Heat Alarm
9V
with
Alkaline
Battery
110-1146B
135°F (58°C) FIXED TEMPERATURE
MODEL ADHB
PLEASE READ AND SAVE
THIS MANUAL
Installer: Please leave this
manual with the product.
WARNING! Heat alarms are not life safety devices and are not designed to
detect smoke or fire. Heat alarms detect temperatures of 135°
or greater,
F
and are intended to be used as supplements to smoke alarms by provid-
ing early warning. See the IMPORTANT SAFETY INFORMATION section of
this manual.
HEAT ALARM FEATURES
This heat alarm is powered by a 9-volt alkaline battery.
Optional tamper-resist feature.
Unique “battery missing” lockout – heat alarm will not attach to
the mounting bracket if a battery is not in the battery pocket.
Improperly connected or weak battery signal – heat alarm will
sound a short beep once a minute if the battery is weak or
improperly connected.
Red LED indicates that the heat alarm is receiving power from the
battery and is working under normal operation, or in alarm.
Loud alarm horn—85 decibels at 10 feet—sounds to alert you
to an emergency.
Test button checks heat alarm operation.
SPECIFICATIONS
Model Number:
ADHB
Electrical Rating:
9 volt alkaline battery
U.L. temperature rating:
135°F (58°C) fixed temperature
U.L. Maximum ambient
temperature at unit:
100°F
Operating temperature:
-10°F to 158°F (-23°C to 70°C)
U.L. Recommended coverage: 2500 square feet (see Note A)
U.L. Recommended spacing:
50 feet
Maximum distance from wall:
25 feet (see Note B)
NOTE A: Maximum alarm coverage has been determined by UL to provide detection
time equal to sprinkler devices spaced at 10-ft intervals (100 square foot area) on a
smooth ceiling 15 ft 9 in. high. Higher ceilings can adversely affect detection time. In
some instances, earlier detection may be obtained by reducing the distance between
detectors. See the latest edition of the NFPA 72E, Automatic Fire Detectors.
NOTE B: Maximum distance is measured from any wall partition or ceiling projection
extending down more than 12 inches.
IMPORTANT SAFETY INFORMATION
PLEASE READ AND SAVE
THESE INSTRUCTIONS
!
W A R N I N G
This heat alarm requires a working 9-volt battery to operate
properly. This heat alarm WILL NOT work if the battery is
removed, drained or improperly connected. DO NOT use any
other kind of battery except as specified in this manual.
The Push-to-Test button accurately tests all heat alarm
functions. For temperatures that are below -10°F use a hand
held hair dryer and blow hot air into heat alarm to test. DO
NOT use any other test method. Test heat alarm weekly to
ensure proper operation.
This heat alarm should be installed only by a licensed,
qualified electrician. Observe and follow all local and national
electrical and building codes for installation.
Page 1
