Summary of Contents for Toyota FJ CRUISER 2010

  • Page 1: Quick Reference

    FJ CRUISER CUSTOMER EXPERIENCE CENTER 2 0 1 0 1-800-331-4331 QUICK REFERENCE GUIDE Printed in U.S.A. 9/09 I n f o r ma t i o n P r o v i d e d b y : 00505-QRG10-FJC 08-TCS-03069...
  • Page 2 Tool location supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, Jack U.S.A., Inc. wish you many years of satisfied driving in your new FJ Cruiser.
  • Page 3: Table Of Contents

    Spare tire & tools Tire Pressure Monitoring (warning) System Visit your Toyota dealer for information on this and other customizable options. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 4 OVERVIEW Instrument panel Steering wheel controls (if equipped) Instrument panel light control Power rearview mirror controls* Clutch start cancel switch* Roll Sensing of Curtain shield Airbag OFF switch Tilt steering lock release Headlight and turn signal control Wiper and washer controls Ignition switch Emergency flasher button Clock...
  • Page 5 Rear differential lock button* Active traction control switch* Sub woofer ON-OFF button* Power outlet AUX audio jack Intuitive parking assist switch* Power outlet main switch* Cruise control* Hood release Volume control switch (for audio)* “ ” button (for audio)* “MODE” button (for audio)* * If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 6: Instrument Cluster

    OVERVIEW Instrument cluster Tachometer Service indicators and reminder Speedometer Voltmeter Automatic Transmission indicator Engine coolant temperature Fuel gauge Trip meter reset knob Odometer and two trip meters Indicator symbols Brake system warning Driver/Front passenger seat belt reminder (alarm will sound if speed is over 12 mph) Battery warning Low engine oil pressure warning Malfunction/Check Engine indicator...
  • Page 7 Airbag SRS warning Automatic Transmission fluid temperature warning Unengaged Park warning Low Tire Pressure Warning Engine immobilizer system indicator Front passenger occupant classification indicator Headlight high beam indicator Turn signal indicator Automatic Transmission indicator Rear differential lock indicator Center differential lock indicator Vehicle Stability Control OFF indicator Four-wheel drive indicator Slip indicator...
  • Page 8: Keyless Entry 1

    OVERVIEW Fuel tank door release and cap NOTE: Tighten Turn until one click is heard. If the cap is Pull not tightened enough, Check Engine “ ” indicator may illuminate. Keyless entry (if equipped) Beep sound can be switched ON or OFF. Refer to the Owner’s Manual for more details.
  • Page 9: Hood Release

    Hood release Pull up latch and raise hood Pull Engine maintenance Windshield washer fluid tank Power steering fluid reservoir Engine oil level dipstick Engine coolant reservoir Engine oil filler cap NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Warranty Maintenance Guide.”...
  • Page 10: Automatic Transmission

    FEATURES/OPERATIONS Automatic Transmission (if equipped) Park* Reverse Neutral Drive Fourth gear Third gear Second gear First gear * The key must be in the “ON” position and the brake pedal depressed to shift from Park. Downshifting increases power going uphill, or provides engine braking downhill.
  • Page 11: Four-Wheel Drive

    Four-wheel drive (if equipped) Part-time four-wheel drive models High speed (2WD) High speed (4WD) Shift to “H4” with speed below 50 mph. Low speed (4WD) Stop vehicle, shift to “N” position, then move the lever to “L4.” NOTE: For best fuel economy and performance under normal driving conditions, shift vehicle into “H2”...
  • Page 12: Parking Brake

    FEATURES/OPERATIONS Parking brake Release (2) Push (1) Pull slightly Pull (3) Lower Seat adjustments-Front Seat position (forward/backward) Cushion angle (driver side only) Height crank (driver side only) Seatback angle Seats-Head restraints Lock release button I n f o r ma t i o n P r o v i d e d b y :...
  • Page 13: Seats-Folding Rear Seats

    Seats-Folding rear seats (4) Pull up (1) Push (2) Remove (5) Push down (3) Stow (6) Fold-down Seats-Removing rear seats (2) Loosen (1) Pull up (3) Separate (4) Fold I n f o r ma t i o n P r o v i d e d b y :...
  • Page 14 FEATURES/OPERATIONS Lights & turn signals Headlights Low beam Headlights High beam flasher Parking lights High beam -Automatic light cutoff system Automatically turns lights off after 30 seconds when all doors are closed with the key in “ACC” or “LOCK.” Lights may also be turned off by pushing lock button on remote after locking.
  • Page 15: Door-Back

    Windows Driver side Windows lock switch Down Automatic down operation (driver side only) Push the switch completely down and release to fully open. To stop window at any point, lightly pull the switch up. Window lock switch Deactivates all passenger windows. Driver’s window remains operable.
  • Page 16 FEATURES/OPERATIONS Audio Type 1 Eject CD Preset buttons-functions in other modes indicated above number. Push to turn ON/OFF Push to adjust tone & balance Seek station/ Push to skip CD track select up/down folder Station/CD track scan Mode View radio and CD information Type 2 Eject CD Mode...
  • Page 17 RADIO Preset buttons Tune in the desired station and press a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select. “SCAN” Push and hold “SCAN” to scan preset stations. Push again to hold selection. Steering wheel switches (if equipped) Volume control “...
  • Page 18: Clock

    FEATURES/OPERATIONS Air Conditioning/Heating Fresh or recirculated cabin air Air Conditioning ON/OFF Airflow vent In “ ” mode, use fresh air (“ ” indicator OFF) to reduce window fogging. “ ” mode uses fresh air only. Temperature selector Fan speed Rear window defogger Clock H- Hour set M- Minute set...
  • Page 19: Cruise Control

    Cruise control (if equipped) Turning system ON/OFF Functions Resume /Increase Cancel speed System ON/OFF Set/Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed exceeds 25 mph. Intuitive parking assist (if equipped) ON/OFF switch When vehicle is in reverse, a buzzer will sound to inform driver when...
  • Page 20: Power Outlet-12V Dc

    FEATURES/OPERATIONS VSC OFF button VSC OFF button The VSC OFF button is used to switch between modes related to the TRAC, VSC and Auto LSD functions. Refer to Section 2-4 of the Owner’s Manual for more information. Power outlet-12V DC Instrument panel Key must be in the “ACC”...
  • Page 21: Bottle Holders-Rear Seat

    Bottle holders-Rear seat Cup holders Automatic Manual Transmission models Transmission models Rear console I n f o r ma t i o n P r o v i d e d b y :...
  • Page 22: Safety And Emergency Features

    SAFETY AND EMERGENCY FEATURES Seat belts Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. This feature is used to help hold child restraint systems securely.
  • Page 23 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Two Wheel Drive Four Wheel Drive Anti-Lock Brake System Accessory AI-SHIFT Artificial Intelligence shifting Automatic Locking Retractor A-TRAC Active Traction Control AUTO LSD Automatic Limited Slip Differential Child Restraint System English/U.S. Customary System and metric Electronic Control Unit Event Data Recorder Emergency Locking Retractor...
  • Page 24 ABBREVIATIONS MEANING Tire Identification Number TPMS Tire Pressure Warning System TRAC Traction Control Treadwear indicators Vehicle Identification Number Vehicle Stability Control I n f o r ma t i o n P r o v i d e d b y :...
  • Page 25 TABLE OF CONTENTS Index 1-6. Theft deterrent system Before driving Engine immobilizer system ........ 77 Theft prevention labels 1-1. Key information (U.S.A.)....... 79 Keys ........28 1-7. Safety information 1-2. Opening, closing and locking Correct driving posture ..80 the doors SRS airbags ......
  • Page 26 2-3. Operating the lights and Interior features wipers Headlight switch....145 Windshield wipers and 3-1. Using the air conditioning washer ......147 system and defogger Rear window wiper and Air conditioning system ..204 washer ......149 Rear window defogger ..210 2-4.
  • Page 27 TABLE OF CONTENTS Index 3-5. Other interior features 4-3. Do-it-yourself maintenance Sun visors ......254 Do-it-yourself service precautions ....... 289 Vanity mirrors ..... 255 Hood ........293 Clock ........256 Engine compartment ..294 Outside temperature display ......257 Tires........308 Power outlet (12V DC) ..
  • Page 28 5-2. Steps to take in an emergency For owners If a warning light turns on or a warning buzzer sounds......354 Reporting safety defects If you have a flat tire.... 364 for U.S. owners ....416 If the engine will not start ..376 Seat belt instructions for If the shift lever cannot be Canadian owners...
  • Page 29: For Your Information

    Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
  • Page 30 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
  • Page 31 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
  • Page 32 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 33 I n f o r ma t i o n P r o v i d e d b y :...
  • Page 34: Before Driving

    TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
  • Page 35 Pictorial index Exterior Outside rear view mirror ∗ illumination lights P. 145 Windshield wipers P. 147 Hood P. 293 Outside rear view mirrors P. 68 Headlights P. 145 Front turn signal/parking and front side marker lights P. 133, 145 I n f o r ma t i o n P r o v i d e d b y :...
  • Page 36 Stop/tail and rear side marker lights P. 145 Fuel filler door P. 73 Access doors P. 36 Side doors P. 33 Tires ●Rotation P. 308 ●Replacement P. 364 ●Inflation pressure P. 313 Rear turn signal lights P. 133 ●Information P. 401 ∗...
  • Page 37 Pictorial index Exterior Glass hatch P. 43 ∗ Rear window wiper P. 149 Rear window defogger P. 210 Back door P. 38 License plate lights P. 145 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 38 I n f o r ma t i o n P r o v i d e d b y :...
  • Page 39 Pictorial index Interior Seat belts P. 57 Head restraints P. 54 SRS driver airbag P. 82 Horn P. 136 Bottle holders P. 252 Auxiliary box P. 253 SRS front passenger airbag P. 82 Rear seats P. 49 Floor mats P. 266 Cup holders Front seats P.
  • Page 40 Sun visors Interior lights P. 245 P. 254 Vanity mirrors P. 255 SRS curtain shield airbags P. 82 Personal lights P. 246 Anti-glare inside rear view mirror P. 64 ∗ Rear view monitor system P. 158 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 41 Pictorial index Interior Inside door lock button P. 34 Door lock switch P. 33 Window lock switch P. 71 Power window switches P. 71 I n f o r ma t i o n P r o v i d e d b y :...
  • Page 42 Automatic transmission Front-wheel drive control Shift lever P. 129 Cup holders ∗ lever P. 164 P. 248 Parking brake lever P. 134 Shift lock override Cup holders P. 248 button P. 377 Manual transmission Four-wheel drive control Shift lever P. 131 lever P.
  • Page 43: Instrument Panel

