DM-III Multitest Power Quality Recorders
Features: • True RMS (TRMS) • Measures
and records broad spectrum of power quality
parameters: AC current, AC voltage to 600V
including sags and surges, harmonics (THD
and individual up to 49th), active, reactive and
apparent power and energy, peak demand,
power factor, frequency measurement and
phase sequence • Works with single and three
phase systems • Detects and records voltage
anomalies, sags and surges • Built in scope
displays waveforms • Phase sequence indication
• Records up to 64 parameters simultaneously
• Man ual and programmable recording start • Line
or battery powered • Megohmmeter functions: test insulation of wires, cables,
transformers and electrical motors • Safety ratings: CAT III 600V phase to
phase, CAT III 300V phase to ground
Includes: • CTs • Voltage leads • Ground probes and leads • PC software
and download cable
705-1026-ND
(DM-III MULTITEST F) . . . . . . . . . . . . . . . . . . . . . . . . . . $3484.20
DM-4 Power Quality Recorder
Features:
• True RMS (TRMS) • Works with single (two and
three wire) and three phase systems (Y and Delta)
• Detects and records voltage spikes 100nS or slower
• Detects and records voltage sags and surges • Built
in scope displays waveforms • Records all parameters
simultaneously • Manual and programmable recording
start • Safety rating: CAT III 600V
Includes:
• Carrying case • CTs • Test leads • PC software and
download cable • Remote User Interface (PDA) with
protective hard case and interface cable
705-1024-ND
(DM-4) . . . . . . . . . . . . . . . . $3695.68
DGC-1000A Clamp-on Ground
Resistance Tester
Features:
• Accurate ground resistance measurement from
0.025Ω ~ 1500Ω • TRMS current measurement
• Continuity beep if the resistance is lower than 40.00Ω
• Data logging capability: 116 records • Individual
data point recording • User selectable high and low
Ω audible alarms • Auto power off • Low battery
indicator • Large LCD display • Safety rating: CAT III
300V, CAT II 600V
705-1023-ND
(DGC-1000A) . . . . . . . . . $1479.33
TMULD-300 Leak
Detector Kit
Features: • Locates arcing in an electrical
system • Transmitter "pressurizes" area
with ultrasonic sound enabling the ULD-
HIGH
LOW
300 to pinpoint leaks • Applications include
air tightness of cars or houses • Useful
X1
X10
X100
in finding the ends of buried PVC pipes
BATTERY
GREEN-OK
RED-LOW
• Detects any pressurized gas leak regardless
of type CFC's, HFC's, Nitrogen, etc.
Includes: • Ultrasonic transmitter • Flexible
tubing adapter • Tubular extension • Pa rabola
• Headphones
705-1037-ND
(TMULD-300) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $422.92
TH-2A Digital
Thermo Hygrometer
Features:
• Temperature readings
• Relative humidity measurement
• Max/Min with time stamp
• Data hold function
• Selectable °C and °F readout
• Dual LCD display with bargraph indication
• Auto power off
705-1033-ND
(TH-2A) . . . . . . . . . . . . . . $84.54
THWD-2 Digital Sling
Psychrometer
Features:
• Temperature readings
• Relative humidity measurement
• Dew point and wet bulb readings
• Max/Min with time stamp
• Selectable °C and °F readout
• Data hold function
• Dual LCD display with bar graph indication
• Auto power off
705-1034-ND
(THWD-2) . . . . . . . . . . . . . . $116.26
All prices in Canadian dollars and include duty and brokerage fees.
RC-120S Remcon Relay Switch
Features:
• Switches AC power ON and OFF using low voltage
control circuit • Built in transformer, no step down
AMPROBE
DM-III MultiTest
R
transformers necessary • Single relay can be controlled
by multiple switches and multiple relays can be
controlled by a single switch • AC voltage from 105V ~
125V • AC current up to 6.5A
705-1032-ND
(RC-120S) . . . . . . . . . . . . . . . . . . . . . . $42.24
3Ø Power Quality Recorder
Ground Resistance Tester / Megohmmeter
F1
F2
F3
F4
INSULATION
TEST
LOW Ω
GROUND
TEST
Start
Stop
PRM-3 Phase Sequence and
HOLD
SAVE
ENTER
POWER
QUALITY
MENU
ESC
Motor Rotation Tester
Features:
• Use for phase sequence
testing, three phase motor
installation and maintenance
• Checks motors for rotation
direction • Identifies the
phase sequence of the three
phase electrical system
• Indicates normal or
reversed phases as well as
loss of the phase
705-1031-ND
(PRM-3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $105.69
12V
RS232
GP-2 Ground Resistance and
IR
AMPROBE
R
DM-4
Power Quality Recorder
Resistivity Tester
ON/OFF LED
STATE
RECORD LED
Unit-ON-AC Power
Green Solid
Unit-ON-Battery Power
Red Solid
Record
Low Battery
Slow Blink
Low Memory
Fast Blink* - Urgent message, connect to recorder immediately!
