- Page 1 Acer Projector X1161P/X1161PA/X110P/H110P/ X1161N/X1261P Series User's Guide http://www.pureglare.com.au...
- Page 2 Serial number: ___________________________________ Date of purchase: ________________________________ Place of purchase: ________________________________ Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies' product names or trademarks are used herein for identification purposes only and belong to their respective companies.
- Page 3 Information for your safety and comfort Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product. Turning the product off before cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
- Page 4 • To avoid damage of internal components and to prevent battery leakage, do not place the product on a vibrating surface. • Never use it under sporting, exercising, or any vibrating environment which will probably cause unexpected short current or damage rotor devices, lamp.
- Page 5 Product servicing Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage points or other risks. Refer all servicing to qualified service personnel. Unplug this product from the wall outlet and refer servicing to qualified service personnel when: •...
- Page 6 Do not stand the projector on end vertically. It may cause the projector to fall over, causing injury or damage. • This product is capable of displaying inverted images for ceiling mount installation. Only use acer ceiling mount kit for mounting the projector and ensure it is securely installed. http://www.pureglare.com.au...
- Page 7 For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit http://www.acer-group.com/public/Sustainability/sustainability01.htm Mercury advisory For projectors or electronic products containing an LCD/CRT monitor or display: “Lamp(s) contain Mercury, Dispose Properly.”...
-
Page 8: Precautions
viii First things first Usage Notes • Turn off the product before cleaning. • Use a soft cloth moistened with mild detergent to clean the display housing. • Disconnect the power plug from AC outlet if the product is not being used for a long period of time. -
Page 9: Table Of Contents
Adjusting the Height of Projected Image How to optimize image size and distance How to get a preferred image size by adjusting distance and zoom User Controls Installation menu Acer Empowering Technology Onscreen Display (OSD) Menus Color Image Setting Management... - Page 10 LED & Alarm Definition Listing Replacing and cleaning the dust filters Replacing the Lamp Ceiling Mount Installation Specifications Compatibility modes Regulations and safety notices http://www.pureglare.com.au...
-
Page 11: Introduction
X1261P series : Native 1024 x 768 XGA resolution 4:3 / 16:9 aspect ratio supported • Acer ColorBoost technology delivers nature's true colors for vivid, life-like images • Acer Spectra Boost technology increases color range by 30%, delivering vivid colors like never before. -
Page 12: Package Overview
Contact your dealer immediately if any thing is missing. Projector with lens cap Power cord VGA cable XXXXXX Composite video cable Battery Security card (X1161P/X1261P series) Acer Projector Quick Start Guide User’s guide Remote control Quick start guide Carrying case Dust filters (Optional) (Optional) -
Page 13: Projector Overview
Projector Overview Projector Outlook Front / upper side Description Description Ventilation (inlet) Lens cap Ventilation (outlet) Power button Remote control receivers Remote control Focus ring Zoom lever Zoom lens 10 Horn Rear side http://www.pureglare.com.au... - Page 14 Description Description X1161N Series: X1261P Series: Power socket Power socket Kensington lock port Kensington lock port PC analog signal/HDTV/component PC analog signal input connector (VGA video input connector (VGA IN 1 or In 1 or VGA In) VGA IN) USB connector S-Video input connector Composite video input connector X1161P/X1161PA/X110P/H110P only:...
-
Page 15: Remote Control And Control Panel Layout
Remote Control and Control Panel Layout # Icon Function Description Remote control Receives signals from remote control. receiver POWER Refer to the "Turning the Projector On/Off" section. • MENU Press "MENU" to launch the Onscreen display (OSD) menu, back to the previous step for the OSD menu operation or exit the OSD menu. - Page 16 # Icon Function Description Empowering Unique Acer functions: eView, eTimer, ePower Management. Press "VGA" to change source to the VGA connector. This connector supports analog RGB, YPbPr (480p/576p/720p/ 1080i), YCbCr (480i/576i) and RGBsync. VIDEO Press "VIDEO" to change source to composite video.
