HOT WATER
GENERATOR
INSTALLATION and OPERATION
MANUAL
Unit shown with optional control package.
The information contained in this
WARNING
manual is intended for use by
qualified professional installers, or
service technicians. Consult your
local expert for proper installation
or service procedures.
Save this manual for future reference.
Advertisement
Table of Contents
Related Manuals for Lochinvar Hot Water Generator
Summary of Contents for Lochinvar Hot Water Generator
- Page 1 HOT WATER GENERATOR INSTALLATION and OPERATION MANUAL Unit shown with optional control package. The information contained in this WARNING manual is intended for use by qualified professional installers, or service technicians. Consult your local expert for proper installation or service procedures. Save this manual for future reference.
-
Page 2: Table Of Contents
CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, if not CAUTION avoided, may result in property damage. NOTICE indicates special instructions on installation, operation, or maintenance that are important NOTICE but not related to personal injury or property damage. Hot Water Generator Installation and Operation Manual... -
Page 3: General Information
Lochinvar for clarification before proceeding. These Hot Water Generator Systems are designed for indoor use only, unless otherwise required by design specifications. Each unit requires at least two feet of clearance around and above the unit. -
Page 4: Optional Control Packages
Options: • Manual Reset High Limit • Solenoid Valve • Manway (see notes on manway) • 150 psi Tank Working Pressure • Temperature & Pressure Gauge • Vacuum Breaker Hot Water Generator Installation and Operation Manual (see page 5) - Page 5 All precautions contained in the warnings should be carefully followed to reduce the chance of injury. Hot Water Generator Installation and Operation Manual (continued) WARNING WARNING Steam or boiler water present situations WARNING...
-
Page 6: Installation
Transporting and unpacking the unit Each Lochinvar Hot Water Generator is crated as necessary at the factory. The crating is designed to provide protection for the unit during transportation, and to provide a safe means by which to lift and move the unit with a fork lift or hand truck. -
Page 7: Examining The Unit
Unit and components Lochinvar Hot Water Generators are designed to make installation a relatively simple procedure. Because the unit is “Packaged”, after placing and mounting the unit, installation involves the following: •... - Page 8 Piping the relief valves to drain All Lochinvar Hot Water Generators are equipped with a pressure relief valve for the tank. The valve should be piped to a vent line leading to a suitable drain. Piping the pressure...
-
Page 9: Completing Installation
Hot Water Generator Installation and Operation Manual Completing installation Installation of the Lochinvar Hot Water Generator is now complete. All documentation supplied with the unit should be passed along to maintenance personnel for future reference. -
Page 10: Operation
For initial installation the bypass valve should be closed. Hot Water Generator Installation and Operation Manual WARNING As a Turn on power to the rest of the electrically controlled components of the unit (if equipped). -
Page 11: Inspection
Inspection The following table summarizes the recommended time intervals for inspections of the water heater, components, inlet and outlet water, energy source lines (steam or boiler water), and power connections. To Be Inspected Manufacturer Specs Circulating Pump Control Valves - Temperature &... -
Page 12: Troubleshooting
• Control valve bulb not installed or not • Control valve actuator defective. Hot Water Generator Installation and Operation Manual P P R R O O B B A A B B L L E E C C A A U U S S E E... - Page 13 Hot Water Generator Installation and Operation Manual (continued) P P R R O O B B A A B B L L E E C C A A U U S S E E low or boiler water temperature is too low.
- Page 14 Hot Water Generator Installation and Operation Manual P P R R O O B B A A B B L L E E C C A A U U S S E E • The primary / inlet temperature control valve is not closing properly.
-
Page 15: Maintenance
Close the hot water tap if no air discharge is observed. Hot Water Generator Installation and Operation Manual Turn on electric power to the circulating pump and other electrical components if necessary. - Page 16 16. Observe tank and piping to ensure all components are functioning properly. Figure 7_Horizontal Storage Tank w/Anodes Hot Water Generator Installation and Operation Manual Magnesium anode rod inspection Glass lined storage tanks have a magnesium anode(s) to provide cathodical protection of the lining and minimize corrosion.
-
Page 17: Component(S) Replacement
If the Lochinvar Hot Water Generator is equipped with a circulating pump to assist in the even heating of the water, manual shutoff valves will be located on both the inlet and outlet side piping. To replace the valves, follow the procedure detailed below. - Page 18 Tube bundle inspection replacement The tube bundle is the heart of the Lochinvar Hot Water Generator. It should be removed and inspected every two (2) years. Steam or boiler water present situations WARNING that can be very dangerous because of the high temperature and pressures.
- Page 19 Follow the startup procedure (page 10) to put the unit back on-line. Carefully check all connections for any sign of leakage. Hot Water Generator Installation and Operation Manual (continued) Single solenoid safety system (optional) - inspection and replacement The single solenoid safety system closes the steam (or boiler water) control valve in an over-temperature condition.
- Page 20 Hot Water Generator Installation and Operation Manual Remove the temperature control valve from the system. Follow the supplied manufacturer instructions for inspecting the valve. If found to be malfunctioning, replace the valve.
- Page 21 / or type of joint compound or sealer at the connections. Follow the startup procedure (page 10) to put the unit back on-line. Carefully check all connections for any sign of leakage. Hot Water Generator Installation and Operation Manual (continued) contained...
-
Page 22: Notes Page
Hot Water Generator Installation and Operation Manual Notes... - Page 23 Hot Water Generator Installation and Operation Manual Notes...
- Page 24 HWG-i&o-01 CP-2M-12/05...
