- Page 1 SERVICE MANUAL (Basic Information) RS1211 C1211 CL1211 SPLIT SYSTEM AIR CONDITIONER Indoor Unit Outdoor Unit C1211 / CL1211 RS1211 8526481017700 REFERENCE NO. WM – 700703...
-
Page 3: Service Manual
SERVICE MANUAL RS1211 C1211 CL1211 (Basic Information) WM – 700703... -
Page 4: Special Precautions
IMPORTANT! When Transporting Please Read Before Starting Be careful when picking up and moving the indoor and out- This air conditioning system meets strict safety and operating door units. Get a partner to help, and bend your knees when standards. As the installer or service person, it is an important lifting to reduce strain on your back. -
Page 5: Table Of Contents
Table of Contents Page 1. OPERATING RANGE..........................2. SPECIFICATIONS............................. Unit Specifications ............................3. DIMENSIONAL DATA ..........................4. COOLING CAPACITY ..........................5. REFRIGERANT FLOW DIAGRAM....................... 6. ELECTRICAL DATA ..........................G Electrical Characteristics ........................G Electric Wiring Diagram........................WM – 700703... -
Page 6: Operating Range
1. OPERATING RANGE RS1211 / C1211 Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 95°F DB /71°F WB 115°F DB Minimum 67°F DB /57°F WB 67°F DB RS1211 / CL1211 Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. -
Page 7: Specifications
2. SPECIFICATIONS Unit Specifications Indoor unit RS1211 Model No. Outdoor unit C1211, CL1211 Cooling BTU/h 11,500 Capacity 3.37 Air circulation (High) cu. ft./min. Moisture removal (High) pints/h Phase, Frequency Single, 60 Voltage rating Available voltage range 103 to 127 Running amperes 11.2 Power input 1,200... -
Page 8: Dimensional Data
3. DIMENSIONAL DATA Indoor Unit: RS1211 25/36 opening) ceiling (For 23-7/32 2-3/4 25/32 2-3/8 19/32 19/32 7-11/16 10-5/8 18-11/16 19/32 4-11/32 2-3/4 2-3/4 1-3/16 11-13/32 24-13/32 8-7/32 6-7/64 WM – 700703... - Page 9 Outdoor Unit: C1211 / CL1211 4 × 15/32 dia. hole Air intake intake Air discharge Check port 23-15/16 2-3/8 1/4" narrow tubing service valve 29-17/32 2-1/4 1-3/16 9-27/32 1/2" wide tubing service valve WM – 700703...
-
Page 10: Cooling Capacity
4. COOLING CAPACITY 115V RS1211 / C1211 and CL1211 Rating Capacity: 11,500 BTU/H Air Flow Rate: 280 CFM Evaporator Condenser Ent. Temp. °F/(°C) Ambient Temp. °F/(°C) (23.9) (29.4) (35.0) (40.6) (46.1) 11,390 10,870 10,350 9,760 8,970 0.85 0.93 1.01 1.10 1.21... -
Page 11: Refrigerant Flow Diagram
5. REFRIGERANT FLOW DIAGRAM RS1211 / C1211 and RS1211 / CL1211 INDOOR UNIT RS1211 OUTDOOR UNIT C1211 Service valve Wide tube Accumulator O.D. 1/2" (12.7 mm) Evaporator Condenser Service valve Check port Narrow tube Capillary tube Drier O.D. 1/4" (6.35 mm) -
Page 12: Electrical Data
6. ELECTRICAL DATA G Electrical Characteristics RS1211 / C1211 and RS1211 / CL1211 Indoor Unit Outdoor Unit Performance at Complete Unit 115V – 1ø – 60Hz Fan Motor Fan Motor Compressor 0.71 0.69 9.81 11.2 Rating Conditions 1,044 1,200 Locked-Rotor Amperes 1.15... -
Page 13: G Electric Wiring Diagram
G Electric Wiring Diagram WARNING: To avoid electrical shock hazard, be sure to Indoor Unit: RS1211 disconnect power before checking, servicing and/or cleaning any electrical parts. RS1211RW Power transformer Thermistor Switch assy IND lamp assy 1 2 3 Connector 1 2 3 2P (WHT) 1 2 3 Connector... - Page 14 Outdoor Unit: C1211 WARNING: To avoid electrical shock hazard, be sure to disconnect power before checking, servicing and/or cleaning any electrical parts. Terminal plate Capacitor Overload relay Fan motor Compressor motor WM – 700703...
- Page 15 Outdoor Unit: CL1211 WARNING: To avoid electrical shock hazard, be sure to disconnect power before checking, servicing and/or cleaning any electrical parts. Terminal plate Compressor motor Crank case Capacitor heater Relay (1) Thermistor TRANS Air sensor Coil sensor motor Capacitor POW-123CL WM –...
- Page 16 For parts or service contact SFS Corporation: 1200 West Artesia Blvd., Compton, California 90220 CORPORATION In Canada SANYO Canada Inc.: Toronto, Ont. M4H 1M6 H407/12M Printed in U.S.A. 1991/Nov./12M Printed in U.S.A. WM – 700703...