-
Page 17: Getting Started
Getting Started Connecting the Projector RS232 RS232 D-Sub D-Sub D-Sub X1161 series S-Video output Video output Description Description X1161N series: X1261P series: Power cord Power cord VGA cable VGA cable USB cable Composite video cable X1161P/X1161PA/X110P/H110P series: RS232 cable Power cord S-Video cable VGA cable Audio cable jack/jack... -
Page 18: Turning The Projector On/Off
Turning the Projector On/Off Turning on the Projector Remove the lens cap.(Illustration #1) Ensure that the power cord and signal cable are securely connected. The Power indicator LED will flash red. Turn on the projector by pressing "Power" button on the control panel, and the Power indicator LED will turn blue. -
Page 19: Turning The Projector Off
Turning the projector off To turn the projector off, press the power button. This message appears: "Please press the power button again to complete the shutdown process." Press the power button again. The LED power indicator will turn RED and blink rapidly after the projector is turned off, and the fan(s) will continue to operate for about 2 minutes to ensure that the system cools properly. -
Page 20: Adjusting The Projected Image
Adjusting the Projected Image Adjusting the Height of Projected Image The projector is equipped with elevator feet for adjusting the height of image. To raise/lower the image: Use Tilt adjusting wheel (Illustration #1) to fine-tune the display angle. Tilt adjusting wheel http://www.pureglare.com.au... -
Page 21: How To Optimize Image Size And Distance
How to optimize image size and distance Consult the table below to find the optimal image sizes achievable when the projector is positioned at a desired distance from the screen. Example: If the projector is 3 m from the screen, good image quality is possible for image sizes between 69"... - Page 22 Screen size Screen size Desired (Min zoom) (Max zoom) Distance From base to From base to top Diagonal Diagonal W (cm) x W (cm) x <A> top of image (inch) (inch) of image (cm) H (cm) H (cm) <B> <B> (cm) <C>...
-
Page 23: How To Get A Preferred Image Size By Adjusting Distance And Zoom
How to get a preferred image size by adjusting distance and zoom Height Form base to top of image 2.2 m Desired Distance The table below shows how to achieve a desired image size by adjusting either the position or the zoom ring. Example: to obtain an image size of 50" set the projector at a distance 2 m and 2.2 m from the screen and adjust the zoom level accordingly. - Page 24 Desired Image Size Distance (m) Top (cm) From base to top of Diagonal (inch) Max zoom Min zoom W (cm) x H (cm) image <A> <B> <C> <D> 61 x 46 81 x 61 102 x 76 122 x 91 142 x 107 163 x 122 183 x 137...
-
Page 25: User Controls
The new settings will be saved automatically upon exiting the menu. Push the menu button anytime to exit the menu and return to the Acer welcome screen. http://www.pureglare.com.au... -
Page 26: Acer Empowering Technology
Acer Empowering Technology Acer Empowering Key provide three Empowering Acer unique functions, they are "Acer eView Management", "Acer eTimer Management" and "Acer ePower Management" respectively. Press " " key for more than one second to launch the Onscreen display main menu to modify its function. -
Page 27: Onscreen Display (Osd) Menus
Onscreen Display (OSD) Menus The projector has multilingual OSD that allow you to make image adjustments and change a variety of settings. Using the OSD menus • To open the OSD menu, press "MENU" on the remote control. • When the OSD is displayed, use the keys to select any item in the main menu. -
Page 28: Color
Color Display Mode There are many factory presets optimized for various types of images. • Bright: For brightness optimization. • Presentation: For meeting presentation with higher brightness. • Standard: For common environment. • Video: For playing video in a bright environment. •... -
Page 29: Image
Saturation Adjusts a video image from black and white to fully saturated color. • Press to decrease the amount of color in the image. • Press to increase the amount of color in the image. Tint Adjusts the color balance of red and green. •... - Page 30 Use this function to choose your desired aspect ratio. Aspect Ratio • Auto: Keep the image with original width-higth ratio and maxi mize the image to fit native horizontal or vertical pixels. • 4:3: The image will be scaled to fit the screen and displayed using a 4:3 ratio.
