COLOUR TELEVISION
AV-32WFX1EU
AV-28WFX1EU
Instructions
Thank you for buying this JVC colour television.
To make sure you understand how to use your new TV,
please read this manual thoroughly before you begin.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EX-
POSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION:
TO ENSURE PERSONAL SAFETY, OBSERVE THE
FOLLOWING RULES REGARDING THE USE OF THIS
UNIT.
1. Operate only from the power source specified (AC
220 - 240 V, 50 Hz) on the unit.
2. Avoid damaging the AC plug and power cord.
3. Avoid improper installation and never position the
unit where good ventilation is unattainable.
When installing this television, distance recommen-
dations must be maintained between the floor and
wall, as well as instalment in a tightly enclosed area
or piece of furniture. Adhere to the minimum dis-
tance guidelines shown for safe operation.
15 cm
10 cm
10 cm
15 cm
4. Do not allow objects or liquid into the cabinet open-
ings.
5. In the event of a fault, unplug the unit and call a
service technician. Do not attempt to repair it your-
self or remove the rear cover.
6. For AV-32WFX1EU only:
The surface of the TV screen is coated with a thin
film which can easily be damaged. Be very careful
with it when handling the TV.
Should the TV screen become soiled, wipe it with a
soft dry cloth. Never rub it forcefully. Never use any
cleaner or detergent on it.
When you don't use this TV set for a long period of time,
be sure to disconnect the power plug from the AC socket.
reparation2
CONTENTS
Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
T-V LINK Functions . . . . . . . . . . . . . . . . . . . . . . . 5
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Remote Control Buttons and Functions . . . . . . . . 8
Menu Operation . . . . . . . . . . . . . . . . . . . . . . . . . 14
Picture Setting . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Picture Features . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sound Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . 18
EXT Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Demo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Additional Preparation . . . . . . . . . . . . . . . . . . . . 28
Connecting an Audio System . . . . . . . . . . . . . . . 29
Channel Table . . . . . . . . . . . . . . . . . . . . . . . . . . 30
TV Buttons and Parts . . . . . . . . . . . . . . . . . . . . . 31
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 32
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
