Page 1: Table Of Contents
Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems Auxiliary input jack (Line in) Satellite radio information Navigation system Climate Controls Dual automatic temperature control Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors...
Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Transmission operation Roadside Emergencies Hazard flasher switch Fuel pump/High voltage shut-off switches Fuses and relays Changing tires...
Page 3 Maintenance and Specifications Engine compartment Engine oil Battery Engine Coolant and Motor/Electronics Coolant Fuel information Air filter(s) Maintenance product specifications and capacities Engine data Accessories Service Maintenance Section Normal scheduled maintenance and log Special operating conditions and log Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from MNAO.
Page 4: Introduction
The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Mazda Motor Corporation and its products visit the following website: • In the United States: www.mazdausa.com •...
Page 5 WARNING: Fuel pump and high voltage battery shut-off switches: In the event of an accident the fuel pump shut-off switch may automatically cut off the fuel supply to the engine and the high voltage shut-off switch cuts off power from the high voltage battery.
Page 6 Introduction Drive your new vehicle at least 500 miles (800 km) before towing a trailer. For more detailed information about towing a trailer, refer to Trailer towing in the Tires, Wheels and Loading chapter. Do not add friction modifier compounds or special break-in oils since these additives may prevent piston ring seating.
Page 7 Introduction Stopping: The gas engine may shut off to conserve fuel as you come to a stop. Restarting the vehicle is not required. Simply step on the accelerator when you are ready to drive. Transmission Operation: Due to the technologically advanced, electronically controlled Continuously Variable Transaxle (eCVT) you will not feel shift changes like those of a non-hybrid vehicle.
Page 8 Introduction If the vehicle is left inoperative for over 31 days, it may be necessary to jumpstart the vehicle. For more information, refer to Jump starting your (Low voltage [underhood] battery only) in the Roadside Emergencies chapter. Engine: The engine speed in your hybrid is not directly tied to your vehicle speed.
Page 9 Driving to optimize fuel economy Your fuel economy should improve throughout your hybrid’s break-in period. As with any vehicle, fuel economy can be significantly impacted by your driving habits and accessory usage. For best results, keep in mind these tips: Tire Inflation: Keep tires properly inflated and only use recommended size.
Page 10 Introduction Frequently asked questions Question What is the pumping sound I hear when I unlock or enter the vehicle, and the venting sound a few minutes after shutting off my vehicle? What are the series of clicks from the cargo area when I first turn the key in the ignition? Why does the engine always start at key-on?
Page 11 Question Why does my engine never shut down above 40 mph (64 km/h)? Why does my engine stay ON when it’s extremely cold outside? Why does my engine rev up so high sometimes when I accelerate? What does it mean when my power assist gauge moves to the right? To the left? Introduction...
Page 12 Introduction Question What is the fan noise and slight tapping sound I hear from the rear of my hybrid? How far can I go in Electric Drive if I run out of gas? What is the engine oil change service interval? Can I put E10 or E85 in my vehicle, and how will it affect my fuel economy?
Page 13 Question Can you charge the battery with a plug into an A/C outlet? What is the purpose of the ECON button? Can I tow the hybrid behind my motor home with all four wheels down? SPECIAL NOTICES New Vehicle Limited Warranty For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, refer to the Warranty Information Booklet that is provided to you along with your Owner’s...
Page 14 In order to properly diagnose and service your vehicle, Mazda Motor Corporation, Mazda Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 15 To access this information, special equipment must be directly connected to the recording modules. Mazda Motor Corporation and Mazda Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority.
Page 16 Introduction These are some of the symbols you may see on your vehicle. Safety Alert Protecting the Environment Airbag - Front Passenger Airbag Off Child Seat Tether Anchor Anti-Lock Brake System Brake Fluid - Non-Petroleum Based Stability Control System Hazard Warning Flasher Fuse Compartment Windshield Wash/Wipe Vehicle Symbol Glossary...
Page 17 Passenger Compartment Air Filter Check Fuel Cap INFORMATION ABOUT THIS GUIDE The information found in this guide was accurate at the time of printing. Mazda may change the contents without notice. Vehicle Symbol Glossary Power Windows Personal Alarm System Feature...
Page 18: Instrument Cluster
Instrument Cluster Instrument cluster (pg. 20) Multi-function lever (pg. 58) Hazard flasher control (pg. 202) Headlamp control (pg. 47) Steering wheel controls* (pg. 72) Speed controls* (pg. 69) Hood release Parking brake release (pg. 249) (pg. 189) * if equipped...
Page 19 Instrument Cluster Climate controls Audio system (pg. 42) (pg. 27) Auxiliary input jack (pg. 35) Auxiliary power point (pg. 61) *if equipped...
Page 20: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a safety hazard or a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions.
Page 21 WARNING: Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Service engine soon warning light to come on, refer to Fuel filler cap in the...
Page 22 Instrument Cluster Airbag readiness: If this light fails to illuminate when the ignition is turned to RUN, continues to flash or remains on, have the system serviced immediately by your authorized dealer. A chime will also sound when a malfunction in the supplemental restraint system has been detected.
Page 23 Engine oil pressure: Illuminates when the oil pressure falls below the normal range, refer to Engine oil in the Maintenance and Specifications chapter. Engine or motor electronic coolant temperature: Illuminates when the coolant temperature exceeds the threshold. When the light is flashing or remains on, stop the vehicle as soon as possible, switch off the engine and let cool.
Page 24 Instrument Cluster Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter). Speed control: Illuminates when the speed control is engaged. Turns off when the speed control system is disengaged.
Page 25: Gauges
Instrument Cluster Transmission not in park chime: Sounds when the PRNDL is not in P (Park) position, the driver’s door is ajar and the ignition is in the RUN position. HEV Engine off Reminder Chime: Sounds for 10 seconds when the PRNDL is in the P (Park) position and the Driver’s door is ajar (open) while ignition is in the RUN position.
Page 26 Instrument Cluster Battery gauge: Provides information about the vehicle’s energy usage. • ASSIST — Battery provides extra power to boost the vehicle’s acceleration. • CHARGE — Storing extra energy in the battery when coasting or slowing down. Odometer: Registers the total miles (kilometers) of the vehicle.
Page 27: Entertainment Systems
AUDIO SYSTEMS AM/FM/single CD/in-dash CD6/MP3 satellite compatible sound system Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window switches, radio and moon roof (if equipped) may be used for up to ten minutes after the ignition is turned off or until either front door is opened.
Page 28 Entertainment Systems For a CD6 system, press EJECT and select the desired CD slot by pressing the corresponding memory preset #. The display will read EJECTING #. When the system has ejected the CD, the display will read REMOVE CD #. Remove the CD. If you do not remove the CD the system will reload the disc.
Page 29 FADE: Press SOUND repeatedly to reach the fade setting. Press SEEK/TRACK and front (F) speakers. SPEED COMPENSATED VOLUME (if equipped): Press SOUND repeatedly to reach the SPEED COMPENSATED VOLUME setting. Radio volume automatically gets louder with increasing vehicle speed to compensate for road and wind noise.
Page 30 Entertainment Systems display. After a category is selected, press SEEK to search for that specific category of channels only (i.e. ROCK). You may also select CATEGORY ALL to seek all available SIRIUS categories and channels. Press OK to close and return to the main menu. •...
Page 31 stations without losing your original manually set preset stations for AM/FM1/FM2. To activate the autoset feature, toggle AUTOSET to ON, and either wait five seconds for the search to initiate or press OK to immediately initiate the search. (If you press another control within those five seconds, the search will not initiate.
Page 32 Entertainment Systems 9. SAT (Satellite Radio, if equipped): Press SAT to access satellite radio mode, if equipped. Press repeatedly to cycle through SAT1, SAT2 and SAT3 modes. 10. CD: Press to enter CD/MP3 mode. If a disc is already loaded into the system, CD/MP3 play will begin where it ended last.
Page 33 In MP3 mode, press FOLD and then press previous/next folder. In satellite radio mode (early availability — if equipped), use to select from various satellite radio categories. To change categories in satellite radio mode, press CAT/FOLD. The active category will appear in the display.
Page 34 Entertainment Systems For a CDX6 system, the system will shuffle between all loaded discs. The disc # will appear in the top left hand corner of the display. 16. SCAN: In radio mode, press for a brief sampling of all strong radio stations.
Page 35: Auxiliary Input Jack (Line In)
will prompt you to load discs for the remaining available slots. Insert the discs, one at a time, label side up, when prompted. Once loaded, the disc in preset #1 will begin to play. 19. CD slot: For a single CD system, insert a CD/MP3, label side up.
Page 36 Entertainment Systems 3. Attach one end of the audio extension cable to the headphone output of your player and the other end of the audio extension cable to the AIJ in your vehicle. 4. Turn the radio on, using either a tuned FM station or a CD loaded into the system.
