KitchenAid KUDK03CT Specification Sheet

Kitchenaid appliances undercounter dishwasher specification sheet.
Hide thumbs

®
Undercounter Dishwasher
PRODUCT MODEL NUMBERS
OVERALL DIMENSIONS
KUDC03IT
KUDS03FT
KUDC03FV
KUDK03CT
KUDS03ST
KUDL03IV
3/4" (1.9 cm)
24-7/8" (64.1 cm)
KUDK03FT
KUDT03FT
KUDL03FV
insulation – may be
KUDK03IT
KUDT03ST
KUDE03FT
23-7/8"
compressed (not used
24-1/2"
(60.6 cm)
on all models)
(62.2 cm)
KUDL03IT
KUDU03FT
KUDM03FT
KUDU03ST
KUDS03CT
KUDX03FT
Electrical: 120-volt, 60-Hz, AC-only, 15- or
20-amp. fused electrical supply. Use copper wire
33-7/8"
only. A time-delay fuse or circuit breaker and
(86 cm) min. with
wheels removed
separate circuit is recommended.
Water: A hot water line with 20-120 psi
(138-862 kPa) water pressure. Water temperature
must be 120°F (49°C) at dishwasher. Use 3/8" O.D.
copper tubing with compression fitting or flexible
stainless steel braided fill line (1/2" minimum plastic
tubing is optional but not recommended). Use a 90°
21" (53.3 cm)
elbow with 3/8" N.P.T. external pipe threads on one
end to connect to water inlet valve. Do not solder
Side view
Rear view
within 6" (15.2 cm) from water inlet valve.
Drain: Use the new drain hose supplied with your
CABINET OPENING DIMENSIONS
dishwasher. If this is not suitable, use a new drain
hose with a maximum length of 12 feet (3.7 m)
that meets all current AHAM/IAPMO test
standards, is resistant to heat and detergent, and
fits the drain connector of the dishwasher. Must
have a high drain loop 20 inches (50.8 cm) above
the subfloor or floor. Connect drain hose to waste
**
tee or disposer inlet above drain trap in house
24" (61 cm)
plumbing and 20 inches (50.8 cm) minimum
above the floor. An air gap must be used if the
All surfaces must be free
drain hose is connected to house plumbing lower
from intrusions
than 20 inches (50.8 cm) above subfloor or floor.
Use 1/2" minimum I.D. drain line fittings.
24" (61 cm)
min.
34"
(86.4 cm)
min.*
3-1/4"
3-1/4"
(8.3 cm)
(8.3 cm)
2"
2"
(5.1 cm)
(5.1 cm)
5-1/2"
3-1/2"
(14 cm)
6" ***
(8.9 cm)
6" ***
(15.2 cm)
(15.2 cm)
2"
9"
(5.1 cm)
10"
(22.9 cm)
(25.4 cm)
2-3/4"
3-1/4"
3-1/4"
2-3/4"
(7 cm)
(8.3 cm)
(8.3 cm)
(7 cm)
Cut holes in shaded area of cabinet walls or floor as specified below:
water line – 1/2" (1.3 cm)
drain line – 1-1/2" (3.8 cm)
direct wire – 3/4" (1.9 cm)
power supply cord – 1-1/2" (3.8 cm)
* Measured from the lowest point on the underside of countertop. May be
reduced to 33-7/8" (86 cm) by removing wheels from dishwasher.
** Minimum, measured from narrowest point of opening.
*** May be increased to 6-7/8" (17.5 cm) if height of opening is 34-1/2" (87.6 cm)
at its lowest point.
‡ Both sides
Because Whirlpool Corporation policy includes a continuous commitment to improve
Dimensions are for planning purposes only. For complete details, see Installation
Ref. W10078153C
08-15-08
our products, we reserve the right to change materials and specifications without notice.
Instructions packed with product. Specifications subject to change without notice.
