ER-A310
CHAPTER
1. GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
CHAPTER
2. LIST OF OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
CHAPTER
CHAPTER
CHAPTER
CHAPTER
CHAPTER
CHAPTER
CHAPTER
CHAPTER 10. ONE HOLE CASHIER KEY KIT: DKIT-8669BHZZ
(For ER-A310 & ER-A330) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
CHAPTER 11. KEY TOP KIT: ER-11KT7/12KT7/22KT7/11DK7/51DK7
(For ER-A310 & ER-A330) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Parts marked with "! " is important for maintaining the safety of the set. Be sure to replace these parts with specified ones for
maintaining the safety and performance of the set.
INSTALLATION MANUAL
ER-A330
CONTENTS
SHARP CORPORATION
CODE: 00ZERA310VIME
ELECTRONIC
CASH REGISTER
ER-A310
MODEL
ER-A330
MODEL
SRV Key : LKGIM7113RCZZ
PRINTER : ER-A310 : CR-510
:
ER-A330 : UCR-812A
(For "V" version)
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.

Advertisement

Table of Contents
loading

Summary of Contents for Sharp ER-A310

  • Page 1: Table Of Contents

    CHAPTER 10. ONE HOLE CASHIER KEY KIT: DKIT-8669BHZZ (For ER-A310 & ER-A330) ....... . . 7 CHAPTER 11.
  • Page 2: General

    CHAPTER 1. GENERAL This manual describes the ER-A310/A330 disassembly procedures Master reset (All memory clear) and the option attachment procedures. For assembly procedures, reverse the disassembly procedures. For attachment of options which There are two possible methods to perform a master reset.
  • Page 3: Removing The Top Cabinet (For Er-A310 & Er-A330)

    5) Remove transformer cable and drawer cable from the main CHAPTER 3. REMOVING THE TOP PWB. CABINET (For ER-A310 & ER-A330) 1. ER-A310 1) Remove the printer cover 2) Remove the two screws 3) Remove the screw and grounding wire 4) Separate the top cabinet and the drawer unit.
  • Page 4: Removing The Bottom Cabinet (Only For Er-A330)

    5) Remove transformer cable and drawer cable from the main 2. ER-A330 PWB. 1) Remove the printer cover 2) Remove the three screws 3) Remove the screw and grounding wire CHAPTER 4. REMOVING THE BOTTOM CABINET (Only for ER-A330) 1. ER-A330 1) Remove the top cabinet.
  • Page 5: Removing The Printer Unit (For Er-A310 & Er-A330)

    4) Remove the screw and grounding wire 5) Remove the printer unit from the top cabinet. CHAPTER 6. REMOVING THE MAIN PWB (For ER-A310 & ER-A330) 1. ER-A310/A330 1) Remove the top cabinet. 2) Remove the printer unit. 3) Remove the following connector cables from the main PWB.
  • Page 6: Remote Drawer: Er-04Dw (For Er-A310 & Er-A330)

    The drawer unit should be securely fitted to the supporting platform to avoid instability when the drawer is open. 1. Outline The ER-A310/A330 allows connection of one remote drawer ER- 04DW. 2. Installation procedure for ER-A310 5) Fix ground wire of the ER-04DW on the standard drawer with 1) Remove the top cabinet.
  • Page 7: Drawer Fixing Kit: Dkit-8670Rczz (Only For Er-A330)

    (Only for ER-A330) bracket-B to the platform. * For the ER-A310, standard provision. The drawer fixing kit is used for securing the cash drawer when installing separately from the ECR main unit. By using two of brackets, the drawer box can be protected from drifting especially when it is filled with coins.
  • Page 8: Shield Plate Kit: Dkit-8666Bhzz (Only For Er-A330)

    CHAPTER 9. SHIELD PLATE KIT: CHAPTER 10. ONE HOLE CASHIER DKIT-8666BHZZ (Only KEY KIT: for ER-A330) DKIT-8669BHZZ (For ER-A310 & 330) * Standard provision for the TQ, TR, and TS versions of the ER- 1. Component list A330. PRICE PARTS CODE DESCRIPTION Q’TY...
  • Page 9: (For Er-A310 & Er-A330)

    No. NC9 on the main PWB. CHAPTER 11. KEY TOP KIT 1. Outline The ER-A310/A330 employs the following key top (option) to allow additional installation of the key top and change in the key layout. MODEL NAME DESCRIPTION 1 ×...
  • Page 10 ER-12KT7, ER-22KT7 Note: There are black spacers and white spacers. Refer to the figure before for attaching them. • Attach the black spacer to the left lower side, and the white spacer to the right lower side. ER-11DK7, ER-51DK7 – 9 –...
