Summary of Contents for Mazda 2008 B2300 Truck

  • Page 1: Table Of Contents

    Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems AM/FM stereo AM/FM stereo with single CD AM/FM stereo with CDX6/MP3 Auxiliary input jack (Line in) Satellite radio information Climate Controls Heater only Manual heating and air conditioning Lights Headlamps Turn signal control Bulb replacement Driver Controls...
  • Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Transmission operation Roadside Emergencies Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires...
  • Page 3 Maintenance and Specifications Engine compartment Engine oil Battery Engine coolant Fuel information Air filter(s) Maintenance product specifications and capacities Engine data Accessories Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from MNAO.
  • Page 4: Introduction

    The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Mazda and its products visit the following website: • In the United States: www.mazdausa.com •...
  • Page 5: Safety And Environment Protection

    WARNING: In the event of an accident the Fuel pump shut-off switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.
  • Page 6: Special Notices

    Introduction SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper to Bumper Coverage, Safety Restraint Coverage and Corrosion Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Information Booklet that is provided to you along with your Owner’s Manual.
  • Page 7 Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls. WARNING: Please read the section Airbag supplemental restraint system (SRS) in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury. WARNING: Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger airbag.
  • Page 8 Introduction These are some of the symbols you may see on your vehicle. Safety Alert Protecting the Environment Airbag - Front Child Seat Lower Anchor Brake System Parking Brake System Parking Aid System Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist Vehicle Symbol Glossary...
  • Page 9 Check fuel cap Low Tire Pressure Warning INFORMATION ABOUT THIS GUIDE The information found in this guide was accurate at the time of printing. Mazda may change the contents without notice. Vehicle Symbol Glossary Power Window Lockout Engine Oil Engine Coolant...
  • Page 10: Instrument Cluster

    Instrument Cluster Instrument panel dimmer control (pg. 43) Headlamp control (pg. 42) Turn signal and wiper/washer control (pg. 53) Parking brake release (pg. 153) * If equipped Instrument cluster (pg. 12) Driver air bag (pg. 86) Hood release (pg. 222) Speed control* (pg.
  • Page 11 4wd control* (pg. 162) Cigar lighter* (pg. 55) Auxiliary input jack* (pg. 32) Instrument Cluster Audio system (pg. 19) Passenger airbag indicator (pg. 91) Auxiliary power point* (pg. 54) Climate control system (pg. 39) * if equipped...
  • Page 12: Instrument Cluster

    Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
  • Page 13 WARNING: Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Check fuel cap: Illuminates when the fuel cap may not be properly installed. Check the fuel filler cap if this light remains on.
  • Page 14 Instrument Cluster Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected; have the system serviced immediately by your authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated. Airbag readiness: If this light fails to illuminate when the ignition is turned to ON, continues to flash or...
  • Page 15 Engine coolant temperature: Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as possible , switch off the engine and let cool. Refer to Engine coolant in the Maintenance and Specifications chapter. WARNING: Never remove the coolant reservoir cap while the engine is running or hot.
  • Page 16 Instrument Cluster NOTE: If the light continues to flash have the system serviced. Anti-theft system: Flashes when the SecuriLock™ Passive Anti-theft System has been activated. Speed control (if equipped): Illuminates when the speed control is engaged. Turns off when the speed control system is disengaged.
  • Page 17: Gauges

    GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
  • Page 18 Instrument Cluster Trip odometer: Registers the miles (kilometers) of individual journeys. Press the button once until “TRIP” appears in the display (this represents the trip mode). To reset the trip, press and hold the control again for approximately 2 seconds, until the trip reading is 0.0 miles (kilometers).
  • Page 19: Entertainment Systems

    AM/FM stereo (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Mazda strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
  • Page 20 Entertainment Systems 2. CLK —To set the time: Ensure that your audio system is turned off. Press and hold CLK until the hours flash in the display. Press AUDIO Press and hold CLK again until the minutes flash. Press AUDIO to adjust the minutes.
  • Page 21 7. ON/OFF/Volume: Press to turn the system ON/OFF. Turn to adjust the volume levels. If the volume is set above a certain level, and the ignition is turned off, the volume will come back to a “nominal” listening level when the ignition is turned back AM/FM stereo single CD/MP3 Satellite Compatible system (if equipped) 1.
  • Page 22 Entertainment Systems 3. MUTE: Press to mute the playing media. Press again to return to the playing media. 4. MENU: Press MENU repeatedly to scroll through the following modes and use an adjustment in those modes. SATELLITE RADIO MENU (if equipped): Press MENU when satellite radio mode is active to access.
  • Page 23 select either RETURN or CANCEL. Note: If there are no songs presently saved, the display will read NO SONGS. • DELETE ALL SONGS: Press SEEK system’s memory. The display will read ARE YOU SURE ? Press SEEK to confirm deletion of all saved songs and the display will read ALL DELETED.
  • Page 24 Entertainment Systems 5. TUNE: Press to manually go down/up ( ) the radio frequency and also to select various settings in menu mode. 6. SHUFF (Shuffle): Press to play the current CD/MP3 tracks in random order. In MP3 directory mode, press to play the tracks within the current directory in random order.
  • Page 25 In CATEGORY MODE, press that category. Press in the selected category. Press and hold through the previous /next channels. In TEXT MODE, press display text. Satellite radio is available only with a valid SIRIUS subscription. Check with your authorized dealer for availability. 12.
  • Page 26 Entertainment Systems 15. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
  • Page 27 1. AM/FM: Press to select AM/FM1/FM2 frequency bands. 2. CD: Press to enter CD/MP3 mode. If a CD/MP3 is already in the system, the disc will start playing. 3. AUX: Press to access AUX modes. To return to radio mode, press AM/FM.
  • Page 28 Entertainment Systems SATELLITE RADIO MENU (if equipped): Press MENU when satellite radio mode is active to access. Press SEEK into the satellite radio menu. Press options: • CATEGORY: Press SEEK MENU to scroll through the list of available SIRIUS channel Categories (Pop, Rock, News, etc.) Press SEEK category appears in the display.
  • Page 29 • DELETE ALL SONGS: Press SEEK system’s memory. The display will read ARE YOU SURE ? Press SEEK to confirm deletion of all saved songs and the display will read ALL DELETED. Note: If there are no songs presently saved, the display will read NO SONGS.
  • Page 30 Entertainment Systems 8. TUNE/DISC:In radio mode, press to manually go down/up ) the radio frequency, or to access another CD/MP3. Also use in menu mode to select various settings. 9. SHUFF (Shuffle): Press to play the tracks on the current CD/MP3 in random order.
  • Page 31 15. SEEK/TRACK:In radio, CD and MP3 flat file mode, press to access the previous/next strong station or track. In MP3 directory mode, press to select the next/previous track in the current directory. In satellite radio mode (if equipped), press the previous/next channel. In CATEGORY MODE, press that category.
  • Page 32: Auxiliary Input Jack (Line In)

    Entertainment Systems 18. LOAD: Press to load a CD/MP3. To load a CD/MP3 disc to a specific slot, press LOAD and select the slot number by pressing the memory preset buttons. Press and hold LOAD to autoload up to six discs. 19.
  • Page 33: General Audio Information

    6. Press AUX on the vehicle radio repeatedly until LINE IN appears in the display. You should hear audio from your portable music player although it may be low. 7. Adjust the sound on your portable music player until it reaches the level of the FM station or CD by switching back and forth between the AUX and FM or CD controls.
  • Page 34 • Clean using a circular motion. CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Mazda CD players.
  • Page 35: Satellite Radio Information

