ELECTRIC DRYER INSTALLATION INSTRUCTIONS
TABLE OF CONTENTS ..................................................................1
DRYER SAFETY..............................................................................1
INSTALLATION REQUIREMENTS ................................................2
Tools and Parts ............................................................................2
Optional Equipment .....................................................................2
Location Requirements................................................................3
ELECTRIC DRYER POWER HOOKUP .........................................4
Electrical Requirements ...............................................................4
Electrical Connection ...................................................................5
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
DANGER
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
W10267633A
U.S.A. ONLY
Para una version de estas instrucciones en español, visite www.Whirlpool.com
TABLE OF CONTENTS
DRYER SAFETY
Your safety and the safety of others are very important.
VENTING........................................................................................10
Venting Requirements................................................................10
Plan Vent System .......................................................................11
Install Vent System.....................................................................12
INSTALL LEVELING LEGS...........................................................12
CONNECT VENT...........................................................................12
CONNECT INLET HOSE (STEAM MODELS)..............................13
LEVEL DRYER ..............................................................................13
COMPLETE INSTALLATION .......................................................13
Reverse Door Swing...................................................................14
TROUBLESHOOTING .................................................................15
Dryer Operation ..........................................................................15
Dryer Results ..............................................................................16
You can be killed or seriously injured if you don't immediately
follow instructions.
You
can be killed or seriously injured if you don't follow
instructions.
