American DJ FLASH 2C User Instruction

American DJ
1 2
FEATURES:
• THREE TRIGGER OPTIONS: AUDIO, MANUAL, AND AUTOMATIC
• PUSH BUTTON CONVENIENCE
• 19" RACK MOUNT, LED DISPLAY
• 4 FLASH PATTERNS: DOWN AND BACK, CRISSCROSS, BACK TO FRONT, AND FRONT TO
BACK
• SPEED AND RATE CONTROL

CONTROLS AND FUNCTIONS:

1. MASTER ON/OFF SWITCH - Press this button to switch the controller on and off.
2. LINE ON/OFF SWITCHES - These are on/off switches for the 4 flash tube lines.
3. BUTTON - This button will activate the down and back pattern.
4. BUTTON - This button will activate the crisscross pattern.
5. BUTTON - This button will make the flash tubes run from the last tube to the first tube in
6. BUTTON - This button will make the flash tube run from the first tube to the last tube in
7. SYNC BUTTON - Activates all 4 flash tube lines.
8. FLASH BUTTON - This button will activate the fastest speed and rate times.
9. AUTO BUTTON - This button will activate each flash tube line one-by-one. Starting with line 1,
10. MANUAL BUTTON - This button allows you to manually trigger flash tube runs. First press this
11. SPEED CONTROL - With this knob you can control the speed of the flash tube patterns.
12. AUDIO BUTTON - This button activates sound active mode.
13. RATE CONTROL - With this knob you can control the time of the flash in the flash tubes.
14. TRIGGER BUTTON - This will activate a run when the controller is in Manual mode.
®
FLASH 2C
3 4 5
the line.
the line.
then line 2, etc.....
button, and then press the trigger buttton to activate the runs.
© AMERICAN DJ® LOS ANGELES, CA 90058
USER INSTRUCTIONS
-
Flash Tube Controller
6 7 8 9 10 11 12 13 14
