SERVICE MANUAL
Ver 1.2 2004. 05
This set is the speaker system in
MHC-V5500/V7700AV.
Sony Corporation
9-920-980-13
2004E04-1
Home Audio Company
© 2004. 05
Published by Sony Engineering Corporation
SPECIFICATIONS
Speaker system
4-way, 5 unit bass-reflex type
Speaker units
Woofer
Centes Tweeter : 3 cm dia, cone type
Side Tweeter
Super Tweeter
Nominal impedance 6 ohms
Approx. 220 × 410 × 335 mm (w/h/d)
Dimensions
Mass
Approx. 6.1 kg
net per speaker
Design and specifications are subject to change without notice.
SS-V5500
Chinese Model
: 17 cm dia, cone type
: 5 cm dia, cone type × 2
: 2 cm dia, dome type
SPEAKER SYSTEM
E Model