Page 37 GENERAL AUDIO INFORMATION Radio frequencies: AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM: 530, 540–1700, 1710 kHz FM: 87.7, 87.9–107.7, 107.9 MHz Radio reception factors: There are three factors that can affect radio reception: •...
Page 38: Satellite Radio Information
CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Mazda CD players. Do not use any irregular shaped CDs or discs with a scratch protection film attached.
Page 39 Mazda Motor Corporation shall not be responsible for any such programming changes. Satellite Radio Electronic Serial Number (ESN): This 12–digit Satellite Serial Number is needed to activate, modify or track your satellite radio account.
Page 40 Entertainment Systems Radio Display ACQUIRING SAT FAULT INVALID CHNL UNSUBSCRIBED NO TEXT Condition Radio requires more than two seconds to produce audio for the selected channel. Internal module or system failure present. Channel no longer available. Subscription not available for this channel.
Page 41: Navigation System
Radio Display NO TEXT NO TEXT NO SIGNAL UPDATING CALL SIRIUS 1–888–539–7474 NAVIGATION SYSTEM (IF EQUIPPED) Your vehicle may be equipped with a Navigation System. Refer to the Navigation supplement for further information. Entertainment Systems Condition Song title information not available. Category information not available.
Page 42: Climate Controls
Climate Controls DUAL AUTOMATIC TEMPERATURE CONTROL 1. AUTO/Driver temperature: Press to engage full automatic operation. The system will automatically determine fan speed, airflow distribution, A/C on or off, and outside or recirculated air, to heat or cool the vehicle to reach the desired temperature. Turn to increase/decrease the temperature on the driver side of the vehicle.
Page 43 Defrost/Floor: Distributes air through the windshield defroster vents, demister vents, floor vents and rear seat floor vents. The system will automatically provide outside air to reduce window fogging. On days where the outside temperature is approximately freezing or higher, the engine will run continuously in this mode. Power/ : Press to activate/deactivate the climate control system.
Page 44 Climate Controls 12. ECON: Press to activate/deactivate economy air conditioning operation. ECON mode may provide improved fuel economy by preventing the gasoline engine from running for the sole purpose of providing A/C. When the gas engine turns off, the A/C compressor does not operate to cool the cabin and comfort may be reduced.
Page 45: Manual Operation
For maximum cooling performance: • Automatic operation: 1. Press AUTO for full automatic operation. 2. Do not override A/C or 3. Set the temperature to 60°F (16°C). Make sure ECON mode is deactivated. • Manual operation: 1. Select A/C. 2. Select 3.
Page 46: Rear Window Defroster
Climate Controls REAR WINDOW DEFROSTER The rear defroster control is located on the climate control panel and works to clear the rear window of fog and thin ice. The ignition must be in the 3 (RUN) position to operate the rear window defroster.
Page 47: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to turn on the headlamps. Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 48 Lights Autolamp delay system (if equipped) If your vehicle is equipped with autolamps, you can set the delay time to keep the headlights on for up to three minutes after the key is turned OFF. The delay time is set to 20 seconds at the factory, but the delay time may be changed by following the steps below (Steps 1 through 6 must be done within 10 seconds): 1.
Page 49 High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate. Flash to pass Pull toward you slightly to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) Turns the lowbeam headlamps on with a reduced output. To activate: •...
Page 50 Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parklamp operation. Move the control to the full upright position, past detent, to turn on the interior lamps. Rotate to full down position (past detent) to prevent interior lamps from illuminating when the doors...
Page 51: Turn Signal Control
3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood. Cover the left-hand headlamp with an opaque cloth. 4. On the wall or screen you will observe a light pattern with a distinct horizontal edge of high intensity light towards the right.
Page 52 Lights INTERIOR LAMPS Dome lamps and map lamps The front dome lamp is located overhead between the driver and passenger seats. The dome lamp control has three positions: • OFF: In this position, the lamp will not illuminate. • DOOR: In this position, the dome lamp will illuminate only when a door is opened and will remain illuminated for 25 seconds after...
Page 53: Bulb Replacement
Cargo and dome lamp Rear cargo lamp equipped with an ON/OFF/DOOR control will light when: • the doors are closed and the control is in the ON position. • the control is in the DOOR position and any door is open. When the control is in the OFF position, it will not illuminate when you open the doors.
Page 54 Lights Function Backup lamp Foglamp (front) Center High-mount stop lamp Rear license plate lamp All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your authorized dealer Replacing the interior bulbs Check the operation of all bulbs frequently. Replacing exterior bulbs Check the operation of all the bulbs frequently.
Page 55 When the grooves in the plastic base are aligned, turn the new bulb clockwise to install. Replacing front parking lamp/turn signal bulbs For bulb replacement, see your authorized Mazda dealer. Replacing tail/stop/turn/backup lamp bulbs The tail/stop/turn/sidemarker/backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other.
Page 56 Lights 7. Carefully install the tail lamp assembly on the vehicle and secure with two screws. Replacing license plate lamp bulbs 1. Make sure the headlamp switch is in the OFF position. 2. Depress the lever and carefully pry the license plate lamp assembly (located above the license plate) from the liftgate.
Page 57 3. Pull the bulb straight out of the socket and push in the new bulb. To complete installation, follow the removal procedure in reverse order. Replacing foglamp bulbs (if equipped) 1. Make sure the foglamp switch is in the OFF position. 2.
Page 58: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...
Page 59: Steering Wheel Adjustment
Rear window wiper/washer controls For rear wiper operation, rotate the rear window wiper and washer control to the desired position. Select: INT 2 — Normal speed operation of rear wiper. INT 1 — Intermittent operation of rear wiper. OFF — Rear wiper and washer off. For rear wash cycle, rotate (and hold as desired) the rear wiper/washer control to either position.
Page 60 Driver Controls WARNING: Adjusting the steering wheel while the vehicle is moving is dangerous. Moving it can very easily cause the driver to abruptly turn to the left or right. This can lead to loss of control or an accident. Never adjust the steering wheel while the vehicle is moving.
Page 61 Driver Controls The tray and inside bin can be removed to open up space to fit a laptop computer, MP3 players, CDs or handbags. To remove, open the console lid and pull the bin straight up and out from the console housing.
Page 62 Driver Controls The auxiliary power point is located in the instrument panel. A second auxiliary power point is located on the rear side of the center console. Do not use the power point for operating the cigarette lighter element (if equipped). To prevent the fuse from being blown, do not use the power point(s) over the vehicle capacity of 12 VDC/180W.
Page 63 Note: The 110 VAC power point is equipped with a safety cap and a safety twist tab. They both provide protection from inserting any object into the power point other than the 110 VAC electrical device plug. The safety cap should always be in a closed position whenever the power point outlet is not in use.
Page 64: Power Windows
Driver Controls Green light is On — Power point is ready to supply power Green light is Off — Power point power supply is off. Ignition is not in RUN position Green light is blinking — Power point is in fault mode POWER WINDOWS WARNING: Do not leave children unattended in the vehicle and do not let children play with the power windows.
Page 65 Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls (except for the driver’s) press the right side of the control. Press the left side to restore the window controls.
Page 66 Driver Controls Electronic compass (if equipped) The compass heading is displayed as one of N, NE, E, SE, S, SW, W and NW in the center stack display. The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy.
Page 67 4. Press and hold the reset button on the compass module for approximately 5 seconds until ZONE XX appears in the center stack display. 5. Continue to press the reset button until the correct zone appears in the center stack display. 6.
Page 68: Mirrors
Driver Controls EXTERIOR MIRRORS Power side view mirrors To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror. 2. Move the control in the direction you wish to tilt the mirror.
Page 69: Cruise Control
CRUISE CONTROL/SPEED CONTROL (IF EQUIPPED) With cruise control/speed control set, you can maintain a set speed without keeping your foot on the accelerator pedal. WARNING: Using cruise control in the following conditions could cause you to lose control of the vehicle: •...
Page 70 Driver Controls • If the vehicle speed decreases more than 10 mph (16 km/h) below your set speed on an uphill, your speed control will disengage. Disengaging speed control To disengage the speed control: • Depress the brake pedal Disengaging the speed control will not erase previous set speed. Resuming a set speed Press the RESUME control and release it.
Page 71 Reducing speed while using speed control There are three ways to reduce a set speed: • Press and hold the SET - control until you get to the desired speed, then release the control. • Press and release the SET - control to operate the Tap-Down function.
