Memorex MVD2009CB Service Manual

Color television/dvd video player
Hide thumbs Also See for MVD2009CB:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
MVD2009CB
SERVICE MANUAL
COLOR TELEVISION/DVD VIDEO PLAYER
ORIGINAL
MFR'S VERSION A
Design and specifications are subject to change without notice.

Advertisement

Table of Contents
loading

Related Manuals for Memorex MVD2009CB

Summary of Contents for Memorex MVD2009CB

  • Page 1 MVD2009CB SERVICE MANUAL COLOR TELEVISION/DVD VIDEO PLAYER ORIGINAL MFR'S VERSION A Design and specifications are subject to change without notice.

  • Page 2: Important Warning

    IMPORTANT WARNING CAUTION: DVD PLAYER IS A CLASS 1 LASER PRODUCT. HOWEVER THIS PLAYER USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE PLAYER CORRECTLY AS INSTRUCTED. THE FOLLOWING CAUTION LABEL IS LOCATED ON THE REAR PANEL OF THE PLAYER. CLASS 1 LASER PRODUCT (Printed on the Rear Panel)

  • Page 3: Disc Removal Method At No Power Supply

    DISC REMOVAL METHOD AT NO POWER SUPPLY Remove the Back Cabinet and AV PCB/DVD Block. (Refer to item 1 of the DISASSEMBLY INSTRUCTIONS.) Rotate the white gear of Deck CD section in the direction of the arrow by hand. (Refer to Fig. 1) Draw the Tray.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS IMPORTANT WARNING ......................A1-1 SERVICING NOTICES ON CHECKING .................. A1-1 HOW TO ORDER PARTS ....................... A1-1 TAPE REMOVAL METHOD AT NO POWER SUPPLY ............A1-2 DISC REMOVAL METHOD AT NO POWER SUPPLY ............A1-2 TABLE OF CONTENTS ......................A2-1 GENERAL SPECIFICATIONS ....................

  • Page 5: General Specifications

    GENERAL SPECIFICATIONS G - 1 CRT Size / Visual Size 9 inch / 228.6 mmV S ystem CRT Type Normal Deflection 90 degree Magnetic Field BV/BH +0.45G / 0.18G Color System NTSC Speaker 2 Speaker Position Side Size 3 inch Impedance 8 ohm Sound Output...
  • Page 6 GENERAL SPECIFICATIONS G - 8 Operating Humidity Less than 80% RH G - 9 On Screen Menu(TV) Display Menu Type Icon Picture Brightness Contrast Color Tint Sharpness Sound Bass Treble Balance TV/CATV Add/Delete Auto CH Memory Option V-Chip Language Open Close Clock Clock Set...
  • Page 7 GENERAL SPECIFICATIONS Time Sub Title No. Angle No. Vocal On/Off Audio No. Audio Stereo L/R Zoom Marker No. Program Play Back Yes (CD) Surround On/Off Screen Saver Folder Name File Name File No Time Track No G - 1 1 OSD Language (TV) English, French, Spanish...
  • Page 8 GENERAL SPECIFICATIONS Game Position FM Transmitter Energy Star Closed Caption Comb Filter Protect of FBT Leak Circuit Choke Coil Power On Memory Parental Lock (DVD Only) Tray Lock VIDEO CD Playback SVCD Playback Overlay Graphics And Text Command List Entry Point Jump MP3 Playback WMA Playback JPEG Playback...
  • Page 9 GENERAL SPECIFICATIONS G - 1 6 Size Approx. W x D x H (mm) 278x312.5x311.5 G - 1 7 Weig h t Net (Approx.) 8.0 kg (17.6lbs) Gross (Approx.) 11.5 kg (25.4lbs) G - 1 8 C arton Master Carton Content --- Sets Material...

  • Page 10: Disassembly Instructions

    DISASSEMBLY INSTRUCTIONS 1. REMOVAL OF MECHANICAL PARTS 1-3: TV/DVD BLOCK (Refer to Fig. 1-3) AND P.C. BOARDS Remove the 2 screws (1). Disconnect the following connectors: 1-1: BACK CABINET (Refer to Fig. 1-1) (CP301, CP302, CP401 and CP403). Remove the 5 screws (1). Remove the TV/DVD Block in the direction of arrow.
  • Page 11 DISASSEMBLY INSTRUCTIONS 1-5: FRONT TRAY PLATE/TOP SHIELD (Refer to Fig. 1-5) Pick Up PCB Unlock the 2 supports (1). Remove the Front Tray Plate in the direction of arrow (A). Remove the 12 screws (2). Remove the Top Shield in the direction of arrow (B). DVD Deck Make the sort circuit using a soldering.

