- Page 1 Use & Care Guide Dishwasher MAYTAG MSE 860 FARS...
-
Page 2: Quick Guide
Remove large food particles and debris. There is no need to rinse thanks to the Super Cleaning System ™ 2. Dispensing dishwasher detergent The detergent compartment has a small compartment for pre-wash and one for main wash. 3. Ensure that the spray arms can rotate freely 4. -
Page 3: Table Of Contents
General Winter storage/Transport Overfill protection Cleaning Packaging materials Scrapping Child safety Child-safe button lock Child-safe dishwashing Protect your children! Dishwasher detergent is corrosive Parts of the dishwasher Technical information Baskets Control panel Dispenser Basic Course Load the baskets correctly Dispensing dishwasher detergent... - Page 4 C. Adjusting machines with adjustable foot Adjusting the plinth (Only if you have a kick-plate as an accessory) Screw the dishwasher into place Fitting strip seal (on floor plinth covering plate) NB! Not all models Setting water hardness Setting water hardness Service &...
-
Page 5: Before Doing Your First Wash
Check the door Check that the door of the dishwasher fits properly: open the door a little and let it go. Does it stay exactly where you released it? If not, you should check the installation instructions or consult the installer. -
Page 6: Safety
• Installation of water, drainage and elec- tricity must be carried out by a qualified professional. • Do not use the dishwasher for any pur- poses other than those stated in these directions for use. • Do not load the dishwasher door or the dishwasher baskets with anything other than dishes. -
Page 7: Child Safety
To prevent children starting the machine, you can activate a button lock. Proceed as follows: 1. Switch off the dishwasher with the main switch. 2. Press and hold the Temperature button, and at the same time switch on the main switch. -
Page 8: Parts Of The Dishwasher
Parts of the dishwasher* 1. Knife basket (*Not all models) 2. Upper basket 3. Lamp 4. Spray arms 5. Lower basket 6. Cutlery basket 7. Rinse Aid Filling 8. Dishwasher detergent compartment 9. Main switch 10. Program panel 11. Filter 12. -
Page 9: Baskets
Baskets* Upper basket Lower basket Cutlery basket Knife basket ( *Not all models ) 1. Wine glass shelf 2. Folding glass support 3. Divided cup shelves 4. Knife stop (* Not all models ) 5. Folding plate stand 6. Cutlery basket with door and folding handle *Details may differ depending on the model and market! -
Page 10: Control Panel
Control panel Prog Prog 1. Program selector 2. Display window 3. Temperature button Dispenser 4. Start/stop 5. Drying button 1. Compartment for main wash dish- washer detergent 2. Compartment for pre-wash detergent 3. Inspection window for rinse aid (not all models) 4. -
Page 11: Basic Course
Follow the dosage instructions on the deter- gent package. If your machine is fitted with a water softener, dispense as for soft water. Pour the dishwasher detergent into the dish- washer detergent compartment. There is one compartment for pre-wash and one for main wash, see Dispenser. - Page 12 Select a programme by pressing the pro- gramme selector one or more times until the required programme is displayed. Auto wash The dishwasher detects how soiled the dishes are and adjusts water consumption and temperature accordingly. Heavy wash The Heavy Wash programme should be used for heavily soiled dishes, e.g.
-
Page 13: Options
Options Select options To select an option, press one of the option buttons Drying You can select different drying time lengths depending on how dry you want your dishes to be when the machine has finished. The tem- perature can be selected in all programmes except Auto wash, Rinse &... -
Page 14: Eco-Dishwashing
Do not rinse before dishwashing Thanks to the dishwasher’s Super Cleaning System™ you do not need to rinse the dishes under running water before loading them into the machine. -
Page 15: Settings
Specialsettings Language, Child lock, Buzzer volume, Water hardness, Temperature unit, Machine information, Reset machine to the original settings You will probably only need to adjust these settings when the machine is new. To get to the Specialsettings 1. Turn the machine off with the main power button. -
Page 16: Press Start
Press Start/Stop and close the door The dishwasher will now start. It manages the entire wash automatically. Ensure that the door is properly closed or the machine will not start. Changing options If you want to change program after having started the machine, press the Start/Stop button for three seconds. -
Page 17: Fragile Dishes
Certain types of adhesive cannot withstand machine washing. In such cases the handles can come loose. Wood Wooden articles should only be machine washed if they are labelled as dishwasher proof. Aluminium Aluminium can be dulled by machine wash- ing. However, good quality aluminium... -
Page 18: Standard Program
Standard program Program Press Auto Program wash Options How the machine works Temperature 40-60°C Pre-wash with SCS* (number) Main wash (number) Rinse & Dry (number) Final rinse 60°C Consumption values Wash time 75-150 (approx. min)** Energy 0,7-1,0 (approx. kWh) Wash time 90-175 (approx. - Page 19 Standard program Program Press Upper Program basket wash Options How the machine works 55˚C Temperature Pre-wash with SCS* (number) Main wash (number) Rinse & Dry (number) Final rinse 60˚C Consumption values 1. Wash time (approx. min)** 1. Energy (approx. kWh) 2.