Page 72 STEERING WHEEL CONTROLS (IF EQUIPPED) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Mazda strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
Page 73: Moon Roof
In any mode: • Press VOL + or - to adjust the volume. MOON ROOF (IF EQUIPPED) WARNING: Do not let children play with the moon roof or leave children unattended in the vehicle. They may seriously hurt themselves. WARNING: When closing the moon roof, you should verify that it is free of obstructions and ensure that children and/or pets are not in the proximity of the moon roof opening.
Page 74: Message Center
Driver Controls If you open and close the moon roof repeatedly, the moon roof motor may overheat and shut down for 45 seconds while the motor cools. MESSAGE CENTER (IF EQUIPPED) With the ignition in the RUN position, the message center, located on your instrument cluster, displays important vehicle information through a constant...
Page 75 Distance to empty (DTE) Selecting this function from the INFO menu will give you an estimate of how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition OFF when refueling your vehicle. Otherwise, the display will not show the addition of fuel for a few miles (kilometers).
Page 76 Driver Controls Your vehicle must be moving to calculate instantaneous fuel economy. When your vehicle is not moving, this function shows , one or no bars illuminated. Instantaneous fuel economy cannot be reset. Electric Energy Select this function from the INFO menu for the state of charge of the high voltage battery.
Page 77 Pressing the RESET control cycles the message center through each of the systems being monitored. If you don’t press any button, the system will cycle itself. The sequence of the system check report is as follows: 1. Oil life 2. Electric drive 3.
Page 78 Driver Controls Units (English/Metric) 1. Select this function from the SETUP menu for the current units to be displayed. 2. Press the RESET control to change the message display from English to Metric. Autolamp delay This feature keeps your headlights on for up to three minutes after the ignition is switched off.
Page 79 Language 1. Select this function from the SETUP menu for the current language to be displayed. 2. Waiting 4 seconds or pressing the RESET control cycles the message center through each of the language choices. Selectable languages are English, Spanish, or French. 3.
Page 80 Driver Controls Warnings Stop safely now High engine temperature High motor temperature Park brake engaged XXX miles (km) to empty fuel level low Liftgate/Glass ajar Service brake system Low brake fluid Regen brakes disabled Low tire pressure Tire pressure monitor fault Tire pressure sensor fault XX% oil life change soon Oil change required...
Page 81 WARNING: When the engine and radiator are hot, scalding coolant and steam may shoot out under pressure and cause serious injury. Do not remove the cooling system cap when the engine and radiator are hot. HIGH MOTOR TEMPERATURE. Displayed when the motor electronics are overheating.
Page 82 Driver Controls Understanding Your Tire Pressure Monitoring System in the Tires, Wheels and Loading chapter. If the warning stays on or continues to come on, have the system inspected by your authorized dealer XX% OIL LIFE CHANGE SOON/OIL CHANGE REQUIRED. Displayed when the engine oil life remaining is 10% or less.
Page 83 CARGO AREA FEATURES Cargo shade (if equipped) If your vehicle has a cargo shade, you can use it to cover items in the cargo area of your vehicle. To install the shade: • Insert the ends of the cargo shade into the mounting features located behind the rear seat on the rear trim panels.
Page 84 Driver Controls LUGGAGE RACK Your vehicle is equipped with a roof rack. The maximum load for the roof rack is 100 lbs (44 kg), evenly distributed on the cross-bars. If it is not possible to evenly distribute the load, position it in the center or as far forward on the cross-bars as possible.
Page 85 2. Slide the cross-bar to the end of the rail. 3. Use a long, flat object to depress the tongue in the endcaps on both sides of the cross-bar. 4. Slide the cross-bar assembly off the end of the rail. To reinstall the cross-bar assembly (if equipped) to the roof rack side rails: 1.
Page 86: Locks And Security
Locks and Security KEYS Your vehicle is equipped with two Integrated Keyhead Transmitters (IKTs). The IKT functions as both a programmed ignition key that operates all the locks and starts the vehicle, and a remote keyless entry transmitter. Your IKTs are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start.
Page 87: Locks
POWER DOOR LOCKS • Press the control to unlock all doors. • Press the control to lock all doors. Door key unlocking/locking Unlocking the doors Turn the key in the door cylinder to unlock the driver’s door only. All other doors will remain locked. Locking the doors Turn the key in the door cylinder to lock the driver’s door only.
Page 88 Locks and Security REMOTE ENTRY SYSTEM (IF EQUIPPED) The Integrated Keyhead Transmitter (IKT) complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 89 2. Press and release again within three seconds to unlock the passenger doors, the liftgate and liftgate glass. The battery saver feature will turn off the interior lamps 10 minutes after the ignition is turned to the 1 (OFF/LOCK) position. One step door unlocking If the one step door unlocking feature is activated, press once to unlock all of the doors, the liftgate and liftgate glass.
Page 90 Locks and Security Sounding a panic alarm Press and hold for 1.5 seconds to activate the alarm. To deactivate the feature, press the control again, turn the ignition to the 3 (RUN) or 4 (START) position, or wait for the alarm to time out in approximately 3 minutes.
Page 91 Locks and Security Replacing lost Integrated Keyhead Transmitters (IKTs) If you would like to have your Integrated Keyhead Transmitters reprogrammed because you lost one, or would like to buy additional IKTs, you can either reprogram them yourself, or take all IKTs to your authorized dealer for reprogramming.
Page 92 Locks and Security • Tail lamps The lamps will automatically turn off: • if the ignition switch is turned to the 3 (RUN) position, or • the IKT (lock) control is pressed, or • after 25 seconds of illumination. Note: On some vehicles, the perimeter lamps illuminated entry feature will not activate in daylight conditions.
Page 93: Anti-Theft System
Note: The SecuriLock™ passive anti-theft system is not compatible with non-Mazda aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 94 Locks and Security If a problem occurs with the SecuriLock™ system, the indicator will flash rapidly or glow steadily when the ignition is in the 3 (RUN) position. If this occurs, the vehicle will not start and should be taken to an authorized dealer for service.
Page 95 portion of the IKT to your vehicle. Note: A maximum of eight coded keys can be programmed to your vehicle; only four of these eight can be IKTs with remote entry functionality. Tips: • Only use Integrated Keyhead Transmitters (IKTs) or standard SecuriLock™...
Page 96 Locks and Security 8. Turn the ignition from the 1 (LOCK) position to the 3 (RUN) position. Keep the ignition in the 3 (RUN) position for at least six seconds. 9. Remove the newly programmed coded key from the ignition. If the key has been successfully programmed it will start the vehicle’s engine and will operate the remote entry system (if the new key is an Integrated Keyhead Transmitter).
Page 97: Seating And Safety Restraints
FRONT SEATS Notes: WARNING: Reclining the seatback can cause an occupant to slide under the seat’s seat belt, resulting in severe personal injuries in the event of a collision. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop. WARNING: Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback.
Page 98 Seating and Safety Restraints Push side control and push down on head restraint to lower it. Adjusting the front manual seat (if equipped) Lift handle to move seat forward or backward. Pull lever up to adjust seatback.
Page 99 Seating and Safety Restraints Adjusting the front power seat (if equipped) WARNING: Never adjust the driver’s seat or seatback when the vehicle is moving. You could move out of position to control the vehicle. Then a serious accident could occur. Sudden braking or a collision could cause serious injury.
Page 100 Seating and Safety Restraints The control is located on the outboard side of the seat cushion. Move the front of the control up or down to raise or lower the front portion of the seat cushion. Move the rear of the control up or down to raise or lower the rear portion of the seat cushion.
Page 101 Seating and Safety Restraints REAR SEATS Head restraints The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 102 Seating and Safety Restraints 2. Place the head restraint under the front seat for storage. 3. Pull the seat release control. Note: Make sure the floor is clear of all objects before folding the seat. 4. Flip seat forward.
Page 103 Attach the seat belt web snap button to the quarter trim panel snap button. This will ensure that seat belt does not get caught by staying out of the seat back folding path. 5. To release seatback, pull the seatback release lever (on top of seat) toward the front seat.
Page 104 Seating and Safety Restraints Returning the rear seats to upright position 1. Pull seatback up and into upright position making sure seatback locks into place and the red seat unlatched indicator on release paddle is not visible. 2. Rotate seat cushion down into the seating position making sure that the seat cushion is locked into place and that the seat belt...
Page 105: Safety Restraints
WARNING: Remove the head restraint stored under the front set and return it to the original position on the seatback. Failure to do so could result in personal injury. 3. Unsnap the seat belt webbing from the quarter trim panel. To remove the rear cushion 1.
Page 106 Seating and Safety Restraints analyze different occupant conditions and crash severity before activating the appropriate safety devices to help better protect a range of occupants in a variety of frontal crash situations. Your vehicle’s Personal Safety System™ consists of: • Driver and passenger dual-stage airbag supplemental restraints •...
