Summary of Contents for Mazda 2006 Mazda3 4-Door

Page 1 Mazda3_8U55-EA-05G_Edition1 Page1 Tuesday, May 31 2005 1:18 PM Black plate (1,1) Form No.8U55-EA-05G...
Page 2 Mazda3_8U55-EA-05G_Edition1 Page2 Tuesday, May 31 2005 1:18 PM Black plate (2,1) Form No.8U55-EA-05G...
Page 3: A Word To Mazda Owners
Mazda product. Important Notes About This Manual Keep this manual in the glove box as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 4: How To Use This Manual
Illustrations complement the words of the manual to best explain how to enjoy your Mazda. By reading your manual, you can find out about the features, important safety information, and driving under various road conditions.
Page 5: Table Of Contents
Mazda3_8U55-EA-05G_Edition1 Page5 Tuesday, May 31 2005 1:18 PM Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Use of safety equipment, including seats, seat belt system, SRS air bags and child-restraint systems.
Page 6 Mazda3_8U55-EA-05G_Edition1 Page6 Tuesday, May 31 2005 1:18 PM Black plate (6,1) Form No.8U55-EA-05G...
Page 7: Your Vehicle At A Glance
Mazda3_8U55-EA-05G_Edition1 Page7 Tuesday, May 31 2005 1:18 PM Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Dashboard and Interior Overview ... 1-2 Exterior Overview ... 1-4 Form No.8U55-EA-05G Black plate (7,1)
Page 8: Dashboard And Interior Overview
Mazda3_8U55-EA-05G_Edition1 Page8 Tuesday, May 31 2005 1:18 PM Your Vehicle at a Glance Dashboard and Interior Overview Power window lock switch ... page 3-18 Power window switches ... page 3-17 Power door lock switch ... page 3-8 Form No.8U55-EA-05G Black plate (8,1) The equipment and installation position varies by grade.
Page 9 Mazda3_8U55-EA-05G_Edition1 Page9 Tuesday, May 31 2005 1:18 PM Headlight leveling switch ... page 5-48 Dashboard illumination ... page 5-32 Lighting control/Turn signals ... page 5-46 Fog light switch ... page 5-49 Instrument cluster ... page 5-28 Air bags ... page 2-38 Cruise control switches ...
Page 10: Exterior Overview
Mazda3_8U55-EA-05G_Edition1 Page10 Tuesday, May 31 2005 1:18 PM Black plate (10,1) Your Vehicle at a Glance Exterior Overview 4 Door The equipment and installation position varies by grade. Form No.8U55-EA-05G...
Page 11 Mazda3_8U55-EA-05G_Edition1 Page11 Tuesday, May 31 2005 1:18 PM Trunk lid ... page 3-12 Antenna ... page 6-16 Rear window defroster ... page 5-54 Power windows ... page 3-16 Tires ... page 8-30 Fuel-filler lid ... page 3-18 Light bulbs ... page 8-35 Hood ...
Page 12 Mazda3_8U55-EA-05G_Edition1 Page12 Tuesday, May 31 2005 1:18 PM Black plate (12,1) Your Vehicle at a Glance Exterior Overview 5 Door The equipment and installation position varies by grade. Form No.8U55-EA-05G...
Page 13 Mazda3_8U55-EA-05G_Edition1 Page13 Tuesday, May 31 2005 1:18 PM Liftgate ... page 3-9 Rear window defroster ... page 5-54 Windshield wiper blades ... page 8-23 Antenna ... page 6-16 Fuel-filler lid ... page 3-18 Power windows ... page 3-16 Tires ... page 8-30 Light bulbs ...
Page 14 Mazda3_8U55-EA-05G_Edition1 Page14 Tuesday, May 31 2005 1:18 PM Black plate (14,1) Form No.8U55-EA-05G...
Page 15: Essential Safety Equipment
Mazda3_8U55-EA-05G_Edition1 Page15 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Use of safety equipment, including seats, seat belt system, SRS air bags and child-restraint systems. Seats ... 2-2 Front Seats ... 2-2 Rear Seat ... 2-5 Seat Belt Systems ... 2-9 Seat Belt Precautions ...
Page 16: Seats
Such modifications could damage the supplemental restraint system and result in serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Damaged Front Seats: Driving with damaged front seats is dangerous.
Page 17 Mazda3_8U55-EA-05G_Edition1 Page17 Tuesday, May 31 2005 1:18 PM qSeat Recline WARNING Reclining: Sitting in a reclined position while the vehicle is moving is dangerous because you don't get the full protection from seat belts. During sudden braking or a collision, you can slide under the lap belt and suffer serious internal injuries.
Page 18 Mazda3_8U55-EA-05G_Edition1 Page18 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Seats CAUTION When returning a rear-reclined seatback to its upright position, make sure you hold onto the seatback with your other hand while operating the lever. If the seatback is not supported, it will flip forward suddenly and could cause injury.
Page 19: Rear Seat
Mazda3_8U55-EA-05G_Edition1 Page19 Tuesday, May 31 2005 1:18 PM í qSeat Warmer The front seats are electrically heated. The ignition switch must be in the ON position. Press the switch to turn the seat warmer on or off. When the switch is in the ON position, the indicator light will come on.
Page 20 Mazda3_8U55-EA-05G_Edition1 Page20 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Seats WARNING Unlocked Seatback: The seatback plays an important role in your protection in a vehicle. Leaving the seatback unlocked is dangerous as it can allow passengers to be ejected or thrown around and baggage to strike occupants in a sudden stop or collision, resulting in severe injury.
Page 21 Mazda3_8U55-EA-05G_Edition1 Page21 Tuesday, May 31 2005 1:18 PM 4. Push the rear seatback knob down. To return the seatbacks to the upright position 1. Position the outboard seat belts to the side. 2. Lift the seatbacks upright. 3. Make sure the seat belts are fully pulled out from under the seatbacks.
Page 22 Mazda3_8U55-EA-05G_Edition1 Page22 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Seats qRear Seatback Lock (4 Door) To lock or unlock a seatback, move the lever. NOTE The seatback locks are part of the trunk security system (page 3-14). qHead Restraint WARNING Head Restraints Adjustment: Driving with the head restraints...
Page 23: Seat Belt Systems
Have an Authorized Mazda Dealer inspect all seat belt systems in use during an accident before they are used again.
Page 24 Mazda3_8U55-EA-05G_Edition1 Page24 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Seat Belt Systems One Belt, One Passenger: Using one seat belt for more than one person at a time is dangerous. A seat belt used in this way can't spread the impact forces properly and the two passengers could be crushed together and seriously injured or even killed.
Page 25 Mazda3_8U55-EA-05G_Edition1 Page25 Tuesday, May 31 2005 1:18 PM qEmergency Locking Mode In the emergency locking mode, the belt remains comfortable on the occupant and the retractor will lock in position during a collision. When the seat belt is retracted, it will always be in the emergency locking mode until it is switched to automatic locking mode by pulling it all the way out to its full length.
Page 26: Seat Belt (Except Center-Rear Position)
Mazda3_8U55-EA-05G_Edition1 Page26 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Seat Belt Systems Seat Belt (Except Center- Rear Position) NOTE When using the center-rear seat belt, refer to Center-Rear Position Seat Belt (page 2-16). qFastening the Seat Belts 1. Grasp the tongue. 2.
Page 27 If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an Authorized Mazda Dealer. qShoulder Belt Adjuster Adjust the height of the shoulder belt if the seat belt touches your neck, or if it crosses your arm instead of your shoulder.
Page 28: Front Seat Belt Pretensioner And Load Limiting Systems
If the seat belt pretensioners are not replaced, the risk of injury in a collision will increase. Always have an Authorized Mazda Dealer inspect the seat belt pretensioners and air bags after any collision. Expended seat belt pretensioners and air bags must be replaced after any collision which caused them to deploy.
Page 29 ON position. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident. WARNING Self-Servicing the Air Bag/...
Page 30: Center-Rear Position Seat Belt (3-Point Type)
The air bag and seat belt pretensioner system warning beep sound will continue to be heard for approximately 35 minutes. Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible. WARNING Air Bag/Front Seat Belt Pretensioner System Warning Beep:...
Page 31 Mazda3_8U55-EA-05G_Edition1 Page31 Tuesday, May 31 2005 1:18 PM WARNING Fastening the Center-Rear Seat Belt with Only One Buckle: Fastening the center-rear seat belt with only one buckle is dangerous. If only one pair of seat belt tongue and buckle, either tongue (A) and anchor buckle (B) or tongue (C) and anchor buckle (D), is fastened, the seat belt cannot provide full protection.
Page 32: Seat Belt Extender
When ordering an extender, only order one that provides the necessary additional length to fasten the seat belt properly. Please contact your Authorized Mazda Dealer for more information. WARNING Unnecessary Use of an Extender: Using a seat belt extender when not necessary is dangerous.
Page 33: Seat Belt Warning Light/Beep
Mazda3_8U55-EA-05G_Edition1 Page33 Tuesday, May 31 2005 1:18 PM WARNING Using an Extender That is Too Long: Using an extender that is too long is dangerous. The seat belt will not fit properly. In an accident, the seat belt will not provide adequate protection and you could be seriously injured.
Page 34 ON position again. (Long-term deactivation) To deactivate the belt minder over the long term, consult an Authorized Mazda Dealer. If the belt minder is long-term deactivated, the belt minder will not activate until it is restored at the Authorized Mazda...
Page 35: Child Restraint Precautions
Even if the front passenger air bag is shut off, Mazda strongly recommends that children be properly restrained and child-restraint systems of all kinds are properly secured on the rear seats which are the best place for children.
Page 36 Mazda3_8U55-EA-05G_Edition1 Page36 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Child Restraint Proper Size of Child-Restraint System: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size.
Page 37 Mazda3_8U55-EA-05G_Edition1 Page37 Tuesday, May 31 2005 1:18 PM Seating Children in a Child-Restraint System on the Front Passenger Seat: If your vehicle is equipped with front passenger seat weight sensors, the vehicle is also equipped with an air bag deactivation indicator light (page 2-30). Even with the front passenger seat weight sensors, if you must use the front passenger seat for children, seating a child in a child-restraint system on the front passenger seat under the following conditions increases the danger of the front passenger air bag deploying...
Page 38 To avoid burning yourself or a child, check them before you or your child touches them. NOTE Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. When using these anchors to secure a child-restraint system, refer to LATCH Child-Restraint Systems (page 2-33).
Page 39: Installing Child-Restraint Systems
Some child-restraint systems now come with tethers and therefore must be installed on the seats that take tethers to be effective. In your Mazda, tethered child-restraint systems can only be accommodated in the three positions on the rear seat.
Page 40 Mazda3_8U55-EA-05G_Edition1 Page40 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Child Restraint 1. Make sure the seatback is securely latched by pushing it back until it is fully locked. 2. Secure the child-restraint system with the lap portion of the lap/shoulder belt. See the manufacturer's instructions on the child-restraint system for belt routing instructions.
Page 41 Mazda3_8U55-EA-05G_Edition1 Page41 Tuesday, May 31 2005 1:18 PM Anchor bracket location (4 Door) Anchor bracket Tether strap position (4 Door) Anchor bracket Anchor bracket location (5 Door outboard position) Form No.8U55-EA-05G Black plate (41,1) Tether strap position (5 Door outboard position) Tether strap Anchor bracket location (5 Door center...
Page 42 Mazda3_8U55-EA-05G_Edition1 Page42 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Child Restraint WARNING Child-Restraint Tether Usage: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous. This could weaken or damage the tether or tether anchor and result in injury.
Page 43 Tuesday, May 31 2005 1:18 PM NOTE To check if your front seats have side air bags: Every Mazda side air bag will have a SRS AIRBAG tag on the outboard shoulder of the front seats. To check if your vehicle has curtain...
Page 44 Mazda3_8U55-EA-05G_Edition1 Page44 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Child Restraint WARNING Children and Seating Position with Side and Curtain Air Bags: Allowing anyone to lean over or against the side window, the area of the front passenger seat, front and rear window pillars and the roof edge along both sides from which the side and curtain air bags deploy, even if a...
Page 45 Mazda3_8U55-EA-05G_Edition1 Page45 Tuesday, May 31 2005 1:18 PM NOTE Inspect this function before each use of the child-restraint system. You should not be able to pull the shoulder belt out of the retractor while the system is in the automatic locking mode.
Page 46 Authorized Mazda Dealer as soon as possible. While it is always better to install any child-restraint system on the rear seat, it is essential...
Page 47: Latch Child-Restraint Systems
Tuesday, May 31 2005 1:18 PM LATCH Child-Restraint Systems Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. Both anchors must be used, otherwise the seat will bounce around and put the child in danger. Most LATCH child-restraint systems must also be used in conjunction with a tether to be effective.
Page 48 Mazda3_8U55-EA-05G_Edition1 Page48 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Child Restraint qChild-Restraint System Installation Procedure (Rear Outboard Seats) 1. Make sure the seatback is securely latched by pushing it back until it is fully locked. 2. Expand the area between the seat bottom and the seatback slightly to verify the locations of the LATCH lower anchors.
Page 49 Mazda3_8U55-EA-05G_Edition1 Page49 Tuesday, May 31 2005 1:18 PM Tether strap position (5 Door) Tether strap WARNING Child-Restraint Tether Usage: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous. This could weaken or damage the tether or tether anchor and result in injury.
Page 50 Mazda3_8U55-EA-05G_Edition1 Page50 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment Child Restraint 2. Expand the area between the seat bottom and the seatback slightly to verify the locations of the LATCH lower anchors. NOTE The markings above the LATCH lower anchors indicate the locations of LATCH lower anchors for the attachment of a child-restraint system.
Page 51 Mazda3_8U55-EA-05G_Edition1 Page51 Tuesday, May 31 2005 1:18 PM Tether strap position (5 Door) Tether strap WARNING Child-Restraint Tether Usage: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous. This could weaken or damage the tether or tether anchor and result in injury.
Page 52: Srs Air Bags
Mazda3_8U55-EA-05G_Edition1 Page52 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment SRS Air Bags Supplemental Restraint Systems (SRS) Precautions The front and side supplemental restraint systems (SRS) include up to 6 air bags (verify SRS AIRBAG location indicator marks). They are located in: The steering wheel hub (driver air bag) The front passenger dashboard (front passenger air bag) The outboard sides of the front seatbacks (side air bags)
Page 53 Mazda3_8U55-EA-05G_Edition1 Page53 Tuesday, May 31 2005 1:18 PM Air Bags without Seat Belts: Depending only on the air bags for protection during an accident is dangerous. Alone, air bags may not prevent serious injuries. The appropriate air bags can be expected to inflate only in the first collision with frontal, near frontal or side forces that are at least moderate.
