 394 Navigation Set Up MENU Before Steps Open the [USER SETTINGS] screen select ENTER select ENTER Arrival Time The time which is displayed until reaching the destination or a way point can be set as an estimated arrival time or the remaining time.
Page 395: Quick Poi Selection
Navigation Set Up This function allows you set the categories on the area displayed when the (Point of Interest) menu is selected on the map. Quick POI enables you store up to six different kinds of categories which you use most regularly. MENU ENTER select...
Page 396 Navigation Set Up Language You can change the language of the menu and the voice guidance. select MENU ENTER ENTER Before Steps select ENTER ENTER Open the [LANGUAGE] screen Select your preferred language from the list.
Page 397: Map Screen
Navigation Set Up MENU Before Steps ENTER Open the [MAP CONFIGURATION] screen Map Configuration select ENTER select Map Screen Select single or dual map display. Single map Turn Guidance Turn Arrow (on first screen) While using route guidance, the directions for the next junction where you have to turn are shown as a Turn Arrow in the upper right.
Page 398 Navigation Set Up This function allows you to correct any error in the position or direction of your vehicle display. Before Steps MENU Adjusting Current Position and Direction select ENTER Open the [Calibrate Position] screen Distance This function automatically corrects any error in the display of the current position that might occur after tire replacement.
Page 399 select ENTER ENTER ENTER Map Version The map and software version numbers can be confirmed using this function. select ENTER ENTER Map and software versions are now displayed.
Page 400: Restore System Defaults
Navigation Set Up This function replaces all the settings in the mobile navigation system with the initial default settings. Before Steps Open the [SYSTEM DEFAULTS] screen If you execute Restore System Defaults, all of your stored setting data will be deleted. [Default List] Item Menu names...
Page 401: Screens During Route Guidance
Screen Names and Functions Screens Before Setting Route ENTER Returns after a few seconds. (1) Map Orientation control page 29) (2) GPS (Global Positioning System) marker page 52) (3) Clock Clock will be displayed when you set up Clock on Navigation Set Up On. (4) Vehicle marker Shows the current position and direction of your vehicle.
Page 402: Screen Adjustments And Settings
This selection can only be done when the headlights are on. Press to switch between day and night modes. ENTER lThe screen can be returned to the daytime screen while the headlights or running lights are . (Mazda 3 only) on using Screen adjustments and settings and the screen will disappear.
Page 403: Screen Change
Screen change Do not keep your eyes fixed on the monitor screen or operate the system while driving Do not change the settings and destination locations while driving. Minimize the time Warning spent viewing the monitor screen and listening to the voice guidance while driving. Operating the system will distract the driver from looking ahead of the vehicle and may cause an accident.
Page 404: Destination Entry And Route Search
Destination Entry and Route Search lYou can set the destination using various methods provided by the system. Before Steps MENU Open the [DESTINATION ENTRY] Menu Change (Change Search Area) Open the [DESTINATION ENTRY] Menu Address select ENTER Select Select When narrowing down to city name Select When narrowing...
Page 405 Do not keep your eyes fixed on the monitor screen or operate the system while driving. Do not change the settings and destination locations while driving. Minimize the time spent viewing the monitor screen and listening to the voice guidance while driving. Operating the system Warnings will distract the driver from looking ahead of the vehicle and may cause an accident.
Page 406 Destination Entry and Route Search Open the [DESTINATION ENTRY] Menu Point of interest When entering Select the destination point directly Select When narrowing down to city name Select When narrowing down to category name Select When narrowing down to the nearest facility Select When narrowing...
Page 407 Cancel the city selection. Select the city name Displays list from the of 5 city list names nearest the current position. Enter the Select the city name city name Displays the and select from the city name list input screen. Select the category name from...
Page 408 Destination Entry and Route Search Select When stopped Displays the police station select screen. Displays the hospital select screen. Emergency When driving Sets the destination to the nearest police station automatically. Sets the destination to the nearest hospital automatically.
Page 409 Select the sort methods : Sorts the police station or the hospital by Distance. : Sorts the police station or the hospital by name. Select the name from Select the list...
Page 410 Destination Entry and Route Search Before Steps MENU Open the [DESTINATION Memory Point ENTRY] Menu Home Preset Destination Previous Destination Intersection Freeway On/ Off Ramp Coordinates Select from select ENTER Select Select Select Select Select Select Select Select...
Page 411 Select the desired Memory Point : Display up to five previous suggestions. : Display the five previous suggestions. : The order of the displayed list can be changed. Select the desired Preset Destination. Select the Previous Destination. Enter/Select the Enter/Select the 2nd 1st street name street name Enter/Select the...
Page 412: Local Search
Quick POI lYou can select one of the Six Categories on the menu or List Categories and then select the POI(s) to be displayed on the map. Before Steps ENTER Open the [QUICK POI] Displaying POI(s) on a Local Search Deleting Markers Displaying POI(s) on a Map (...
Page 413: Character Entry
Character Entry Select the first several characters on the screen. (Step 1) Select To enter the street name, city name, and : Move the cursor to the previous other. position and delete a character. : The list appears. Examples Street: CANAL Enter by selecting characters: Street: MAIN STREET Enter by selecting characters:...