    Audio system warranty and service Refer to the Warranty Information Booklet for audio system warranty information. If service is necessary, see your authorized Mazda dealership. Satellite radio information (if equipped) Satellite radio channels: SIRIUS broadcasts a variety of music, news, sports, weather, traffic and entertainment satellite radio channels.
  • Page 36 Mazda Motor Corporation shall not be responsible for any such programming changes. Satellite Radio Electronic Serial Number (ESN): This 12–digit Satellite Serial Number is needed to activate, modify or track your satellite radio account.
  • Page 37 Radio Display ACQUIRING SAT FAULT INVALID CHNL UNSUBSCRIBED NO TEXT Entertainment Systems Condition Radio requires more than two seconds to produce audio for the selected channel. Internal module or system failure present. Channel no longer available. Subscription not available for this channel.
  • Page 38 Entertainment Systems Radio Display NO TEXT NO TEXT NO SIGNAL UPDATING CALL SIRIUS 1–888–539–7474 Condition Song title information not available. Category information not available. Loss of signal from the SIRIUS satellite or SIRIUS tower to the vehicle antenna. Update of channel programming in progress.
  • Page 39: Climate Controls

    HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
  • Page 40: Manual Heating And Air Conditioning

    Climate Controls 4. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. WARNING: Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
  • Page 41 • Under normal weather conditions, do not leave the air flow selector in MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents. • Do not put objects under the front seats that will interfere with the airflow to the back seats.
  • Page 42: Lights

    Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Foglamp control (if equipped) The foglamps can be turned on when the headlamp control is in position and the high beams are not turned on.
  • Page 43: Panel Dimmer Control

    Flash to pass Pull toward you slightly to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: • the ignition must be in the ON position and • the headlamp control is in the OFF or parking lamp. WARNING: Always remember to turn on your headlamps at dusk or during inclement weather.
  • Page 44: Headlamps

    Lights switch from the full dim position to the full Dome/ON position to reset. This will ensure that your displays are visible under all lighting conditions. AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed before leaving the assembly plant.
  • Page 45 3. Turn on the low beam headlamps and open the hood. 4. Locate the high intensity area of the beam pattern and place the top edge of the intensity zone even with the horizontal reference line (4). If the top edge of the high intensity area is not even with the horizontal line, follow the next step to...
  • Page 46: Turn Signal Control

    Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Courtesy/reading lamps (if equipped) The courtesy lamp lights when: • any door is opened. • the instrument panel dimmer switch is held up until the courtesy lamps come on.
  • Page 47 Check the operation of all the bulbs frequently. Replacing headlamp bulbs NOTE: The procedure can be difficult. Your Mazda dealer has the proper tools, training and parts to perform this task. If you have difficulty with this, visit your local Mazda dealer.
  • Page 48 Lights WARNING: Children and Halogen Bulbs: Playing with a halogen bulb is dangerous. Serious injuries could be caused by dropping a halogen bulb or breaking in some other way. Always keep halogen bulbs out of the reach of children. To remove the headlamp bulb: 1.
  • Page 49 tabs in the lamp assembly. When the grooves are aligned, push the bulb into the lamp assembly until the plastic base contacts the rear of the lamp assembly. 2. Install the bulb retaining ring over the plastic base until it contacts the rear of the socket by rotating clockwise until you feel a “stop.”...
  • Page 50 Lights 5. Carefully pull bulb straight out of socket and push in the new bulb. 6. Install the bulb socket in lamp assembly by turning clockwise. 7. Align the lamp on the vehicle and push to snap in place. 8. Install the screw on lamp assembly. Replacing stop lamp/tail lamp/sidemarker lamp/turn lamp/backup lamp bulbs These bulbs are located in the same...
  • Page 51 Replacing fog lamp bulbs WARNING: Handling Halogen Bulbs: When a halogen bulb breaks, it is dangerous. These bulbs contain pressurized gas. If one is broken, it will explode and serious injuries could be caused by the flying glass. If the glass portion of the bulb is touched with bare hands, body oil could cause the bulb to overheat and explode when lit.
  • Page 52 Lights Replacing license plate lamp bulbs The license plate bulbs are located behind the rear bumper. To change the license plate lamp bulbs: 1. Reach behind the rear bumper to locate the bulb socket. 2. Twist the socket counterclockwise and remove. 3.
  • Page 53: Driver Controls

    MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers (from desired interval to low or high speed position); rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...
  • Page 54: Tilt Steering Wheel (If Equipped)

    Driver Controls TILT STEERING WHEEL (IF EQUIPPED) To adjust the steering wheel: 1. Pull and hold the steering wheel release control toward you. 2. Move the steering wheel up or down until you find the desired location. 3. Release the steering wheel release control.
  • Page 55: Power Windows

    The auxiliary power points are located on the instrument panel. Do not use the power point for operating the cigarette lighter element (if equipped). To prevent the fuse from being blown, do not use the power point(s) over the vehicle capacity of 12 VDC/180W.
  • Page 56: Interior Mirror

    Driver Controls Press and pull the window switches to open and close windows. • Push down (to the first detent) and hold the switch to open. • Pull up and hold the switch to close. One touch down Allows the driver’s window to open fully without holding the control down.
  • Page 57: Speed Control

    Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash. SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a set speed without keeping your foot on the accelerator pedal. WARNING: Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
  • Page 58 Driver Controls • If the vehicle speed increases above the set speed on a downhill, you may want to apply the brakes to reduce the speed. • If the vehicle speed decreases more than 10 mph (16 km/h) below your set speed on an uphill, your speed control will disengage. Disengaging speed control To disengage the speed control: •...
  • Page 59 Reducing speed while using speed control There are three ways to reduce a set speed: • Press and hold the CST - control until you get to the desired speed, then release the control. • Press and release the CST - control to operate the Tap-Down function.
  • Page 60: Bed Extender (If Equipped)

    Driver Controls Deactivating overdrive Press the Transmission Control Switch (TCS) located on the end of the gearshift lever. The O/D Off indicator light will illuminate on the instrument cluster. The transmission will operate in all gears except overdrive. To return to normal overdrive mode, press the Transmission Control Switch again.
  • Page 61 Activating bed extender Theft Deterrent Device: The following procedure can be done with the bed extender in the stowed or extended position. 1. Locate the Phillips head screw in the middle of the vertical brace in front of the locking clip.
  • Page 62: Locks And Security

    Locks and Security KEYS The key operates all locks on your vehicle. You should always carry a second key with you in a safe place in case you require it in an emergency. If your vehicle is equipped with the SecuriLock™ Passive Anti-theft system, your keys are coded to your vehicle;...
  • Page 63: Locks

    Your vehicle is equipped with a remote entry system which allows you to: • unlock the vehicle doors without a key. • lock all the vehicle doors without a key. • activate the personal alarm. If there are problems with the remote entry system, make sure to take ALL remote entry transmitters with you to your authorized dealer in order to aid in troubleshooting the problem.
  • Page 64 Locks and Security Note: The panic alarm will only operate when the ignition is in the 2 (LOCK) or 3 (OFF) position. Replacing the battery The remote entry transmitter uses one coin type three-volt lithium battery CR2032 or equivalent. To replace the battery: 1.
  • Page 65 transmitters, you can either reprogram them yourself, or take all remote entry transmitters to your authorized dealer for reprogramming. How to reprogram your remote entry transmitters You must have all remote entry transmitters (maximum of four) available before beginning this procedure. Note: Ensure the brake pedal is not depressed during this sequence.
  • Page 66: Securilock™ Passive Anti-Theft System (If Equipped)

    Note: The SecuriLock™ passive anti-theft system is not compatible with non-Mazda aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
  • Page 67: Anti-Theft System

    Vehicles equipped with the SecuriLock™ Passive Anti-theft system behave as follows: • When the ignition is in the 1(OFF/LOCK) position, the indicator will flash once every 2 seconds for a total of 10 seconds to indicate the SecuriLock™ system is functioning as a theft deterrent. •...
  • Page 68 Locks and Security 1. Insert a previously programmed coded key into the ignition. 2. Turn the ignition from the 3 (OFF) position to the 4 (ON) position. Keep the ignition in the 4 (ON) position for at least one second, but no more than 10 seconds.
  • Page 69: Seating And Safety Restraints

