Series Ten
GAS WATER HEATER
USER'S GUIDE
FOR POTABLE WATER HEATING ONLY
NOT SUITABLE FOR SPACE HEATING
NOT FOR USE IN
MANUFACTURED (MOBILE) HOMES
C3 Technology
the new ANSI Z21.10.1 standard that deals
with the accidental or unintended ignition
of flammable vapors, such as those
emitted by gasoline.
PRINTED IN THE U.S.A 0405
®
Gas Water Heaters meet
1
Model Numbers
HRX40YARS
HRX40HARS
HRX40YART
HRX40HART
HRX40YQRT
HRX40HQRT
For Your Safety
AN ODORANT IS ADDED TO THE GAS USED
BY THIS WATER HEATER.
HRX50YART
HRX50HART
HRX50YQRT5
HRX50HQRT5
HRX50YQRT
HRX50HQRT
PART NO. 184388-002
66001907
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Maytag HRX40HARS
Summary of Contents for Maytag HRX40HARS
-
Page 1: For Your Safety
PRINTED IN THE U.S.A 0405 Gas Water Heaters meet HRX40YARS HRX40HARS HRX40YART HRX40HART HRX40YQRT HRX40HQRT AN ODORANT IS ADDED TO THE GAS USED Model Numbers... -
Page 2: Safe Installation, Use And Service
• Maytag Service Specialist: A Maytag Service Specialist has the equivalent to a licensed tradesman in the fields of plumbing, air supply, venting and gas supply, including a thorough understanding of the requirements of the National Fuel Gas Code as it relates to the installation of gas fired water heaters. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS... -
Page 4: Table Of Contents
Tools ... 6 INSTRUCTIONS FOR INSTALLATION ... Removing the Old Water Heater ... 7 TYPICAL INSTALLATION ... Get to Know Your Water Heater ... 8 Mixing Valve Usage ... 9 LOCATING THE NEW HEATER... Facts to Consider About the Location ... 10-11 Insulation blankets ... -
Page 5: Customer Responsibilities
Thank You for purchasing a Maytag water heater. Properly installed and maintained, it should give you years of trouble free service. It is strongly suggested that this new water heater be professionally installed, contact a Maytag Service Specialist at 1-800-365-0024 for recommended installers. -
Page 6: Accessories And Tools Needed
Accessories To simplify the installation Maytag has available the installation parts shown below. You may or may not need all of these accessories depending on your type of installation. Call a Maytag Service Specialist at 1-800-365-0024 for an authorized installer. -
Page 7: Instructions For Installation
6. If you have copper piping to the water heater, the two copper water pipes can be cut with a hacksaw approximately four inches away from where they connect to the water heater. -
Page 8: Typical Installation
GET TO KNOW YOUR WATER HEATER - GAS MODELS Vent Pipe Draft Hood Anode Hot Water Outlet Outlet Flexible Water Connections Gas Supply Manual Gas Shut-off Valve Ground Joint Union * INSTALL IN ACCORDANCE WITH LOCAL CODES. * DRIP LEG AS REQUIRED BY LOCAL CODES. -
Page 9: Mixing Valve Usage
Mixing valves are available at a plumbing supply distributor, see Figure 8. Valves for reducing point of use, temperature by mixing cold and hot water are also available. Consult a Maytag Service Specialist at 1-800-365-0024. Follow mixing valve manufacturer’s instructions for installation of the valves. Before changing the factory setting on the thermostat, read the “Temperature Regulation”... -
Page 10: Locating The New Heater
• Devices that will turn off the gas supply to a gas water heater while at the same time shutting off its water supply. -
Page 11: Insulation Blankets
Insulation Blankets Insulation blankets available to the general public for external use on gas water heaters are not necessary with Maytag products. The purpose of an insulation blanket is to reduce the standby heat loss encountered with storage tank heaters. Your... -
Page 12: In Unconfined Spaces
Combustion Air and Ventilation for Appliances Located in Unconfined Spaces UNCONFINED SPACE is space whose volume is not less than 50 cubic feet per 1,000 Btu per hour (4.8 m aggregate input rating of all appliances installed in that space. Rooms communicating directly with the space in which the appliances are installed, through openings not furnished with doors, are considered a part of the unconfined space. -
Page 13: Water Piping
Refer to the Thermal Expansion section under Troubleshooting Guide or contact local plumbing authority or call a Maytag Service Specialist at 1-800-365-0024 for an authorized installer on how to control this situation. -
Page 14: T & P And Pipe Insulation
It will harm the dip tube and damage the tank. • Look at the top cover of the water heater. The water outlet is marked “HOT”. Put two or three turns of teflon tape around the threaded end of the threaded-to-sweat coupling and around both ends of the 3/4”... -
Page 15: Filling The Water Heater
(150 psi = 1,035 kPa) and a discharge capacity not less than the water heater input rate as shown on the model rating plate. For safe operation of the water heater, the relief valve must not be removed from its designated opening nor plugged. -
