- Page 1 Operating manual Washer extractors Type W3... 438 9065-31/EN Operating manual in original language 2010.06.02...
-
Page 3: Table Of Contents
Contents Contents Safety Precautions ..................5 General ......................7 Program buttons ..................7 Option buttons..................8 Start-button ..................... 8 Detergent container ................. 8 Display information .................. 9 Error code ....................10 Wash program ..................11 Program 4G01 ..................11 Wash program description ..............12 Error codes .................... -
Page 5: Safety Precautions
Safety Precautions Safety Precautions The machine is only intended for water-wash use. Do not allow minors to use the machine. Do not hose down the machine with water. The machine's door lock must under no circumstances be bypassed. If the machine develops a fault, this must be reported to the person in charge as soon as possible. -
Page 7: General
General General Program buttons 90°C White. 629 60°C Colour. 40°C Colour. 6294 60°C Synthetics. 6295 40°C Synthetics. 0°C Delicate. 6296 6297 6298... -
Page 8: Option Buttons
General Option buttons "Light soiled" Reduce the temperature and program time. 600 "Pre-wash" Adds a pre-wash and one rinse, longer wash time. Can be used together with program 1-5 (see page ). 6299 Start-button • START: Press button to start a program. •... -
Page 9: Display Information
General Display information • The clock symbol and two figures are now lit in the display. The two figures show the time remaining until the end of the wash. The two time figures are not displayed im- mediately after installation. The relevant program has to have been used at least once before the remaining time is displayed. -
Page 10: Error Code
General Error code Error code can be shown in the display. For further information, see separate chapter. 224 A... -
Page 11: Wash Program
Wash program Wash program Program 4G01 The wash programs are designed for cotton and synthetic textiles. You can wash normal household textiles and also textiles from hotels, restaurants and many other professional businesses. • Press the button for the program required. • Press the button for option "Pre-wash" or "Light soiled". •... -
Page 12: Wash Program Description
Wash program Wash program description 4G01 Pre-wash Main wash Rinses Final Detergent extraction compartment No. – 80°C 6 min and 2 or 4 – 75°C 4 min and 2 or 4 0°C 85°C 6 min 1, and 2 or 4 – 55°C 6 min and 2 or 4 –... - Page 13 Wash program Wash program description 4G01 Pre-wash Main wash Rinses Final Detergent extraction compartment No. – 40°C 2 min and 2 or 4 – 40°C 2 min and 2 or 4 0°C 40°C 2 min 1, and 2 or 4 – 0°C 1.5 min and 2 or 4 –...
-
Page 15: Error Codes
Error codes Error codes If the power supply to the machine should be cut while it is working, the programmer has a memory which stores the program at least one minute. The machine will restart automatically once the power supply is restored. When error code occur a new start attempt can be made directly by activate the START-button. -
Page 17: Coin Meter
Coin meter Coin meter Price programming • Press the relevant program selection button. When programming washing programs with options, press the relevant program selection button + option button. • Keep the price programming button activated. (The button is located in the space for the coin box.) 5750 00 now appears in the display and the ‘coin’... -
Page 19: Maintenance
Maintenance Maintenance Daily • Clean the door seal from detergent residue. • Make sure the door is not leaking. • Clean the detergent supply box and wipe off the machine with a damp rag. • Make sure the drain valve is not leaking. • Start the machine and make sure the door is locked during the program. Rapid advance the program to stop and make sure the door cannot be opened until after the program is complete. Every month • Check that valves, hoses and connections are not leaking. • Remove any lint from the drain connection, joints in the drain pipe, etc. Every third month When chemicals have collected on the edges of the panels: • Turn off power to machine. • Turn off the water supply and release the pressure from the inlet hoses. • Remove the water inlet hoses from the back of the machine and clean or change the inlet filter. • Clean the detergent supply box thoroughly. • Take off the top and front machine panels. • Wash away detergent and other chemicals from the panels to stop them rusting. • Make sure there are no leaks inside the machine. Repair as necessary. - Page 21 A11 (2003) WN3..., N5... EN 61000-3-11 (2001) EXSM.X. EN 61000-6-2 (2005) WN3..., N4..., N5... EN 61000-6-3 (2007) N4... Försäkran om överensstämmelse EF-samsvarserklæring Electrolux Laundry Systems Sweden AB Electrolux Laundry Systems Sweden AB SE-341 80 Ljungby, Sverige SE-341 80 Ljungby, Sverige, försäkrar under eget ansvar att denna produkt, med typbeteckning och enl. ovan, är tillverkad i erklærer på eget ansvar at dette produktet, med typebetegnelse og produksjonsnummer som överensstämmelse med följande direktiv: angitt nedenfor, er produsert i samsvar med bestemmelsene i følgende direktiver:...
- Page 22 Translation table for model name to type of approval Commercial name Type W455H W.55H. W465H W3... W475H W3... W4105H W3... W4130H W3... W4180H W3... W4240H W3... W4300H W3... FOM71 CLS W3... WB4130H W3... WB4180H W3... W3... W475S W3... W485S W3... W4105S W3...
- Page 23 Skrotning av maskin När maskinen inte längre skall användas måste den lämnas till en återvinningsstation för destruktion. Många detaljer i maskinen går att återanvända, men den innehåller även annat material som måste tas om hand på ett korrekt sätt. Lämna därför aldrig maskinen eller delar av maskinen i hushållsavfallet, eftersom det kan leda till hälsorisker eller skador på...
- Page 24 Electrolux Laundry Systems Sweden AB 341 80 Ljungby, Sweden www.electrolux.com/laundrysystems Share more of our thinking at www.electrolux.com...