Page 54 Mazda3_8U55-EA-05G_Edition1 Page54 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment SRS Air Bags Seating Position with Side and Curtain Air Bags: Sitting too close to the side air bag modules or placing hands on them is extremely dangerous. The side air bags inflate with great force and speed directly out of the outboard side of the front seat and expand along the front door on the side the car is hit.
Page 55 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.
Page 56: Supplemental Restraint System Components
Mazda3_8U55-EA-05G_Edition1 Page56 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment SRS Air Bags Supplemental Restraint System Components The supplemental restraint systems (SRS) have two basic subsystems: The air bag system with inflators and air bags. The electrical system with crash sensors and diagnostic module. The air bags are mounted in the following locations: The steering wheel hub The front passenger dashboard...
Page 57 Mazda3_8U55-EA-05G_Edition1 Page57 Tuesday, May 31 2005 1:18 PM qFront Air Bag System Components (10) (1) Driver seat slide position sensor (page 2-45) (2) Front seats (3) Front dual stage inflators and air bags (4) Front air bag sensor (5) Front passenger air bag deactivation indicator light (page 2-45) (6) Front seat belt pretensioner and load limiting systems (page 2-14) (7) Front passenger seat weight sensors (page 2-45) (8) Front passenger seat weight sensor control module...
Page 58 Mazda3_8U55-EA-05G_Edition1 Page58 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment SRS Air Bags qSide and Curtain Air Bag System Components 4 Door 5 Door (1) Side and curtain inflators and air bags (2) Front seats (3) Crash sensors and diagnostic module (SAS unit) (4) Side crash sensor í...
Page 59: How The Air Bags Work
The front air bags will function only once. After that, the front air bags will not work again and must be replaced. Only an Authorized Mazda Dealer can replace the system components. The front, dual stage air bags control air bag inflation in two energy stages. During an impact of moderate severity the front air bags deploy with lesser energy, whereas during more severe impacts, they deploy with more energy.
Page 60 Mazda3_8U55-EA-05G_Edition1 Page60 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment SRS Air Bags Front passenger seat weight sensors If your vehicle is equipped with front passenger seat weight sensors, a front passenger air bag deactivation indicator light is also equipped (page 2-30). These sensors are located under both of the front passenger seat rails.
Page 61 ON position and does not illuminate as indicated in the above chart, do not allow a child to sit in the front passenger seat and consult an Authorized Mazda Dealer as soon as possible. The system may not work properly in an accident.
Page 62 Mazda3_8U55-EA-05G_Edition1 Page62 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment SRS Air Bags Increasing the Total Seated Weight on the Front Passenger Seat: When an infant or small child sits on the front passenger seat, increasing the total seated weight on the front passenger seat from the total seated weight of approximately 30 kg (66 lb) is dangerous.
Page 63 If the front passenger air bag deactivation indicator light does not illuminate after installing a child-restraint system on the front passenger seat, install the child-restraint system on the rear seat and consult an Authorized Mazda Dealer as soon as possible. Driver and front passenger buckle switches The buckle switches on the front seat belts detect whether or not the front seat belts are securely fastened and further control the deployment of the air bags.
Page 64 Mazda3_8U55-EA-05G_Edition1 Page64 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment SRS Air Bags Damaged Side and Curtain Air Bag Wiring under the Seats: Placing luggage or other objects under the front seats is dangerous. The side and curtain air bag wiring could be damaged, and in the event of a side collision, the side and curtain air bags may not deploy, which could result in death or serious injury.
Page 65 Mazda3_8U55-EA-05G_Edition1 Page65 Tuesday, May 31 2005 1:18 PM Driving into a big hole or hitting the far side of a hole. Limitations to front air bag activation Depending on the severity of impact, the front air bags may not inflate in the following cases: Impacts involving trees or poles cause severe cosmetic damage but may not...
Page 66 Mazda3_8U55-EA-05G_Edition1 Page66 Tuesday, May 31 2005 1:18 PM Essential Safety Equipment SRS Air Bags Side and curtain air bag activation Greater than moderate impact to one side of the vehicle (driver or passenger side areas) will cause the side and curtain air bags on that side to inflate, but it will not normally deploy the front air bags.
Page 67 ON position. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident. WARNING Self-Servicing the Air Bag/...
Page 68 Do not drive the vehicle with the air bag/front seat belt pretensioner system warning beep sounding. Contact an Authorized Mazda Dealer to have the vehicle inspected as soon as possible. qMaintenance The air bag systems do not require regular maintenance.
Page 69 Authorized Mazda Dealer, refer to Customer Assistance (U.S.A.) (page 9-2). Form No.8U55-EA-05G Black plate (69,1)
Page 70 Mazda3_8U55-EA-05G_Edition1 Page70 Tuesday, May 31 2005 1:18 PM Black plate (70,1) 2-56 Form No.8U55-EA-05G...
Page 71: Knowing Your Mazda
Mazda3_8U55-EA-05G_Edition1 Page71 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts. Doors and Locks ... 3-2 Keys ... 3-2 Keyless Entry System Door Locks ... 3-6 Liftgate (5 Door) ... 3-9 Trunk Lid (4 Door) ...
Page 72: Doors And Locks
NOTE Write down the code number and keep it in a separate, safe and convenient place, but not in the vehicle. If your key is lost, consult your Authorized Mazda Dealer and have your code number ready.
Page 73: Keyless Entry System Í
To install a new battery, refer to Maintenance (page 3-5). Additional transmitters can be obtained at an Authorized Mazda Dealer. Up to 3 transmitters can be used with the keyless entry system per vehicle. Bring all transmitters to an Authorized Mazda Dealer when the electronic codes need to be reset.
Page 74 Mazda3_8U55-EA-05G_Edition1 Page74 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Doors and Locks To confirm that all doors and the liftgate have been locked, press the lock button again within 5 seconds. If they are closed and locked, the horn will sound.
Page 75 Never throw the battery into fire and/or water. Never deform or crush. Form No.8U55-EA-05G Black plate (75,1) Knowing Your Mazda Doors and Locks Replacing the transmitter battery 1. Insert a small screwdriver into the slot and gently pry open the transmitter.
Page 76: Door Locks
Authorized Mazda Dealer. If your transmitter is lost or stolen, bring all remaining transmitters to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen transmitter inoperative. CAUTION Radio equipment like this is governed by laws in the United States.
Page 77 Turn the key toward the front to unlock, toward the back to lock. Unlock Lock Form No.8U55-EA-05G Black plate (77,1) Knowing Your Mazda Doors and Locks NOTE If your vehicle is equipped with a front passenger door key slot, the door can be locked/unlocked with the key.
Page 78 Mazda3_8U55-EA-05G_Edition1 Page78 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Doors and Locks To lock any door with the door-lock knob from the outside, push the door-lock knob to the lock position and close the door. This does not operate the other door locks.
Page 79: Liftgate (5 Door)
Keyless Entry System (page 3-3). qLocking, Unlocking with Door- Lock Switch The liftgate can be locked/unlocked by operating the door-lock switch, refer to Power Door Locks (page 3-8). Lock Black plate (79,1) Knowing Your Mazda Doors and Locks...
Page 80 Lever After performing this emergency measure, have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. Closing the liftgate Use both hands to push the liftgate down until the lock snaps shut. Do not slam it.
Page 81 If it is not firmly secured, it could unexpectedly disengage resulting in injury. Form No.8U55-EA-05G Black plate (81,1) Knowing Your Mazda Doors and Locks Luggage compartment cover strap The luggage compartment can be accessed by opening the liftgate when the straps are attached to the sides of the liftgate.
Page 82: Trunk Lid (4 Door)
Mazda3_8U55-EA-05G_Edition1 Page82 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Doors and Locks CAUTION To prevent cargo from shifting while driving or during sudden deceleration, be careful of the following: Do not open the luggage compartment cover while the vehicle is moving.
Page 83 Form No.8U55-EA-05G Black plate (83,1) Knowing Your Mazda Doors and Locks Opening the trunk lid with the key Insert the key into the slot and turn it clockwise.
Page 84 Mazda3_8U55-EA-05G_Edition1 Page84 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Doors and Locks qTrunk Security In some situations you may want to prevent the trunk from being opened with the remote trunk lid release lever. Give your key only to someone you trust.
Page 85: Inside Trunk Release Lever (4 Door)
Form No.8U55-EA-05G Black plate (85,1) Knowing Your Mazda Doors and Locks WARNING Trunk Access and Children: Leaving the trunk lid open or leaving children in the vehicle with the keys is dangerous.
Page 86: Power Windows Í
Mazda3_8U55-EA-05G_Edition1 Page86 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Doors and Locks qOpening the Trunk Lid from the Inside Slide the inside trunk release lever in the direction of the arrow. The lever is made of material that will glow for hours in the darkness of the trunk following a brief exposure to ambient light.
Page 87 To stop the window partway, lightly pull up the switch and then release it. Form No.8U55-EA-05G Black plate (87,1) Knowing Your Mazda Doors and Locks qOperating the Passenger Power Windows The power windows may be operated...
Page 88: Fuel-Filler Lid And Cap
CAUTION Always use only a genuine Mazda fuel cap or an approved equivalent, available at an Authorized Mazda Dealer. The wrong cap can result in a serious malfunction of the fuel and emission control systems.
Page 89 If the light remains on (even after you have tightened the cap securely, driven, and restarted the engine several times), it may indicate a different problem. Contact an Authorized Mazda Dealer as soon as possible. 3-19...
Page 90: Hood
Mazda3_8U55-EA-05G_Edition1 Page90 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Doors and Locks Hood WARNING Closed and Securely Locked Hood: A hood that is not closed and securely locked is dangerous as it could fly open while the vehicle is moving and block the driver's vision which could result in a serious accident.
Page 91: Moonroof Í
3. Close the hood so that it locks securely. Form No.8U55-EA-05G Black plate (91,1) Knowing Your Mazda Doors and Locks í Moonroof The moonroof can be opened or closed electrically only when the ignition switch is in the ON position.
Page 92 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Doors and Locks NOTE After washing your Mazda or after a rain, wipe the water off the moonroof before operating it to avoid water penetration which could cause rust and water damage to your headliner.
Page 93: Security System
Form No.8U55-EA-05G Black plate (93,1) Knowing Your Mazda Security System CAUTION When starting the engine do not allow the following, as the engine may not start due to the electronic signal from the ignition key not being transmitted correctly.
Page 94 If the security indicator light flashes continuously while you are driving, don't shut off the engine. Go to an Authorized Mazda Dealer and have it checked. If you shut off the engine while the light is flashing you won't be able to restart it.
Page 95 They are only available through an Authorized Mazda Dealer. Always keep a spare key, in case one is lost. If a key is lost, contact an Authorized Mazda Dealer as soon as possible. If you lose a key, an Authorized Mazda Dealer will reset the electronic codes of your remaining keys and immobilizer system.
Page 96: Theft-Deterrent System Í
Mazda3_8U55-EA-05G_Edition1 Page96 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Security System Theft-Deterrent System The theft-deterrent system is designed to prevent your vehicle or its contents from being stolen when all doors, hood, and trunk lid/liftgate are locked. If forcible entry is attempted, the system sounds the horn and flashes the hazard warning lights.
Page 97 Labels A label indicating that your vehicle is equipped with a Theft-Deterrent System is in the glove box. Mazda recommends that you affix it to the lower rear corner of a front door window. Form No.8U55-EA-05G Black plate (97,1)
Page 98: Steering Wheel And Mirrors
Mazda3_8U55-EA-05G_Edition1 Page98 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Steering Wheel and Mirrors Steering Wheel WARNING Adjusting the Steering Wheel: Adjusting the steering wheel while the vehicle is moving is dangerous. Moving it can very easily cause the driver to abruptly turn to the left or right.
Page 99 To adjust, move the mirror's control lever, just inside the door. Control lever Form No.8U55-EA-05G Black plate (99,1) Knowing Your Mazda Steering Wheel and Mirrors Folding the mirror Fold the outside mirror rearward until it is flush with the vehicle.
Page 100 Mazda3_8U55-EA-05G_Edition1 Page100 Tuesday, May 31 2005 1:18 PM Knowing Your Mazda Steering Wheel and Mirrors qRearview Mirror Rearview mirror adjustment Before driving, adjust the rearview mirror to center on the scene through the rear window. Reducing glare from headlights Do this with the day/night lever in the day position.
Page 101: Important Information About Driving Your Mazda
Mazda3_8U55-EA-05G_Edition1 Page101 Tuesday, May 31 2005 1:18 PM Before Driving Your Mazda Important information about driving your Mazda. Fuel and Engine Exhaust Precautions ... 4-2 Fuel Requirements ... 4-2 Emission Control System ... 4-3 Engine Exhaust (Carbon Monoxide) ... 4-5 Before Starting the Engine ...
Page 102: Fuel And Engine Exhaust Precautions
Never add fuel system additives. Never add cleaning agents other than those specified by Mazda. Other cleaning agents and additives may damage the system. Consult an Authorized Mazda Dealer. Gasoline blended with oxygenates such as alcohol or ether compounds are generally referred to as oxygenated fuels.
Page 103: Emission Control System
Either condition will damage the converter and cause poor performance. USE ONLY UNLEADED FUEL. Don't drive your Mazda with any sign of engine malfunction. Don't coast with the ignition switch turned off. Don't descend steep grades in gear with the ignition switch turned off.
Page 104 Mazda3_8U55-EA-05G_Edition1 Page104 Tuesday, May 31 2005 1:18 PM Before Driving Your Mazda Fuel and Engine Exhaust Precautions NOTE While the engine is off, the sound of a valve opening and closing can be heard at the rear of the right side of the vehicle, however this does not indicate an abnormality. Your vehicle has a self-checking device and it operates while the engine is off.
Page 105: Engine Exhaust (Carbon Monoxide)
When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside your vehicle, keep all windows fully open and contact an Authorized Mazda Dealer immediately. Exhaust Gas in Enclosed Area: Running the engine inside an enclosed area, such as a garage, is dangerous. Exhaust gas, which contains poisonous carbon monoxide, could easily enter the cabin.
Page 106: Before Starting The Engine
Mazda3_8U55-EA-05G_Edition1 Page106 Tuesday, May 31 2005 1:18 PM Before Driving Your Mazda Before Starting the Engine Before Getting In Be sure the windows, outside mirrors, and outside lights are clean. Inspect inflation pressures and condition of tires. Look under the vehicle for any sign of a leak.
Page 107: Driving Tips
No special break-in is necessary, but a few precautions in the first 1,000 km (600 miles) may add to the performance, economy, and life of your Mazda. Don't race the engine. Don't maintain one constant speed, either slow or fast, for a long period of time.