  • Page 12: Removal Of Anode Cap

    DISASSEMBLY INSTRUCTIONS 2. REMOVAL OF ANODE CAP 3. After one side is removed, pull in the opposite direction to remove the other. Read the following NOTED items before starting work. NOTE After turning the power off there might still be a potential Take care not to damage the Rubber Cap.

  • Page 13: Removal And Installation Of Flat Package Ic

    DISASSEMBLY INSTRUCTIONS REMOVAL AND INSTALLATION OF When IC starts moving back and forth easily after desoldering completely, pickup the corner of the IC using FLAT PACKAGE IC a tweezers and remove the IC by moving with the IC desoldering machine. (Refer to Fig. 3-3.) REMOVAL NOTE Put the Masking Tape (cotton tape) around the Flat...
  • Page 14 DISASSEMBLY INSTRUCTIONS INSTALLATION When bridge-soldering between terminals and/or the soldering amount are not enough, resolder using a Thin- Take care of the polarity of new IC and then install the tip Soldering Iron. (Refer to Fig. 3-8.) new IC fitting on the printed circuit pattern. Then solder each lead on the diagonal positions of IC temporarily.

  • Page 15: Service Mode List

    SERVICE MODE LIST This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily. To enter to the SERVICE MODE function, press and hold both buttons simultaneously on the main unit and on the remote control for more than a standard time (second).

  • Page 16: When Replacing Eeprom (Memory) Ic

    WHEN REPLACING EEPROM (MEMORY) IC If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1. NOTE: No need setting for after INI 1F due to the adjustment value. Table 1 Enter DATA SET mode by setting VOLUME to minimum.

  • Page 17: Electricaladjustments

    ELECTRICAL ADJUSTMENTS BEFORE MAKING ELECTRICAL FUNCTION FUNCTION ADJUSTMENTS OSD H CONT. AV(MIN) OSD CONTRAST COL. AV(CENT.) Read and perform these adjustments when repairing the CUT OFF COL. AV(MAX) H POSITION COL. AV(MIN) circuits or replacing electrical parts or PCB assemblies. H.BLK L TINT AV H.BLK R...
  • Page 18 ELECTRICAL ADJUSTMENTS 2-5: WHITE BALANCE 2-10: OSD HORIZONTAL NOTE: Adjust after performing CUT OFF adjustment. Activate the adjustment mode display of Fig. 1-1 and press the channel button (01) on the remote control to Place the set with Aging Test for more than 15 minutes. select "OSD".
  • Page 19 ELECTRICAL ADJUSTMENTS 2-12: BRIGHT CENTER Using the remote control, set the brightness and contrast to normal position. Activate the adjustment mode display of Fig. 1-1 and press the channel button (18) on the remote control to select "BRTC". Press the RIGHT/LEFT button on the remote control "A"...
  • Page 20 ELECTRICAL ADJUSTMENTS 2-18: Confirmation of Fixed Value (Step No.) White 0% Please check if the fixed values of the each adjustment items are set correctly referring below. FUNCTION STEP NO FUNCTION STEP NO OSD CONTRAST COL. AV(MIN) H.BLK L SUB BIAS 100% H.BLK R BRI.
  • Page 21 ELECTRICAL ADJUSTMENTS PURITY AND CONVERGENCE 3-3: STATIC CONVERGENCE ADJUSTMENTS NOTE Adjust after performing adjustments in section 3-2. NOTE Receive the crosshatch pattern from the color bar Turn the unit on and let it warm up for at least 30 generator. minutes before performing the following adjustments.
  • Page 22 ELECTRICAL ADJUSTMENTS 4. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (WIRING CONNECTION) CD803 CD802 CRT PCB CP803B CP802B TP022 J801 TP024 POWER PCB J3801 J4201 CP3001 FB401 CP402 CD3001 CP803A CP3802 CD805 D3824 CP802A CP401 SPEAKER CP403 CD3801 CP302 AC IN VR401 SPEAKER J2203 J2204...

