OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the washer is installed
correctly and safely. Leave these instructions near the washer
after installation for future reference.
WD14060SD6
P/No.: MFL62644914
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG Operating Guide
Summary of Contents for LG Operating Guide
-
Page 1: Washing Machine
OWNER’S MANUAL WASHING MACHINE Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the washer is installed correctly and safely. Leave these instructions near the washer after installation for future reference. WD14060SD6 www.lg.com P/No.: MFL62644914... -
Page 2: Table Of Contents
Contents Contents........2 Thank you for buying a LG Fully Product Features......3 Automatic Washing Machine. Important safety instructions Please read your owner’s manual Important safety instructions ....4 Basic safety precautions .......5 carefully, it provides instruction on safe Save these instructions......6 installation, use and maintenance. -
Page 3: Product Features
Product Features Inverter Direct Drive system The advanced Brushless DC motor directly drives the drum without belt and pulley. 6 Motion Washer is able to perform various drum actions or a combination of different actions depending on the wash program selected. Combined with a controlled spin speed and the ability of the drum to rotate both left and right, the wash performance of the machine is greatly improved, giving you perfect results every time. -
Page 4: Important Safety Instructions
Important safety instructions READ ALL INSTRUCTIONS AND EXPLANATION OF THE INSTALLATION BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. Your Safety and the safety of others are very important. -
Page 5: Basic Safety Precautions
Important safety instructions Basic safety precautions WARNING To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions, including the following: • Before installation, check for exterior • Do not wash or dry articles that have damages. -
Page 6: Save These Instructions
Important safety instructions Basic safety precautions WARNING To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions, including the following: • Before discarding an old machine • To reduce the risk of personal injury, unplug it. -
Page 7: Specifications
Specifications Power plug Transit bolts • If the supply cord is damaged, it must be replaced by the manufacturer or its service agents Drawer or a similarly qualified person in (For detergent and order to avoid a hazard. fabric softener) 1:1 5 Rest tid W as hi ng... -
Page 8: Installation
Installation Removing packing 1. Remove the cardboard box and styrofoam packing. 2. Lift the washing machine and remove the base packing. This will require 2 or Washer more people or a lifting device. 3. Remove the tape securing the power supply cord and drain hose. -
Page 9: Installation Place Requirements
Installation Installation place requirements ❿ Location • Level floor : Washer Allowable slope under entire washer is 1˚. • Power outlet : Must be within 1.5 meters of either side of location of washer. Do not overload the outlet with more than one appliance. -
Page 10: Electrical Connection
Installation ❿ Electrical connection • Do not use an extension cord or double adapter. • If the supply cord is damaged, it must be replaced by the manufacturer or its service agents or similarly qualified person in order to avoid a hazard. •... -
Page 11: Connecting Water Supply Hose
Installation Connecting water supply hose • Water supply pressure must be between 100 kPa and 600 kPa (1.0 - 6.0 kgf / cm • Do not strip or crossthread when connecting inlet hose to the valve. • If the water supply pressure is more than 600 kPa, a water pressure reduction device should be installed. - Page 12 Installation Type-C : Connecting one touch type hose to tap without thread 1. Unscrew the adapter ring plate and the 4 adapter retaining screws. 2. Remove the guide plate if the tap is Ring plate too large to fit the adapter. Guide plate 3.
-
Page 13: Installation Of Drain Hose
Installation Installation of drain hose • The drain hose should not be placed higher than 100 cm above the floor. Water in the washer does not drain or drains slowly if above this height. about 100 cm • Securing the drain hose correctly will about 145 cm protect the floor from damage due to water leakage. -
Page 14: Leveling
Installation Leveling 1. Leveling the washing machine properly prevents excessive noise and vibration. Install the appliance on a solid and level floor surface, preferably in a corner of the room. NOTE • Timber or suspended type flooring may contribute to excessive vibration and unbalance. - Page 15 • Fit the rubber cups to reduce vibration. • You can obtain the rubber cups (p/no.4620ER4002B) from the LG spares dept. • If vibration persists with rubbers fitted. The flooring structure or rigidity may be inadequate for proper operation.