Page 107 Front crash severity sensor The front crash severity sensor enhances the ability to detect the severity of an impact. Positioned up front, it provides valuable information early in the crash event on the severity of the impact. This allows your Safety System to distinguish between different levels of crash severity and modify the deployment strategy of the dual-stage airbag and seat belt pretensioners.
Page 108 Seating and Safety Restraints technology, parents are STRONGLY encouraged to always properly restrain children in the rear seat. The sensor also turns off the passenger front airbag and seat-mounted side airbag (if equipped) when the passenger seat is empty to prevent unnecessary replacement of airbag(s) after a collision.
Page 109 seat belt pretensioners, front seat belt buckle sensors, driver seat position sensor, and front passenger sensing system. In addition, the RCM also monitors the restraints warning light in the instrument cluster. A difficulty with the system is indicated by one or more of the following. •...
Page 110 Seating and Safety Restraints WARNING: In a rollover crash, an unbelted person is significantly more likely to die or be seriously injured than a person wearing a seat belt. WARNING: Each seating position in your vehicle has a specific seat belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
Page 111 2. To unfasten, push the release button and remove the tongue from the buckle. Energy Management Feature • This vehicle has a seat belt system with an energy management feature at the front outboard seating positions to help further reduce the risk of injury in the event of a head-on collision.
Page 112 Seating and Safety Restraints How to use the automatic locking mode • Buckle the combination lap and shoulder belt. • Grasp the shoulder portion and pull downward until the entire belt is pulled out. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
Page 113 WARNING: BELT AND RETRACTOR ASSEMBLY MUST BE REPLACED if the seat belt assembly “automatic locking retractor” feature or any other seat belt function is not operating properly when checked by an authorized dealer. Failure to replace the Belt and Retractor assembly could increase the risk of injury in collisions.
Page 114 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Mazda Motor Corporation recommends that all seat belt assemblies in use in vehicles involved in a collision be replaced.
Page 115 WARNING: Failure to inspect and if necessary replace the seat belt assembly under the above conditions could result in severe personal injuries in the event of a collision. For proper care of soiled seat belts, refer to Interior in the Cleaning chapter.
Page 116 Seating and Safety Restraints Both the driver’s and passenger’s seat belt usages are monitored and either may activate the Belt-Minder feature. The warnings are the same for the driver and the front passenger. If the Belt-Minder warnings have expired (warnings for approximately 5 minutes) for one occupant (driver or front passenger), the other occupant can still activate the Belt-Minder feature.
Page 117 I’m not going far 3 of 4 fatal crashes occur within 25 miles of home. Belts are Your Mazda seat belts are designed to enhance uncomfortable comfort. If you are uncomfortable - try different positions for the seat belt upper anchorage and seatback which should be as upright as possible;...
Page 118 Seating and Safety Restraints WARNING: Do not sit on top of a buckled seat belt or insert a latchplate into the buckle to avoid the Belt-Minder chime. To do so may adversely affect the performance of the vehicle’s air bag system One time disable If at any time the driver/front passenger quickly buckles then unbuckles the seat belt for that seating position, the Belt-Minder is disabled for...
Page 119 1. Turn the ignition switch to the RUN (or ON) position. (DO NOT START THE ENGINE) 2. Wait until the seat belt warning light turns off. (Approximately 1 minute) • Step 3 must be completed within 50 seconds after the seat belt warning light turns off.
Page 120: Airbags
Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the seat belt to help protect the driver and right front passenger from certain upper body injuries. WARNING: Airbags DO NOT inflate slowly or gently and the risk of injury from a deploying...
Page 121 Do not modify the front end of the vehicle. WARNING: Additional equipment may affect the performance of the airbag sensors increasing the risk of injury. Consult your authorized Mazda dealership before installation of additional equipment. Seating and Safety Restraints...
Page 122 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 123 The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder or sodium compounds which may irritate the skin and eyes, but none of the residue is toxic.
Page 124 Seating and Safety Restraints WARNING: If the airbag has deployed, the airbag will not function again and must be replaced immediately. If the airbag is not replaced, the unrepaired area will increase the risk of injury in a collision. Front passenger sensing system The front passenger sensing system is designed to meet the regulatory requirements of Federal Motor Vehicle Safety Standard (FMVSS) 208 and is designed to disable (will not inflate) the front passenger’s frontal...
Page 125 Note: The indicator lamp will illuminate for a short period of time when the ignition is turned to the ON position to confirm it is functional. When the front passenger seat is not occupied (empty seat) or in the event that the front passenger frontal airbag is enabled (may inflate), the indicator lamp will be unlit.
Page 126 Seating and Safety Restraints Occupant Empty seat Small child in child safety seat or booster Small child with seat belt buckled or unbuckled Adult WARNING: Even with Advanced Restraints Systems, children 12 and under should be properly restrained in the back seat. After all occupants have adjusted their seats and put on seat belts, it’s very important that they continue to sit properly.
Page 127 Objects Small (i.e. 3 ring binder, small purse, bottled water) Medium (i.e. heavy briefcase, fully packed luggage) Empty seat, or small to medium object with seat belt buckled If you think that the status of the passenger airbag off indicator lamp is incorrect, check for the following: •...
Page 128 DO NOT attempt to repair or service the system; take your vehicle immediately to an authorized Mazda dealer. Ask the front seat occupant to sit in a rear seat until the air bag system if checked by the authorized Mazda Dealer.
Page 129 A difficulty with the system is indicated by one or more of the following: • The readiness light will either flash or stay lit. • The readiness light will not illuminate immediately after ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and/or light are repaired.
Page 130 Seating and Safety Restraints How does the side airbag system work? The design and development of the side airbag system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 131 to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration. WARNING: Several airbag system components get hot after inflation. Do not touch them after inflation. WARNING: If the side airbag has deployed, the airbag will not function again.
Page 132 (if equipped), fuses, the A, B, or C pillar trim, or the headliner on a vehicle containing side-curtain airbags. See your authorized Mazda dealer. WARNING: All occupants of the vehicle including the driver should always wear their seat belts even when an airbag SRS and side-curtain airbags (if equipped) are provided.
Page 133 How do the side-curtain airbags (if equipped) work? The design and development of the side air curtain system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group. These recommended testing procedures help reduce the risk of injuries related to the deployment of side airbags (including side air...
Page 134 Seating and Safety Restraints The side-curtain airbags are mounted to roof side-rail sheet metal, behind the headliner, above the first and second row seats. In certain lateral collisions or rollover events, the side-curtain airbags will be activated, regardless of which seats are occupied. In certain rollover events, the side-curtain airbag (if equipped) on both sides of the vehicle will be inflated, regardless of which seats are occupied.
Page 135: Child Restraints
If any of these things happen, even intermittently, have the SRS serviced at your authorized Mazda dealership immediately. Unless serviced, the system may not function properly in the event of a collision.
Page 136 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Mazda Motor Corporation recommends use of a belt-positioning booster. Booster seats position a child so that seat belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 137 • Can the child sit all the way back against the vehicle seat back with knees bent comfortably at the edge of the seat without slouching? • Does the lap belt rest low across the hips? • Is the shoulder belt centered on the shoulder and chest? •...
Page 138 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 139 80 lb. (36 kg) using an upper torso harness and a belt-positioning booster. Mazda recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and...
Page 140 Seating and Safety Restraints tether anchors. For more information on top tether straps and anchors, refer to Attaching safety seats with tether straps in this chapter. For more information of LATCH anchors refer to Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments in this chapter.
Page 141 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted.
Page 142 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 143 Attaching child safety seats with tether straps Most new forward-facing child safety seats include a tether strap which goes over the back of the seat and hooks to an anchoring point. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap.
Page 144 Seating and Safety Restraints 4. Clip the tether strap to the anchor as shown. The arrow in the above graphic points toward the front of the vehicle. WARNING: If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision.
Page 145 Your vehicle has LATCH anchors for child seat installation at the following locations: The anchors on both sides of the center of the rear seat are provided primarily for child seats at the outboard seats, and are further apart than the pairs of lower anchors for child seat installation at other seats.
Page 146 Seating and Safety Restraints If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it. Keep the tether strap just snug without lifting the front of the child seat.
Page 147: Tires, Wheels And Loading
NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under...
Page 148 Tires, Wheels and Loading VEHICLE CHARACTERISTICS 4WD and AWD Systems A vehicle equipped with AWD or 4WD has the ability to use all four wheels to power itself. This increases traction which may enable you to safely drive over terrain and road conditions that a conventional two-wheel drive vehicle cannot.
Page 149: Tire Information
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Mazda Motor Corporation to give you the following information about tire grades exactly as the government has written it.
Page 150 Tires, Wheels and Loading government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and may depart significantly from the norm due to variations in driving habits, service practices, and differences in road characteristics and climate.