  • Page 23: Dvd

    DVD ST SOLUTION BLOCK DIAGRAM 64M SDRAM FLASH IC4012 IC4007 IS42S16400-7T M29W160ET90N6 AD0~13, SMI_DQMU TV BLOCK ADDR1~20, F_OE/CE/ /CLK/DQML/WE/CAS WE/DQM0/RESET /RAS/CS0 MECHA VR-DVD/CD, CVBS LD-DVD/CD, DVD_Y LMD1/2, CD-DVD IRQ0,BB_V4,AFEC_EVALID, XDATA,XBCLK,XPCLK,XERROR DVD_C TR+/–, FO+/– Pick REFD, A, B, C, D, E, F RF AMP/DSP AUDIO L FE_RESET...

  • Page 24: Power

    TV BLOCK DIAGRAM RESET IC IC103 PST3231NR POWER TU001 ON/OFF OPEN/CLOSE MICON IC STOP IC101 OEC6072B X101 16MHz PLAY Q105 SKIP FF V-BUFFER 6 11 12 40 41 SKIP REW FROM DVD BLOCK CVBS DVD C DVD Y DVD_RESET R.OUT G.OUT V801 B.OUT...

  • Page 25: Power Block Diagram

    POWER BLOCK DIAGRAM SOUND+B UNREG+8V D3840~D3843 F3801 TRANSFORMER SWITCHING RECTIFIER AC IN T3802 IC3803 Q3810 Q3811, Q3812 PS2561L1-1-V(W) FEED BACK FEED BACK VR3802 UNREG+5V UNREG+12V VR3801 TRANSFORMER SWITCHING T3801 J3801 Q3808 DC JACK 11.3V REG OPE AMP PROTECTOR RY3801 IC3802 NJM2368D Q3806 RELAY DC POWER...
  • Page 26 PRINTED CIRCUIT BOARDS DVD (TOP SIDE) DVD (BOTTOM SIDE) D8507 R4128 R4119 R4124 Q4001Q4002 IC4007 W818 W838 R4118 W837 R4144 R4018 R4123 Q8503 X4001 R4120 Q8508 R8506 R4146 R4125 Q8507 R4017 Q8502 Q8506 IC4003 R4073 R4117 R4135 IC4012 L4003 Q8501 R4131 R4069 R4067...
  • Page 27 PRINTED CIRCUIT BOARDS AV/CRT (INSERTED PARTS) SOLDER SIDE CP301 IC301 C2204 CP8001 CP8002 W068 Q3002 R303 W046 IC3005 S803Y R301 W031 C130 W047 W090 L3001 W048 W839 W059 S803X C303 W060 W158 R3001 R3002 W061 SW2220 R3003 W168 R346 Q3006 R2201 Q3009 W102...
  • Page 28 PRINTED CIRCUIT BOARDS AV/CRT (CHIP MOUNTED PARTS) SOLDER SIDE Q403 R816 Q601 R632 Q605 Q602 R142 R634 R622 Q4201 R4246 R611 R610 R125 R608 R103 Q106 R150 IC4202 IC103 R115 IC902 Q105 IC903 IC904 R916 Q4206 R4229 R147 Q4207 R4239 Q901 R4240 R323...
  • Page 29 PRINTED CIRCUIT BOARDS POWER SOLDER SIDE R3800 D3840 IC3803 R3832 R3814 D3841 S3802 R3833 C3833 CD3801_1 D3843 F3801 FH3801 FH3802 Q3810 D3804 W001 D3842 C3829 C3828 L3802 C3834 R3829 R3828 R3830 W865 R3826 S3801 C3806 Q3803 R3835 R3837 D3849 R3843 B3806 IC3802 Q3812...
  • Page 30 RF AMP/DSP SCHEMATIC DIAGRAM (DVD PCB) DVD LOADER DK4001 CV-VLM102 VCC5 JG2004 JG2001 JG2002 R2043 R2065 FFC(P=0.5mm) CD2001 2H0O1902 CD_LD_CTL R2028 DVD_LD_CTL R2010 Q2006 FROM/TO MPEG Q2001 2SA1036K LCD_CTL 6.8K 6.8K 2SA1036K LD_CTL Q2008 Q2003 FE_RESET KTC3875S_Y_RTK R2031 KTC3875S_Y_RTK FROM/TO LOADER JG2009 C2065_1 6.3V...