Page 414: Direct Destination Input
Direct Destination Input Direct Destination Input Operate after Step 3 of [Direct Destination Input] Selecting Route Position the ENTER cursor on your destination on the map Scroll the map and change the map scale if necessary. ENTER Select ENTER Select Route calculation will be carried out and the entire route will be displayed on the map.
Page 415: Poi Icons On Maps / Delete Destination
Chinese Continental Fast Food French Italian Japanese Mexican Seafood Thai Other Restaurants Shopping Grocery Store Shopping Mall Automotive Automobile Club Gas Station Parking Auto Service & Maintenance Delete MENU destination ENTER Travel Bus Station Ferry Terminal Hotel Rental Car Agency...
Page 416: Route Options
Route Options Before Steps MENU Open the [ROUTE OPTIONS] Menu Route Preferences Modification of Destination or Way Point Positions Deletion of Destination or Way Points Detour Turn List lDuring route guidance you can change the route options, stop or check the route. select ENTER Select...
Page 417 Do not keep your eyes fixed on the monitor screen or operate the system while driving Do not change the settings and destination locations while driving. Minimize the time spent viewing the monitor screen and listening to the voice guidance while driving. Operating the system Warning will distract the driver from looking ahead of the vehicle and may cause an accident.
Page 418 Route Options Before Steps MENU Open the [ROUTE OPTIONS] Menu Display Preview Route Preview select ENTER Select ENTER Select...
Page 419 Use the buttons displayed on-screen to carry out a simulation run. : Move the start point. : Carry out a simulation run in the direction of the start point. When the Simulation starts the button will be displayed as , and when selected, it will cause the Simulation to advance quickly. : Stop the simulation run.
Page 420: Address Book
Address Book Before Steps MENU Open the Memory Point [ADDRESS Storage BOOK] Memory Point Confirmation Modification Preset Destinations or Home storage Memory Point Deletion All Memory Point Deletion Displays Icons at Memory Points lYou can, edit, or delete any marked point. select ENTER Select...
Page 421 Set a memory point using your preferred method. Select a memory point to be modified Select a memory point to be stored Allows the storage in Preset category to be changed. Select the Destinations or button corresponding Home. to the new category. Select a memory point to be deleted.
Page 422: (Category Name Modification), (Previous Destination Deletion)
Address Book Before Steps MENU Open the Avoid Area [ADDRESS Storage BOOK] Avoid Area Confirmation Modification Avoid Area Deletion All Avoid Area Deletion Category Name Modification Previous Destination Deletion All Preset Destination Deletion select ENTER Select Select...
Page 423 Select an avoid area using your preferred method. Select an avoid area to be modified. Select an avoid area to be deleted. Cancel the deletion. Select a destination to be deleted. : The order of the displayed list can be changed.
Page 424: Volume Adjustment
Volume Adjustment You can adjust the volume control for the voice guidance. Before Steps Open the [VOLUME] screen select MENU ENTER Select the appropriate button to set the volume between (maximum). :Sound output will be muted. Press the current vehicle position screen. ENTER (minimum) and button to return to the...
Page 425: Voice Guidance
Precautions/System Performance The navigation system is just a support system for the driver. The driver should always pay attention to the traffic situation to safely make decisions. You may be unable at times to arrive at your destination due to out-of-date information Warnings on a map disc.
Page 426: Map Matching
lIf you are using the system for the first time, or if you have not used it for some time, it takes about 5 minutes (or about 2 minutes in open areas) to calculate your vehicle’s position. GPS signal reception is poor in the following places In tunnels lThe GPS satellites are controlled by the U.S.
Page 427: Positioning Accuracy
Precautions/System Performance In the following situations, your vehicle position may not be displayed correctly on the map. But, as you keep driving, your vehicle position will be automatically corrected utilizing map matching and GPS data. Running on an Making a turn after elevated road driving on a long straight road...
Page 428: Route Search
The navigation system is just a support system for the driver. The driver should always pay attention to the traffic situation to safely make decisions. You may be unable to arrive at your destination due to out-of-date information on a map disc. You should be especially careful Warning when selecting an urgent destination such as a hospital or a police station.
Page 429: Troubleshooting
There may be some problems due to operational errors or mistakes. Please read this manual again and verify that there really is a problem before calling an Expert Dealer, we recommend an Authorized Mazda Dealer to ask for repair services. Symptom No picture lCheck if a fuse has blown.
Page 430 Symptom No GPS symbols are displayed The vehicle position is not displayed No voice guidance Buttons on the remote control do not beep Check point lGPS signals may not be received because of obstructions. After moving the vehicle away from obstructions, the GPS signals can be received.
Page 431: Error Messages
Troubleshooting Error message lThe disc is not installed. Please insert a MAP DVD. MAP DVD-Read Error lThe disc is wet, dirty, scratched, or upside down, or the disc The disc installed is not a MAP DVD. Solution Check if the disk is installed. If installed, check if the installed disk is correct.
Page 432: Maintenance
Never use solvents such as benzene and thinners, they could mar the surface of the unit. Map disc If you require the latest map disc, consult an Expert Dealer, we recommend an Authorized Mazda Dealer. How to hold the disc lDo not touch the underside of the disc.
