Page 4
Basic 基本設定 (I) 自動彩色 – 自動探測原稿是彩色文件 或黑白文件 Auto Color – This setting to automatically detect the documents are in color or black and white 全彩 – 列印彩色文件 Full Color – The copy in full color 黑色 – 列印黑白文件 Black – The copy in black and white 兩色...
Page 5
Basic 基本設定 (II) -- Paper 紙張 更改手送紙紙張尺寸 Change Bypass Tray Setting 按 基本設定 ,按 紙張 Press Basic, Press Paper 選擇手送紙盤 Select Paper Type 按 紙盤變更設定 Press change Tray Settings 選擇紙張類型 Press Select Paper Type 輸入適合的尺寸 Input paper size 按尺寸設定,選擇標準尺寸 Touch Standard Size 按自定尺寸...
Page 6
Basic 基本設定 (III) -- 倍率 Zoom 按 倍率 Press ZOOM 選擇一般的變焦比率 Select fixed zoom size a 按預設的縮小 / 放大比率 例如︰A3 A4 設定數字為 0.707 Touch default zoom ratios e.g.︰A3 A4 default zoom ratio is 0.707 b 按 - + 加減號增加或減少變焦數字 Touch- + to change zoom ratio 按...
Page 7
分頁/分類 Sort/Group 按分頁機 Press Finishing 可按分頁或 群組 Press Sort or Group Sort 如沒有其他設定,按 Start 影印鍵 Press Start to Copy 位移功能 Offset 1. 按分頁機 Press Finishing 2. 在位移功能項目中按是 In Offset option select Yes 3. 如沒有其他設定,按 Start 影印鍵 Press Start to Copy *如沒有安裝訂裝器,副本會用十字型式分隔...
Page 8
(必需加裝配件才有以下功能) (Optional Function) 訂裝 Staple 1. 按 分頁機 Press Finishing 2. 在訂裝項目中按 訂角 或 2 個位置 At Staple select Corner or 2position 3. 按 位置設定選擇訂裝位置 Press position Setting to desired staple positions 4. 如沒有其他設定,按 Start 影印鍵 Press Start to Copy 打孔...
Page 9
摺疊/書本訂裝 Fold/Bind 1. 按分頁機 Press Finishing 2. 在 摺疊/裝訂項目中按 Yes 啟動功能 At Fold/Bind select Yes 3. 按 對摺 中間裝訂 或 三摺 Touch Half-Fold Center Staple & Fold or Tri-Fold Half-Fold 對摺 Center Staple & Fold 中間裝訂 Tri-Fold 三摺...
Page 10
Basic 基本設定 (IV) --Duplex/Combine 雙面/組合 組合 選擇 Combine function 按 2 in 12 合 1 兩張原稿縮為一張 或 4 in 1/ 8 in 14 合 1/8 合 1 四張/八張原稿縮為一張 Touch 2 in 1 or Touch 4 in 1/ 8 in 1 To reduce the size from 2 / 4 / 8 sheets originals into 1 sheet of copy 選擇...
Page 11
Originals Setting 原稿設定 1. 按混合原稿啓動探測功能, 如放在 自動 送紙器的原稿有不同大小的混合 Press Mixed Original automatically detects the documents size and automatically choose paper tray 2. 按 Z 摺疊原稿使摺疊的原稿能準確感應 Press Z-Folded Original to detect the original size when folded originals correctly 3. 按原稿空白邊設定原稿內容的方向 Touch Binding Direction select copy-binding direction 4.
Page 12
Quality/Density 品質濃淡度 1. 1. 可在原稿類型 選擇適當的原稿 類型 Select Original Type to choose Text, Text/Photo, Photo, Map, Dot Matrix Original or Copied Paper 2. 按 濃淡度 調校整份文件的深淺度 Touch Density – the print image can be adjusted, each time [Lighter] or [Darker] is touched, the density is lightened or darkened by one level. 3.
- Booklet 小冊子 按 應用功能 Press Application 按小冊子 Press Booklet 可選擇 左邊或右邊 裝訂 Select left bind or right bind Left Binding /Right Binding 按 Start Press Start 戳記構成 Stamp Composition 1. 按 應用功能 Press Application 2. 可選擇 日期/時間或頁碼或戳記 等 Select Date/Time , Page Number or Stamp etc.
