User Manual
Quick start guide (Canada version)
CS6428-32/CS6429/CS6429-2/CS6429-3/
CS6429-4/CS6429-5
Introduction
This quick start guide provides you with the basic installation
and setup instructions. A limited set of features are described in
abbreviated form.
Please refer to the online user’s manual for complete installation
and operation instructions.
Telephone base and charger installation
Install the telephone base and charger as shown below.
Telephone
Telephone base
Charger adapter
wall jack
power adapter
A DSL filter (not
included) is required
if you have DSL
Electrical
high-speed Internet
outlet not
service
controlled
by a wall
Electrical
switch
outlet not
controlled by
a wall switch
Telephone
line cord
Charger
Telephone base
Use only the power adapter(s) and battery(ies) supplied with
this product.
Battery installation and charging
Install the battery as shown below. Once you have installed
the battery, you may be able to make and receive short
calls. For best performance, charge the handset battery
continuously for at least
10 hours.
1
2
Place the battery with the
Plug the battery connector
label THIS SIDE UP facing
securely into the socket.
up and the wires inside the
battery compartment.
3
4
Place the handset in the
Slide the battery
telephone base or charger
compartment cover towards
to charge.
the center of the handset
until it clicks into place.
CHARGE light
remains on when
charging.
Enter the handset menu
Press MENU when the telephone is not in use.
1.
2.
Press
or
until the screen displays the desired
feature menu.
Press SELECT to enter that menu.
3.
To return to the previous menu, press CANCEL.
•
To return to idle mode, press and hold CANCEL.
•
Set date and time
Press MENU when the handset is not in use.
1.
Scroll to >SETTINGS then press SELECT.
2.
Scroll to >SET DATE/TIME then press SELECT.
3.
4.
Use the dialing keys (0-9) to enter the month, date and year
and then press SELECT.
5.
Use the dialing keys (0-9) to enter the hour and minute.
to choose AM or PM.
6.
Press
or
Press SELECT to save.
7.
Set number of rings
You can set the answering system to answer an incoming call
after 2, 3, 4, 5 or 6 rings; or toll saver. If you choose toll saver,
the answering system answers a call after 2 rings when you
have new messages, or after 4 rings when you have no
new messages.
Press MENU when the handset is not in use.
1.
Scroll to >ANSWERING SYS then press SELECT.
2.
Scroll to >ANS SYS SETUP then press SELECT.
3.
Scroll to ># OF RINGS then press SELECT.
4.
to choose 2, 3, 4, 5, 6 or TOLL SAVER and
5.
Press
or
then press SELECT.
Record your own announcement
You can use the preset announcement to answer calls,
or replace it with your own recorded announcement. The
announcement can be up to 90 seconds in length.
Press MENU when the handset is not in use.
1.
Scroll to >ANSWERING SYS then press SELECT twice.
2.
The handset announces, “To play, press 2 . To record,
3.
press 7 .” Press 7 to record.
The handset announces, “Record after the tone. Press 5
4.
when you are done.” After the tone, speak towards the
handset microphone. Press 5 when done.
5.
The answering system automatically plays back the newly
recorded announcement. Press 5 to stop the playback
at any time; 2 to replay the recorded announcement; 3 to
delete the recorded announcement; or 7 to record again
if desired.
IMPORTANT!
Refer to the online user’s manual for a full set of installation and
operation instructions. For manual download or customer service,
visit our website at www.vtechcanada.com or call 1 (800) 267-7377.
Copyright © 2012 for VTECH TELECOMMUNICATIONS LTD.
All rights reserved. Printed in China.