Page 108: Hazardous Driving
Mazda3_8U55-EA-05G_Edition1 Page108 Tuesday, May 31 2005 1:18 PM Before Driving Your Mazda Driving Tips Hazardous Driving WARNING Downshifting on Slippery Surfaces: Downshifting into lower gear while driving on slippery surfaces is dangerous. The sudden change in tire speed could cause the tires to skid.
Page 109: Winter Driving
Carry emergency gear, including tire chains, window scraper, flares, a small shovel, jumper cables, and a small bag of sand or salt. Ask an Authorized Mazda Dealer to perform the following precautions: Have the proper ratio of antifreeze in the radiator.
Page 110 Mazda3_8U55-EA-05G_Edition1 Page110 Tuesday, May 31 2005 1:18 PM Before Driving Your Mazda Driving Tips qTire Chains Check local regulations before using tire chains. CAUTION Chains may scratch or chip aluminum wheels. Install tire chains on steel wheels only. Chains may affect handling.
Page 111: Driving In Flooded Area
Interior materials could get moldy, and many electronic devices in the cabin and the engine could be damaged. Form No.8U55-EA-05G Black plate (111,1) Before Driving Your Mazda Driving Tips Overloading WARNING Vehicle Load Weight: The gross axle weight rating (GAWR)
Page 112: Towing
Mazda3_8U55-EA-05G_Edition1 Page112 Tuesday, May 31 2005 1:18 PM Black plate (112,1) Before Driving Your Mazda Towing Trailer Towing The Mazda3 is not designed for towing. Never tow a trailer with your Mazda3. 4-12 Form No.8U55-EA-05G...
Page 113: Driving Your Mazda
Mazda3_8U55-EA-05G_Edition1 Page113 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Explanation of instruments and controls. Starting and Driving ... 5-2 Ignition Switch ... 5-2 Starting the Engine ... 5-3 Brake System ... 5-4 Manual Transaxle Operation ... 5-9 Automatic Transaxle Controls ... 5-11 Power Steering ...
Page 114: Starting And Driving
Mazda3_8U55-EA-05G_Edition1 Page114 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Starting and Driving Ignition Switch qIgnition Switch Positions LOCK The steering wheel locks to protect against theft. Only in this position can the key be removed. To turn the key from the ACC to the...
Page 115: Starting The Engine
ACC position with the key inserted, a continuous beep sound will be heard when the driver's door is opened. Form No.8U55-EA-05G Black plate (115,1) Driving Your Mazda Starting and Driving Starting the Engine NOTE Engine-starting is controlled by the spark ignition system.
Page 116: Brake System
Form No.8U55-EA-05G Black plate (116,1) Brake System qFoot Brake Your Mazda has power-assisted brakes that adjust automatically through normal use. Should power-assist fail, you can stop by applying greater force than normal to the brake pedal. But the distance required to stop will be greater than usual.
Page 117 For parking in snow, refer to Winter Driving (page 4-9) regarding parking brake use. Form No.8U55-EA-05G Black plate (117,1) Driving Your Mazda Starting and Driving Setting the parking brake Depress the brake pedal and then firmly pull the parking brake lever fully upwards...
Page 118 Form No.8U55-EA-05G Black plate (118,1) NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. WARNING Brake Warning Light: Driving with the brake system warning light on is dangerous.
Page 119 If this occurs, your brakes will function normally as if the vehicle had no ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS warning light comes on.
Page 120 Don't drive with both lights on, have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as soon as possible. í qBrake Assist During emergency braking situations...
Page 121: Manual Transaxle Operation
Do not use sudden engine braking on slippery road surfaces or at high speeds. Form No.8U55-EA-05G Black plate (121,1) Driving Your Mazda Starting and Driving CAUTION Keep your foot off the clutch pedal except when shifting gears. Also, don't use the clutch to hold the vehicle on an upgrade.
Page 122 Mazda3_8U55-EA-05G_Edition1 Page122 Tuesday, May 31 2005 1:18 PM Black plate (122,1) Driving Your Mazda Starting and Driving Downshifting When you must slow down in heavy traffic or on a steep upgrade, downshift before the engine starts to overwork. This reduces the chance of stalling and gives better acceleration when you need more speed.
Page 123: Automatic Transaxle Controls
To hold the vehicle, set the shift lever to P AND set the parking brake. Form No.8U55-EA-05G Black plate (123,1) Driving Your Mazda Starting and Driving CAUTION Shifting into P, N or R while the vehicle is moving can damage your transaxle.
Page 124 Mazda3_8U55-EA-05G_Edition1 Page124 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Starting and Driving N (Neutral) In N, the wheels and transaxle are not locked. The vehicle will roll freely even on the slightest incline unless the parking brake or brakes are on.
Page 125 Tuesday, May 31 2005 1:18 PM 2. Insert a screwdriver and push it down. 3. Move the shift lever. 4. Take the vehicle to an Authorized Mazda Dealer to have the system checked. qManual Shift Mode This mode gives you the feel of driving a...
Page 126 Mazda3_8U55-EA-05G_Edition1 Page126 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Starting and Driving NOTE If the gears cannot be shifted down when driving at higher speeds, the gear position indicator will flash twice to signal that the gears cannot be shifted down.
Page 127 Gear Vehicle speed M4→M3 36 km/h (22 mph) M3 or M2→M1 12 km/h (7 mph) NOTE The gear does not shift down to M1 automatically while in the second gear fixed mode. Driving Your Mazda 5-15...
Page 128 Mazda3_8U55-EA-05G_Edition1 Page128 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Starting and Driving If the vehicle is kicked down at the following speeds or lower, the gears shift down automatically: Gear Vehicle speed M4→M3 170 km/h (105 mph) M3→M2 72 km/h (44 mph) Shifting specification (2.3-liter engine...
Page 129: Power Steering
If the steering feels rigid during normal driving, consult an Authorized Mazda Dealer. CAUTION Never hold the steering wheel to the extreme left or right for more than 5 seconds with the engine running.
Page 130: Cruise Control
Mazda3_8U55-EA-05G_Edition1 Page130 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Starting and Driving The light illuminates to indicate that the power steering is inoperable. If the light illuminates, turn off the engine and restart If the light does not illuminate after...
Page 131 To deactivate the system, press the switch again. The cruise main indicator light turns off. Form No.8U55-EA-05G Black plate (131,1) Driving Your Mazda Starting and Driving WARNING Cruise Main Switch: Leaving the ON/OFF switch on when not using the cruise control is dangerous as it may be switched on accidentally.
Page 132 Mazda3_8U55-EA-05G_Edition1 Page132 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Starting and Driving NOTE The SET function can't be activated until about 2 seconds after the ON/ OFF switch has been engaged. On a steep grade, the vehicle may momentarily slow down going up or speed up while going down.
Page 133 Multiple taps will decrease your vehicle speed 1.6 km/h (1 mph) for each tap. Form No.8U55-EA-05G Black plate (133,1) Driving Your Mazda Starting and Driving qTo Resume Cruising Speed at More Than 30 km/h (19 mph) If some other method besides the ON/...
Page 134: Tire Pressure Monitoring System
Mazda3_8U55-EA-05G_Edition1 Page134 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Starting and Driving Press the CANCEL button. The system is off when the ignition is off. NOTE Cruise control will cancel at about 15 km/h (9 mph) below the preset speed or below 30 km/h (19 mph).
Page 135 TPMS low tire pressure telltale. Form No.8U55-EA-05G Black plate (135,1) Driving Your Mazda Starting and Driving CAUTION To avoid false readings, the system samples for a little while before indicating a problem. As a result it will not instantaneously register a rapid tire deflation or blow out.
Page 136 (page 10-7). CAUTION When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. NOTE Perform tire pressure adjustment when the tires are cold. Tire pressure...
Page 137 Warning light flashes When the warning light flashes, there may be a system malfunction. Consult an Authorized Mazda Dealer. qSystem Error Activation When the warning light flashes, there may be a system malfunction. Consult an Authorized Mazda Dealer.
Page 138 Replacing tires and wheels CAUTION When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Page 139 For purchase of a tire pressure sensor and registration of the tire pressure sensor ID signal code, consult an Authorized Mazda Dealer. When reinstalling a previously removed tire pressure sensor to a wheel, replace the grommet for the tire pressure sensor.
Page 140: Instrument Cluster And Indicators
Mazda3_8U55-EA-05G_Edition1 Page140 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Instrument Cluster and Indicators Meters and Gauges (Black-out meter) When the ignition switch is in the ON position, the dashboard gauges illuminate. Speedometer ... page 5-29 Odometer, Trip Meter and Trip Meter Selector ... page 5-29 Tachometer ...
Page 141 The selected mode will be displayed. Selector Trip meter Odometer Form No.8U55-EA-05G Black plate (141,1) Instrument Cluster and Indicators Trip meter A Odometer Press the selector Trip meter B Odometer Press the selector Driving Your Mazda 5-29...
Page 142 Mazda3_8U55-EA-05G_Edition1 Page142 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Instrument Cluster and Indicators NOTE (Standard meter) The odometer and trip meter can be displayed as follows even when the ignition switch is in the ACC or LOCK position.
Page 143 E, refuel as soon as possible. Low fuel warning light NOTE The direction of the arrow ( next to the low fuel warning light indicates that the fuel-filler lid is on the right side of the vehicle. Driving Your Mazda ) shown 5-31...
Page 144 Mazda3_8U55-EA-05G_Edition1 Page144 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Instrument Cluster and Indicators qDashboard Illumination When the exterior lights are on, rotate the thumb-wheel to adjust the brightness of the dashboard lights. Bright NOTE Black-out meter When the instrument cluster dimmer is...
Page 145: Warning/Indicator Lights And Beep Sounds
ABS Warning Light Air Bag/Front Seat Belt Pretensioner System Warning Light Low Fuel Warning Light Form No.8U55-EA-05G Warning/Indicator lights will appear in any of the highlighted areas Warning/Indicator Lights Black plate (145,1) Driving Your Mazda Page 5-35 5-36 5-37 5-37 5-35...
Page 146 Mazda3_8U55-EA-05G_Edition1 Page146 Tuesday, May 31 2005 1:18 PM Driving Your Mazda Warning/Indicator Lights and Beep Sounds Signal Seat Belt Warning Light/Beep Door-Ajar Warning Light Low Washer Fluid Level Warning Light Automatic Transaxle Warning Light Tire Pressure Monitoring System Warning Light...
Page 147 Black plate (147,1) Driving Your Mazda NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. WARNING Brake Warning Light: Driving with the brake system warning light on is dangerous.
Page 148 If this occurs, your brakes will function normally as if the vehicle had no ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS warning light comes on.
Page 149 The emission control system has a problem. The fuel-filler cap is missing or not tightened securely. If the check engine light remains on or flashes continuously, do not drive at high speeds and consult an Authorized Mazda Dealer as soon as possible. 5-37...
Page 150 ON position. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident. WARNING Self-Servicing the Air Bag/...
Page 151 ON position again. (Long-term deactivation) To deactivate the belt minder over the long term, consult an Authorized Mazda Dealer. If the belt minder is long-term deactivated, the belt minder will not activate until it is restored at the Authorized Mazda Dealer.
Page 152 CAUTION If the automatic transaxle warning light illuminates, the transaxle has an electrical problem. Continuing to drive your Mazda in this condition could cause damage to your transaxle. Consult an Authorized Mazda Dealer as soon as possible. í...
Page 153 Refer to the specification charts (page 10-7). CAUTION When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. Form No.8U55-EA-05G Black plate (153,1) Driving Your Mazda...
Page 154 3 seconds and then goes out. If the engine doesn't start with the correct ignition key, and the security indicator light keeps illuminating or flashing, the system may have a malfunction. Consult an Authorized Mazda Dealer. 5-42 Form No.8U55-EA-05G Black plate (154,1) qHeadlight High-Beam Indicator...
Page 155 If the light remains illuminated, the power steering is still inoperable. Consult an Authorized Mazda Dealer. NOTE The power steering system is inoperable when the power steering malfunction indicator light illuminates. Steering is possible, but requires more physical effort.
Page 156: Beep Sounds
The air bag and seat belt pretensioner system warning beep sound will continue to be heard for approximately 35 minutes. Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible. WARNING Air Bag/Front Seat Belt Pretensioner System Warning Beep:...
Page 157 Inflation Pressure Warning í Beep The warning beep sound will be heard for about 3 seconds when there is any abnormality in tire inflation pressures (page 5-22). Form No.8U55-EA-05G Black plate (157,1) Driving Your Mazda í 5-45 Some models.
Page 158: Headlights
Mazda3_8U55-EA-05G_Edition1 Page158 Tuesday, May 31 2005 1:19 PM Driving Your Mazda Switches and Controls Lighting Control qHeadlights Type A (Without AUTO position) Turn the headlight switch to turn the headlights, other exterior lights and dashboard illumination on or off. Switch Position...
Page 159 Do not replace the xenon fusion bulbs by yourself. Consult an Authorized Mazda Dealer when the replacement is necessary. NOTE If the headlights flash, or the brightness weakens, the bulb-life may be depleted and a replacement is necessary.
Page 160 Mazda3_8U55-EA-05G_Edition1 Page160 Tuesday, May 31 2005 1:19 PM Driving Your Mazda Switches and Controls qLights-On Reminder If lights are on and the key is removed from the ignition switch, a continuous beep sound will be heard when the driver's door is opened.
Page 161: Turn And Lane-Change Signals
Form No.8U55-EA-05G Black plate (161,1) Driving Your Mazda Switches and Controls í Fog Lights The fog lights help you to see as well as to be seen.
Page 162: Windshield Wipers And Washer
After 5 minutes, turn on the switch and the blades should operate normally. If they don't resume functioning, consult an Authorized Mazda Dealer as soon as possible. Drive to the side of the road and park off the right-of-way. Wait until the weather clears before trying to drive with the wipers inoperative.
Page 163 From the center position (normal), turn the switch towards (+) for higher sensitivity (faster response) or turn the switch towards ( _ ) for less sensitivity (slower response). Switch í Driving Your Mazda Less sensitivity Center position Higher sensitivity 5-51 Some models.
Page 164 Be careful not to pinch hands or fingers as it may cause injury, or damage the wipers. When washing or servicing your Mazda, make sure the wiper lever is in the OFF position. 5-52 Form No.8U55-EA-05G...
Page 165: Rear Window Wiper And Washer (5 Door)
(Type A)/AUTO (Type B) position, the wipers will operate continuously until the lever is released. If the washer doesn't work, inspect the fluid level (page 8-20). If it's OK, consult an Authorized Mazda Dealer. Form No.8U55-EA-05G Black plate (165,1) Driving Your Mazda Switches and Controls...
