Series Ten
ELECTRIC
WATER HEATER
USER'S GUIDE
GAMA certification applies to all residential
electric water heaters with capacities of 20 to
120 Gallons. Input rating of 12 Kw or less at a
voltage no greater than 250 V.
READ THE GENERAL SAFETY SECTION BEGINNING ON INSIDE
COVER AND THEN THIS ENTIRE MANUAL BEFORE INSTALLING OR
OPERATING THIS WATER HEATER.
Save this Manual for Future Reference.
Printed in the U.S.A. 0104
WARNING
Model Numbers
HRX30DERT
HRX40DERS
HRX40DERT
HRX52DERS
HRX52DERT
HRX66DERT
HRX82DERT
FOR POTABLE WATER
HEATING ONLY
NOT SUITABLE FOR
SPACE HEATING
Caution:
Read and Follow All
Safety Rules and
Operating Instructions
Before First Use of
This Product.
Part No. 184742-000
66001712
Advertisement
Table of Contents
Related Manuals for Maytag HRX30DERT
Summary of Contents for Maytag HRX30DERT
- Page 1 READ THE GENERAL SAFETY SECTION BEGINNING ON INSIDE COVER AND THEN THIS ENTIRE MANUAL BEFORE INSTALLING OR OPERATING THIS WATER HEATER. Save this Manual for Future Reference. Printed in the U.S.A. 0104 WARNING Model Numbers HRX30DERT HRX40DERS HRX40DERT HRX52DERS HRX52DERT HRX66DERT HRX82DERT...
-
Page 2: Safety Instructions
• DO obtain new warning and instruction labels from Maytag for placement on the blanket directly over the existing labels. WARNING Do not use this appliance if any part of it has been under water. -
Page 3: Safety Instructions
For this reason, it is not advisable to install the water heater in an attic or upper floor. When such locations cannot be avoided, a suitable drain pan should be installed under the water heater. -
Page 4: Table Of Contents
Accessories ... 7 Tools ... 7 Instructions for Installation Removing the Old Water Heater... 8 Locating the New Water Heater ... 9 Typical Installation... 9 Water Piping... 10 T&P Valve and Pipe Insulation ... 10 Temperature-Pressure Relief Valve ... 11 Filling the Water Heater... -
Page 5: Customer Information
Properly installed and maintained, it should give you years of trouble free service. It is strongly suggested that this new water heater be professionally installed, call a Maytag Service Specialist at 1-800-365-0024 for recommended installers. Abbreviations Found In This Instruction Manual U.L. -
Page 6: Product Specifications
* Standard element wattages are shown. Other element wattages (up to the maximum shown) are available when specified. ** Wiring size based on standard 60°C copper wire. If distance from fuse box to water heater is more than 90 feet, refer to your local electrical code. -
Page 7: Accessories And Tools Needed
Accessories and Tools Needed Accessories To simplify the installation Maytag has available the installa- tion parts shown below. You may or may not need all of these accessories depending on your type of installation. Call a Maytag Service Specialist at 1-800-365-0024 for an autho- rized installer. -
Page 8: Instructions For Installation
If you have copper piping to the water heater, the two copper water pipes can be cut with a hacksaw approxi- mately four inches away from where they connect to the water heater. -
Page 9: Locating The New Water Heater
Heater You should carefully choose an indoor location for the new water heater, because the placement is a very important con- sideration for the safety of the occupants in the building and for the most economical use of the appliance. This water heater is not intended for outdoor installation. -
Page 10: Water Piping
Contact the local utility or call a Maytag Service Specialist at 1-800-365-0024 for an authorized servicer on how to control this situation. -
Page 11: Temperature-Pressure Relief Valve
Your local jurisdictional authority, while mandating the use of a Temperature-Pressure Relief Valve complying with ANS Z21.22 and ASME, may require a valve model different from the one furnished with the water heater. Compliance with such local requirements must be satisfied by the installer or end user of the water heater with a locally prescribed Temperature-Pressure Relief Valve installed in the designated opening in the water heater. -
Page 12: Filling The Water Heater
Instructions for Installation (cont’d) Filling the Water Heater To fill the water heater with water: 1. Close the water heater drain valve by turning the handle to the right (clockwise). The drain valve is on the lower front of the water heater. -
Page 13: Wiring
If you are not familiar with electric codes and practices, or if you have any doubt in your ability to connect the wiring to this water heater, obtain the service of a competent electrician. Call a Maytag Service Specialist at 1-800-365-0024 for an authorized servicer. WARNING... -
Page 14: Installation Checklist
“Product Specifications” section? 3. Are the wires from the circuit breaker or fuse service to the water heater’s junction box on the correct wire size (gauge) as shown in the chart in the “Product Specifications” section? 4. Is the new temperature-pressure relief valve properly installed, and piped to an adequate drain? See “Temperature-Pressure Relief Valve”... -
Page 15: Service And Maintenance
Thermostats The thermostats of this water heater have been factory set at a position which approximates 120°F (HOT) to reduce the risk of scald injury. The upper and lower thermostats are factory set at a position which approximates 120°F ( HOT) and are adjustable if a dif-... -
Page 16: Thermostat Adjustments
To adjust the temperature setting for both upper and lower thermostats, proceed as follows: 1. Turn “OFF” the electric power to the water heater at the junction box. WARNING HAZARD OF ELECTRICAL SHOCK! Before removing... -
Page 17: Draining
5. OPEN the water heater drain valve to allow for tank draining. NOTE: If the water heater is going to be shut down and drained for an extended period, the drain valve should be left open with hose connected allowing water to termi- nate to an adequate drain. -
Page 18: Element Cleaning And Replacement
“OFF”. Failure to do this could result in DEATH, SERIOUS BODILY INJURY, OR PROPERTY DAMAGE. 2. Turn off the water supply to the water heater at the water shutoff valve or water meter. 3. Attach a hose to the water heater drain valve and put the other end in a floor drain or outdoors. - Page 19 11. Close the water heater drain valve by turning the handle to the right (clockwise). The drain valve is on the lower front of the water heater.
