WARNINGS • Hot! Do not touch! The glass and surfaces of this appliance will be hot during operation and will retain heat for a while after shutting off the appli- ance. Severe burns may result. • Carefully supervise children in the same room as appliance.
CONGRATULATIONS! In selecting this LENNOX B-Vented Gas Appliance you have chosen the finest and most dependable fireplace to be found anywhere. It is a beautiful, prestigious alternative to a wood burning fireplace. Welcome to a Family of tens of thousands of satisfied LENNOX Fireplace Owners.
The following table shows the units' gas ori- fice size for the elevations indicated: i f i Maximum manifold pressure is 3.5 in. w.c. (0.87 kPa) for natural gas and 10 in. w.c. (2.49 kPa) for LP/Propane gas. Do not use these appliances if any part has been under water.
Gas Controls/Control Compartment Access The gas controls can be found behind the control compartment access panel. To open the control compartment access panel, actuate the spring-loaded magnetic catch securing the panels right side, by gen- tly depressing the outer top corner of the panel until the catch "pops"...
Variable Flame Height Adjustment ( Millivolt Appliances only) 1. All Millivolt appliances are equipped with a variable gas control valve. Flame height for these models may be adjusted through a range between fixed low and high settings while the appliance is in operation. Adjust the flame height as desired after lighting the appliance by rotating the variable adjust- ment control knob located on the front of the...
Manual-Reset Safety Limit Switch This appliance is equipped with a manual- reset blocked flue safety limit switch. Refer to Figure 5 for its location. If, during appliance operation, the flame goes out (independently of the burner on/off wall switch), it may be due to the operation of this safety limit switch.
Maintenance Schedule Annually (Before the onset of the Burning Season) Maintenance Task Inspecting/Cleaning Burner, Logs and Controls Check Flame Patterns and Flame Height Inspecting/Cleaning Pilot Burner and the Two Main Burners Checking Vent System Appliance Checkout Periodically (After the Burning Season) Maintenance Task Cleaning Firebox Interior Check Flame Patterns and Flame Height...
WARNING: DO NOT ATTEMPT TO SUB- STITUTE THE MATERIALS USED ON THESE DOORS, OR REPLACE CRACKED OR BROKEN GLASS WITH ANY MATERI- ALS OTHER THAN THOSE PROVIDED BY THE APPLIANCE MANUFACTURER. THE GLASS DOORS OF THIS APPLIANCE MUST ONLY BE REPLACED AS A COMPLETE UNIT AS PROVIDED BY THE MANUFACTURER.
Log Placement WARNING: LOG SET GETS VERY HOT AND WILL REMAIN HOT UP TO ONE HOUR AFTER GAS SUPPLY IS TURNED OFF. HANDLE ONLY WHEN LOG SET IS COOL. TURN OFF ALL GAS TO THE APPLIANCE BEFORE INSTALLING THE GRATE AND LOG SET. WARNING: THIS APPLIANCE IS NOT DE- SIGNED TO BURN WOOD.
6. The installation date of the appliance. If you encounter any problems or have any questions concerning the installation or appli- cation of this system, please contact your dis- tributor, or Lennox directly: LENNOX HEARTH PRODUCTS 1110 West Taft Avenue Orange, CA 92865...
ACCESSORY COMPONENTS i l o i n i t i n . n i s t i i l o i n i t i n . n i Door Frame Kits A decorative door frame kit is available for use with these appliances.
ACCESSORY COMPONENTS CONTINUED Remote Control System (Deluxe) H0251 Deluxe Remote Control System (Model RCL-T) The Model RCL-T (Deluxe) Remote Control System has all of the features of the standard system along with an added easy to read LCD screen which presents access to many en- hancements, including;...
ACCESSORY COMPONENTS CONTINUED i l o i n i t i n . n i s t i i l o i n i t i n . n i 2-Piece Polished Brass and Brushed Stainless Louvers Kits Decorative louvers are available for use with all Multi-Open Series appliances.
ACCESSORY COMPONENTS CONTINUED Style View Doors Continued - Style View Doors also come in a Tall Arch Pane Design. Two distinctive grille kits, the “Crescents” and “Sunrise” design, are also offered seperately. They are easy to install and will not require hardware to attach them to the standard glass door frame. The door includes heavy duty magnet door latches and functional twin-pane doors.
NOTES: NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A. This appliance has a pilot which must be lighted with a piezo ignitor. When lighting the pilot, follow these instructions exactly.
INSTRUCTIONS D’ALLUMAGE – VANNE GAZ MILLIVOLT POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. A.
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A. When lighting the appliance, follow these instructions exactly. B. BEFORE OPERATING smell all around the appliance area for gas.
INSTRUCTIONS D’ALLUMAGE — ELECTRONIC POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT: SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. A.
TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM ote: Before troubleshooting, make sure that the appliance main line gas shut-off valve and the gas control valve are in the "OPEN" position and the burner ON/OFF switch is in the “ON” position. Important: Valve system troubleshooting should only be accomplished by a qualified service technician. SYMPTOM 1.
TROUBLESHOOTING THE ELECTRONIC IGNITION SYSTEM ote: Before troubleshooting, make sure that the appliance main line gas shut-off valve and the gas control valve are in the "OPEN" position and the burner ON/OFF switch is in the “ON” position. Important: Valve system troubleshooting should only be accomplished by a qualified service technician. SYMPTOM POSSIBLE CAUSES 1.
t o l t o l t o l t o l t i n t o l REPLACEMENT PARTS GAS CONTROLS — SIT MILLIVOLT t i n GAS CONTROLS — HONEYWELL ELECTRONIC l l e ) t i GAS ORIFICES — SIT AND HONEYWELL SYSTEMS i f i i f i NOTE: DIAGRAMS &...
, t n . n i . n i e l t . n i , e l . n i , e l . n i , e l . n i e t i i t a , t e , t e i t n , t e...
EBVST, EBVCR, EBVCL fireplaces. Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.