Page 166: Rear Window Defroster
Mazda3_8U55-EA-05G_Edition1 Page166 Tuesday, May 31 2005 1:19 PM Driving Your Mazda Switches and Controls Rear Window Defroster The rear window defroster clears frost, fog, and thin ice from the rear window. The ignition switch must be in the ON position.
Page 167: Horn
To sound the horn, press around the mark on the steering wheel. Form No.8U55-EA-05G Black plate (167,1) Driving Your Mazda Switches and Controls Hazard Warning Flasher The hazard warning lights should always be used when you stop on or near a roadway.
Page 168 Mazda3_8U55-EA-05G_Edition1 Page168 Tuesday, May 31 2005 1:19 PM Black plate (168,1) 5-56 Form No.8U55-EA-05G...
Page 169: Interior Comfort
Mazda3_8U55-EA-05G_Edition1 Page169 Tuesday, May 31 2005 1:19 PM Interior Comfort Use of various features for drive comfort, including air-conditioning and audio system. Climate Control System ... 6-2 Operating Tips ... 6-2 Vent Operation ... 6-3 Types of the Climate Control System ... 6-5 Manual Type ...
Page 170: Climate Control System
Have the air conditioner checked before the weather gets hot. Lack of refrigerant may make the air conditioner less efficient. Consult an Authorized Mazda Dealer for refrigerant inspection. The air conditioner is filled with HFC134a (R134a), a refrigerant that will not damage the ozone layer.
Page 171: Vent Operation
Mazda3_8U55-EA-05G_Edition1 Page171 Tuesday, May 31 2005 1:19 PM qAdjusting the Vents Directing airflow Side Vents To adjust the direction of airflow, open the vents and rotate them left and right. Push Form No.8U55-EA-05G Black plate (171,1) Climate Control System Vent Operation Center vents Center Vents To adjust the direction of airflow, move...
Page 172 Mazda3_8U55-EA-05G_Edition1 Page172 Tuesday, May 31 2005 1:19 PM Interior Comfort Climate Control System qSelecting the Airflow Mode Dashboard Vents Dashboard and Floor Vents Floor Vents Form No.8U55-EA-05G Black plate (172,1) Defroster and Floor Vents Defroster Vents...
Page 173: Types Of The Climate Control System
Mazda3_8U55-EA-05G_Edition1 Page173 Tuesday, May 31 2005 1:19 PM Types of the Climate Control System Manual type and fully automatic type climate control systems are explained separately. Check your vehicle's climate control type and read the appropriate pages. Climate control information is displayed on the information display. Manual Type ...
Page 174: Manual Type
Mazda3_8U55-EA-05G_Edition1 Page174 Tuesday, May 31 2005 1:19 PM Interior Comfort Climate Control System Mode selector dial A/C Switch qControl Switches Temperature control dial Cold This dial controls temperature. Turn it clockwise for hot and counterclockwise for cold. Form No.8U55-EA-05G Manual Type Fan control dial Temperature control dial Air intake selector...
Page 175 Mazda3_8U55-EA-05G_Edition1 Page175 Tuesday, May 31 2005 1:19 PM Mode selector dial Turn the mode selector dial to select airflow mode (page 6-4). NOTE If you want to slightly adjust the airflow amount, set the mode selector dial at For example, when the mode selector dial is at the position between the positions, airflow from...
Page 176 Mazda3_8U55-EA-05G_Edition1 Page176 Tuesday, May 31 2005 1:19 PM Interior Comfort Climate Control System WARNING The Recirculated Air Position: Using the position in cold or rainy weather will cause the windows to fog up. Your vision will be hampered, which could lead to a serious accident.
Page 177 Mazda3_8U55-EA-05G_Edition1 Page177 Tuesday, May 31 2005 1:19 PM CAUTION When using the air conditioner while driving up long hills or in heavy traffic, closely monitor the temperature gauge (page 5-31). The air conditioner may cause engine overheating. If the gauge indicates overheating, turn the air conditioner off (page 7-12).
Page 178 Mazda3_8U55-EA-05G_Edition1 Page178 Tuesday, May 31 2005 1:19 PM Interior Comfort Climate Control System qDehumidifying (With Air Conditioner) Operate the air conditioner in cool or cold weather to help defog the windshield and side windows. 1. Set the mode selector dial to the desired position.
Page 179: Fully Automatic Type
Mazda3_8U55-EA-05G_Edition1 Page179 Tuesday, May 31 2005 1:19 PM Fully Automatic Type Climate control information is displayed on the information display. Fan control dial OFF switch A/C Switch Air intake selector qControl Switches AUTO switch By pressing the AUTO switch the following functions will be automatically controlled in accordance with the set temperature:...
Page 180 Mazda3_8U55-EA-05G_Edition1 Page180 Tuesday, May 31 2005 1:19 PM Interior Comfort Climate Control System NOTE AUTO switch indicator light When on, it indicates AUTO operation, and the system will function automatically. When off, indicates the operation of other switches such as the mode selector switch, fan control dial, A/C switch and windshield defroster switch.
Page 181 Mazda3_8U55-EA-05G_Edition1 Page181 Tuesday, May 31 2005 1:19 PM A/C switch With the AUTO or fan control dial ON, press the A/C switch to select the air conditioning (cooling/dehumidifying functions) on or off. NOTE Selection of A/C and A/C ECO is done automatically.
Page 182 Mazda3_8U55-EA-05G_Edition1 Page182 Tuesday, May 31 2005 1:19 PM Interior Comfort Climate Control System NOTE The displayed ambient temperature may vary from the actual ambient temperature depending on the surrounding area and vehicle conditions. Press the AMB button again to switch the display from ambient temperature to the temperature set for the air conditioner.
Page 183 Mazda3_8U55-EA-05G_Edition1 Page183 Tuesday, May 31 2005 1:19 PM qWindshield Defrosting and Defogging Press the windshield defroster switch. In this position, the position is automatically selected, and the air conditioner automatically turned on. The air conditioner will direct dehumidified air to the front windshield and side windows (page 6-4).
Page 184: Audio System
Mazda3_8U55-EA-05G_Edition1 Page184 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System Antenna qDetachable Type To remove the antenna, turn it counterclockwise. To install the antenna, turn it clockwise. Make sure the antenna is securely installed. Install Remove CAUTION To prevent damage to the antenna, remove it before entering a car wash facility or passing beneath a low overhead clearance.
Page 185 Mazda3_8U55-EA-05G_Edition1 Page185 Tuesday, May 31 2005 1:19 PM qRadio Reception AM characteristics AM signals bend around such things as buildings or mountains and bounce off the ionosphere. Therefore, they can reach longer distances than FM signals. Because of this, two stations may sometimes be picked up on the same frequency at the same time.
Page 186 Mazda3_8U55-EA-05G_Edition1 Page186 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System Flutter/Skip noise Signals from an FM transmitter move in straight lines and become weak in valleys between tall buildings, mountains, and other obstacles. When a vehicle passes through such an area, the reception conditions may change suddenly, resulting in annoying noise.
Page 187 Use a good quality head- cleaning tape or a liquid cleaner cassette tape to remove it. Should the unit not operate normally, consult an Authorized Mazda Dealer. Never attempt to repair it or insert a screwdriver or anything else. Handling the cassette tape player The following precautions should be observed.
Page 188 Mazda3_8U55-EA-05G_Edition1 Page188 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System qOperating Tips for CD Player/In- Dash CD Changer Condensation phenomenon Immediately after turning on the heater when the vehicle is cold, the CD or optical components (prism and lens) in the CD player/changer may become clouded with condensation.
Page 189 Mazda3_8U55-EA-05G_Edition1 Page189 Tuesday, May 31 2005 1:19 PM When driving over uneven surfaces, the sound may jump. The CD player/changer has been designed to play CDs bearing the identification logo as shown. No other discs can be played. Be sure never to touch the signal surface when handling the CDs.
Page 190 Mazda3_8U55-EA-05G_Edition1 Page190 Tuesday, May 31 2005 1:19 PM Black plate (190,1) MEMO 6-22 Form No.8U55-EA-05G...
Page 191: Audio Set
Mazda3_8U55-EA-05G_Edition1 Page191 Tuesday, May 31 2005 1:19 PM Audio information is displayed on the information display. CD Player Cassette Tape Player Power/Volume/Sound Controls ... page 6-24 Operating the Radio ... page 6-28 Operating the Cassette Tape Player ... page 6-30 Operating the Compact Disc (CD) Player ...
Page 192 Mazda3_8U55-EA-05G_Edition1 Page192 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System qPower/Volume/Sound Controls Power ON/OFF Turn the ignition switch to the ACC or ON position. Press the power/volume dial to turn the audio system on. Press the power/volume dial again to turn the audio system off.
Page 193 Mazda3_8U55-EA-05G_Edition1 Page193 Tuesday, May 31 2005 1:19 PM BOSE Sound System-equipped model Depending on the mode selected, the indication changes. 2. Turn the audio control dial to adjust the selected functions as follows: Standard audio-equipped model Indication Turn Left Turn Right Select mode Decrease bass...
Page 194 Mazda3_8U55-EA-05G_Edition1 Page194 Tuesday, May 31 2005 1:19 PM Black plate (194,1) Interior Comfort Audio System The following four modes are available. Select the desired mode. Mode Volume change No change Minimum Medium Maximum Turn the audio control dial to select the ALC OFF, ALC LEVEL1 3 mode.
Page 195 Mazda3_8U55-EA-05G_Edition1 Page195 Tuesday, May 31 2005 1:19 PM Black plate (195,1) MEMO 6-27 Form No.8U55-EA-05G...
Page 196 Mazda3_8U55-EA-05G_Edition1 Page196 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System qOperating the Radio Band selector buttons Scan button Seek tuning buttons *For reception of optional SIRIUS digital satellite radio. Used on vehicles equipped with the separately sold SIRIUS digital satellite radio unit. For information on use, read the manual accompanying the SIRIUS unit.
Page 197 Mazda3_8U55-EA-05G_Edition1 Page197 Tuesday, May 31 2005 1:19 PM Seek tuning Pressing the seek tuning button ( , will cause the tuner to seek a higher or lower frequency automatically. NOTE If you continue to press and hold the button, the frequency will continue changing without stopping.
Page 198 Mazda3_8U55-EA-05G_Edition1 Page198 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System qOperating the Cassette Tape Player Repeat button APC button: (next program) (one being played) Program button Dolby NR button Cassette tape insert Insert the cassette tape into the slot, open edge to the right and cassette tape will begin play, and TAPE PLAY will be displayed.
Page 199 Mazda3_8U55-EA-05G_Edition1 Page199 Tuesday, May 31 2005 1:19 PM NOTE The cassette tape can be ejected when the ignition switch is in the OFF position. Fast-forward/Rewind Press the fast-forward button ( fast-forward. Press the rewind button ( To stop this operation and play the cassette tape, press the button again.
Page 200 Mazda3_8U55-EA-05G_Edition1 Page200 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System qOperating the Compact Disc (CD) Player Scan button Load button Track up button Track down button Inserting the CD Insert the CD into the slot, label-side up. The auto-loading mechanism will set the CD and begin play.
Page 201 Mazda3_8U55-EA-05G_Edition1 Page201 Tuesday, May 31 2005 1:19 PM Music scan This feature helps to find a program by playing about the first 10 seconds of each track. Press the scan button ( ) during play to start scan play operation (the track number will flash).
Page 202 Mazda3_8U55-EA-05G_Edition1 Page202 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System qOperating the In-Dash CD Changer Scan button Load button Repeat button Track up button Track down button Random button Display button Inserting the CD The CD must be label-side up when inserting.
Page 203 Mazda3_8U55-EA-05G_Edition1 Page203 Tuesday, May 31 2005 1:19 PM Multiple insertion 1. Press and hold the load button ( for about 2 seconds until a beep sound is heard. 2. Press the load button ( while WAIT is displayed. NOTE If the button is not operated while WAIT is displayed, the display changes to IN and the CD can be inserted.
Page 204 Mazda3_8U55-EA-05G_Edition1 Page204 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System NOTE CDs will be ejected starting with the one with the lowest number. All CDs in the tray will be ejected continuously. CDs can be ejected when the ignition switch is off.
Page 205 Tuesday, May 31 2005 1:19 PM qError Indications If you see an error indication on the display, find the cause in the chart. If you cannot clear the error indication, take the vehicle to an Authorized Mazda Dealer. Indication CD is inserted upside down...
Page 206: Audio Control Switch Operation (Steering Wheel) Í
í 6-38 Some models. Form No.8U55-EA-05G Black plate (206,1) NOTE í Mazda has installed this system to prevent distraction while driving the vehicle and using audio controls on the dashboard. Always make safe driving your first priority. qAdjusting the Volume To increase the volume, press the volume button ( ).
Page 207 Mazda3_8U55-EA-05G_Edition1 Page207 Tuesday, May 31 2005 1:19 PM qChanging the Source Press the mode switch ( ) to change the audio source (FM1 radio> FM2 radio> AM radio> CD player or CD changer> Cassette tape player> SIRIUS1> SIRIUS2> SIRIUS3> cyclical). NOTE Cassette tape, CD, CD changer and SIRIUS digital satellite radio modes...
Page 208 Mazda3_8U55-EA-05G_Edition1 Page208 Tuesday, May 31 2005 1:19 PM Interior Comfort Audio System qMute Switch Press the mute switch ( ) once to mute audio, press it again to resume audio output. NOTE If the ignition switch is turned to the LOCK position with the audio muted, the mute will be canceled.
Page 209: Safety Certification
This CD player should not be adjusted or repaired by anyone except qualified service personnel. If servicing is required, contact an Authorized Mazda Dealer. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser exposure. Never operate the CD player with the top case of the unit removed.
Page 210: Interior Equipment
Mazda3_8U55-EA-05G_Edition1 Page210 Tuesday, May 31 2005 1:19 PM Interior Comfort Interior Equipment Sunvisors When you need a sunvisor, lower it for use in front or swing it to the side. Sunvisor qVanity Mirrors To use the vanity mirror, lower the sunvisor.
Page 211 Mazda3_8U55-EA-05G_Edition1 Page211 Tuesday, May 31 2005 1:19 PM í qOverhead Lights Front With moonroof Without moonroof Switch Front Overhead Lights Position Light off Light on when any door is open (With illuminated entry system) Light on or off when the illuminated entry system is on Form No.8U55-EA-05G Black plate (211,1)
Page 212 Mazda3_8U55-EA-05G_Edition1 Page212 Tuesday, May 31 2005 1:20 PM Interior Comfort Interior Equipment Without moonroof Switches qLuggage Compartment Light (5 Door) Switch Luggage Compartment Light Position Light off Light on when the liftgate is open 6-44 Form No.8U55-EA-05G Black plate (212,1)
Page 213: Information Display
Mazda3_8U55-EA-05G_Edition1 Page213 Tuesday, May 31 2005 1:20 PM Trip computer/Clock With trip computer Without trip computer qInformation Display Functions The information display has the following functions: Clock Ambient Temperature Display (Outside Temperature Display) Climate Control Display (Fully Automatic Type) Audio Display í...