-
Page 20: Drain Valve Washer Replacement
Conditions” and “Operational Conditions” found in the “Troubleshooting” section of this manual. If a condition persists or you are uncertain about the opera- tion of the water heater, let a qualified person check it out. Call a Maytag Service Specialist at 1-800-365-0024. ″ x ″... -
Page 21: Troubleshooting
Expansion tanks are available for ordering through the Maytag Service Specialist. Contact the local water supplier and/or call a Maytag Service Specialist at 1-800-365-0024 for an authorized servicer for assistance in controlling these situations. -
Page 22: High Temperature Shut Off System
6. Replace the access panel. 7. Turn “ON” electric power to the water heater. CAUTION If the high limit must be reset again, call a Maytag Service Specialist at 1-800-365-0024 for an autho- rized servicer to find out why the high limit turned “OFF”... -
Page 23: Leakage Checkpoints
If you are not thoroughly familiar with electric codes, the water heater, and safety practices, contact your local utility or call a Maytag Service Specialist at 1-800-365-0024 for an authorized servicer to check the water heater. *Condensation may be seen on pipes in humid weather or pipe connections may be leaking. -
Page 24: Repair Parts List
Repair Parts List MAYTAG ELECTRIC WATER HEATERS MODEL NUMBERS HRX40DERS 40 GALLON HRX52DERS 50 GALLON NOTE: LOWER ELEMENT and UPPER ELEMENT: These water heaters have 5500 watt lower and upper elements as standard. Order part no. 9000396 replacement element. However, your specific model may be equipped with non- standard elements. - Page 25 Now that you have purchased this water heater, should a need ever exist for repair parts or service, simply call a Maytag Service Specialist at 1-800-365-0024 for an autho- rized servicer. Be sure to provide all pertinent facts when you call or visit.
- Page 26 Repair Parts List (cont’d) MAYTAG ELECTRIC WATER HEATERS MODEL NUMBERS HRX30DERT 30 GALLON HRX40DERT 40 GALLON HRX52DERT 50 GALLON HRX66DERT 66 GALLON HRX82DERT 80 GALLON NOTE: LOWER ELEMENT and UPPER ELEMENT: These water heaters have 5500 watt lower and upper elements as standard.
- Page 27 Now that you have purchased this water heater, should a need ever exist for repair parts or service, simply call a Maytag Service Specialist at 1-800-365-0024 for an autho- rized servicer. Be sure to provide all pertinent facts when you call or visit.
- Page 28 Repair Parts List (cont’d) MAYTAG ELECTRIC WATER HEATERS STATE / MAYTAG PART NUMBER CONVERSION KEY STATE MAYTAG 9000308 66001053 9000309 66001054 9000396 66001087 9000399 66001112 9000507 66001201 9000509 66001202 9000947 66001217 9001453 66001068 9001583 66001415 9001584 66001021 9001588 66001246 9001608...
- Page 29 Notes...
- Page 30 Notes...
- Page 31 Notes...
-
Page 32: Warranty
To locate an authorized service company in your area contact the Maytag Contractor Dealer from whom your appli- ance was purchased; or call a Maytag Service Specialist at the number listed below. Should you not receive satisfacto- ry warranty service, please call or write: When contacting a Maytag Service Specialist be sure to provide the Model and Serial Number of your appliance, The Name and Address of the Contractor Dealer from whom you purchased the appliance and the Date of Purchase.
