- Page 1 CleanView ™ B A G L E S S P O W E R T R A K ™ plus U S E R ’ S G U I D E 3593 SERIES – 220/240V Safety Instructions Product View Assembly Instructions Operation / Special Tools 9-12 Maintenance...
- Page 2 Vacuum. Everything we know about floor care went into the design and construction of this complete, high-tech home vacuuming system. Your BISSELL CleanView Bagless Power Trak Plus is well made, and we back it with a limited comprehensive two-year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Services Department, so, should you ever have a problem, you’ll receive fast, considerate assistance.
-
Page 3: Important Safety Instructions
Not intended for use by young children or infirm the carrier contained in the plug. (Spares may be persons without supervision. obtained from your BISSELL supplier). If for any ■ Young children should be supervised to ensure that reason the plug is cut off, it must be disposed they do not play with the appliance. - Page 4 Handle Cord Clip Hose Clip Stretch Hose Carrying TurboBrush ™ Handle Quick Release ™ Cord Wrap Crevice Tool Power Cord Power Switch Quick Reach ™ Handle Clean Filter Upper Tank Knob Indicator Louvers Extension Wand Hose Wand Upper Tank Frame and Filter Dusting Brush/ (Inside Louvers) Hose...
-
Page 5: How To Use This Guide
Familiarize yourself with the parts and where they fit. Following this User’s Guide will greatly enhance your ability to get the most performance from your BISSELL CleanView Bagless Power Trak Plus for many years. How To Put It Together The only tool you’ll need to assemble your vacuum... -
Page 6: Attach Vacuum Hose And Tools
Attach Vacuum Hose and Tools Position the Twist ‘n Snap Hose assembly on the back of the vacuum. Line up the tabs on the base of the Twist ‘n Snap Hose with the corresponding notches on the hose collar as shown. Turn the Twist ‘n Snap Hose to the right to lock the hose into place. -
Page 7: Handle Positions
How To Use Your Vacuum Handle Positions Press the Handle Release Pedal with your foot to place your vacuum into one of three cleaning positions. Upright- For storage and above floor cleaning with tools. Normal Cleaning- Press Handle Release Pedal once. Use for most household floor cleaning tasks. -
Page 8: Special On-Board Tools
Clean Filter Indicator The Clean Filter Indicator tells you when airflow in the vacuum is reduced due to dirty Filters or a clog in the hose. The Clean Filter Indicator will remain green until the airflow is reduced. At that time, it begins to change to red. -
Page 9: Power Cord Storage
Power Cord Storage When you are done using your vacuum, return it to the Upright position and store the Power Cord. Turn vacuum cleaner OFF. Unplug Power Cord by grasping the plug (NOT the cord) and disconnect from outlet. Loop Power Cord around Cord Wraps on side of vacuum cleaner. - Page 10 Cleaning The Upper Tank & Filter Use only BISSELL Style 7 Replacement Upper Tank Filters in your CleanView Bagless Power Trak Plus. Unplug the cleaner from electrical outlet. The Upper Tank Filter can be reached by removing the Dirt Container, reaching underneath the Upper Tank and turning the rim of the Filter Frame to unlock.
-
Page 11: Replace Drive Belt
Check Air Passageway for obstructions. Remove debris from this area. Replace Drive Belt Air Passageway Use only BISSELL Style 7 Replacement Belts in your CleanView Bagless Power Trak Plus. Unplug cleaner from electrical outlet. With Rotating Floor Brush removed from vacuum cleaner (Steps 1-4 of check Rotating Floor Brush and Drive Belt), grasp old Drive Belt and remove from Motor Pulley. -
Page 12: Clearing Clogs
Maintaining TurboBrush The TurboBrush should be checked regularly for clogs or debris wrapping around the brush roll. Unplug vacuum from electrical outlet. If a clog is present or debris is visible, unscrew the two screws on the back of the TurboBrush to remove the faceplate and clear any obstructions. -
Page 13: Troubleshooting
Check Upper Tank, Pre-Motor and Post-Motor Filters for correct installation Dirt Container installed incorrectly Pull out and re-insert Dirt Container correctly If suggested solutions for this or any function of the CleanView Bagless Power Trak Plus do not correct the problem, call BISSELL Consumer Services. - Page 14 If your BISSELL product should require service: In the UK call BISSELL Consumer Services at the number below and we will give you the location of a BISSELL Authorized Service Center in your area. For all other countries contact your local in country distributor for questions, service, or repair.
- Page 15 Replacement Parts – BISSELL CleanView Power Trak Plus Item Part No. Part Name 32074 Style 7/9/10 Drive Belt - 2 Pack 203-1063 Crevice Tool 203-1228 Dusting Brush/Upholstery Tool 203-1227 TurboBrush 203-6624 Stair Cleaning Tool (Optional Item) 203-1084 Extension Wand 203-2035 Wire Reinforced Twist ‘n Snap Vacuum Hose Clear...
-
Page 16: Limited Two Year Warranty
Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, BISSELL Homecare, Inc., will replace (with new or remanufactured components), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for two years any defective or malfunctioning part do to manufacturers defect.