Page 151: Tire Inflation
Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry. • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture.
Page 152 (if equipped), at least monthly and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Mazda recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 153 When weather temperature changes occur, tire inflation pressures also change. A 10°F (6°C) temperature drop can cause a corresponding drop of 1 psi (7 kPa) in inflation pressure. Check your tire pressures frequently and adjust them to the proper pressure which can be found on the Safety Compliance Certification Label or Tire Label.
Page 154 Tires, Wheels and Loading TIRE CARE Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves. Check for holes or cuts that may permit air leakage from the tire and make necessary repairs.
Page 155 WARNING: Age Tires degrade over time depending on many factors such as weather, storage conditions, and conditions of use (load, speed, inflation pressure, etc.) the tires experience throughout their lives. In general, tires should be replaced after 6 years regardless of tread wear.
Page 156 Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door. If this information is not found on these labels then you should consult your Mazda dealer. Use of any tire or wheel not recommended by Mazda can affect the safety...
Page 157 The tire pressure monitoring sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Mazda Motor Corporation may affect the operation of your Tire Pressure Monitoring System.
Page 158 Tires, Wheels and Loading Tire and wheel alignment A bad jolt from hitting a curb or pothole can cause the front end of your vehicle to become misaligned or cause damage to your tires. If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment.
Page 159 Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a Mazda dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 160 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
Page 161 Note: You may not find this information on all tires because it is not required by federal law. Letter rating Note: For tires with a maximum speed capability over 149 mph (240 km/h), tire manufacturers sometimes use the letters ZR. For those with a maximum speed capability over 186 mph (299 km/h), tire manufacturers always use the letters ZR.
Page 162 Tires, Wheels and Loading Compliance Certification Label, which is located on the B-Pillar or the edge of the driver’s door, for the correct tire pressure for your vehicle. 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 163 Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 164 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 165: Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
Page 166 Tires, Wheels and Loading following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: The Tire Pressure Monitoring System is NOT a substitute for manually checking tire pressure.
Page 167 Tires, Wheels and Loading When your temporary spare tire is installed When one of your road tires needs to be replaced with the temporary spare, the TPMS system will continue to identify an issue to remind you that the damaged road wheel/tire needs to be repaired and put back on your vehicle.
Page 168 Tires, Wheels and Loading Low Tire Pressure Warning Light Solid Warning Light Possible cause Customer Action Required Tire(s) 1. Check your tire pressure to under-inflated ensure tires are properly inflated; refer to Inflating your tires in this chapter. 2. After inflating your tires to the manufacturer’s recommended inflation pressure as shown on the Tire...
Page 169 Low Tire Pressure Warning Light Flashing Warning Light When inflating your tires When putting air into your tires (such as at a gas station or in your garage), the Tire Pressure Monitoring System may not respond immediately to the air added to your tires. It may take up to two minutes of driving over 20 mph (32 km/h) for the light to turn OFF after you have filled your tires to the recommended inflation pressure.
Page 170: Vehicle Loading
• Do not use cables on dry roads. • Do not exceed 30 mph (48 km/h) with tire cables on your vehicle. Consult your authorized dealer for information on other Mazda Motor Corporation approved methods of traction control. VEHICLE LOADING – WITH AND WITHOUT A TRAILER...
Page 171 Vehicle Curb Weight – is the weight of your new vehicle when you picked it up from your authorized dealer plus any aftermarket equipment. Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
Page 172 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 173 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 174 Tires, Wheels and Loading WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury. GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer.
Page 175 WARNING: Do not use replacement tires with lower load carrying capacities than the original tires because they may lower the vehicle’s GVWR and GAWR limitations. Replacement tires with a higher limit than the original tires do not increase the GVWR and GAWR limitations. WARNING: Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury.
Page 176: Trailer Towing
Tires, Wheels and Loading • A final example for your vehicle with 1400 lb. (635 kg) of cargo and luggage capacity. You and one of your friends decide to pick up cement from the local home improvement store to finish that patio you have been planning for the past 2 years.
Page 177 Trailer towing puts additional loads on your vehicle’s engine, transaxle, axle, brakes, tires, and suspension. For your safety and to maximize vehicle performance, be sure to use the proper equipment while towing. Follow these guidelines to ensure safe towing procedure: •...
Page 178 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Engine Maximum GCWR - lb. (kg) 2.3L 4980 (2259) Notes: For high altitude operation, reduce GCW by 2% per 1000 ft. (300 meters) elevation. For definitions of terms and instructions on calculating your vehicle’s load, refer to Vehicle loading in this chapter.
Page 179 If you use a rental trailer, follow the instructions that the rental agency gives to you. Do not attach safety chains to the bumper. Trailer brakes Electric, manual, automatic or surge-type brakes, if compatible with the vehicle, are safe if installed properly and adjusted to the manufacturer’s specifications.
Page 180 Tires, Wheels and Loading • Do not exceed the GCWR rating or transmission damage may occur. Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your scheduled maintenance information for more information.
Page 181: Recreational Towing
Tires, Wheels and Loading Exceeding these limits may allow water to enter vehicle components: • causing internal damage to the components. • affecting driveability, emissions and reliability. Replace the rear axle lubricant any time the axle has been submerged in water.
Page 182: Driving
Driving STARTING Positions of the ignition 1. LOCK, locks the gearshift lever and allows key removal. 2. ACCESSORY, allows the electrical accessories such as the radio to operate while the vehicle is not running. 3. RUN, all electrical circuits operational and warning lights will illuminate.
Page 183 Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs higher than normal in order to warm the engine. If the engine idle speed does not slow down automatically, have the vehicle checked.
Page 184 Driving 3. Turn the key to 3 (RUN) without turning the key to 4 (START). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights. Starting the vehicle 1.
Page 185 vehicle still does not start, it may require refueling, jump starting, resetting of the fuel pump/high voltage shut-off switches or service. For information on jump starting the vehicle and resetting the fuel pump/high voltage shut-off switches, refer to the Jump starting your vehicle (low voltage [underhood] battery only) section, the Jump starting the high voltage battery section, and the Fuel pump/High voltage shut-off switches section found in the Roadside Emergencies...
Page 186 Driving Association (CSA). Use only an extension cord that can be used outdoors, in cold temperatures, and is clearly marked Suitable for Use with Outdoor Appliances. Never use an indoor extension cord outdoors; it could result in an electric shock or fire hazard. •...
Page 187: Brakes
Brake dust can be cleaned by weekly washing with soapy water and a soft sponge. Heavier deposits can be removed with Mazda Wheel and Tire Cleaner (ZC-37–A). Four-wheel anti-lock brake system (ABS) Your vehicle is equipped with an Anti-lock Braking System (ABS).
Page 188 Driving Using ABS When hard braking is required, apply continuous force on the brake pedal; do not pump the brake pedal since this will reduce the effectiveness of the ABS and will increase your vehicle’s stopping distance. The ABS will be activated immediately, allowing you to retain steering control during hard braking and on slippery surfaces.
Page 189 to interact with the anti-lock brake system (ABS). Regenerative braking is disabled when the ABS is activated or the battery is fully charged. Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops.
Page 190 Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. STEERING Your vehicle is equipped with an Electric Power-Assisted Steering (EPAS) system. There is no fluid reservoir to check or fill. If your vehicle loses electrical power while you are driving (or if the ignition is turned off), you can steer the vehicle manually, but it takes more effort.
Page 191: Transmission Operation
WARNING: In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Utility vehicles and trucks have larger tires and increased ground clearance, giving the vehicle a higher center of gravity than a passenger car.
Page 192 Driving 2. Using a screwdriver or similar tool, carefully pry out the small Brake Transmission Shift Interlock (BTSI) cover cap located to the right of the gearshift lever. 3. Depress the brake pedal and then start the vehicle. 4. Insert a screwdriver or similar tool straight down into the access hole and press downward while pulling the gearshift lever...
Page 193 Understanding the gearshift positions of the electronically-controlled Continuously Variable Transaxle (eCVT) P (Park) This position locks the transaxle and prevents the front wheels from turning. To put your vehicle in gear: • Start the engine • Release the parking brake •...
Page 194 Driving N (Neutral) With the gearshift lever in N (Neutral), the vehicle is free to roll; hold the brake pedal down while in this position. Because of the unique nature of the hybrid vehicle, the engine will not start in the N (Neutral) position.
Page 195 power distribution between the front and rear wheels. It combines transparent all-surface operation with highly capable four-wheel drive. The 4WD system is always active and requires no driver input. It is capable of handling all road conditions, including street and highway driving as well as off-road and winter driving.
