Echo SRM-211 Operator's Manual

Grass trimmer/brush cutter
Hide thumbs Also See for SRM-211:
Table of Contents

Advertisement

Quick Links

Grass Trimmer/Brush Cutter
Operator's Manual
MODEL
Read rules for safe operation and instructions carefully. ECHO provides an Operator's
Manual and a Safety Manual. Both must be read and understood for proper and safe
operation.
X7702272400
SRM-211
SRM-211U
Serial Number 002001001 - 02999999
WARNING
DANGER
X770000180
06/00

Advertisement

Table of Contents
loading

Related Manuals for Echo SRM-211

Summary of Contents for Echo SRM-211

  • Page 1 SRM-211 SRM-211U Serial Number 002001001 - 02999999 WARNING DANGER Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X770000180 X7702272400 06/00...
  • Page 3 If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information. Metal Debris...

  • Page 4: International Symbols

    • Beware of KICKOUT (blade thrust) when using blades. Special precautions are necessary for blade operation, see your Operator's and Safety Manuals. ONLY install ECHO approved blades on Brush Cutters (SRM) models equipped with proper blade shield, U-handles, harness, blade collar, nut and cotter pin.
  • Page 5 See Assembly for proper adjustment. • Have repairs done only by an authorized ECHO Service Dealer. • Do not use any attachment, accessory or replacement part unless it is recommended in the Operator's Manual.

  • Page 6: Personal Condition And Safety Equipment

    IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions. Some states may require the use of automatic fuel shut-off containers to reduce fuel spillage. Contact your ECHO dealer for ordering information. After Refueling; • Wipe any spilled fuel from the unit.
  • Page 7 Trimmer/Brush Cutter handles. Gloves also reduce the transmission of machine vibration to your hands. Hearing Protection -- ECHO recommends wearing hearing protection whenever unit is used. Proper Clothing -- Wear snug fitting, durable clothing; - Pants should have long legs, shirts with long sleeves.

  • Page 8: Safe Operation

    SAFE OPERATION Determine Operation Area • Provide all operators of this equipment with the operator's manual and instructions for safe operation. (50 ft.) • Review the area to be trimmed. Look for hazards that could contribute to unsafe conditions. • Spectators and fellow workers must be warned, and children and animals prevented from coming nearer than 15M (50 ft.) while the trimmer is in use.

  • Page 9: Extended Operation

    RASS RIMMER RUSH UTTER PERATOR ANUAL EXTENDED OPERATION EXTREME CONDITIONS Vibration and Cold -- It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals may be brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning sensations followed by loss of color and numbness in the fingers.
  • Page 10 The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions, shield installation and other assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.

  • Page 11: Blade Terms & Definitions

    BLADE TERMS & DEFINITIONS Blade Convertible Model (SRM-211) can be converted to utilize blades. Plastic/nylon blades require a, "Blade Conversion Kit", which includes a shoulder harness, and steel shield with necessary attaching hardware. Steel/metal blades also require the, "Blade Conversion Kit", plus a "U-Handle Kit", or a Combo Kit, must be installed.
  • Page 13 26. SAFETY VIDEO - (Not included with unit) P/N 99922202540 English version only is available at a cost of $5.00 from ECHO, INC. or any authorized ECHO dealer. The video overviews safety precautions and proper operating techniques and is supplemental to the Safety Manual. Read and understand the Safety Manual for complete information on safe...

  • Page 14: Specifications

    PECIFICATIONS MOD E L SR M-211 SR M-211U Length 1770 mm (69.7 in.) W idth 245 mm (9.65 in.) 680 mm (26.8 in.) Height 225 mm (8.86 in.) 415 mm (16.3 in.) W eight (dry) w/cutter head 5.3 kg (11.6 lb.) 5.75 kg (12.7 lb.) Engine Type Air cooled, two-stroke, single cylinder gasoline engine...

  • Page 15: Plastic Shield Installation

    Read and comply with all safety instructions listed in this manual and attachment manual. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO for use with these units.