  • Page 31 MOTOR DRV SCHEMATIC DIAGRAM (DVD PCB) R2314 R2313 W808 HS2301 763WSA0023 W806 TO LOADER CP2302 00_6232_004_102_800 FROM/TO RF_AMP/DSP ST1+ C2328_1 ST1- ST2+ 6.3V ST2- OPN_SW C2305 C2306 C2309 PSMUTE 0.1 B SBMUTE 0.1 B 0.1 B R2303 SPD_FG REFDAC SLD1 R2311 SLD2 C2329_1...
  • Page 32 MPEG SCHEMATIC DIAGRAM (DVD PCB) L4003 22uH 0305 R4138 JG4050 TRST R4139 JG4051 CLOCK_GENERATOR IC R4140 JG4052 IC4003 SN74AHCU04PWR FROM/TO MEMORY R4141 JG4053 R4142 JG4054 F_CE F_WE/DQM0 JG4055 JG4034 F_OE JG4036 JG4056 DATA0 JG4035 DATA1 JG4037 R4125 DATA2 JG4026 DATA3 JG4020 C4003 DATA4...
  • Page 33 MEMORY SCHEMATIC DIAGRAM (DVD PCB) 64M SDRAM IC IC4007 IS42S16400-7T FLASH IC C4056 IC4012 M29W160ET90N6 ADDR17 ADDR16 DQ15 DQ15 C4061 ADDR15 BYTE VSSQ VDDQ FROM/TO MPEG ADDR14 DQ14 DQ14 F_CE F_WE/DQM0 DATA15 ADDR13 DQ13 DQ15/A-1 F_OE DQ13 DATA0 C4052 DATA1 DATA7 ADDR12 VDDQ...
  • Page 34 AUDIO/VIDEO SCHEMATIC DIAGRAM (DVD PCB) FROM REGULATOR2 D_GND B8501 VCC+9V FCM2012H-102T04 P.CON+5V P.CON+3.3V W839 Y_V_OUT C8504 22P CH BUFFER Q8501 L8501 R8505 Y_VIDEO KTA1504S_Y_RTK 2.2uH 0305 C8515 W844 C_V_OUT 22P CH BUFFER L8502 R8520 C_VIDEO Q8502 2.2uH 0305 KTA1504S_Y_RTK FROM/TO MPEG Y_VIDEO C_VIDEO CVBS_VIDEO...
  • Page 35 REGULATOR2 SCHEMATIC DIAGRAM (DVD PCB) W825 D8510 MCL4148 LEVEL_CONVERT Q8505 KTC3875S_Y_RTK FROM/TO REGULATOR1 200mm CD8505 (CP8001) CU2B2001 TO MOTOR DRV P.CON+A5V M_GND GND(M) R8537 P.CON+9V P.CON+9V L8507 1/2W P.CON+A5V P.CON+5V R8538 2.2uH 0305 W871 P.CON+3.3V B8505 1/2W P.CON+3.3V W870 W4BRH3.5X6X1.0X2 D_GND SPDIF SPDIF...
  • Page 36 REGULATOR SCHEMATIC DIAGRAM (AV PCB) FROM POWER CP3001 (CP3803) B2013H02-8P SOUND_GND SOUND GND SOUND+B TO SOUND AMP SOUND+B UNREG+5V UNREG+5V SOUND+B UNREG+5V POWER_FAIL P.FAIL SOUND_GND UNREG+12V UNREG+12V UNREG+8V UNREG+8V 5VREG. IC UNREG+12V IC3001 KIA7805API 3.3V OUT Q3003 UNREG+8V KTB1366 DRIVER 3.3V CTL Q3012 Q3006...
  • Page 37 MICON /TUNER SCHEMATIC DIAGRAM (AV PCB) TU001 115-V-K015AR_B FROM/TO IN/OUT 0.45 3.12 4.98 C006_1 C002 6.3V I2C_OFF 0.1 B REMOCON KEY_A D106 R150 R151 KEY_B MTZJ10B POWER_ON_H 1/4W EXT_MUTE Q106 KTA1504S_Y_RTK RESET IC IC103 PST3231NR FROM/TO CHROMA R140 X101 OSD_Y R144 1002T01606 D101...