    SEATING Adjusting the front manual seat (if equipped) WARNING: Never adjust the driver’s seat or seatback when the vehicle is moving. The seat could slide too far leaving you unable to operate vital controls just when you need them. WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
  • Page 70 Seating and Safety Restraints Pull lever located at the side of the seat cushion up to adjust seatback. 60/40 seat (if equipped) To gain access to the storage compartment in your armrest (if equipped), lift the latch to open lid. The 60/40 seat cupholder (if equipped) is detachable for cleaning.
  • Page 71: Rear Seats

    To return seat to original position, slide the seat bottom back, then push the seatback up to lock it in place. The seat will lock, and you will have to use the release bar to move the seat back to the original position. REAR SEATS Center facing jump seat (four–door Cab Plus 4) (if equipped) To open, pull seat assembly down,...
  • Page 72 Seating and Safety Restraints • Front passenger sensing system • Passenger Airbag Off indicator light. • Restraints Control Module (RCM) with impact and safing sensors. • Restraint system warning light and back-up tone. • The electrical wiring for the airbags, crash sensor(s), seat belt pretensioners, front seat belt usage sensors, driver seat position sensor, and indicator lights.
  • Page 73 Driver’s seat position sensor The driver’s seat position sensor allows your Personal Safety System™ to tailor the deployment level of the driver dual-stage airbag based on seat position. The system is designed to help protect smaller drivers sitting close to the driver airbag by providing a lower airbag output level. Front passenger sensing system For airbags to do their job they must inflate with great force, and this force can pose a potentially deadly risk to occupants that are very close...
  • Page 74 Seating and Safety Restraints Front seat belt usage sensors The front seat belt usage sensors detect whether or not the driver and front outboard passenger seat belts are fastened. This information allows your Personal Safety System™ to tailor the airbag deployment and seat belt pretensioner activation depending upon seat belt usage.
  • Page 75 If any of these things happen, even intermittently, have the Personal Safety System™ serviced at an authorized dealer immediately. Unless serviced, the system may not function properly in the event of a collision. Safety restraints precautions WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
  • Page 76 Seating and Safety Restraints WARNING: Each seating position in your vehicle has a specific seat belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only. Never wear the shoulder belt under the arm.
  • Page 77 WARNING: The lap belts should fit snugly and as low as possible around the hips, not around the waist. Failure to position the lap belt correctly may cause serious injury in an accident. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from).
  • Page 78 Seating and Safety Restraints movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 5 mph (8 km/h) or more, the combination seat belts will lock to help reduce forward movement of the driver and passengers.
  • Page 79 How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. WARNING: After any vehicle collision, the entire seat belt system should be checked for proper operation by an authorized dealer.
  • Page 80 NOTE: If unsure about the proper procedures, bring your vehicle to an authorized Mazda dealership for inspection. Inspect the seat belts to make sure there are no nicks, tears or cuts, replacing if necessary. Check the automatic locking retractor on the passenger outboard seating position.
  • Page 81 (if equipped), child safety seat tether bracket assemblies (if equipped), and attaching hardware, should be inspected after a collision. Mazda recommends that all seat belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was minor and an authorized Mazda technician finds that the belts do not show damage and continue to operate properly, they do not need to be replaced.
  • Page 82 Seating and Safety Restraints Belt-Minder The Belt-Minder feature is a supplemental warning to the seat belt warning function. This feature provides additional reminders by intermittently sounding a chime and illuminating the seat belt warning light in the instrument cluster when the driver’s and front passenger’s seat belt is unbuckled.
  • Page 83 If... The driver’s or front passenger’s seat belt becomes unbuckled for approximately 1 minute while the vehicle is traveling at least 3 mph (5 km/h) and more than 1-2 minutes have elapsed since the ignition switch has been turned to ON...
  • Page 84 Seating and Safety Restraints Reasons given... Consider... The people I’m Set the example, teen deaths occur 4 times more with don’t wear often in vehicles with TWO or MORE people. belts Children and younger brothers/sisters imitate behavior they see. I have an airbag Airbags offer greater protection when used with seat belts.
  • Page 85 • The parking brake is set • The gearshift is in P (Park) (automatic transmission) • The ignition switch is in the OFF position • The driver and front passenger seat belts are unbuckled WARNING: While the design allows you to deactivate your Belt-Minder , this system is designed to improve your chances of being safely belted and surviving an accident.
  • Page 86: Airbag Supplemental Restraint System (Srs)

    Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) The airbag supplemental restraint system is designed to work in conjunction with the seat belts to help protect the driver and front outboard passenger from certain upper body injuries. The term “supplemental restraint”...
  • Page 87 Seating and Safety Restraints WARNING: Airbags DO NOT inflate slowly or gently and the risk of injury from a deploying airbag is greatest close to the trim covering the airbag module. Always wear your seat belt. WARNING: Airbags have been known to kill or injure a child in front facing child restraints.
  • Page 88 WARNING: Additional equipment may effect the performance of the airbag sensors increasing the risk of injury. Consult your authorized Mazda dealership before installation of additional equipment. WARNING: The front passenger airbag is not designed to offer...
  • Page 89 Children and airbags For additional important safety information, read all information on safety restraints in this guide. WARNING: Do not install a child seat in a center facing jump seat. WARNING: Airbags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active airbag.
  • Page 90 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
  • Page 91 Disposal of airbags and airbag equipped vehicles (including seat belt pretensioners) For disposal of seat belt pretensioners, airbags, or airbag equipped vehicles, see your authorized Mazda dealership or qualified technician. Airbags MUST BE disposed of by qualified personnel. Front passenger sensing system The front passenger sensing system will turn off the front passenger’s...
  • Page 92 Seating and Safety Restraints • the system determines that a small child is present in a booster seat, • a front passenger takes his/her weight off of the seat for a period of time, WARNING: Even with Advanced Restraints Systems, children 12 and under should be properly restrained in the back seat (if equipped).
  • Page 93 the indicator lamp remains lit even after this, then the occupant should be advised to ride in the back seat. Occupant Empty seat Small child in child safety seat or booster Small child with seat belt buckled or unbuckled Adult After all occupants have adjusted their seats and put on seat belts, it’s very important that they continue to sit upright, with their back against the seatback, with their feet comfortably extended on the floor while the...
  • Page 94: Safety Restraints For Children

    Seating and Safety Restraints If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Mazda Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Manual.
  • Page 95 NOTE: Always follow the instructions and warnings that come with any infant or child restraint you might use. WARNING: Do not install a child seat in a center facing jump seat. Children and seat belts If the child is the proper size, restrain the child in a safety seat. Children who are too large for child safety seats (as specified by your child safety seat manufacturer) should always wear seat belts.
  • Page 96 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Mazda recommends use of a belt-positioning booster seat. Booster seats position a child so that seat belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
  • Page 97 Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
  • Page 98 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
  • Page 99: Safety Seats For Children

    80 pounds (36 kg) using an upper torso harness and a belt-positioning booster. Mazda recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage.
  • Page 100 Seating and Safety Restraints WARNING: Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision. Installing child safety seats with combination lap and shoulder belts (front outboard passenger seat only) 1.
  • Page 101 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear...
  • Page 102 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with knee on the child seat. 8. Allow the seat belt to retract to remove any slack in the belt.
  • Page 103: Bucket Seats