Page 214 Mazda3_8U55-EA-05G_Edition1 Page214 Tuesday, May 31 2005 1:20 PM Interior Comfort Interior Equipment qClock NOTE When the trip computer is being displayed, press the CLOCK button to change the display to the time. When the ignition switch is in the ACC or ON position, the time is displayed.
Page 215 When the time is being displayed, press the INFO button to change the display to the trip computer. If you have any problems with your trip computer, consult an Authorized Mazda Dealer. Current fuel economy mode This mode displays the current fuel...
Page 216 Mazda3_8U55-EA-05G_Edition1 Page216 Tuesday, May 31 2005 1:20 PM Interior Comfort Interior Equipment U.S.A. CANADA When you've slowed to about 5 km/h (3 mph), L/100 km ( mpg) will be displayed. Average fuel economy mode This mode displays the average fuel economy by calculating the fuel consumption and the distance traveled since connecting the battery or resetting...
Page 217 Mazda3_8U55-EA-05G_Edition1 Page217 Tuesday, May 31 2005 1:20 PM U.S.A. CANADA NOTE Even though the distance-to-empty display may indicate a sufficient amount of remaining mileage before refueling is required, refuel as soon as possible if the fuel gauge needle nears E or the low fuel warning light illuminates.
Page 218: Lighter
Don't use the lighter socket for plug- in accessories such as shavers and coffee pots. They may damage it or cause electrical failure. Use only a genuine Mazda lighter or the equivalent. If the lighter doesn't pop out within 30 seconds, remove it to prevent overheating.
Page 219: Cup Holder
Mazda3_8U55-EA-05G_Edition1 Page219 Tuesday, May 31 2005 1:20 PM Cup Holder WARNING Using Cup Holder: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous. If the contents spill, you could be scalded. Never use a cup holder to hold hot liquids while the vehicle is moving.
Page 220: Bottle Holder
Mazda3_8U55-EA-05G_Edition1 Page220 Tuesday, May 31 2005 1:20 PM Interior Comfort Interior Equipment Bottle Holder Bottle holders are on the inside of the front doors. Bottle holder CAUTION Don't use the bottle holders for containers without caps. The contents may spill when the door is opened or closed.
Page 221 Mazda3_8U55-EA-05G_Edition1 Page221 Tuesday, May 31 2005 1:20 PM qCenter Console To open, pull the lower release catch. Small items can be placed in the tray of the center console lid. To open it, pull the upper release catch. qCargo Securing Loops (5 Door) WARNING Not Securing Luggage and Cargo: Not securing cargo while driving is...
Page 222 Mazda3_8U55-EA-05G_Edition1 Page222 Tuesday, May 31 2005 1:20 PM Interior Comfort Interior Equipment Without flexible floor board To use the cargo sub-compartment, remove or lift the trunk board. Trunk board Cargo sub- compartment qFlexible Floor Board (5 Door) The luggage compartment can be separated vertically and/or horizontally, using the trunk board and the trunk board loops.
Page 223 Mazda3_8U55-EA-05G_Edition1 Page223 Tuesday, May 31 2005 1:20 PM 2. Insert the trunk board loops into the trunk board slits. Trunk board NOTE To facilitate insertion of the trunk board loops into the trunk board slits, first insert the bottom of the rear trunk board into the groove of the luggage sub- compartment.
Page 224 Mazda3_8U55-EA-05G_Edition1 Page224 Tuesday, May 31 2005 1:20 PM Interior Comfort Interior Equipment 3. Insert the other trunk board loop into slit B until a click sound is heard. Slit B 4. Rock the trunk board to make sure the board is installed securely. CAUTION Do not place or remove luggage via the rear passenger seat area while the...
Page 225: In Case Of An Emergency
Mazda3_8U55-EA-05G_Edition1 Page225 Tuesday, May 31 2005 1:20 PM In Case of an Emergency Helpful information on what to do in an emergency. Parking in an Emergency ... 7-2 Parking in an Emergency ... 7-2 Flat Tire ... 7-3 Spare Tire and Tool Storage ... 7-3 Changing a Flat Tire ...
Page 226: Parking In An Emergency
Mazda3_8U55-EA-05G_Edition1 Page226 Tuesday, May 31 2005 1:20 PM In Case of an Emergency Parking in an Emergency Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.
Page 227: Flat Tire
Mazda3_8U55-EA-05G_Edition1 Page227 Tuesday, May 31 2005 1:20 PM Spare Tire and Tool Storage Spare tire and tools are stored in the locations illustrated in the diagram. 4 Door Jack 5 Door Jack Form No.8U55-EA-05G Spare tire Lug wrench Jack handle Lug wrench Tiedown eyelet Jack handle...
Page 228 2. Turn the wing bolt counterclockwise. To secure the jack Perform the removal procedure in reverse. qSpare Tire Your Mazda has a temporary spare tire. The temporary spare tire is lighter and smaller than a conventional tire, and is designed only for emergency use and should be used only for VERY short periods.
Page 229 Mazda3_8U55-EA-05G_Edition1 Page229 Tuesday, May 31 2005 1:20 PM NOTE (With Tire Pressure Monitoring System) A tire pressure sensor is not installed to the temporary spare tire. The warning light will flash continuously while the temporary spare tire is being used (page 5-23).
Page 230: Changing A Flat Tire
Black plate (230,1) CAUTION (With Tire Pressure Monitoring System) The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors. Do not use non-genuine wheels, otherwise it may not be possible to install the tire pressure sensors.
Page 231 Mazda3_8U55-EA-05G_Edition1 Page231 Tuesday, May 31 2005 1:20 PM 6. Block the wheel diagonally opposite the flat tire. When blocking a wheel, place a tire block both in front and behind the tire. NOTE When blocking a tire, use rocks or wood blocks of sufficient size to hold the tire in place.
Page 232 Before removing the lug nuts, make sure your Mazda is firmly in position and that it cannot slip or move. 6. Remove the lug nuts by turning them counterclockwise;...
Page 233 If you lose this key, consult an Authorized Mazda Dealer or use the lock manufacturer's order form, which is with the registration card.
Page 234 Use the lug wrench to tighten the nuts in the order shown. If you're unsure of how tight the nuts should be, have them inspected at an Authorized Mazda Dealer. Nut tightening torque N·m (kgf·m, ft·lbf) 88 117 (9 11, 65 93)
Page 235 Metric Studs and Lug Nuts: Because the wheel studs and lug nuts on your Mazda have metric threads, using a non-metric nut is dangerous. On a metric stud, it would not secure the wheel and would damage the stud, which could cause the wheel to slip off and cause an accident.
Page 236: Overheating
If the cooling fan does not operate while the engine is running, the engine temperature will increase. Stop the engine and call an Authorized Mazda Dealer. 5. Make sure the cooling fan is operating, then turn off the engine after the temperature has decreased.
Page 237 CAUTION If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an Authorized Mazda Dealer. Form No.8U55-EA-05G Black plate (237,1) In Case of an Emergency...
Page 238: Emergency Starting
Mazda3_8U55-EA-05G_Edition1 Page238 Tuesday, May 31 2005 1:20 PM In Case of an Emergency Emergency Starting Starting a Flooded Engine If the engine fails to start, it may be flooded (excessive fuel in the engine). Follow this procedure: 1. Depress the accelerator all the way and hold it there.
Page 239: Jump-Starting
Mazda3_8U55-EA-05G_Edition1 Page239 Tuesday, May 31 2005 1:20 PM Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 240 Mazda3_8U55-EA-05G_Edition1 Page240 Tuesday, May 31 2005 1:20 PM In Case of an Emergency Emergency Starting Keep Flames Away: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
Page 241 Mazda3_8U55-EA-05G_Edition1 Page241 Tuesday, May 31 2005 1:20 PM Connect cables in numerical order and disconnect in reverse order. 1. Remove the battery cover from its front side. Battery cover 2. Make sure the booster battery is 12 V and that its negative terminal is grounded.
Page 242: Push-Starting
Mazda3_8U55-EA-05G_Edition1 Page242 Tuesday, May 31 2005 1:20 PM In Case of an Emergency Emergency Starting NOTE Verify that the covers are securely installed. 7-18 Form No.8U55-EA-05G Black plate (242,1) Push-Starting WARNING Towing a Vehicle to Start It: Towing a vehicle to start it is dangerous.
Page 243: Emergency Towing
Mazda3_8U55-EA-05G_Edition1 Page243 Tuesday, May 31 2005 1:20 PM Towing Description We recommend that towing be done only by an Authorized Mazda Dealer or a commercial tow-truck service. Proper lifting and towing are necessary to prevent damage to the vehicle. Government and local laws must be followed.
Page 244: Tiedown Hook
Mazda3_8U55-EA-05G_Edition1 Page244 Tuesday, May 31 2005 1:20 PM In Case of an Emergency Emergency Towing CAUTION Do not use the hooks under the rear bumper for towing and tying down, as they cannot hold the load and it will damage the bumper. Hooks 7-20 Form No.8U55-EA-05G...
Page 245 Mazda3_8U55-EA-05G_Edition1 Page245 Tuesday, May 31 2005 1:20 PM CAUTION The cap cannot be completely removed. Do not use excessive force as it may damage the cap or scratch the painted bumper surface. 3. Securely install the tiedown eyelet using the lug wrench. 4.
Page 246: Recreational Towing
Mazda3_8U55-EA-05G_Edition1 Page246 Tuesday, May 31 2005 1:20 PM In Case of an Emergency Emergency Towing Recreational Towing An example of recreational towing is towing your vehicle behind a motorhome. The transaxle is not designed for towing this vehicle on all 4 wheels. When doing recreational towing refer to Towing Description (page 7-19) and Tiedown Hook (page 7-20) and...
Page 247: Maintenance And Care
Mazda3_8U55-EA-05G_Edition1 Page247 Tuesday, May 31 2005 1:20 PM Maintenance and Care How to keep your Mazda in top condition. Introduction ... 8-2 Introduction ... 8-2 Scheduled Maintenance ... 8-3 Scheduled Maintenance ... 8-3 Owner Maintenance ... 8-8 Owner Maintenance Schedule ... 8-8 Owner Maintenance Precautions ...
Page 248: Introduction
Claims against the warranty resulting from lack of maintenance, as opposed to defective materials or authorized Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance. But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts.
Page 249: Scheduled Maintenance
Mazda3_8U55-EA-05G_Edition1 Page249 Tuesday, May 31 2005 1:20 PM Scheduled Maintenance Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. If any do apply, follow Schedule 2 (Canada and Puerto Rico residents follow Schedule 2). Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes...
Page 250 Mazda3_8U55-EA-05G_Edition1 Page250 Tuesday, May 31 2005 1:20 PM Maintenance and Care Scheduled Maintenance qSchedule 1 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles ENGINE Engine valve clearance Drive belts (tension) Engine oil Engine oil filter COOLING SYSTEM Cooling system...
Page 251 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 252 Mazda3_8U55-EA-05G_Edition1 Page252 Tuesday, May 31 2005 1:20 PM Maintenance and Care Scheduled Maintenance qSchedule 2 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles ENGINE Engine valve clearance Drive belts (tension) Puerto Rico Engine oil Others Engine oil filter...
Page 253 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 254: Owner Maintenance
The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.
Page 255: Owner Maintenance Precautions
Improper owner maintenance during the warranty period may affect warranty coverage. For details, read the separate Mazda Warranty statement provided with the vehicle. If you're unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.
Page 256: Engine Compartment Overview
Mazda3_8U55-EA-05G_Edition1 Page256 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance Engine Compartment Overview Engine coolant reservoir Engine oil-filler cap Power steering fluid reservoir Windshield washer fluid reservoir 8-10 Form No.8U55-EA-05G Main fuse Brake/Clutch fluid Battery reservoir Engine oil Air filter dipstick Automatic transaxle fluid-level dipstick...
Page 257: Engine Oil
International Lubricant Standardization and Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. –30 –10 –20 –20 5W-20 Except U.S.A. and CANADA...
Page 258 Mazda3_8U55-EA-05G_Edition1 Page258 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance The quality designation SL, or ILSAC must be on the label. –30 –10 –20 –20 5W-20 qInspecting Engine Oil Level 1. Be sure the vehicle is on a level surface.
Page 259 Use only specified engine oil (page 10-4). Changing oil filter Because you need a special tool to retighten the filter, an Authorized Mazda Dealer should do the work. Tighten Drain plug Black plate (259,1) Maintenance and Care 4.3 (4.5, 3.8)
Page 260: Engine Coolant
MAX. CAUTION Radiator coolant will damage paint. Rinse it off quickly if spilled. If the coolant reservoir is empty or new coolant is required frequently, consult an Authorized Mazda Dealer.
Page 261 Mazda3_8U55-EA-05G_Edition1 Page261 Tuesday, May 31 2005 1:20 PM qChanging Coolant Change coolant according to Scheduled Maintenance (page 8-3). CAUTION Use only soft (demineralized) water in the coolant mixture. Water that contains minerals will cut down on the coolant's effectiveness. Don't add only water. Always add a proper coolant mixture.
Page 262: Brake/Clutch Fluid
Inspect the fluid level in the reservoir regularly. It should be kept at MAX. The level normally drops with accumulated distance, a condition associated with wear of brake and clutch linings. If it is excessively low, have the brake/clutch system inspected by an Authorized Mazda Dealer.
Page 263: Power Steering Fluid
Add fluid if necessary; it does not require periodic changing. The level must be kept between MIN and MAX. Visually examine the lines and hoses for leaks and damage. If new fluid is required frequently, consult an Authorized Mazda Dealer. 8-17...
Page 264: Automatic Transaxle Fluid (Atf)
Mazda3_8U55-EA-05G_Edition1 Page264 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance Automatic Transaxle Fluid (ATF) qInspecting Automatic Transaxle Fluid Level The automatic transaxle fluid level should be inspected regularly. Measure it as described below. 2.3-liter engine CAUTION Always check the automatic transaxle fluid level according to the following procedure.
Page 265 Mazda3_8U55-EA-05G_Edition1 Page265 Tuesday, May 31 2005 1:20 PM 9. Shift the shift lever to the park position (P), check the ATF level while the engine is idling, and make sure that the ATF level is within the proper level. If the ATF level is not within the proper level, add ATF.
Page 266: Washer Fluid
Mazda3_8U55-EA-05G_Edition1 Page266 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance Fluid cold scale B When the engine has not been running and the outside temperature is about 20°C (70°F), the fluid level should be close to, but not above, the bottom notch on the dipstick.