Page 16: Venting
ANSI Z21.68 (ANSI Z21.66 & 67, respectively, cover electrically and mechanically actuated vent dampers). Before installation of any vent damper, consult your Maytag Customer Service Center or the local gas supplier for further information. To insure proper venting of this gas-fired water heater, the correct vent pipe diameter must be utilized. -
Page 17: Gas Piping
“OFF” until the water heater installation is complete. A gas line of sufficient size must be run to the water heater. Consult the current edition of National Fuel Gas Code ANSI Z223.1/NFPA 54 and your gas supplier concerning pipe size. -
Page 18: Sediment Trap
ANSI Z223.1/NFPA 54. A sediment trap shall be installed as close to the inlet of the water heater as practical at the time of water heater installation. The sediment trap shall be either a tee fitting with a capped nipple in the bottom outlet or other device recognized as an effective sediment trap. -
Page 19: Operating Instructions
D. Do not use this appliance if any part has been under water. Immediately contact a qualified installer or service agency to replace the flooded water heater. Do not attempt to repair the unit! It must be replaced! LIGHTING INSTRUCTIONS... -
Page 20: Temperature Regulation
Temperature Regulation Due to the nature of the typical gas water heater, the water temperature in certain situations may vary up to 30F° (16.7 C°) higher or lower at the point of use such as, bathtubs, showers, sink, etc. Any water heater’s intended purpose is to heat water. Hot water is needed for cleansing, cleaning, and sanitizing (bodies, dishes, clothing). -
Page 21: Service And Maintenance
DEATH, SERIOUS BODILY INJURY, OR PROPERTY DAMAGE. Contact the Maytag dealer from whom the appliance was purchased or call a Maytag Service Specialist at 1-800-365-0024 for an authorized servicer to replace a flooded water heater. -
Page 22: Housekeeping
You may have a check valve installed in the water line or a water meter with a check valve. Consult a Maytag Service Specialist at 1-800-365-0024 for further information. Do not plug the temperature-pressure relief valve. -
Page 23: Drain Valve Washer Replacement
Operational Conditions found in the Troubleshooting Guide of this manual. If a condition persists or you are uncertain about the operation of the water heater, let the Maytag Customer Service check it out. Call a Maytag Service Specialist at 1-800-365-0024 for an authorized servicer. -
Page 24: Smoke / Odor
Thermal expansion tanks are available for ordering through a Maytag Service Specialist at 1-800-365-0024. Contact the local plumbing inspector, water supplier and/or call a Maytag Service Specialist at 1-800-365-0024 for assistance in controlling these situations. -
Page 25: High Temperature Shut Off System
Turn “OFF” the entire gas supply to the water heater. The high temperature Shut-off is built into the gas control valve. It is non-resettable. If the high temperature shut-off activates, the gas control valve must be replaced. Call a Maytag Service Specialist at 1-800-365-0024 for an authorized servicer. -
Page 26: Troubleshooting Guide
TROUBLESHOOTING GUIDE These guidelines should be used by a qualified Maytag Service Specialist. Call a Maytag Service Specialist at 1-800-365-0024 for assistance. Inform the associate that this is a “Flammable Vapor Ignition Resistant” Product. Problem Cause Improperly sealed, hot or cold supply connection, relief valve, drain valve, or thermostat threads. -
Page 27: Repair Parts List
Includes Inner Door Gasket Now that you have purchased this gas water heater, should a need ever exist for repair parts or service, simply call a Maytag Service Specialist at 1-800-365-0024 for an authorized servicer. Be sure to provide all pertinent facts when you call or visit. - Page 28 Includes Inner Door Gasket Now that you have purchased this gas water heater, should a need ever exist for repair parts or service, simply call a Maytag Service Specialist at 1-800-365-0024 for an authorized servicer. Be sure to provide all pertinent facts when you call or visit.
-
Page 29: Repair Parts List
STATE/MAYTAG PART NUMBER CONVERSION KEY STATE MAYTAG STATE MAYTAG ETC2X 66001013 ETC5X 66001014 9000071 66001079 9000275 66001187 9000728 66001216 9000734 66001020 9001584 66001021 9001595 66001812 9001829 66001251 9001834 66001252 9002401 66001015 9002402 66001016 9002978 66001901 9003379 66001491 9003382 66001492 9003383... -
Page 30: Notes
NOTES... - Page 31 NOTES...
-
Page 32: Warranty
When contacting a Maytag Service Specialist be sure to provide the model and serial number of your appliance, the name and address of the dealer from whom you purchased the appliance and the date of purchase.
