Summary of Contents for RIDGID 614
- Page 1 Dry Cut Saw OPERATOR’S MANUAL • Français – 11 • Castellano – pág. 23 WARNING! Read this Operator’s Manual carefully before using this tool. Failure to understand and follow the contents of this manual may result in electri- cal shock, fire and/or serious personal injury.
-
Page 2: Table Of Contents
614 Dry Cut Saw Table of Contents Recording Form for Machine Serial Number ......................1 General Safety Information Work Area Safety................................2 Electrical Safety ................................2 Personal Safety................................2 Tool Use and Care..............................3 Service ..................................3 Specific Safety Information Dry Cutter Safety ................................3 Description, Specifications and Standard Equipment Description ..................................4... -
Page 3: Recording Form For Machine Serial Number
Dry Cut Saw 614 Dry Cut Saw Record Serial Number below and retain product serial number which is located on nameplate. Serial... -
Page 4: General Safety Information
614 Dry Cut Saw General Safety Information • When operating a power tool outside, use an out- door extension cord marked “W-A” or “W”. These WARNING! Read and understand all instructions. Failure cords are rated for outdoor use and reduce the risk of to follow all instructions listed below may electrical shock. -
Page 5: Tool Use And Care
Read this operator’s manual carefully before using support the workpiece to a stable platform. Holding the 614 Dry Cut Saw. Failure to understand and fol- low the contents of this manual may result in the workpiece by hand or against your body is unsta- electrical shock, fire and/or serious personal injury. -
Page 6: Description, Specifications And Standard Equipment Description
Description 1. Inspect the power cord and plug for damage. If the The RIDGID 614 Dry Cut Saw is designed to cut ferrous grounding prong is missing or the cord is damaged, do not use the tool until the cord has been replaced. -
Page 7: Saw And Work Area Set-Up
614 Dry Cut Saw earlier. If the power cord does not reach the outlet, use an extension cord in good condition. To avoid electrical shock and electrical WARNING fires, never use an extension cord that is damaged or does not meet the following requirements: •... -
Page 8: Clamping The Workpiece
614 Dry Cut Saw Clamping the Workpiece NOTE! Always use both hands when using the vise to prevent saw from tipping. 1. Dry Cut Saw is equipped with a two-lever vise that NOTE! For smoother operation and extended life, keep can be adjusted to make an angle cut from 45º... -
Page 9: Removing The Workpiece
614 Dry Cut Saw Removing the Workpiece 1. Raise the upper lever of the vise to release the work- piece. Pull back on the horizontal lever to allow the workpiece to be easily removed from the vise. Pivot Pin 2. Slide the workpiece out of the saw keeping a firm grip on the workpiece as it clears the saw. -
Page 10: Replacing Brushes
614 Dry Cut Saw Spindle Lock Figure 10 – Carbon Brush Wear 2. Use the slotted ( – ) screw driver to remove the brush caps (Figure 11). Figure 8 – Removing Saw Blade Figure 11 – Removing Brush Caps 3. -
Page 11: Service And Repair
Any problems not addressed by this section should only be handled by an authorized RIDGID service technician. Tool should be taken to a RIDGID Independent Authorized Service Center or returned to the factory. All repairs made by Ridge service facilities are warranted against defects in material and workmanship. -
Page 12: Wiring Diagram
614 Dry Cut Saw Wiring Diagram YELLOW ON/OFF SWITCH NEUTRAL WHITE BLACK BLUE GROUND GREEN BLACK GREEN Ridge Tool Company...