  • Page 38 CHROMA SCHEMATIC DIAGRAM (AV PCB) FROM/TO REGULATOR1 DVD_VIDEO DVD_Y DVD_C UNREG+12V P.CON+5V P.CON+9V AT5.7VREG 8.5VREG R625 FROM/TO DEFLECTION V.OUT H.OUT C4227 R632 C628 FROM/TO IN/OUT CHROMA IC 0.47 W861 DVD_VIDEO IC601 LA76319M-MPB-E VIDEO_OUT FRONT_VIDEO W827 C622 W832 R620 CLMP APC1 1.5K 1/4W VIDEO CLMP...
  • Page 39 SOUND AMP SCHEMATIC DIAGRAM (AV PCB) HS301 763WAA0233 L CH CP301 SP301 SPEAKER TID-X02P-B2 SA08A05BWC SP OUT L+ 8 OHM SP OUT L- R CH CP302 SPEAKER TID-X02P-B2 SP OUT R+ 8 OHM SP OUT R- FROM REGURATOR1 SP302 SOUND+B SA08A05BWC FROM/TO IN/OUT SOUND_L+...
  • Page 40 IN/OUT SCHEMATIC DIAGRAM (AV PCB) AT+5.6V OS2202 PIC-37143SY-H REMOCON Vout R2202 AT+5.6V 1/4W FROM/TO STEREO C4201 R4203 AUDIO_OUT_L 560 1/4W C4202 R4204 AUDIO_OUT_R 560 1/4W DVD_AUDIO_L POWER_ON_H DVD_AUDIO_R FRONT_A_IN_L Q2201 R4206 FRONT_A_IN_R DTC124EKA R2214 R2216 R2218 R2220 R2221 KEY_A 10K 1/4W MUTE SW L4202 Q4205...
  • Page 41 STEREO SCHEMATIC DIAGRAM (AV PCB) W862 W868 C920 W867 C940 C942 C922 W871 BUFFER C949 Q901 12.3 12.3 KTA1504S_Y_RTK BUFFER C948 Q902 KTA1504S_Y_RTK L904 D901 FROM/TO MICON/TUNER 100uH 0305 1SS133 TUNER_AUDIO R911 100 1/4W R912 1/4W TO SOUND AMP R908 P.CON+12V_A A_OUT_L A_OUT_R...
  • Page 42 DEFLECTION SCHEMATIC DIAGRAM CP403 (AV PCB) A1561WV2-2P DEGAUSS COIL L3800 8R090008 V.OUTPUT IC W888 IC401 AN5522 THERMAL PROTECTION R427 PUMP UP 3.9K 1/4W DEGAUSE SW Q403 KRA102SRTK 25.5 12.9 24.8 W884 FROM/TO MICON/TUNER TO DY CP401 POWER_ON_H B04B-DVS X-RAY C423 +30V 250V 0.27...
  • Page 43 CRT SCHEMATIC DIAGRAM FROM CHROMA CP802B (CP802A) CRT PCB) B2013H02-6P CLAMP G.OUT R.OUT B.OUT CLAMP_OFF FROM DEFLECTION CP803B (CP803A) B2013H02-4P HEATER FROM/TO DEFLECTION CP801 (CD805) A2361WV2-2P 120.0 122.0 115.0 RED AMP GREEN AMP BLUE AMP Q804 Q805 Q806 KTC3207 KTC3207 KTC3207 C804 160V...
  • Page 44 POWER SCHEMATIC DIAGRAM (POWER PCB) DC JACK RY3801 ALKS325 J3801 D3812 HEC0824-010010 MTZJ6.2B PROTECTOR/AC,DC SW DC POWER SW Q3802 Q3808 PROTECTOR DC POWER SW. KTC3209_Y Q3803 KRC102MAT Q3806 10.9 KRC102MAT KTC3198 R3822 L3803 AC_H 100 1/4W HF70T22*10*14 D3803 MTZJ10B W822 DC_PROTECT C3819_1 FROM DEFLECTION...
  • Page 45 INTERCONNECTION DIAGRAM COMMAND TRANSMITTER TM601 H1 H2 H1 H2 Vout CP3803 CP3001 PCB020 SOUND GND SOUND GND VPB164 SOUND+B SOUND+B CVBS/AUDIO/D.OUT UNREG+5V UNREG+5V OS2202 WHITE J4201 YELLOW CP2001 CD2001 DVD PCB FRONT VIDEO JACK FRONT AUDIO JACK FRONT AUDIO JACK PCB130 J2203 J2204...