    Pictorial index Instrument panel Headlight switch P. 145 Turn signal lever P. 133 Gauges and meters P. 137 Windshield wipers and washer switch P. 147 Rear window wiper and ∗ washer switch P. 149 ∗ Accessory meter P. 143 Glove box P.
  • Page 44 Clock P. 256 Emergency flasher switch P. 344 Audio system P. 211 Security indicator P. 77 Air conditioning system P. 204 Rear window defogger switch P. 210 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 45 Pictorial index Instrument panel VSC OFF switch P. 168, 175, 176 ∗ RR DIFF LOCK switch P. 170 ∗ A-TRAC switch P. 166 ∗ SUB WOOFER switch P. 238 Power outlet P. 258 AUX adapter P. 240 ∗ Intuitive parking assist switch P.
  • Page 46 Engine (ignition) switch P. 126 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 47 Pictorial index Instrument panel ∗ Audio remote control switches P. 242 I n f o r ma t i o n P r o v i d e d b y :...
  • Page 48 Instrument panel light control dial P. 138 Tilt steering lock release lever P. 63 RSCA OFF switch P. 93 ∗ CLUTCH START CANCEL switch P. 173 ∗ Outside rear view mirror switches P. 68 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 49 Pictorial index Luggage compartment Child restraint anchor brackets P. 104 Tie-down hooks P. 268 I n f o r ma t i o n P r o v i d e d b y :...
  • Page 50 Shopping bag hooks P. 270 Cargo net hooks P. 269 Jack Tools P. 364 P. 364 Shopping bag hooks P. 270 Cargo net hooks P. 269 Luggage storage P. 267 ∗ Power outlet P. 259 ∗ : If equipped : Vehicles without sub woofer I n f o r ma t i o n P r o v i d e d b y :...
  • Page 51: Key Information

    Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 378) ■...
  • Page 52 1-1. Key information NOTICE ■ To prevent key damage ● Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. ● Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.
  • Page 53: Opening, Closing And Locking

    1-2. Opening, closing and locking the doors ∗ Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.
  • Page 54 When the wireless key has been left near an electrical appliance such as a personal computer ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control system) can be changed. (Customizable features →P. 412) I n f o r ma t i o n P r o v i d e d b y :...
  • Page 55 1-2. Opening, closing and locking the doors ■ Certification for wireless remote control For vehicles sold in U.S.A. FCC ID: HYQ12BBT FCC ID: HYQ13BBL NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 56: Side Doors

    1-2. Opening, closing and locking the doors Side doors The vehicle can be locked/unlocked using the wireless remote con- trol, key or door lock switch. ■ Wireless remote control (if equipped) →P. 30 ■ Locks all doors Unlocks all doors Turning the key a single time in the driver’s door unlocks the driver’s door,...
  • Page 57 A buzzer sounds if the driver’s door is opened, while the engine switch is in the ACC or LOCK position to remind you to remove the key. ■ Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customizable features →P. 412)
  • Page 58 1-2. Opening, closing and locking the doors CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
  • Page 59: Access Doors

    1-2. Opening, closing and locking the doors Access doors The access door (rear door) can be opened using the inside handle. Open the front door widely Pull (from the outside) or push (from the inside) the inside handle of the access door.
  • Page 60 1-2. Opening, closing and locking the doors NOTICE ■ When opening or closing the front door and access door The front door and access door could be damaged if they hit each other when being opened or closed. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 61: Back Door

    1-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked using a key, wireless remote control or door lock switch. ■ Wireless remote control (if equipped) →P. 30 ■ Unlocks the back door Locks the back door Opens the back door When you turn the key clock- wise and hold it for about 1...
  • Page 62 1-2. Opening, closing and locking the doors ■ Back door fixing function The back door can be held in the following positions: Half open position Open the back door to the half open position. It cannot be held in this posi- tion when being closed.
  • Page 63 1-2. Opening, closing and locking the doors Rear step bumper For rear end protection and eas- ier step-up loading. To get on the rear step bumper, use the shaded area in the illus- tration. CAUTION ■ Caution while driving ● Keep the back door closed while driving.
  • Page 64 Doing so may cause hands to be caught or the back door damper stay to break, causing an accident. ● Do not attach any accessories other than genuine Toyota parts to the back door. Such additional weight on the back door may cause the back door to closed again after it is opened.
  • Page 65 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply vertical forces to it.
  • Page 66: Glass Hatch

    1-2. Opening, closing and locking the doors Glass hatch The glass hatch can be opened using the key. Turn the key clockwise and hold it for about 1 second. Raise ■ Opening the glass hatch ● The glass hatch opens slightly, after the back door is locked. ●...
  • Page 67 1-2. Opening, closing and locking the doors CAUTION ■ Caution while driving ● Keep the glass hatch closed while driving. If the glass hatch is left open, it may hit near-by objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
  • Page 68 Doing so may cause hands to be caught or the glass hatch damper stay to break, causing an accident. ● Do not attach any accessories other than genuine Toyota parts to the glass hatch. Such additional weight on the glass hatch may cause the glass hatch to fall closed again after it is opened.
  • Page 69 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the glass hatch. ● Do not place your hand on the damper stay or apply lateral forces to it.
  • Page 70: Adjustable Components

    1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seat cushion angle adjust- ment knob (driver’s side only) Seat height adjustment lever (driver’s side only) Seatback angle adjustment lever Active head restraints When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for-...
  • Page 71 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may show the head restraint inner structure. These do not indicate problems. During rear-end collision...
  • Page 72: Rear Seats

    1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats The seatbacks of the rear seats can be folded down. Stow the seat belt buckles and remove the head restraints. Swing the bottom cushion up by pulling the lock release strap. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 73 1-3. Adjustable components (seats, mirrors, steering wheel) Push the lock release button and fold down the seatback. Removing rear seat bottom cushions Loosen the bolts with the wrench at first and turn the dials with hands to remove them. Hexagon head bolt Dial I n f o r ma t i o n P r o v i d e d b y :...
  • Page 74 1-3. Adjustable components (seats, mirrors, steering wheel) Separate the bottom cushion from the hinge. Fold the hinge as shown in the illustration. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 75 1-3. Adjustable components (seats, mirrors, steering wheel) ■ If you cannot raise the seatback Release the seat belt lock by: Pushing on the lower front edge of the seatback to slacken the seat belt. Let the seat belt retract a little. ■...
  • Page 76 Have the hexagon head bolts tightened with a torque wrench to 12.5 ft·lbf (17 N·m, 1.7 kgf·m), or have them tightened by your Toyota dealer. Failure to do so may cause the dials to be loosened and the bottom cush- ions to be removed.
  • Page 77: Head Restraints

    1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pushing the lock release Lock release button button. Rear seats Vertical adjustment Pull the head restraints up.
  • Page 78 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats Pull the head restraint up while pushing the lock release button. ■ Installing the head restraints Front seats Align the head restraint with the installa- tion holes and push it down to the lock position.
  • Page 79 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the rear seat head restraints Always raise the head restraint one level from the stowed position when using. CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury.
  • Page 80: Seat Belts

    1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
  • Page 81 1-3. Adjustable components (seats, mirrors, steering wheel) Releasing the belt Press the release button. Release button ■ Adjusting the height of the belt (front seats) Move the height adjuster up as needed until you hear a click. Down Push the lock release button and slide the height adjuster down.
  • Page 82 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
  • Page 83 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
  • Page 84 ● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
  • Page 85 ● Do not attempt to install, remove, modify, disassemble or dispose of the seat belts. Have any necessary repairs carried out by your Toyota dealer. Inappropriate handling of the pretensioner may prevent it from operating properly resulting in death or serious injury.
  • Page 86: Steering Wheel

    1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and pull and hold the lever. Adjust to the ideal position by moving the steering wheel vertically. After adjustment, release the lever to secure the steering wheel.
  • Page 87: Anti-Glare Inside Rear View Mirror

    1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position I n f o r ma t i o n P r o v i d e d b y :...
  • Page 88 1-3. Adjustable components (seats, mirrors, steering wheel) Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Turns automatic mode on/off The indicator comes on when automatic mode is turned on.
  • Page 89 1-3. Adjustable components (seats, mirrors, steering wheel) ■ If a sun visor interferes with the mirror Hold and rotate the mirror to adjust the support. CAUTION ■ Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.
  • Page 90 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE ■ When adjusting the support Do not push the mirror horizontally from the side. The mirror could fall off. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 91: Outside Rear View Mirrors

    1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted. Power-adjustable type Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch. Manually adjustable type Adjust the mirror up, down, in or out by pushing the mirror surface.
  • Page 92 1-3. Adjustable components (seats, mirrors, steering wheel) Folding back the mirrors Push backward to fold the mir- rors. ■ Mirror operating conditions (vehicles with power-adjustable type) The engine switch is in the ACC or ON position. CAUTION ■ When driving the vehicle Observe the following precautions while driving.
  • Page 93 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE ■ If ice should jam the mirror Do not operate the control or scrape the mirror face. Use a spray de-icer to free the mirror. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 94: Opening And Closing The Windows

    1-4. Opening and closing the windows Power windows The power windows can be opened/closed using the following switches. Driver’s power window switches Closing Opening One-touch opening (driver’s window only) Pressing the switch in the opposite direction will stop win- dow travel partway. Front passenger’s power window switch Closing Opening...
  • Page 95 1-4. Opening and closing the windows ■ The power windows can be operated when The engine switch is in the ON position. ■ Operating the power windows after turning the engine switch off The power windows can be operated for approximately 45 seconds even after the engine switch is turned off.
  • Page 96: Refueling Opening The Fuel Tank Cap

    1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Turn the engine switch off and ensure that all the doors, win- dows and glass hatch are closed. ■...
  • Page 97 1-5. Refueling Closing the fuel tank cap When installing the fuel tank cap, turn it until you hear a click. The cap will turn slightly to the opposite direction when released. ■ Fuel types Use unleaded gasoline. (Octane Rating 87 [Research Octane Number 91] or higher) ■...
  • Page 98 ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
  • Page 99 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle's painted surface. ■ To prevent damage to the fuel filler door Do not apply excessive force.
  • Page 100: Theft Deterrent System

    1-6. Theft deterrent system Engine immobilizer system The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The security indicator light flashes after the key has been removed...
  • Page 101 1-6. Theft deterrent system For vehicles sold in Canada This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 102: Theft Prevention Labels (U.s.a.)