Page 267: Body Lubrication
Mazda3_8U55-EA-05G_Edition1 Page267 Tuesday, May 31 2005 1:20 PM Inspect fluid level in the washer fluid reservoir; add fluid if necessary. To inspect the washer fluid level in the front reservoir, pull off the cap. Then, holding your thumb over the hole in the center of the cap, lift it straight up.
Page 268: Air Filter
NOTE If the vehicle is operated in very dusty or sandy areas, replace the filter more often than the recommended intervals. CAUTION Use a Mazda genuine air filter. Use of other filters could damage the airflow sensor. 8-22 Form No.8U55-EA-05G Black plate (268,1) 1.
Page 269: Wiper Blades
Be careful not to pinch hands or fingers as it may cause injury, or damage the wipers. When washing or servicing your Mazda, make sure the wiper lever is in the OFF position. Contamination of either the windshield or the blades with foreign matter can reduce wiper effectiveness.
Page 270 Mazda3_8U55-EA-05G_Edition1 Page270 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance If the blades are not wiping properly, clean the window and blades with a good cleaner or mild detergent; then rinse thoroughly with clean water. Repeat if necessary.
Page 271 Mazda3_8U55-EA-05G_Edition1 Page271 Tuesday, May 31 2005 1:20 PM CAUTION Don't bend or discard the stiffeners. You need to use them again. If the metal stiffeners are switched, the blade's wiping efficiency could be reduced. So don't use the driver's side metal stiffeners on the passenger's side, or vice versa.
Page 272 Mazda3_8U55-EA-05G_Edition1 Page272 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance 3. Remove the metal stiffeners from the blade rubber and install them in new blades. CAUTION Don't bend or discard the stiffeners. You need to use them again. 4.
Page 273: Battery
Mazda3_8U55-EA-05G_Edition1 Page273 Tuesday, May 31 2005 1:20 PM Battery-Related Lead Materials: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Wash hands after handling. Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 274 Mazda3_8U55-EA-05G_Edition1 Page274 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance Keep Flames Away: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
Page 275 Mazda3_8U55-EA-05G_Edition1 Page275 Tuesday, May 31 2005 1:20 PM NOTE Remove the battery cover before performing battery maintenance. qBattery Maintenance To get the best service from a battery: Keep it securely mounted. Keep the top clean and dry. Keep terminals and connections clean, tight, and coated with petroleum jelly or terminal grease.
Page 276: Tires
(radial, bias-belted, bias-type) on all four wheels. Using Wrong-Sized Tires: Using any other tire size than what is specified for your Mazda (page 10-7) is dangerous. It could seriously affect ride, handling, ground clearance, tire clearance, and speedometer calibration.
Page 277 Mazda3_8U55-EA-05G_Edition1 Page277 Tuesday, May 31 2005 1:20 PM NOTE Always check tire pressure when tires are cold. Warm tires normally exceed recommended pressures. Don't release air from warm tires to adjust the pressure. Underinflation can cause reduced fuel economy, uneven and accelerated tire wear, and poor sealing of the tire bead, which will deform the wheel and cause...
Page 278 CAUTION (With Tire Pressure Monitoring System) When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. NOTE (With Tire Pressure Monitoring System) When tires with steel wire...
Page 279 Mazda3_8U55-EA-05G_Edition1 Page279 Tuesday, May 31 2005 1:20 PM qTemporary Spare Tire Inspect the temporary spare tire at least monthly to make sure it's properly inflated and stored. NOTE The temporary spare tire condition gradually deteriorates even if it has not been used.
Page 280 (With Tire Pressure Monitoring System) When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Page 281: Light Bulbs
Mazda3_8U55-EA-05G_Edition1 Page281 Tuesday, May 31 2005 1:20 PM 4 Door Overhead light/Map lights (Front) Headlights (Low beam) Headlights (High beam) Fog lights Front turn signal lights/Side-marker lights Side turn signal lights 5 Door Overhead light/Map lights (Front) Headlights (Low beam) Headlights (High beam) Fog lights...
Page 282 Do not replace the xenon fusion bulbs yourself. Consult an Authorized Mazda Dealer when the replacement is necessary. Handling Halogen Bulbs: When a halogen bulb breaks, it is dangerous.
Page 283 3. Install the new bulb in the reverse order of removal. NOTE To replace the bulb, contact an Authorized Mazda Dealer. If the halogen bulb is accidentally touched, it should be cleaned with rubbing alcohol before being used. Use the protective cover and carton...
Page 284 Front turn signal lights/Side-marker lights Due to the complexity and difficulty of the procedure, the bulbs should be replaced by an Authorized Mazda Dealer. Side turn signal lights 1. Slide the unit as shown in the figure to remove it.
Page 285 3. Turn the socket and bulb assembly counterclockwise and remove it. 4. Disconnect the bulb from the socket. Brake lights/Taillights Rear turn signal lights 5. Install the new bulb in the reverse order of removal. NOTE To replace the bulb, contact an Authorized Mazda Dealer. 8-39...
Page 286 Brake lights/Taillights (5 Door) With LED bulb Due to the complexity and difficulty of the procedure, the LED bulbs should be replaced by an Authorized Mazda Dealer. NOTE LED bulb replacement is not possible. The rear combination component must be replaced.
Page 287 3. Disconnect the bulb from the socket. 4. Install the new bulb in the reverse order of removal. NOTE To replace the bulb, contact an Authorized Mazda Dealer. Form No.8U55-EA-05G Black plate (287,1) Maintenance and Care Owner Maintenance Reverse light 4 Door 1.
Page 288 3. Disconnect the bulb from the socket. 4. Install the new bulb in the reverse order of removal. NOTE To replace the bulb, contact an Authorized Mazda Dealer. 8-42 Form No.8U55-EA-05G Black plate (288,1) High-mount brake light 4 Door 1.
Page 289 4. Disconnect the bulb from the socket. 5. Install the new bulb in the reverse order of removal. NOTE To replace the bulb, contact an Authorized Mazda Dealer. Form No.8U55-EA-05G Black plate (289,1) Maintenance and Care Owner Maintenance License plate lights 1.
Page 290 Mazda3_8U55-EA-05G_Edition1 Page290 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance 2. Turn the socket and bulb assembly counterclockwise and remove it. 3. Disconnect the bulb from the socket. 4. Install the new bulb in the reverse order of removal.
Page 291: Fuses
If a fuse has blown, the inside element will be melted. If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. qFuse Replacement Replacing the fuses on the front passenger's side below the glove box...
Page 292 7. Push in a new fuse of the same amperage rating, and make sure it fits tightly. If it doesn't, have an Authorized Mazda Dealer install it. If you have no spare fuses, borrow one of the same rating from a circuit not essential to vehicle operation, such as the MIRROR or CIGAR circuit.
Page 293 3. If a fuse is blown, replace it with a new one of the same amperage rating. Normal Blown NOTE To replace the MAIN fuse, contact an Authorized Mazda Dealer. Form No.8U55-EA-05G Black plate (293,1) Maintenance and Care Owner Maintenance 8-47...
Page 294 Mazda3_8U55-EA-05G_Edition1 Page294 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance qFuse Panel Description Fuse block (Engine compartment) FUSE DESCRIPTION RATING 40 A P/ST 80 A 40 A HEAD 40 A 80 A GLOW 60 A ABS 1 30 A ABS 2 20 A...
Page 295 Mazda3_8U55-EA-05G_Edition1 Page295 Tuesday, May 31 2005 1:20 PM DESCRIPTION AUDIO ABS IG HORN H/CLEAN F/PUMP P/ST IG A/C MAG ENG +B ROOM ENG BAR 4 ENG BAR 3 EGI INJ ENG BAR 1 ENG BAR 2 Form No.8U55-EA-05G Owner Maintenance FUSE PROTECTED COMPONENT RATING...
Page 296 Mazda3_8U55-EA-05G_Edition1 Page296 Tuesday, May 31 2005 1:20 PM Maintenance and Care Owner Maintenance Fuse block (Passenger's side) 43 44 45 46 47 48 49 50 515253 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 7475 76 77 78 79 80 81 82 83 84 85 86 FUSE DESCRIPTION RATING...
Page 297 Mazda3_8U55-EA-05G_Edition1 Page297 Tuesday, May 31 2005 1:20 PM DESCRIPTION P/WIND L ALARM M/DEF HEAD LOW R HEAD LOW L METER IGNITION WIPER ENGINE IG SIG SAS 2 SEAT WARM D/LOCK 1 P/WIND L P/WIND R BACK SUN ROOF TAIL L ILLUMI Form No.8U55-EA-05G Owner Maintenance...
Page 298: Appearance Care
Prevention It is necessary to have your Mazda washed and waxed to preserve its finish according to the instructions in this section. This should be done as soon as possible.
Page 299 In low temperatures a vehicle's finish hardens. This increases the chance of paint chipping. Chipped paint can lead to rust forming on your Mazda. Before this happens, repair the damage by using Mazda touch-up paint according to the instructions in this section.
Page 300: Exterior Care
Be careful not to pinch hands or fingers as it may cause injury, or damage the wipers. When washing or servicing your Mazda, make sure the wiper lever is in the OFF position. To help protect the finish from rust and...
Page 301 Mazda3_8U55-EA-05G_Edition1 Page301 Tuesday, May 31 2005 1:20 PM CAUTION Don't use steel wool, abrasive cleaners, or strong detergents containing highly alkaline or caustic agents on chrome-plated or anodized aluminum parts. This may damage the protective coating; also, cleaners and detergents may discolor or deteriorate the paint.
Page 302 Exposed metal quickly rusts and can lead to major repairs. CAUTION If your Mazda is damaged and needs metal parts repaired or replaced, make sure the body shop applies anti- corrosion materials to all parts, both repaired and new.
Page 303: Interior Care
Mazda3_8U55-EA-05G_Edition1 Page303 Tuesday, May 31 2005 1:20 PM qAluminum Wheel Maintenance A protective coating is provided over the aluminum wheels. Special care is needed to protect this coating. NOTE Don't use a wire brush or any abrasive cleaner, polishing compound, or solvent on aluminum wheels.
Page 304 WARNING Damaged Seat Belt: Using damaged seat belts is dangerous. In a collision, damaged belts cannot provide adequate protection. Have an Authorized Mazda Dealer replace damaged belts immediately. qCleaning the Window Interiors If the windows become covered with an oily, greasy, or waxy film, clean them with glass cleaner.
Page 305: Customer Information And Reporting Safety Defects
Mazda Importer/Distributors ... 9-10 Importer/Distributor ... 9-10 Distributor in Each Area ... 9-10 Warranty ... 9-12 Warranties for Your Mazda ... 9-12 Outside the United States ... 9-13 Outside Canada ... 9-14 Registering Your Vehicle in A Foreign Country (Except United States and Canada) ...
Page 306: Customer Assistance
Authorized Mazda Dealer. qSTEP 1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 307 4. Purchase date and current mileage 5. Your dealer's name and location 6. Your question(s) If you live outside the U.S.A., please contact your nearest Mazda Distributor. Form No.8U55-EA-05G Black plate (307,1) Customer Information and Reporting Safety Defects...
Page 308: Customer Assistance (Canada)
Your complete and permanent satisfaction is of primary concern to Mazda. All Authorized Mazda Dealers have both the knowledge and tools to keep your Mazda in top condition. In our experience, any questions, problems, or complaints regarding the operation of your Mazda or any other general service transactions are most effectively resolved by your dealer.
Page 309 If a specific item of concern arises, where a solution cannot be reached between an owner, Mazda, and/or one of it's dealers (that all parties cannot agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 310 British Columbia & Yukon Territories Alberta & Northwest Territories Saskatchewan Manitoba Ontario Atlantic Canada Quebec qRegional Offices REGIONAL OFFICES MAZDA CANADA INC. WESTERN REGION 8171 ACKROYD ROAD SUITE 2000 RICHMOND B.C. V6X 3K1 (604) 303-5670 MAZDA CANADA INC. CENTRAL/ATLANTIC REGION...
Page 311: Customer Assistance (Puerto Rico)
1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 312: Customer Assistance (Mexico)
1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 313 Mazda3_8U55-EA-05G_Edition1 Page313 Tuesday, May 31 2005 1:21 PM By letter at: Attn: Customer Assistance Mazda North American Operations 7755 Irvine Center Drive Irvine, CA 92618-2922 P.O. Box 19734 Irvine, CA 92623-9734 In order to serve you efficiently and effectively, please help us by providing the following information: 1.
Page 314: Mazda Importer/Distributors
55 Vogell Road, Richmond Hill, Ontario, L4B 3K5 Canada TEL: 1 (800) 263-4680 (in Canada) (905) 787-7000 (outside Canada) qPUERTO RICO/U.S. Virgin Island Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936-2722 TEL: (787) 641-9300...
Page 315 (d.b.a. Triple J Motors) P.O. Box 500487 Saipan, MP 96950-0487 TEL: (670) 234-7133/3051 qAMERICAN SAMOA Polynesia Motors, Inc. P.O. Box 1120, Pago Pago, American Samoa 96799 TEL: (684) 699-9347 Form No.8U55-EA-05G Black plate (315,1) Customer Information and Reporting Safety Defects Mazda Importer/Distributors 9-11...
Page 316: Warranty
Emission Defect Warranty Emission Performance Warranty California Emission Control Warranty (U.S.A. only) Emission Control Warranty (Canada only) Replacement Parts and Accessories Limited Warranty Tire Warranty NOTE Detailed warranty information is provided with your Mazda. 9-12 Form No.8U55-EA-05G Black plate (316,1)
Page 317: Outside The United States
We strongly recommend that you NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety requirements (CMVSS).
Page 318: Outside Canada
We strongly recommend that you NOT take your Mazda outside Canada. However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with specific vehicle modifications to comply with the United States Federal Motor Vehicle Safety Standards (FMVSS).
Page 319: Registering Your Vehicle In A Foreign Country (Except United States And Canada)
Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 320: Add-On Non-Genuine Parts And Accessories
Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle's performance or safety systems;...
Page 321: Cell Phones
Mazda3_8U55-EA-05G_Edition1 Page321 Tuesday, May 31 2005 1:21 PM Use of Cell Phones and Other Devices by Driver: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver's hands.
Page 322: Type Approval Of Equipment
Mazda3_8U55-EA-05G_Edition1 Page322 Tuesday, May 31 2005 1:21 PM Black plate (322,1) Customer Information and Reporting Safety Defects Type Approval of Equipment Type Approval of Equipment Immobilizer system 9-18 Form No.8U55-EA-05G...