  • Page 46: Mpeg

    WAVEFORMS MICON/TUNER RF_AMP/DSP POWER ON 10µs 100ns 0.2ms 100mV 100mV POWER ON 20ns 10µs 0.2ms 200mV 200mV MOTOR DRIVE POWER ON 500µs 0.2ms 500mV MPEG POWER ON 20ns 500µs 500mV 500mV AUDIO/VIDEO REGULATOR 2 POWER ON 10µs 100ns 50µs 200mV 500mV NOTE: The following waveforms were measured at the point of the corresponding...

  • Page 47: Chroma

    WAVEFORMS CHROMA IN/OUT POWER ON DVD PLAY POWER ON 20µs 10ms 0.5ms 0.5V 0.5V 200mV STANDBY POWER ON DVD PLAY 0.5µs 20µs 0.5ms 50mV 0.5V 200mV STEREO POWER ON POWER ON POWER ON 10µs 20µs 50mV SOUND AMP POWER ON POWER ON POWER ON 10µs...

  • Page 48: Deflection

    WAVEFORMS DEFLECTION POWER ON POWER ON 20µs POWER ON 20µs POWER ON 20µs POWER ON 20µs NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.

  • Page 49: Mechanical Exploded Views

    MECHANICAL EXPLODED VIEW PCB110 (CRT PCB ASS'Y) SP301 101F 101C 101E 101B 101D SP302 101A I1-1...
  • Page 50 MECHANICAL EXPLODED VIEW PCB020 (POWER PCB ASS'Y) PCB130 (DVD PCB ASS'Y) 209 119 PCB250 (AV PCB ASS'Y) I1-2...

  • Page 51: Mechanical Replacement Parts List

    MECHANICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION A5G607I720 CABINET,FRONT ASSY 101A 701WPJC360 CABINET,FRONT 101B 713WPA0160 GUIDE,REMOCON 101C 713WPA0161 GLASS,LED 101D 735WPBA822 BUTTON,FRAME 101E 738WPAA010 BUTTON,BASE 101F 800WQ00056 FELT, SHEET 100x5xT0.3 A5G607I740 CABINET,BACK ASS'Y 702WPAA473 CABINET,BACK 7232020746 SHEET,IC 753WSA0159 SHIELD,TV MAIN PCB 761WSA0115 ANGLE,DECK 800WB0A008 FIBER WASHER 899EFBA001 WIRING CLIP...

  • Page 52: Electrical Replacement Parts List

    ELECTRICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION RESISTORS DIODES ! R401 R3X28A331J R,METAL OXIDE 330 OHM 2W D2001 DDARDS1210 DIODE SILICON KDS121RTK ! R402 R3X28A391J R.METAL OXIDE 390 OHM 2W D2002 DDARDS1200 DIODE SILICON KDS120RTK ! R415 R4X5T44R7F R,METAL...
  • Page 53 ELECTRICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION TRANSISTORS ! IC3802 I0QD023680 NJM2368D Q8502 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK ! IC3803 000220001W PHOTO COUPLER PS2561L1-1-V(W) Q8503 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK IC4002 I5PK055890 STM5589AVA Q8505 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK IC4003 I5CF0CU040...
  • Page 54 ELECTRICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION RESISTOR MISCELLANEOUS RC....CARBON RESISTOR B3801 024HT03564 CORE,BEADS W4BRH3.5X6X1.0 B3802 024HT03564 CORE,BEADS W4BRH3.5X6X1.0 CAPACITORS B3803 024HT03553 CORE,BEADS W5RH3.5X5X1.0 CC....CERAMIC CAPACITOR B3804 024HT03553 CORE,BEADS W5RH3.5X5X1.0 CE....ALUMI ELECTROLYTIC CAPACITOR B3805 024HT03563 CORE,BEADS W4BRH3.5X6X1.0X2 CP....
  • Page 55 M5G6-07I SPEC.NO. O/R NO. W375035...
