Magnavox 30MW5405/17 User Manual

Magnavox user manual color television 30mw5405/17.


U
M
SER
ANUAL
Color Television
30MW5405/17
Thank you for choosing Magnavox.
Need help fast?
Read your Quick Use Guide and/or User Manual first for
quick tips that make your using your Magnavox product
more enjoyable. If you have read your instructions and still
need assistance you may access or our online help at
www.magnavox.com
or
call 1-800-705-2000
while with your product.
3141 095 20371
Next page ->

Summary of Contents

  • Page 1

    Need help fast? Read your Quick Use Guide and/or User Manual first for quick tips that make your using your Magnavox product more enjoyable. If you have read your instructions and still need assistance you may access or our online help at www.magnavox.com...

  • Page 2

    Return your Warranty Registration card today to ensure you receive all the benefits you’re entitled to. Once your MAGNAVOX purchase is registered, you’re eligible to receive all the privileges of owning a MAGNAVOX product. So complete and return the Warranty Registration Card enclosed with your pur- chase at once.

  • Page 3

    IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions.

  • Page 4: Table Of Contents

    ANEL MODEL PANEL PANEL REGISTRATION Side 1 INFORMATION SAFETY PANEL PANEL INFO PANEL PANEL PANEL PANEL PANEL Side 2 PANEL PANEL LIMITED WARRANTY (Panel 38) Index Panel PANEL PANEL Sequence Panel ANEL Subject Panel No. Alternate Channel ....29 Audio/Video Connections Rear Audio/Video Input Jacks .

  • Page 5

    ASIC combination antenna receives normal broadcast channels (VHF 2–13 and UHF 14–69).Your connection is easy because there is only one 75Ω (ohm) antenna plug on the back of your TV, and that’s where the antenna goes. If your antenna has a round cable (75 ohm) on the end, then you're ready to connect it to the If your antenna has a flat,...

  • Page 6

    ABLE f your cable signal uses a cable box or decoder, follow the easy steps below to com- plete the connection. Cable Box (w/RF In/Outputs): This connection will be mono. Connect the Cable Company sup- plied cable to the signal IN(put) plug on the back of the Cable Box.

  • Page 7

    ASIC ELEVISION Press the POWER button to turn the TV ON. Note:You can also press any but- ton on the top of the TV to turn the TV ON. Press the VOLUME + button to increase the sound level, or the VOLUME –...

  • Page 8

    (CD, DVD, etc.) inserted, press the PLAY button to view the tape on the television. ELPFUL Audio and video cables are not supplied with the TV, but are avail- able from Magnavox or electronics retailers. AV2 I N OR NPUT ACKS...

  • Page 9

    AV1 in VIDEO L/Mono AUDIO COMPONENT VIDEO INPUT Audio Cable (Red and White) S-Video Cable VIDEO S-VIDEO ANT/CABLE AUDIO OUT Back of VCR VCR (Equipped with S-Video Jacks) POWER A/CH STATUS EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX S-VIDEO...

  • Page 10

    Y indicates the luminance signal. Refer to your DVD or digital accessory owner’s manual for definitions and connection details. Note: Cables are not supplied with the TV, but are available from Magnavox or electronics retailers. ACKS S-VIDEO Audio...

  • Page 11

    TV screen. ELPFUL Audio and video cables are not sup- plied with the TV, but are available from Magnavox or electronics retailers. ONITOR ACKS Jack Panel Located on the back of the TV Monitor out...

  • Page 12

    Optional Audio Cables Headphones (red & white) POWER AUDIO RIGHT LEFT Jack Panel of A/CH Accessory STATUS Device EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX Jack Panel located on the Side of TV Video Cable (yellow) VIDEO S-VIDEO...

  • Page 13

    TV models. This TV does not contain the SmartSurf features, so therefore the button will have no func- tionality when pressed. Continued on Next Panel EMOTE ONTROL UTTONS A/CH STATUS EXIT MENU SLEEP SURF SMART PICTURE MAGNAVOX POWER MUTE SOUND...

  • Page 14

    STATUS EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX UTTONS (C EMOTE ONTROL POWER button Press to turn the TV on or off. CH(annel) +/– Buttons Press to scan memorized channels. VOL(ume) +/– Buttons Press to increase or decrease the sound.

  • Page 15: Language Control

    TV’s on-screen MENU items appear in English or Spanish text. It does not change the other on- screen text features such as Closed Caption (CC) TV shows. ANGUAGE ONTROL POWER A/CH STATUS EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX...

  • Page 16: Tuner Mode

    Channel Edit STATUS EXIT MENU SLEEP MUTE SURF SMART Install Language PICTURE SOUND Tuner Mode Auto Program Channel Edit MAGNAVOX Install Language Tuner Mode Auto Program Channel Edit Language Tuner Mode Auto Program Channel Edit English Antenna English Cable English...

  • Page 17

    MUTE Auto Program SURF SMART Channel PICTURE SOUND Auto Program Channel MAGNAVOX Auto Program Channel ELPFUL When CABLE is selected, channels 1-125 are available. When ANTENNA is selected, chan- nels 2-69 are available. When AUTO is selected, the TV will automatically set itself to the...

  • Page 18: Channel Edit

    MENU SLEEP MUTE Channel Edit SURF SMART Channel Skipped PICTURE SOUND MAGNAVOX Channel Edit Channel Skipped Channel Edit Channel Skipped ELPFUL An “X” appearing in front of any channel will indicate that channel has skip on.When the CH + or CH - buttons are used, those channels will be skipped.

