Maytag Agility User Manual

Maytag agility deep cleaner user guide.
Hide thumbs

Advertisement

*
*
Deep Cleaner
Your AGILITY™ Deep
Cleaner is fully assembled
and
ready to begin cleaning!
www.maytag.co.uk

Advertisement

Table of Contents

   Related Manuals for Maytag Agility

   Summary of Contents for Maytag Agility

  • Page 1 ™ Deep Cleaner Your AGILITY™ Deep Cleaner is fully assembled ready to begin cleaning! www.maytag.co.uk...
  • Page 2: Important Safeguards

    • Store in a dry place. Do not expose machine to freezing temperatures. Save these instructions! To contact us: • www.maytag.co.uk • 01737 231000 - our Consumer Response Centre (9 AM to 5 PM Monday - Friday) • ukservice@maytag.com...
  • Page 3: Table Of Contents

    Fill in and Save For your records, enter the model number and serial numbers in the spaces provided. These numbers are located on the data label on the underside of the cleaner. Model No. ____________________________ Serial No. _____________________________ Save your sales receipt and attach it to this manual.
  • Page 4: Deep Cleaner

    Cleaner Description Your AGILITY™ Deep Cleaner is fully assembled and ready to begin cleaning! Unfold handle Raise upper handle (A) to upright position until it locks in place. Features Hand grip Solution trigger: press to release cleaning solution Clean Surge™ button...
  • Page 5: Deep Cleaner Basics

    Carpet caps Upholstery NOTE: For best results, use only MAYTAG detergents. They are specifically formulated for use with your AGILITY™ Deep Cleaner. Pour detergent into tank Fill tank to fill line (C) (approx. 4 litres) with hot tap water (Fig.
  • Page 6: Emptying The Recovery Tank

    Empty the recovery tank Unplug deep cleaner from electrical source. An automatic shut-off device prevents the cleaner from picking up more dirty water than it can hold in the recovery tank. You will know the tank needs to be emptied -- •...
  • Page 7: Attaching The Hose

    Attach the hose Unplug deep cleaner from electrical source. Place handle in upright position. The hose and tool caddy can be removed from the cleaner if you desire. Remove hose from tool caddy. Open hose door (A) on back of deep cleaner (Fig. 13). Align hose connector with hose and solution ports (C) (Fig.
  • Page 8: Draining & Storing Hose

    The handle must be in the upright position in order to get cleaning solution through the hose. Drain the hose When finished using the hose and tool, remove water from the hose. Turn deep cleaner on and hold end of hose up for several seconds (A).
  • Page 9 Hose caddy You can either store the hose caddy on the cleaner or remove it to store separately. To store caddy on the cleaner: Slide tabs (G) on caddy into slots on back of cleaner (Fig. 25). Hook top of caddy to cleaner (H). Wrap cable around cable hooks (I) on caddy (Fig.
  • Page 10: Cleaning Carpet

    Wait ten minutes. Blot with white cloth or paper towel and check for color transfer. Pretreat spots, stains and high traffic areas with MAYTAG Spot and Stain Spray (Fig. 32). Spray spot or area with Spot and Stain Spray. Then proceed with the next cleaning steps.
  • Page 11: Cleaning Upholstery

    Spray spot or area with Spot and Stain Spray. Then proceed with the next cleaning steps. Fill solution tank with hot tap water and proper amount of MAYTAG deter- gent (see page 5)(Fig. 38). Use only MAYTAG brand detergents in your deep cleaner. Other brands may damage the deep cleaner.
  • Page 12 Routine care for your Deep Cleaner Clean the nozzle Unplug deep cleaner from electrical source. Remove solution and recovery tanks to prevent possible leaks. Lift up on top of nozzle (A) and slide off cleaner (Fig. 41). Wipe debris off nozzle and front of cleaner with a damp cloth. Tilt cleaner back, raising front of cleaner off floor.
  • Page 13 Storing your Deep Cleaner Empty solution tank and rinse thoroughly. Place empty solution tank on deep cleaner. Turn deep cleaner ON. Squeeze trigger and push deep cleaner forward and back several times. This will clear any solution remaining inside the cleaner.
  • Page 14: Troubleshooting

    IMPORTANT Cord Replacement This MAYTAG appliance is supplied complete with a plug. If the main cord of this appliance is damaged, the appliance must be repaired by an Authorised Maytag Repairer to avoid safety hazard. Guarantee The 2 year guarantee on your AGILITY™ Deep Cleaner becomes effective from your date of purchase. We suggest you record the model and serial number from the information plate on your AGILITY™...
  • Page 16: Basic Steps For Cleaning

    Vacuum carpet thoroughly to remove loose dirt. Test detergent for colorfastness on a hidden area of carpet or upholstery. Pretreat spots, stains and high traffic areas with MAYTAG Spot and Stain Spray. Blot spots or stains to remove as much of the spot as possible.