    1-6. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 103: Safety Information

    1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 47) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 104 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver's seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
  • Page 105: Srs Airbags

    1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 106 1-7. Safety information Airbag system components Front passenger airbag Side and curtain shield air- bag sensors Curtain shield airbags Driver airbag Side airbags RSCA OFF switch Occupant detection system (ECU and sensors) Driver’s seat position sen- Front passenger’s seat belt buckle switch Driver’s seat belt buckle switch...
  • Page 107 1-7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on US motor vehicle safety standards (FMVSS208). The airbag sys- tem controls airbag deployment power for the driver and front pas- senger. The driver airbag system consists of the driver seat’s position sensor etc.
  • Page 108 1-7. Safety information ■ Operating conditions (front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to a 12-18 mph [20-30 km/h] frontal collision with a fixed wall that does not move or deform).
  • Page 109 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
  • Page 110 1-7. Safety information ■ Types of collisions that may not deploy the SRS airbag (side airbags and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
  • Page 111 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the battery cables before contacting your Toyota dealer. ● Any of the SRS airbags have been inflated.
  • Page 112 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
  • Page 113 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
  • Page 114 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
  • Page 115 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 116 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
  • Page 117 1-7. Safety information ■ The switch only should be used In a situation where inflation is not desired (such as during extreme off-road driving). ■ Operating conditions when the RSCA OFF indicator is on ● The curtain shield airbag and seat belt pretensioner will not activate in a vehicle rollover.
  • Page 118: Front Passenger Occupant Classification System

    1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light Front passenger’s seat belt reminder light AIR BAG ON indicator light...
  • Page 119 1-7. Safety information Condition and operation in the front passenger occupant classification system ■ Adult AIR BAG ON and AIR BAG OFF indicator AIR BAG ON lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seat Devices...
  • Page 120 1-7. Safety information ■ There is a malfunction in the system AIR BAG ON and AIR BAG OFF indicator AIR BAG lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front passenger side...
  • Page 121 1-7. Safety information CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
  • Page 122 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
  • Page 123: Child Restraint Systems

    1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
  • Page 124 1-7. Safety information Forward facing — Convertible seat Booster seat ■ Selecting an appropriate child restraint system ● Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belts. ●...
  • Page 125 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 126 1-7. Safety information CAUTION ■ Child restraint precautions ● Make sure you have complied with all installation instructions provided by the child restraint manufacturer and that the system is properly secured. If it is not secured properly, it may cause death or serious injury to the child in the event of sudden braking, sudden swerving or an accident.
  • Page 127: Installing Child Restraints

    1-7. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
  • Page 128 1-7. Safety information Anchor bracket (for top tether strap) Anchor brackets are provided for all rear seats. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 129 1-7. Safety information Installation with LATCH system Type A Widen the gap between the seat cushion and seatback slightly. Latch the hooks of the lower straps onto the LATCH anchors tighten the lower straps. If the child restraint has a top tether strap, the top tether strap should be latched...
  • Page 130 1-7. Safety information Type B Widen the gap between the seat cushion and seatback slightly. Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchor. (→P.
  • Page 131 1-7. Safety information Run the seat belt through the child seat and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode.
  • Page 132 1-7. Safety information Run the seat belt through the child seat and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode.
  • Page 133 1-7. Safety information ■ Booster seat Place the booster seat on the seat facing the front of the vehi- cle. Sit the child in the booster seat. Fit the seat belt to the booster seat according to the manufac- turer's instructions and insert the plate into the buckle.
  • Page 134 1-7. Safety information Child restraint systems with a top tether strap Secure the child restraint using the LATCH anchors or seat belt, and remove the head restraint. Raise the anchor bracket, latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched.
  • Page 135 1-7. Safety information ■ When the anchor bracket is not in use Lower the anchor bracket. The anchor bracket is only designed to secure the top tether strap. Do not use the anchor bracket for any other pur- pose. CAUTION ■...
  • Page 136 1-7. Safety information CAUTION ■ When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving or an accident.
  • Page 137 1-7. Safety information CAUTION ■ Do not use a seat belt extender If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of sud- den braking, sudden swerving or an accident.
  • Page 138: Driving Procedures

    2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine (→P. 126) ■ Driving Automatic transmission With the brake pedal depressed, shift the shift lever to D. (→P. 129) Release the parking brake.
  • Page 139 2-1. Driving procedures ■ Parking the vehicle Automatic transmission With the shift lever in D, depress the brake pedal. Set the parking brake. (→P. 134) Shift the shift lever to P. (→P. 129) When parking on a hill, if necessary, block the wheels. Turn the engine switch off to stop the engine.
  • Page 140 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or when- ever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding down.
  • Page 141 Have the vehicle inspected by your Toyota dealer immediately. ● On vehicles with an automatic transmission, do not shift the shift lever to P while the vehicle is moving.
  • Page 142 2-1. Driving procedures CAUTION ● Do not shift the shift lever to R while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift lever to D (vehicles with an automatic transmission) or 1 (vehicles with a manual transmission) while the vehicle is moving back- ward.
  • Page 143 2-1. Driving procedures CAUTION ● Do not drive in excess of the speed limit. Even if the legal speed limit per- mits it, do not drive over 85 mph (140 km/h) unless your vehicle has high- speed capability tires. Driving over 85 mph (140 km/h) may result in tire failure, loss of control and possible injury.
  • Page 144 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
  • Page 145 2-1. Driving procedures CAUTION ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, you may accidentally move the shift lever or depress the accelerator pedal, which could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
  • Page 146 If you hear a squealing or scraping noise while driving (brake pad wear limit indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
  • Page 147 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. ● Brake function ●...
  • Page 148: Engine (Ignition) Switch

    2-1. Driving procedures Engine (ignition) switch ■ Engine switch LOCK The steering wheel is locked and the key can be removed. (Vehicles with an automatic transmission: The key can be removed only when the shift lever is in P.) Some electrical components such as the audio system can be used.
  • Page 149 2-1. Driving procedures ■ Turning the key from ACC to LOCK Shift the shift lever to P (auto- matic transmission) or N (man- ual transmission). (→P. 129, 131) Push in the key and turn to the LOCK position. ■ Steering lock release When starting the engine, the engine switch may seem stuck in the LOCK posi- tion.
  • Page 150 2-1. Driving procedures CAUTION ■ Caution while driving Do not turn the engine switch to the LOCK position. If in an emergency, you must turn the engine off while the vehicle is moving, turn the engine switch only to the ACC position. NOTICE ■...
  • Page 151: Automatic Transmission

    2-1. Driving procedures ∗ Automatic Transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the engine switch is on, depress the brake pedal and move the shift lever. ■ Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing...
  • Page 152 2-1. Driving procedures ■ Downshifting restrictions The shift lever cannot be downshifted if the following speeds are exceeded. 2WD models Maximum speed Downshifting mph (km/h) 4 → 3 91 (148) 3 → 2 61 (99) 2 → L 25 (41) 4WD models Maximum speed Downshifting...
  • Page 153: Manual Transmission

    2-1. Driving procedures ∗ Manual Transmission Fully depress the clutch pedal before operating the shift lever, and then release it slowly. ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 154 2-1. Driving procedures ■ Maximum allowable speed Observe the following maximum allowable speeds in each gear when maxi- mum acceleration is necessary. Maximum speed Shift position Transfer position mph (km/h) H or HL 30 (48) 11 (18) H or HL 58 (93) 22 (35) H or HL...
  • Page 155: Turn Signal Lever

    2-1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
  • Page 156: Parking Brake

    2-1. Driving procedures Parking brake ■ Set the parking brake Fully set the parking brake while depressing the brake pedal. At this time, the indicator will come on. ■ Release the parking brake Slightly raise the lever Press the button Lower it completely I n f o r ma t i o n P r o v i d e d b y :...
  • Page 157 2-1. Driving procedures ■ Usage in winter time See “Winter driving tips” for parking brake usage in winter time. (→P. 188) NOTICE ■ Before driving Fully release the parking brake. Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear.
  • Page 158: Horn

    2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
  • Page 159: Instrument Cluster Gauges And Meters

    2-2. Instrument cluster Gauges and meters The following gauges, meters and displays illuminate when the engine switch is in the ON position. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Voltmeter Displays the charge state. Engine coolant temperature gauge Displays the engine coolant temperature.
  • Page 160 2-2. Instrument cluster Odometer/trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display differ- ent distances independently.
  • Page 161 2-2. Instrument cluster NOTICE ■ To prevent damage to the engine and its components ● Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed. ● The engine may be overheating if the temperature gauge is in the red zone (H).
  • Page 162: Indicators And Warning Lights

    2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Center panel I n f o r ma t i o n P r o v i d e d b y :...
  • Page 163 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Active traction control Turn signal indicator system indicator (→P. 133) (→P. 166) (if equipped) Headlight high beam AUTO LSD indicator indicator (→P. 145) (→P.
  • Page 164: Warning Lights

    There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
  • Page 165: Accessory Meter

    2-2. Instrument cluster ∗ Accessory meter Compass Displays the direction that the vehicle is heading. (→P. 271) Outside temperature Displays the outside air temperature. (→P. 257) Clinometer Displays the longitudinal and lateral inclination of the vehicle. SET button This button is used to calibrate the compass. (→P. 272) E/M button Outside temperature mode: Switch between English/U.S.
  • Page 166 2-2. Instrument cluster CAUTION ■ Caution while driving Do not adjust the display. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 167: Operating The Lights And Wipers

    2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually. The side marker, park- ing, tail, license plate, outside rear view mir- illumination equipped) and instru- ment panel lights turn The headlights and all lights listed above turn Turning on the high beam headlights With the headlights on, push the lever forward to turn on the...
  • Page 168 To turn the lights on again, turn the engine switch to the ON position, or turn the headlight switch off once and then back to the position. ■ Customization that can be configured at Toyota dealer Settings (automatic light off system) can be changed. (Customizable features →P. 412) NOTICE ■...
  • Page 169: Windshield Wipers And Washer

