Nespresso Gran Maestria B520 User Manual

Hide thumbs Also See for Gran Maestria B520:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual, Manual

Advertisement

Table of Contents
loading

Related Manuals for Nespresso Gran Maestria B520

Summary of Contents for Nespresso Gran Maestria B520

  • Page 2 Cutting marks...
  • Page 3 Cutting marks Water t Power c Gran Maestria B/C/D520 CN: 220V, 50Hz, 2100 W KR: 220V, 60Hz, 2100 W AU/HK/NZ/SG: 220-240V, 50/60Hz, 2300W 19 bar 7 kg 1.4 l 45 cm 35.6 cm 36.4 cm...
  • Page 4 Water tank 2. ON/OFF button Lever Indication Lights Power cord and storage Espresso and Lungo dials Coffee outlet Cup support Up right position *...
  • Page 5 9. Cup heater Aeroccino dial Aeroccino Maintenance unit Aeroccino Aeroccino Spout * Lid * Capsule container: Rips * 10–14 capsules * Milk Frother * Drip tray and grid * *(1) *(2) *(3) *(4) *(5) *(6) (10~14 (10-14 *(7)

  • Page 6: Table Of Contents

    Nespresso, a unique system creating the perfect espresso, time after time. All Nespresso machines are equipped with a unique extraction system that guarantees up to 19 bar pressure. Each parameter has been calculated with great precision to ensure that all the aromas from each Grand Cru can be extracted, to give the coffee body and create an exceptionally thick and smooth crema.

  • Page 7: Safety Precautions

    Call the Nespresso Club or Keep it out reach of children. long period. Disconnect by pulling out the plug and not by pul- Nespresso authorized representative.
  • Page 8 Nespresso quality is only guaranteed when Nespresso grid and dispose. capsules are used in the Nespresso Appliances. SAVE THESE INSTRUCTIONS Pass them on to any subsequent user This instruction manual is also available as a PDF at nespresso.com. – – –...
  • Page 9 1.5 mm...

  • Page 11: Preparing Your Machine For First Use

    PREPARING YOUR MACHINE FOR FIRST USE/ First read the safety precautions to avoid risks of fatal electrical shock and fire. 1. Lift cup support, remove water tank and 2. Adjust cord length and store excess under machine 3. Close lever and plug into mains. maintenance unit.

  • Page 12: Coffee Preparation

    2. Reposition water 3. Close lever and switch machine on. tank. Steady: Ready 4. Lift lever and insert Nespresso capsule. 5. Close lever and place cup under coffee outlet. 6. Cup support can be turned up right to support macchiato glass.

  • Page 13: Cup Heater

    1. Cup heater is always in ready mode (except during 2. 3 rips must be pressed down 3. A jet of hot water heats a standard Nespresso cup within heat up). Take cup and place it upside down on cup simultaneously to activate flow...

  • Page 14: Barista: Aeroccino Use

    NOTE: Make sure to clean your Aeroccino before and after each usage. PREPARATION/ TIP: Always use cold, fresh, full-fat or semi-skimmed milk. Jugs maximum level for: Max milk: 1 Nespresso Recipe Glass Max foam: 1 Nespresso Recipe Glass/or 2 Nespresso Cappuccino Cups...