    The tether strap anchors in your vehicle are in the following positions (shown from top view): • Bucket seats • 60/40 seats WARNING: Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
  • Page 104 Seating and Safety Restraints 3. Locate the correct anchor for the selected seating position. The tether anchor is located on the rear lower portion of the passenger seat. 4. Clip the tether strap to the anchor. WARNING: If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event...
  • Page 105 Center seating location 60/40 seats with folding armrest When installing a child safety seat in the center position, route the tether strap over the center arm rest and clip it to the center anchor. WARNING: If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision.
  • Page 106: Tires, Wheels And Loading

    Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
  • Page 107 Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter. Information on transfer case maintenance can be found in the Maintenance and Specifications chapter.
  • Page 108: Information About Uniform Tire Quality Grading

    10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Mazda to give you the following information about tire grades exactly as the government has written it.
  • Page 109 Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
  • Page 110: Inflating Your Tires

    Tires, Wheels and Loading Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry. • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacture.
  • Page 111 (if equipped), at least monthly and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Mazda recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge.
  • Page 112 Tires, Wheels and Loading door. The cold inflation pressure should never be set lower than the recommended pressure on the Safety Compliance Certification Label or Tire Label. When weather temperature changes occur, tire inflation pressures also change. A 10° F (6° C) temperature drop can cause a corresponding drop of 1 psi (7 kPa) in inflation pressure.
  • Page 113: Tire Care

    Tires, Wheels and Loading 7. Check the sidewalls to make sure there are no gouges, cuts or bulges. TIRE CARE Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves.
  • Page 114 Tires, Wheels and Loading WARNING: Age Tires degrade over time depending on many factors such as weather, storage conditions, and conditions of use (load, speed, inflation pressure, etc.) the tires experience throughout their lives. In general, tires should be replaced after six years regardless of tread wear.
  • Page 115 Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door. If this information is not found on these labels then you should consult your Mazda dealer. Use of any tire or wheel not recommended by Mazda can affect the safety...
  • Page 116 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Mazda Motor Corporation may affect the operation of your Tire Pressure Monitoring System.
  • Page 117 Wheel misalignment in the front or the rear can cause uneven and rapid treadwear of your tires and should be corrected by a qualified technician at a Mazda dealer. Front wheel drive (FWD) vehicles and those with an independent rear suspension require alignment of all four wheels.
  • Page 118 Tires, Wheels and Loading • Front Wheel Drive (FWD) vehicles (front tires at top of diagram) • Rear Wheel Drive (RWD) vehicles/Four Wheel Drive (4WD)/All Wheel Drive (AWD) vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires.
  • Page 119: Information Contained On The Tire Sidewall

    Note: If your tires show uneven wear ask a qualified technician at a Mazda dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. Note: Your vehicle may be equipped with a dissimilar spare tire/wheel. A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that is different in brand, size or appearance from the road tires and wheels.
  • Page 120 Tires, Wheels and Loading 4. R: Indicates a “radial” type tire. 5. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter. 6.
  • Page 121 8. U.S. DOT Tire Identification Number (TIN): This begins with the letters “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
  • Page 122 Tires, Wheels and Loading 13. Maximum Permissible Inflation Pressure: Indicates the tire manufacturers’ maximum permissible pressure and/or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure which can be found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
  • Page 123 Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
  • Page 124: Tire Pressure Monitoring System (Tpms)

    Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
  • Page 125 following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: The Tire Pressure Monitoring System is NOT a substitute for manually checking tire pressure. The tire pressure should be checked periodically (at least monthly) using a tire gauge, see Inflating your tires in this chapter.
  • Page 126 Tires, Wheels and Loading When your temporary spare tire is installed When one of your road tires needs to be replaced with the temporary spare, the TPMS system will continue to identify an issue to remind you that the damaged road wheel/tire needs to be repaired and put back on your vehicle.
  • Page 127 Low Tire Pressure Possible cause Customer Action Required Warning Light Solid Warning Light Tire(s) under-inflated Spare tire in use Your temporary spare tire is in TPMS malfunction Tires, Wheels and Loading 1. Check your tire pressure to ensure tires are properly inflated;...
  • Page 128 Tires, Wheels and Loading Low Tire Pressure Warning Light Flashing Warning Light When inflating your tires When putting air into your tires (such as at a gas station or in your garage), the Tire Pressure Monitoring System may not respond immediately to the air added to your tires.
  • Page 129: Snow Tires And Chains

    any tire is under-inflated, carefully drive the vehicle to the nearest location where air can be added to the tires. Inflate all the tires to the recommended inflation pressure. SNOW TIRES AND CHAINS WARNING: Driving too fast for conditions creates the possibility of loss of vehicle control.
  • Page 130 Tires, Wheels and Loading provide maximum return of vehicle design performance. Before loading your vehicle, familiarize yourself with the following terms for determining your vehicle’s weight ratings, with or without a trailer, from the vehicle’s Tire Label or Safety Compliance Certification Label: Base Curb Weight –...
  • Page 131 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
  • Page 132 MFD. BY FORD MOTOR CO. IN U.S.A. FOR MAZDA MOTOR CORPORATION DATE: XX/XX GVWR:XXXXXLB/ XXXXXKG FRONT GAWR: XXXXL REAR GAWR:...
  • Page 133 GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
  • Page 134 Tires, Wheels and Loading WARNING: Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
  • Page 135: Trailer Towing

    to transport the cement to your home? If you and your friend each weigh 220 lb. (99 kg), the calculation would be: 1400 - (2 x 220) - (12 x 100) = 1400 - 440 - 1200 = - 240 lb. No, you do not have enough cargo capacity to carry that much weight.
  • Page 136 Tires, Wheels and Loading 4x2 w/manual transmission Engine Rear axle ratio 2.3L 3.0L* 3.73 3.0L* Dual 4.10 Sport 2.3L 3.0L* 3.73 3.0L* Dual 4.10 Sport 4.0L 4.0L Dual Sport For high altitude operation, reduce GCW by 2% per 1,000 ft. (300 meters) elevation.
  • Page 137 4x4 w/manual transmission Engine Rear axle ratio 3.0L* 4.0L 4.0L For high altitude operation, reduce GCW by 2% per 1,000 ft. (300 meters) of elevation. *When towing on roads with steep grades or moderate but long sustained grades (5 miles [8 km] or more), or when ambient temperatures exceed 100°F (37°C), vehicle speed should not exceed 45 mph (72 km/h) in both cases.
  • Page 138 Tires, Wheels and Loading 4x2 w/automatic transmission Engine Rear axle ratio 2.3L 4.10 3.0L* 3.73 3.0L* Dual 4.10 Sport 4.0L 4.0L Dual Sport For high altitude operation, reduce GCW by 2% per 1,000 ft. (300 meters) elevation. *When towing on roads with steep grades or moderate but long sustained grades (5 miles [8 km] or more), or when ambient temperatures exceed 100°F (37°C), vehicle speed should not exceed 45 mph (72 km/h) in both cases.
  • Page 139 4x4 w/automatic transmission Engine Rear axle ratio 3.0L* 3.73 4.0L 4.0L For high altitude operation, reduce GCW by 2% per 1,000 ft. (300 meters) of elevation. *When towing on roads with steep grades or moderate but long sustained grades (5 miles [8 km] or more), or when ambient temperatures exceed 100°F (37°C), vehicle speed should not exceed 45 mph (72 km/h) in both cases.
  • Page 140 Tires, Wheels and Loading Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle. See your authorized dealer or a reliable trailer dealer if you require assistance. Hitches For towing trailers up to 2,000 lb. (907 kg), use a weight carrying hitch and ball which uniformly distributes the trailer tongue loads through the underbody structure.
  • Page 141 Tires, Wheels and Loading Trailer lamps Trailer lamps are required on most towed vehicles. Make sure all running lights, brake lights, turn signals and hazard lights are working. See your authorized dealer or trailer rental agency for proper instructions and equipment for hooking up trailer lamps.
  • Page 142 Tires, Wheels and Loading Refer to the following chart for information regarding the factory-equipped trailer tow connector: Trailer tow connector Color Function 1. Dark Green Trailer right-hand turn signal 2. Yellow Trailer left-hand turn signal 3. Tan/White Tail lamp 4. White Ground Driving while you tow When towing a trailer:...
  • Page 143 • Anticipate stops and brake gradually. • Do not exceed the GCWR rating or transmission damage may occur. Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your scheduled maintenance information for more information.
  • Page 144: Recreational Towing

