Casio 4754 Operation Manual

MA0607-EA
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to read this manual carefully.
Elapsed time bezel
About This Manual
General Guide
• Press A to change from mode to mode.
Timekeeping Mode
Timekeeping
SMT indicator
City code
PM indicator
Current time for
the selected city code
(Hour : Minutes Seconds)
Digital Time
Use the Timekeeping Mode to set and view a digital display of the current time.
When setting the digital time, you can also configure settings for daylight saving time
(Summer Time or SMT), and the 12/24-hour format.
• This watch is preset with a number of city codes, each of which represents the time
zone where that city is located. When setting the digital time, it is important that you
select the correct city code for your Home City (the code for the city where you
normally use the watch). If your location is not included in the preset city codes,
select the preset city code that is in the same time zone as your location.
• Note that all of the times for the city codes are displayed in accordance with the
digital time settings you configure in the Timekeeping Mode.
• After you correctly set your Home City time, you can set the watch up for
timekeeping with a different city code simply by changing the city code in the
Timekeeping Mode.
To set the digital time
Operation Guide 4754
• For watch with the elapsed time bezel
Rotate the elapsed time bezel to align the
the minute hand. After certain amount of time elapsed,
read the graduation on the elapsed time bezel which the
minute hand points to. The elapsed time is indicated.
• Some water resistant models are equipped with a
screw lock crown.
• With such models, you must unscrew the crown in the
direction noted in the illustration to loosen it before
you can pull it out. Do not pull too forcibly on such
crowns.
• Also note that such watches are not water resistant
while their crowns are loosened. Be sure to screw the
crowns back in as far as they will go after making any
setting.
• For the sake of simplicity, the sample displays in this
manual do not show the analog hands of the watch.
• All of the displays in this manual show black-on-white.
• Button operations are indicated using the letters shown
in the illustration.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
Calendar Mode
Press .
This watch features separate digital and analog
timekeeping. The procedures for setting the digital time
and analog time are different.
The Timekeeping Mode digitally displays the current time
in 29 cities (19 time zones) around the world.
• The same city code is displayed in the Timekeeping
Mode and the Calendar Mode. The city code that
appears first when you enter the Timekeeping Mode is
the city code that was on the display the last time you
were in the Calendar Mode.
• All of the operations in this section are performed in the
Timekeeping Mode, which you enter by pressing A.
1. In the Timekeeping Mode, use B and C to scroll
through the city codes (time zones) until the one you
want to use as your Home City is displayed.
Press B to scroll eastward through the city codes.
Press C to scroll westward through the city codes.
• For full information about city codes, see the "City
Code Table".
2. After you select the city code, hold down B until the
SMT (Summer Time) on/off status starts to flash, which
indicates the setting screen.
mark with
Alarm Mode
3. Press B to move the flashing in the sequence shown below to select the other
settings.
SMT (Summer Time)
(Exit the setting screen)
4. When the setting you want to change is flashing, use C to change it as described
below.
Screen To do this:
Toggle between Summer Time (
Standard Time (
Reset the seconds to
Change the hour or minutes
Toggle between 12-hour (
( ) timekeeping
5. Press A to exit the setting screen.
• See "Digital Time Summer Time (SMT) Setting" below for details about the SMT
setting.
Digital Time Summer Time (SMT) Setting
Stopwatch Mode Countdown Timer Mode
Seconds
12/24-Hour format Minutes
Do this:
Press C.
) and
)
Use C.
Press C.
) and 24-hour
Summer Time (daylight saving time) advances the digital
time setting by one hour from Standard Time. Remember
that not all countries or even local areas use Summer
Time.
To toggle the Timekeeping Mode digital time between
SMT and Standard Time
1. In the Timekeeping Mode, use B and C to scroll
through the city codes (time zones) until the one you
want to use as your Home City is displayed.
Press B to scroll eastward through the city codes.
Press C to scroll westward through the city codes.
• For full information on city codes, see the "City Code
Table".
2. After you select the city code, hold down B until the
SMT (Summer Time) on/off status starts to flash, which
indicates the SMT setting screen.
Hour
1