Page 196 Driving • It often may be less risky to strike small objects, such as highway reflectors, with minor damage to your vehicle rather than attempt a sudden return to the pavement which could cause the vehicle to slide sideways out of control or roll over. Remember, your safety and the safety of others should be your primary concern.
Page 197 Emergency maneuvers • In an unavoidable emergency situation where a sudden sharp turn must be made, remember to avoid “over-driving” your vehicle, i.e., turn the steering wheel only as rapidly and as far as required to avoid the emergency. Excessive steering will result in less vehicle control, not more.
Page 198 Mazda Motor Corporation joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and...
Page 199 Driving Driving on hilly or sloping terrain Although natural obstacles may make it necessary to travel diagonally up or down a hill or steep incline, you should always try to drive straight up or straight down. Avoid driving crosswise or turning on steep slopes or hills.
Page 200 The suspension and steering systems on your vehicle have been designed and tested to provide durable load carrying capability and predictable performance whether loaded or empty. For this reason, Mazda Motor Corporation strongly recommends that you do not make modifications such as adding or removing parts (such as lift kits or stabilizer bars) or using replacement parts not equivalent to the original factory equipment.
Page 201 Driving DRIVING THROUGH WATER If driving through deep or standing water is unavoidable, proceed very slowly especially when the depth is not known. Never drive through water that is higher than the bottom of the wheel rims (for cars) or the bottom of the hubs (for trucks).
Page 202: Roadside Emergencies
Roadside Emergencies HAZARD FLASHER CONTROL The hazard flasher is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Push in the flasher control and all front and rear direction signals will flash.
Page 203 The fuel pump shut-off switch is located in the front passenger’s footwell, behind a flip-up cover. The high voltage shut-off switch is located in the cargo area on the passenger side of the vehicle in the jack compartment, behind the jack access door.
Page 204: Fuses And Relays
Roadside Emergencies If you see or smell fuel, do not reset the fuel pump shut-off or try to start your vehicle; you could injure yourself or others. Have all the passengers get out of the vehicle and call the local fire department or a towing service.
Page 205 Fuse Mini rating fuses — — Passenger compartment fuse panel The fuse panel is located on the right-hand side of the center console, by the instrument panel. Remove the panel cover to access the fuse cover. Press the tabs on the top and bottom of the fuse cover to remove.
Page 206 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating Passenger Compartment Fuse Panel Description Not used (spare) Brake On/Off switch Not used (spare) 110V inverter Brake Shift Interlock (BSI), SPDJB, Keypad illumination Turn signals, Stop lamps Low beam headlamps (left) Low beam headlamps (right) Interior lights...
Page 207 Fuse/Relay Fuse Amp Location Rating 30A Circuit Breaker Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. WARNING: Always disconnect the low voltage (underhood) battery before servicing high current fuses.
Page 208 Roadside Emergencies WARNING: To reduce risk of electrical shock, always replace the cover to the power distribution box before reconnecting the low voltage (underhood) battery or refilling fluid reservoirs. If the low voltage (underhood) battery has been disconnected and reconnected, refer to the Low voltage (underhood) battery section of the Maintenance and Specifications chapter.
Page 209 Fuse/Relay Fuse Amp Location Rating 30A** 30A** 40A** 10A* 10A* 50A** 40A** 40A** 50A** 30A** — — — — — — 20A* 15A* 10A* 15A* 15A* — — — — — — Roadside Emergencies Power Distribution Box Description Front wipers PCM/Power sustain Blower motor A/C clutch...
Page 210: Changing Tires
Roadside Emergencies Fuse/Relay Fuse Amp Location Rating * Mini fuse ** Cartridge fuse CHANGING A FLAT TIRE If you get a flat tire while driving: • do not brake heavily. • gradually decrease the vehicle’s speed. • hold the steering wheel firmly. •...
Page 211 Mazda. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 212 Roadside Emergencies Use of one of the dissimilar spare tires listed above at any one wheel location can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs •...
Page 213 Stopping and securing the vehicle 1. Park on a level surface, set the parking brake and activate the hazard flashers. 2. Place gearshift lever in P (Park) and turn engine off. Removing the jack and tools The jack and tools are located in the right rear of the cargo area behind an access panel.
Page 214 Roadside Emergencies To remove jack from vehicle: 1. Release the thumbscrew on the bracket. 2. Release the retention clip on the upper part of the jack bracket. 3. Dislodge the jack from the bracket and carefully guide jack down and out through trim opening, upper end out first.
Page 215 If equipped with a tether, perform the following additional steps: 4. Lift the spare tire on end to access tether attachment (1). 5. Use the lug wrench to remove the lug nut from the spare tire tether. 6. If not replacing the spare or flat tire to the underbody storage area, raise winch up into the installed position.
Page 216 Roadside Emergencies WARNING: To help prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed. WARNING: Changing a tire is dangerous if not done properly.
Page 217 Roadside Emergencies • Front View shown from rear of front tire. Position the jack directly below the protruding bolt. • Rear View shown from forward of rear tire. Position jack directly below the stud on the rear trailing arm.
Page 218 Roadside Emergencies 3. Position the jack according to the guides and turn the jack handle clockwise until the tire is a maximum of 1 inch (25 mm) off the ground. Never use the differentials as a jacking point. WARNING: To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a...
Page 219 Stowing the jack and tools Make sure the jack is fully lowered and reclip the tools onto the jack. Reinstall the jack and tools in the cargo area. To replace the jack in the vehicle, • guide the jack bottom first in the trim opening and position in the bracket (3), •...
Page 220 Roadside Emergencies 1. Place tire on end with valve stem facing rearward, away from vehicle. 2. Place tether into bolt holes in wheel and attach lug nut using lug wrench. 3. Lay the tire on the ground with the valve stem facing down. If your vehicle is equipped with aluminum wheels, remove the wheel ornament.
Page 221: Lug Nut Torque
M12 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Mazda recommended replacement fasteners. WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 222: Jump Starting
Roadside Emergencies JUMP STARTING (LOW VOLTAGE [UNDERHOOD] BATTERY ONLY) Your vehicle has two separate jump starting procedures; the following procedure is for the low voltage (underhood) battery only. Refer to Jump starting the high voltage battery in this chapter for information on jump starting the high voltage battery.
Page 223 5. Turn the heater fan on in both vehicles to protect from any electrical surges. Turn all other accessories off. Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
Page 224 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 225 Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected.
Page 226 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 227 JUMP STARTING THE HIGH VOLTAGE BATTERY Your vehicle has two separate jump starting procedures; the following procedure is for the cargo area high voltage battery only. Refer to the Jump starting your vehicle (Low voltage [underhood] battery only) section in this chapter for information on jump starting the low voltage (underhood) battery.
Page 228 Roadside Emergencies When the button is pressed, the indicator light on the button will illuminate. After eight minutes has passed, the indicator light will flash rapidly for two minutes. Turn the ignition to RUN. You may now attempt to start the engine. If you attempt to start the engine before the eight minutes passes, the jump starting procedure will stop and will have to be restarted if the engine does not start.
Page 229: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Mazda Motor Corporation has not approved a slingbelt towing procedure. On FWD vehicles, if your vehicle is to be towed from the front, ensure proper wheel lift equipment is used to raise the front wheels off the ground.
Page 230 (all wheels on the ground) with the transmission placed in N (Neutral). Mazda Motor Corporation produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.
Page 231: Customer Assistance
STEP 1: Contact Your Authorized Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the authorized dealer or the OWNER.
Page 232 STEP 2: Call the Mazda Regional Office If you feel that you still require assistance, ask the authorized dealer Service Manager to arrange for you to meet the local Mazda Service Representative. If more expedient, contact Mazda Canada Inc. Regional Office nearest you for such arrangements.
Page 233 Your complete satisfaction is the goal of Mazda Canada Inc. and our authorized dealers. Mazda’s participation in CAMVAP makes a valuable contribution to our achieving that goal.
Page 234 However, before you can proceed with CAMVAP you must follow your Mazda dispute resolution process as outlined previously. CAMVAP is fully implemented in all provinces and territories. Consumers wishing to obtain further information about the Program can obtain an...
Page 235 Mazda Dealer personnel, we recommend that you take the following steps: STEP 1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the authorized dealer or the OWNER.
Page 236 In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Mazda North American Operations 7755, Irvine Center Drive Irvine, CA 92618–2922 MAZDA IMPORTERS/DISTRIBUTORS U.S.A (Importer/Distributor)
Page 237 Richmond Hill, Ontario L4B 3K5 Canada TEL: 1 (800) 263–4680 (in Canada) (416) 609–9909 (outside Canada) PUERTO RICO & VIRGIN ISLANDS Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936–2722 TEL: (787) 788–9300 GUAM (d.b.a.
Page 238 NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety requirements.