    Tires, Wheels and Loading Exceeding these limits may allow water to enter vehicle components: • causing internal damage to the components. • affecting driveability, emissions and reliability. Replace the rear axle lubricant any time the axle has been submerged in water.
  • Page 145: Camper Bodies

    Tires, Wheels and Loading • Place the transmission in N (Neutral). • Do not exceed a distance of 50 miles (80 km). • Do not exceed 35 mph (56 km/h) vehicle speed. • Put 4x4 switch in 2WD mode (4x4 only) •...
  • Page 146: Driving

    Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. For vehicles equipped with a manual transmission, you must depress the ignition release lever to release the key.
  • Page 147 When starting a fuel-injected engine, don’t press the accelerator before or during starting. Only use the accelerator when you have difficulty starting the engine. For more information on starting the vehicle, refer to Starting the engine in this chapter. WARNING: Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage.
  • Page 148 Driving If starting a vehicle with an automatic transmission: • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: 1. Make sure the parking brake is set.
  • Page 149 • steering wheel is turned when getting in or out of the vehicle Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights. Starting the engine Note: Whenever you start your vehicle, release the key as soon as the engine starts.
  • Page 150: Engine Block Heater - If Equipped

    Driving ENGINE BLOCK HEATER (IF EQUIPPED) An engine block heater warms the engine coolant which aids in starting and allows the heater/defroster system to respond quickly. If your vehicle is equipped with this system, your equipment includes a heater element which is installed in your engine block and a wire harness which allows the user to connect the system to a grounded 120 volt a/c electrical source.
  • Page 151: Brakes

    • Be sure that areas where the vehicle is parked are clean and clear of all combustibles such as petroleum products, dust, rags, paper and similar items. • Be sure that the engine block heater, heater cord and extension cord are solidly connected.
  • Page 152 Driving travel a little farther as soon as ABS braking is done and normal brake operation resumes. Pedal pulsation coupled with noise while braking under panic conditions or on loose gravel, bumps, wet or snowy roads is normal and indicates proper functioning of the vehicle’s anti-lock brake system.
  • Page 153 ABS warning lamp The ABS lamp in the instrument cluster momentarily illuminates when the ignition is turned on. If the light does not illuminate during start up, remains on or flashes, the ABS may be disabled and may need to be serviced. Even when the ABS is disabled, normal braking is still effective.
  • Page 154 Driving rear brakes, the vehicle’s stopping distance will increase greatly and the handling of your vehicle will be adversely affected. Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy.
  • Page 155: Traction-Lok Axle (If Equipped)

    • Loose or worn suspension components TRACTION-LOK AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface. Under normal conditions, the Traction-Lok axle functions like a standard rear axle. The axle may exhibit a slight noise or vibration in tight turns with low vehicle speed.
  • Page 156: Automatic Transmission Operation (If Equipped)

    Driving AUTOMATIC TRANSMISSION OPERATION (IF EQUIPPED) Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless the brake pedal is depressed. If you cannot move the gearshift lever out of P (Park) with ignition in the ON position and the brake pedal depressed: 1.
  • Page 157 WARNING: If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized dealer. Driving with a 5–speed automatic transmission (if equipped) This vehicle is equipped with an adaptive Transmission Shift Strategy. Adaptive Shift Strategy offers the optimal transmission operation and shift quality.
  • Page 158 Driving WARNING: Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse).
  • Page 159: Manual Transmission Operation (If Equipped)

    2 (Second) Use 2 (Second) to start-up on slippery roads or to provide additional engine braking on downgrades. 1 (First) • Provides maximum engine braking. • Allows upshifts by moving gearshift lever. • Will not downshift into 1 (First) at high speeds; allows for 1 (First) when vehicle reaches slower speeds.
  • Page 160 Driving Failure to fully depress the clutch pedal to the floor may cause increased shift efforts, prematurely wear transmission components or damage the transmission. Do not drive with your foot resting on the clutch pedal or use the clutch pedal to hold your vehicle at a standstill while waiting on a hill.
  • Page 161: Four-Wheel Drive (4Wd) Operation (If Equipped)

    3. Turn the ignition off. WARNING: Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Removing the key Turn the ignition off, push the release lever (located above the ignition), then turn the key toward you and remove the key.
  • Page 162 Driving 4WD system indicator lights • 4x4 - Momentarily illuminates when the vehicle is started. Illuminates when 4H (4WD High) is engaged. • 4x4 LOW – Momentarily illuminates when the vehicle is started. Illuminates when 4L (4WD Low) is engaged. Using the electronic shift 4WD system 2H (2WD High) - Power to the rear wheels only;...
  • Page 163 2. On vehicles equipped with an automatic transmission, place the transmission in N (Neutral); on vehicles equipped with a manual transmission, depress the clutch. 3. Move the 4WD control to the desired position. • If shifting into 4L (4WD Low), wait for the 4WD LOW light in the instrument cluster to turn on indicating the shift is complete.
  • Page 164 Driving If your vehicle goes off the edge of the pavement • If your vehicle goes off the edge of the pavement, slow down, but avoid severe brake application, ease the vehicle back onto the pavement only after reducing your speed. Do not turn the steering wheel too sharply while returning to the road surface.
  • Page 165 Emergency maneuvers • In an unavoidable emergency situation where a sudden sharp turn must be made, remember to avoid “over-driving” your vehicle, i.e., turn the steering wheel only as rapidly and as far as required to avoid the emergency. Excessive steering will result in less vehicle control, not more.
  • Page 166 Driving When driving through water, determine the depth; avoid water higher than the bottom of the hubs (if possible) and proceed slowly. If the ignition system gets wet, the vehicle may stall. Once through water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes.
  • Page 167: Driving Through Water

    Driving Driving on snow and ice A 4WD vehicle has advantages over 2WD vehicles in snow and ice but can skid like any other vehicle. Avoid sudden applications of power and quick changes of direction on snow and ice. Apply the accelerator slowly and steadily when starting from a full stop.
  • Page 168: Roadside Emergencies

    Roadside Emergencies HAZARD FLASHER CONTROL The hazard flasher is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Push in the flasher control and all front and rear direction signals will flash.
  • Page 169: Fuses And Relays

