P
A
OWER
VAILABILITY
PowerSure PSI™
U
M
SER
ANUAL
1000 - 3000VA
230V
Version française, : reportez-vous au CD du guide d'utilisateur Liebert.
Para español, consulte el CD del Manual del Usuario de Liebert.
Die deutsche Fassung finden Sie auf der CD des Liebert-Benutzerhandbuchs.
Per l'Italiano, consultare il CD contenente il Manuale dell'utente Liebert.
Advertisement
Table of Contents
Related Manuals for Liebert PSITM
Summary of Contents for Liebert PSITM
- Page 1 230V Version française, : reportez-vous au CD du guide d'utilisateur Liebert. Para español, consulte el CD del Manual del Usuario de Liebert. Die deutsche Fassung finden Sie auf der CD des Liebert-Benutzerhandbuchs. Per l'Italiano, consultare il CD contenente il Manuale dell'utente Liebert.
-
Page 3: Table Of Contents
MPORTANT AFETY NSTRUCTIONS LOSSARY OF YMBOLS ............4 NTRODUCTION AJOR OMPONENTS... - Page 4 OLTAGE ROGRAMMING 10.0 ............22 AINTENANCE 10.1 Cleaning the UPS .
-
Page 5: Important Safety Instructions
• Do not place UPS power cord in any area where it may get damaged by heavy objects. WARNING If your UPS demonstrates any of the following conditions, turn Off and unplug your UPS from the outlet and contact your local dealer, Liebert representative or Liebert Worldwide Support Group: • The power cord or plug is damaged. - Page 6 Provided are a Liebert MultiLink cable and a USB cable for connection to a computer. Do not use the Liebert MultiLink cable for other applications. Store in a safe place if not required at this time.
-
Page 7: Glossary Of Symbols
Glossary of Symbols. LOSSARY OF YMBOLS Risk of electrical shock Indicates caution followed by important instructions Requests the user to consult the manual Indicates the unit contains a valve-regulated lead acid battery Recycle DC voltage Equipment grounding conductor Bonded to ground AC voltage ON/Alarm Silence/Battery Test Voltage Programming Button... -
Page 8: Introduction
Liebert’s MultiLink software. MultiLink software can also remotely control UPS operation. The USB port provides detailed operating information and alarm status to the host system when used in conjunction with the Liebert Human Interface Device (HID) and Microsoft Power Manager software. -
Page 9: Figure 2 1000 And 1440Va Psi-Rear View
Figure 2 1000 and 1440VA PSI—rear view Intellislot Port REPO INTELLISLOT USB Port RS232 (DB-9) Port Figure 3 2200 and 3000VA PSI—rear view Intellislot Input Circuit Port REPO Breaker REPO INTELLISLOT INPUT RS-232 INPUT BREAKER PUSH TO RESET AC Input Port RS232 (DB-9) Port... -
Page 10: Major Components
AJOR OMPONENTS Figure 4 Line diagram of PowerSure PSI 1000VA & 1440VA Input EMI/RFI Filter Charger Figure 5 Line diagram of PowerSure PSI 2200VA & 3000VA Input EMI/RFI Filter Charger Transient Voltage Surge Suppression (TVSS) and EMI/RFI Filters These UPS components provide surge protection and filter both electromagnetic interference (EMI) and radio frequency interference (RFI). -
Page 11: Automatic Voltage Regulator
Automatic Voltage Regulator The Automatic Voltage Regulator (AVR) protects connected equipment from power spikes, sags and other abnormalities by raising (boosting) or lowering (bucking) the output voltage as needed. This keeps the UPS output voltage within the connected equipment’s tolerance and accommodates wide mains voltage fluctuations without utilizing the batteries. -
Page 12: What
’ NCLUDED The PowerSure PSI is shipped with the following items: • PowerSure PSI user manual • MultiLink software CD • MultiLink serial cable, 3m (10 ft) • USB cable, 1.8m (6 ft) • RJ-11 cord, 2.1m (7 ft) • Rack mount handles •... -
Page 13: Installation
NSTALLATION Preparation 1. Visually inspect the UPS for freight damage. Report damage to the carrier and your local dealer or Liebert representative. CAUTION The UPS is heavy (see Table 4 - Battery cabinet specifications). Take proper precautions when lifting or moving it. -
Page 14: Rack-Mount Ups Conversion And Installation
Rack-Mount UPS Conversion and Installation NOTE When rack mounted, the UPS must be supported by a shelf, slide rails, brackets or fixed rails on each side. The rack mount handles WILL NOT support the weight of the UPS. They are used to move the UPS into and out of the rack. -
Page 15: Figure 9 Rack Mounting Rails And Slide Assemblies
4. Attach the two (2) fixed rails to the racks mounting rails. The fixed rail assemblies fit on the inside of the rack mounting rails. 5. Insert two (2) M5 flat head screws loosely (finger-tight) into the top and bottom holes on the front of the fixed rail assembly (see Figure 9). - Page 16 15. Connect Phone/Fax/DSL/Network/Modem devices to data line connectors. RJ11/RJ45 connection INPUT BREAKER PUSH TO RESET LOAD 1 PHONE / FAX / MODEM / NETWORK PROTECTION INPUT LOAD 2 INTELLISLOT 16. Communication options (see 8.0 - Communications for details): Option 1 - Serial Communications Serial communications provides parametric data, for example, input voltage and battery voltage.