Page 239 NOT take your Mazda outside Canada. However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with specific vehicle modifications to comply with the United States Federal Motor Vehicle Safety requirements.
Page 240 Mazda assumes no responsibility for death, injury, or expenses that may result from the installation of add-on non-genuine parts or accessories. SERVICE PUBLICATIONS Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair.
Page 241: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer or Mazda Corporation. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 242: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo. • Never use strong household detergents or soap, such as dish washing or laundry liquid. These products can discolor and spot painted surfaces.
Page 243 • Never spray the engine or other engine components with water. Water will damage the engine or other engine components. • Spray Engine Shampoo and Degreaser (0000–77–410E-09), available at your authorized Mazda dealer, on all parts that require cleaning and pressure rinse clean. Cleaning...
Page 244 • For routine cleaning, use cool or lukewarm water with a neutral pH shampoo. • If tar or grease spots are present, use Extra Strength Tar and Road Oil Remover (0000–77–410E-01), available at your authorized Mazda dealer. WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly.
Page 245 INSTRUMENT PANEL / INTERIOR TRIM AND CLUSTER LENS Clean the interior trim areas and instrument panel with a damp cloth, then with a clean, dry cloth, or use Mazda Deluxe Leather and Vinyl Cleaner (0000-77-430E-15). • Avoid cleaners or polish that increase the gloss of the upper portion of the instrument panel.
Page 246 MAZDA CAR CARE PRODUCTS Your Mazda dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 247: Maintenance And Specifications
Information Booklet to find out which parts and services are covered. Use only recommended fuels, lubricants, fluids and service parts conforming to specifications. Mazda parts are designed and built to provide the best performance in your vehicle. PRECAUTIONS WHEN SERVICING YOUR VEHICLE •...
Page 248 Maintenance and Specifications 1. High voltage connector shield 2. Service Disconnect 3. High voltage battery case Working with the engine off 1. Set the parking brake and ensure the gearshift is securely latched in P (Park). 2. Turn off the engine and remove the key. 3.
Page 249 OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2. At the front of the vehicle, lift up on the auxiliary latch handle located in the center between the hood and the grille. 3.
Page 250: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.3L I4 engine 1. Engine coolant reservoir 2. Motor/Electronics (M/E) coolant reservoir 3. Engine oil filler cap 4. Brake fluid reservoir 5. Power distribution box 6. Low Voltage (underhood) battery 7. Engine air filter assembly 8.
Page 251 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Mazda specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 252 Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper blade and arm away from the glass. Turn the blade at a right angle to the arm. 2. Squeeze the locking tabs to release the blade from the arm and pull the blade away from the arm to remove it.
Page 253: Engine Oil
To replace the wiper blade: 1. Grab the wiper arm just below the blade attachment and pull it as far away from the glass as possible. Do not use excessive force because it can break the wiper arm at the heel. Hold it there until the next step.
Page 254 Maintenance and Specifications 5. Locate and carefully remove the engine oil level dipstick. 6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is within the MIN and MAX marks or the lower and upper holes, the oil level is acceptable.
Page 255 International Lubricant Standardization and Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine’s warranty use Mazda SAE 5W-20 or an equivalent SAE 5W-20 oil meeting Mazda specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 256: Battery
Mazda material and design specifications, start-up engine noises or knock may be experienced. It is recommended you use the appropriate Mazda oil filter or another with equivalent performance for your engine application. LOW VOLTAGE (UNDERHOOD) BATTERY...
Page 257 WARNING: Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation. WARNING: When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the...
Page 258: Engine Coolant And Motor/Electronics Coolant
Maintenance and Specifications 6. Drive the vehicle to complete the relearning process. • The vehicle may need to be driven 10 miles (16 km) or more to relearn the idle and fuel trim strategy. • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
Page 259 Maintenance and Specifications Checking engine coolant The concentration and level of engine coolant should be checked at the intervals listed in scheduled maintenance information. The coolant concentration should be maintained at 50/50 coolant and distilled water, which equates to a freeze point of -34°F (-36°C).
Page 260 Maintenance and Specifications Checking motor/electronics (M/E) coolant The M/E coolant reservoir is located behind the engine coolant reservoir. Refer to the following engine coolant sections for all information, instructions and warnings related to cooling systems. The two systems use the same coolant and operate similarly, with the Motor and Electronics system generally operating at a lower temperature...
Page 261 Adding engine coolant Use only Mazda Genuine Engine Coolant or a premium engine coolant that meets a Mazda specification. • DO NOT USE Extended Life Engine Coolant (orange in color).
Page 262 Maintenance and Specifications A large amount of water without engine coolant may be added, in case of emergency, to reach a vehicle service location. In this instance, the cooling system must be drained and refilled with a 50/50 mixture of engine coolant and distilled water as soon as possible.
Page 263 Recycled engine coolant Mazda Motor Corporation does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Mazda Premium Gold Engine Coolant since a Mazda-approved recycling process is not yet available.
Page 264: Fuel Information
Replace the fuel filter with an authorized Mazda part. The customer warranty may be void for any damage to the fuel system if an authorized Mazda fuel filter is not used.
Page 265 WARNING: Gasoline may contain benzene, which is a cancer-causing agent. Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before refueling your vehicle. • Always turn off the vehicle before refueling. • Automotive fuels can be harmful or fatal if swallowed.
Page 266 Maintenance and Specifications WARNING: The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container. Refueling WARNING: Fuel vapor burns violently and a fuel fire can cause severe injuries.
Page 267 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Mazda fuel filler cap is not used. WARNING: The fuel system may be under pressure. Remove fuel filler cap slowly.
Page 268 Ask your fuel supplier about gasolines that meet the World-Wide Fuel Charter. Cleaner air Mazda endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the Right Fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 269 If you have run out of fuel: • You may need to cycle the ignition from OFF to ON several times after refueling to allow the fuel system to pump the fuel from the tank to the engine. On restarting, cranking time will take a few seconds longer than normal.
Page 270 Maintenance and Specifications 2. Each time you fill the tank, record the amount of fuel added (in gallons or liters). 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading. 4. Subtract your initial odometer reading from the current odometer reading.
Page 271 • Minimize temperature extremes when the vehicle is parked, for example by storing in a garage to avoid extreme cold in winter and extreme sun loads in summer. The high voltage battery operates more efficiently in moderate temperatures. • Combine errands. Your vehicle is more fuel efficient when the engine is warm.
Page 272 If other than Mazda or Mazda-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Mazda parts should be equivalent to genuine Mazda Motor Corporation parts in performance and durability.
Page 273 it from working. Information about your vehicle’s emission system is on the Vehicle Emission Control Information Decal located on or near the engine. This decal identifies engine displacement and gives some tune up specifications. Please consult your Warranty Information Booklet for complete emission warranty information.
Page 274 Maintenance and Specifications Readiness for Inspection/Maintenance (I/M) testing Some state/provincial and local governments may have Inspection/Maintenance (I/M) programs to inspect the emission control equipment on your vehicle. Failure to pass this inspection could prevent you from getting a vehicle registration. Your vehicle may not pass the I/M test if the indicator is on or not working properly (bulb is burned out), or if the OBD-II system has determined that some of the emission...
Page 275 BRAKE FLUID The fluid level will drop slowly as the brakes wear, and will rise when the brake components are replaced. Check fluid levels with the ignition in the RUN position. Fluid levels between the “MIN” and “MAX” lines are within the normal operating range;...
Page 276 Maintenance and Specifications Note: The brake system on this vehicle can only be bled at a authorized dealer. TRANSMISSION FLUID Checking electronically controlled continuously variable transmission (eCVT) Refer to your scheduled maintenance information chapter for scheduled intervals for fluid checks and changes. Your transaxle does not consume fluid.
Page 277 5. Using the hole in the splash shield, remove the check plug from the side of the transmission. If this is the first check of the transmission fluid, it may be necessary to remove the perforated section of the splash shield (as indicated on the splash shield).
Page 278: Air Filter(S)
Refer to scheduled maintenance information for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the Mazda air filter element listed. Refer to Mazda part numbers in this chapter. WARNING: To reduce the risk of vehicle damage and/or...
Page 279 Refer to the scheduled maintenance information for the appropriate intervals for air filter. When changing the air filter element, use only the Mazda air filter element listed. Refer to Mazda part numbers in this chapter. Maintenance and Specifications...
Page 280 Maintenance and Specifications Changing the high voltage battery air filter element 1. Remove access panel located in the rear cargo area on the driver’s side trim panel to expose the filter cover. 2. Push the tabs (located on each side of filter cover) while pulling gently to remove filter cover.
Page 281: Maintenance Product Specifications And Capacities
Maintenance and Specifications...
Page 282 Maintenance and Specifications...