    The fuel pump shut-off switch is located on the right side of the passenger footwell, behind the fuse panel door. To reset the switch: 1. Turn the ignition OFF. 2. Check the fuel system for leaks. 3. If no leaks are apparent, reset the switch by pushing in on the reset button.
  • Page 170 Roadside Emergencies Standard fuse amperage rating and color Fuse Mini rating fuses Grey Violet Pink 7.5A Brown Blue Yellow Natural Green — — — — — Passenger compartment fuse panel The fuse panel is located under the right-hand side of the instrument panel behind the kick panel.
  • Page 171 The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating Roadside Emergencies Passenger Compartment Fuse Panel Description Instrument panel dimmer switch Trailer tow park lamps Right low beam headlamp Left low beam headlamp Windshield wiper module (RUN/ACCY) Radio (RUN/ACCY), Door switch illumination Not used (spare) Restraints Control Module (RCM), PADI...
  • Page 172 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating 30A cartridge fuse Passenger Compartment Fuse Panel Cluster (RUN/START), 4x4 module (RUN/START) Smart Junction Box (SJB) (Logic power) Audiophile subwoofer amplifier, Satellite radio Horn, Interior lamps High beam headlamp, High beam indicator (cluster) —...
  • Page 173 Fuse/Relay Fuse Amp Location Rating Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. WARNING: Always disconnect the battery before servicing fuses.
  • Page 174 Roadside Emergencies 2.3L engine (if equipped) The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating 40A** 40A** 50A** 30A** 40A** 30A** 30A** Power Distribution Box Description Passenger compartment fuse panel — Not used Passenger compartment fuse panel —...
  • Page 175 Fuse/Relay Fuse Amp Location Rating — — 40A** — 20A** — 10A* — 30A* — 10A* — — — 30A* — — — 30A* — — — — 7.5A* 15A* — 10A* 7.5A* 20A* Roadside Emergencies Power Distribution Box Description Not used Not used Anti-lock Brake System (ABS) module...
  • Page 176 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating 15A* * Mini Fuses ** Maxi Fuses Power Distribution Box Description Ignition coil, Capacitor — Not used — Not used — Fuel pump relay, Fuel injectors relay — Not used — Engine fan relay —...
  • Page 177 3.0L and 4.0L engines (if equipped) The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating 40A** 40A** 50A** 30A** 40A** 30A** 30A** Roadside Emergencies Power Distribution Box Description Passenger compartment fuse panel — Not used Passenger compartment fuse panel —...
  • Page 178 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating 40A** 10A* 30A* 10A* 20A* 30A* 15A* 30A* 7.5A* 15A* 10A* 7.5A* 20A* Power Distribution Box Description — Not used — Not used Anti-lock Brake System (ABS) module — Not used — Not used —...
  • Page 179: Changing Tires

    Fuse/Relay Fuse Amp Location Rating 15A* * Mini Fuses ** Maxi Fuses CHANGING THE TIRES If you get a flat tire while driving: • do not brake heavily. • gradually decrease the vehicle’s speed. • hold the steering wheel firmly. •...
  • Page 180 Mazda. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
  • Page 181 Roadside Emergencies • Comfort and noise • Ground clearance and parking at curbs • Winter weather driving capability • Wet weather driving capability For vehicles equipped with 4WD, it is not recommended that the vehicle be operated in 4WD modes with a temporary emergency spare tire. If 4WD operation is necessary, do not operate above speeds of 10 mph (16 km/h) or for distances above 50 miles (80 km).
  • Page 182 Roadside Emergencies Stopping and securing the vehicle 1. Park on a level surface, activate hazard flashers and place gearshift lever in P (Park) (automatic transmission) or 1 (First) (manual transmission). 2. Set the parking brake and turn engine OFF. Location of the spare tire and tools Note: The tire pressure monitoring system (TPMS) indicator light will illuminate when the spare is in use.
  • Page 183 When connecting the jack handle, assemble the following: • one handle extension and one typical extension. To assemble, slide parts together. To disconnect, depress button and pull apart. • one wheel nut wrench. Depress button and slide together. 2. If equipped, unlock and remove the spare tire carrier lock from the rear access hole located just above the rear bumper and...
  • Page 184 Roadside Emergencies 3. Insert the square end of the jack handle into the rear access hole located just above the rear bumper and below the tailgate. Forward motion will stop and resistance to turning will be felt when properly engaged. 4.
  • Page 185 1. Block the diagonally opposite wheel. 2. Insert tapered end of the lug wrench behind hub caps and twist them off. 3. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground.
  • Page 186 Roadside Emergencies • Rear Never use the differential as a jacking point. It is too easy for the vehicle to tilt or fall and you can be injured. 5. Remove the wheel lug nuts with the lug wrench. 6. Replace the flat tire with the spare tire, making sure the valve stem is facing outward.
  • Page 187: Wheel Lug Nut Torque Specifications

    Lug nut socket size: ⁄ (19 mm) hex Bolt size: ⁄ x 20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Mazda recommended replacement fasteners. Roadside Emergencies Wheel lug nut torque* lb.ft. inch N•m...
  • Page 188: Overheating

    Roadside Emergencies WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel. Ensure that any fasteners that attach the rotor to the hub are secured so they do not interfere with the mounting surfaces of the wheel.
  • Page 189: Jump Starting

    • If steam is coming from the engine compartment: do not go near the front of the vehicle. Stop the engine, then turn the ignition switch to the ON position without starting the engine. The radiator cooling fans will start to cool the engine. •...
  • Page 190 Roadside Emergencies transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission. Over time, the adaptive learning process will fully update transmission operation. 1. Use only a 12–volt supply to start your vehicle. 2.
  • Page 191 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. Roadside Emergencies...
  • Page 192 Roadside Emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the fuel injection system. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. WARNING: Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
  • Page 193 Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
  • Page 194 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
  • Page 195: Wrecker Towing

    It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Mazda has not approved a slingbelt towing procedure. On 4x2 vehicles, it is acceptable to tow the vehicle with the front wheels on the ground and the rear wheels off the ground.
  • Page 196: Customer Assistance

    STEP 1: Contact Your Authorized Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the authorized dealer or the OWNER.
  • Page 197: Customer Assistance (Canada)

    STEP 2: Call the Mazda Regional Office If you feel that you still require assistance, ask the authorized dealer Service Manager to arrange for you to meet the local Mazda Service Representative. If more expedient, contact Mazda Canada Inc. Regional Office nearest you for such arrangements.
  • Page 198 Your complete satisfaction is the goal of Mazda Canada Inc. and our authorized dealers. Mazda’s participation in CAMVAP makes a valuable contribution to our achieving that goal.
  • Page 199 (514) 694–6390 CUSTOMER ASSISTANCE (PUERTO RICO & VIRGIN ISLANDS) Your complete and permanent satisfaction is our business. That is why all Authorized Mazda Dealers have the knowledge and the tools to keep your Mazda vehicle in top condition. Customer Assistance...
  • Page 200 Mazda Dealer personnel, we recommend that you take the following steps: STEP 1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the authorized dealer or the OWNER.
  • Page 201: In California (U.s. Only)

    In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Mazda North American Operations 7755, Irvine Center Drive Irvine, CA 92618–2922 MAZDA IMPORTERS/DISTRIBUTORS U.S.A (Importer/Distributor)
  • Page 202 Richmond Hill, Ontario L4B 3K5 Canada TEL: 1 (800) 263–4680 (in Canada) (416) 609–9909 (outside Canada) PUERTO RICO & VIRGIN ISLANDS Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936–2722 TEL: (787) 788–9300 GUAM (d.b.a.
  • Page 203 NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety requirements.
  • Page 204: Add-On Non-Genuine Parts And Accessories

    ADD-ON NON-GENUINE PARTS AND ACCESSORIES Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by the manufacturer for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle’s performance or...
  • Page 205: Service Publications

    Mazda assumes no responsibility for death, injury, or expenses that may result from the installation of add-on non-genuine parts or accessories. SERVICE PUBLICATIONS Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair.
  • Page 206: Reporting Safety Defects (U.s. Only)

    However, NHTSA cannot become involved in individual problems between you, your dealer or Mazda Corporation. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
  • Page 207: Cleaning

    WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo. • Never use strong household detergents or soap, such as dish washing or laundry liquid. These products can discolor and spot painted surfaces. •...
  • Page 208: Aluminum Wheels And Covers

    • Spray Engine Shampoo and Degreaser (0000–77–410E-09), available at your authorized Mazda dealer, on all parts that require cleaning and pressure rinse clean. • Cover the highlighted areas to prevent water damage when cleaning...
  • Page 209 Cleaning • 2.3L Engine • 3.0L Engine...
  • Page 210: Plastic (Non-Painted) Exterior Parts

    • For routine cleaning, use cool or lukewarm water with a neutral pH shampoo. • If tar or grease spots are present, use Extra Strength Tar and Road Oil Remover (0000–77–410E-01), available at your authorized Mazda dealer. WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly.
  • Page 211: Instrument Panel / Interior Trim And Cluster Lens