  • Page 16: Blade Installation

    3. Install upper plate (D) on splined PTO shaft. Blade installation requires use of Upper Plate (D) with 20mm pilot. Upper plate with 37mm pilot of the SRM-211 should be retained for use with nylon line head. 4. Place Blade (E) over upper plate pilot, install the Lower Plate (F) and 10mm LH nut (G).
  • Page 17 RASS RIMMER RUSH UTTER PERATOR ANUAL Install Harness Clamp NOTE Some models require installation of Harness Clamp. If your unit does not have a clamp, follow these directions. Tools Required: Screwdriver, 8mm x 10mm Open End Wrench. Parts Required: Clamp, 4mm x 18mm Hexagon Head, Bolt, Link. 6.

  • Page 18: U - Handle Installation

    HANDLE INSTALLATION Tools Required: 8mm x 10mm Open End Wrench, Slotted Screwdriver, (3mm Hex Wrench SRM-211 only.) Parts Required: U-Handle Kit. (SRM-211) P/N 35130454130 NOTE On model SRM-211U use Steps 9, 10, 12 - 15 only. Disconnect ignition stop leads (E).
  • Page 19 13. Attach inner throttle cable to swivel (B). Check throttle for freedom of movement and that wide open throttle / low idle extremes are adjusted properly. If adjustment cannot be achieved by adjusting nuts (A), consult with your Echo Dealer for correct adjustment procedure. 14. Attach ignition leads (E).

  • Page 20: Operation With Blades

    PERATION OPERATION WITH BLADES Preparing the Trimmer/Brush Cutter for Blade Use WARNING DANGER Blade use DEMANDS specific Brush Cutter configuration. Operation without specified shield and harness can result in serious personal injury. Plastic and Nylon Blades Require "Blade Conversion Kit," P/N 99944200415 (metal shield and shoulder harness).
  • Page 21 RASS RIMMER RUSH UTTER PERATOR ANUAL Plastic/Nylon Blades may be used where ever the nylon line head is used. DO NOT use this blade for heavy weeds or brush! 8 Tooth Weed/Grass Blade P/N 69600120331 is designed for grass, garden debris and thick weeds. DO NOT use this blade for brush or heavy woody growth, 3/4"...

  • Page 22: Handling Fuel

    50:1 oil meets these standards. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD and J.A.S.O FC cerified oil, such as Echo Premium 50:1 Two-stroke Oil, will void the two- stroke engine warranty. (Emission related parts only are covered for two years, regardless of two-stroke oil used, per the statement listed in the California Emission Defect Warranty Explanation.)

  • Page 23: Equipment Check

    RASS RIMMER RUSH UTTER PERATOR ANUAL Storage - S M T W T F Fuel storage laws vary by locality. Contact your local government for 3 4 5 6 the laws affecting your area. As a precaution, store fuel in an approved, 8 9 10 11 12 13 14 air tight container.

  • Page 24: Determine Operation Area

    DETERMINE OPERATION AREA • Review the area to be trimmed. Look for hazards that could contribute to unsafe conditions. (50 ft.) • Spectators and fellow workers must be warned, and children and animals prevented from coming nearer than 15 m (50 ft.) while the trimmer is in use.

  • Page 25: Starting Cold Engine

    DANGER The cutting attachment should not rotate at idle. If attachment rotates, readjust carburetor according to "Carburetor Adjustment" instructions in this manual or see your ECHO Dealer, otherwise serious personal injury may result. 1. Stop Switch - Start/Run. Move stop switch button (A) forward away from the STOP posi- tion.

  • Page 26: Starting Warm Engine

    The cutting attachment should not rotate at idle. If attachment rotates, readjust carburetor according to "Carburetor Adjustment" instructions in this manual or see your ECHO Dealer, otherwise serious personal injury may result. 1. Stop Switch - Start/Run. Move Stop Switch button (A) away from the STOP position.

  • Page 27: Stopping Engine

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see you Echo Dealer for repairs.

  • Page 28: Maintenance Intervals

    MAINTENANCE INTERVALS i l y t I - t l i t l i i l o l f f ) s l l i o s t l t n i ® ® o i t n i f i r u o i t .