Page 283: Engine Data
ENGINE DATA Engine Cubic inches Required fuel Firing order Ignition system Spark plug gap Compression ratio Engine drivebelt routing • 2.3L I4 Engine HIGH VOLTAGE BATTERY DATA High Voltage Battery Battery chemistry Nominal Voltage Capacity Maintenance and Specifications 2.3L I4 engine 87 octane 1-3-4-2 Coil on plug...
Page 284: Instrument Panel
Please note that in the graphic, XXXX is representative of your vehicle identification number. MFD. BY FORD MOTOR CO. IN U.S.A. FOR MAZDA MOTOR CORPORATION DATE: XX/XX GVWR:XXXXXLB/ XXXXXKG FRONT GAWR: XXXXL REAR GAWR: WITH...
Page 285 Description Electronically controlled continuously variable transmission, eCVT Maintenance and Specifications MFD. BY FORD MOTOR CO. IN U.S.A. FOR MAZDA MOTOR CORPORATION DATE: XX/XX FRONT GAWR: XXXXL XXXXKG XXXX/XXXXXXX XXXX.XX AT XXX kPa/XX THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR VEHICLE SAFETY AND THEFT PREVENTION STANDARDS IN EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.
Page 286: Accessories
Accessories CELL PHONES Use of cell phones and other devices by driver: WARNING: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver’s hands.
Page 287: Service Maintenance Section
Your Mazda dealer, or Mazda Quality Care Center has factory trained technicians who can perform the required maintenance using genuine Mazda parts. They are committed to meeting your service needs and to assuring your continuing satisfaction. Protecting your investment Maintenance is an investment that will pay dividends in the form of improved reliability, durability and resale value.
Page 288 Mazda Motor Corporation parts in performance and durability. It is the owner’s responsibility to determine the equivalency of such parts. Please consult your Warranty Information Booklet for complete warranty information.
Page 289 Get the most from your service and maintenance visits There are a lot of reasons why visiting your Mazda Dealership for all your service needs is a great way to help keep your vehicle running great.
Page 290 Mazda Motor Corporation’s specifications are used. Genuine Mazda branded parts meet these specifications. You can find them at your Mazda Dealership. Look for the following brand logos to ensure the parts installed on your vehicle meet Mazda Motor Corporation Specifications.
Page 291: Owner Checks And Services
6 years or 100,000 miles (160,000 km) - change Mazda Premium Gold Engine Coolant (whichever comes first) ❑ After initial change - change Mazda Premium Gold Engine Coolant every 3 years or 50,000 miles (80,000 km). ❑ Check function of all interior and exterior lights ❑...
Page 292: Normal Scheduled Maintenance And Log
In order to keep your vehicle running right, it is important that you have the systems on your vehicle checked regularly. This can help identify any potential issue before there are any problems. Mazda Motor Corporation suggests the following multi-point inspection to be performed at every scheduled maintenance as the way to ensure your vehicle keeps running right.
Page 293 U.S. AND CANADIAN SCHEDULE ❑ Inspect tires for wear and measure tread depth ❑ Rotate tires ❑ Change engine oil and replace oil filter ❑ Inspect tires for wear and measure tread depth ❑ Rotate tires ❑ Inspect high voltage battery A/C filter, replace if necessary ❑...
Page 294 Service Maintenance Section ❑ Change engine oil and replace oil filter ❑ Inspect tires for wear and measure tread depth ❑ Rotate tires ❑ Inspect high voltage battery A/C filter, replace if necessary ❑ Replace engine air filter ❑ Change engine oil and replace oil filter ❑...
Page 295 ❑ Change engine oil and replace oil filter ❑ Inspect tires for wear and measure tread depth ❑ Rotate tires ❑ Inspect brake pads, shoes, rotors, drums, brake lines and hoses and parking brake ❑ Inspect engine and Motor/electronics cooling system and hoses ❑...
Page 296 ❑ Replace high voltage battery A/C filter ❑ Replace fuel filter ❑ Replace engine coolant and Motor/electronics coolant (see Mazda Premium Gold Coolant Change Record) ❑ Inspect accessory drive belt ❑ Replace spark plugs ❑ Change engine oil and replace oil filter ❑...
Page 297 ❑ Change engine oil and replace oil filter ❑ Inspect tires for wear and measure tread depth ❑ Rotate tires ❑ Inspect brake pads, shoes, rotors, drums, brake lines and hoses and parking brake ❑ Inspect engine and Motor/electronics cooling system and hoses ❑...
Page 298 Inspect high voltage battery A/C filter ❑ Replace engine air filter ❑ Replace engine coolant and Motor/electronics coolant (see Mazda Premium Gold Coolant Change Record) ❑ Replace accessory drive belt (if not replaced in the last 100,000 miles) ❑ Inspect PCV valve for flow and replace, if required ❑...
Page 299: Special Operating Conditions And Log
SPECIAL OPERATING CONDITIONS Towing a trailer or using a camper or car-top carrier Every 5,000 miles, 6 months or 200 hours of engine operation (whichever comes first) Every 5,000 miles Inspect tires and rotate Extensive Idling and/or Low Speed Driving for Long Distances as in Heavy Commercial Use Such as Delivery, Taxi, Patrol Vehicle or Livery.
Page 300 Service Maintenance Section Special Operating Conditions Log EALER ALIDATION RO#: P&A C ILEAGE EALER ALIDATION RO#: P&A C ILEAGE EALER ALIDATION RO#: P&A C ILEAGE EALER ALIDATION RO#: P&A C ILEAGE EALER ALIDATION RO#: P&A C ILEAGE RO#: RO#: RO#: RO#: RO#: EALER...
Page 301 Special Operating Conditions Log EALER ALIDATION RO#: P&A C ILEAGE EALER ALIDATION RO#: P&A C ILEAGE EALER ALIDATION RO#: P&A C ILEAGE EALER ALIDATION RO#: P&A C ILEAGE EALER ALIDATION RO#: P&A C ILEAGE Service Maintenance Section RO#: RO#: RO#: RO#: RO#: EALER...
Page 302 MAZDA PREMIUM GOLD ENGINE COOLANT CHANGE RECORD Mazda Premium Gold Engine Coolant ❑ 6 years or 100,000 miles (160,000 km) (whichever comes first) - change Mazda Premium Gold Engine Coolant and motor/electrical coolant. ❑ After initial change - change Mazda Premium Gold Engine Coolant every 3 years or 50,000 miles (80,000 km) Current mileage goes here =>...
Page 303: Index
..143 in front seat ...140 in rear seat ...140 Child safety seats - booster seats ...136 Cleaning your vehicle engine compartment ...243 instrument panel ...245 interior ...245 Mazda car care products ...246 plastic parts ...244 washing ...242 Index...
Page 304 Index waxing ...242 wheels ...243 wiper blades ...244 Climate control (see Air conditioning or Heating) ...42 Compass, electronic ...66 calibration ...67 set zone adjustment ...66 Console ...60 Controls power seat ...99 steering column ...72 Coolant checking and adding ...258–260 refill capacities ...263, 281 specifications ...281 Cruise control ...69 Cruise control...
Page 305 fuel pump/high voltage shut-off switches ...202 improving fuel economy ...269 octane rating ...268, 283 quality ...268 running out of fuel ...268 safety information relating to automotive fuels ...264 Fuses ...204–205 Gas cap (see Fuel cap) ...266 Gas mileage (see Fuel economy) ...269 Gauges ...25 Hazard flashers ...202 Head restraints ...97, 101...
Page 306 Index doors ...87 Lubricant specifications ...281 Lug nuts ...221 Luggage rack ...84 Manual transmission fluid capacities ...281 lubricant specifications ...281 Message center ...74 english/metric button ...78 system check button ...76 warning messages ...79 Mirrors ...65, 68 automatic dimming rearview mirror ...65 fold away ...68 heated ...68 side view mirrors (power) ...68...
Page 307 Safety Compliance Certification Label ...284 Satellite Radio Information ...38 Scheduled Maintenance Guide ...287 General Maintenance Information ...287 Normal Scheduled Maintenance and Log ...292 Special Operating Conditions ...299 What Maintenance Schedule Should You Follow? ...291 Seat Belt Maintenance ...114 Seat belts (see Safety restraints) ...105, 109–113 Seats ...97 child safety seats ...139...
Page 308 Index Vehicle Identification Number (VIN) ...284 Vehicle loading ...170 Ventilating your vehicle ...185 Warning lights (see Lights) ...20 Washer fluid ...251 Water, Driving through ...201 Windows power ...64 rear wiper/washer ...59 Windshield washer fluid and wipers ...58 checking and adding fluid ...251 liftgate reservoir ...251 replacing wiper blades ...252 Wrecker towing ...229...