    INSTRUMENT PANEL / INTERIOR TRIM AND CLUSTER LENS Clean the interior trim areas and instrument panel with a damp cloth, then with a clean, dry cloth, or use Mazda Deluxe Leather and Vinyl Cleaner (0000-77-430E-15). • Avoid cleaners or polish that increase the gloss of the upper portion of the instrument panel.
  • Page 212 MAZDA CAR CARE PRODUCTS Your Mazda dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
  • Page 213: Maintenance And Specifications

    Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda’s original equipment may perform maintenance. But we recommend that it always be done by an authorized Mazda Dealer using genuine Mazda parts.
  • Page 214: Chart Symbols

    Maintenance and Specifications CHART SYMBOLS I: Inspect and if necessary, correct, clean or replace A Adjust R: Replace L: Lubricate Normal driving service intervals — perform at the months or distances shown, whichever occurs first. Maintenance Item x 1000 miles (x 1000 km) ENGINE Engine oil...
  • Page 215 Maintenance Item x 1000 miles (x 1000 km) Disc brake system Caliper slide rails Drum brake system, lines and hoses Exhaust system for leaks, damage, looseness Manual transmission fluid Automatic transmission fluid Exhaust system shielding (for trapped material) Propeller shaft U-joints (if equipped with grease fittings) Parking brake system (for damage and operation)
  • Page 216 Maintenance and Specifications *5 The California Air Resources Board has determined that the failure to perform this maintenance item will not nullify the emission warranty nor limit recall liability prior to completion of the vehicle’s useful life. Schedule 1 continued Maintenance Item x 1000 miles (x 1000 km)
  • Page 217 Maintenance Item x 1000 miles (x 1000 km) Exhaust system for leaks, damage, looseness Manual transmission fluid Automatic transmission fluid Exhaust system shielding (for trapped material) Propeller shaft U-joints (if equipped with grease fittings) Parking brake system (for damage and operation) Ball joints (4x2) Transfer case fluid (4x4) Rear axle lubricant...
  • Page 218 (door-to-door delivery, taxi, police, power/utility company trucks, or similar duty), then Mazda recommends you increase the frequency of oil and filter changes to an interval equivalent to 200 ENGINE HOURS or use. Since most vehicles are not equipped with hour-meters, it may be necessary for you to approximate your idle time and plan oil/filter changes accordingly.
  • Page 219 Operating in dusty conditions such as unpaved or dusty roads Off road operation For specific recommendations see your authorized Mazda dealer or qualified service professional. Maintenance and Specifications 5,000 15,000 30,000 60,000 miles...
  • Page 220: Owner Maintenance

    The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible. While operating your vehicle •...
  • Page 221: Service Recommendations

    Use only recommended fuels, lubricants, fluids and service parts conforming to specifications. Genuine Mazda parts are designed and built to provide the best performance in your vehicle. PRECAUTIONS WHEN SERVICING YOUR VEHICLE •...
  • Page 222: Opening The Hood

    Maintenance and Specifications 2. Turn off the engine and remove the key. 3. Block the wheels. • Manual transmission/transaxle: 1. Set the parking brake, depress the clutch and place the gearshift in 1 (First). 2. Turn off the engine and remove the key. 3.
  • Page 223: Engine Compartment

    IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.3L I4 engine 1. Windshield washer fluid reservoir 2. Engine coolant reservoir 3. Engine oil dipstick 4. Transmission fluid dipstick (automatic transmission) 5. Engine oil filler cap 6. Brake fluid reservoir 7. Power distribution box 8.
  • Page 224 Maintenance and Specifications 3.0L V6 engine 1. Engine coolant reservoir 2. Windshield washer fluid reservoir 3. Engine oil filler cap 4. Transmission fluid dipstick (automatic transmission) 5. Engine oil dipstick 6. Brake fluid reservoir 7. Power distribution box 8. Clutch fluid reservoir (manual transmission) 9.
  • Page 225 4.0L SOHC V6 engine 1. Windshield washer fluid reservoir 2. Transmission fluid dipstick (automatic transmission) 3. Engine oil filler cap 4. Engine oil dipstick 5. Brake fluid reservoir 6. Power distribution box 7. Clutch fluid reservoir (manual transmission) 8. Battery 9.
  • Page 226: Windshield Washer Fluid

    In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Mazda specification . Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
  • Page 227: Engine Oil

    Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
  • Page 228 Maintenance and Specifications • 2.3L I4 engine • 3.0L V6 engine...
  • Page 229 • 4.0L SOHC V6 engine 6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is between the two holes or between the MIN and MAX marks (depending on application), the oil level is acceptable, DO NOT ADD OIL.
  • Page 230 Maintenance and Specifications • 3.0L V6 engine SAE 5W-20 • 4.0L SOHC V6 engine SAE 5W-30 • Oil levels above the MAX mark or upper hole may cause engine damage. Some oil must be removed from the engine by an authorized dealer.
  • Page 231 7. Put the dipstick back in and ensure it is fully seated. Adding engine oil 1. Check the engine oil. For instructions, refer to Checking the engine oil in this chapter. 2. If the engine oil level is not within the normal range, add only certified engine oil of the recommended viscosity.
  • Page 232 Maintenance and Specifications automobile manufacturers. Use an equivalent oil Mazda specification. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine. Change your engine oil and filter according to the appropriate schedule listed in scheduled maintenance.
  • Page 233: Battery

    Maintenance and Specifications oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Mazda Material and design specifications, start-up engine noises or knock may be experienced. Mazda production and replacement oil filters are designed for added engine protection and long life.
  • Page 234 Maintenance and Specifications It is recommended that the negative battery cable terminal be disconnected from the battery if you plan to store your vehicle for an extended period of time. This will minimize the discharge of your battery during storage. WARNING: Batteries normally produce explosive gases which can cause personal injury.
  • Page 235: Engine Coolant

    Checking engine coolant Your engine’s cooling system has been factory-filled with a 50/50 mixture of distilled water and Mazda Genuine Engine Coolant, or an equivalent premium engine coolant that meets Mazda specification. A 50/50 mixture of distilled water and Mazda Genuine Engine Coolant provides: •...
  • Page 236 Maintenance and Specifications • an accurate temperature readout from the engine coolant gauge. The engine coolant must be maintained at the correct fluid level and concentration to work properly. If the engine coolant fluid level and concentration is not maintained correctly, damage to the engine and cooling system may result.
  • Page 237 • 3.0L & 4.0L engines When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
  • Page 238 Maintenance and Specifications Adding engine coolant Use only Mazda Genuine Engine Coolant or a premium engine coolant that meets a Mazda specification. • DO NOT USE Extended Life Engine Coolant (orange in color). • DO NOT USE a DEX-COOL engine coolant or an equivalent engine coolant.
  • Page 239 For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool. Add the proper mixture of coolant and water to the “FULL COLD” level. For all other vehicles, which have a coolant degas system with a pressurized cap, or if it is necessary to remove the coolant pressure relief cap on the radiator of a vehicle with an overflow system, follow these steps to add engine coolant.
  • Page 240 Recycled engine coolant Not all coolant recycling processes produce coolant which meets Mazda specification. Use of a recycled engine coolant which does not meet Mazda specifications may harm engine and cooling system components.
  • Page 241: Fuel Filter

    Replace the fuel filter with an authorized Mazda part. The customer warranty may be void for any damage to the fuel system if an authorized Mazda fuel filter is not used.
  • Page 242 Maintenance and Specifications WARNING: Gasoline may contain benzene, which is a cancer-causing agent. Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling.
  • Page 243 WARNING: The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container. Use the following guidelines to avoid electrostatic charge build-up when filling an ungrounded fuel container: •...
  • Page 244 Repairs to correct the effects of using a fuel for which your vehicle was not designed may not be covered by your warranty. Cleaner air Mazda endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the Right Fuel section.
  • Page 245 Octane recommendations Your vehicle is designed to use “Regular” unleaded gasoline with pump (R+M)/2 octane rating of 87. We do not recommend the use of gasolines labeled as “Regular” that are sold with octane ratings of 86 or lower in high altitude areas. Do not be concerned if your engine sometimes knocks lightly.
  • Page 246: Essentials Of Good Fuel Economy