- Page 31 Note: "H. Position", "V. Position", "Frequency" and "Tracking" functions are not supported under DVI or Video mode. Note: "Sharpness" functions is not supported under DVI and Computer mode. Note: "Auto Keystone" functions is not supported in X1161PA/X110P/ H110P/X1161N. Note: "Projection Location--> "...
-
Page 32: Setting
Setting Menu Location Choose the menu location on the display screen. Closed Caption Selects a preferred closed captioning mode from CC1, CC2, CC3, CC4, (CC1 displays captions in the primary language in your area). Select "Off" to turn off the captioning feature. This function is only available when a composite video or S-Video input signal is selected and its system format is NTSC. - Page 33 Administrator Password is. • If losing this security card and number, please contact with an Acer service center. Disable Power button • When "ON" is selected, only the Power Key on the remote control can be used. If "OFF" is selected, then the Power Key on either the remote control or the control panel can be used to control the projector.
-
Page 34: Management
Management Choose "On" to dim the projector lamp which will lower power ECO Mode consumption, extend the lamp life and reduce noise. Choose "Off" to return normal mode. Choose "On" to turn on High Altitude mode. Operate the fans at High Altitutde full speed continuously to allow for proper high altitude cooling of the projector. -
Page 35: Language
Timer • Timer Location Choose the location of the timer on the screen. Timer Start • Press to start or stop the timer. Timer Period • Press to adjust the timer period. Timer Display • Press to which timer mode to display on the screen. -
Page 36: Appendices
Appendices Troubleshooting If you experience a problem with your Acer projector, refer to the following troubleshooting guide. If the problem persists, please contact your local reseller or service center. Image Problems and Solutions Problem Solution No image appears • Connected as described in the "Getting Started"... - Page 37 Partial, scrolling • Press "RESYNC" on the remote control. or incorrectly • For an incorrectly displayed image: displayed image • Follow the steps for item 2 (above) to adjust (For notebooks) the resolution of your computer. • Press the toggle output settings. Example: [Fn]+[F4], Compaq [Fn]+[F4], Dell [Fn]+[F8], Gateway [Fn]+[F4], IBM [Fn]+[F7], HP [Fn]+[F4], NEC [Fn]+[F3], Toshiba [Fn]+[F5 ]...
-
Page 38: Problems With The Projector
Image is too small • Adjust the zoom lever on the front of the projector. or too large • Move the projector closer to or further from the screen. • Press "MENU" on the remote control. Go to "Image --> Aspect Ratio" and try different settings or press"Aspect Ratio"... -
Page 39: Osd Messages
OSD Messages Condition Message Reminder Message Fan Fail - the system fan is not working. Projector Overheated - the projector has exceeded its recommended operating temperature and must be allowed to cool down before it may be used. Replace the lamp - the lamp is about to reach its maximum lifetime. -
Page 40: Led & Alarm Definition Listing
LED & Alarm Definition Listing LED Messages Power LED Message Blue Input Power Plug Flash ON to OFF 100ms Standby Power button ON Lamp retry Quick Flashing Power off (Cooling state) Quick Flashing Power button OFF: Cooling completed; Standby Mode Error (Thermal Failure) Quick Flashing RED and Steady BLUE by returns Error (Fan lock) -
Page 41: Replacing And Cleaning The Dust Filters
Replacing and cleaning the dust filters Replacing the dust filters Turn the projector off then unplug the power cord. Pull the both sides dust filters out. (Illustration #1) Clean or replace the dust filter. To put the dust filters back, reverse the previous step. (Illustration #1) Cleaning the dust filters Clean the dust filters after every 1000 hours of use. -
Page 42: Replacing The Lamp
Replacing the Lamp Use a screwdriver to remove the screw(s) from the cover, and then pull out the lamp. The projector will detect the lamp life. You will be shown a warning message "Lamp is approaching the end of its useful life in full power operation. Replacement Suggested!"... -
Page 43: Ceiling Mount Installation
Ceiling Mount Installation If you wish to install the projector using a ceiling mount, please refer to the steps below: Drill four holes into a solid, structurally sound part of the ceiling, and secure the mount base. Note: Screws are not included. Please obtain the appropriate screws for your type of ceiling. - Page 44 Use the appropriate number of screws for the projector size to attach the projector to the ceiling mount bracket. Screw Type B Smaller Washer Large Washer Projector Bracket Supports projector and allows - for adjustments Spacer - For heat dissipation Note: It is recommended that you keep a reasonable space between the bracket and the projector to allow for proper heat distribution.