  • Page 15: Recipes

    RECIPES/ 1. Cold, velvety milk foam 2. Warm, velvety milk foam 3. Warm, dense milk foam 4. Warm milk Attach whisk. Pour milk up to desired level indicators Place lid on Aeroccino. depending on recipe. 5. Light on machine will light up blue or red, depending 6.
  • Page 16 CLASSIC RECIPES/ CAFFÉ LATTE/ CAPPUCCINO/ Proportions: Proportions: 1 espresso capsule 1 Lungo capsule Topped up with hot milk froth Topped up with hot milk Prepare an espresso in a Cappuccino cup and top up with hot milk froth. Prepare a Lungo in a tall glass (350ml) and top up with hot milk. Intense: Ristretto Grand Cru / Light: Rosabaya de Columbia Grand Cru Intense: Fortissio Lungo Grand Cru / Light: Vivalto Lungo Grand Cru...
  • Page 17 CLASSIC RECIPES/ LATTE MACCHIATO/ ICED CAPPUCCINO/ Proportions: Proportions: 1 espresso capsule 1 espresso capsule Crushed ice cubes Topped up with hot milk froth Topped up with cold milk froth Fill a tall glass with hot milk froth (300ml). Top up with an espresso preparation. Prepare an espresso in a tall glass (350ml), add four or five crushed ice cubes.
  • Page 18 GOURMET RECIPES/ ICED VANILLA CARAMEL COFFEE/ Proportions: 2 Volluto espresso capsules 1 scoop of vanilla ice cream 2 teaspoons of caramel syrup 1 teaspoon of chocolate chips Topped up with hot milk froth Prepare the hot milk froth, add the caramel syrup to it and set aside.
  • Page 19 GOURMET RECIPES/ AFTER EIGHT® COFFEE/ AFTER EIGHT® Proportions: 1 Capriccio espresso capsule After Eight® mint chocolate Nougat chocolate Topped up with hot milk froth Prepare the Capriccio capsule into an espresso cup. Top it up with hot milk froth. Sprinkle shavings of nougat chocolate on top and add an After Eight®...

  • Page 20: Menu Modes

    MENU MODES/ 1. To enter menu modes press the espresso button while 2. Set the dials to the required settings (see chart 3. Once selected, press lungo the button to confirm (Middle light steady turning the machine on. (Middle light blinks orange) below).

  • Page 21: Emptying Mode

    EMPT YING MODE/ Note: Your machine should be emptied before and after a long period of non-use. COFFEE: / 1. While in menu mode, set espresso button to position 2. Remove water tank and lift lever. 3. Press lungo button to empty machine (ready when 3 for emptying.

  • Page 22: Care & Cleaning

    CARE AND CLEANING/ 1. To assemble (disassemble) maintenance unit, make 2. Maintenance unit can be removed in one piece and separated for sure cup support is in upright position. easy cleaning. Cup heater grill can be removed for cleaning. AEROCCINO CLEANING/ Do not use any strong cleaning agent or solvent cleaner.
  • Page 23 1. 4. To enter descaling mode press the espresso button while 5. Fill water tank with 2 Nespresso descaling liquid 6. Place a cup on cup heater and press down on 3 rips to turning the machine on.
  • Page 24 CAUTION The descaling solution can be harmful. Avoid contact with eyes, skin and surfaces. Never use any product other than the Nespresso descaling kit available at the Nespresso Club to avoid damage to your machine. The following table will indicate the descaling frequency requi-...

  • Page 25: Troubleshooting

    Middle light blinks orange consistently. £ Descaling needed. No coffee, water just comes out (despite £ In case of difficulties, call the Nespresso Club. inserted capsule). Machine switches itself off automatically. £ To save energy the machine will turn itself off after 9 minutes of non-use.
  • Page 26 Should you need any additional information, in case of problems or simply to seek advise, call the Nespresso Club or your Nespresso authorized representative. Contact details for your nearest Nespresso Club or your Nespresso authorized representative can be found in the «Welcome to Nespresso» folder in your machine box or at nespresso.com ‘Welcome to Nespresso’...
  • Page 27 2003 (Rainforest Alliance) We chose aluminium as the material for our capsules because it protects the coffee and aromas of the Nespresso Grand Cru. Aluminium is also infinitely recyclable, without loosing any of its qualities. Nespresso is committed to designing and making appliances that are innovative, high-performing and user friendly. Now we are engineering environmental benefits into the...
  • Page 28 Warranty service outside the country of purchase is limited to the terms and conditions of the corresponding warranty in the country of service. Where the cost of repairs or replacement is not covered by this warranty, Nespresso will advise the owner and the cost shall be charged to the owner. This limited Warranty shall be the full extent of Nespresso’ s liability however caused. Except to the extend allowed by applicable law, the terms of this limited warranty do not exclude, restrict or modify the mandatory statutory rights applicable to the sale of this product and are in addition to those rights.

This manual is also suitable for:

Gran maestria c520Gran maestria d520