  • Page 19: Picture Menu Controls

    OW TO SE THE o adjust your TV picture controls, select a channel and use the Picture Menu Controls listed below: Brightness: Press the CURSOR RIGHT 3 3 or LEFT 2 2 buttons until the darkest parts of the picture are as bright as you prefer.

  • Page 20

    OW TO SE THE o adjust your TV sound, select and use the Sound Menu Controls listed below: Treble Boost: Press the Éor Ñ buttons to turn the control On or Off.When On, the control will enhance the high frequency sounds. Bass Boost: Press the Éor Ñ...

  • Page 21

    NOTE : "Nudge" works when appear on the TV screen. SE THE ORMAT ONTROL Zoom 14:9 POWER A/CH STATUS EXIT Zoom 16:9 MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX Subtitle Zoom Super Zoom Widescreen...

  • Page 22

    Activate STATUS Display EXIT MENU SLEEP MUTE Timer SURF SMART Time PICTURE SOUND Start Time Stop Time Channel Activate Display MAGNAVOX ELPFUL INTS Remember, be sure to press “0” and then the hour number for single digit entries. --:-- AM...

  • Page 23

    Activate Display EXIT MENU SLEEP MUTE SURF SMART Timer PICTURE SOUND Time Start Time Stop Time Channel Activate Display MAGNAVOX Timer Time Start Time Stop Time Channel Activate Display Activate Activate Timer Time Start Time Stop Time Channel Activate Display Display ’...

  • Page 24

    NDERSTANDING THE he AutoLock™ feature is an integrated cir- cuit that receives and processes data sent by broadcasters, or other program providers, that contain program content advisories.When pro- grammed by the viewer, a TV with Autolock™ can respond to the content advisories and block program content that may be found objection- able (such as offensive language, violence, sexual situations, etc.).This is a great feature to censor...

  • Page 25: Access Code

    Block All Movie Rating TV Rating POWER A/CH STATUS EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX Timer Start Time Stop Time Channel Activate Display Access Code XXXX New Code - - - - OffStop Time Channel Activate Display...

  • Page 26: Block Channels

    Enter your Access Code to Channel 12 Blocked By SmartLock view a tuned Channel Blocking channel that is Access Code blocked with - - - - Block Channel. POWER A/CH STATUS EXIT MENU MUTE SLEEP SURF SMART PICTURE SOUND MAGNAVOX...

  • Page 27: Clear All Blocked Channels

    ?Stop Time Block All Channel Movie Rating Activate TV Rating Display Clear All Cleared AutoLock Block Channel Setup Code Clear All Block All Movie Rating TV Rating Block All POWER A/CH STATUS EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX...

  • Page 28

    ASED ON OVIE AutoLock Block Channel Setup Code Clear All PG-13 Block All Movie Rating NC-17 TV Rating Movie Rating PG-13 NC-17 but- POWER A/CH STATUS EXIT MENU MUTE SLEEP SURF SMART PICTURE SOUND MAGNAVOX ATINGS...

  • Page 29: Tv Ratings

    TV-MA TV-Y Block All, FV TV-Y7 TV-G Block All, V, S, L, D TV-PG Block All, V, S, L, D TV-14 Block All, V, S, L TV-MA POWER A/CH STATUS EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX ATINGS...

  • Page 30

    LEFT 2 2 buttons on the remote. ™ B LOCKING PTIONS AutoLock Setup Code Clear All Block All Movie Rating TV Rating Block Options Blocking Unrated No Rating POWER A/CH STATUS EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX...

  • Page 31: Sleeptimer

    ONTROLS CC Off CC Off POWER A/CH STATUS CC Mute EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX LEEPTIMER ONTROL Sleep off Sleep 15 Sleep 30 POWER Sleep 45 Sleep 60 A/CH Sleep 90 STATUS EXIT Sleep 120 MENU...

  • Page 32

    WEAK SIGNAL - Preset pic- PICTURE SOUND ture options for watching pro- grams where the reception is not at its best. MULTIMEDIA - Preset picture options for use with video gaming. MAGNAVOX ™ C OUND ONTROL Personal Theatre Music Voice...

  • Page 33: Alternate Channel

    Press the A/CH button on the remote control.The channels will toggle between the current channel and the last viewed channel. HANNEL POWER A/CH STATUS EXIT MENU SLEEP MUTE SURF SMART PICTURE SOUND MAGNAVOX...

  • Page 34: Troubleshooting

    ROUBLESHOOTING No Power •Check the TV power cord. Unplug the TV, wait 10 seconds, then reinsert the plug into the outlet and push the POWER button again. •Check that the outlet is not on a wall switch. •Be sure the fuse is not blown on the AC power strip, if one is being used.

  • Page 35

    ARE AND WARNING Concerning Stationary Images on the TV Screen: Do not leave stationary or letterbox images on screen for extended peri- ods of time. This can cause uneven picture-tube aging. Normal use of the TV should involve the showing of pictures that contain constantly moving and changing images that fill the screen.

  • Page 36

    Magnavox. • A product that requires modification or This warranty gives you specific legal rights. You may have other rights which vary from state/province to Magnavox, P.O. Box 520890, Miami, FL 33152 (402) 536-4171 IMITED ARRANTY adaptation to enable it to operate in any...