    2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation (when INT is selected.) Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Decreases the intermittent windshield wiper frequency Increases the intermittent windshield wiper frequency I n f o r ma t i o n P r o v i d e d b y :...
  • Page 170 ■ When a nozzle becomes blocked In this case, contact your Toyota dealer immediately. Do not try to clear it with a pin or other object. The nozzle will be damaged. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 171: Rear Window Wiper And Washer

    2-3. Operating the lights and wipers ∗ Rear window wiper and washer Intermittent window wiper operation. The wiper operates 3 times at normal speed and then moves to intermittent mode. Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion The rear window wiper oper- ates while the washer squirts.
  • Page 172: Using Other Driving Systems

    2-4. Using other driving systems ∗ Cruise control Use cruise control to maintain a set speed without using the acceler- ator. Indicator Cruise control switch ■ Set the vehicle speed Press the ON-OFF button to turn the cruise control on. At this time, the cruise control indicator will come on.
  • Page 173 2-4. Using other driving systems ■ Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed (approximately 1.0 mph [1.6 km/h]) can be made by lightly pushing the lever up or down and releasing it.
  • Page 174 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. CAUTION ■...
  • Page 175: Intuitive Parking Assist

    2-4. Using other driving systems ∗ Intuitive parking assist The intuitive parking assist assists the driver by communicating the distance to obstacles measured by the sensors via the buzzer when parallel parking or maneuvering into a garage. Always check the sur- rounding area when using this system.
  • Page 176 2-4. Using other driving systems ■ Intuitive parking assist switch ON/OFF When on, the buzzer sounds to inform the driver that the system is operational. At this time, the indicator will come Press the switch to switch the ON/OFF mode. The distance and buzzer When a sensor detects an obstacle, the buzzer sounds.
  • Page 177 2-4. Using other driving systems Sensors that operate and detection range The following diagrams show the sensor detection range. Note that sensors may not be able to detect obstacles that are extremely close to the vehicle. ■ Detection range of the sensors Approx.
  • Page 178 Objects lower than the sensors or thin stakes etc. may be detected ini- tially, but as they draw closer, they may cease to be detected. • A towing hitch is mounted to the vehicle. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. • When attaching a two-way radio antenna.
  • Page 179 2-4. Using other driving systems ● The shape of the obstacle may prevent a sensor from detecting it. Pay particular attention to the following obstacles: • Wires, fences, ropes, etc. • Cotton, snow and other materials that absorb radio waves •...
  • Page 180: Rear View Monitor System (Vehicles With Auto Anti-Glare Inside Rear View Mirror)

    2-4. Using other driving systems Rear view monitor system (vehicles with auto anti-glare inside rear view mirror) The rear view monitor system assists the driver by displaying an image of the area behind the vehicle. The image is displayed in reverse on the screen.
  • Page 181 2-4. Using other driving systems ■ Switching the screen ON/OFF mode When the screen is displayed, press the AUTO button on the inside rear view mir- ror to switch the screen ON/OFF mode. Screen ON mode: Green indicator comes Screen OFF mode: Orange indicator comes on.
  • Page 182 2-4. Using other driving systems ■ Rear view monitor system camera In the following cases, it may become dif- ficult to see the images on the screen, even when the system is functioning cor- rectly. ● The vehicle is in a dark area, such as at night.
  • Page 183 Conditions which may affect the rear view monitor system ● If the back of the vehicle has been hit, the camera’s position and mounting angle may have changed. Have the vehicle inspected by your Toyota dealer. ● Rapid temperature changes, such as when hot water is poured on the vehicle in cold weather, may cause the system to function abnormally.
  • Page 184: Four-Wheel Drive System (4Wd Models With A Manual Transmission)

    2-4. Using other driving systems Four-wheel drive system (4WD models with a manual transmission) Use the four-wheel drive control lever to select the following transfer modes. The center differential lock indicator comes on when the LL or HL mode is selected.
  • Page 185 2-4. Using other driving systems ■ Shifting between H and HL ● You need not to depress the clutch pedal. ● If the center differential lock indicator does not come on when you shift from H to HL, drive straight ahead while accelerating or decelerating. ●...
  • Page 186: Four-Wheel Drive System (4Wd Models With An Automatic Transmission)

    2-4. Using other driving systems Four-wheel drive system (4WD models with an automatic transmission) Use the front-wheel drive control lever to select the following trans- fer modes. The four-wheel drive indicator comes on when the H4, N or L4 mode is selected.
  • Page 187 2-4. Using other driving systems ■ Shifting between H2 and H4 ● Reduce your speed to less than 50 mph (80 km/h) and shift the front- wheel drive control lever from H2 to H4. If you have trouble shifting in cold weather, reduce your speed or stop the vehicle.
  • Page 188: Active Traction Control System

    2-4. Using other driving systems ∗ Active traction control system The active traction control system automatically helps prevent the spinning of 4 wheels when the vehicle is started or accelerated on slippery road surfaces. ■ System operation Vehicles with an automatic transmission: Stop the vehicle, shift the shift lever to N and shift the front- wheel drive control lever into L4.
  • Page 189 2-4. Using other driving systems ■ When the rear differential is locked (vehicles with the rear differential lock system) The active traction control system is activated only when the vehicle speed is less than 4 mph (6 km/h). ■ Sounds and vibrations caused by the active traction control system ●...
  • Page 190: Auto Lsd System (2Wd Models)

    2-4. Using other driving systems AUTO LSD system (2WD models) The AUTO LSD system aids traction by using the traction control system to control engine performance and braking when one of the rear wheels begins to spin. The system should be used only when wheel spinning occurs in a ditch or rough surface.
  • Page 191 2-4. Using other driving systems ■ If the engine is turned off and restarted The AUTO LSD system and the indicators are automatically turned off. ■ Automatic VSC reactivation If the AUTO LSD system is turned on and the vehicle speed decreases, the vehicle speed increases the VSC system will turn on and the VSC OFF indi- cator will turn off.
  • Page 192: Rear Differential Lock System

    2-4. Using other driving systems ∗ Rear differential lock system The rear differential lock system is provided for use only when wheel spinning occurs in a ditch or on a slippery or rugged surface. The rear differential lock system is effective in case one of the rear wheels is spinning.
  • Page 193 2-4. Using other driving systems Manual transmission Before using the rear differential lock system. Stop the vehicle or reduce your speed to less than 5 mph (8 km/h). Depress the clutch pedal and shift the four-wheel drive control lever into LL to see if this is sufficient. If this has no effect, additionally use the rear differential lock system.
  • Page 194 2-4. Using other driving systems CAUTION ■ To avoid an accident ● Do not use the rear differential lock system except when wheel spinning occurs in a ditch or on a slippery or ragged surface. Large steering effort and careful cornering control will be required. ●...
  • Page 195: Clutch Start Cancel Switch (Vehicles With A Manual Transmission)

    2-4. Using other driving systems Clutch start cancel switch (vehicles with a manual transmission) The switch allows the vehicle to be driven out of difficult situations by cranking the engine with the clutch engaged. Never use the switch for normal engine starting. Be sure to follow the starting procedure.
  • Page 196: Driving Assist Systems

    2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
  • Page 197 2-4. Using other driving systems To disable TRAC and/or VSC (2WD models) If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. ■...
  • Page 198 2-4. Using other driving systems To disable TRAC and/or VSC (H2 and H4 mode [automatic transmission] or H and HL mode [manual transmission] on 4WD models) If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels.
  • Page 199 2-4. Using other driving systems ■ Automatic TRAC and VSC reactivation If the TRAC and VSC systems are turned off, the systems will not turn on, even when vehicle speed increases. ■ Sounds and vibrations caused by the ABS, TRAC, VSC and brake assist system ●...
  • Page 200 In addition, make sure that the tires are inflated to the appro- priate tire pressure level. The ABS and VSC will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
  • Page 201: Driving Information

    2-5. Driving information Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
  • Page 202 2-5. Driving information CAUTION ■ Off-road vehicle precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
  • Page 203 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
  • Page 204 2-5. Driving information CAUTION ■ Off-road driving precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
  • Page 205 2-5. Driving information NOTICE ■ To prevent the water damage ● Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
  • Page 206: Cargo And Luggage

    2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ●...
  • Page 207 2-5. Driving information (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Example on your vehicle Cargo capacity Total load capacity...
  • Page 208 2-5. Driving information CAUTION ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment. ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury.
  • Page 209: Vehicle Load Limits

    2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. ■ Total load capacity: 1130 lb. (510 kg) Total load capacity means the combined weight of occupants, cargo and luggage. ■...
  • Page 210: Winter Driving Tips

    2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 211 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P (automatic trans- mission) or to 1 or R (manual transmission) without setting the parking brake.
  • Page 212 NOTICE ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
  • Page 213: Trailer Towing

    For your safety and the safety of others, do not overload the vehicle or trailer. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. ■...
  • Page 214 Total trailer weight Tongue load Towing a trailer Consult your Toyota dealer for further information about additional requirements such as a towing kits, etc. Hitch and tow hitch receiver ■ Hitch Trailer hitch assemblies have different weight capacities estab- lished by the hitch manufacturer.
  • Page 215 2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
  • Page 216 Break-in schedule ● Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bearings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
  • Page 217 ■ Hitches ● If you wish to install a trailer hitch, your Toyota dealer should be consulted. ● Use only a hitch that conforms to the total trailer weight requirement. ● Follow the directions supplied by the hitch manufacturer.
  • Page 218 NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Brakes Toyota recommends trailers with brakes that conform to any applicable fed- eral and state/provincial regulations.
  • Page 219 2-5. Driving information Trailer towing tips Your vehicle will handle differently when towing a trailer. The three main causes of vehicle-trailer accidents are driver error, excessive speed and improper trailer loading. Keep these in mind when towing. ● Before starting out, check the trailer’s light and the vehicle-trailer connections.
  • Page 220 2-5. Driving information ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a larger than normal turning radius. ● Crosswinds and rough roads will adversely affect handling of your vehicle and trailer, causing sway.
  • Page 221 2-5. Driving information ● Always place wheel blocks under both the vehicle and the trailer wheels when parking. Apply the parking brake firmly, and put the transmission in P (automatic transmission) or in 1 or R (manual transmission). Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
  • Page 222 2-5. Driving information CAUTION ■ To avoid an accident ● Do not exceed 45 mph (72 km/h) or posted towing speed limit, whichever is lower. As instability (swaying) of the towing vehicle-trailer combination increases as speed increases, exceeding 45 mph (72 km/h) may cause loss of control.
  • Page 223: Dinghy Towing