Page 323: Uniform Tire Quality Grading System (Utqgs)
Mazda3_8U55-EA-05G_Edition1 Page323 Tuesday, May 31 2005 1:21 PM Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality Grading System (UTQGS) This information relates to the tire grading system developed by the U.S. National Highway Traffic Safety Administration for grading tires by tread wear, traction, and temperature performance.
Page 324 These grades will be added to the sidewalls of passenger vehicle tires over the next several years according to a schedule established by the NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicles may vary with respect to grade.
Page 325: Tire Information (U.s.a.)
Mazda3_8U55-EA-05G_Edition1 Page325 Tuesday, May 31 2005 1:21 PM Federal law requires tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a tire identification number for safety standard certification and in case of a recall.
Page 326 Mazda3_8U55-EA-05G_Edition1 Page326 Tuesday, May 31 2005 1:21 PM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) 11. Tread wear, traction and temperature grades 12. Max. permissible inflation pressure 13. SAFETY WARNING P215/65R15 95H is an example of a tire size and load index rating. Here is an explanation of the various components of that tire size and load index rating.
Page 327 Mazda3_8U55-EA-05G_Edition1 Page327 Tuesday, May 31 2005 1:21 PM H is the speed rating. The speed rating denotes the maximum speed for which the use of the tire is rated. Letter Rating * For tires with a maximum speed capability over 149 mph, tire manufacturers sometimes use the letters ZR. For tires with a maximum speed capability over 186 mph, tire manufacturers always use the letters ZR.
Page 328 Mazda3_8U55-EA-05G_Edition1 Page328 Tuesday, May 31 2005 1:21 PM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Tread Wear, Traction and Temperature Grades Tread wear: The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 329 Mazda3_8U55-EA-05G_Edition1 Page329 Tuesday, May 31 2005 1:21 PM qInformation on Temporary Tires Please refer to the diagram below. 1. Temporary tires 2. Nominal width of tire in millimeters 3. Ratio of height to width (aspect ratio) 4. Diagonal 5. Rim diameter code T115/70D 16 is an example of a tire size and load index rating.
Page 330 Mazda3_8U55-EA-05G_Edition1 Page330 Tuesday, May 31 2005 1:21 PM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) D is the tire construction symbol. D indicates diagonal ply construction . 16 is the wheel rim diameter in inches. 9-26 Form No.8U55-EA-05G Black plate (330,1)
Page 331: Location Of The Tire Label (Placard)
Mazda3_8U55-EA-05G_Edition1 Page331 Tuesday, May 31 2005 1:21 PM Location of the Tire Label (Placard) You will find the tire label containing tire inflation pressure by tire size and other important information on the driver's side B-pillar or on the edge of the driver's door frame. SAMPLE qRecommended Tire Inflation Pressure On the tire label you will find the recommended tire inflation pressure in both kPa and psi...
Page 332 Mazda3_8U55-EA-05G_Edition1 Page332 Tuesday, May 31 2005 1:21 PM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Tire Under-Inflation: Driving your vehicle with under-inflated tires is dangerous. Under-inflation is the most common cause of failures in any kind of tire and may result in severe cracking, tread separation or blowout , with unexpected loss of vehicle control and increased risk of injury.
Page 333 Mazda3_8U55-EA-05G_Edition1 Page333 Tuesday, May 31 2005 1:21 PM NOTE Warm tires normally exceed recommended pressures. Don't release air from warm tires to adjust the pressure. Under-inflation can cause serious failures and accidents. Over-inflation can produce a harsh ride and the greater possibility of damage from road hazards.
Page 334: Specifications
Mazda3_8U55-EA-05G_Edition1 Page334 Tuesday, May 31 2005 1:21 PM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Tire Maintenance Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Here are some important maintenance points: qTire Inflation Pressure Inspect all tire pressure monthly (including the spare) when the tires are cold. Maintain recommended pressures for the best ride, top handling, and minimum tire wear.
Page 335 Mazda3_8U55-EA-05G_Edition1 Page335 Tuesday, May 31 2005 1:21 PM Rotate unidirectional tires and radial tires that have an asymmetrical tread pattern or studs only from front to rear, not from side to side. Tire performance will be weakened if rotated from side to side. (With limited-slip differential) Don't use the following: Tires not of the designated size...
Page 336 Mazda3_8U55-EA-05G_Edition1 Page336 Tuesday, May 31 2005 1:21 PM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) NOTE Tires degrade over time, even when they are not being used on the road. It is recommended that tires generally be replaced when they are 6 years or older. Heat caused by hot climates or frequent high loading conditions can accelerate the aging process.
Page 337: Vehicle Loading
Mazda3_8U55-EA-05G_Edition1 Page337 Tuesday, May 31 2005 1:21 PM NOTE This vehicle is not designed to tow a trailer. This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
Page 338 Mazda3_8U55-EA-05G_Edition1 Page338 Tuesday, May 31 2005 1:21 PM Black plate (338,1) Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Vehicle Curb Weight is the weight of your new vehicle when you picked it up from your dealer plus any aftermarket equipment. PAYLOAD Payload is the combined weight of cargo and passengers that the vehicle is designed to carry.
Page 339 Mazda3_8U55-EA-05G_Edition1 Page339 Tuesday, May 31 2005 1:21 PM SAMPLE Cargo Weight includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. The cargo weight limit decreases depending on the number of vehicle occupants.
Page 340 Mazda3_8U55-EA-05G_Edition1 Page340 Tuesday, May 31 2005 1:21 PM Black plate (340,1) Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Examples: Based on a single occupant weight of 68 kg, and a value of 385 kg for the combined weight of occupants and cargo should never exceed : The cargo weight limit with one occupant is 385 kg _ 68 kg = 317 kg The cargo weight limit with two occupants is 385 kg _ (68 ×...
Page 341 Mazda3_8U55-EA-05G_Edition1 Page341 Tuesday, May 31 2005 1:21 PM SAMPLE Exceeding Axle Weight Rating Limits: Exceeding the Safety Certification Label axle weight rating limits is dangerous and could result in death or serious injury as a result of substandard vehicle handling, performance, engine, transmission and/or structural damage, serious damage to the vehicle, or loss of control.
Page 342 Mazda3_8U55-EA-05G_Edition1 Page342 Tuesday, May 31 2005 1:21 PM Black plate (342,1) Customer Information and Reporting Safety Defects Tire Information (U.S.A.) GCW (Gross Combined Weight) is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) is the maximum allowable weight of the vehicle and the loaded trailer - including all cargo and passengers - that the vehicle can handle without risking damage.
Page 343 Mazda3_8U55-EA-05G_Edition1 Page343 Tuesday, May 31 2005 1:21 PM Exceeding GVWR or GAWR Specifications: Exceeding the GVWR or the GAWR specified on the certification label is dangerous. Exceeding any vehicle rating limitation could result in a serious accident, injury, or damage to the vehicle. Do not use replacement tires with lower load carrying capacities than the originals because they may lower the vehicle's GVWR and GAWR limitations.
Page 344: Steps For Determining The Correct Load Limit
Mazda3_8U55-EA-05G_Edition1 Page344 Tuesday, May 31 2005 1:21 PM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Steps for Determining the Correct Load Limit: Steps for Determining Correct Load Limit: (1) Locate the statement The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs on your vehicle's placard.
Page 345: Reporting Safety Defects
U.S. Department of Transportation. Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from the Hotline. NOTE If you live in the U.S.A., all correspondence to Mazda Motor Corporation should be forwarded to: Mazda North American Operations...
Page 346: Reporting Safety Defects (Canada)
Mazda3_8U55-EA-05G_Edition1 Page346 Tuesday, May 31 2005 1:21 PM Black plate (346,1) Customer Information and Reporting Safety Defects Reporting Safety Defects Reporting Safety Defects (Canada) Canadian customers who wish to report a safety-related defect to Transport Canada, Defect Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330 Sparks Street, Ottawa ON K1A 0N5.
Page 347: Service Publications
Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair. When requesting any of our publications through an Authorized Mazda Dealer, refer to the chart below. If they don't have what you need in stock, they can order it for you.
Page 348 Mazda3_8U55-EA-05G_Edition1 Page348 Tuesday, May 31 2005 1:21 PM Black plate (348,1) 9-44 Form No.8U55-EA-05G...
Page 349: Specifications
Mazda3_8U55-EA-05G_Edition1 Page349 Tuesday, May 31 2005 1:21 PM Specifications Technical information about your Mazda. Identification Numbers ... 10-2 Vehicle Information Labels ... 10-2 Specifications ... 10-4 Specifications ... 10-4 Form No.8U55-EA-05G Black plate (349,1) 10-1...
Page 350: Identification Numbers
Mazda3_8U55-EA-05G_Edition1 Page350 Tuesday, May 31 2005 1:21 PM Identification Numbers Vehicle Information Labels qVehicle Identification Number The vehicle identification number legally identifies your vehicle. The number is on a plate attached the cowl panel located on the left corner of the dashboard. This plate can easily be seen through the windshield.
Page 351 Mazda3_8U55-EA-05G_Edition1 Page351 Tuesday, May 31 2005 1:21 PM Black plate (351,1) Identification Numbers qEngine Number Forward 10-3 Form No.8U55-EA-05G...
Page 352: Specifications
Mazda3_8U55-EA-05G_Edition1 Page352 Tuesday, May 31 2005 1:21 PM Specifications qEngine Item Type Bore×Stroke 87.5 × 83.1 mm (3.44 × 3.27 in) Displacement 1,999 ml (1,999 cc, 121.9 cu in) Compression ratio qElectrical System Item Battery Alternator 2.0-liter engine Starter 2.3-liter engine Spark-plug number Spark-plug gap * ex factory...
Page 353 Mazda3_8U55-EA-05G_Edition1 Page353 Tuesday, May 31 2005 1:21 PM qCapacities (Approximate Quantities) Item With oil filter replacement Engine oil Without oil filter replacement With heater Coolant Without heater Manual transaxle oil 4-speed transaxle Automatic transaxle fluid 5-speed transaxle Fuel tank Check oil and fluid levels with dipsticks or reservoir gauges. qDimensions Item (STD)
Page 354 Mazda3_8U55-EA-05G_Edition1 Page354 Tuesday, May 31 2005 1:21 PM Specifications 2.3-liter engine Item GVWR (Gross Vehicle Weight Rating) GAWR (Gross Axle Weight Rating) 5 Door Item GVWR (Gross Vehicle Weight Rating) GAWR (Gross Axle Weight Rating) qAir Conditioner Gas complies with SAE J639 HFC134a (R-134a) qLight Bulbs Exterior light...
Page 355 NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer. Check the tire pressure label for tire size and inflation pressure.
Page 356 Mazda3_8U55-EA-05G_Edition1 Page356 Tuesday, May 31 2005 1:21 PM Black plate (356,1) 10-8 Form No.8U55-EA-05G...
Page 357: Index
Mazda3_8U55-EA-05G_Edition1 Page357 Tuesday, May 31 2005 1:21 PM Black plate (357,1) Index 11-1 Form No.8U55-EA-05G...
Page 358 Mazda3_8U55-EA-05G_Edition1 Page358 Tuesday, May 31 2005 1:21 PM Index Add-On Non-Genuine Parts and Accessories ... 9-16 Air Bag Systems ... 2-38 Air Filter ... 8-22 Ambient Temperature Display ... 6-46 Antenna ... 6-16 Anti-Lock Brake System (ABS) ... 5-6 Warning light ... 5-7 Appearance Care ...
Page 359 Mazda3_8U55-EA-05G_Edition1 Page359 Tuesday, May 31 2005 1:21 PM Customer Assistance ... 9-2 Dashboard Illumination ... 5-32 Daytime Running Lights ... 5-48 Defroster Rear window ... 5-54 Dimensions ... 10-5 Door Locks ... 3-6 Driving In Flooded Area ... 4-11 Driving Tips ... 4-7 Automatic transaxle ...
Page 360 Mazda3_8U55-EA-05G_Edition1 Page360 Tuesday, May 31 2005 1:21 PM Index Headlights Control ... 5-46 Flashing ... 5-48 High-low beam ... 5-48 Leveling ... 5-48 On reminder ... 5-48 Hood Release ... 3-20 Horn ... 5-55 Ignition Keys ... 3-2 Switch ... 5-2 Illuminated Entry System ...
Page 361 Mazda3_8U55-EA-05G_Edition1 Page361 Tuesday, May 31 2005 1:21 PM Odometer and Trip Meter ... 5-29 Outside Mirrors ... 3-28 Overhead Lights ... 6-43 Overheating ... 7-12 Overloading ... 4-11 Paint Damage ... 8-52 Parking Brake ... 5-5 Parking in an Emergency ... 7-2 Power Door Locks ...
Page 362 Mazda3_8U55-EA-05G_Edition1 Page362 Tuesday, May 31 2005 1:21 PM Index Tachometer ... 5-31 Temporary Spare Tire ... 8-33 Theft-Deterrent System ... 3-26 Tiedown Hook ... 7-20 Tire Information ... 9-21 Tire Pressure Monitoring System ... 5-22 System error activation ... 5-25 Tire pressure monitoring system warning light ...
Page 363: Navigation System
NAVIGATION SYSTEM...
Page 364 MAZDA3_Navi_EA.book Page 2 Monday, June 6, 2005 9:39 AM Contents, Accessories, and Laser Accessories Please contact an Authorized Mazda Dealer if you are missing any of the following accessories. ●Map Disc CAUTION: THIS PRODUCT IS A CLASS HOWEVER THIS PRODUCT USES A VISIBLE/ INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED.
Page 365 MAZDA3_Navi_EA.book Page 3 Monday, June 6, 2005 9:39 AM Product Accessories ...2 Laser Product ...2 Contents ...3 Safety Information...4 Introduction ...6 Names and Functions...8 Activation ...10 Screen names and functions ...12 Screen change ...14 ● Changing the Map Orientation/Scale ... 15 Destination Entry and Route Search ●...
Page 366: Safety Information
■ Read this owner’s manual for your Navigation System carefully before using the system. They contain instructions about how to use the system in a safe and effective manner. Mazda assumes no responsibility for any problems resulting from failure to observe the instructions given in this manual.
Page 367 This navigation system is designed use for exclusively in automobiles. This navigation system should only be installed in an automobile. Do not install it in a ship, aircraft, or any other vehicles except an automobile. Do not use it detached from the vehicle.
Page 368: Navigation System
If the system does not operate thereafter, consult an Expert repairer, we recommend an Authorized Mazda Dealer. This navigation system utilizes GPS* satellite signals, Speed sensor and Gyrosensor to track and display your vehicle’s current position, and to guide you from your starting point to your...
Page 369 MAZDA3_Navi_EA.book Page 7 Monday, June 6, 2005 9:39 AM...