-
Page 17: External Battery Cabinet Installation
Ground External Battery Cabinet Installation Optional Liebert external battery cabinets may be connected to the UPS to provide additional battery run time. External battery cabinets are designed to be placed all on one side of the UPS or stacked beneath the UPS. The run time is limited to a maximum of four (4) hours. -
Page 18: Controls And Indicators
• After 24 hours, retest the batteries. • After the batteries have been retested, if all five (5) Battery indicators are not illuminated, con- tact your local dealer, Liebert representative or Liebert Worldwide Support Group. OFF Button When the UPS is on (in either Normal or Battery mode), pressing the OFF button for more than one (1) second will shut down the UPS. -
Page 19: Voltage Programming Button
Voltage Programming Button The PowerSure PSI contains a Voltage Programming button that allows the operator to select the nominal mains voltage. This setting changes the mains transfer points (low and high) of the UPS and the nominal output voltage when operating in Battery mode. The operator can select between 220, 230 and 240VAC output. -
Page 20: Over Temp Indicator-Amber
Over Temp Indicator—Amber The Over Temp Indicator flashes when the UPS detects an over temperature condition. This indicator illuminates when the UPS shuts down due to an over temperature condition (see 11.0 - Trouble- shooting for details). 6.10 Fault Indicator—Red The Fault Indicator illuminates when the UPS detects an internal problem (see 11.0 - Trou- bleshooting for details). -
Page 21: Modes Of Operation
ODES OF PERATION Normal Mode During Normal mode operation, the PowerSure PSI supplies conditioned, computer-grade power to the connected equipment: mains power passes through the TVSS circuitry and the EMI/RFI filters and then through the Inverter (1000VA & 1440VA) / Bi-Directional Converter (2200VA & 3000VA) to connected equipment. -
Page 22: Battery Mode
Battery Mode The UPS switches to Battery mode in the event of an extreme input voltage/frequency condition or complete mains failure. The battery system supplies power through the Inverter (1000VA & 1440VA) or through the DC-to-DC converter to the Bi-Directional Converter (2200VA & 3000VA) to generate power for the connected equipment. -
Page 23: Communications
MultiLink software. The DB-9 is capable of supplying serial communica- tion, on battery and low battery signals. MultiLink, Liebert’s UPS monitoring and shutdown soft- ware, is shipped with the UPS, along with a 3m (10 ft) DB-9 cable required for running MultiLink. -
Page 24: Usb Interface Port
The PowerSure PSI is equipped with an Intellislot monitoring options. Liebert’s MultiLink software continually monitors the UPS and can shut down your computer or server in the event of an extended power failure. MultiLink can also be configured for use without the serial cable when the Intellislot OCWEBCARD is installed in the UPS. -
Page 25: Voltage Programming Procedure
OLTAGE ROGRAMMING Figure 17 Load Level Indicators Voltage Programming Button 1. Remove the front bezel from the UPS. 2. UPS must be operating in Normal (AC) mode. NOTE Mains power will be applied to the connected load. 3. The AC Input, Load, and Battery Level Indicators should be lit. 4. -
Page 26: Maintenance
The PowerSure PSI is designed to allow the user to replace the internal batteries safely. Read the safety cautions before proceeding. Contact your local dealer or Liebert representative to obtain the appropriate replacement battery kit part number and pricing. -
Page 27: 10.3.1 Internal Battery Replacement Procedure
6. Unpack the new battery assembly, taking care not to destroy the packing. Compare new and old battery assemblies to make sure they are the same. If so, proceed with Step 7; otherwise STOP and contact your local dealer, Liebert representative, or the Liebert Worldwide Support Group. 7. Slide in the new replacement battery pack. -
Page 28: Roubleshooting
11.0 T ROUBLESHOOTING The information below indicates various symptoms a user may encounter in the event the PowerSure PSI experiences a problem. Use this information to determine whether external factors caused the problem. See Table 2 - Troubleshooting chart for suggested remedy. 1. -
Page 29: Table 2
Solution Check the circuit protector on the rear of the UPS. If it is tripped, reset it and restart the UPS. For further help, contact your local dealer, Liebert representative or the Liebert Worldwide Support Group. Check for proper connection of battery or batteries. -
Page 30: Specifications
12.0 S PECIFICATIONS Table 3 UPS specifications PS1000RT2-230 Model Number Power Rating, VA/W 1000VA/750W Dimensions, W x D x H, mm (in) 87 x 557 x 430 Unit (3.43 x 22 x 17) 300 x 706 x 598 Shipping (11.8 x 27.8 x 23.5) Weight, kg (lbs) Unit 28 (61.7) -
Page 31: Table 4 Battery Cabinet Specifications
Table 3 UPS specifications (continued) PS1000RT2-230 Model Number Agency Safety Surge Susceptibility Electrical Fast Transient Emissions Conducted Immunity Harmonics Flicker Transportation Table 4 Battery cabinet specifications Model Number Used w/UPS Model Dimensions, W x D x H, mm (in) Unit Shipping Weight, kg (lbs) Unit... -
Page 32: Table 5 Battery Run Times
Table 5 Battery run times Load% Internal Battery (minutes) 100% Internal Battery + 1 External Battery Cabinet (minutes) 100% Internal Battery + 2 External Battery Cabinet (minutes) 100% Internal Battery + 3 External Battery Cabinet (minutes) 100% Internal Battery + 4 External Battery Cabinet... - Page 34 PowerSure PSI™ The Company Behind the Products With over a million installations around the globe, Liebert is the world leader in computer protection systems. Since its founding in 1965, Liebert has developed a complete range of support and protection systems for sensitive electronics: •...