    2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 224 2-5. Driving information I n f o r ma t i o n P r o v i d e d b y :...
  • Page 225: Air Conditioning System

    3-1. Using the air conditioning system and defogger Air conditioning system Outside air or recirculated Air conditioning air mode switch ON/OFF switch Fan speed control dial Temperature control dial Air outlet selection dial Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool).
  • Page 226 3-1. Using the air conditioning system and defogger ■ Adjusting the fan speed Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Set the dial to OFF to turn the fan off. ■ Selecting the air outlets Set the air outlet selection dial to an appropriate position.
  • Page 227 3-1. Using the air conditioning system and defogger When the dial is set to , air flows to the feet and the wind- shield defogger operates. The air intake selector is automat- ically set to outside air mode. To return the recirculated air mode, press When the dial is set to , air...
  • Page 228 3-1. Using the air conditioning system and defogger ■ If the ambient temperature drops while using the recirculated air mode The air intake mode automatically changes from recirculated air mode to outside air mode after a few minutes. To cancel this function: Press and hold for longer than 2 seconds.
  • Page 229 3-1. Using the air conditioning system and defogger Right and left side outlets Direct air flow to the left or right, up or down. Opening and closing the right and left side outlets Open the vent. Close the vent. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 230 3-1. Using the air conditioning system and defogger ■ Using the system in recirculated air mode The windows will fog up more easily if the recirculated air mode is used for an extended period. ■ When outside air temperature approaches 32°F (0°C) The air conditioning system may not operate even when is pressed.
  • Page 231: Rear Window Defogger

    3-1. Using the air conditioning system and defogger Rear window defogger This feature is used to defog the rear window. On/off Press the button to turn on the rear window defogger. The indicator light will come on. The defogger will automatically turn off after 15 to 240 minutes.
  • Page 232: Using The Audio System

    3-2. Using the audio system Audio system types Type A: CD player with external CD changer controller and AM/FM radio Type B: CD player with changer and AM/FM radio Type A Type B I n f o r ma t i o n P r o v i d e d b y :...
  • Page 233 3-2. Using the audio system Title Page Using the radio P. 214 Using the CD player P. 220 Playing back MP3 and WMA discs P. 227 Optimal use of the audio system P. 235 Operating the sub woofer P. 238 Changing display color P.
  • Page 234 3-2. Using the audio system CAUTION ■ For vehicles sold in U.S.A. and Canada ● Part 15 of the FCC Rules FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device. ●...
  • Page 235: Using The Radio

    3-2. Using the audio system Using the radio Type A Power Volume Adjusting the Station selector frequency Scanning for receivable stations AM/FM mode buttons Seeking the frequency Type B Adjusting the frequency Power Volume (AM, FM mode) or channel (SAT mode) AM·SAT/FM mode buttons Scanning for receivable stations Display text message...
  • Page 236 3-2. Using the audio system ® Setting station presets (excluding XM Satellite Radio) Search for desired stations by turning ∧ pressing “ ” or “∨” on Press and hold the button (from ) that the station is to be set to until you hear a beep. ®...
  • Page 237 3-2. Using the audio system Turn to select the desired channel in the all catego- ∧ ries or press “ ” or “∨” on to select the desired channel in the current category. ® ■ Setting XM Satellite Radio channel presets Select the desired channel.
  • Page 238 3-2. Using the audio system ■ When the battery is disconnected Stations presets are erased. ■ Reception sensitivity ● Cargo loaded on the roof luggage carrier, especially metal objects, may ® adversely affect the reception of XM Satellite Radio. ● Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
  • Page 239 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to the XM Satellite Radio. The radio is being updated with the latest ®...
  • Page 240 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877-438-9677 (Canada).
  • Page 241: Using The Cd Player

    3-2. Using the audio system Using the CD player Type A Power Volume CD selection (with external CD changer only) Fast-forward CD eject Reverse Search playback Repeat play Display text message Random playback Track selection Playback Type B Power Volume Playback CD selection Fast-forward...
  • Page 242 3-2. Using the audio system Loading CDs ■ Loading a CD (type A) Insert a CD. ■ Loading a CD (type B) Press “WAIT” is shown on the display. Insert a CD when the indicator on the slot turns from amber to green.
  • Page 243 3-2. Using the audio system Press and remove the CD. ■ Ejecting all the CDs (type B only) Press and hold until you hear a beep, and then remove the CDs. Selecting and scanning a track ■ Selecting a track ∧...
  • Page 244 3-2. Using the audio system Repeat play ■ Repeating a track Press (RPT) or (RPT). ■ Repeating all of the tracks on a CD (with CD changer only) Press and hold (RPT) or (RPT) until you hear a beep. Random playback ■...
  • Page 245 3-2. Using the audio system ■ Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 charac- ters.
  • Page 246 3-2. Using the audio system ■ Lens cleaners Do not use lens cleaners. Doing so may damage the CD player. NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs or 3 in. (8 cm) CD adapters or Dual Disc.
  • Page 247 3-2. Using the audio system NOTICE ● CDs that have had tape, stickers or CD- R labels attached to them, or that have had the label peeled off ■ CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself.
  • Page 248: Playing Back Mp3 And Wma Discs

    3-2. Using the audio system Playing back MP3 and WMA discs Type A Power Volume File selection Fast-forward Folder selection Disc eject Reverse File selection Repeat play Display text message Search playback Playback Random playback Type B Power Volume File selection Disc selection Playback Fast-forward...
  • Page 249 3-2. Using the audio system Loading MP3 and WMA discs ■ Loading a disc (type A) Insert a disc. ■ Loading a disc (type B) Press “WAIT” is shown on the display. Insert a disc when the indicator on the slot turns from amber to green.
  • Page 250 3-2. Using the audio system ■ Ejecting all the discs (type B only) Press and hold until you hear a beep, and then remove the discs. Selecting a disc (type B only) ■ Selecting the desired disc ∧ Press (∨) or Selecting a folder ■...
  • Page 251 3-2. Using the audio system ■ Selecting the desired file by cueing the files in the folder Press The first 10 seconds of all files in the folder will be played. When the desired file is reached, press the switch once again. Fast-forwarding and reversing files To fast-forward or reverse.
  • Page 252 3-2. Using the audio system ■ Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 charac- ters.
  • Page 253 3-2. Using the audio system ■ Lens cleaners Do not use lens cleaners. Doing so may damage the MP3 and WMA player. ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression.
  • Page 254 3-2. Using the audio system ● Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
  • Page 255 3-2. Using the audio system ● Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
  • Page 256: Optimal Use Of The Audio System

    3-2. Using the audio system Optimal use of the audio system Type A Displays the current mode Changes the following set- ting Sound quality and volume balance (→P. 236) The sound quality and bal- ance setting can be changed to produce the best sound. Type B Using the AUDIO CONTROL function ■...
  • Page 257 3-2. Using the audio system ■ Adjusting sound quality Turning adjusts the level. Sound qual- Mode Turn to the Turn to the Level ity mode displayed left right Bass -5 to 5 High Treble -5 to 5 Front/rear Shifts to volume F7 to R7 Shifts to rear...
  • Page 258 3-2. Using the audio system ■ Trademark owned by New Transducers Limited This vehicle incorporates NXT flat panel speaker technology by New Transducers Limited, UK. is a registered trademarks of New Transducers Limited. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 259: Operating The Sub Woofer

    3-2. Using the audio system ∗ Operating the sub woofer Pressing the switch, to oper- ate the sub woofer. To stop it, press the switch again. ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 260: Changing Display Color (Type B Only)

    3-2. Using the audio system Changing display color (type B only) Display color can be changed by following the procedure below. Select the function of which you want to change the display color. Turn the audio system off by pressing Push for more than 5 seconds.
  • Page 261: Using The Aux Adapter

    3-2. Using the audio system Using the AUX adapter This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Connect the portable audio device. Type A Press I n f o r ma t i o n P r o v i d e d b y :...
  • Page 262 3-2. Using the audio system Type B Press ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls. All other adjustments must be made on the portable audio device itself. ■...
  • Page 263: Using The Steering Wheel Audio Switches

    3-2. Using the audio system ∗ Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio: Select radio stations Select tracks, files (MP3 and WMA) and discs Power on, select audio source Turning on the power...
  • Page 264 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “–” to decrease the volume. Press and hold “+” or “–” on to continue increasing or decreasing the volume. Selecting a radio station Press to select the radio mode.
  • Page 265: Using The Interior Lights

    3-3. Using the interior lights Interior lights list Rear interior light (→P. 245) Front interior light (→P. 245) Personal lights (→P. 246) Engine switch light ■ Illuminated entry system When the interior light switch is in the DOOR position, the interior light and engine switch light automatically turns on/off according to whether the doors are locked/unlocked and whether the doors are open/closed and the engine switch position.
  • Page 266: Interior Lights

    3-3. Using the hand-free phone system (for cellular system Interior lights ■ Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features →P. 412) Interior lights Front DOOR position...
  • Page 267: Personal Lights

    3-3. Using the hands-free phone system (for cellular phone) Personal lights Personal lights On/off ■ To prevent the battery from being discharged The personal lights will automatically turn off in about 30 minutes after the key is removed from the engine switch. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 268: Using The Storage Features

    3-4. Using the storage features List of storage features Glove box Auxiliary box Glove box Bottle holders Cup holders Glove box Pull up the lever. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 269: Cup Holders (Front)

    3-4. Using the storage features Glove box and cup holders (front) CAUTION ■ Caution while driving Keep the glove box closed. Injuries may result in the event of an accident or sudden braking. Cup holders (front) Vehicles with an automatic transmission I n f o r ma t i o n P r o v i d e d b y :...
  • Page 270 3-4. Using the storage features Cup holders (front) Vehicles with a manual transmission ■ Holding large cups Vehicles with an automatic transmission Remove the adapter. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 271 3-4. Using the storage features Cup holders (front) Vehicles with a manual transmission Remove the adapter. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 272: Cup Holders (Rear)