- Page 45 Adjust the angle and positioning as necessary. Tightening Screw Allen Key 30° Allen Key Tightening Screw Note: The appropriate type of screw and washer for each model is listed in the table below. 3 mm diameter screws are enclosed in the screw pack.
-
Page 46: Specifications
Specifications The specifications listed below are subject to change without notice. For final specs, please refer to Acer's published marketing specifications. Projection system ® Resolution X1161P/X1161PA/X110P/H110P/X1161N: Native: SVGA (800 x 600) , Maximum: UXGA (1600 x 1200), WSXGA+ (1680x1050), 1080p(1920x1080) - Page 47 I/O connectors X1161N series: • Power socket x1 • VGA input x1 • USB x1: for remote computer control X1161P/X1161PA/X110P/H110P series: • Power socket x1 • VGA input x1 • USB x1: for remote computer control • Composite video x1 •...
-
Page 48: Compatibility Modes
Compatibility modes A. VGA Analog VGA Analog - PC Signal Modes Resolution V.Frequency [Hz] H.Frequency [KHz] 640x480 31.47 640x480 37.86 640x480 37.50 640x480 43.27 640x480 119.51 61.60 SVGA 800x600 35.20 800x600 37.88 800x600 48.08 800x600 46.88 800x600 53.67 800x600 119.85 77.20 1024x768 48.36... - Page 49 VGA Analog - Extended Wide Timing Modes Resolution V.Frequency [Hz] H.Frequency [KHz] WXGA 1280x768 47.78 1280x768 60.29 1280x768 68.63 1280x720 44.80 1280x800 49.60 1440x900 55.90 1680x1050 65.30 1366x768 47.71 1920x1080-RB 66.60 1024x600 37.30 VGA Analog -Component Signal Modes Resolution V.Frequency [Hz] H.Frequency [KHz] 480i 720x480...
-
Page 50: Regulations And Safety Notices
Regulations and safety notices FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 51: Declaration Of Conformity For Eu Countries
Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada. Declaration of Conformity for EU countries Acer hereby declares that this projector series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Compliant with Russian regulatory certification... -
Page 52: Declaration Of Conformity
Taipei Hsien 221, Taiwan Declaration of Conformity Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan Contact Person: Mr. Easy Lai, e-mail:easy_lai@acer.com.tw And, Acer Italy s.r.l Via Lepetit, 40, 20020 Lainate (MI) Italy Tel: +39-02-939-921, Fax: +39-02 9399-2913, www.acer.it... - Page 53 -. EN301 489-17 z Article 3.2 Spectrum Usages -. EN300 328 -. EN301 893 (Applicable to 5GHz high performance RLAN). Year to begin affixing CE marking 2009. Nov. 3, 2010 _______________________________ Easy Lai /Manager Date Regulation Center, Acer Inc. http://www.pureglare.com.au...
- Page 54 Acer America Corporation 333 West San Carlos St., San Jose CA 95110, U. S. A. Tel : 254-298-4000 Fax : 254-298-4147 www.acer.com Federal Communications Commission Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the...