Note: Allow 10 seconds of start-up time (Fast Blink), after unit is turned on.
Features:
MAX
1V~
RESET
• Measure earth ground resistance; 3 point or 2 point
ON/OFF
I1
I2
I3
tests • Automatically calculates resistivity; 4 point
RECORD
test • Automatic voltage measurement prevents false
!
CAT III 600V/CAT II 1000V
V1
V2
V3
COM
measurements • Automatically applies three testing
frequencies for the most accurate readings • Auto
ranging • 999 internal memory locations to store
measurements • RS-232 download to a personal
computer • Safety rating: CAT III 250V
Includes:
• Test leads • Auxiliary electrodes • Software • Carrying Case
705-1027-ND
(GP-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $1585.07
Megohmmeters
AMB-25
Features:
• Test insulation of wires, cables, transformers and
motors • Comes as a complete kit including test
leads • Internal memory
Specifications:
• Insulation resistance with 250, 500 and 1000 VDC
test voltages: 0 ~ 4.000 / 40.00 / 400.00 / 4000MΩ
• Resistance: 0 ~ 9999Ω
AMB-45
Features:
10
• Test insulation of wires, cables, transformers
8
6
and electrical motors • Comes as a complete
POWER
4
HIGH
kit including test leads and PC software • Pro-
MED
2
LOW
grammable timer • Internal memory • Safety rating:
OFF
ON
CAT III 600V
Specifications:
ULTRASONIC
ULTRASONIC
TRANSMITTER
LEAK DETECTOR
Model
MODEL
UT-300
ULD-300
• Insulation resistance with 250, 500 and 1000 VDC
test voltages: 0 ~ 4.000 / 40.00 / 400.00 / 4000MΩ
• Re sistance: 4000Ω • AC/DC Voltage: 600.0V
AMC-2
Features:
• Test insulation of wires, cables, transformers
and electrical motors • Does not require
batteries or any external power supply, always
ready for use • Ohmmeter
%RH
Specifications:
ºF
• 500VDC Test Voltage: 0 ~ 100MΩ ±5% Rdg
@ (0.1 ~ 50MΩ) ±10% Rdg @ > 50MΩ
MX/MN
HOLD
%RH
°C/°F
TEMP
AMB-5KV-D
Features:
AMPROBE
R
TH-2A
i
• Test insulation of wires, cables,
Digital
Thermo
Hygrometer
transformers, electrical motors and
generators • Comes as a complete kit
including test leads and PC software
• Built in automatic voltmeter up
to 5000V warns against hazardous
energized systems • Programmable
setups of test voltages and timers
%RH
Specifications:
ºF
• Voltages: 100V ~ 5000V • Resistance: 100kΩ ~ 500GΩ • Voltmeter: 0 ~
MX/MN
HOLD
5000V ± (10% Rdg = 10 LSD) @ 0 ~ 500V ± (10% Rdg + 5 LSD) @ 500V ~
MEM
°C/°F
READ
5000V • Memory: 20 programmable setup configurations
%RH
DEW
TEMP
WET
705-1014-ND
(AMB-25) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $317.17
AMPROBE
R
705-1015-ND
(AMB-45) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $475.79
THWD-2
i
Digital
Sling
705-1017-ND
(AMC-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $687.27
Psychrometer
705-1016-ND
(AMB-5KV-D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $2379.14
1-800-344-4539 • ca.digikey.com • 218-681-6674 • Fax: 218-681-3380
AT-1000 Advanced Tracer
Features:
• Trace energized lines up to 300VAC
or VDC • Trace unenergized and open
conductors • Identifies breakers and
REMCON
R
SOLID STATE
AMPROBE
fuses without powering down • Locates
R
A United Union Company
CAT . NO: RC - 120 S
U L
IND.
CONT.
THIS DEVICE GENERATES HEAT
EQ.
READ INSTALLATION INSTRUCTIONS!
R
shorts • Identifies wires in a bundle
9 57 B
120
VOLTS AC 60HZ
LISTED
6.5 AMPS RESISTIVE LOAD
PATENT NO.