    3-4. Using the storage features Cup holders (rear) Cup holders (rear) ■ Removing the mat Pull up. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 273: Bottle Holders

    3-4. Using the storage features Bottle holders Bottle holders ■ Bottle holders Depending on their size or shape, some bottles may not fit in the holders. NOTICE ■ Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid.
  • Page 274: Auxiliary Box

    3-4. Using the storage features Auxiliary box Auxiliary box Push the button. Pull up the lid. CAUTION ■ Items that should not be left in the auxiliary box Do not leave anything flammable or deformable, such as a lighter or glasses in the box.
  • Page 275: Other Interior Features

    3-5. Other interior features Sun visors Front Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side Flip down. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 276: Vanity Mirrors

    3-5. Other interior features Vanity mirrors Open the cover. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 277: Clock

    3-5. Other interior features Clock Adjusts the hours Adjusts the minutes ■ The clock is displayed when The engine switch is in the ACC or ON position. ■ When disconnecting and reconnecting battery terminals The time display will automatically be set to 1:00. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 278: Outside Temperature Display

    System and metric. ■ When – –°C or – –°F is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ The outside air temperature is displayed when The engine switch is in the ON position.
  • Page 279: Power Outlet (12V Dc)

    3-5. Other interior features Power outlet (12V DC) The power outlet can be used for 12 V accessories that run on less than 10A. ■ The power outlet can be used when The engine switch is in the ACC or ON position. NOTICE ■...
  • Page 280: Power Outlet (115V Ac)

    3-5. Other interior features ∗ Power outlet (115V AC) The power outlet can be used for electrical appliances. ■ Operation Main switch To use the power outlet, turn on the main switch. The power supply starts a few seconds after the main switch is pressed.
  • Page 281 3-5. Other interior features Maximum available capacity of the power outlet ■ While the vehicle is being driven The maximum capacity of the power outlet is always 115V AC/ 100W. ■ When the vehicle is stationary The maximum capacity of the power outlet varies depending on the following conditions.
  • Page 282 3-5. Other interior features ■ The power outlet can be used when The engine is started. ■ The indicator light changes according the maximum available capacity, as follows: Indicates 115V AC/400W Indicates 115V AC/100W ■ When the power outlet is in operation The sound of the cooling fan may be heard from the right side of the luggage compartment.
  • Page 283 Do not modify, disassemble or repair the power outlet or its inverter, in any way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact a Toyota dealer for any necessary repairs. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 284 3-5. Other interior features CAUTION ■ To prevent injuries and accidents, securely fix all electric appliances before use and do not use any appliances that may do any of the fol- lowing: ● Distract the driver while driving, or hamper safe driving. ●...
  • Page 285 If the power outlet is loose when an electrical appliance plug is con- nected Replace the outlet. Contact a Toyota dealer for any necessary replacements. ■ If the power outlet gets dirty Turn the main switch off and use a soft, clean cloth to wipe it gently.
  • Page 286: Armrest

    3-5. Other interior features Armrest Adjusting to the desired angle: Lower the armrest from the highest position to the lowest position. Raise the armrest to the desired angle. Unlock the armrest: Lift the armrest to raise it to the highest position. NOTICE ■...
  • Page 287: Floor Mat

    3-5. Other interior features Floor mat Securely place a mat that matches the size of the space on the carpet. Secure the front floor mat using the hooks provided. CAUTION ■ When inserting the floor mat Observe the following precautions. Failure to do so may result in the floor mat slipping and interfering with the movement of the pedals during driving, resulting in an accident.
  • Page 288: Luggage Storage Box (Vehicles Without Sub Woofer)

    3-5. Other interior features Luggage storage box (vehicles without sub woofer) Push the lid down and pull it towards you. CAUTION ■ Caution while driving Keep the luggage storage box closed. Injuries may result in the event of an accident or sudden braking. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 289: Luggage Compartment Features

    3-5. Other interior features Luggage compartment features ■ Tie-down hooks Tie-down hooks are provided for securing loose items. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 290 3-5. Other interior features ■ Cargo net hooks To hang the cargo net, use the cargo net hooks and tie-down hooks. The cargo net itself is not included as an original equip- ment. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 291 3-5. Other interior features ■ Shopping bag hooks To hang the shopping bag, use the cargo net hooks. CAUTION ■ When the tie-down hooks and cargo net hooks are not in use To avoid injury, always return the tie-down hooks and cargo net hooks to their positions when they are not in use.
  • Page 292: Compass

    3-5. Other interior features ∗ Compass The compass indicates the direction that the vehicle is heading. ■ Operation The compass points north for about 3 seconds after the engine switch is turned to the ON position, and then indi- cates the actual direction the vehicle facing.
  • Page 293 3-5. Other interior features Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
  • Page 294 3-5. Other interior features After calibration, leave the system for 6 seconds or press the SET button for about 2 seconds. If the display returns to the outside temperature display, the calibra- tion is complete. ■ Circling calibration Stop the vehicle where it is safe to drive in a circle. Press the SET button until the zone number appears on the outside...
  • Page 295 3-5. Other interior features ■ Conditions unfavorable to correct operation The compass may not show the correct direction in the following conditions: ● The vehicle is stopped immediately after turning. The compass does not adjust while the vehicle is stopped. ●...
  • Page 296 3-5. Other interior features NOTICE ■ To avoid the compass malfunctions Do not place magnets or any metal objects on or near the accessory meter. Doing this may cause a malfunction of the compass sensor. ■ To ensure normal operation of the compass ●...
  • Page 297 3-5. Other interior features I n f o r ma t i o n P r o v i d e d b y :...
  • Page 298: Maintenance And Care

    4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 299 4-1. Maintenance and care ■ Aluminum wheels (if equipped) Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the point. ■...
  • Page 300: Maintenance And Care

    Allow the leather to dry in a shaded and venti- lated area. ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available.
  • Page 301 4-1. Maintenance and care CAUTION ■ Water in the vehicle ● Do not splash or spill liquid in the vehicle. Doing so may cause the electrical components etc. to malfunction or catch fire. ● Do not get any of the SRS components or wiring in the vehicle interior wet. (→P.
  • Page 302 4-1. Maintenance and care NOTICE ■ Cleaning the inside of the rear window ● Do not use glass cleaner to clean the rear window, as this may cause damage to the rear window defogger heater wires. Use a cloth dampened with lukewarm water to gently wipe the window clean.
  • Page 303: Maintenance

    ■ Repair and replacement It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than Toyota dealer performs repairs, confirm the war- ranty coverage.
  • Page 304 000000. If the system fails to reset, the light will continue flashing. ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
  • Page 305 4-2. Maintenance I n f o r ma t i o n P r o v i d e d b y :...
  • Page 306: Maintenance

    “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
  • Page 307: Vehicle Interior

    4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be hold securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
  • Page 308: Vehicle Exterior

    4-2. Maintenance Items Check points • Moves smoothly? Steering wheel • Has correct free play? • No strange noises? Vehicle exterior Items Check points Door • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? •...
  • Page 309: Emission Inspection And Maintenance (I/M) Programs

    If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
  • Page 310: Do-It-Yourself Maintenance

    • FMVSS No.116 DOT 3 or SAE Brake fluid level (→P. 300) J1703 brake fluid • Rag or paper towel • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
  • Page 311 4-3. Do-it-yourself maintenance Items Parts and tools • Bulb with same number and watt- Light bulbs (→P. 335) age rating as original • Phillips-head screwdriver • Automatic transmission fluid Power steering fluid level ® DEXRON II or III (→P. 302) •...
  • Page 312 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing, and tools away from the moving fan and engine drive belt.
  • Page 313 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment. ■...
  • Page 314: Hood

    4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the hood catch lever and lift the hood. CAUTION ■...
  • Page 315: Engine Compartment

    4-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (→P. 306) Engine oil filler cap (→P. 295) Power steering fluid reservoir (→P. 302) Brake fluid reservoir (→P. 300) Radiator cap Fuse box (→P. 324) Engine oil level dipstick (→P. 295) Battery (→P.
  • Page 316 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After turning off the engine, wait more than 5 minutes for the oil to drain back into the bot- tom of the engine.
  • Page 317 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 318 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
  • Page 319 4-3. Do-it-yourself maintenance NOTICE ■ To prevent serious engine damage Check the oil level on regular basis. ■ When replacing the engine oil ● Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, as the engine could be damaged. ●...
  • Page 320: Engine Coolant

    If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. ■...
  • Page 321 Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
  • Page 322 4-3. Do-it-yourself maintenance ■ Adding fluid Make sure to check the fluid type and prepare the necessary items. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Rag or paper towel Turn the engine switch off. Depress the brake pedal 20 times or more. Remove the reservoir cap.
  • Page 323 4-3. Do-it-yourself maintenance Power steering fluid ■ Fluid level The fluid level should be within the appropriate range. Full (when cold) Add fluid (when cold) Full (when hot) Add fluid (when hot) Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frigid temperatures.
  • Page 324 4-3. Do-it-yourself maintenance CAUTION ■ Checking the fluid level Take care, as the reservoir may be hot. NOTICE ■ When adding fluid Avoid overfilling, or the power steering may be damaged. ■ After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
  • Page 325 4-3. Do-it-yourself maintenance ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive. Therefore, before recharging: ● If recharging with the battery installed on the vehicle, be sure to discon- nect the ground cable. ● Make sure the power switch on the charger is off when connecting and disconnecting the charger cables to the battery.
  • Page 326 4-3. Do-it-yourself maintenance CAUTION ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
  • Page 327 4-3. Do-it-yourself maintenance Washer fluid Add washer fluid in the following situations. ● Any washer does not work. ● The low washer fluid warning light comes on. (Canada only) Open the lid. Check the washer fluid level on the level gauge. NORMAL The washer fluid level can be checked by checking where the...
  • Page 328 4-3. Do-it-yourself maintenance CAUTION ■ When refilling the washer fluid Do not refill the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■...
  • Page 329: Tires

    ■ The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 357)
  • Page 330 ID codes must be registered in the tire pressure warning computer and tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. Registering ID codes The tire pressure warning valve and transmitter is equipped with a unique ID code.
  • Page 331 4-3. Do-it-yourself maintenance ■ If the tread wears down below 0.16 in. (4 mm) on snow tires The effectiveness of snow tires is lost. ■ Maximum load of tire Check that the number given by dividing the maximum load by 1.10 of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater.
  • Page 332 4-3. Do-it-yourself maintenance ■ Routine tire inflation pressure checks The tire pressure warning system does not replace routine tire inflation pressure checks. Make sure to check tire inflation pressure as part of your routine of daily vehicle checks. ■ Tire pressure warning system certification FCC ID: PAXPMV107J FCC ID: HYQ13BCG IC ID: 3729A-PMV107J...
  • Page 333 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
  • Page 334: Tire Inflation Pressure