Page 370: Names And Functions
MAZDA3_Navi_EA.book Page 8 Monday, June 6, 2005 9:39 AM Names and Functions Joystick ●Selects items ENTER by tilting it up, down, right, and left. ●Scrolls map. RET key Returns to the previous screen. VOICE key ●Initiates vocal guidance for route VOICE maneuvers.
Page 371 MAZDA3_Navi_EA.book Page 9 Monday, June 6, 2005 9:39 AM POS (Position) key Displays your current position. ENTER key ENTER ●Executes a selected item. ●Displays pop up menu. MENU key Displays menu. MENU page 13) ZOOM key Changes the map scale. ZOOM page 15) DIM key...
Page 372: Activation
1 hour. Wipe the condensation off the map disc with a soft cloth. If the unit does not operate correctly after 1 hour, consult an Authorized Mazda Dealer. [CAUTION] screen TILT TILT...
Page 373 MAZDA3_Navi_EA.book Page 11 Monday, June 6, 2005 9:39 AM Read CAUTION carefully, and select and press ENTER ●The Current Position screen appears. Note ●You can select the language by select selected language using Language Selection. ( ●The CAUTION screen remains on the display unless you select Removing the Map Disc When the ignition switch is in the ACC position and press Buttons on the screen...
Page 374: Screens During Route Guidance
MAZDA3_Navi_EA.book Page 12 Monday, June 6, 2005 9:39 AM Screen names and functions Screens Before Setting Route ENTER (9) (10) (1) Map Orientation control page 15) (2) GPS (Global Positioning System) marker page 47) (3) Clock Clock will be displayed when you set up Clock on Navigation Set Up On.
Page 375: Screen Adjustments And Settings
MAZDA3_Navi_EA.book Page 13 Monday, June 6, 2005 9:39 AM Menu appears when pressing Screen adjustments and settings Display Menu screen will be shown when you press Note Display Menu screen will be disappeared when they have been unused during a few seconds. ■...
Page 376: Screen Change
MAZDA3_Navi_EA.book Page 14 Monday, June 6, 2005 9:39 AM Screen change Current position map Shows the current position of your vehicle on the scale selected. Route and flags When the route has been set, the blue line represents the route and the following two flags appear on the map.
Page 377: Changing The Map Orientation/Scale
MAZDA3_Navi_EA.book Page 15 Monday, June 6, 2005 9:39 AM Changing the Map Orientation/Scale ■ Do not keep your eyes fixed on the monitor screen or operate the system while driving Do not change the settings and destination locations while driving. Minimize the time Warning spent viewing the monitor screen and listening to the voice guidance while driving.
Page 378: Destination Entry And Route Search
MAZDA3_Navi_EA.book Page 16 Monday, June 6, 2005 9:39 AM Destination Entry and Route Search ●You can set the destination using various methods provided by the system. Before Steps MENU Open the [DESTINATION ENTRY] Menu Change (Change Search Area) Open the [DESTINATION ENTRY] Menu Address...
Page 379 MAZDA3_Navi_EA.book Page 17 Monday, June 6, 2005 9:39 AM ● Warnings ● Select the desired Search Area : ID, OR, WA, : CA, NV : AZ, CO, MT, NM, UT, WY : IA, KS, MN, MO, ND, NE, SD : OK, TX : IL, IN, KY, MI, OH, WI rrowing Enter the...
Page 380: Point Of Interest
MAZDA3_Navi_EA.book Page 18 Monday, June 6, 2005 9:39 AM Destination Entry and Route Search Open the [DESTINATION ENTRY] Menu Point of interest Emergency Select When entering the destination point directly When narrowing down to category name Select When narrowing down to city name Select Select...
Page 381 MAZDA3_Navi_EA.book Page 19 Monday, June 6, 2005 9:39 AM t directly Select the category name from the list Cancel the ty name city selection. Displays 5 city name list nearest the current position. Displays the city name input screen. ays the police ays the tal select nearest police...
Page 382: Memory Point
MAZDA3_Navi_EA.book Page 20 Monday, June 6, 2005 9:39 AM Destination Entry and Route Search Before Steps MENU Open the [DESTINATION Memory Point ENTRY] Menu Home Preset Destination Previous Destination Intersection Freeway On/ Off Ramp Phone number Coordinates Select from select ENTER Select Select...
Page 383 MAZDA3_Navi_EA.book Page 21 Monday, June 6, 2005 9:39 AM Select the Select the desired Memory Point category for the : Display up to five previous suggestions. desired Memory : Display the five previous suggestions. Point : The order of the displayed list can be changed. Select the desired Preset Destination.
Page 384: Local Search
MAZDA3_Navi_EA.book Page 22 Monday, June 6, 2005 9:39 AM Use POI Before Steps ENTER Open the [QUICK POI] Displaying POI(s) on a Local Search Deleting Markers Displaying POI(s) on a Map ( Before Steps Display the POI. Showing POI Data ●You can select one of the six categories on the menu or List Categories and then select the POI(s)
Page 385: Phone Number
MAZDA3_Navi_EA.book Page 23 Monday, June 6, 2005 9:39 AM Character Entry Select the first several characters on the screen. Select To enter the street name, city name, and : Move the cursor to the previous other. position and delete a character. : The list appears.
Page 386: Direct Destination Input
MAZDA3_Navi_EA.book Page 24 Monday, June 6, 2005 9:39 AM Direct Destination Input Direct Destination Input Operate after Step 3 of [Direct Destination Input] Selecting Route Position the ENTER cursor on your destination on the map Scroll the map and change the map scale if necessary.
Page 387: Poi Icons On Maps / Delete Destination
MAZDA3_Navi_EA.book Page 25 Monday, June 6, 2005 9:39 AM POI Icons on Maps / Delete Destination ■ POI (Point of Interest) Icons The following are POI icons shown on maps. Restaurant Automotive All restaurants Automobile Club American Gas Station Chinese Parking Auto Service & Continental Maintenance...
Page 388: Route Options
MAZDA3_Navi_EA.book Page 26 Monday, June 6, 2005 9:39 AM Route Options Before Steps MENU Open the [ROUTE OPTIONS] Menu Search Condition Route Preferences ●During route guidance you can change the route options, stop or check the route. select ENTER Select Select...
Page 389 MAZDA3_Navi_EA.book Page 27 Monday, June 6, 2005 9:39 AM ■ Do not keep your eyes fixed on the monitor screen or operate the system while driving Do not change the settings and destination locations while driving. Minimize the time spent viewing the monitor screen and listening to the voice guidance while driving.
Page 390 MAZDA3_Navi_EA.book Page 28 Monday, June 6, 2005 9:39 AM Route Options Before Steps MENU Open the [ROUTE OPTIONS] Menu Addition of Way points Modification of Destination or Way Point Positions Modification of the Visiting Order Deletion of Destination or Way Points Deletion of Destination...
Page 391 MAZDA3_Navi_EA.book Page 29 Monday, June 6, 2005 9:39 AM Select erred method. stination), it will Select the button for the (Change location to be modified. Shows the map for the destination/way points. When the sequence has buttons for the in the order that been completed, the visiting order will be to cancel an...
Page 392 MAZDA3_Navi_EA.book Page 30 Monday, June 6, 2005 9:39 AM Route Options Before Steps MENU Open the [ROUTE Display OPTIONS] Menu Route Route Preview Setting the conditions simulation Recalculates the route Stops route guidance select ENTER Select Select Select Select The Entire R Enter the ma Use the butt : Enter...
Page 393 MAZDA3_Navi_EA.book Page 31 Monday, June 6, 2005 9:39 AM The Entire Route screen appears. Enter the map scroll. Use the buttons displayed on screen to carry out a simulation run. : Enter the map scroll. : Move the start point. : Carry out a simulation run in the direction of the start point.
Page 394: Address Book
MAZDA3_Navi_EA.book Page 32 Monday, June 6, 2005 9:39 AM Address Book Before Steps MENU Open the Memory Point [ADDRESS Storage BOOK] Memory Point Confirmation Modification Memory Point Deletion All Memory Point Deletion Category Name Modification ●You can, edit, or delete any destinations, way points, or marked point.
Page 395 MAZDA3_Navi_EA.book Page 33 Monday, June 6, 2005 9:39 AM list. Changes the selected category name Set a memory point using your preferred method. Select a memory : Allows the display icon to be point to be modified selected. Page 1 and 2 contain standard icons, whereas the With Sound page contains icons which also playback sounds.
Page 396 MAZDA3_Navi_EA.book Page 34 Monday, June 6, 2005 9:39 AM Address Book Before Steps MENU Open the Avoid Area [ADDRESS Storage BOOK] Avoid Area Confirmation Modification Avoid Area Deletion All Avoid Area Deletion Category Name Modification select ENTER Select...
Page 397 MAZDA3_Navi_EA.book Page 35 Monday, June 6, 2005 9:39 AM Select an avoid area using your preferred method. Select an avoid area to be modified. Select an avoid area to be deleted. Cancel the deletion. : Reduces the size of the avoid area.
Page 398 MAZDA3_Navi_EA.book Page 36 Monday, June 6, 2005 9:39 AM Address Book Before Steps MENU Open the Destination & [ADDRESS Way Points BOOK] Previous Destination Deletion All Previous Destination Deletion Preset Destination Storage Preset Destination Confirmation and Modification Preset Destination Deletion All Preset Destination Deletion Displays Icons...
Page 399 MAZDA3_Navi_EA.book Page 37 Monday, June 6, 2005 9:39 AM Select a destination to be deleted. : The order of the displayed list can be changed. : Cancel the deletion. Select a preset number. Select a preset number. Select a preset number to be deleted.
Page 400: Navigation Set Up
MAZDA3_Navi_EA.book Page 38 Monday, June 6, 2005 9:39 AM Navigation Set Up ●You can alter the map display conditions, the route guidance conditions and show the system information. ■ Stop your vehicle before the following operations. Do not change the settings and destination locations while driving. Minimize the time spent viewing the monitor screen and listening to the voice guidance while driving.
Page 401: User Setting
MAZDA3_Navi_EA.book Page 39 Monday, June 6, 2005 9:39 AM Navigation Set Up MENU ENTER Before Steps select ENTER ■ Open the [USER SETTINGS] screen ■ Select page ■ ■ ■ ■ How to exit User Setting select ENTER MAP Color Select a screen color from Map Mode ●...
Page 402 MAZDA3_Navi_EA.book Page 40 Monday, June 6, 2005 9:39 AM Navigation Set Up MENU Before Steps ENTER Open the [USER SETTINGS] screen Select page Select page ■ How to exit select ENTER select ■ Keyboard layout The layout of input keys can be selected as ■...
Page 403: Quick Poi Selection
MAZDA3_Navi_EA.book Page 41 Monday, June 6, 2005 9:39 AM Navigation Set Up This function allows you set the categories on the area displayed when the (Point of interest) menu is selected on the map. Quick POI enables you store up to six different kinds category which you use most regularly.
Page 404 MAZDA3_Navi_EA.book Page 42 Monday, June 6, 2005 9:39 AM Navigation Set Up This function allows you to correct any error in the position or direction of your vehicle display. Before Steps MENU Adjusting Current Position and Direction select ENTER Open the [Position calibration] screen Move and select Distance...
Page 405 MAZDA3_Navi_EA.book Page 43 Monday, June 6, 2005 9:39 AM ENTER Set Clock The current time is set using this function. Since time notification is provided by a GPS satellite, time-zone adjustment can be carried out automatically. select ENTER Open the [SET CLOCK] screen ou are heading, Map Version The map and software version numbers can be confirmed by using this...
Page 406: Restore System Defaults
MAZDA3_Navi_EA.book Page 44 Monday, June 6, 2005 9:39 AM Navigation Set Up This function replaces all the settings in the mobile navigation system with the initial default settings. MENU Before Steps ENTER Open the [SYSTEM DEFAULTS] screen If you execute Restore System Defaults, all of your Stored setting data will be deleted. [Default List] Item Menu names...
Page 407: Volume Adjustment
MAZDA3_Navi_EA.book Page 45 Monday, June 6, 2005 9:39 AM Navigation Set Up You can change the languege of the menu and the voice guidance. MENU Before Steps select ENTER Open the [LANGUAGE] screen Select your preferred language from the list. You can adjust the volume control for the voice guidance.
Page 408: Precautions/System Performance
MAZDA3_Navi_EA.book Page 46 Monday, June 6, 2005 9:39 AM Precautions/System Performance ● The navigation system is just a support system for the driver. The driver should always pay attention to the traffic situation to safely make decisions. You may be unable at times to arrive at your destination due to out-of-date information Warnings on a map disc.
Page 409: Map Matching
MAZDA3_Navi_EA.book Page 47 Monday, June 6, 2005 9:39 AM GPS is a position detecting system utilizing the signals from GPS satellites deployed by the U.S. Department of Defense. The Mobile Navigation System uses input from three or more satellites and calculates the vehicle position based on the principle of triangulation.
Page 410: Positioning Accuracy
MAZDA3_Navi_EA.book Page 48 Monday, June 6, 2005 9:39 AM Precautions/System Performance In the following situations, your vehicle position may not be displayed correctly on the map. But, as you keep driving, your vehicle position will be automatically corrected utilizing map matching and GPS data. Running on an Making a turn after elevated road...
Page 411: Route Search
MAZDA3_Navi_EA.book Page 49 Monday, June 6, 2005 9:39 AM The navigation system is just a support system for the driver. The driver should always pay attention to the traffic situation to safely make decisions. You may be unable to arrive at your destination due to out-of-date information on a map disc.
Page 412: Troubleshooting
There may be some problems due to operational errors or mistakes. Please read this manual again and verify that there really is a problem before calling an Expert repairer, we recommend an Authorized Mazda Repairer to ask for repair services. Symptom No picture Display doesn’t...
Page 413 MAZDA3_Navi_EA.book Page 51 Monday, June 6, 2005 9:39 AM Symptom No GPS ●GPS signals may not be received because of obstructions. symbols are After moving the vehicle away from obstructions, the GPS signals can be received. displayed The vehicle ●Check if the mode is set to the current position screen. position is not Press displayed...
Page 414: Error Messages
MAZDA3_Navi_EA.book Page 52 Monday, June 6, 2005 9:39 AM Troubleshooting Error message Please insert a MAP DVD. MAP DVD-Read Error The disc installed is not a MAP DVD. Error Messages Solution ●The disc is not installed. Check if the disk is installed. If installed, check if the installed disk is correct.
Page 415: Maintenance
Never use solvents such as benzene and thinners, they could mar the surface of the unit. ■ Map disc If you require the latest map disc, consult an Expert repairer, we recommend an Authorized Mazda Repairer. Handling and Care of Map Discs ■ How to hold the disc ●Do not touch the underside of the disc.
Page 416 MAZDA3_Navi_EA.book Page 54 Monday, June 6, 2005 9:39 AM...