6.5 AMPS TUNGSTEN LOAD
4,751,401
6.5 AMPS BALLAST LOAD
OTHERS
• Identifies control, alarm and telephone
1/4 HP MOTOR LOAD
PENDING.
system wiring • Traces coaxial cable
shield • Receiver range 1 to 3 feet from a
cable being traced
Includes:
• Receiver • Transmitter • Carrying case • 110V pigtail cordset • Alligator
clip cordset (2 pcs.) • CT-326 type adaptor
705-1018-ND
(AT-1000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $370.04
AT-3000 PRO Underground Hawk Buried Wire
A
B
C
!
and Pipes Tracer
CAT III 600V
V
PHASE to PHASE
50V to 600V~
PHASE
NORMAL
(ABC)
LOSS
Features:
LOW
BATTERY
REVERSE
• Locates underground energized
ON/OFF
AMPROBE
R
PRM-3
and de-energized wires, cables and
Phase Sequence & Motor
Rotation Tester
pipes • Depth measurement up to 10
feet • Visual (LCD) and audible (with
loudspeaker) indicators • Rugged
durable construction • Backlight
• Real Sound Technology - the sound
is derived from the signal radiating
R
GP - 2
GeoTest
from the cable or pipe • Ready for use
AMPROBE
with receiver, transmitter, connection
cable, ground stake and ground
cable • Allows user to pinpoint the
path of the underground traced object
• Weatherproof and drop resistant
AVG
DIST
EARTH
EARTH
3 WIRES
2 WIRES
RS
232
OFF
DISP
GO
705-1019-ND
(AT-3000 PRO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $2638.26
CLR
ESC
RCL
SAVE
TIF300HV Tic Tracer -
AC Voltage Detector
Features:
• Use to check fuses, break panels, power outlets,
transmission lines, etc.
• Safety rating: UL, CE and MSHA Approved
705-1035-ND
(TIF300HV) . . . . . . . . . . . . . . . . $73.97
m:
s
ME
M
RE
AD
AC
HOLD
K
705-1036-ND
48" Hot Stick (TIF410A) . . $105.69
M
VG
BT-250
Break'r Trac'r™
Features:
• Identifies circuit breaker location
• Works on all electrical systems from
90 to 250 VAC • Automatic sensitivity
MegaTest 1
adjustment • Quick and easy to use
• Extremely accurate reading always
finds the right breaker • Safety rating:
UL approved
Includes:
• Transmitter • Carrying case • Test leads
• Socket adapter
705-1022-ND (BT-250) . . . . . . . . $105.69
AT-4004/AT4005 Advanced Wire Tracers
AT-4005CON
AMPROBE INSTRUMENT
MODEL
MΩ : 1000V.
AMC-3
Ω : 6V.
OHMS
MEG-OHMS
MEG-OHM
OHM
Features:
• One universal transmitter; automatically switches to work with either
energized or non-energized systems • Receiver not position sensitive
• Traces live wires buried or hidden behind walls • Locates breakers, neutrals
and ground lines • Pinpoints shorts, ground faults and broken wires
• Clamp-on attachment injects signal for non-contact operation • Safety rating:
CAT III 600V
Includes:
• Hard carrying case • Receiver • Transmitter • 110V pigtail - banana plug
cord set • Alligator clip - banana plug cord set • Grounding test lead, 25 ft.
with alligator clip • Clamp-on transmitter accessory • Rechargeable battery
pack and battery pack recharger (AT4005CON Only)
705-1020-ND
(AT-4004CON) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $793.01
705-1021-ND
(AT-4005CON) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $951.63
AMPROBE
R
R-3000 PRO
R-3000 PRO
G-3000 PRO
ON
AUTO
SENSITIVITY
ADJUSTMENT
BT-250T
OFF
Transmitter for
Break'r Trac'r
Break'r
Use on 90-2250VAC
25/ 50/60 Hz Circuits
Trac'r
BT-250R
C
US
LISTED
CIRCUIT TESTER
AC circuit
82X5
breaker identifier
Made in the USA
Made in the USA
K
HI
CAT III 600V MAX
OPEN
MID
SHORT
LOW
MODE
SENSITIVITY
SIGNAL LEVEL
ON/OFF
ON/OFF
ON
LOW BATT
SIGNAL LEVEL
SIGNAL LEVEL
R
R
TRANSMITTER
RECEIVER
T-4000
R-4000
AMPROBE
R
AMPROBE
R
2189
(C081)
Advertisement