Page 15
停止正在等候的工作 Delete the copy jab in the Waiting List 按作業顯示 press Job List 按作業細節 Press Job Details 選擇正在等候的工作 Select the job you want to delete 按 刪除 Press Delete 按 是 後按 OK 清除工作的命令 Press Yes and then OK to delete printing job...
掃瞄設定 Scan Setting 按 Fax/Scan Press Fax/Scan 選擇一按鍵的索引及名稱 Select one-touch Index and Name 掃描設定 Scan Setting 原稿型態 – 選擇原稿類型 Original Type - Select original type 單面/雙面 - 設定原稿是單或雙面 Simplex/Duplex - Select original single-sided or double-sided C. 解晰度 - 設定解像度 Resolution – resolution setting D.
Remove Jammed Paper 清除塞紙 *版面顯示塞紙位 Remove misfeed at circle 1. 打開出紙位置之綠色鍵後, 拉出紙張 Pull up the upper right side door release lever, and then open the upper right side door 2. 如雙面器塞紙, 請打開雙面器後拉出紙張 Open the door of the automatic duplex unit 3.
Page 23
Display the Job History List 檢查傳送記錄 按 Job Details 作業細節 按 Send 傳送 按 Job History 作業日誌 按 Comm. List 通信清單 選擇 Scan TX List / Fax TX List 後 選擇要列印的報告 Activity Report 動態式報表 TX Report 傳送報表 C. RX Report 接收報表 按...
Page 24
報讀和打印總咪錶數 Check and Print meter list, 如沒有安裝數碼醫生,請每月把咪錶報告傳真至 2565 2128 If Digital Doctor not installed, please fax the meter report to 2565 2128 monthly 按 Utility / Counter Press Utility / Counter 按 計數器 Press Meter Count 按 細節檢查 Press Check Details 按...
Page 26
列印信封或特別尺寸紙張 Print Envelope or custom size paper 1. 先把影印機手送盤上的紙拿走 Take paper away in Bypass tray, to keep it empty. 電腦打印程序設計 Printer Driver Setting 在電腦開啓文件後,選擇本印表機 Open the file,Click printer driver 點選 [內容] Click [Preferences] 在[原稿尺寸]內選擇[自定尺寸]輸入原稿 紙張之尺寸(如: 110mm x 220mm) Click [Original Size] select [Custom size] then input Width and Length (e.g.
Page 27
列印長紙張之簡易程序 Banner Paper Printing User Guide 長紙尺寸 寛 高 210 - 296mm / 457.3 –1200mm Banner paper size: (Width) 210 - 296mm / (Length) 457.3 –1200mm 請在列印長紙前,先在印表機開啟此功能 Prepare printing on Banner Paper 按 [Utility/ Counter] Press [Utility/ Counter] 選 [6. 長紙張] Press [6.
Page 28
在 紙張尺寸 內選 如同原稿尺寸 ** 印表機裝置自動選取 手送紙盤及 紙張類型 為 厚紙 3 Click [Output Size] select [Same as Original Size] Printer Driver automatically select to Bypass tray and Paper type automatically select to Think 3 8. 按 [確定] Press [OK] 當印表機接收到列印文件指令時 Printing Banner Printing 9.
使用外置記憶體 Using External Memory USB Port 從外置記憶體打印 Print from External Memory 按[User Box] [系統] [外接記憶體] [使用/檔案] 選擇要打印的檔案 [列印] [Start] Press [User Box] [System user box] [External Memory] [Use/file] Select file [Print] [Start] 掃瞄到外置記憶體 scan to External Memory (要先在管理員模式先開動此功能 Must enable in Admin mode first) 按[User Box] [儲存文件] [外接記憶體] [Start]...
Page 30
部門熱線 Particulars 市務科 Marketing Division 銷售熱線 Sales Hotlines 查詢產品及銷售詳情 New Product and Sales Enquires 服務科 Technical Service Division 維修熱線 Repair Hotline 多功能產品之維修服務 Repair Services of MFPs 服務科 Technical Service Division 產品之技術支援熱線 Imaging Support Group 軟件及網絡支援 Software and Network Support 服務科 Technical Service Division 客戶服務熱線...
Page 32
柯尼卡美能達商業系統(香港)有限公司 Konica Minolta Business Solutions (HK) Limited...