-
Page 20: The Display
The display When you have selected programme and option, the display shows the length of time the programme took the last time it was used. When you have started the machine, the display window shows how much of the programme time remains. This time can vary a little from one occasion to another depending on the temperature of the inlet water, the amount of dishes, the... -
Page 21: Cleaning
However, if you have calciferous (hard) water, lime deposits can form in the dishwasher. In this case, run a normal wash program with two tablespoons of citric acid in the dishwasher detergent compartment. -
Page 22: Spray Arms
CAUTION! Do not use a spray bottle or similar around the door catch. Tip! In order to prevent bad odours in the dishwasher, clean the strips and corners with a dish brush and low-lather detergent. -
Page 23: Rinse Aid
Rinse aid Pour in rinse aid Drying proceeds more quickly if you use rinse aid. Machines with indicator on the panel When the rinse aid has run out and more is needed, the rinse aid symbol on the panel lights up*. To fill with rinse aid: 1. -
Page 24: Salt
Use coarse salt or spe- cial salt for dishwashers. It is best to fill with salt when you are about to do a wash, as the dishwasher needs to be rinsed out immediately after filling. Proceed as follows the first time: 1. -
Page 25: Fault Indications
Fault indications Display Type of fault Overfilling Too much water in the machine Water inlet fault Fault in the water inlet Inlet valve leakage Inlet valve leakage Drainage fault Blocked drain Blocked filter Clogged filter To remove the fault indications from the display, turn off the main switch and then turn it back on again. -
Page 26: Troubleshooting
The dishes are not clean. Stains or a film on the china. Possible causes • The spray arms are not rotating. • Old dishwasher detergent. NB! Detergent is a perishable. • Incorrect dosage of detergent. • Insufficiently powerful dishwashing program. -
Page 27: The China Has A Whitish-Blue Sticky Film
(1 part rinse aid, 1 part water). • Rinse off food residue of this type if you do not intend to start the dishwasher immediately. • Seperate your cutlery into the varians compartments in the basket. Make sure silver and stainless steel are not together. -
Page 28: Water Remains In The Machine
Problems Water remains in the machine. Bad odour in the machine The dishes are not sufficiently dry Possible causes pump) can be heard from the machine, this does not stop when the power is switched off using the main power switch. •... -
Page 29: Performance Information
Main wash 25 gram Standard detergent. Rinse aid dosage 3. Energy labelling Europe: Dishwasher program: Normal wash 55°C, economy drying Program time: Connection: Test method noise measurement: Example of dishwasher loading EN 50 242 Technical information Height: Width: Weight: Capacity: Water pressure: Connection: Output: *The weight can vary due to varying specifications. -
Page 30: Installation
Installation Suggestions on positioning the dishwasher The dishwasher can be built in, fully free- standing or semi-freestanding. CAUTION! Connection to electricity, water and drain- age must be carried out by a suitably quali- fied person. A. Built-in The dishwasher can be built in under a worktop with a working height of 820 - 870 mm. -
Page 31: Connection To Electricity
Connection to electricity A dishwasher fitted with a lead and plug must be connected to an earthed socket. Repairs and maintenance relating to safety or performance must be carried out by a qualified professional. -
Page 32: Positioning The Machine
Positioning the machine A. Adjusting machines with six feet (freestanding dishwasher) 1. Adjust the height of the dishwasher with the four steel feet. 2. Lock the feet with the nuts. NB! The dishwasher must not be allowed to lean more than 5 mm. -
Page 33: Adjusting The Plinth
Adjusting the plinth (Only if you have kick-plate as accessory) The dishwasher has two kick-plates (certain models). The taller one should be used if the machine is to be 850 - 870 mm high and the plinth depth can be varied between 45 - 105 mm. -
Page 34: Setting Water Hardness
Setting water hardness Setting water hardness (machines with water softener) Before starting to use the dishwasher, you should set the correct water hardness. Phone your local water board to ascertain the water hardness in your area. The machine is set for low water hardness on delivery. -
Page 35: Service & Guarantee
Service & guarantee Service Before calling for service, check to see whether the faults is due to something that you can put right yourself. See Trouble shooting pages 26-28. Guarantee For guarantee details, see the guarantee card. -
Page 36: Own Comments
Own comments... - Page 37 Own comments...
- Page 38 Own comments...
-
Page 39: Search Words
Cleaning 6, 21 Connection 19, 29, 31 Control panel 10 Crystal 3, 5, 17, 26 Cutlery basket 8, 9, 11 Dishwasher detergent 3, 6, 7, 11, 24 Door 5, 16 Drainage 21, 28, 31 Efter disken 16 Environment 3, 11, 14, 40... - Page 40 Art. No: 80 785 79. Rev. 03 • We reserve the right to make changes. Printed on environmentally-friendly paper which meets the demands of Friends of the Earth and the Swedish Society for Nature Conservation.