  • Page 29: Air Filter

    RASS RIMMER RUSH UTTER PERATOR ANUAL AIR FILTER Level 1. Tools required: 25 - 50 mm (1 - 2 in.) Cleaning Brush Parts required: 90008 REPOWER AIR & FUEL FILTER KIT. 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed.

  • Page 30: Spark Plug

    WARNING DANGER Catalytic mufflers operate at extremely high temperatures. Muffler area must be kept clean. Do not perform maintenance on the muffler until engine and muffler are completely cool, otherwise serious personal injury may occur. SPARK PLUG Level 2. Tools required: Scrench (combination socket wrench and screw driver supplied with unit), Feeler gauge (preferably a wire gauge), Soft metal brush Parts Required: 90064 REPOWER...
  • Page 31 RASS RIMMER RUSH UTTER PERATOR ANUAL 1. Remove spark plug lead 2. Loosen outer throttle cable nut (A) and remove cable from engine housing bracket slot. 3. Remove two (2) engine cover screws at top of starter. 4. Remove screw and arm rest (B). Lift cover (C) from engine. 5.

  • Page 32: Exhaust System

    The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service. CARBURETOR ADJUSTMENT...
  • Page 33 Accelerate to full throttle to check for smooth transition from idle to full throttle. If engine stops or stalls after full warm up return the unit to your authorized ECHO dealer for repair. 7. Check HI speed RPM at W.O.T. (Wide Open Throttle). HI speed RPM should be set to specifications found on page 14 "Specifica-...
  • Page 34 LUBRICATION Level 1. Tools required: 8 mm Open End Wrench, Cross Head Screwdriver, Clean rag Parts Required: Echo Lube 8 oz. (P/N 91014) or Lithium Base Grease. Gear Housing 1. Clean all loose debris from gear box. 2. Remove plug (A) and check level of grease.

  • Page 35: Nylon Line Replacement

    Level 1. Tools required: Head locking tool (if head is to be removed) Parts Required: ECHO 0.095" Nylon Trimmer Line 12m (40 ft.) long. 1. Hold drum (A) and turn spool (B) CW (clockwise) until it stops. Pull spool from drum. DO NOT push in on spool when turning.
  • Page 36 3. Hold the spool, opening toward you. Place index finger between the two strands and wind line, tightly and evenly, in direction of arrow marked "CC". 4. Stop when approximately 15-20 cm (6-8 in.) line (C) remains and place ends of line in notches (E) in spool (B). 5.

  • Page 37: Sharpening Metal Blades

    UTTER PERATOR ANUAL SHARPENING METAL BLADES Three styles of metal blades are approved for use on the ECHO Brush Cutter. The 8-tooth blade can be sharpened during normal mainte- nance. The clearing blade and 80 tooth blade require professional service.

  • Page 38: Troubleshooting

    No fuel at Fuel strainer clogged Clean Cranks carburetor carburetor Fuel line clogged Clean Carburetor See your ECHO dealer Fuel at No fuel at Carburetor See your ECHO dealer cylinder cylinder Muffler wet Fuel Mixture is too rich Open choke...
  • Page 39 RASS RIMMER RUSH UTTER PERATOR ANUAL TORAGE Long Term Storage (over 30 days) WARNING DANGER During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result.

  • Page 40: Echo Consumer Product Support

    The card plus proof of purchase provides you the assur- ance that authorized warranty work will be done. It also provides a direct link between you and ECHO if we find it necessary to contact you. ADDITIONAL OR REPLACEMENT MANUALS...
  • Page 41 MANUAL Some Echo units may be factory pre-assembled. The nylon line head, plastic debris shield, and mounting hardware shown in the contents list are pre-assembled to the unit. No assembly tools are needed. The front handle may need to be re-positioned for comfortable operation.

  • Page 42: Control De Emisiones

    SUPPLEMENT TO OPERATOR'S MANUAL PART NUMBER X7702272400 (X770000180) FOR MODELS: SRM-211/U S/N 02001101 & UP SUPLEMENTO DEL MANUAL DEL OPERADOR NUMERO DE PIEZA 7702272400 (X770000180) PARA LOS MODELO: SRM-211/U S/N 02001101&UP The updated emissions information for your unit is: MISSION CONTROL...