    Maintenance and Specifications • Normally, adding 1 gallon (3.8L) of fuel is enough to restart the engine. If the vehicle is out of fuel and on a steep grade, more than 1 gallon (3.8L) may be required. • The indicator may come on. For more information on the “check engine”...
  • Page 247 • Always use fuel with the recommended octane rating. • Use a known quality gasoline, preferably a national brand. • Use the same side of the same pump and have the vehicle facing the same direction each time you fill up. •...
  • Page 248 Maintenance and Specifications • Anticipate stopping; slowing down may eliminate the need to stop. • Sudden or hard accelerations may reduce fuel economy. • Slow down gradually. • Driving at reasonable speeds (traveling at 55 mph [88 km/h] uses 15% less fuel than traveling at 65 mph [105 km/h]).
  • Page 249: Emission Control System

    If other than Mazda authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Mazda parts should be equivalent to genuine Mazda parts in performance and durability. Maintenance and Specifications...
  • Page 250 Maintenance and Specifications WARNING: Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power, could indicate that the emission control system is not working properly.
  • Page 251 4. Driving through deep water—the electrical system may be wet. These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel, properly tightening the fuel cap or letting the electrical system dry out. After three driving cycles without these or any other temporary malfunctions present, the the next time the engine is started.
  • Page 252: Power Steering Fluid

    Maintenance and Specifications 15 minutes of steady driving on an expressway/highway followed by 20 minutes of stop-and-go driving with at least four 30-second idle periods. Allow the vehicle to sit for at least eight hours without starting the engine. Then, start the engine and complete the above driving cycle. The engine must warm up to its normal operating temperature.
  • Page 253 • 4.0L V6 engine Check the power steering fluid. Refer to the service maintenance section for the service interval schedules. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
  • Page 254: Brake Fluid

    During normal operation, the fluid level in the clutch reservoir should remain constant. If the fluid level drops, refill the fluid level to the step in the reservoir. Use only a DOT 3 brake fluid designed to meet Mazda specification. Refer to Maintenance product specifications and capacities in this chapter.
  • Page 255: Transmission Fluid

    TRANSMISSION FLUID Checking automatic transmission fluid • Refer to scheduled maintenance information for scheduled check and change intervals. • Transmission does not consume fluid. • Check fluid when transmission is not operating properly or if you see a leak. • Fluid level must be checked at normal operating temperature, 20 miles (30 km) of driving.
  • Page 256 Maintenance and Specifications Low fluid level Do not drive the vehicle if the fluid level is at or below the bottom of the dipstick. High fluid level Fluid levels above the safe range may cause overheating, shift and/or engagement concerns and internal transmission damage.
  • Page 257: Transfer Case Fluid (If Equipped)

    8. Install and tighten the fill plug securely. Use only fluid that meets Mazda specifications. Refer to the Maintenance product specifications and capacities section in this chapter. TRANSFER CASE FLUID (IF EQUIPPED) 1.
  • Page 258: Driveline Universal Joint And Slip Yoke

    AIR FILTER Refer to scheduled maintenance for the appropriate intervals for changing the air filter element. When changing the air filter element, only use a genuine Mazda air filter element. WARNING: To reduce the risk of vehicle damage and/or personal burn injuries do not start your engine with the air cleaner removed and do not remove it while the engine is running.
  • Page 259 1. Loosen the clamp that secures the air inlet tube to the engine air filter cover and disconnect the tube from the cover (for V6 only). 2. Release the clamps that secure the air filter housing cover. 3. Carefully separate the two halves of the air filter housing.
  • Page 260 Maintenance and Specifications...
  • Page 261 Maintenance and Specifications...
  • Page 262 Maintenance and Specifications...
  • Page 263 Maintenance and Specifications...
  • Page 264: Engine Specifications

    Maintenance and Specifications ENGINE SPECIFICATIONS Engine 2.3L I4 engine 3.0L V6 engine 4.0L V6 engine Cubic inches Required fuel 87 octane Firing order 1-3-4-2 Spark plug gap 0.049–0.053 inch (1.25–1.35mm) Ignition system EDIS Compression 9.7:1 ratio Engine drivebelt routing • 2.3L I4 Engine without A/C (with A/C similar) •...
  • Page 265 Maintenance and Specifications • 3.0L V6 Engine with A/C • 4.0L V6 Engine...
  • Page 266: Instrument Panel

    Please note that in the graphic, XXXX is representative of your vehicle identification number. MFD. BY FORD MOTOR CO. IN U.S.A. FOR MAZDA MOTOR CORPORATION DATE: XX/XX GVWR:XXXXXLB/ XXXXXKG FRONT GAWR: XXXXL REAR GAWR: WITH...
  • Page 267: Transmission/Transaxle Code Designations

    Description Five-speed automatic (5R44E/5R55E) Five-speed manual (HD) Five-speed manual (R1) Maintenance and Specifications MFD. BY FORD MOTOR CO. IN U.S.A. FOR MAZDA MOTOR CORPORATION DATE: XX/XX FRONT GAWR: XXXXL XXXXKG XXXX/XXXXXXX XXXX.XX AT XXX kPa/XX THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR VEHICLE SAFETY AND THEFT PREVENTION STANDARDS IN EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.
  • Page 268: Accessories

    Accessories CELL PHONES Use of cell phones and other devices by driver: WARNING: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver’s hands.
  • Page 269: Index

    ...102 Child safety seats - booster seats ...96 Chimes (warning) ...17 Cleaning your vehicle engine compartment ...208 instrument panel ...211 interior ...211 Mazda car care products ...212 plastic parts ...210 washing ...207 waxing ...207 wheels ...208 Index...
  • Page 270 Index wiper blades ...210 Clock adjust AM/FM Stereo ...20 AM/FM stereo CD ...21 Premium AM/FM stereo CD6/MP3 ...27 Clutch fluid ...254 operation while driving ...159 recommended shift speeds ...160 Console ...54 Coolant checking and adding ...235 refill capacities ...240 specifications ...260 Cruise control (see Speed control) ...57 Customer...
  • Page 271 octane rating ...245, 264 quality ...245 running out of fuel ...245 safety information relating to automotive fuels ...241 Fuel pump shut-off switch ...168 Fuses ...169–170 Gas cap (see Fuel cap) ...243 Gas mileage (see Fuel economy) ...246 Gauges ...17 Hazard flashers ...168 Headlamps ...42 aiming ...44 bulb specifications ...46...
  • Page 272 Index lubricant specifications ...260 reverse ...160 Mirrors ...56 fold away ...57 side view mirrors (power) ...56–57 Motorcraft parts ...241 Octane rating ...245 Oil (see Engine oil) ...227 Overdrive ...59–60 Overheating ...188 Parking brake ...153 Passenger Occupant Classification Sensor ...73 Power distribution box (see Fuses) ...173 Power door locks ...62 Power mirrors ...56–57...
  • Page 273 Spark plugs, specifications ...264 Special notice ambulance conversions ...7 utility-type vehicles ...7 Specification chart, lubricants ...260 Speed control ...57 Starting your vehicle ...146–147, 149 jump starting ...189 Steering wheel tilting ...54 Tether anchors ...102 Tilt steering wheel ...54 Tire Pressure Monitoring System (TPMS) Roadside Emergencies ...179 Tires, Wheels and Loading ...124...

Table of Contents