-
Page 16: How To Use Washer
How to use washer Operating washing machine 1. Sort Laundry. (Refer to 17 page) 2. Open the door and load laundry. 3. Press the Power button. 4. Select a Program. (Refer to 18~20 page) Select options at this time (Refer to 22~25 page) Additional Program Temperature Spin Speed... -
Page 17: Care Before Washing
How to use washer Care before washing 1. Care Labels Wash temperature Look for a care label on your clothes. Normal machine wash This will tell you about the fabric content of your garment and how it should be washed. Permanent press Delicate Hand wash... -
Page 18: Washing Program Table
How to use washer Washing program table • Recommended courses according to the laundry type. Proper Maximum Description Fabric type Program Temp. Load Provides better performance by 40°C Cotton Color fast garments (shirts, combining various drum motions. (Cold to 95°C) nightdresses, pajamas, etc) and Rating Provides optimized washing... -
Page 19: Extra Options
How to use washer • Water Temperature: Select water temperature to suit wash cycles. Always follow garment manufacture’s care label or instructions when washing. • Set program at “Cotton Eco + 40°C + Intensive + 1400rpm” option for test in accordance or in conformity with AS/NZS 2040.1. -
Page 20: Operating Data
How to use washer Operating data Program Max RPM Cotton 1400 Cotton Eco 1400 Easy Care 1000 Silent Wash 1000 1400 Duvet 1000 Allergy Care 1400 Refresh – Sports Wear Dark Wash 1400 Delicate Wool Quick 30 1400 Intensive 60 1400... -
Page 21: Control Panel
How to use washer Control panel SMARTDIAGNOSIS™ function is available only for the products with Additional program a SMARTDIAGNOSIS™ mark. buttons LCD display Spin dial 1:15 Time Left Washing Rinse Temp. 40°C Power Program Start/Pause Child Option Beep Rinse Temp. button dial Lock... -
Page 22: Additional Program
How to use washer Additional program Time Delay Favorite Favorite program allows you to store You can set a time delay so that the a customized wash cycle for future use. washing machine will start automatically and finish after a specified time interval. 1. -
Page 23: Options
How to use washer Options Other functions Option Rinse+Spin • Medic Rinse : For best results or for 1. Press the Power button. cleaner rinsing. 2. Select a cycle. Medic Rinse is a 40 degree final rinse. 3. Press the Option button •... -
Page 24: Child Lock
How to use washer Child Lock Select this function to lock the buttons on the control assembly to prevent tampering. "Child Lock" can be set only during the washing cycle. Locking the control panel 1. Press the Option buttons simultaneously 1:20 Time Left for 3 seconds. -
Page 25: Tub Clean
How to use washer Tub Clean Tub Clean is a special cycle to clean the inside of the washing machine. A higher water level is used in this cycle at higher spin speed. Perform this cycle regularly. 1. Remove any clothing or items from the washer and close the door. -
Page 26: Adding Detergent
Adding detergent Adding detergent and fabric softener ❿¤The dispenser drawer • Main wash only ➔ • Pre Wash + Main Wash ➔ WARNING • Keep all washing detergents away from children as there is danger of poisoning. • Too much detergent, bleach or softener may cause an overflow. -
Page 27: Detergent Dosage
Adding detergent ❿¤Detergent dosage • Detergent should be used according to the instruction of the detergent manufacture. • If too much detergent is used, too many suds can occur and this will decrease the washing result or cause heavy load to the motor. •... -
Page 28: Maintenance
Maintenance • Before cleaning the washer interior, unplug the electrical power cord to avoid electrical shock hazards. • Turn off the stopcock if the machine is to be left for any length of time (e.g. holiday), especially if there is no floor drain(gully) in the immediate vicinity. The water inlet filter •... -
Page 29: The Drain Pump Filter
Maintenance The drain pump filter • The drain filter collects threads and small objects left in the laundry. Check regularly that the filter is clean to ensure smooth running of your machine. CAUTION • First drain using the drain hose and then open the pump filter to remove any threads or objects. -
Page 30: Dispenser Drawer
Maintenance Dispenser drawer • After a while, detergents and fabric softeners leave a deposit in the drawer. • It should be cleaned from time to time with a jet of running water. • If necessary it can be removed completely from the machine by pressing the catch downwards and by pulling it out. -
Page 31: The Washing Drum
Maintenance The washing drum • If you live in a hard water area, limescale may build up continuously in places where it cannot be seen and thus not easily removed. Over time the build up of scale clogs appliances, and if it is not kept in check these may have to be replaced. •... -
Page 32: Troubleshooting Guide
Troubleshooting guide • This washing machine is equipped with automatic safety functions which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not function at all, check the following points before you contact your service provider. Diagnosing Problems Symptom Possible Cause... - Page 33 Troubleshooting guide Symptom Possible Cause Solution Washer does not • Electrical power cord may not be Make sure plug fits tightly in wall start plugged in or connection may be outlet. loose. • House fuse blown, circuit breaker Reset circuit breaker or replace tripped,or a power outage has fuse.
-
Page 34: Error Messages
Troubleshooting guide Error Messages Symptom Possible Cause Solution • Water supply is not adequate in area. Check another tap in the house. • Water supply taps are not completely Fully open tap. open. Straighten hose(s). • Water inlet hose(s) are kinked. Check the filter of the inlet hose. -
Page 35: Using Smartdiagnosis
Troubleshooting guide NOTE • SMARTDIAGNOSIS™ function is available only for the products with a SMARTDIAGNOSIS™ mark. In case of a mobile phone with static option, the SMARTDIAGNOSIS™ function might not operate. Using SMARTDIAGNOSIS™ • Only use this feature when instructed to do so by the call center. The transmission sounds similar to a fax machine, and so has no meaning except to the call center.
