1. INTRODUCTION
2. KEYPAD FEATURES
The Model AM-KPI keypad is designed for use with Linear's AM/II
RED/GREEN
YELLOW
access control system. The keypad is housed in a rugged, plastic
AM-KPI
POWER/ACCESS
"LOCKOUT"
enclosure and is designed to be mounted indoors in a standard single-
INDICATOR
INDICATOR
gang electrical box. Tamper resistant screws secure the keypad to its
mounting plate. The die-cast keys have bright, easy-to-read yellow
BEZEL
graphics.
Access
The keypad is supplied with a satin-chrome plastic bezel installed.
Three interchangeable colored plastic bezels (white, ivory, & bronze)
Control
SOLID STATE
are included with the unit to customize the keypad appearance for the
WHITE LED
installation.
DOWN LIGHT
Keypad
DEVICE
All system indicators and lights are long-lasting, solid-state LEDs. Two
ADDRESS
SELECTOR
indicators show the status of the entry system. The left indicator lights
red to indicate power, then turns green when access is granted. The
FACEPLATE
right indicator lights yellow when the keypad is in "lockout" condition
Installation
KEYPAD
(from too many incorrect code entries). A white LED downlight lights
the keypad for nighttime use. An internal sounder beeps when each
Instructions
key is pressed.
The AM-KPI is normally powered from the AM/II controller. Alternately,
the keypad can be powered locally with a 12 VDC power supply.
TERMINAL
Robust static and lightning protection circuits safeguard the keypad's
BLOCK
electronics.
A rotary switch selects the keypad's device address. Each device
connected to the AM/II must be set to a different device address.
MOUNTING
PLATE
(760) 438-7000 • FAX (760) 438-7043
USA & Canada (800) 421-1587 & (800) 392-0123
Toll Free FAX (800) 468-1340
www.linearcorp.com
3. OPEN THE KEYPAD
4. CUSTOMIZE THE BEZEL (OPTIONAL)
5. INSTALL WALL BOX & MOUNTING PLATE
1
PRY UP ON THE
TO CHANGE THE APPEARANCE OF THE KEYPAD
FACEPLATE HERE
INSTALL A SINGLE-GANG
TO BLEND IN WITH THE INSTALLATION,
ELECTRICAL BOX AT THE
CHOOSE THE APPROPRIATE KEYPAD BEZEL
PROPER LOCATION
FOR THE KEYPAD
2
REMOVE THE
KEYPAD BEZEL COLORS:
FACEPLATE
• SATIN-CHROME (FACTORY INSTALLED)
• WHITE
KEYPAD
BEZEL
• IVORY
• BRONZE
KEYPAD
ASSEMBLY
MAKE SURE THE
TAB IS UP
MOUNTING
PLATE
3
ATTACH THE MOUNTING
REMOVE THE
THE BEZEL SNAPS
MOUNTING
TWO SCREWS
PLATE TO THE
ONTO THE KEYPAD
PLATE
ELECTRICAL BOX
ASSEMBLY
4
SEPARATE THE
MOUNTING PLATE
FROM THE KEYPAD