    4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 396) I n f o r ma t i o n P r o v i d e d b y :...
  • Page 335 ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 336 4-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours and has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
  • Page 337 4-3. Do-it-yourself maintenance NOTICE ■ When inspecting and adjusting tire inflation pressure Be sure to reinstall the tire valve caps. Without the valve caps, dirt or moisture could get into the valve and cause air leakage, which could result in an accident. If the caps have been lost, replace them as soon as possible.
  • Page 338: Wheels

    ● Bent wheels that have been straightened ■ Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrench designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
  • Page 339 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
  • Page 340: Air Conditioning Filter

    4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the engine switch off. Open the glove box. Slide off the damper. Push in each side of the glove box to disconnect the claws.
  • Page 341 2 minutes at 72 psi (500 kPa, 5.0 kgf/cm or bar). If it is not available, have the filter cleaned by your Toyota dealer. ■ Replacement method Remove the air conditioning filter and replace it with a new one.
  • Page 342 4-3. Do-it-yourself maintenance ■ Checking interval Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule. In dusty areas or areas with heavy traffic flow, more fre- quent cleaning or early replacement may be required. (For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide”...
  • Page 343: Key Battery

    4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Small Phillips-head screwdriver ● Lithium battery CR1616 ■ Replacing the battery Remove the screw and cover. Push the cover in the arrow direction.
  • Page 344 ● The operational range is reduced. ■ Use a CR1616 lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer. ●...
  • Page 345: Checking And Replacing Fuses

    4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch off. The fuses are located in the following places. To check the fuses, follow the instructions below.
  • Page 346 4-3. Do-it-yourself maintenance ■ Under the instrument panel Remove the lid. After a system failure, see “Fuse layout and amperage rat- ings” (→P. 328) for details about which fuse to check. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 347 4-3. Do-it-yourself maintenance Remove the fuse with the pull- out tool. Check if the fuse has blown. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 348 4-3. Do-it-yourself maintenance Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
  • Page 349 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Type A Type B (if equipped) I n f o r ma t i o n P r o v i d e d b y :...
  • Page 350 4-3. Do-it-yourself maintenance Fuse Ampere Circuit SPARE 10 A Spare fuse SPARE 15 A Spare fuse TOWING TAIL 15 A Trailer lights RR FOG 10 A No circuit OFFROAD LP 15 A Offroad lamp Stop lights, high mounted stop- light, anti-lock brake system, trac- tion control system, active traction control system, vehicle stability STOP...
  • Page 351 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ DEFOG NO.2 7.5 A sequential multiport fuel injection system Interior light, personal lights, DOME 10 A engine switch light, clock, acces- sory meter, meter and gauge RADIO NO.1 20 A Audio system Air conditioning system, multiplex communication system, SRS air-...
  • Page 352 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Anti-lock brake system, vehicle sta- bility control system, traction con- ABS MTR 40 A trol system, active traction control system, AUTO LSD system IGN and GAUGE, multiport fuel injection system/sequential multi- 30 A port fuel injection system, starting system Anti-lock brake system, vehicle sta- bility control system, traction con-...
  • Page 353 4-3. Do-it-yourself maintenance ■ Under the instrument panel 6 7 8 10 11 Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection system, anti-lock brake system, vehicle stability control system, 10 A traction control system, active trac- tion control system, AUTO LSD system, SRS airbag system, front passenger occupant classification system...
  • Page 354 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Anti-lock brake system, vehicle sta- bility control system, traction con- trol system, active traction control system, AUTO LSD system, multi- ECU-IG 10 A port fuel injection system/sequen- tial multiport fuel injection system, cruise control system, back door lock system, shift lock system, mul- tiplex communication system Turn signal lights, air conditioning...
  • Page 355 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
  • Page 356: Light Bulbs

    You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
  • Page 357 4-3. Do-it-yourself maintenance ■ Rear bulb locations Stop/tail and rear side marker lights Back-up lights Rear turn signal lights License plate lights Replacing light bulbs ■ Headlights Unplug the connector. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 358 4-3. Do-it-yourself maintenance Remove the rubber cover. Release bulb retaining spring. Remove the bulb. To install a new bulb, align the tabs of the bulb with the cutouts of the mounting hole. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 359 4-3. Do-it-yourself maintenance ■ Front turn signal/parking and front side marker lights Turn the bulb base counterclock- wise. Remove the light bulb. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 360 4-3. Do-it-yourself maintenance ■ Back-up lights, stop/tail and rear side marker and rear turn signal light bulbs ● Removing the sub woofer speaker (vehicles with sub woofer) Remove the speaker cover. Remove the cover. Installing the sub woofer speaker (→P. 342) Remove the sub woofer speaker.
  • Page 361 4-3. Do-it-yourself maintenance ● Removing the back-up, stop/tail and rear side marker and rear turn signal light bulbs Open the back door and remove the cover. Using a flathead screwdriver or equivalent which is wrapped with a cloth. Turn the bulb bases counter- clockwise.
  • Page 362 ■ Lights other than the above If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. • Outside rear view mirror illumination lights (if equipped) • High mounted stoplight I n f o r ma t i o n P r o v i d e d b y :...
  • Page 363 LED high mounted stoplight The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ■ Installing the sub woofer speaker (vehicles with sub woofer) Install the rubber inside the panel as shown in the illustration.
  • Page 364: Essential Information

    5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
  • Page 365: If Your Vehicle Needs To Be Towed

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 366 5-1. Essential information ■ Emergency towing procedure The engine switch must be in the ACC (engine off) or the ON (engine running) position. 4WD models with an automatic transmission: Shift the front-wheel drive control lever in H2. 4WD models with a manual transmission: Unlock the center differ- ential.
  • Page 367 5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel lift-type truck from the front Use a towing dolly under the rear wheels.
  • Page 368 5-1. Essential information Towing with a wheel lift-type truck from the rear 2WD models Turn the engine switch to the ACC position. 4WD models Vehicles with a manual transmis- sion: Use a towing dolly under the front wheels. Vehicles with an automatic trans- mission: When not using a tow- ing dolly, turn the engine switch to the ACC position, shift the...
  • Page 369 5-1. Essential information Using a flat bed truck If your Toyota is transported by a Front flat bed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°.
  • Page 370: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
  • Page 371: Fuel Pump Shut Off System

    5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
  • Page 372: Event Data Recorder

    5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
  • Page 373 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained ●...
  • Page 374: Steps To Take In An Emergency If A Warning Light Turns On Or A Warning Buzzer Sounds

    Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light •...
  • Page 375 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: •...
  • Page 376 5-2. Steps to take in an emergency Warning light Warning light/Details ABS warning light (U.S.A.) Indicates a malfunction in: • The ABS; or • The brake assist system. (Canada) Slip indicator The indicator comes on to indicate a malfunction in: •...
  • Page 377 Have the system after blinking for 1 checked by your minute: Malfunction in Toyota dealer. the tire pressure warning system. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 378 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Low fuel level warning light Refuel the vehicle. Low level of fuel. Low washer fluid warn- ing light Fill the tank. (Canada only) Low level of washer fluid. Maintenance required reminder light •...
  • Page 379 5-2. Steps to take in an emergency speed of at least 12 mph (20 km/h), the buzzer sounds intermittently for 10 seconds. Then, if the seat belt is still unfastened, the buzzer will sound in a different tone for 20 more seconds. : Front passenger’s seat belt reminder: The front passenger’s seat belt reminder sounds to alert the front passenger that his or her seat belt is not fastened.
  • Page 380 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
  • Page 381 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
  • Page 382 5-2. Steps to take in an emergency ■ Customization that can be configured at Toyota dealer The vehicle speed linked seat belt reminder buzzer can be disabled. (Customizable features →P. 412) CAUTION ■ If the tire pressure warning light comes on Be sure to observe the following precautions.
  • Page 383 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tire As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS-tire pressure warning system) that illuminates a low tire pressure telltale (tire pressure warning light) when one or more of your tires is significantly under-inflated.
  • Page 384 5-2. Steps to take in an emergency NOTICE ■ Precaution when installing a different tire When a tire of a different specification or maker is installed, the tire pres- sure warning system may not operate properly. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 385: If You Have A Flat Tire

    5-2. Steps to take in an emergency If you have a flat tire I n f o r ma t i o n P r o v i d e d b y :...
  • Page 386 5-2. Steps to take in an emergency Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ● Shift the shift lever to P (automatic transmission) or R (manual transmission).
  • Page 387 5-2. Steps to take in an emergency Taking out the jack and tool bag Remove the cover and loosen the strap. Loosen and remove the jack. Tighten Loosen Taking out the spare tire (vehicles without rear view monitor system) Vehicles with aluminum wheel: Remove the wheel orna-...
  • Page 388 5-2. Steps to take in an emergency Turn the hold-down nuts counter- clockwise with the wheel nut wrench and remove them. Taking out the spare tire (vehicles with rear view monitor system) Remove the bolt cover. Bolt cover Remove the bolt which fixes the spare wheel cover using the wrench in the tool bag (→P.
  • Page 389 5-2. Steps to take in an emergency Remove the spare wheel cover. Turn the hold-down nuts counter- clockwise with the wheel nut wrench and remove them. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 390 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Wheel Flat tire chock positions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of Left- the front...
  • Page 391 5-2. Steps to take in an emergency Remove the wheel ornament using the wheel nut wrench or the remover as shown. To protect the wheel and wheel ornament, place a rag between the wheel nut wrench or the remover and the wheel ornament, as shown in the illustration.
  • Page 392 5-2. Steps to take in an emergency Position the jack at the correct jack point as shown. Front Rear Make sure the jack is positioned on a level and solid place. Front Assemble the jack handle exten- sion as shown. Be sure to tighten each bolt securely.
  • Page 393 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 394 5-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque: 85 ft·lbf (113 N·m, 11.5 kgf·m) Reinstall the wheel ornament. Aluminum wheel I n f o r ma t i o n P r o v i d e d b y :...
  • Page 395 5-2. Steps to take in an emergency Steel wheel Stowing the flat tire, jack and all tools Install the flat tire in the reverse order of removal. Tightening torque: 65 ft·lbf (88 N·m, 8.9 kgf·m) Vehicles with rear view monitor system: Install the spare wheel cover in the reverse order of removal.
  • Page 396 5-2. Steps to take in an emergency CAUTION ■ Using the jack Improper use of the jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. ● Do not use the jack for any purpose other than replacing tires or install- ing and removing tire chains.
  • Page 397 When replacing the tires ● When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor- rectly.
  • Page 398: If The Engine Will Not Start

    ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (→P. 379) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 399: If The Shift Lever Cannot Be Shifted From P

    (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
  • Page 400: If You Lose Your Keys

    5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using one of the master keys and the key number stamped on your key number plate. (→P. 28) ■...
  • Page 401: If The Vehicle Battery Is Discharged

    You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. Connecting the jumper cables...
  • Page 402 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged (vehicles with an automatic transmission) The engine cannot be started by push-starting.
  • Page 403 5-2. Steps to take in an emergency CAUTION ■ Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery. ● When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
  • Page 404: If Your Vehicle Overheats

    If the fan is not operating: Stop the engine immediately and call your local Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 405 (→P. 392) Have the vehicle checked at your nearest Toyota dealer as soon as possible. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 406 5-2. Steps to take in an emergency ■ Overheating If you observe the following, your vehicle may be overheating. ● The engine coolant temperature gauge enters the red zone or a loss of power is experienced. ● Steam is coming from under the hood. CAUTION ■...
  • Page 407: If The Vehicle Becomes Stuck

    5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift lever in P (vehicles with an automatic transmission) or N (vehicles with a manual transmission).
  • Page 408 5-2. Steps to take in an emergency CAUTION ■ When attempting to free a stuck vehicle If you choose to rock the vehicle back and forth to free it, make sure the sur- rounding area is clear, to avoid striking other vehicles, objects or persons. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
  • Page 409: Specifications Maintenance Data (Fuel, Oil Level, Etc.)

    6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 183.9 in. (4670 mm) Overall width 75.0 in. (1905 mm) 2WD models 71.3 in. (1810 mm) Overall height* 4WD models 72.0 in. (1830 mm) Wheelbase 105.9 in. (2690 mm) Front tread 63.2 in.
  • Page 410 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 411 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. Engine Model 1GR-FE Type 6-cylinder V type, 4-cycle, gasoline 3.70 × 3.74 in. (94.0 × 95.0 mm) Bore and stroke Displacement 241.4 cu.in. (3956 cm Drive belt tension Automatic adjustment Valve clearance...
  • Page 412: Lubrication System

    6.0 qt. (5.7 L, 5.0 Imp.qt.) ■ Engine oil selection “Toyota” Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
  • Page 413: Cooling System

    10.4 qt. (9.8 L, 8.6 Imp.qt.) Capacity Vehicles with a manual transmission 9.9 qt. (9.4 L, 8.3 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
  • Page 414: Electrical System

    Rear 75W-85 GL-5 or equivalent : “Toyota Genuine Differential Gear Oil” is filled in your Toyota vehicle at factory fill. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
  • Page 415: Automatic Transmission

    : The fluid capacity is the quantity of reference. If replacement is necessary, contact your Toyota dealer. NOTICE ■ Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied vibration, ultimately...
  • Page 416 Recommended oil viscosity SAE 75W : “Toyota Genuine Transfer Gear oil LF” is filled in your Toyota vehicle at factory fill. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
  • Page 417 6-1. Specifications Chassis lubrication Propeller shafts Spider Lithium base chassis grease, NLGI No.2 Slide yoke Molybdenum — disulfide lithium base chassis grease, NLGI No.2 or lithium base multipurpose grease, NLGI No.2 Steering Free play Less than 1.2 in. (30 mm) ®...
  • Page 418 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights — 60/55 Front turn signal/ parking and front side — 21/5 marker lights Outside rear view mirror illumination — Exterior lights Rear turn signal lights — Stop/tail and rear side 7443 21/5 marker lights...
  • Page 419: Fuel Information

    ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
  • Page 420 Toyota allows the use of oxygenate blended gasoline where the oxygenate content is up to 10% ethanol or 15% MTBE. ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 91. ●...
  • Page 421 6-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
  • Page 422: Tire Information

    6-1. Specifications Tire information Typical tire symbols Tire size (→P. 403) DOT and Tire Identification Number (TIN) (→P. 402) Location of treadwear indicators (→P. 404) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
  • Page 423 6-1. Specifications Radial tires or bias-ply tires A radial tire has RADIAL on the sidewall. A tire not marked RADIAL is a bias-ply tire. Summer tire or all season tire (→P. 310) An all season tire has M+S on the sidewall. A tire not marked M+S is a summer tire.
  • Page 424 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
  • Page 425 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
  • Page 426 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
  • Page 427 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. Glossary of tire terminology Tire related term Meaning...
  • Page 428 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as Occupant distribution specified in the third column of Table 1 below The combined weight of installed regular production options weighing over 5 lb.
  • Page 429 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
  • Page 430 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a)The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on Intended outboard the other sidewall of the tire, or sidewall...
  • Page 431 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between Ply separation adjacent plies A mechanical device made of rubber, chemicals, fabric and steel or other materials, Pneumatic tire that, when mounted on an automotive wheel, provides the traction and contains the gas or fluid that sustains the load A pneumatic tire in which the ply cords that...
  • Page 432 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear designed to give a visual indication of the...
  • Page 433: Customization

    Programming these preferences requires specialized equipment and may be performed by an autho- rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
  • Page 434 6-2. Customization Customized Item Function Default setting setting Automatic Time elapsed before 0 seconds light off sys- headlights automati- 60 seconds 30 seconds cally turn off after doors 90 seconds (→P. 145) are closed 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Operation after the...
  • Page 435: Items To Initialize

    6-2. Customization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Maintenance data After maintenance is performed P.
  • Page 436: Reporting Safety Defects For U.s. Owners

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 437: Seat Belt Instructions For Canadian Owners (In French)

    Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 438 I n f o r ma t i o n P r o v i d e d b y :...
  • Page 439: Alphabetical Index

    Alphabetical index Alphabetical index A/C..........204 MP3/WMA disc ..... 227 ABS ...........174 Optimal use......235 Access doors ......36 Portable music player ... 240 Accessory meter ......143 Radio........214 Active traction control Steering wheel audio system ........166 switch........242 Air conditioning filter....319 Sub woofer......238 Air conditioning system Type ........
  • Page 440 Alphabetical index Care Seat belts ......280 Exterior ......... 278 Clinometer ........143 Interior ........280 Clock ........256 Seat belts ......280 Clutch start cancel switch..173 Cargo capacity ......184 Compass......143, 271 Cargo net hook......269 Condenser ........300 CD player ......... 220 Cooling system Center differential lock ...
  • Page 441 Alphabetical index Emergency, in case of Engine oil Blown fuse......324 Capacity ........ 391 If the engine will not start ..376 Checking ....... 295 If the shift lever cannot be Preparing and checking before shifted from P......377 winter ........188 If the vehicle battery is Warning light ....
  • Page 442 Alphabetical index Refueling ........ 73 Interior lights Type ........390 Switch........245 Warning light ......357 Wattage.........397 Fuel door........73 Instrument panel light Fuel filler door ......73 control ........138 Fuel pump shut off system ..351 Intuitive parking assist ....153 Fuses Fuses........
  • Page 443 Alphabetical index Turn signal lights switch ..133 Outside rear view mirror Wattage.........397 illumination lights Limited slip differential....168 Replacing light bulbs..... 341 Load capacity ...184, 187, 388 Switch ........145 Lock steering column....63 Wattage......... 397 Luggage storage box....267 Outside rear view mirrors Luggage compartment Adjusting and folding....68 features........268...
  • Page 444 Alphabetical index Rear window defogger.... 210 Folding down the rear seat Replacing precautions ......53 Key battery ......322 Front seat adjustment .....47 Fuses........324 Front seat adjustment Light bulbs ......335 precautions ......48 Tires ......308,364 Head restraint......54 Wheels ......... 317 Properly sitting in the seat..80 Rear differential lock Service reminder...
  • Page 445 Alphabetical index Stop lights Theft deterrent system Replacing light bulbs .....339 Engine immobilizer system ..77 Wattage.........397 Theft prevention labels....79 Storage feature......247 Theft prevention labels .....79 Storage precautions ....184 Tire inflation pressure ..... 396 Stuck Tire information If the vehicle becomes Glossary........406 stuck ........385 Size ........403...
  • Page 446 Alphabetical index Vanity mirrors......255 Washer Vehicle identification Checking .......306 number........389 Preparing and checking Vehicle stability control..174 before winter .......188 Voltmeter........137 Switch......147, 149 VSC........... 174 Washing and waxing ....278 Weight Cargo capacity ......184 Warning buzzers Load limits ......187 Key reminder ......
  • Page 447: What To Do If

    What to do if... What to do if... A tire punctures If you have a flat tire P. 364 P. 376 If the engine will not start The engine does not start P. 77 Engine immobilizer system P. 379 If the battery is discharged If the shift lever cannot be shifted The shift lever cannot be P.
  • Page 448 What to do if... ■ Instrument cluster ■ Center panel I n f o r ma t i o n P r o v i d e d b y :...
  • Page 449 What to do if... ■Warning lights Unengaged Park warning Brake system warning light light P. 354 P. 356 Charging system warning Slip indicator* light P. 355 P. 356 Tire pressure warning Low engine oil pressure light warning light P. 355 P.
  • Page 450 Memo I n f o r ma t i o n P r o v i d e d b y :...
  • Page 451 Memo I n f o r ma t i o n P r o v i d e d b y :...
  • Page 452 Memo I n f o r ma t i o n P r o v i d e d b y :...
  • Page 453: Gas Station Information

    (L, Imp.qt.) Engine oil capacity With filter 6.4 (6.1, 5.4) (Drain and refill) Without filter 6.0 (5.7, 5.0) Toyota Genuine Motor Oil or equivalent Oil grade: P. 391 Engine oil type ILSAC multigrade engine oil Recommended oil viscosity: SAE 0W-20...

Table of Contents
